Elta Select Product Range 4th Edition

(1)

Elta Select

Product Range

4th Edition

t: 01384 275800

f: 01384 275810

visit: eltafans.com

MIXED FLOW

CENTRIFUGAL

ROOF MOUNTED

OTHER PRODUCTS

(2)

CENTRIFUGAL

MIXED FLOW

ROOF MOUNTED

OTHER PRODUCTS

AXIAL FLOW

Compact SCP

p8

Compact SCPA

p11

Compact SCD

p15

Compact SCDA

p18

Miniflow SAMF

p23

Multiflow SMB

p57

Multiflow SMC

p62

Multiflow SMT

p68

Jetflow SJ

p72

Hideaway SH

p78

Jetstream SJS

p84

Hideaway SHM

p89

Quietflow SQS

p92

Skyflow SSF

p121

Skyflow SSMF

p127

Miniflow SMF

p132

Singleflow

SSDR & SSBR p136

Twinflow

STDR & STBR p141

Window/Wall Fan

SAX

p162

Industrial Wall Fan

SPE

p164

In Wall SEIE p166

Thru Wall SEWE p168

Portacooler SPC

p171

Pedestal/Wall Fan

HPF/HWF

p173

Elta Select

Product Range

(3)

ACO Controllers

p182

Electrical Accessories

p184

Twinflow STDD &

STBD

p114

Biflow SB (CON)

p45

Smokevent SLCS

p51

CENTRIFUGAL

MIXED FLOW

ROOF MOUNTED

OTHER PRODUCTS

AXIAL FLOW

Quietflow SQT

p98

Powerduct SPD

p103

Singleflow SSDD &

SSBD

p108

Compact Power Plus

SCPP

p28

Heritage SGE

p147

Revolution SLC

p34

Biflow SB (CYL)

p42

Heritage SCH

p150

Heritage SCHT

p153

Skyflow SSFV

p156

Ceiling Fan HCF

p175

Voltage Controllers

p177

Inverter Controllers

_p179

f: 01384 275810

visit: eltafans.com

(4)

The fact is, choosing the right fan manufacturer for your requirements is an important decision. Which is why we thought a few facts about Elta Fans and its ‘SELECT’ range might help with that decision.

It’s not just one of the widest range of H&V products on the market today.

Nor is it our extensive distributor network - We have over 80 distributors in the UK and in 36 countries across 6 continents.

Nor is it the people – Elta Fans attracts some of the most talented and experienced professionals in the H&V industry, providing excellence in technical support and a level of customer service the envy of many.

Nor is it the depth of stock of standard products we carry, or the flexibility to respond quickly to more specialist product requirements.

It is knowing that our customers

come back to us time and time again.

What’s INSIDE the SELECT catalogue?

The SELECT catalogue reflects the continuing development of our high quality range of industrial & commercial ventilation products for the building services markets which we launched in September 1999.

Within it, you will see;

• A number of NEW products developed in response to your needs.

• More sizes and higher duties in several existing product ranges.

• An overview of features and benefits for each and every product.

• Additional information provided on each product to make your

selections even easier than before.

• Selection tips on the DO’s & DONT’s with fans.

(5)

Our products include……… • Plate & duct mounted fans • Square cased & circular mixed flow fans • Long cased axial fans • Single & twin in line centrifugal duct fans • Bifurcated fans • Low silhouette & vertical axial roof extract fans • Two stage axial fans • Direct & belt drive roof mounted fans • Certified smoke extract fans • Centrifugal roof mounted fans • Commercial window & wall mounted fans • Industrial wall fans • Portable cooling fans • Ceiling fans • Voltage controllers • Inverter controllers • Auto changeover controllers • Electrical accessories • And of course all SELECT products are supported by our vast range of

accessories available from stock.

Can’t find what you’re looking for?

Don’t worry!

Our capabilities go well beyond the SELECT range.

More than thirty years experience in specialised applications allows our Building Services division to work closely and confidently with you in designing a fan around your particular application.

Whether you require smoke extract, car park ventilation, ATEX fans for hazardous locations, improved efficiency, or simply increased capability - we have the ability to meet the criteria you set, all to the very latest standards.

(6)

products at the click of a button. The ‘Fans by ELTA’ interactive product suite, a user friendly CD with a browsable catalogue section, has been adopted by distributors, consultants and contractors alike as an essential business tool for fast, accurate and time efficient fan selection.

Website

The ELTA Fans website allows users to see the very latest products, learn more about the company, download the latest brochures, wiring diagrams, installation & maintenance instructions and much more.

• Selection of all types of fans

• Performance curves and technical data

• Acoustic analysis with attenuator selection

(7)

Fastlane

Air handling units are an integral part of many Building Services projects. Fastlane Ventilation Equipment (also part of the ELTA Group) provide a wide range of air handlers from standard direct drive, belt drive, plant and roof mounted units, to bespoke units with a wide range of options, including heat recovery.

For more information on our air handling unit range,

contact Fastlane on

01384 720460.

commercial applications from residential bathrooms, toilets and utility rooms to sports halls, public houses and other commercial premises.

Want an Elta Binder?

How about a full binder, containing all the most up to date

information on Elta Fans? Simply call

01384 275800

(8)

AXIAL FLOW

Features & Benefits

Compact SCP -

Plate Mounted

8 Features & Benefits

Motors

– These are protected to IP55 which means they are highly resistant to dust and water ingress.

Quality impellers

- Adjustable pitch aerodynamic impellers allow easy site adjustment of the impeller from factory set maximum pitch angles if required.

Adaptable

- Compact SCP fans operate as Form A running, but are available as Form B if required, so the fan can be used for supply as well as extract.

Cost effective

– Very efficient for moving high volumes of air at relatively low pressures.

Speed controllable

– Each fan is fully speed controllable with an electronic or transformer controller, which means airflow can be altered to suit site conditions.

Safety

– All motors are fitted with integral ‘Thermal overload protection’ preventing the motor from

overheating and all fans come with an integral motor side guard.

Ease of installation

– Fans are supplied with an integral IP55 terminal box which allows the fan to be positioned conveniently to incoming electrical inputs.

Efficiency

– The advanced engineering and design provides higher efficiency with lower power absorption characteristics, which improves quality and life expectancy.

Solid Construction -

The powder coated steel fan plate incorporates a pressed inlet which provides extra rigidity, smoother airflow and enhanced performance characteristics. Finish is pastel beige (RAL 7032).

Extensive stock range available

– Selection issues minimized due to the wide range of sizes, motors and controls options.

Mounting

– Fans can be mounted in any position and are suitable for wall or roof mounted applications.

Full Accessory range

– Speed controllers, inverters, louvre shutters, impeller guards (recommended), wall cowls.

Tested to the very latest standards

– SCP units are tested to ISO 5801:1997 (airside performance) and to

BS 848 Pt 2:1985 (sound performance) at Elta Fans own test facility, meaning accurate, up to date information on performance and noise data that can be relied upon.

