Electrical Distribution

Services from

Schneider Electric

Life-cycle Solutions to Help

Keep Your Facility Safe, Reliable,

Productive and Efficient

range of electrical distribution services

to support the life-cycle of any manufacturer’s equipment.

Our solutions include:

Any brand. Any industry. Any time.

Engineering Services

• Solutions for OSHA and NFPA 70E Compliance

• Power System Design and Upgrades

• Power System Assessment Services

• Power System Analytical Studies

New Installation Services

• Start-Up and Commissioning • Spare Parts • Extended Warranty • Multi-Year Maintenance Agreements • Engineering Studies » Time-current Coordination Analysis » Short Circuit Analysis » Arc Flash Analysis • Training Services

Maintenance and Testing Services

• Preventive Maintenance & Testing • Predictive Maintenance Solutions » Infrared Windows » Wireless Temperature Monitoring System (WTMS) » Partial Discharge Monitoring • Multi-Year Maintenance Agreements • Additional Services » Circuit Breaker Testing — LV » D.C. High Potential Testing » Grounding System Testing » Relay and Metering Calibration » Rotating Equipment » Variable Frequency Drive and Softstart Repair » UPS and Battery Maintenance

Modernization and Upgrade Solutions

• Switchgear Modernization Solutions » Direct Replacement — LV/MV » Retrofill Solutions — LV/MV • Motor Control Center Upgrades » Direct Replacement Units » Retrofit OEM Bucket • Additional Services » Circuit Breaker Reconditioning » Contactor Conversions for Motor Starting Applications » Network Protectors » Legacy Product Support and Upgrades

Substation Solutions

• Engineering, Procurement, and Construction • Maintenance, Repair, and Upgrade • Power Transformer Services • Instrument Transformer Services • Substation Equipment » VOX Outdoor Dead Tank Circuit Breaker » Powersub™ _{Vacuum Circuit Breaker Type FVR} » Metal-Clad Switchgear » Walk-In Enclosures

Custom Solutions

• Match-in-Line or Custom-Sized Switchgear • Solar Substation Design • Complete Turnkey Solutions

Emergency Preparedness

• Emergency Response — 24/7 • Temporary Generator Connection • Emergency Action Plan

Nothing Operates Without a Reliable Flow

of Electricity.

Whether you are concerned with providing a safe workplace, increasing electrical reliability, boosting

productivity or reducing operating costs,

you can count on our nationwide network of professional

engineers and qualified service representatives

to help address your specific requirements.

In addition, through our

Projects and Engineering Center

and

Program Management Office

, we provide

full-service contract and project management capabilities to assist with complex or high-risk projects. The

result is a streamlined, reliable project solution.

Emergency

Engineering Services

Schneider Electric Engineering Services provides industry-leading expertise to

address all of your power system requirements to help ensure

safe, reliable, and

continuous power.

For over forty years, our power system engineers have completed over 10,000 power system assessments, studies, and designs for our customers. We are focused on helping facilities manage their energy and solve complex power system issues that may involve equipment, automation, or the utility. Our professional engineers have in-depth knowledge of power distribution and control equipment with advanced expertise of calculation methods as well as industry codes and standards.

Electrical hazards

cause more than

300 deaths and

4,000 injuries in the

workplace each year.

(Source: ESFI)

Arc flash mitigation

strategies are

available for any

manufacturer’s

electrical equipment.

Solutions for OSHA and NFPA 70E

Compliance

Schneider Electric is a recognized leader in promoting electrical workplace safety and helping companies comply with the requirements of NFPA 70E. Basic compliance to NFPA 70E requirements is established with a five-step process: 1. Develop and Audit an Electrical Safe Work Practices Policy 2. Conduct an Electrical System Study to Determine the Present Degree of Arc Flash Hazards and Apply Equipment Labeling 3. Ensure Adequate Supplies of Personal Protective Equipment (PPE) and Proper Tools 4. Conduct Regularly-Scheduled Safety Training and Audits for All Electrical Workers 5. Maintain All Electrical Distribution System Components In addition to the NFPA 70E requirements, Schneider Electric recommends a crucial sixth step to optimize the safety and performance of the power system. 6. Follow Strategies to Mitigate and Control Arc Flash Hazards, which may include: » Overcurrent Protective Device (OCPD) Coordination Study » Upgrade Switchgear with a Virtual Main Relay » Infrared Viewing Windows » Remote Racking System » Wireless Temperature Monitoring System

