V2.0
HYPER-CONVERGED
INFRASTRUCTURE SWITCHES
Quick Start Guide
S58 Series 10G/25G Switches
CON ETH USB SYS FAN PWR1 PWR2 STCKIND S 5 8 0 0-8TF12S 10/100/1000 BASE -T 100/1000 BASE-X 10G BASE-X 1234 1234 5678 5678 9101112 1314 1516 1718 1920 SYS ETH CON ID S 5 8 5 0-24T16S 10/100/1000 BASE-T 1 0 G 3456 12 78 1112 1314 910 1516 1920 2122 1718 2324 2728 2930 2526 31323334 35363738 3940 SYS ETH CON ID S 5 8 5 0-24T16B 10/100/1000 BASE-T 1 0 / 2 5 G 3456 12 78 1112 1314 910 1516 1920 2122 1718 2324 2728 2930 2526 31323334 35363738 3940Introduction
Accessories
Grounding Cable x1 Power Cord x2
Rubber Pad x4 M4 Screw x8
Console Cable x1
Thank you for choosing S58 series switches. This guide is designed to familiarize you with the layout of the switches and describes how to deploy the switches in your network.
Network Cable x1 Mounting Bracket x2 S5800-8TF12S CON ETH USB SYSFANPWR1 PWR2 STCKIND S 5 8 0 0 - 8 T F 1 2 S
10/100/1000 BASE-T 100/1000 BASE-X 10G BASE-X
12345678 1234 5678 9101112 1314 15 16 1718 19 20 S5850-24T16S S5850-24T16B SYS ETH CON ID S 5 8 5 0 - 2 4 T 1 6 S 10/100/1000 BASE-T 1 0 G 3456 12 78 9101112 13141516 17181920 21222324 25262728 293031323334 35363738 3940 SYS ETH CON ID S 5 8 5 0 - 2 4 T 1 6 B 10/100/1000 BASE-T 1 0 / 2 5 G 3456 12 78 9101112 13141516 17181920 21222324 25262728 293031323334 35363738 3940
Hardware Overview
Front Panel Ports
RJ45
CON USB
SFP+ ports for 1/10G connection An Ethernet management port
An RJ45 console port for serial management
ETH
10/100/1000BASE-T ports for Ethernet connection
SFP+
Ports
Description
S5850-24T16B
S5850-24T16S
Ports
Description
RJ45 SFP28 ETH CON10/100/1000BASE-T ports for Ethernet connection SFP28 ports for 10/25G transceivers
An Ethernet management port
An RJ45 console port for serial management
USB A USB management port for software and configuration
backup and offline software upgrade
A USB management port for software and configuration backup and offline software upgrade
RJ45 USB SYS ETH CON ID S 5 8 5 0 - 2 4 T 1 6 B 10/100/1000 BASE-T 1 0 / 2 5 G 3 45 6 1 2 7 8 9 1011 12 13 1415 16 17 1819 20 21 2223 24 25262728 29 3031 32 33 34 35 3637 38 ETH CON SFP28 39 40 RJ45 USB SYS ETH CON ID S 5 8 5 0 - 2 4 T 1 6 S 10/100/1000 BASE-T 1 0 G 3 45 6 1 2 7 8 9 1011 12 13 1415 16 17 1819 20 21 2223 24 25262728 29 3031 32 33 34 35 3637 38 ETH CON SFP+ 39 40
S5800-8TF12S
S5850-24T16S
CONETH USB SYSFANPWR1 PWR2 STCKIND
S 5 8 5 0 - 8 T F 1 2 S
10/100/1000 BASE-T 100/1000 BASE-X 10G BASE-X
1 23 45 67 8 1 23 4 5 67 8 9 1011 12 13 14 15 16 17 18 19 20 RJ45 10G SFP+ CON USB ETH SFP
Ports
Description
RJ45 SFP SFP+ CON10/100/1000 BASE-T ports for Ethernet connection SFP ports for 100/1000 BASE-X transceivers SFP+ ports for 1/10G transceivers An RJ45 console port for serial management
ETH An Ethernet management port
USB
Combo Ports
/
LEDs
S5800-8TF12S
A USB management port for software and configuration backup and offline software upgrade
S5850-24T16B
RJ45 SYS ETH CON ID S 5 8 5 0 - 2 4 T 1 6 B 10/100/1000 BASE-T 1 0 / 2 5 G 3 45 6 1 2 7 8 9 1011 12 13 1415 16 17 1819 20 21 2223 24 25 2627 28 29 3031 32 33 34 35 3637 38 ID SYS SFP28 39 40 RJ45 SYS ETH CON ID S 5 8 5 0 - 2 4 T 1 6 S 10/100/1000 BASE-T 1 0 G 3 45 6 1 2 7 8 9 1011 12 13 1415 16 17 1819 20 21 2223 24 25 2627 28 29 3031 32 33 34 35 3637 38 ID SYS ETH SFP+ 39 40 SYS P1 RJ45 P2 Location SFP+ CON ETH USB SYSFANPWR1 PWR2 STCKINDS 5 8 0 0 - 8 T F 1 2 S
10/100/1000 BASE-T 100/1000 BASE-X 10G BASE-X
1 23 45 67 8 1 23 4 5 67 8 9 1011 12 13 14 15 16 17 18 19 20
Blinking Green Quickly (2Hz) Blinking Green Slowly
(0.5Hz) Green
Amber Blinking Amber Quickly
Blinking Amber Slowly Off
LEDs
Status
Description
System is abnormal.