Quality assurance

– All units are designed and manufactured with procedures as defined in BS EN ISO 9001: 2000.

Warranty

– Each SCP has a 12 month warranty.

Applications

Factories, sports halls, shops, industrial units, warehousing, schools, kitchens.

The Compact SCP is a slim profile plate mounted axial fan. The fan design, construction and finish

provides a strong durable and weather proofed range. Compact fans boast highly efficient lightweight,

robust motors, with proven reliability, ensuring long life and trouble free operation, excellent all round

performance and simple speed control.

·

10 standard sizes from 250mm to 800mm.

·

Air volume flow rates of up to 6.18 m3_/sec.

·

Static pressures of up to 200 Pa.

·

Highly efficient, lightweight induction motors.

·

Fully speed controllable.

·

Impellers are highly efficient aerofoil bladed section, produced from GRP,

retained in an aluminium hub and balanced to Grade G6.3.

·

Suitable for operating temperatures up to 70°C (50°C under speed control).

(9)

Compact SCP -

Plate Mounted

Dimensional Data

Accessories

p14 p14 p14 p177

9

Weight kg

Product

Code

A

B

C

D

E

F

G

H

SCP250 250 260 265 370 320 100 73 15 6 SCP315 315 325 360 430 380 85 88 15 8 SCP350 350 360 395 485 435 85 88 15 8 SCP400 400 410 450 540 490 84 99 15 12 SCP450 450 460 500 575 535 84 99 15 13 SCP500 500 510 560 655 615 140 99 15 20 SCP560 560 575 625 725 670 140 99 20 24 SCP630 630 645 705 805 750 140 101 20 30 SCP710 710 725 765 850 810 146 101 27 30 SCP800 800 820 870 970 910 146 101 27 33 4-HOLES 10 DIA 550mm LENGTH OF 20mm FLEXIBLE CONDUIT COMPLETE WITH TERMINAL BOX

MOUNTING FACE D E CTS B A C F G H

PRODUCT CODE A B C D E F G H WEIGHT _KG

SCP800 SCP710 SCP630 SCP560 SCP500 SCP450 SCP400 SCP350 SCP315 SCP250 630 800 710 560 500 450 400 350 315 250 645 820 725 575 510 460 360 410 325 260 705 870 765 625 560 500 395 450 360 265 805 970 850 725 655 575 485 540 430 370 750 910 810 670 615 535 435 490 380 320 140 146 146 140 140 84 85 84 85 100 101 101 101 99 99 99 88 99 88 73 20 27 27 20 15 15 15 15 15 15 30 33 30 24 20 13 8 12 8 6

AXIAL FLOW

(10)

SCP250/4-1 1455 0.35 0.29 0.22 0.90 1.45 0.09 EL31TK TC12 44 SCP315/4-1 1390 0.65 0.58 0.50 0.90 1.45 0.09 EL31TK TC12 48 SCP350/4-1 1330 0.88 0.77 0.66 0.54 0.90 1.45 0.09 EL31TK TC12 53 SCP400/4-1 1375 1.35 1.25 1.13 0.97 1.80 3.60 0.25 EL31TK TC14 56 SCP450/6-1 850 1.16 0.98 0.73 1.05 2.00 0.12 EL31TK TC12 50 SCP450/4-1 1300 1.65 1.55 1.43 1.25 1.10 1.80 3.60 0.25 EL31TK TC14 59 SCP500/6-1 860 1.55 1.40 1.10 1.55 3.50 0.18 EL31TK TC14 54 SCP500/4-1 1350 2.48 2.34 2.20 2.05 1.90 1.76 3.60 10.8 0.55 EL61TK TC18 62 SCP560/6-1 875 2.40 2.20 2.05 1.70 2.20 5.50 0.25 EL31TK TC14 58 SCP560/4-1 1350 3.45 3.25 3.10 2.90 2.60 2.35 4.90 15.0 0.75 EL61TK TC18 65 SCP630/6-1 850 3.55 3.20 2.80 2.40 1.90 6.00 12.6 0.55 EL101 TC18 59 SCP630/4-1 1310 4.16 4.06 3.95 3.84 3.71 3.57 3.42 3.04 7.90 19.75 1.1 - TC110 68 0 25 50 75 100 125 150 200

Product

Code

Speedr/min

Airflow m3_{/s @ Static Pressure Pa.} _{Motor Electrical Data}

FLC

Amps SC Amps OutputkW Trans-former

dBA @ 3m Speed Control Electr-onic SCP315/4-3 1390 0.65 0.58 0.50 0.50 1.15 0.12 TC33 48 SCP350/4-3 1330 0.88 0.77 0.66 0.54 0.50 1.15 0.12 TC33 53 SCP400/4-3 1375 1.35 1.25 1.13 0.97 1.40 4.50 0.37 TC33 56 SCP450/6-3 850 1.16 0.98 0.73 0.68 1.70 0.18 TC33 50 SCP450/4-3 1300 1.65 1.55 1.43 1.25 1.10 1.40 4.50 0.37 TC33 59 SCP500/6-3 830 1.55 1.40 1.10 0.94 2.40 0.25 TC33 54 SCP500/4-3 1320 2.48 2.34 2.20 2.05 1.90 1.76 1.75 6.20 0.55 TC33 62 SCP560/6-3 830 2.40 2.20 2.05 1.70 0.94 2.40 0.25 TC33 58 SCP560/4-3 1320 3.45 3.25 3.10 2.90 2.60 2.35 2.00 7.50 0.75 TC35 65 SCP630/6-3 850 3.55 3.20 2.80 2.40 1.90 1.90 5.80 0.55 TC35 59 SCP630/4-3 1320 4.75 4.65 4.54 4.40 4.25 4.05 3.80 3.30 4.30 15.5 1.5 TC35 68 SCP710/6S-3 720 3.87 3.46 3.03 2.48 1.50 5.40 0.50 TC33 56 SCP710/6D-3 880 4.67 4.39 4.09 3.76 3.37 3.40 12.3 1.1 TC35 60 SCP710/4S-3 1380 6.00 5.76 5.49 5.23 4.97 4.69 4.37 4.30 15.5 1.5 TC35 69 SCP800/6S-3 620 4.70 4.13 3.52 1.50 5.40 0.50 TC33 53 SCP800/6D-3 820 6.18 5.79 5.39 4.95 4.41 3.40 12.3 1.1 TC35 67 0 25 50 75 100 125 150 200

Product

Code

Speedr/min

FLC

Amps SC Amps OutputkW Trans-former dBA @ 3m Speed Control

THREE Phase - 380V-415V / 50Hz

SINGLE Phase - 220V-240V / 50Hz

Performance & Electrical Data

Compact SCP -

Plate Mounted

AXIAL FLOW

10

Sound levels are average spherical free field values at 50% peak pressure for comparative purposes only. Sound levels are average spherical free field values at 50% peak pressure for comparative purposes only.

