imotion LITE HELP Built to impress

imotion | LITE |

HELP

Built to impress

Retail promo point

Sun readable

All weather

Vandal proof

Casablanca, Morocco

imotion 46” portrait

single side

imotion

LITE

These semi-outdoor single-sided free-standing and wall-mount displays are intended for use in outdoor locations not directly exposed to sun and operational within -20°C to +40°C (in the shadow).

imotion

HELP

Is Infinitus specialty full-outdoor double sided display line. It is intended for organizations with strong accent on social responsibility. With integrated automatic external defibrillator (AED) it can act as lifesaving point for sudden cardiac arrest emergency cases, #1 cause of death worldwide.

Outdoor LCD specialists

Our range of advanced all-in-one systems contains imotion®_{, imotion HELP and imotion LITE} product lines intended for full and semi-outdoor locations.

imotion

Is full-outdoor (direct sun exposure) product line, designed to optimally isolate inner system from outdoor environment. With widest temperature operational range on the market and immunity to humidity and dust particles it allows constant peak performance of components in Canadian cold, Middle Eastern heat and dust, or South Eastern Asian rain and humidity.

Infinitus is EU based specialist developer of bespoke intelligent, highest reliability and performance full and semi outdoor LCD systems under brand imotion®_{, intended}

for 24/7/365 operation even in roughest conditions. Our full outdoor LCD digital sign technology presents quality standard

standard with unique features of operation in widest temperature range on the market (-40°C to +55°C), as well as unique inner enclosure “room temperature” operating conditions allowing peak performance for best sun-readability and longest life time of LCD panel. With manufacturing quality attention and numerous add-on options imotion systems are built to impress and can be used for interactive as well as simpler one way Full HD visuals.

Use and applications

Take your message to the streets

imotion large format Full High Definition LCD digital signs, with all add-ons and upgrades

are intended to be utilized in higher footfall areas as one-way or interactive:

• Information and/or entertainment source • Promotional and advertising medium

DOOH advertising

Possible applications:

• Advertising and Promotion • Facility mapping

• Wayfinding • Event list display

• Schedules and live scoring • Menu boards

• Welcome messaging

• Weather forecasting and clock • Virtual concierge

• Safety alerts • Readerboard • Flight schedule Interactive wayfinding and local business promotion

Our approach - Best environment for electronics

imotion full-outdoor as a quality standard

Highest reliability, peak performance of LCD panel and manufacturing detail quality are our engineering guidelines.

imotion technology delivers constant optimal “room temperature” (between 20°C and 25°C) inner enclosure conditions throughout widest temperature range on the market, detailed remote surveillance capabilities and automatic self-protection.

imotion advantages:

• Widest temperature operational range on

market +55°C (+75°C on sun)

• Advanced system self-protection features

and remote technical management

• Emergency failure technical team

messaging

• Immunity to humidity and particles entry

• Automatic cold/warm starts

imotion unique feature

Stable inner system “room temperature” between 20°C and

25°C enabling peak operation of LCD panel, high MTBF,

Gdansk, Poland

Outdoor LCD fails

It is “simply” not as simple

Most of outdoor LCD systems are at best offering limited performance and fail to deliver promised. Systems below are characterized as operational outdoor LCD systems with IP 65 enclosure and integrated high brightness LCD panel. As you can see these systems are incapable of sustaining good enough inner environment for images to appear visible in high ambient light.

Do not let “cheap” initial investment turn into nightmare for you and your clients.

Difference between good and bad outdoor systems is not only in bad visibility and

black spot occurrence, but also life time of integrated components which can degrade

extremely fast especially in case of constant overheating of electronics.

Finland Slovenia Germany

There is no such thing as bad weather …

… there are only bad outdoor LCD systems

Gdansk, Poland

Electronic operational requirements

LCD panel operation requirements Integrated electronics requirements

System malfunction protection

Evasion of critical

system failures

Compliance to digital

signage components

Issues of outdoor environment

Outdoor LCD systems - More than LCD in a box

It all starts with operation requirements of integrated electronics. These systems have to cope 24/7/365 with the worst of outdoor environment effects. Full-outdoor units are exposed also to powerful effect of solar radiation (UV, visible light and IR), which presents main difference to semi-outdoor units. Solar radiation is so potent it can raise temperature within enclosure far above ambient air temperature.