Power System Design and Upgrades

We have the expertise to meet requirements for the most challenging design and upgrade projects. Our portfolio includes customers in every industry segment — from data centers to steel mills. Projects can be customized from basic design consultation to feasibility studies to a complete turnkey solution. Our capabilities include: • Substation Solutions • Switchgear Modernization • Control and Protection System Upgrades • Generator Backup Design and Construction • Power Factor Correction and Filter Design • High Resistance Grounding Conversions

Power System Assessment Services

Our assessment services provide a roadmap to optimize future capital and operational expenditures. They are customized based on your need to reduce risk to your facility from: reliability issues, process disruptions, code violations or outdated workplace safety requirements. Included in this category are:

• Power Quality Analysis

Technologies such as variable frequency drives (VFD) and robotic welders are designed to lower energy costs, but they also can give rise to unwanted harmonics and transients within an electrical system. Capacitor switching, motor starting, and ground faults within the utility infrastructure can also cause transients. The result may be only an annoyance or a shutdown that can cost hundreds of thousands of dollars. Our registered professional engineers will document the symptoms, examine damaged equipment, assess the power and grounding in the area, collect data using temporary monitors, and develop a report of findings that identifies the most probable cause. The report will include cost-effective mitigation recommendations to prevent future occurrences of the problem.

• Power System Grounding Evaluation Lack of proper grounding translates into an increased chance of fire, data and equipment losses, process anomalies, plant shutdowns, and workplace safety hazards. Components of a grounding system are subject to corrosion due to electro-chemical, electrolytic, or chemical reactions. Facilities that have sensitive electronic equipment are particularly vulnerable to disruptions. Our power system engineers will develop a scope of work to address your area(s) of concern.

We have over

100

strategically-located professional

engineers who

are

collectively

registered in every

state of the U.S. to

meet state licensing

requirements.

For more than forty

years, our power

system engineers

have completed

over 10,000

power system

assessments,

designs and analyses.

• Equipment Condition Evaluation, Risk

Assessment, and Contingency Planning Electrical distribution equipment is subject to degradation due to age, environmental stresses, and heat. Our professional engineers produce a basic* equipment condition evaluation by visually inspecting the equipment during a walk-through of the facility. For each non-optimum condition identified during the equipment condition assessment, a measure of risk can be defined. A contingency plan identifies a power system’s key components (major assets) and evaluates available alternatives, in case of a major asset loss. It also produces an action plan to be implemented should a major loss occur.

* A more detailed evaluation, which is performed by removing equipment covers, is most economically accomplished during the data collection phase of an arc flash study.

Power System Analytical Studies

Our analytical studies help ensure your electrical system operates as it was designed and intended. Each study includes a detailed report of findings along with corrective recommendations to help maximize the reliability and operational efficiency of your system. Our broad range of analyses includes:

• Protective Device Time-Current Coordination Analysis: Evaluates an electrical system’s protective devices, including relays, fuses and circuit breakers, and the equipment to which they are applied.

• Short Circuit Analysis: Calculates the fault current levels throughout the power system. The interrupting duties of the devices being analyzed are compared with the available fault currents.

• Load Flow Analysis: Addresses present electrical system deficiencies or identifies system requirements to meet future demand. • Harmonic Analysis: Found in facilities with a large number of non-linear loads (including electronic networks), a harmonic analysis identifies the sources of the power quality issues that can reduce system efficiency and increase operating costs.

• Motor Starting Analysis: The most significant effect of starting large motors is voltage sag, which extends the acceleration time, potentially causing thermal and mechanical stresses. This analysis calculates the voltage, current, and the accelerating torque of motors during the starting process.

• Switching Transient Modeling and Analysis: Determines stresses that system components are exposed to and recommends corrective measures. • Reliability Analysis: Quantifies the probability that a system or component will operate as intended. These are typically performed for mission-critical power systems.

• Substation Ground Grid Analysis: Optimizes grid geometry and evaluates high-risk areas of the switchyard. Opportunities for risk mitigation are also identified. • Stability Analysis: Evaluates various power system scenarios corresponding to switching actions or the initiation of a fault. They are typically applied to facilities that utilize large generators.

New Installation Services

If you are installing new equipment, Schneider Electric Services recommends

the following services to maximize your investment

throughout the entire

product life cycle. Our new installation services help reduce the risk of costly

downtime and delays.

Start-Up and Commissioning

Our start-up and commissioning services confirm that your equipment is installed properly, meets factory standards, and passes our stringent performance tests to help minimize downtime and delays in the future. Not only do we perform the standard electrical, mechanical, and visual equipment inspections, we also check the equipment and components to ensure they are set up and functioning correctly. Electrical testing is also performed to check insulation, current path, functionality, and sequencing to minimize costly downtime.