(11)

Compact SCPA -

Plate Mounted

Features & Benefits

11 Features & Benefits

Aluminium Blades

- With a full solidity, 10 bladed aluminium impeller, the SCPA offers improved pressure development, as well as a cost effective solution for situations that demand a metal impeller.

Motors

Quality impellers

Adaptable

- Compact SCPA fans operate as Form A running, but are available as Form B if required, so the fan can be used for supply as well as extract.

Cost effective

Speed controllable

Safety

– All motors are fitted with integral ‘Thermal overload protection’ preventing the motor from overheating and all fans come with integral motor side guard.

Ease of installation

– Fans are supplied with an integral IP55 terminal box, which allows the fan to be positioned conveniently to incoming electrical inputs.

Efficiency

Solid Construction -

The powder coated steel fan plate incorporates a pressed inlet which provides extra rigidity, smoother airflow and enhanced performance characteristics. Finish is pastel beige (RAL 7032).

Extensive stock range available

– Selection issues minimized due to the wide range of sizes, motors and control options.

Mounting

– Fans can be mounted in any position and are suitable for, wall or roof mounted applications.

Full accessory range

– Speed controllers, inverters, louvre shutters, impeller side guards (recommended), wall cowls.

Tested to the very latest standards

– SCPA units are tested to ISO 5801:1997 (airside performance) and to

Quality assurance

Warranty

– Each SCPA has a 12 month warranty.

Applications

Factories, sports halls, shops, industrial units, warehousing, schools, kitchen extract.

The Compact SCPA is a plate mounted axial fan with a 10 bladed aluminium impeller, offering improved

pressure development, whilst being ideal for speed control.

The fan design, construction and finish provides a strong, durable and weather proofed range.

Compact SCPA fans boast highly efficient lightweight, robust motors, with proven reliability ensuring a

long life and trouble free operation.

·

Impellers are highly efficient aerofoil bladed section, produced

from and retained in an aluminium hub and balanced to Grade G6.3.

·

Extensive stock range available.

(12)

AXIAL FLOW

Dimensional Data

Compact SCPA -

Plate Mounted

12

Weight kg

Product

Code

A

B

C

D

E

F

G

H

SCPA315 315 325 360 430 380 85 88 15 8 SCPA350 350 360 395 485 435 85 88 15 10 SCPA400 400 410 450 540 490 84 99 15 14 SCPA450 450 460 500 575 535 104 99 15 15 SCPA500 500 510 560 655 615 140 99 15 22 SCPA560 560 575 625 725 670 140 99 20 29 SCPA630 630 645 705 805 750 140 101 20 32 4-HOLES 10 DIA: 550mm LENGTH OF 20mm FLEXIBLE CONDUIT COMPLETE WITH TERMINAL BOX

MOUNTING FACE

PRODUCT CODE A B C D E F G H WEIGHT _KG

SCPA630 SCPA560 SCPA500 SCPA450 SCPA400 SCPA350 SCPA315 630 560 500 450 400 350 315 645 575 510 460 360 410 325 705 625 560 500 395 450 360 805 725 655 575 485 540 430 750 670 615 535 435 490 380 140 140 140 104 85 84 85 101 99 99 99 88 99 88 20 20 15 15 15 15 15 30 24 20 13 8 12 8 D SQ. E CTS B A C F G H

Accessories

p14 p14 p14 p177

(13)

Performance & Electrical Data

Compact SCPA -

Plate Mounted

13 SINGLE Phase - 220V-240V / 50Hz

SCPA315/4-1 1370 0.48 0.44 0.40 0.34 0.9 1.45 0.09 EL31TK TC12 54 SCPA350/4-1 1290 0.70 0.65 0.60 0.54 0.9 1.45 0.09 EL31TK TC12 57 SCPA400/4-1 1385 1.13 1.07 1.00 0.93 0.85 1.8 3.6 0.25 EL31TK TC14 59 SCPA450/4-1 1340 1.66 1.59 1.52 1.44 1.34 1.20 3.0 9.0 0.37 EL61TK TC14 63 SCPA500/4-1 1375 2.61 2.49 2.36 2.21 2.05 1.87 1.64 4.9 15.0 0.75 EL61TK TC18 66 SCPA560/4-1 1340 3.45 3.33 3.21 3.08 2.93 2.78 2.64 2.46 7.9 19.75 1.1 - TC110 67 SCPA630/4-1 1310 4.16 4.06 3.95 3.84 3.71 3.57 3.42 3.25 3.04 2.79 2.39 7.9 19.75 1.1 - TC110 68 0 25 50 75 100 125 150 175 200 225 250

Product

Code

Speedr/min

Airflow m3/s @ Static Pressure Pa. Motor Electrical Data

FLC

dBA @ 3m Speed Control Electr-onic

Sound levels are average spherical free field values at 50% peak pressure for comparative purposes only.

Speed control

Part L of the UK Building Regulations encourages the speed control of fans to provide energy savings,

which can be dramatic – halving fan speed reduces power consumption by 87 _%.

Speed control can also be applied to reduce airflow to match lower ventilation rates when these are demanded and obviously reduce noise levels accordingly.

Whatever method of speed control is adopted, it is essential to ensure that the motor is designed and manufactured for speed control. Speed controllers range from 3-speed switches for small single phase motors up to 16 Amp, 5-step auto-transformer units for single or three phase supply and on to unlimited amperages with inverters for use with three phase motors.

Single phase

Fans suitable for variable voltage speed control must have motors with high resistance rotors. Electronic speed controllers are the most cost effective option but they can generate a magnetic hum and should be used with care in noise sensitive areas. They are also the least efficient option with an increase in current at about 70% of full speed.

Multi-step auto-transformer controllers are more expensive but do not suffer from magnetic hum. They are also more efficient.

Three phase

Fans suitable for variable voltage speed control must have motors with high resistance rotors. Multi-step auto-transformer controllers are a cost effective option and do not create a magnetic hum. Fans fitted with modern standard motors are suitable for variable frequency control using inverter controllers. Whilst these have the highest initial cost they are the most efficient and versatile option and offer many additional features such as soft start, programmable functions and BMS integration. (N.B. External rotor motors must have enhanced winding insulation to be suitable for variable frequency control).

AXIAL FLOW

1 2

(14)

MODEL A B C SCP250 SCP315 SCP350 SCP400 935 755 610 500 815 645 510 410 555 470 390 325 AREA m 2 GRILLE DUCT 0.345 0.312 0.217 0.196 0.140 0.126 0.088 0.078 D 270 400 570 715 SCP450 SCP500 SCP560 SCP630 935 815 555 635 0.345 0.312 0.217 0.196 0.140 0.126 0.088 0.078 755 645 470 510 610 510 390 460 500 410 325 365

001-SWC-CAT

DETAIL OF WALL MOUNTING COWL 1.0 1 1 HH 16/12/03 1:4 I

3rd ANGLE PROJECTION DO NOT SCALE-IF IN DOUBT, ASK!