If we need to find one single biggest problem of outdoor LCD systems operation it will be heat generated by three factors: ambient air temperature, integrated high brightness LCD and electronics, and solar radiation.These systems are heavily influenced by powerful heat generators arising from ambient air, high brightness panels and huge solar load. For long life this problem needs to be managed as good as possible.

Ease of

maintenance

Minimization of

downtime

Rain, snow, salt Humidity and condensation Dust, dirts and toxic particles

Tourist info point

Saariselkä, Finland

Full outdoor public LCD system

imotion

Highest reliability all-in-one intelligent systems based on bespoke closed split HVAC system and ECU (electronic control unit) made for stable peak performance of components and lowest TCO.

All-weather

• Intelligent closed-split HVAC system (Heating Ventilating Air Conditioning)

• Operating at temperature range between -40°C and +75°C (at sun exposed area)

• IP65 waterproof, hermetically closed system protected from dust, dirt and moisture • Housing enclosure made of non-oxidizing

material aluminium and steel

Sun readable

• Up to 3.000 nit high brightness / high contrast professional full HD LCD panels

• Anti-reflective glass with less than 1% reflection

• Constant temperature inner system environment allows LCD panel to perform optimally

Vandal-proof

• Strong steel and aluminum housing protects inner system from vandalism

• 6mm + 6mm laminated / tempered glass prevents direct LCD panel assault

• Easy to remove and reinstall housing protective

masks provide simple but effective protection of core enclosure • Enclosed parts are not reachable to passersby

Extra reliable

• ECU monitoring and automatic self-protection

• ControlMotion Basic software remote system health monitoring • 2 year 24/7 operating warranty, with options up to 5 years • High performance digital signage specialized computer

imotion 52” portrait double side, Valašské Klobouky, Czech Republic

Ljubljana, Slovenia

(Since 2008)

imotion 65” landscape single side

imotion

HELP

Infinitus special line consists of double sided full outdoor imotion technology based display systems intended to leverage DOOH advertising with social responsibility. With integrated automatic external defibrillator (AED) slot and possibility of video education, it presents our solution to fight #1 cause of death worldwide, sudden cardiac arrest (SCA).

Did you know that on average every 2 minutes one person dies in USA because of sudden cardiac arrest. In Europe this figure rises to more than 700.000 people per year. In case of sudden cardiac arrest the survival rate is extremely low, between 3% and 7%. In case of quick

emergency care, the survival rate rises to 75%.

Socially responsible

• Lifesaving purpose

• Possibility to register unit as life saving device

Full outdoor

• imotion full outdoor technology

• Temperature operational range between -40°C and +75°C (at sun exposed area)

• Immune to humidity and dust particles

Sun readable

• High brightness / High contrast • Professional full HD LCD panels

• Anti-reflective glass with less than 1% reflection • Constant temperature inner system environment

allows LCD panel to perform optimally

imotionHELP55” portrait double side, Budapest, Hungary

Extra reliable

• ECU monitoring and automatic self-protection • ControlMotion Basic software remote system

health monitoring

• 2 year 24/7 operating warranty, with options up to 5 years • High performance digital signage specialized computer

Converging AED and digital communication for the benefit

of community and OOH owner edge

Tourist info point

imotion LITE 65”

portrait single side

imotion

LITE

A set of heating/ventilating technology based semi-outdoor set of displays delivering highest Full HD resolution images in high ambient light locations and other areas influenced by outdoor environment factors such as cold, heat, dust particles and fluctuation in temperature. Although not as nearly as powerful as imotion full-outdoor, it is nevertheless a great choice for sun protected outdoor areas, such as entrances to buildings and roof covered locations. Its slim, minimalistic design can invigorate number of areas and is available also in portable mode.

Weather protection:

• Powerful heating/ventilating thermal management system

• Dust particles and humidity protection • Operation between -20°C to +40°C

High ambient light visibility:

• High brightness / high contrast professional 20/7 operation LCD panels

• Anti reflective glass coating (0,5% glass reflectivity)

Vandalism protection

• Tough steel and aluminium housing • 4 + 4 mm tempered glass

• Special anti-graffiti coating (Add-on)

imotion LITE 55” Portrait

imotion LITE 46” Landscape Wall-mount

imotion 46” portrait single side

Gdansk, Poland

Outdoor LCD deployment considerations

To be able to utilize capabilities of imotion platform, clients should be aware of additional requirements needed. All companies offering Infinitus products are capable of designing a fit-to-your-needs digital communication system. Independently or with help of experts from different fields, they will deliver free and payable services to set-up your complete digital signage solution.