Spare Parts

We understand the criticality of your electrical equipment and the importance of having spare parts on hand to minimize downtime. Our services will evaluate your electric system, identify the equipment that is critical to your operations and recommend specific spare parts. In addition, we offer shipping management solutions that will consolidate your spare parts into one shipment to your site.

Extended Warranty

Although our electrical distribution equipment is among the most reliable in the industry, it is important to have an extended warranty plan in place. Schneider Electric Services offers numerous warranty options that provide customers the opportunity to protect their investment for years to come. In addition to our standard 18-month warranty, we offer long-term extended warranty coverage for all electrical distribution equipment — including other manufacturer’s equipment.

Multi-Year Maintenance Agreements

Our multi-year maintenance agreements are designed to help you avoid expensive downtime by minimizing unplanned outages and remedial action. Our preventive maintenance scope of work includes: inspections, cleaning and lubrication, adjustments, overcurrent protective device testing, oil testing, and electrical testing. In addition, having a maintenance agreement in place helps you comply with NFPA 70E standards and mitigate risks by ensuring that regular maintenance is performed on your equipment. Maintenance agreements can be customized based upon your specific requirements, such as: • One maintenance agreement can cover all equipment. • Billing can be structured to prevent fluctuations to your maintenance and repair budget. • Flexible payment options are available for annual and long-term maintenance needs.

Engineering Studies

Schneider Electric offers engineering analyses for your electrical distribution equipment to help optimize performance and reliability and meet applicable requirements for short-circuit protection, overcurrent device coordination, and arc flash hazard identification.

• A protective device time-current coordination analysis is performed to provide power equipment with the required protection and minimize

service interruption under overload or short circuit conditions.

• A short circuit analysis calculates fault-current levels throughout your electrical network to determine if the electrical equipment can withstand worst-case events.

• An arc flash analysis provides the basis for your facility’s electrical safety program by identifying arc flash exposure levels at all points in your electrical system.

Training Services

Schneider Electric instructors are experienced engineers and technicians who are OSHA-trained and certified and have received extensive training on how to effectively adapt engineering codes, standards, and factory-approved documentation into a classroom setting and real-world application. We offer over 70 training courses, available regionally, on-site or online that include: • Safety training for NFPA 70E including Arc Flash Training plus 10- and 30-hour OSHA Certification Courses • Electrical distribution training for medium- and low-voltage distribution equipment, and distribution substation transformers • Automation and control training for variable frequency drives, programmable logic controllers (PLCs), Human Machine Interfaces (HMIs), and industrial communications

Managing an

electrical system

and the energy it

delivers requires:

•

A comprehensive

understanding

of the system’s

normal and

abnormal

operation

•

Knowledge of

a wide variety

of electrical

distribution

equipment

•

The successful

application of

industry codes

and standards

Maintenance and Testing Services

Preventive Maintenance & Testing

An effective electrical preventive maintenance program can reduce your risk of an unscheduled outage by as much as 66% according to statistics from the Institute of Electrical and Electronics Engineers. The most common causes of electrical equipment breakdowns* include: • Mechanical Failure — Loose connections, overheating, load changes and/or additions • Environmental Conditions — Humidity, corrosive environments, dirt, or dust may require preventive maintenance more frequently than the OEM’s recommended schedule

• Work Improperly Performed — OSHA and NFPA® _{require electrical equipment maintenance}

to be performed by qualified personnel

* Source: Hartford Steam Boiler Inspection and Insurance Company To help ensure reliable power, periodic maintenance, cleaning, and lubrication of electrical equipment is required. Our qualified field service representatives provide comprehensive maintenance and testing services with a scope of work that includes: • Equipment inspection • Overcurrent protective device testing • Cleaning and lubrication • Adjustments • Oil testing • Electrical testing, including insulation, current path, system function and others

Predictive Maintenance Solutions

Schneider Electric Services offers predictive maintenance solutions to detect early warning signs and help prevent downtime. Monitoring the condition of equipment provides trending data and alarming to help anticipate and plan maintenance activities. • Infrared Windows Schneider Electric Services provides infrared windows that can be retrofit into any brand of electrical distribution equipment. Having infrared windows installed in existing equipment enables permanent access for inspection of electrical components without disturbing operations. More importantly, it removes the operator from contact with energized parts.