DRAWING No. SHEET OF ISSUE DRAWN BY DATE SCALE STATUS APPROVED CHECKED ELTA FANS LTD, 17 BARNES WALLIS ROAD, SEGENSWORTH INDUSTRIAL ESTATE, FAREHAM, HAMPSHIRE. PO15 5ST. Tel. 01489 566500 Fax. 01489 566555

Elta Fans Ltd. own the copyright of this drawing/

in writing from its owners Elta Fans Ltd. and must not be reproduced without permission purpose other than that for which it is supplied confidence and which must not be used for any specification document which is supplied in C

FINISH MATERIAL SPECIFICATION

DIMENSIONS ARE IN mm UNLESS STATED OTHERWISE

THIS IS A C.A.D. PRODUCED DRAWING AND THEREFORE NO SUBSEQUENT MANUAL MODIFICATIONS WILL BE ALLOWED. TITLE TOLERANCES UNLESS OTHERWISE STATED. ± BY ISS CN. DATE CHKD ISS CN. BY DATE CHKD ISS CN. BY DATE CHKD ISS CN. BY DATE CHKD A3 A 1 B C D E F G 2 3 4 5 7 6 7 6 5 4 3 2 1 A B C D E F G DATE ISS CN. CHKD DATE BY ISS CN. CHKD BY DATE ISS CN. CHKD DATE BY CN. ISS CHKD BY USED ON

OF THESE VIEWS FOR MANUFACTURING PURPOSES ARE AT SUPPLIERS RISK.

REFERENCE PURPOSES ONLY. USE ANY DEVELOPMENT VIEWS SHOWN ON

THIS DRAWING ARE SHOWN FOR

C A

B

Accessories

Compact SCP/A -

Plate Mounted

AXIAL FLOW

14

078C-0250-C 250 270 18 0.9 078C-0315-C 315 335 21 1.1 078C-0350-C 350 370 23 1.4 078C-0400-C 400 420 26 1.6 078C-0450-C 450 470 29 1.8 078C-0500-C 500 520 32 2.2 078C-0560-C 560 585 32 2.5 078C-0630-C 630 655 40 2.6 078C-0710-C 710 730 50 3.2 078C-0800-C 800 820 50 3.5

Product

Code

Fan

Dia.

A

B

Weightkg

GUARD FIXING CLIPS 500 520 32 2.2 078C-1000-C 078C-0630-C 078C-0560-C 078C-0800-C 078C-0710-C 1000 1020 60 800 710 630 560 820 730 50 50 665 585 40 32 4.5 3.5 3.2 2.6 2.5 078C-0500-C 078C-0450-C 078C-0400-C 078C-0315-C PRODUCT CODE DIA 450 400 315 470 420 29 26 335 21 FAN A B _KG 1.8 1.6 1.1 WEIGHT WB-SMC-009 MULTIFLOW SMC DETAIL OF INLET GUARD 1.0 1 1 A HH 24/07/06 1:3 3rd ANGLE PROJECTION DO NOT SCALE-IF IN DOUBT, ASK!

DRAWING No. SHEET OF ISSUE DRAWN BY DATE SCALE STATUS APPROVED CHECKED ELTA FANS LTD,

17 BARNES WALLIS ROAD, SEGENSWORTH INDUSTRIAL ESTATE, FAREHAM, HAMPSHIRE. PO15 5ST. Tel. 01489 566500 Fax. 01489 566555

FINISH MATERIAL SPECIFICATION DIMENSIONS ARE IN mm UNLESS STATED OTHERWISE

THIS IS A C.A.D. PRODUCED DRAWING AND THEREFORE NO SUBSEQUENT MANUAL MODIFICATIONS WILL BE ALLOWED. TITLE TOLERANCES UNLESS OTHERWISE STATED. ± BY ISS CN. DATE CHKD ISS CN. BY DATE CHKD ISS CN. BY DATE CHKD ISS CN. BY DATE CHKD A3 A 1 B C D E F G 2 3 4 5 7 6 7 6 5 4 3 2 1 A B C D E F G DATE ISS CN. CHKD DATE BY ISS CN. CHKD BY DATE ISS CN. CHKD DATE BY CN. ISS CHKD BY USED ON OF THESE VIEWS FOR MANUFACTURING

PURPOSES ARE AT SUPPLIERS RISK. REFERENCE PURPOSES ONLY. USE ANY DEVELOPMENT VIEWS SHOWN ON

A B AIR-FLOW CENTRE MULLION ON SIZES 560, 630, 710 & 800 APPLIES TO SIZE 350 ON LY D A C (HOLE CTRS) D B E (HOLE CTS) or 696 610 548 502 460 398 348 30 30 30 30 26 26 26 627 530 452 404 364 298 274 510 460 423 360 310 30 745 666 298 26 235 260 PRODUCT CODE 064-0710-C 064-0630-C 064-0560-C 064-0500-C 064-0450-C 064-0400-C 064-0350-C 064-0315-C 064-0250-C A B C D D 568 655 702 064-0800-C 840 40 770 800 E 323 064-0250-C 298 26 235 260 - - 0.5 064-0315-C 348 26 274 310 - - 0.5 064-0350-C 348 26 298 360 323 1.0 064-0400-C 460 26 364 423 - - 1.0 064-0450-C 502 30 404 460 - - 1.5 064-0500-C 548 30 452 510 - - 2.0 064-0560-C 610 30 530 - 568 - 2.0 064-0630-C 696 30 627 - 655 - 3.0 064-0710-C 745 30 666 - 702 - 3.0 064-0800-C 840 40 770 - 800 - 4.0

Product

Code

A

B

C

D

Impeller Guard

Louvre Shutter

· Bright zinc plated steel

· Fix with clips & screws provided

Wall Cowl

· Durable, light grey polypropylene · Opens automatically with airflow

· Mount independently of fan (ideally downstream) · Screw fixings provided

SWC25/31 500 410 325 0.088 2 SWC35/40 610 510 390 0.140 3 SWC45/50 755 645 470 0.217 7 SWC56/63 935 815 555 0.345 10

Product

Code

A

B

C

Weightkg Grille Area m2 Weight kg

E

· Protects fan openings from prevailing weather conditions

· Minimises resistance to airflow

· Manufactured from GRP - Colour impregnated into gel coat

(15)

Features & Benefits

Compact SCD -

Duct Mounted

15 Features & Benefits

Slim Casing

– The compact design of the induction motors allow a shorter casing length, which means a lightweight unit that is easier to install, especially within restricted ductwork space.

Cost effective

Motors

Flexible performance

Adaptable

- Compact SCD fans operate as Form A running and can be used for supply as well as extract.

Speed controllable

– Each fan is fully speed controllable with an electronic or transformer controller, which means the airflow can be altered to suit site conditions.

Ease of installation

– Fans are supplied with an integral IP55 terminal box which allows the fan to be positioned conveniently to incoming electrical inputs.

Efficiency

Strong durable casing

– The steel fan case has an additional ‘return’ on the flange for extra strength and rigidity and the powder coated finish (pastel beige, RAL 7032) ensures a long life.

