Computational Science Series
PETASCALE COMPUTING: Algorithms and Applications
Edited by David A. Bader
PuBliSHED TiTlES
SERiES EDiToR
Horst Simon
Associate Laboratory Director, Computing Sciences Lawrence Berkeley National Laboratory
Berkeley, California, U.S.A.
AiMS AND SCoPE
This series aims to capture new developments and applications in the field of computational sci-ence through the publication of a broad range of textbooks, refersci-ence works, and handbooks. Books in this series will provide introductory as well as advanced material on mathematical, sta-tistical, and computational methods and techniques, and will present researchers with the latest theories and experimentation. The scope of the series includes, but is not limited to, titles in the areas of scientific computing, parallel and distributed computing, high performance computing, grid computing, cluster computing, heterogeneous computing, quantum computing, and their applications in scientific disciplines such as astrophysics, aeronautics, biology, chemistry, climate modeling, combustion, cosmology, earthquake prediction, imaging, materials, neuroscience, oil exploration, and weather forecasting.
P
etascale
c
omPuting
a
lgorithms and
a
PPlications
EditEd by
daVid a. Bader
Georgia institute of technology Atlanta, U.S.A.
Taylor & Francis Group
6000 Broken Sound Parkway NW, Suite 300 Boca Raton, FL 33487‑2742
© 2008 by Taylor & Francis Group, LLC
Chapman & Hall/CRC is an imprint of Taylor & Francis Group, an Informa business No claim to original U.S. Government works
Printed in the United States of America on acid‑free paper 10 9 8 7 6 5 4 3 2 1
International Standard Book Number‑13: 978‑1‑58488‑909‑0 (Hardcover)
This book contains information obtained from authentic and highly regarded sources. Reprinted material is quoted with permission, and sources are indicated. A wide variety of references are listed. Reasonable efforts have been made to publish reliable data and information, but the author and the publisher cannot assume responsibility for the validity of all materials or for the conse‑ quences of their use.
Except as permitted under U.S. Copyright Law, no part of this book may be reprinted, reproduced, transmitted, or utilized in any form by any electronic, mechanical, or other means, now known or hereafter invented, including photocopying, microfilming, and recording, or in any information storage or retrieval system, without written permission from the publishers.
For permission to photocopy or use material electronically from this work, please access www.
copyright.com (http://www.copyright.com/) or contact the Copyright Clearance Center, Inc. (CCC)
222 Rosewood Drive, Danvers, MA 01923, 978‑750‑8400. CCC is a not‑for‑profit organization that provides licenses and registration for a variety of users. For organizations that have been granted a photocopy license by the CCC, a separate system of payment has been arranged.
Trademark Notice: Product or corporate names may be trademarks or registered trademarks, and
are used only for identification and explanation without intent to infringe.
Library of Congress Cataloging‑in‑Publication Data
Petascale computing : algorithms and applications / editor, David A. Bader. p. cm. ‑‑ (Computational science series)
Includes bibliographical references and index.
ISBN 978‑1‑58488‑909‑0 (hardback : alk. paper) 1. High performance computing. 2. Petaflops computers. 3. Parallel processing (Electronic computers) I. Bader, David A. II. Title. III. Series.
QA76.88.P475 2007
004’.35‑‑dc22 2007044024
Visit the Taylor & Francis Web site at
http://www.taylorandfrancis.com
and the CRC Press Web site at
http://www.crcpress.com
Computational Science Series
Computational science, the scientific investigation of physical processes through modelling and simulation on computers, has become generally accepted as the third pillar of science, complementing and extending theory and experimen-tation. This view was probably first expressed in the mid-1980s. It grew out of an impressive list of accomplishments in such diverse areas as astrophysics, aeronautics, chemistry, climate modelling, combustion, cosmology, earthquake prediction, imaging, materials, neuroscience, oil exploration, and weather fore-casting. Today, in the middle of the first decade of the 21st century, the pace of innovation in information technology is accelerating, and consequently the opportunities for computational science and engineering abound. Computa-tional science and engineering (CSE) today serves to advance all of science and engineering, and many areas of research in the future will be only accessible to those with access to advanced computational technology and platforms.