SYS
The system is running in u-boot mode. The system is normally running. The system occurs alarm or error.
No power or no system runs or runs abnormally. System software is in initial state.
System is initial in u-boot mode.
Green Green Blinking Green Green Blinking Green Green Blinking Green Amber Blinking Amber Off Amber Blinking Amber Off Off Blue Amber Off PWR ID ETH RJ45 Off
Power supply is ok.
Port is linked.
Power supply is abnormal.
Power supply is absent or single power supply is abnormal.
ID indication function enable. ID indication function disable. Port is receiving or transmitting packets. Port is not linked.
1G port is linked.
1G packets are receiving or transmitting. 10/100M port is linked.
Port is not linked.
SFP+
10G port is linked.
10G packets are receiving or transmitting. 1G port is linked.
1G packets are receiving or transmitting. Port is not linked.
10/100M packets are receiving or transmitting.
Green
Amber Off
25G port is linked.
25G packets are receiving or transmitting. 1G/10G port is linked.
1G/10G packets are receiving or transmitting. Port is not linked.
On
On Blinking Blinking
Installation Requirements
Phillips screwdriver.
Before you begin the installation, make sure that you have the following:
Site Environment:
Standard-sized, 19" wide rack with a minimum of 1U height available. Category 5e or higher RJ-45 Ethernet cables for connecting network devices.
Do not install the equipment in a dusty environment.
The installation site must be free from leaking or dripping water, heavy dew, and humidity. Do not operate it in an area that exceeds an ambient temperature of 45°C.
The installation site must be well ventilated. Ensure that there is adequate air flow around the switch.
Be sure that the switch is level and stable to avoid any hazardous conditions.
2 Hot-swappable Power Supplies
Grounding Points 4 Fans
GND PS2 PS1
S5800-8TF12S
Back Panels
S5850-24T16B/S5850-24T16S
4 Hot-swappable Fans 2 Hot-swappable Power Supplies
FAN4 FAN1 PS2 PS1 Grounding Point 100-240Vac 50-60HZ 3-1.5A 100-240Vac 50-60HZ 3-1.5A 100-240Vac 50-60HZ 3-1.5A 100-240Vac 50-60HZ 3-1.5A S5850-24T16S ID SYS ETH CON 10/100/1000 BASE-T 1 2 3 4 5 6 7 8 9 1011 12 13 1415 16 17 1819 2021 22
10G
25 2627 28 29 3031 32 33 34 35 36 37 38 39 40
Rack Mounting
1. Secure the mounting brackets to the two sides of the switch with eight M4 screws.
Mounting the switch
Desk Mounting
1. Attach four rubber pads to the bottom. 2. Place the chassis on the desk.
12345678 910 1112 1314 15161718 1920 2122 2324 2526 2728 2930 31323334 3536 3738 3940 ETH CON 10/100/1000 BASE-T 10G ID SYS S5850-24T16S S5850-24T16S ID SYS ETH CON 10/100/1000 BASE-T 1 23 45 6 7 8 9 10 11
Grounding the Switch
1. Connect one end of the grounding cable to a proper earth ground, such as the rack in which the switch is mounted.
2. Secure the grounding lug to the grounding point on the switch back panel with the washers and screws.
CAUTION:The earth connection must not be removed unless all supply connections have
been disconnected.
FAN4
2. Attach the switch to the rack using four M6 screws and cage nuts.
10G
15 16 17 18 19 20 21 22 23 24
Connecting the RJ45 Ports
1. Connect an Ethernet cable to the RJ45 port of a computer, printer, network storage, or other network devices.
2. Connect the other end of the Ethernet cable to the RJ45 port of the switch.
S5850-24T16S ID SYS ETH CON 10/100/1000 BASE-T 1 23 45 6 7 8 9 10 11 12 13 1415 16 17 18 19 20 21 22 23 24 FAN1
1. Plug the AC power cord into the power port on the back of the switch. 2. Connect the other end of the power cord to an AC power source.