Safety

– All motors are fitted with integral ‘Thermal overload protection’ preventing the motor from overheating.

Extensive stock range available

Mounting

- Suitable for duct mounted applications.

Full accessory range

– Speed controllers, inverters, mounting feet, anti-vibration mounts, flexible connectors, matching flanges, silencers and impeller guards

(recommended for end of duct locations).

Tested to the very latest standards

– SCD units are tested to ISO 5801:1997 (airside performance) and to

Quality assurance

Warranty

– Each SCD has a one year warranty.

Applications

Factories, sports halls, shops, industrial units, warehousing, schools, kitchens.

The Compact SCD is a short cased axial fan designed for duct mounting. The fan design, construction

and finish provides a strong, durable and weather proofed range. The Compact fan boasts highly

efficient lightweight, robust motors, with proven reliability, ensuring long life and trouble free operation,

excellent all round performance and simple speed control.

·

Impellers are highly efficient aerofoil bladed section, produced

from GRP, retained in an aluminium hub and balanced to Grade G6.3.

·

Extensive stock range available.

(16)

AXIAL FLOW

Dimensional Data

Accessories

p21 p21 p21 p22 p22 p22 p177 Weight kg

Product

Code

A

B

C

D

E

F

G

SCD250 250 306 180 165 8 7.0 286 7 SCD315 315 382 180 207 8 9.5 356 9 SCD350 350 421 180 224 8 9.5 395 10 SCD400 400 466 190 249 12 9.5 438 12 SCD450 450 515 190 274 12 9.5 487 14 SCD500 500 567 250 300 12 9.5 541 21 SCD560 560 636 250 330 16 11.5 605 23 SCD630 630 709 250 365 16 11.5 674 30 E HOLES F EQUI-SPACED ON G PCD

TERMINAL BOX FITTED AS STANDARD COMPLETE WITH CONNECTION BLOCK. CABLE ENTRY IS 21 B A C D 674 11.5 16 365 250 709 630 SCD630 180 180 190 180 190 250 250 C SCD450 SCD500 SCD560 SCD315 SCD350 SCD400 560 450 500 636 567 515 350 400 315 421 466 382 SCD250 PRODUCT CODE A 250 B 306 9.5 11.5 330 274 300 16 12 12 224 249 207 8 12 8 487 541 605 9.5 356 438 395 9.5 9.5 9.5 7.0 D 165 E 8 286 G F 30 23 14 21 10 12 9 WEIGHT 7 KG MOUNTS A.V. S1G S1G S1B S1B S1G S1B S1B S1B © Elta Fans Ltd

Compact SCD -

Duct Mounted

(17)

Compact SCD -

Duct Mounted

Performance & Electrical Data

17

SCD250/4-1 -9 -12 7 -14 -18 11 SCD315/4-1 -9 -13 10 -15 -19 15 SCD350/4-1 -10 -13 10 -16 -20 16 SCD400/4-1 -9 -13 17 -16 -20 25 SCD450/6-1 -9 -13 8 -16 -19 12 SCD450/4-1 -9 -13 16 -15 -19 24 SCD500/6-1 -10 -14 11 -17 -20 16 SCD500/4-1 -9 -13 14 -15 -18 36 SCD560/6-1 -9 -13 15 -16 -19 23 SCD560/4-1 -9 -13 29 -15 -19 41 SCD630/6-1 -11 -15 16 -16 -23 23 SCD630/4-1 -10 -15 30 -15 -23 51

Product

Code

dBA Attenuation

∆

P (Pa) 1DEP dBA Attenuation

∆

P (Pa) 2DEP

Silencer Data -

SINGLE Phase

SINGLE Phase - 220V-240V / 50Hz

SCD250/4-1 1455 0.35 0.29 0.22 0.90 1.45 0.09 EL31TK TC12 44 S1B SCD315/4-1 1390 0.65 0.58 0.50 0.90 1.45 0.09 EL31TK TC12 48 S1B SCD350/4-1 1330 0.88 0.77 0.66 0.54 0.90 1.45 0.09 EL31TK TC12 53 S1B SCD400/4-1 1375 1.35 1.25 1.13 0.97 1.80 3.60 0.25 EL31TK TC14 56 S1B SCD450/6-1 850 1.16 0.98 0.73 1.05 2.00 0.12 EL31TK TC12 50 S1B SCD450/4-1 1300 1.65 1.55 1.43 1.25 1.10 1.80 3.60 0.25 EL31TK TC14 59 S1B SCD500/6-1 860 1.55 1.40 1.10 1.55 3.50 0.18 EL31TK TC14 54 S1G SCD500/4-1 1350 2.48 2.34 2.20 2.05 1.90 1.76 3.60 10.8 0.55 EL61TK TC18 62 S1G SCP560/6-1 875 2.40 2.20 2.05 1.70 2.20 5.50 0.25 EL31TK TC14 58 S1G SCD560/4-1 1350 3.45 3.25 3.10 2.90 2.60 2.35 4.90 15.0 0.75 EL61TK TC18 65 S1G SCD630/6-1 850 3.55 3.20 2.80 2.40 1.90 6.00 12.6 0.55 EL101 TC18 59 S1G SCD630/4-1 1310 4.16 4.06 3.95 3.84 3.71 3.57 3.42 3.04 7.90 19.75 1.1 - TC110 68 S1G 0 25 50 75 100 125 150 200

Product

Code

Speedr/min

FLC

dBA @ 3m Speed Control Electr-onic A.V. Mounts

THREE Phase - 380V-415V / 50Hz

0 25 50 75 100 125 150 200

Product

Code

Speedr/min

FLC

Amps SC Amps OutputkW Trans-former dBA @ 3m Speed Control _A.V. Mounts SCD315/4-3 1390 0.65 0.58 0.50 0.50 1.15 0.12 TC33 48 S1B SCD350/4-3 1330 0.88 0.77 0.66 0.54 0.50 1.15 0.12 TC33 53 S1B SCD400/4-3 1375 1.35 1.25 1.13 0.97 1.40 4.50 0.37 TC33 56 S1B SCD450/6-3 850 1.16 0.98 0.73 0.68 1.70 0.18 TC33 50 S1B SCD450/4-3 1300 1.65 1.55 1.43 1.25 1.10 1.40 4.50 0.37 TC33 59 S1B SCD500/6-3 830 1.55 1.40 1.10 0.94 2.40 0.25 TC33 54 S1G SCD500/4-3 1320 2.48 2.34 2.20 2.05 1.90 1.76 1.75 6.20 0.55 TC33 62 S1G SCD560/6-3 830 2.40 2.20 2.05 1.70 0.94 2.40 0.25 TC33 58 S1G SCD560/4-3 1320 3.45 3.25 3.10 2.90 2.60 2.35 2.00 7.50 0.75 TC35 65 S1G SCD630/6-3 850 3.55 3.20 2.80 2.40 1.90 1.90 5.80 0.55 TC35 59 S1G SCD630/4-3 1320 4.75 4.65 4.54 4.40 4.25 4.05 3.80 3.30 4.30 15.5 1.5 TC35 68 S1G SCD315/4-3 -9 -13 10 -15 -19 15 SCD350/4-3 -10 -13 10 -16 -20 16 SCD400/4-3 -9 -13 17 -16 -20 25 SCD450/6-3 -9 -13 8 -16 -19 12 SCD450/4-3 -9 -13 16 -15 -19 24 SCD500/6-3 -10 -14 11 -17 -20 16 SCD500/4-3 -9 -13 14 -15 -18 36 SCD560/6-3 -9 -13 15 -16 -19 23 SCD560/4-3 -9 -13 29 -15 -19 41 SCD630/6-3 -11 -15 16 -16 -23 23 SCD630/4-3 -10 -15 38 -15 -23 55

