WebLogic Server Administration

(1)

ORACLE PRODUCT

LOGO

WebLogic Server Administration

Roger Freixa

(2)

WebLogic

Concepts

(3)

Key Concepts

WebLogic Terminology

•

Domain - group of instances and clusters under

unified control

•

Administration Server - central configuration

controller for the domain

•

Managed Server - Instance that hosts

applications and required resources

•

Cluster - group of managed servers to provide

increased scalability and reliability

•

Node Manager - per-machine process used to

(4)

Key Concepts

(5)

Key Concepts

Clusters

•

Can have zero or more clusters in a domain

•

Clusters can have one or more servers

•

Some servers in a domain may not belong to any cluster

(6)

Key Concepts

(7)

Installation

& Configuration

(8)

Installation (add ZIP installer)

Installer

• Different installers

•

Net (selective download) installer, Package (full) installer, Generic (jar, Unix) installer

One installer - different install modes

•

Graphical mode, Character mode, Silent (scripted) mode

8

Custom/Selective Installation

Can choose installation of core

application server only

Optionally add Admin Console,

(9)

Installation

Install Specifics

• Middleware Home (formerly “BEA Home”)

• To store one or more installed products (eg. WLS, WLI, WLP, SOA Suite) • Traditionally c:\Oracle\Middlware or /opt/oracle/middleware

• Recommendation: Use separate MW homes for separate products

• WebLogic Home

• To store installed WebLogic product, containing all the WebLogic library JARs, executables,

9

• To store installed WebLogic product, containing all the WebLogic library JARs, executables, tools, licence info, examples and scripts

• Usually a directory underneath MW home, eg.: c:\Oracle\Middleware\wlserver_10.3 or

/opt/oracle/middleware/wlserver_10.3

• Neither MW nor WebLogic Home should be used to store configuration of

Domains

(10)

Domain Configuration

Domain

• Reminder: Collection of servers and clusters managed centrally

• 1 Admin Server per Domain for centralised administration

• Domain configuration stored locally to the Admin Server (see <domain>/config/config.xml)

• Config is 'pushed out' on demand by Admin Server to Managed Servers

• Options to Create a Domain

10

• Options to Create a Domain

• Domain Configuration Wizard

• WebLogic Scripting Tool (WLST) in Offline mode

(both can use Domain Templates to provide a 'pre-canned' outline structure)

• Additional Options to Modify an Existing Domain *

• Admin Console

• WLST Online mode

(11)

Domain Configuration

WebLogic Domain Structure

(12)

Domain Configuration

Domain Configuration Wizard

•

Graphical or Character mode

•

Silent mode no longer supported –

use WLST instead (far more

flexible)

•

Configure, servers, clusters,

addresses, ports, machines,

data-12

addresses, ports, machines,

data-sources, JMS modules and many

others

•

Default templates provided (eg.

Basic WLS Domain Template) or

choose own custom template

(13)

Administration

13

(14)

Server Start

Many Options

• Java Node Manager (Best Option for HA)

• Use Admin Console | Control | Server Start tools (except for Admin Server) • Use WLST based Node Manager nmStart() function

• Server/JVM start-up parameters obtained from Domain Config (config.xml) • Automatic restart of failed servers

• Supplied Command Line Scripts

14

• Supplied Command Line Scripts

• Admin Server: <domain>/bin/startWebLogic.sh

• Managed Server: <domain>/bin/startManagedWebLogic.sh MngdSrvr

t3://admin-host:adminport

• Server/JVM start-up parameters sourced from 'setDomainEnv.sh

• Operating System Service

• A 'Windows Service' configured using the WebLogic 'beasvc' tool • Custom start/start/restart init.d script on Unix/Linux

(15)

Node Manager & WebLogic

Start/Stop WebLogic Managed Servers Remotely

•

Start/Stop servers remotely via:

• Admin Console

• JMX

• Command Shell

• ANT / WLST

•

Small 'agent' process running on

•Two choices

•Java Node Manager (more established)

•Script (SSH) Node Manager

15

•

Small 'agent' process running on

host machine (Java NM)

•

Supports multiple domains

•

Looks after one or more WLS

instances on the physical machine

•

Server health monitoring

•

Automatic server re-start upon

(16)

Management

Domain Management

Runtime Management

• Performed directly or in-directly via JMX

• Most operations do not require restart

• Variety of tools

• Administration Console

• WLST (online mode)

• Oracle Enterprise Manager

16

• Oracle Enterprise Manager

• Java client (using JMX API)

• Third-party tools (eg. HP OpenView)

Build-time Management

• Domain Configuration Tool • WLST (offline mode)

• Only 'supported' way to automate the building of domains from scratch

(17)

Scripting

WebLogic Scripting Tool (WLST)

Command-line/scripting tools for WebLogic domains

• Offline (not connected to live server - primarily for domain creation)

• Online (connected to live server - primarily for runtime monitoring)

• Interactive mode (a command shell)

• Scripted mode (for automation)

Jython based

17

Jython based

• Python code in JVM

• WebLogic specific set of management

APIs

(18)

Scripting

The Value of WLST

It's a “must use” which most customers are using today

• Stable supported API for domain creation

• Easy access to WebLogic JMX MBeans

• Enables flexibility for generating dev/test/prod domain

• But beware: it has a learning curve (Jython, WLST APIs) Repeatable automated process for domain creation

18

Repeatable automated process for domain creation

• Typically property file driven

• Greatly reduces opportunity for manual errors

• Single command to create a complex domain

• Pays-off even for scripting domains for the development lifecycle of project (not just for test/prod)
