PatchView+
™
The
Next
Generation
Intelligent Infrastructure
Management Solution
2 3
The Challenge: Physical Network Infrastructure is
Vital to Business Yet More Difficult to Manage
With the rise of global online business, communication networks and data centers are becoming increasingly vital to the success of organizations, and are constantly required to increase output while maintaining stability and reliability - since every minute of downtime translates into lost earnings.
Maintaining network infrastructure, however, is increasingly difficult: as data centers become larger and more geographically distributed, they pose a major burden on IT budgets and are a challenge to manage and maintain manually.
Manual network maintenance is labor intensive and error prone; and since most downtime stems from errors in the physical network, manual maintenance may also contribute to the occurrence of downtime.
.
The Answer: PatchView+ Intelligent
infrastructure Management
PatchView+ is the next-generation Intelligent Infrastructure Management solution (IIM) from RiT Technologies, the inventors of IIM.
PatchView+ brings real-time visibility, monitoring and control of all network physical-layer components; identifying points of failure in real time before they escalate; automating work processes and eliminating manual errors; provisioning new equipment and enabling full utilization of all IT assets - down to the last port.
Support for Interconnect Topology
PatchView+ is the first IIM solution to truly support interconnect topology, as well as cross-connect and mixed network topologies. So IT managers can deploy it for optimal management and control in any type of network – now or in the future.
What PatchView+ Does for your Network:
•
Reduced network downtime and improved output.•
Increased work efficiency and elimination of errors.•
Support for interconnect topology.•
Reduced power consumption.•
Lower management and technician overhead.•
Optimized utilization of infrastructure.Support for Interconnect Network Topology
PatchView+ is the industry’s first IIM solution to truly support mixed interconnect, cross-connect and combined topologies, as well as combined copper and fiber cabling. PatchView+ supports future Ethernet protocols (including 1/10/40/100 Gbps over copper and fiber respectively).
New Architecture that Saves on Space and Power
PatchView+ requires Zero U of rack space to support an unlimited number of ports, which means major reduction in the number of panels inside the rack and reduced power, cooling and space consumption. Fewer components also mean fewer points of failure.
A Comprehensive Real-Time View of the Entire Network Infrastructure
The IP Discovery Module creates a visual map of the complete network that is updated in real-time: from building and floor level, down to cabinet, rack, device and port level. The map includes device location, IP and MAC address, host name and type, as well as precise links between devices, switches and ports.
Monitoring and Alerting
PatchView+ continuously monitors the network, including all physical connections and environment sensors; sending proactive alarms on any threshold deviations or a compromise of pre-defined rules.
Detailed Reports
PatchView+ generates detailed reports, alerts and notifications according to pre-set rules, providing vital information on a wide array of network variables such as switch utilization, connectivity, work orders, and more.
Automated Work Orders
PatchView+ generates automated guided work orders, with a mobile application and light indicators to rack and panel; so technicians can get to the right place in minimum time and update upon completion with zero manual errors.
Equipment utilization
PatchView+ checks equipment utilization, such as switches and panel ports, so managers can ensure that all ports on current switches are utilized before investing in additional expensive equipment.
PatchView+: The Next Generation
Intelligent Infrastructure
Management Solution
Provisioning, Asset Management and Support for Network Changes
The PatchView+ automatic provisioning module optimizes placement of IT equipment according to space, power and cooling variables for effective lifecycle management and planning, including “what if” scenarios and simulation of potential changes.
Improved Network security
The “Unauthorized Device” feature designates specific devices to ports and generates alerts if unauthorized connects/disconnects to the ports are attempted. In addition, the patented ID Key detects attempts at unauthorized connections to IT assets such as servers and switches.
PatchView+ also complements application security solutions, providing the physical location of the infected device and helping IT staff zero-in quickly on security threats.
Strong Integration with External Applications
PatchView+ integrates seamlessly with external applications such as building management systems, IT systems and billing systems, using an easily deployable SDK.
Environment Monitoring
Environment sensors provide real-time monitoring and alerting to climate deviations at the rack level, so managers can be alerted to equipment overheating and other malfunctions before damage is done.
Operational
Efficiency
Cost
Savings
N
ew f
ea
tur
e
N
ew f
ea
tur
e
Customer Highlight
Network Security
The PatchView+ ID Key which enables PatchView+ to track network devices in real time, also detects attempts at unauthorized connections to devices such as switches and servers.
A RiT customer commented, “If an unauthorized user tries to connect to one of our servers, panels or switches anywhere in the world, or hook up an unauthorized device - we know about it immediately.
“How much is this worth to me? Well, how much our customers’ confidential information – in fact all my business information – worth to me?”
The link information is then gathered by the PatchView+ Manager that uses it to provide various services such as mapping the network, alerts, reports and more.
A visual map of the physical connectivity between the switch port to an outlet.
Mobile application to manage and update work orders from tablet and smart phone.