Product

Code

dBA Attenuation

∆

P (Pa) 2DEP

Silencer Data-

THREE Phase

For explanation of silencer data see p20.

AXIAL FLOW

(18)

AXIAL FLOW

Compact SCDA -

Duct Mounted

Features & Benefits

18 Features & Benefits

Aluminium blades

- With a full solidity 10 bladed aluminium impeller, the SCDA offers improved pressure development, and a cost effective solution for situations that demand a metal impeller.

Slim Casing

– The compact design of the induction motors allow a shorter casing length, which means a lightweight unit that is easier to install, especially within restricted ductwork space.

Motors

Quality impellers

Adaptable

- Compact SCDA fans operate as Form A running and can be used for supply as well as extract.

Cost effective

Speed controllable

Strong durable casing

– The steel fan case has an additional ‘return’ on the flange for extra strength and rigidity and the powder coated finish (pastel beige, RAL 7032) ensures a long life.

Safety

– All motors are fitted with integral ‘Thermal overload protection’ preventing the motor from overheating.

Ease of installation

– Fans are supplied with an integral IP55 terminal box, which allows the fan to be positioned conveniently to incoming electrical inputs.

Efficiency

Extensive stock range available

Mounting

- Suitable for duct mounted applications.

Full accessory range

– Speed controllers, inverters, mounting feet, anti-vibration mounts, flexible connectors, matching flanges, silencers and impeller guards

(recommended for end of duct locations).

Tested to the very latest standards

– SCDA units are tested to ISO 5801:1997 (airside performance) and to

BS 848 Pt 2:1985 (sound performance) meaning accurate, up to date information on performance and noise data that can be relied upon.

Quality assurance

Warranty

– Each SCDA has a 12 month warranty.

Applications

Factories, sports halls, shops, industrial units, warehousing, schools, kitchen extract.

The Compact SCDA is a duct mounted axial fan with a 10 bladed aluminium impeller, offering improved

performance and pressure development, whilst being ideal for speed control.

The fan design, construction and finish provide a strong, durable and weather proofed range.

Compact SCDA fans boast highly efficient lightweight, robust motors, with proven reliability ensuring a

long life and trouble free operation.

·

Impellers are highly efficient aerofoil bladed section, produced from

and retained in an aluminium hub and balanced to Grade G6.3.

·

(19)

Dimensional Data

Compact SCDA -

Duct Mounted

Weight kg

Product

Code

A

B

C

D

E

F

G

SCDA315 315 382 180 207 8 9.5 356 10 SCDA350 350 421 180 224 8 9.5 395 10 SCDA400 400 466 190 249 12 9.5 438 14 SCDA450 450 515 190 274 12 9.5 487 16 SCDA500 500 567 250 300 12 9.5 541 23 SCDA560 560 636 250 330 16 11.5 605 26 SCDA630 630 709 250 365 16 11.5 674 28 674 11.5 16 365 250 709 630 SCDA630 180 190 180 190 250 250 C SCDA450 SCDA500 SCDA560 SCDA315 SCDA350 SCDA400 560 450 500 636 567 515 350 400 315 421 466 382 PRODUCT CODE A B 9.5 11.5 330 274 300 16 12 12 224 249 207 8 12 8 487 541 605 9.5 356 438 395 9.5 9.5 9.5 D E F G 30 23 14 21 10 12 9 WEIGHT KG E HOLES F EQUI-SPACED ON G PCD

TERMINAL BOX FITTED AS STANDARD COMPLETE WITH CONNECTION BLOCK. CABLE ENTRY IS 21 MOUNTS A.V. S1G S1G S1B S1G S1B S1B S1B B A C D © Elta Fans Ltd

19 Accessories

p21 p21 p21 p22 p22 p22 p177

AXIAL FLOW

(20)

AXIAL FLOW

Performance & Electrical Data

Compact SCDA -

Duct Mounted

SCDA315 -7 -10 7 -13 -14 12 SCDA350 -7 -10 10 -13 -15 16 SCDA400 -8 -11 15 -14 -16 24 SCDA450 -8 -10 21 -14 -15 33 SCDA500 -8 -11 32 -14 -17 51 SCDA560 -8 -11 35 -15 -18 56 SCDA630 -11 -17 27 -17 -26 43

Product

Code

dBA Attenuation

∆

P (Pa) 2DEP

Silencer Data -

SINGLE Phase

20 SINGLE Phase - 220V-240V / 50Hz

SCDA315/4-1 1370 0.48 0.44 0.40 0.34 0.9 1.45 0.09 EL31TK TC12 54 S1B SCDA350/4-1 1290 0.70 0.65 0.60 0.54 0.9 1.45 0.09 EL31TK TC12 57 S1B SCDA400/4-1 1385 1.13 1.07 1.00 0.93 0.85 1.8 3.6 0.25 EL31TK TC14 59 S1B SCDA450/4-1 1340 1.66 1.59 1.52 1.44 1.34 1.20 3.0 9.0 0.37 EL61TK TC14 63 S1B SCDA500/4-1 1375 2.61 2.49 2.36 2.21 2.05 1.87 1.64 4.9 15.0 0.75 EL61TK TC18 66 S1G SCDA560/4-1 1340 3.45 3.33 3.21 3.08 2.93 2.78 2.64 2.46 7.9 19.75 1.1 - TC110 67 S1G SCDA630/4-1 1310 4.16 4.06 3.95 3.84 3.71 3.57 3.42 3.25 3.04 2.39 7.9 19.75 1.1 - TC110 68 S1G 0 25 50 75 100 125 150 175 200 250

Product

Code

Speedr/min

Airflow m3/s @ Static Pressure Pa. Motor Electrical Data FLC

dBA @ 3m Speed Control Electr-onic

Silencer data (flanged circular fans)

A.V. Mounts

For explanation of silencer data see below.

Select silencers for flanged axial flow fans are available in two lengths denoted by either 1D (length = diameter) or 2D (length = 2 x diameter) in the product code.

Each length is then available with and without cylindrical centrebody or ‘pod’ which provides additional attenuation. These are identified by the inclusion in the product code of ‘P’ for podded or ‘NP’ for unpodded versions.