• Wireless Temperature Monitoring System (WTMS) WTMS provides 24/7 temperature monitoring of critical connections within electrical distribution equipment, even areas not seen by infrared cameras. Early detection of heat build-up alerts maintenance personnel of abnormal conditions before they result in forced outages. Sensors, installed inside equipment, transmit temperature readings through a receiver to software to be analyzed. Monitoring temperature in equipment provides trending data to help anticipate and plan maintenance activities, saving time and money.

• Partial Discharge Monitoring

Partial Discharge (PD) is a localized electrical discharge in an insulation system. It is a leading indicator of insulation breakdown and occurs in electrical equipment under high voltage stress. Schneider Electric Services offers Partial Discharge Monitoring Technology to detect and notify facility engineers of impending insulation breakdown. Monitoring sensors can be furnished either in new switchgear or field installed by Schneider Electric Services during a planned outage. Sensors are wired to a monitoring unit, which can be tied into an existing SCADA system via open protocol. Schneider Electric Services will evaluate the monitored results against an existing database and provide a detailed report of findings.

Maintenance Agreements

Schneider Electric offers multi-year programs to help you comply with NFPA 70E standards and mitigate risks by ensuring that regular maintenance is performed on your equipment. Avoid expensive downtime by minimizing unplanned outages and remedial action. Maintenance agreements can cover: • Power equipment • Monitoring systems • Automation and control equipment • Hospital isolation panels • Emergency management • Facility management software

Additional Services

Schneider Electric Services also offers these maintenance and testing services: • Circuit Breaker Testing (Low Voltage) • D.C. High Potential Testing • Grounding System Testing • Relay and Metering Calibration • Rotating Equipment • Variable Frequency Drive and Softstart Repair • UPS and Battery Maintenance

Maintenance

agreements can be

customized based

upon your specific

requirements,

such as:

•

One maintenance

agreement

can cover all

equipment.

•

Billing can be

structured

to prevent

fluctuations to

your maintenance

and repair

budget.

•

Flexible payment

options are

available for

annual and

long-term maintenance

needs.

Having a preventive maintenance program

in place can reduce the risk of unplanned

downtime by as much as 66%.*

Modernization and Upgrade Solutions

Facility managers are often faced with the choice of maintaining an aging

(or obsolete) electrical installation or replacing it with new equipment to take

advantage of current technology.

Even equipment that has been well-maintained may need additional upkeep or upgrades. Factors to consider include the operating environment, availability of spare parts, reliability and the cost of ongoing maintenance. There may also be the need to increase the equipment’s fault or continuous current rating.

Switchgear Modernization Solutions

New design capabilities exist to modernize and extend the life of the active components of switchgear, i.e., circuit breakers, while leaving the existing switchgear structure intact. Schneider Electric Services offers direct replacement and retrofill options to upgrade existing equipment to current technology at a fraction of the cost of new equipment. Our direct replacement and retrofill solutions are available for

any manufacturer’s brand of low- and medium-voltage switchgear. Both options are designed to improve reliability, reduce maintenance and increase equipment capabilities. • Direct Replacement: Circuit breakers are designed to fit into the existing cubicle with little-to-no modification to the switchgear cell. Direct replacement solutions reduce downtime since there is minimal (if any) outage on the equipment bus.

» Low Voltage: A standard Masterpact™ _cradle

is installed into an adapter cradle to form one assembly, which is then installed into the switchgear cubicle. This cradle-in-cradle assembly locks into place and remains in the switchgear cell after the initial installation. The new Masterpact circuit breaker racks in and out of the adapter cradle. A new door is installed, however cell interlocks, the racking mechanism and the switchgear structure are not modified.

» Medium Voltage: Our Magnum™ _{medium-voltage}

replacement circuit breaker is designed to fit directly into the existing OEM switchgear. An adapter cradle is not utilized. • Retrofill Solutions: The existing switchgear cell and bus are modified to accept the new circuit breaker. » This switchgear upgrade option requires a longer bus outage, during which time the internal circuit breaker cell is modified to accept the new circuit breaker. A retrofill solution is often used in lieu of the direct replacement option for larger devices, such as main breakers and tie breakers. As with the direct replacement, retrofill solutions are available for any manufacturer’s existing low- and medium-voltage equipment.