Progress in research using high performance computing platforms has been tightly linked to progress in computer hardware on one side and progress in software and algorithms on the other, with both sides generally acknowl-edged to contribute equally to the advances made by researchers using these technologies. With the arrival of highly parallel compute platforms in the mid-1990s, several subtle changes occurred that changed the face of CSE in the last decade. Because of the complexities of large-scale hardware systems and the increasing sophistication of modelling software, including multi-physics and multiscale simulation, CSE increasingly became a team science. The most successful practitioners of CSE today are multidisciplinary teams that include mathematicians and computer scientists. These teams have set up a software infrastructure, including a support infrastructure, for large codes that are well maintained and extensible beyond the set of original developers.
The importance of CSE for the future of research accomplishments and economic growth has been well established. “Computational science is now indispensable to the solution of complex problems in every sector, from tradi-tional science and engineering domains to such key areas as natradi-tional security, public health, and economic innovation,” is the principal finding of the re-cent report of the President’s Information Technology Advisory Committee (PITAC) in the U.S. (President’s Information Technology Advisory Commit-tee,Computational Science: Ensuring America’s Competitiveness, Arlington, Virginia: National Coordination Office for Information Technology Research and Development, 2005, p. 2.)
As advances in computational science and engineering continue to grow at a rapid pace, it becomes increasingly important to present the latest research and applications to professionals working in the field. Therefore I welcomed the invitation by Chapman & Hall/CRC Press to become series editor and start this new series of books on computational science and engineering. The series aims to capture new developments and applications in the field of com-putational science, through the publication of a broad range of textbooks, ref-erence works, and handbooks. By integrating mathematical, statistical, and computational methods and techniques, the titles included in the series are meant to appeal to students, researchers, and professionals, as well as interdis-ciplinary researchers and practitioners who are users of computing technology and practitioners of computational science. The inclusion of concrete exam-ples and applications is highly encouraged. The scope of the series includes, but is not limited to, titles in the areas of scientific computing, parallel and distributed computing, high performance computing, grid computing, cluster computing, heterogeneous computing, quantum computing, and their appli-cation in scientific areas such as astrophysics, aeronautics, biology, chemistry, climate modelling, combustion, cosmology, earthquake prediction, imaging, materials, neuroscience, oil exploration, and weather forecasting, and others. With this goal in mind I am very pleased to introduce the first book in the series, Petascale Computing: Algorithms and Applications, edited by my good colleague and friend David Bader. This book grew out of a workshop at Schloss Dagstuhl in February 2006, and is a perfect start for the series. It is probably the first book on real petascale computing. At the beginning of an exciting new phase in high performance computing, just as we are about to enter the age of petascale performance, the chapters in the book will form an ideal starting point for further investigations. They summarize the state of knowledge in algorithms and applications in 2007, just before the first peta-scale systems will become available. In the same way as petapeta-scale computing will open up new and unprecedented opportunities for research in computa-tional science, I expect this current book to lead the new series to a deeper understanding and appreciation of research in computational science and en-gineering.
Berkeley, May 2007
Dr. Horst Simon
Series Editor Associate Laboratory Director, Computing Sciences
Over the last few decades, there have been innumerable science, engineering and societal breakthroughs enabled by the development of high performance computing (HPC) applications, algorithms, and architectures. These powerful tools have provided researchers, educators, and practitioners the ability to computationally translate and harness data gathered from around the globe into solutions for some of society’s most challenging questions and problems.
An important force which has continued to drive HPC has been a commu-nity articulation of “frontier milestones,” i.e., technical goals which symbolize the next level of progress within the field. In the 1990s, the HPC community sought to achieve computing at the teraflop (1012 floating point operations per second) level. Teraflop computing resulted in important new discoveries such as the design of new drugs to combat HIV and other diseases; simula-tions at unprecedented accuracy of natural phenomena such as earthquakes and hurricanes; and greater understanding of systems as large as the universe and smaller than the cell. Currently, we are about to compute on the first architectures at the petaflop (1015floating point operations per second) level. Some communities are already in the early stages of thinking about what computing at the exaflop (1018floating point operations per second) level will be like.