When selecting the appropriate silencer, account needs to be taken of both the level of sound reduction achieved and, in the case of a podded silencer, the additional pressure drop in the system which needs to be overcome by the fan.

The silencer data tables in this catalogue provide information required:

· For sound, deducting the appropriate ‘dBA Attenuation’ figure from the ‘dBA @ 3m’ figure in the relevant fan performance table gives a combined ‘dBA @ 3m’ figure for the fan and silencer combination.

· For pressure, the ‘∆P’ figure should be added to the pre-attenuation pressure requirement before selecting the appropriate fan. This may well result in a need to select a different fan!

(21)

Accessories

Compact SCD/A -

Duct Mounted

21

063-0560-MAN150 063-0630-MAN200 150 200 1.4 1.3 063-0315-MAN150 063-0350-MAN150 063-0400-MAN150 063-0450-MAN150 063-0500-MAN150 PRODUCT CODE 150 150 150 150 150 1.2 1.1 0.7 0.9 0.6 B WEIGHT _KG 063-1000-MAN250 250 3.0 063-0900-MAN200 200 2.7 063-0800-MAN200 200 2.3 063-0710-MAN200 200 2.0 FAN DIA. A 315 350 400 450 500 560 630 710 800 900 1000 WB-SLC-007 REVOLUTION DETAIL OF FLEXIBLE CONNECTOR 1.0 1 1 A HH 24/07/06 1:3

Elta Fans Ltd. own the copyright of this drawing/ in writing from its owners Elta Fans Ltd. and must not be reproduced without permission purpose other than that for which it is supplied confidence and which must not be used for any specification document which is supplied in C

A B 063-0250-MAN150 250 150 0.5 063-0315-MAN150 315 150 0.6 063-0350-MAN150 350 150 0.7 063-0400-MAN150 400 150 0.9 063-0450-MAN150 450 150 1.1 063-0500-MAN150 500 150 1.2 063-0560-MAN150 560 150 1.3 063-0630-MAN200 630 200 1.4

Product

Code

B

Weightkg

Fan

Dia.

A

COMPACT FANS MATCHING FLANGES COMPACT FANS 1.0 MILD STEEL SEE TABLE PAINTED BEIGE (RAL 7032)

1 1 A MAT 03/12/99 1:6 DS DS I 560 636 45 1.6 16 11.5 605 709 630 45 1.6 16 11.5 674 250 306 30 1.6 466 567 515 421 382 400 450 500 315 350 40 1.6 45 40 1.6 1.6 30 30 1.6 1.6 A B C D 8 7.5 286 9.5 12 12 12 9.5 9.5 8 8 9.5 9.5 438 541 487 395 356 E F G EQUI-SPACED ON G PCD E HOLES F KG WEIGHT 0.5 0.7 1.0 1.2 2.2 2.6 3.0 3.5 PRODUCT CODE 061A-0630-C 061A-0560-C 061A-0500-C 061A-0450-C 061A-0400-C 061A-0350-C 061A-0315-C 061A-0250-C FAN DIA.

WB-SCD-006

THIS IS A C.A.D. PRODUCED DRAWING AND THEREFORE NO SUBSEQUENT MANUAL MODIFICATIONS WILL BE ALLOWED. TITLE TOLERANCES UNLESS OTHERWISE STATED. ± BY ISS CN. DATE CHKD ISS CN. BY DATE CHKD ISS CN. BY DATE CHKD ISS CN. BY DATE CHKD A3 A 1 B C D E F G 2 3 4 5 7 6 7 6 5 4 3 2 1 A B C D E F G DATE ISS CN. CHKD DATE BY ISS CN. CHKD BY DATE ISS CN. CHKD DATE BY CN. ISS CHKD BY USED ON B DIA A INSIDE DIA D MATL. C 061A-250-C 250 306 30 1.6 8 7.5 286 0.5 061A-315-C 315 382 30 1.6 8 9.5 356 0.7 061A-350-C 350 421 30 1.6 8 9.5 395 1.0 061A-400-C 400 466 40 1.6 12 9.5 438 1.2 061A-450-C 450 515 40 1.6 12 9.5 487 2.2 061A-500-C 500 567 45 1.6 12 9.5 541 2.6 061A-560-C 560 636 45 1.6 16 11.5 605 3.0 061A-630-C 630 709 45 1.6 16 11.5 674 3.5

Product

Code

B

C

D

E

F

G

Fan

Dia.

A

Weight kg 062-S1B 062-S1G

Product

Code

A

B

C

D

E

F

G

Weightkg TAPPED HOLE 5.5 43 50 64 062-S2B 062-S2 062-S1G D PRODUCT CODE _A _B _C 062-S2G 80 57 45 5 32 M8 12x9 M6 F E 20 G ÿ7

NOTE: REFER TO PERFORMANCE CHART FOR AV SELECTION WEIGHT Kg 0.040 0.100 0.100 0.102

WB-SB-008

BIFLOW DETAIL OF AV MOUNTS 1.0 1 1 A HH 24/07/06 1:1 3rd ANGLE PROJECTION DO NOT SCALE-IF IN DOUBT, ASK!

THIS IS A C.A.D. PRODUCED DRAWING AND THEREFORE NO SUBSEQUENT MANUAL MODIFICATIONS WILL BE

ALLOWED. TITLE TOLERANCES UNLESS OTHERWISE STATED. ± BY ISS CN. DATE CHKD ISS CN. BY DATE CHKD ISS CN. BY DATE CHKD ISS CN. BY DATE CHKD A3 A 1 B C D E F G 2 3 4 5 7 6 7 6 5 4 3 2 1 A B C D E F G DATE ISS CN. CHKD DATE BY ISS CN. CHKD BY DATE ISS CN. CHKD DATE BY CN. ISS CHKD BY USED ON

OF THESE VIEWS FOR MANUFACTURING PURPOSES ARE AT SUPPLIERS RISK.

REFERENCE PURPOSES ONLY. USE ANY DEVELOPMENT VIEWS SHOWN ON

B C A E F G D

Matching Flanges

Anti-Vibration Mounts

Flexible Connectors

· Fit to matching flanges to provide flexible connection

· PVC coated polyester · Supplied with plated steel band fixings · Alternative materials available to order

· Fit directly to fan case flange

· Provides easy connection to flexible connector or ducting · Powder coated steel (Pastel beige, RAL 7032)

· Fit directly to mounting feet

· Rubber with steel insert · Supplied as set of 4, complete with fixings

AXIAL FLOW

(22)

GUARD FIXING CLIPS 500 520 32 2.2 078C-1000-C 078C-0630-C 078C-0560-C 078C-0800-C 078C-0710-C 1000 1020 60 800 710 630 560 820 730 50 50 665 585 40 32 4.5 3.5 3.2 2.6 2.5 078C-0500-C 078C-0450-C 078C-0400-C 078C-0315-C PRODUCT CODE DIA 450 400 315 470 420 29 26 335 21 FAN _A _B KG 1.8 1.6 1.1 WEIGHT WB-SMC-009 MULTIFLOW SMC DETAIL OF INLET GUARD 1.0 1 1 A HH 24/07/06 1:3 3rd ANGLE PROJECTION DO NOT SCALE-IF IN DOUBT, ASK!