Connecting the Power
10G
2627 2829 3031 32 33 3435 3637 38 39 40
Connecting the Console Port
1. Insert the RJ45 connector of the console cable into the RJ45 console port on the front of the switch. 2. Connect the other end of the console cable to the RS-232 serial port on the computer.
S5850-24T16S IDSYS ETH CON 10/100/1000 BASE-T 1 23 45 67 8 9 10 11 12 13
Connecting the SFP+ Ports
1. Plug the compatible SFP+/ SFP transceiver into the SFP+ port.
2. Connect a fiber optic cable to the fiber transceiver. Then connect the other end of the cable to another fiber device.
18 17 16 15 19 20 21 22 23 24 25 2627 2829 3031 32 33 3435 3637 3839 40
10G
17 18 19 20 21 22 23 24
25 2627 2829 3031 32 33 3435 3637 3839 40
Connecting the ETH Port
1. Connect one end of a standard RJ45 Ethernet cable to a computer. 2. Connect the other end of the cable to the ETH port on the front of the switch.
S5850-24T16S IDSYS ETH CON 10/100/1000 BASE-T 1 23 45 67 8 9 10 11 12 13 1415 16 17 18 19 20 21 22 23 24
Configuring the Switch
Step 1: Connect the computer to the Management port of the switch using the network cable. Step 2: Set the IP address of the computer to 192.168.1.x ("x" is any number from 2 to 254.). Set the subnet mask of the computer to 255.255.255.0
Configuring the Switch Using the Web-based Interface
? x OK Cancel General IP address: Subnet mask : D efault gateway : Yo u c a n g e t I P s e t t i n g s a s s i g n e d a u t o m a t i c a l l y i f y o u r n e t w o r k s u p p o r t s t h i s c a p a b i l i t y. O t h e r w i s e , y o u n e e d t o a s k y o u r n e t w o r k a d m i n i s t r a t o r f o r t h e a p p r o p r i a t e I P s e t t i n g s .
Internet Protocol Version 4 ( TCP/IPv4) Proper ties
Use the following IP address: Obtain an IP address automatically
Preferred DNS server: Alternate DNS server:
Validate settings upon exit A d v a n c e d . . .
. . . 2168 1 192 0 255 255 255 . . . . . . . . . . . .
Obtain DNS ser ver address automatically Use the following DNS ser ver addresses:
10G
25 2627 2829 3031 32 33 3435 36 37 3839 40
Step 3: Open a browser, type http://192.168.1.1, and enter the default username and password, admin/admin.
Step 4: Click Sign in to display the web-based configuration page.
Configuring the Switch Using the Console Port
Step 1: Connect a computer to the switch's console port using the supplied console cable. Step 2: Start the terminal simulation software such as HyperTerminal on the computer.
Step 3: Set the parameters of the HyperTerminal: 115200 bits per second, 8 data bits, no parity, 1 stop bit and no flow control.
Step 4: Enter the default username and password, admin/admin.
x Quick Connect Protocol: Serial Flow Control DTR/DSR RTS/CTS XON/XOFF Save session Show quick connect on startup
Open in a tab Connect Cancel COM3 115200 8 None 1 Port: Baud rate: Data bits: Parity: Stop bits: Name of pipe:
Troubleshooting
Power LED Working Abnormally
1. Check the power cable connections at the switch and the power source.
2. Make sure the power cord used matches the voltage and frequency of your local power.
1. Make sure the power supply is normal and the console cable is properly connected. 2. Check if the console cable is the right type.
3. Check if the control cable driver is properly installed on the computer. 4. Ensure the parameters of the HyperTerminal are correct.
HyperTerminal Displaying Abnormally
1. Check every port LED on the switch and make sure the Ethernet cable is connected properly. 2. Try another port on the switch and make sure the Ethernet cable is suitable and works normally. 3. Power off the switch and, after a while, power it on again.
4. Make sure the IP address of your PC is set within the subnet of the switch.
5. If you still cannot access the configuration page, please restore the switch to its factory defaults. Then the IP address of your PC should be set as 192.168.1.x ("x" is any number from 2 to 254) and Subnet Mask as 255.255.255.0.
Accessing the Web-based Configuration Page Unsuccessfully
Support and Other Resources
Download Help Center Contact Us https://www.fs.com/download.html https://www.fs.com/service/help_center.html https://www.fs.com/contact_us.html
Product Warranty
FS ensures our customers that any damage or faulty items due to our workmanship, we will offer a free return within 30 Days from the day you receive your goods. This excludes any custom made items or tailored solutions.
Warranty: S58 Series Switches enjoy 5 years limited warranty against defect in materials or workmanship. For more details about warranty, please check at
https://www.fs.com/policies/warranty.html
Return: If you want to return item(s), information on how to return can be found at
https://www.fs.com/policies/day_return_policy.html 5