This functionality is achieved with the PatchView+ patented Smart ID Key that resides in the switch port and stores the link information. The PatchView+ patented
technology provides a designated ID number to every IP active equipment port located in the IT cabinets.
This enables to identify and track any patching changes made to the network, regardless of vendor or connection methodology (through support for RJ-45, LC or MPO connector interface).
PatchView+ Manager
Software Platform
The PatchView+ manager is a robust, highly versatile platform with an intuitive GUI for managing every aspect of your data center.
PatchView+ Software Features:
•
Support for interconnect, cross connect and combined network topologies.•
IP Discovery Module creates a visual map of all IP-driven devices in the network, providing location, link information, IP and MAC address, host name and type; and providing exact links between devices, switches and ports.•
Proactive alarms and notifications, including “unauthorized device” identification.•
Real-time updating of the network map in case of any changes to equipment status or connectivity.•
A web application that can be installed on any computer enables remote monitoring and control of multiple sites.•
Detailed reports compiled and generated according to pre-set rules, provide information on a wide array of network variables such as switch utilization, connectivity status, work order status, environment and more.•
Automatic provisioning of new equipment enables to place IT assets optimally, taking into account variables such as space, power and cooling, available switches and ports, and more.•
Automated work order generation, including multi-tasks; with tablet and smart phone application for onsite work order execution by technicians, real-time supervision of work progress, and real-time updating of network database upon completion.•
Integration with external applications such as BMS, IT, management systems and billing, using an easily deployable SDK.•
“Unauthorized Device” designates specific devices to ports and generates alerts if unauthorized connects/disconnects are attempted.PatchView+
Business Case
Worldwide deployment and
support services, with the RiT
extensive partner network.
The best solution on the market,
with support for the future network.
Reduced costs through improved
network utilization, better planning
and lower maintenance overhead.
Reduced downtime and
disruption to network.
Increases the network’s ability to
support critical business processes.
How PatchView+ Works
Customer Highlight
Customer Highlight
Ensuring Full Utilization of Assets
Sometimes a single IIM function deployed once can save the organization more than the total investment in IIM. A large international university deploying PatchView+ ran the automated device-tracking feature that discovers lost or “orphaned” equipment.
As a result they discovered that 40% of their switch-ports were not being used. So an array of hundreds of switches costing over $500,000 was not being fully utilized. With PatchView+ they were able to locate the vacant ports, postponing a planned procurement of additional expensive switches.
Using PatchView+ for Billing
A RiT customer integrated PatchView+ with its Oracle Services System in order to enable accurate billing of business units.
•
The Oracle system sends out work order requests to PatchView+ for technicians to service the business units.•
PatchView+ generates the work orders for the technicians.•
Once the work orders are completed, PatchView reports back to Oracle.•
Oracle issues billing to business units for the labor and for added network connections.switch PatchView+ Collector Users LAN SQL PatchView Manager Intelligent Panel Environment Controller PDU Tablet 6 7
PatchView+ Hardware
PatchView+ Hardware supports cross-connect and interconnect network topologies; as well as copper, fiber and mixed solutions rated at 10 Gbps or 40/1000 Gbps, requiring 0u (Zero U)of rack space for an unlimited number of ports.
PatchView+ Hardware also includes the patented Smart IDKey technology for identifying link information and is designed with a minimum number of components to maintain simplicity, ease of installation and deployment.
PatchView+ Hardware Features:
•
True support for the interconnect environment.•
Cross-connect and Interconnect network topologies.•
Patented Smart ID Key stores useful link information utilized by other system components (such as switch, rack, cable type, and revision level).•
Rack light indicators and panel LED lights point technician to exact location.•
LED signaling of make/break status.•
High-end smart copper and fiber management frames and cassette trays.•
Zero-U Collector installation.•
Support for environmental controllers and sensors.•
High security.•
Auto-detection/registration of newly added or moved collectors/patching frames.•
Audible alert for unauthorized make/break operations.PatchView+ Environment Controller:
Connects the PatchView+ controller to temperature and humidity sensors. Supports also rack-indicating flashing beacons.
PatchView+ Hardware Componenrs:
PatchView+ Copper Frame:
A cost-effective panel that supports both interconnect and cross-connect topologies.
PatchView+ Copper Patch Cord:
High performance category 6A cord supporting 1 and 10 Gbps.
PatchView+ Fiber Trays:
A special modular design supporting mixed cross-connect and interconnect topology. Available in single and multi-mode.
PatchView+ Fiber Cords:
A high performance fiber cord supporting multi-mode and single-more applications.
PatchView+ Card:
A pluggable device that supports physical network identification on interconnect and cross-connect topologies. Automatically detects and reads up to 24 smart ID devices present on each copper or fiber tray.
PatchView+ Collector:
Provides communication between the PatchView+ Cards and the network system. New architecture saves on ports in the main switch and supports cascading architecture for unlimited network growth.
PatchView+ Hardware Architecture
PatchView MPO MPO panel:
A high performance fiber cord supporting multi-mode and single-more applications.