DRAWING No. SHEET OF ISSUE DRAWN BY DATE SCALE STATUS APPROVED CHECKED ELTA FANS LTD,

17 BARNES WALLIS ROAD, SEGENSWORTH INDUSTRIAL ESTATE, FAREHAM, HAMPSHIRE. PO15 5ST. Tel. 01489 566500 Fax. 01489 566555

FINISH MATERIAL SPECIFICATION DIMENSIONS ARE IN mm UNLESS STATED OTHERWISE

A B PRODUCT CODE 50 50 320 360 400 355 400 355 25 25 2.5 2.5 5.0 4.0 E 40 40 40 40 50 40 280 310 220 240 280 315 275 250 A 250 200 280 230 B 20 225 275 315 250 25 20 20 200 C 170 20 20 D WGT 1.3 2.0 2.5 2.0 2.0 2.0 2.5 1.5 2.0 1.6 F 1.0 KG 0.9 2 HOLES 10 060A-0630-C 060A-0560-C 060A-0500-C 060A-0450-C 060A-0400-C 060A-0350-C 060A-0315-C 060A-0250-C 250 315 350 400 450 500 560 630 FAN DIA A WB-SCD-002 COMPACT SCD DETAIL OF FEET 1.0 1 1 A HH 24/07/06 1:3

DRAWING No. SHEET OF ISSUE DRAWN BY DATE SCALE STATUS APPROVED CHECKED ELTA FANS LTD, 17 BARNES WALLIS ROAD, SEGENSWORTH INDUSTRIAL ESTATE, FAREHAM, HAMPSHIRE. PO15 5ST. Tel. 01489 566500 Fax. 01489 566555 Elta Fans Ltd. own the copyright of this drawing/ in writing from its owners Elta Fans Ltd. and must not be reproduced without permission purpose other than that for which it is supplied confidence and which must not be used for any specification document which is supplied in C

THIS DRAWING ARE SHOWN FOR A C B _E F D COMPACT FANS ROUND SILENCERS FOR COMPACT FANS (PODDED & UNPODDED)

2.0

1 1 D

HH 30/10/06

1:5 I

C No. D TAPPED HOLES ON E - PCD

AIR-FLOW

POD FITTED TO EP TYPE ONLY

EN = WITHOUT POD E = WITH POD or 1 or 2

SEE DIM 'A'

068-0400-*D**P 068-0450-*D**P 068-0500-*D**P 068-0560-*D**P 068-0630-*D**P PRODUCT CODE 068-0315-*D**P 068-0350-*D**P 500 602 653 713 783 1120 1260 630 560 900 800 1000 450 500 400 16 16 M10 M10 12 12 12 M8 M8 M8 674 605 26 22 487 541 436 15 18 13 32 26 48 39 18 22 16 27 32 22 57 46 31 37 26 ESTIMATED WEIGHT Kgs 415 450 B 630 2D 700 315 350 1D A A D C 8 8 M8 M8 E 356 395 9 11 1DENP 11 13 1DEP 15 18 2DENP 17 21 2DEP 068-0250-*D**P 250 500 350 8 M8 286 9 11 15 17

Elta Fans Ltd. own the copyright of this drawing/ in writing from its owners Elta Fans Ltd. and must not be reproduced without permission purpose other than that for which it is supplied confidence and which must not be used for any specification document which is supplied in C

THIS IS A C.A.D. PRODUCED DRAWING AND THEREFORE NO SUBSEQUENT MANUAL MODIFICATIONS WILL BE ALLOWED. TITLE TOLERANCES UNLESS OTHERWISE STATED. ± BY ISS CN. DATE CHKD ISS CN. BY DATE CHKD ISS CN. BY DATE CHKD ISS CN. BY DATE CHKD A3 A 1 B C D E F G 2 3 4 5 7 6 7 6 5 4 3 2 1 A B C D E F G DATE ISS CN. CHKD DATE BY ISS CN. CHKD BY DATE ISS CN. CHKD DATE BY CN. ISS CHKD BY USED ON

WB-SCD-005

B FA N DIA A POD DIA

AXIAL FLOW

Compact SCD/A -

Duct Mounted

Accessories

22

068-0250-*D**P 250 250 500 350 8 M6 286 7 9 11 13 068-0315-*D**P 315 315 630 417 8 M8 356 9 11 15 17 068-0350-*D**P 350 350 700 452 8 M8 395 11 13 18 21 068-0400-*D**PC 400 400 800 500 12 M8 438 13 16 22 26 068-0450-*D**PC 450 450 900 602 12 M8 487 15 18 27 31 068-0500-*D**PC 500 500 1000 652 12 M8 541 18 22 32 37 068-0560-*D**PC 560 560 1120 712 16 M10 605 22 26 39 46 068-0630-*D**PC 630 630 1260 782 16 M10 674 26 32 48 57

Product

Code

A

1D

B

Weight kg

A

2D

C

D

E

_{1DENP 1DEP 2DENP 2DEP}

Fan

Dia.

1 or 2

SEE DIM ‘A’ E = WITH POD orEN = WITHOUT POD

060A-0250-C 250 200 230 170 20 40 1.6 0.9 060A-0315-C 315 250 280 200 20 40 2.0 1.0 060A-0350-C 350 280 310 225 20 40 2.0 1.3 060A-0400-C 400 220 250 250 20 40 2.0 1.5 060A-0450-C 450 240 275 275 20 40 2.0 2.0 060A-0500-C 500 280 315 315 25 50 2.5 2.5 060A-0560-C 560 320 355 355 25 50 2.5 4.0 060A-0630-C 630 360 400 400 25 50 2.5 5.0

Product

Code

B

C

D

E

F

Weightkg

Fan

Dia.

A

078C-0250-C 250 270 18 0.9 078C-0315-C 315 335 21 1.1 078C-0350-C 350 370 23 1.4 078C-0400-C 400 420 26 1.6 078C-0450-C 450 470 29 1.8 078C-0500-C 500 520 32 2.2 078C-0560-C 560 585 32 2.5 078C-0630-C 630 655 40 2.6

Product

Code

Fan

Dia.

A

B

Weightkg

Impeller Guards

Mounting Feet

Silencers

· For free standing mounting of ducted fans · Fixes directly to fan case flange

· Powder coated steel (pastel beige, RAL 7032) · Supplied individually, less fixings

· For information on silencers and an explanation of the data, see p20

· Pre-galvanised sheet steel with perforated steel lining · Infill of glass tissue faced high density mineral wool

· For saturated or other special applications please refer to Elta

· Bright zinc plated steel

· Fix with clips & screws provided
