13. STABILISATORER - STABILIZERS

(1)

13. STABILISATORER - STABILIZERS

Modeller og egenskaper

Models and features

Qmatec Load handling AS – Industriveien 30 Østerhus, 4879 GRIMSTAD (Norway) - Tel +47 47 37 50 50 www.qmatec.com [email protected]

MODELLER

MODELS

F

Fast

Støtteben

F

Fixed

crossbar

M.O

Manuelt uttrekkbare støtteben med

motstående armer

M.O

Manual extendible outrigger with opposed

rods

M.P

Manuelt uttrekkbare støtteben med

parallelle armer

M.P

Manual extendible outrigger with parallel

rods

H.O

Hydraulisk utskyvbare støtteben med

motstående armer

H.O

Hydraulic extendible outrigger with opposed

rods

H.P

Hydraulisk utskyvbare støtteben med

parallelle armer

H.P

Hydraulic extendible outrigger with parallel

rods

H.P uc

Hydraulisk utskyvbare under-chassis

støtteben med parallelle armer

H.P

uc Hydraulic

extendible under-chassis outrigger

with parallel rods

H.LP

Hydraulisk utskyvbare støtteben med

parallelle armer, lang type

H.LP

Hydraulic extendible outrigger with parallel

rods long type

DH.P

Hydraulisk utskyvbare støtteben med

parallelle armer, doble utskyt

DH.P

Hydraulic extendible outrigger with parallel

rods with double extensions

DH.LP

Hydraulisk utskyvbare støtteben med

parallelle armer, doble utskyt, lang type

DH.LP

Hydraulic extendible outrigger with parallel

rods with double extensions long type

Kran / Crane

Teknisk Informasjon

Technical Information

T / m

Type

₉

_{Bygget av den Italienske produsenten}

ICM

9 ₉

Built by Italian manufacturer ICM

_{ICM stabilizers are produced in}

conformity to norm DIN 15018 and

UNI 11011;

9 ICM stabilisatorene er produsert i

henhold til normene DIN 15018 og

UNI 11011

1 2 – 4

9 All models are produced with steel

high level DOMEX 700

9 Alle modellene er produsert i High

Level DOMEX 700 stål

2 4 – 10

9 All cylinders are double acting with

check valve

9 Alle sylindre er toveis med ventil

3 10 – 23

₉

_{Alle sylindre er i C 45 kromstål}

₉

_{All cylinder rods are in steel C 45}

chromed

9 Stålrør er i St 35.4. Slangene er SAE

100 R2T

₉

_{The steel pipes are in St.35.4; the}

hoses are SAE 100 R2T

4 18 – 31

9 Manuelle uttrekk er enkelt siden det

brukes Teflon glideplater

₉

_{The manual extension is easier}

since we use Teflon sliding pads;

9 Forlengelse sylindrene er plasert

innvendig for bedre beskyttelse og

mindre størrelse på stabilisator

5 20 – 38

9 The extension cylinders are placed

inside the outriggers to get better

protection and smaller dimension of

the stabilizers

6 30 – 50

7 40 – 80

_{Leveranse Supply}

_conditions

9 Hver stabilisator kommer ferdig

montert

9 Each stabilizer is supplied fully

mounted

8 70 – 100

9 Stabilisatorene er lakkert med sort

primer

9 Stabilizers are supplied with black

primer coat

9

(2)

13. STABILISATORER - STABILIZERS

Fast Støtteben

Fixed Crossbar

Note

:

N: Standard Sylinder / Standard Cylinder L: Lang Sylinder - Long Cylinder S: Kort Sylinder – Short Cylinder

Alle modellene kommer med varierende sylinderposisjon

All version are supplied with Registrable cylinder positions.

Kran Kode - Code Tekniske data - Technical features Vekt

Weight [Kg]

“ R “ versjon

Varierende sylinderposisjon

Pris

Crane Type Modell Sylinder [ mm ] “ R “ Version

Registrable cylinder position

Price

[Ton x m] Type Model Cylinder L Ø Ps Ø Pd h x w P S Ø F H Jmin/max Kmin/max

2,0 - 4,0 1 F N 1800 40 70 120x80 420 355 160 530 65 125/425 0/250 7.480,- 4,0 - 10,0 2 F N 2000 40 70 120x80 420 355 160 530 70 125/425 0/250 9.440,- 10,0 - 23,0 3 F N 2000 60 85 180x100 530 455 160 685 135 110/550 0/430 10.032,- 3 F L 2000 60 85 180x100 650 580 160 810 150 110/640 0/560 10.432,- 18,0 - 31,0 4 F S 2100 60 95 200x100 540 470 200 700 155 100/550 0/450 11.624,- 4 F N 2100 60 95 200x100 620 550 200 780 165 100/640 0/530 11.968,- 4 F L 2100 60 95 200x100 700 635 200 865 170 100/640 0/530 12.512,-

(3)

13. STABILISATORER - STABILIZERS

Manuell og Hydraulisk utskyvbare støtteben, med

motstående armer

Manual and Hydraulic extendible crossbar, with

opposed rods

Note

:

Weight [ Kg ]

