detecting
Solutions for detection of leading edges, occupancy, overhangs, end positions, fill levels, etc. make processes very stable at maximum performance. throughput max-imization depends on optimal precision tuning of all sensor functions. and SIcK has the right sensor for every task.
Measuring
light grids, camera systems, laser measurement systems and scales measure dis-tance, overhangs, profiles, volumes and weights. they allow efficient sorting, packing and picking, as well as process reliability through qualification.
detecting position
Sensors from SIcK ensure maximum positioning accurancy, reproducibility, speed and optimal cycle times. Its comprehensive portfolio of distance sensors, encoders and vision sensors allow optimal adaptation to the requirements of the respective application.
Identifying
Identification of codes and objects of all types is the basic requirement for automatic storage, picking and sorting. SIcK offers scalable systems for all code types and for all ID technologies (laser, camera, RFID, hybrid) that are easy to adapt to the respec-tive requirements.
taSKS In Storage and conveyor InduStry
Flexibility and cost-efficiency – the competitive
advantage in storage and conveyor systems
the storage and conveyor system plays a central role in in-tralogistics. Maximum throughput and optimal use of storage space is required. highly dynamic markets, innovative logis-tics processes and variable materials to be handled place high demands on flexibility. Sensor technology is a key factor. SIcK offers not only a complete sensor and service portfolio, but also has extensive industry knowledge, a total package with critical added value for the success of your storage and conveyor system.
read more about sensor solutions in the storage and conveyor industry g www.sick.com/storage-and-conveyor
protecting
In the area of safety, sensors, systems, solutions and services from SIcK ensure that safety requirements are met in compliance with applicable laws and standards. they provide efficient protection of hazardous areas, safe, ergonomic work stations and maximum system throughput.
Industry konwledge and knowing what the customer wants: You’ll benefit from the many years of experience and expertise from SIcK. We offer the right solution portfolio to solve your challenge – from individual products to fully equipped, integrated systems. our
sensors and sensor systems for storage and conveyor equipment and machinery are flexible and versatile. From pack-age and baggpack-age identification in the logistics business to the production of consumer goods or industrial vehicle parts, SIcK offers tailor-made solutions
for applications in your industry – giving you an advantage.
Storage and conveyor – the bIg pIcture
Guarantees best performance of machine portfolio:
cold store
•
package conveyor
•
pallet conveyor
•
pallet shuttle
pallet stacker
•
pallet handling machine
•
picking station
•
sorter
storage and retrieval system
•
tote shuttle
•
transfer car
•
etc.
Biggest sensor portfolio:
for optimal solutions for your
application
Holistic system solutions:
to support your industry
specific processes
SICK LifeTime Services:
for safety and productivity
Software solutions from SICK:
S t o r a g e a n d c o n v e y o r | S I c K 8016816/2013-12-19
the traveling unit is positioned by means of a distance sen-sor. high resolution and repeatability enable high speed and acceleration applications. Maximizing synchronicity permits ideal acceleration and braking cycles.
• long range distance sensors dx100
positioning the x axis on the travelling unit
StoRAGE AND REtRIEVAL SYStEM
g www.mysick.com/en/dx100
the data is transmitted between the storage and retrieval machine and the stock management system via infrared technology, using an optical transmission system. this does away with the need for fieldbus cabling. the device is available for a wide range of communication protocols. Fast transmission rates and extended sensing ranges ensure maximum performance.
• optical data transmission systems ISd400
g www.mysick.com/en/ISd400
Wireless data transmission on storage and retrieval machine
g www.mysick.com/en/dx35
g www.mysick.com/en/W27-3
before items are stored, a distance sensor uses an abso-lute value or multiple switching points to check whether the allocated storage area is free. even when faced with differing object colors, the reliable compact devices pro-vide high repeatability and immunity to ambient light.
• Mid range distance sensors DX35
empty bay detection in cases where totes are being stored at
several depth
Before the pallet is finally put into storage, a photoelectric retro-reflective sensor checks whether the load height exceeds the maximum permissible height for the allocated storage area. the sensor is characterized by a high level of resistance to vibrations and immunity to contamination.
• compact photoelectric sensors W27-3
verifying the loading height on the load-carring unit
State-of-the art automated storage and retrieval systems (ASRS) are highly dynamic and therefore place high de-mands on positioning accuracy, speed measurement and data transmission. In addition, the entire process must be error-free and safe during operation. the extremely reliable and powerful sensors guarantee process integrity when com-bined with an intelligent safety concept.
to ensure stable and error-free material flow, reliable, rugged sensors are re-quired for presence detection, overhang evaluation and height measurement of the pallets and their loads. automatic pallet identification solutions that use bar codes or RFID technology support the routing information and storage location assignment.
pallet conveyor
g www.mysick.com/en/W280L-2_Long_Range g www.mysick.com/en/Reflex_Array g www.mysick.com/en/MLG g www.mysick.com/en/clv62x g www.mysick.com/en/IQ40A Reflex Array sensor checks whether the loading station is free or occupied. the sensor ensures that pallets of different heights can be detected reliably. a longrange compact photo-electric background suppression sensor, which is immune to re-flections, checks whether there is a forklift truck at the station.