In driving towards the “<next frontier>-flop,” the assumption is that achiev-ing the next frontier in HPC architectures will provide immense new capacity and capability, will directly benefit the most resource-hungry users, and will provide longer-term benefits to many others. However, large-scale HPC users know that the ability to use frontier-level systems effectively is at least as important as their increased capacity and capability, and that considerable time and human, software, and hardware infrastructure are generally required to get the most out of these extraordinary systems.
Experience indicates that the development of scalable algorithms, models, simulations, analyses, libraries, and application components which can take full advantage of frontier system capacities and capabilities can be as chal-lenging as building and deploying the frontier system itself.
For application codes to sustain a petaflop in the next few years, hundreds of thousands of processor cores or more will be needed, regardless of proces-sor technology. Currently, few real existing HPC codes easily scale to this regime, and major code development efforts are critical to achieve the poten-tial of the new petaflop systems. Scaling to a petaflop will involve improving
physical models, mathematical abstractions, approximations, and other appli-cation components. Solution algorithms may need to be improved to increase accuracy of the resulting techniques. Input data sets may need to increase in resolution (generating more data points), and/or the accuracy of the input data for measured data may need to increase. Each application or algorithmic improvement poses substantial challenges in developing petascale codes, and may motivate new computer science discoveries apart from the new “domain” results of application execution.
This book presents efforts of the individuals who will likely be the first pio-neers in petascale computing. Aggregating state-of-the-art efforts from some of the most mature and experienced applications teams in high performance computing and computational science, the authors herein are addressing the challenging problems of developing application codes that can take advan-tage of the architectural features of the new petascale systems in advance of their first deployment. Their efforts in petascale application development will require intimate knowledge of emerging petascale hardware and systems software, and considerable time to scale, test, evaluate and optimize petascale codes, libraries, algorithms, system software, all on new systems that have yet to be built.
This is an exciting period for HPC and a period which promises unprece-dented discoveries “at scale” which can provide tangible benefits for both science and society. This book provides a glimpse into the challenging work of petascale’s first wave of application and algorithm pioneers, and as such provides an important context for both the present and the future.
Science has withstood centuries of challenges by building upon the commu-nity’s collective wisdom and knowledge through theory and experiment. How-ever, in the past half-century, the research community has implicitly accepted a fundamental change to the scientific method. In addition to theory and ex-periment, computation is often cited as the third pillar as a means for scientific discovery. Computational science enables us to investigate phenomena where economics or constraints preclude experimentation, evaluate complex models and manage massive data volumes, model processes across interdisciplinary boundaries, and transform business and engineering practices. Increasingly, cyberinfrastructure is required to address our national and global priorities, such as sustainability of our natural environment by reducing our carbon footprint and by decreasing our dependencies on fossil fuels, improving hu-man health and living conditions, understanding the mechanisms of life from molecules and systems to organisms and populations, preventing the spread of disease, predicting and tracking severe weather, recovering from natural and human-caused disasters, maintaining national security, and mastering nan-otechnologies. Several of our most fundamental intellectual questions also require computation, such as the formation of the universe, the evolution of life, and the properties of matter.
Realizing that cyberinfrastructure is essential to research innovation and competitiveness, several nations are now in a “new arms race to build the world’s mightiest computer” (John Markoff, New York Times, August 19, 2005). These petascale computers, expected around 2008 to 2012, will perform 1015 operations per second, nearly an order of magnitude faster than today’s speediest supercomputer. In fact several nations are in a worldwide race to deliver high-performance computing systems that can achieve 10 petaflops or more within the next five years.
While petascale architectures certainly will be held as magnificent feats of engineering skill, the community anticipates an even harder challenge in scal-ing up algorithms and applications for these leadership-class supercomputscal-ing systems. This book presents a collection of twenty-four chapters from some of the international researchers who are early thought leaders in designing appli-cations and software for petascale computing systems. The topics span several areas that are important for this task: scalable algorithm design for massive concurrency, computational science and engineering applications, petascale tools, programming methodologies, performance analyses, and scientific visu-alization.
