Mission Briefing (1)
WHY RAID RECOVERY?
•
RAID recovery is EXPENSIVE!
•
Its more difficult than a single drive.
•
Its very time consuming.
•
Has more than one point of failure.
•
Many people have problems with
them and send me questions!
Mission Briefing (2)
Assumptions for this Talk
• We are assuming you have already
done what I previously described in
videos to repair the damaged drive.
• We are also assuming you know
nothing about how the data is
Mission Briefing (3)
Goals for this Talk!
• DIY:* Teach you how to rebuild
RAID yourself from my experiences.
• Do it as cheap as possible!
– i.e. free or under a $100!
• Do as much in software as quickly
as possible by sight and sound
Mission Briefing (4)
Whats it going to take?
• A bit of time...
• Lots of free disk space...
• You have to find the Pictures...
• Persistence and Experimentation...
• In some cases, Research
What is a RAID Array?
• Redundant Array of (Inexpensive or
Independent) Disks.
• Regardless of marketing on the box
some arrays are not “Redundant.”
• Different types of arrays need
different quantities of drives & you
need to know how many that is!
• JBOD’s such as in LaCie or generic
external enclosures.
• XFS/ZFS Arrays such as NAS drives
from Western Digital or Buffalo.
Covering Unusual Arrays
• Combinations with
offsets & RAID 0
JBOD Drives (1)
• Means “Just a Bunch of Disks” and they are just linked logically together end to end.
• These drives usually have no fan, get very hot and contain several drives. Sometimes the cables are melted together.
• Sometimes they are custom and employ different variations for different drives.
• Generally they can be recovered individually by scanning for file headers.
• One drive will have a File System Table of
some sort, other will be just raw files and no file system structure without the first disk.
Host Protected Area (HPA)
• ATA-4 Standard – Host Protected Area aka HPA, used to limit the capacity of a drive for storage of additional info usually
Windows Dynamic Disks
• Dynamic disks do not use partition tables,
they use LDM which is at the end of the disk
and needs to be done backwards.
• It uses one single partition occupying the
entire disk minus one cylinder. When
volumes are added or deleted the partition
table is not updated.
• This will be noticed right away by some data
recovery software like R-Studio.
Processing XFS/ZFS Arrays
• XFS / ZFS is very hard to recover
from due to the lack of commercial
software available. Some software
that can help are tools like:
– TESTDISK (free) supports repairing
XFS partitions and write it back out.
– UFS Explorer (ufsexplorer.com) has
Let’s
talk
about
RAID
ZERO!
RAID 0 Arrays Overview
RAID 0: How it works
• RAID 0 has NO redundancy and
does NOTHING to protect data!
Losing one drive loses all your data.
• RAID 0 should be called AIDS:
RAID 0 with more than TWO
• You can have a RAID 0 array with more than two
drives.
• There is generally no sequencing numbers for the
order.
• If there are four drives in the array, there can be
as many as 72 different combinations to test.
★
More than two drives? No backup? Thats just
CRAZY! Yes, Photographers I mean you! Your
Mac is made of the same crap as a PC :O>
WHICH IS THE FIRST DRIVE?
• In most cases you can determine
the first drive in the array,
depending on the slice size. How?
• In the first sector you will find an
MBR and at sector 63 you will see
the active boot partition, in most
Partition Example
RAID 0
• Put the first drive in the first slot of
whatever software you are using.
• Put the other drives in their slots.
• Set your size of your slice to your
guess…. Usually 64 is the defaults
(unless some tech messed with it)
• Scan for Pictures
(JPG,JPEG,GIF)
or MP3s.
Slice Sizes (2k to 2048k)
• Extract samples between the
boundaries possible i.e.:
»16k
»32k
»64k
»128k
»256k
»512k
How do you know when you
are wrong??
REVIEWING SAMPLES
EXTRACTED
Once
you get
it right
you get
Extracted MP3 Sound File
Extracted MP3 Sound File
Extracted MP3 Sound File
How Large
is your
RAID 5
Array??
RAID 5: Controllers
• There are two kinds of controllers for RAID, Host
Based and Discrete controllers.
RAID 5: How it works
• RAID 5 Array protects the server from
“down time.”
• RAID 5 does this by storing parity data on
all the hard drives.
• Parity is a formula that calculates error
correction data.
• By distributing parity across all drives it
creates a safety net for the data when a
RAID 5 Array Overview
RAID5 XOR
• Parity is calculated by using the
math function XOR with the data
with the number of slices in the row
to store the parity slice.
• For 3 drives it looks like this:
Why is it in for Recovery?
• There have also been times where RAID 5
arrays have failed a single drive, but no one
noticed before a second one failed.
• If two drives fail and the array goes down,
which drive do you need to repair???
RAID 5: How it works
• Usually reassembly of RAID is hard
because there are at least two or more
unknowns so it is hard to guess correctly:
– Disk Order is Unknown
– Slice Sizes can Vary
– Variations on Slice Arrangements
– Fragmentation and Boundaries
• Looking at the Pictures as Jigsaws has
helped me figure out the arrangements.
Slice Sizes (2k to 2048k)
• You still have the slice boundaries:
»16k
»32k
»64k
»128k
»256k
»512k
»1024k
(EXTRA) JPG Start and End
Contiguous Slice Sizes
2 Megs 1 Meg 512k 256k 128k 64kJigsaw: Do they Belong?
Do Slices Belong to Same
Are they in the wrong order?
Do Slices Belong to Same
Steps to rebuild RAID 5 array
1.Repair all necessary BAD drives.
2.Image the damaged drive(s) and recover as
many sectors as possible.
3.Image all the good drives.
4.Use software to analyze and re-weave the
images back together virtually.
Test data!
5.Write the newly weaved image back to a hard
drive to start the logical recovery (follow the
logical recovery section for the type of
Free Code to Assemble Array
• #!/usr/bin/perl –w #
# raid5 perl utility
# Copyright (C) 2005
# Mike Hardy <mike [at] mikehardy.net>
#
# This script understands the default linux raid5 disk layout, # and can be used to check parity in an array stripe, or to calculate
# the data that should be present in a chunk with a read error. my [at] array_components. = my $chunk_size = 64 * 1024; # chunk size is 64K