Low Voltage Motor Control

Center Upgrades

Motor control center structures and internal bus work typically have a long life. Their unit racking systems are simple and most likely, in good shape. So why replace the entire motor control center when problems arise? Schneider Electric also offers direct replacement and retrofit options to upgrade low voltage motor control centers. Both options are designed to improve reliability, reduce maintenance and increase equipment capabilities. • New direct replacement motor control center units are available for many common vintage and current style motor control centers. This approach minimizes outage time and reduces costs associated with having to match existing footprints for the removal and reinstallation of cables. Replacement units can be installed over an extended period, which provides an overall equipment upgrade on a limited maintenance budget. • When a direct replacement unit is not available, Schneider Electric Services can retrofit a genuine OEM bucket with all new Square D™ _components. The genuine OEM stab assembly is reconditioned to like-new condition and the bucket is painted white enamel. All work is performed by factory-trained personnel.

Additional Services

Schneider Electric Services also offers these maintenance and testing services: • Circuit breaker reconditioning • Contactor conversions for motor starting applications • Network protectors • Legacy product support and upgrades

For both the direct replacement and retrofill

modernization solutions, new cubicle

doors are provided to match the existing

equipment and new circuit breaker face.

Square D™ _{replacement MCC unit installed in General Electric} 7700 Series structure

Substation Solutions

Custom Solutions

Engineering, Procurement, and

Construction

For all aspects of your substation construction, upgrade, and/or expansion projects, up to 345 kV

Maintenance, Repair, and Upgrade

Solutions to help reduce outages, lower costs, increase energy efficiency, and extend equipment life

Power Transformer Services

Proven service solutions to promote reliability and extend transformer life

Instrument Transformer Services

Testing services to minimize billing inaccuracies between new, high-accuracy meters and existing equipment

Schneider Electric serves utilities and large power users with

high quality products

and services for their outdoor substations up to 345 kV. Ranging from small jobs

to turnkey design and build contracts, our broad range of capabilities includes:

Regardless of the application

or location, our engineering,

manufacturing, field service and

project management teams

can evaluate your situation

and propose a cost-effective

solution that minimizes

downtime or lead-times.

From custom switchgear, to solar projects, to complete turnkey solutions, partner with Schneider Electric for unique product requirements or complex power issues.

Substation Equipment

• VOX Outdoor Dead Tank Circuit Breaker • Powersub™ _{Vacuum Circuit Breaker Type FVR} • Metal-Clad Switchgear • Walk-In Enclosures

Products supported include:

• Bushings • Power Switches • Circuit Breakers: Oil/SF6/Vacuum • Relays: Electromechanical and Electronic — all brands and types • Circuit Switchers • Switchgear: Gas-Insulated • Control Systems • Transformers: PTs/CTs • Isolated-Phase Bus • Transformers: GSU/Power/Auxiliary — to 600 MVA

Let Schneider Electric Services be your

trusted single point of contact for all of

your substation needs.

Emergency Preparedness

Emergency Response

With a nationwide network of 400+ qualified field service representatives, we are ready to respond to your needs. Qualified field service representatives will assess the situation to determine if your equipment can be repaired, reconditioned, or replaced. If the latter, we will work with our plants to get new equipment onsite as quickly as possible. Our services also include project management and turnkey capabilities.

Temporary Generator Connection

Schneider Electric Services delivers turnkey solutions for temporary generator connection to your normal or emergency power system. A temporary generator connection improves your electrical system’s reliability and is recommended where one of the following applies: • Local governing body requiring portable generator connection provisions in addition to the fixed-mounted emergency generators per NEC® article 708.20(F)(6). • The facility is designated as needing continued operation in the event of a widespread disaster and a temporary connection is acceptable to the governing entity. • The facility can withstand short-term disruptions to electrical power but a long-term disruption will jeopardize the business.

Emergency Action Plan 24/7

While natural disasters cannot be prevented, having a detailed emergency recovery plan can limit the financial and personal havoc they can cause. Schneider Electric engineers can help you create an emergency action plan to help restore power and normal operations as quickly as possible. Components include: • Having a current single-line drawing of the electrical distribution system • Identifying which electrical equipment is critical to the electrical infrastructure • Understanding which equipment must be replaced and that which can be reconditioned, if water damage has occurred

When unplanned outages occur, whether by natural disaster or other emergency,

Schneider Electric Services has the expertise and resources to restore electrical

power safely and efficiently for any manufacturer’s brand of equipment.

Life-cycle solutions for your facility’s

electrical system.

Our solutions help:

Maximize electrical reliability

Extend equipment life

Enhance workplace safety

Improve energy efficiency

In case of emergency, call

888-778-2733

. We are available

any time for any

Square D

Services

is now

Schneider

Electric

Services

Find out more about how we can address your specific needs:

888-778-2733

_{Visit www.SEreply.com and enter key code p358v}
