Engine Optimization Methodologies: Tools and Strategies for Diesel Engine Design

(1)

Engine Optimization Methodologies:

Tools and Strategies for

Diesel Engine Design

George Delagrammatikas

Dennis Assanis, Zoran Filipi, Panos Papalambros,

Nestor Michelena

The University of Michigan

May 24, 2000

(2)

BACKGROUND: VEHICLE AND ENGINE

FUNDAMENTALS ENGINE TUNING INVERSE DESIGN CVT, INJECTION TIMINGS MAP SHAPING AND MATCHING ENGINE FLEXIBILITY: COMPRESSION RATIO, CVT,HYBRID NOVEL TECHNOLOGIES

(3)

Motivation

• Federal Regulations

–

Fuel economy (CAFE)

–

Emissions (NOx, smog, and other pollutants)

• Public Awareness

–

‘Green’ movement

–

Global warming scare

• Decrease Dependence on Foreign Oil

(4)

Objectives

• Develop an engine optimization framework

–

21

st

century conventional and hybrid heavy truck

• Implement techniques to conventional vehicle

–

Define a problem analytically

–

Apply suitable driving cycle(s)

–

Investigate location of use on engine map

(5)

Euro III Steady State Test Procedure

(6)

Power Demands on Engine

(7)

HEV System Simulation Framework

ADVISOR Matlab-SIMULINK environment

Parallel HEV

ENGINE FUEL DELIVERY LOOK-UP TABLE

RPM TORQUE

(8)

Baseline Vehicle Parameters

Cummins M11-330 (246 kW) Diesel Engine

Wheel/axle assembly for heavy truck

Kenworth T400 Vehicle

Standard heavy vehicle accessory loads

Standard catalyst for CI engine

Eaton Fuller RTLO-12610B 10-Speed Transmission

Generic 10-spd constant efficiency gearbox

(9)

Baseline Cummins Engine Map

(10)

Driving Cycles Investigated

US06 REP05

FHDS FUDS

(11)

Engine Use Points for Various Cycles

US06 REP05

FHDS FUDS

(12)

Power Frequency for Each Cycle

US06 REP05

FHDS FUDS

(13)

Output Torque

Engine Speed

Ideal BSFC Line Generation

(14)

• Determine cumulative fuel throughput for

each cycle investigated

–

Interpolate BSFC from engine map for every

torque/speed combination for that given cycle

–

Integrate all BSFC’s from above step

–

Find the total time that engine is producing power

–

Mean effective BSFC = total BSFC/engine on time

Benefits of Flexible Engine Designs

Actual Transmission Case

(15)

Ideal BSFC

vs

. Power Level

Power

BSFC (g/kW-hr)

(16)

Benefits of Flexible Engine Designs

Ideal Transmission Case

• Find ideal BSFC transmission line on engine

map used for a given cycle

–

Interpolate BSFC for every visited power level on

the BSFC vs. Power graph

–

Sum of all BSFC’s is cumulative fuel throughput

–

Mean effective BSFC = numerical average of total

fuel throughput during time steps when engine is

(17)

Potential Benefits of Ideal CVT Design

0 20 40 60 80 100 120 140

US06 REP05 FUDS FHDS

4*BSFCmin 2*BSFCmin

Incr

eas

e in M

ean BSFC Per

Cyc

le

Incr

eas

e in M

ean BSFC Per

Cyc

le

(18)

Optimum Injection Timing Method

• Using an optimization framework

–

Vary injection timing for every torque/speed

combination (over 200 map points, ~100 executions

per point)

–

Computationally prohibitive

• Parallel computer framework

–

Run as many maps as you want at different

injection timings

(19)

Injection Timing Maps

Engine Speed

Output Torque

(20)

Optimum Injection Timing Map

Timing

(21)

Variable Compression Ratio Engine

• Hypothetical investigation of novel engine

design

–

Find the ideal fuel consumption benefit

–

Apply ideal transmission techniques from previous

slides

• Determine how BSFC can be optimized at

various power levels

–

First maximize power density to find engine’s

power upper bound

–

Allow engine controller to change parameters that

are not normally variable

(22)

Problem Formulation

• For each power level :

–

50, 100, 200, 300, 400, 500 kW

• Minimize BSFC, subject to:

–

overall phi < 0.6

–

20% < percent premixed burn < 40%

–

peak cylinder pressure < 150 bar

• Variables:

(23)

(24)

VCRE - Combined Map

TO

RQ

UE

TO

RQ

UE

(25)

Ideal BSFC Line vs. Power Level

170 180 190 200 210 220 230 240 50 100 150 200 250 300 350 400 450 500

Power (kW)

BS

FC (

g

/k

W

-hr)

vcre_bsfc base_bsfc

(26)

Hybrid Powertrain Investigations

(27)

Demands on Engine - CVT vs. 5-Speed

(28)

Demands on Motor - CVT vs. 5-Speed

(29)

Battery SOC - CVT vs. 5-Speed

(30)

Zero Delta SOC - CVT vs. 5-Speed

(31)

Additional Hybrid Clustering Scenarios

Power-Assist Battery Recharge 40 20 60

(32)

Future Directions

• How realistic is the variable compression ratio

engine for the driving cycles and vehicles we are

considering?

• How can we better quantify the benefits of

increased flexibility in transmission parameters?

• What are the effects of injection timing and

variable valve timing on engine map

characteristics?

(33)

Integration with Target Cascading

• Parameterize engine torque curve

• Maximize engine turndown ratio while

meeting mobility constraints

• Match maximum torque curve with a real

engine defined by high fidelity model

• Use engine visitation points in conjunction

with control strategies to meet BSFC and

emissions targets

• Send results back to top level for verification

and subsequent iteration

(34)

Parameterized Max Torque Curve - I

(35)

Parameterized Max Torque Curve - II

(36)

Sample Torque Curves

(37)

Engine

Matching

Subproblem

(38)

Conclusions

• High fidelity engine model can be used at

different levels in the design process

• Methods have been illustrated on a variety of

different engines

• Continue feed-backward work with ADVISOR

and extend methodology to VESIM
