ETSI EN 300 911 V6.8.1 (2000-10)
European Standard (Telecommunications series)
Digital cellular telecommunications system (Phase 2+);
Radio subsystem link control (GSM 05.08 version 6.8.1 Release 1997)
GLOBAL SYSTEM FOR MOBILE COMMUNICATIONS
