Methods of Evaluation of the Positioning Capability

of Cartesian and Non-Cartesian Machines

Andrew Peter Longstaff

A thesis submitted to the University of Huddersfield

in partial fulfilment of the requirements for

the degree of Doctor of Philosophy

The University of Huddersfield

(3)

Abstract

Manufacture and assembly of ever more precise components has been the driving force for many research projects. Error avoidance and error correction are used to improve the

accuracy of the final output, but it is only by error evaluation that a manufacturer can

quantify his production capability.

The ability of a machine to perform the task designated to it is of critical importance. In particular it is essential to be able to determine the capability of a production machine to

produce a part accurately, a measuring machine to dimension a part reliably or a handling

machine to place a part in the appropriate position. In order to achieve this it is necessary to

establish the positioning accuracy of the device throughout its working volume.

In addition to the need for the assessment of machining performance, there is a

strong desire within the machine-building community to allow for the post-assembly

correction of errors inherent in the manufacture of machines. Such techniques are often a

cost-effective complement to error avoidance.

During this project, a new geometric model and supporting measurement methods

are produced for the evaluation of errors in Cartesian-based machines. This work is an

extension of that performed by Ford, et. al. Ell as discussed in chapter 3. The new work

addresses the previously unresolved problem of determining the errors throughout the

working volume of a machine with volumetric compensation and a tool or probe offset. This

simulation method is in contrast to other techniques that quantify machine performance

based upon a small subset of the machine volume.

It is proposed that a figure for volumetric accuracy derived from these methods

cannot stand on its own as a description of the manufacturing capability of a machine. The

effects of measurement uncertainty on the synthesis technique have been examined and

modelled. This has produced a method of quantifying machining capability based upon

machine configuration, tool or head configuration, and supported by uncertainty based upon

the test data input to the model.

An alternative method of evaluating errors through the working volume is to

measure directly using, for example, a tracking laser. One such system (LaserTrace) is

based upon absolute position being resolved by trilateration from two tracking lasers. This

system has been investigated for its applicability to the measurement process. Two methods

have been produced to improve the accuracy of the system and reduce the time required for

its calibration. One is based upon photogrammetry techniques, the other on a novel use of a

(4)

machine checking gauge (MCG). The artefact is used for acquisition of data to perform

parameter identification on a model of the system that has been found from first principles.

This MCG-based calibration technique was successful, within the constraints of the

resolution and repeatability of the control loop. Attempts were then made to apply this

methodology to a second machine of the non-Cartesian type and configuration (UMD).

Simulation shows this technique to be applicable, but the instability of the prototype

precluded comprehensive on-machine testing.

In the course of this research a thennal model of the UMD has also been produced to

overcome the sensitivity of the prototype device to temperature changes. Such a model

could be used to provide software correction of LTMD position values.

(5)

Acknowledgments

The author would like to thank Professor Derek Ford and Dr Mike Freeman for their

immense patience in supervising the project and providing support and guidance throughout

the duration of the work.

The author would also like to thank Dr Scott Postlethwaite for both his technical

expertise and encouragement whenever it was needed. His constant reminder of the reality

of how small a micron really is should not be ignored.

The author would also like to thank Steve Millwood for his technical and software

support. His supporting contribution has been invaluable for the majority of research work

within the team.

Thanks also to Mike Mavromiliales for his input in an advisory capacity.

Thanks also to the establishments who have provided both impetus and feedback for

many aspects of the work. In particular UK Robotics, Renishaw Plc, ITP, DS Technologie,

Rolls Royce and the various companies who allowed testing time on their production

machines.

Thanks also to the members of the two EC projects [2,3] who supported the work on Cartesian machine evaluation discussed in chapter 3 and chapter 4.

Finally, the author extends extreme gratitude to the members of his family, friends

and colleagues who have helped in many ways, both professionally and personally. Their

contribution is immeasurable.