Pre-purchase stage services:

• Helping you to decide about the most appropriate application • Delivering all info needed to support your decision process

• Planning the installation in accordance with your needs and requirements • Choosing optimal content alternatives

• Choosing optimal/possible locations • Choosing appropriate software

• Proposing needed ICT network supporting

Installation set-up services:

• Installing imotion

• Concrete foundation set-up • Internet and power connection

delivery

• Creating ICT support network

• Integrating content management and content player software

• Designing content multimedia sign/s • Education of end-users about use of

the system

After purchase services:

• Additional content multimedia sign/s • Multimedia

• Internet and power

• Control and surveillance of the system • Regular and irregular technical

maintenance activities

• Digital signage software license

imotion HELP 55” portrait double side, Budapest, Hungary

New product

ControlMotion Basic is standard part of imotion units. For larger installations, ControlMotion Advance is available as an upgrade, enabling real time monitoring of whole network.

ControlMotion Software

ControlMotion Basic - powerful technical management software

Delivering additional reliability 24/7/365

• Enables remote control and supervision of imotion systems • Guarantees secure investment and owner’s good night sleep

• Enables immediate reaction of maintenance team in case of failures

control

motion

Enables system operator to control:

• Brightness level • Contrast level • Sound level

• Turning panel on or off • Turning sound on or off

• Daily scheduling of these activities • Integrated computer

• imotion web connection configuration

Delivers information on:

• Inner enclosure temperatures (3 sensors) • AC temperature

• Outdoor temperature • Evaporator temperature • Inner enclosure humidity level • Electronic power consumption • All relevant events

• Events needing attention via email Easy to use ContolMotion Basic web interface is powerful tool of maintenance team.

Our portfolio

Most complete outdoor LCD digital sign offer

Wide 24/7/365 operation engineered semi and full-outdoor portfolio with more than 30 products and our customization capabilities give our customers widest array of options, covering all populated areas.

Full-outdoor

Intended for sun exposed locations Temperature range: -40°C to +55°C

imotion - freestanding

• 32”/46”/55”/65”/70” portrait single side • 46”/55”/65” landscape single side • 46”/55”/65”/70” portrait double side • 46”/55”/65” landscape double side

imotion - wallmount

• 46” landscape wallmount

imotion

HELP

- freestanding

• 46”/55”/65” portrait double side

Semi-outdoor

Intended for shaded areas

Temperature range: -20°C to +40°C

imotion

LITE

- freestanding

• 46”/55”/65” portrait single side • 46”/55”/65” landscape single side

imotion

LITE

- wallmount

• 46”/55”/65” portrait wallmount • 46”/55”/65” landscape wallmount

imotion 46” portrait double side, Chur, Switzerland

Add-ons and upgrades

Touch screen (PCT)

Enables touch interactivity (even with gloves)

IP/USB Camera

Cameras for audience measurement and/or surveillance.

Wi-Fi

Wi-Fi internet connectivity and/or Wi-Fi hot spot

Anti-graffiti

Special coating enabling easier removal of graffiti

Logo and color

Logo plate and customer branding

Additional or upgraded PC More potent or additional computer integration

NFC module

Enables connectivity with smart phones and other NFC elements 18,5” side touch screen* Integrated additional side touch screen

Ambient light sensor Regulates brightness output according to light conditions Printer*

Enabling 7,62 cm /3” printouts for printing tickets and bills

ControlMotion Advance*

Enabling real time surveillance and emergency messaging of all imotion units at once

3G (mobile connection) 3G internet access

Color and design adaptation All imotion products can be branded, or in other color

Ultra high bright LCD panels* Up to 3.000 nit LED and transflective backlight LCD panel options

Bluetooth

Bluetooth share of contents

UPS*

Protects system from power grid irregularities

It is more than “just” a screen

With number of available add-on options imotion digital signs can extend the level of target audience engagement possibilities.

imotion

®

requiremen

ts

© 2013 Infinitus d.o.o. All rights reserved Specifications and design are subject to change without notice

Creating quality standard for outdoor LCD systems

Highest reliability and aesthetics

Diopso inc.