• Multitask photoelectric sensors Reflex Array
• compact photoelectric sensors W280l-2 long range
pallet loading
automation light grids measure the height of the load. In the event a storage area has a height restriction, his can be used to ensure a load will not violate this restriction. the light grids are available for all commonly used commu-nication protocols. A classification based purely on height can also be achieved using photoelectric retro-reflective sensors.
• Advanced automation light grids MLG
height measurement at I point
Bar code scanners with a fixed focus, variable focus or auto focus can be used for nearly any reading distance. they enable track and trace functions, product routing, and assignment to storage areas. thanks to the use of reconstruction technology, high read rates can be achieved even under adverse conditions or when bar codes are partially damaged.
• bar code scanners clv62x
Automated pallet identification with bar codes
a reliable inductive proximity sensor in a rectangular hous-ing signals to the control system when the final stop po-sition of the rotary table has been reached. an increased switching distance allows for greater flexibility in machine design.
• Inductive poximity sensors IQ40
rotational position of turntable
S t o r a g e a n d c o n v e y o r | S I c K 8016816/2013-12-19
pacKage conveyor
High throughput and a reliable, smooth flow of material are the core tasks of every pack-age conveying system. this requires precise presence detection and accurate speed measurement during the process. however, solutions for zero-pressure accumulation and automatic identification of totes and boxes that use bar code or RFID technology are also required. Fast and flexible mount-ing and wirmount-ing solutions reduce installation costs.
g www.mysick.com/en/Zonecontrol
g www.mysick.com/en/RFU62x
g www.mysick.com/en/IME08
g www.mysick.com/en/DFS60
conveying without dynamic pressure ensures a controlled flow of goods. the individual zones are controlled with photoelectric proximity sensors, either with or without a control unit. the photoelectric proximity sensors provide an optimum solution thanks to their minimal blind zone, low black/white shift, and reliable detection of dark objects.
• Multitask photoelectric sensors ZoneControl
conveying and zero pressure accumulation
Compact RFID read/write devices, which are optimized for logistics, feature an integrated antenna as well as a definable reading field. this ensures that RFID tags can be assigned correctly even when objects follow one another in quick succession. the devices are compatible with Id-proand can be integrated into industrial networks.
• RFID RFU62x
Automated tote identification with RFID
an inductive proximity sensor, which triggers on a proper target, monitors the lift end positionp. high resistance to shock and vibrations ensures maximum process reliability even under the toughest application conditions. a photo-electric retro-reflective sensor checks whether the corner conveyor is free.
• Inductive proximity sensors IME08
lift end position and occupied status on the right angle transfer
the conveying speed is controlled using the measured values of a programmable incremental encoder. With its high resolution, the encoder ensures maximum repeatabili-ty. there are numerous versions available to accommodate nearly all mechanical and electrical interfaces.
• Incemental encoders DFS60
SAFEtY
as one of the leading providers of safety technology, SIcK offers a comprehen-sive portfolio of products and systems for fulfilling safety requirements in com-pliance with legislation and standards. SIcK is also able to provide support via specialized services for complete safety solutions - from analysis to certified systems.
g www.mysick.com/en/M4000_Advanced_Curtain
g www.mysick.com/en/S3000_Standard
g www.mysick.com/en/eS21 g www.mysick.com/en/i150rp
vertical safety light curtains put the required safety func-tions into action. Flexible entry and exit monitoring is made possible through a switching amplifier and two or four muting sensors. these are connected directly at the site and reduce the amount of cabling required.
• Safety light curtains M4000 Advanced Curtain
access protection with muting
Safety laser scanners are used to prevent collisions and protect personnel. thanks to freely configurable warning and protective fields, plus the option of static inputs and encoder inputs, fields that are dependent on positioning and speed can be implemented for specific applications.
• Safety laser scanners S3000 Standard
protecting operating personnel and collision avoidance
at transfer cars
numerous standards and regulations govern the safety of operating personnel. SIcK offers emergency stop pushbut-tons and rope pulls that are proven components that con-form to standards, thus ensuring protection against risks.
• Safety command devices eS21, i150rp
Safety throughout the conveyor system
an inductive safety switch monitors the end position of the scissor lift table. the safety switch meets the requirements of various safety standards (such as en 62061 and en ISo 13849).
• non-contact safety switches In4000 direct, In3000 direct
end position monitoring at the scissor lift table
g www.mysick.com/en/IN4000_Direct g www.mysick.com/en/IN3000_Direct