The concept for this book resulted from a week-long seminar held at Schloss Dagstuhl, Germany, in February 2006, on “Architecture and Algorithms for Petascale Computing,” organized by Ulrich R¨ude, Horst D. Simon, and Peter Sloot. The Dagstuhl seminar focused on high end simulation as a tool for computational science and engineering applications. To be useful tools for science, such simulations must be based on accurate mathematical descrip-tions of the processes and thus they begin with mathematical formuladescrip-tions, such as partial differential equations, integral equations, graph-theoretic, or combinatorial optimization. Because of the ever-growing complexity of sci-entific and engineering problems, computational needs continue to increase rapidly. But most of the currently available hardware, software, systems, and algorithms are primarily focused on business applications or smaller scale sci-entific and engineering problems, and cannot meet the high-end computing needs of cutting-edge scientific and engineering work. This seminar primarily addressed the concerns of petascale scientific applications, which are highly compute- and data-intensive, cannot be satisfied in today’s typical cluster environment, and tax even the largest available supercomputer.
In addition to the contributing authors of this book, there are a few people I must mention by name who have influenced me and deserve a special thanks for their role in completing this book. First, I thank Uli R¨ude, Horst Simon, and Peter Sloot, for organizing an intensive Dagstuhl seminar that included a full week of stimulating discussion surrounding the challenges of petascale computing, and for giving me the opportunity to create this book as an out-come of this ground-breaking meeting. I give additional thanks to Horst, who serves as the Chapman & Hall/CRC Computational Science Series editor, not only for helping to shape this book, but also for sharing his insights and ex-pertise in computational science with me, for guiding me professionally, and for his great friendship. I am inspired by Horst’s dedication to computational science, his exuberance in high-performance computing, and his leadership in the community.
The development and production of this book would not have been possible without the able support and assistance of Randi Cohen, computer science ac-quisitions editor for Chapman & Hall/CRC Press. Randi brought this project from concept to production, and has been a wonderful colleague and friend throughout the process. She deserves the credit for all of the tedious work that made my job as editor appear easy. Randi’s warm personality made this project fun, and her advice significantly improved the quality of this book.
I would like to express my deep appreciation to my research group at Geor-gia Tech: (in alphabetical order): Virat Agarwal, Aparna Chandramowlish-waran, Manisha Gajbe, Seunghwa Kang, Kamesh Madduri, and Amrita Math-uriya. They are an amazing bunch of graduate students, and have assisted me with the preparation of this book by organizing the book chapters, reading various drafts of the chapters, and proofreading the manuscript.
Finally, I thank my wife, Sara Gottlieb, and my daughter, Sadie Rose Bader-Gottlieb, for their understanding as I tried, not always successfully, to combine family time with computer time during the preparation of the book.
High-performance computing will enable breakthrough science and engi-neering in the 21st century. May this book inspire you to solve computational grand challenges that will help our society, protect our environment, and im-prove our understanding in fundamental ways, all through the efficient use of petascale computing.
David A. Baderis Executive Director of High-Performance Computing and a Professor in Computational Science and Engineering, a division within the College of Computing, at Georgia Institute of Technology. He received his Ph.D. in 1996 from The University of Maryland, and was awarded a National Science Foundation (NSF) Postdoctoral Research Associateship in Experi-mental Computer Science. He is the recipient of an NSF CAREER Award and an IBM Faculty Fellowship Award, an investigator on several NSF awards, was a distinguished speaker in the IEEE Computer Society Distinguished Vis-itors Program, and a member of the IBM PERCS team for the DARPA High Productivity Computing Systems program. Dr. Bader serves as Director of the Sony-Toshiba-IBM Center of Competence for the Cell Broadband Engine Processor located at Georgia Tech. He is an elected member of Internet2’s Research Advisory Council, serves on the Steering Committees of the IPDPS and HiPC conferences, and has organized and chaired numerous conferences related to high-performance computing and computational science & engi-neering. Dr. Bader is an associate editor for several high impact publications including the IEEE Transactions on Parallel and Distributed Systems, the ACM Journal of Experimental Algorithmics, IEEE DSOnline, and Parallel Computing, a Senior Member of the IEEE Computer Society, and a Member of the ACM.