Pris

Crane Type Modell Sylinder [ mm ] “ R “ Version

Registrable cylinder position

Price

[Ton x m] Type Model Cylinder L E T h x w P S Ø F Ø Pd Ø Ps H Jmin/max Kmin/max

2,0 - 4,0 1 M.O N 1800 500 2800 120x80 420 355 160 70 40 530 110 125/425 0/330 9.384,- 4,0 - 10,0 2 M.O N 2100 600 3300 150x100 420 355 160 70 40 530 130 115/415 0/240 11.360,- 10,0 - 23,0 3 M.O N 2100 600 3300 200x100 520 455 160 85 60 685 200 110/540 0/420 14.208,- 3 M.O L 2100 600 3300 200x100 640 580 160 85 60 810 210 110/640 0/540 14.616,- 3 H.O N 2100 600 3300 200x100 530 455 160 85 60 685 210 110/540 0/420 18.768,- 3 H.O L 2100 600 3300 200x100 640 580 160 85 60 810 230 110/640 0/540 19.168,- 18,0 - 31,0 4 M.O S 2100 600 3300 200x120 540 470 200 95 60 700 225 100/550 0/440 18.088,- 4 M.O N 2100 600 3300 200x120 610 550 200 95 60 780 230 100/640 0/530 18.424,- 4 M.O L 2100 600 3300 200x120 690 635 200 95 60 865 240 100/640 0/530 18.976,- 4 H.O S 2100 600 3300 200x120 540 470 200 95 60 700 250 100/550 0/440 21.008,- 4 H.O N 2100 600 3300 200x120 610 550 200 95 60 780 255 100/640 0/530 21.352,- 4 H.O L 2100 600 3300 200x120 690 635 200 95 60 865 260 100/640 0/530 21.896,-

(4)

13. STABILISATORER - STABILIZERS

Manuell og Hydraulisk utskyvbare støtteben, med

parallelle armer

Manual and Hydraulic extendible crossbar, with

parallel rods

Kran Kode - Code Tekniske data - Technical features

Vekt

Weight

Pris

Crane Type Modell Sylinder [ mm ] [ Kg ] _{Registrable cylinder position}“ R “ Version

Price

[Ton x m] Type Model Cylinder L E T h x w P S Ø F Ø Pd Ø Ps H Jmin/max Kmin/max

10,0 - 23,0 3 M.P N 2100 1150 4400 200x200 500 455 160 85 60 685 290 110/540 0/420 19.920,- 3 M.P L 2100 1150 4400 200x200 650 580 160 85 60 810 300 110/640 0/540 20.464,- 3 H.P N 2100 1150 4400 200x200 520 455 160 85 60 685 320 110/540 0/420 24.752,- 3 H.P L 2100 1150 4400 200x200 650 580 160 85 60 810 330 110/640 0/540 25.296,- 18,0 - 31,0 4 M.P S 2100 1300 4700 200x235 530 470 200 95 60 700 340 100/550 0/450 24.272,- 4 M.P N 2100 1300 4700 200x235 630 550 200 95 60 780 350 100/640 0/540 24.616,- 4 M.P L 2100 1300 4700 200x235 700 635 200 95 60 865 360 100/730 0/610 25.160,- 4 H.P S 2100 1300 4700 200x235 470 470 200 95 60 700 380 100/550 0/450 29.232,- 4 H.P N 2100 1300 4700 200x235 620 550 200 95 60 780 390 100/640 0/540 29.576,- 4 H.P L 2100 1300 4700 200x235 700 635 200 95 60 865 400 100/730 0/610 30.120,- 20,0 - 38,0 5 H.P S 2200 1400 5000 250x235 560 470 200 95 60 750 435 135/585 0/410 33.656,- 5 H.P N 2200 1400 5000 250x235 610 550 200 95 60 830 440 135/675 0/500 33.992,- 5 H.P L 2200 1400 5000 250x235 710 635 200 95 60 915 460 135/675 0/500 34.536,- 30,0 - 50,0 6 H.P S 2200 1400 5000 300x235 540 565 200 105 70 850 540 120/620 0/470 37.728,- 6 H.P N 2200 1400 5000 300x235 750 735 200 105 70 1010 570 120/620 0/470 38.072,- 6 H.P uc S 2350 1575 5500 170x435 565 - 200 110 70 850 740 280/600 130/440 64.240,- 6 H.P uc N 2350 1575 5500 170x435 735 - 200 110 70 1000 760 280/760 130/590 64.576,- 40,0 - 80,0 7 H.P S 2200 1400 5000 305x280 540 460 200 120 90 850 740 # # 46.224,- 7 H.P L 2200 1400 5000 305x280 750 610 200 120 90 1020 760 # # 47.584,- 7 H.LP S 2200 1800 5950 320x320 510 460 200 125 90 850 885 170/670 0/420 64.240,- 7 H.LP L 2200 1800 5950 320x320 662 610 200 125 90 1000 900 170/770 0/570 65.600,-

(5)

13. STABILISATORER - STABILIZERS

Hydraulisk utskyvbare støtteben med parallelle

armer, med doble utskyt

Hydraulic extendible crossbar with parallel rods, with

double extension

Note

:

Weight [ Kg ]

Pris

Crane Tipo Modello Cilindro [ mm ] _{Registrable cylinder position}“ R “ Version

Price

Ton x mt Type Model Cylinder L E T h x w P S Ø F Ø Pd Ø Ps H J min/max K min/max

40.0-80.0 7 DH.P S 2300 2300 6900 320X350 510 460 200 120 90 850 1060 150/650 0/430 73.080,- 7 DH.P L 2300 2300 6900 320X350 660 610 200 120 90 1000 1080 150/750 0/580 74.440,- 70.0-100.0 8 DH.LP S 2300 2800 7900 330X446 170 460 200 120 90 850 1560 220/520 0/350 98.040,- 8 DH.LP L 2300 2800 7900 330X446 170 610 200 120 90 1000 1580 220/620 0/530 99.680,- 80.0-120.0 9 DH.LP S 2350 3000 8350 360X530 170 470 220 140 100 860 2040 220/520 0/340 På forespørsel 9 DH.LP L 2350 3000 8350 360X530 170 # 220 140 100 # # # # On request
