CONTINUING LEADERSHIP IN QUALITY,
SERVICE, AND NEW TECHNOLOGY
SINCE 1933
Specializing in high pressure and severe
applica-tions, Hydril's standard of quality has lead the oil tool
industry since the company was established in 1933.
Hydril's innovative tradition began in the 1930's when
it developed the first hydraulically operated blowout
preventer, the annular blowout preventer, and the
2-step high performance connection. Hydril has
continued to invest in substantial research and
development. Hence, Hydril designs and products
continue to lead the industry into new frontiers of high
pressure, high temperature service. When purchasing
Hydril equipment, customers can be assured they are
enjoying value and reliability for today's most critical
applications.
Advanced engineering means reliable assurance of
product performance. Hydril simulates field conditions
and tests products for specific applications of high
pressure, temperature, and stress, supporting Hydril's
efforts to innovate and improve product performance.
Extensive computerization provides engineers with the
capability to evaluate testing and design equipment
systems. Finite element analysis provides computer
models to predict product performance in the field,
which are double checked by testing. CAD packages
size and customize systems for specific applications.
Reliability analysis ensures that systems will function
when required.
Customers benefit from reliable engineering
assistance. Hydril engineers help customers select
appropriate equipment, material and design after
evaluation of field applications. Hydril's engineering
resources include years of metallurgical experience in
high pressure service. In many cases, Hydril
engineers evaluate products continually after
installation.
Hydril's quality control measures are exacting. Large or small, every part
of a Hydril product is checked repeatedly to make sure it is exactly as designed.
Hydril's quality management system meets worldwide stan-dards. The ISO 9001 Certificate means Hydril has met accepted international standards for marine and offshore products, structural and mechanical metal products, and pressure vessels. Other certi-fications include API 16A for the latest, most exacting specification on drill through equipment; Det Norske Veritas (DNV), American Bureau of Shipping (ABS), and Lloyds of London. Hydril's manu-facturing plants are based worldwide to respond to regional needs.
Product Design. Skilled engineers utilize advanced computer techniques for
Genuine Hydril rubber replacement parts. Hydril
manufactures its own rubber for its blowout preventers
and diverters. Hydril Elastomer and Industrial Products
has set high industry standards of quality for today's
oilfield. The combination of high standards of an
origi-nal equipment manufacturer and years of specialty
rubber experience mean customers receive quality,
durability, and service unmatched by general rubber
suppliers. Purchasing genuine Hydril parts to replace
original rubber means customers receive the reliable
performance and long life they can expect from their
Hydril equipment.
Service and product support are based worldwide.
The company offers field servicemen at convenient
locations to assist in the installation and maintenance
of Hydril equipment. Hydril engineers evaluate
operation of equipment in remote locations. For
restoring mechanical equipment, Hydril sends
engineers to the rig site, or a Hydril Authorized Repair
Facility evaluates the condition of equipment and
offers recommendations for overhaul and repair.
Hydril's global base ensures that customers receive
responsive support. Outside the United States, Hydril
has major facilities for manufacturing in Canada,
Scotland, Singapore and Mexico. In addition, Hydril
has 19 sales offices, 17 authorized independent repair
facilities, and manufacturers' representatives in over
60 countries.
In North America, there are 13 locations for repair,
manufacturing, field service, and sales.
At Hydril Elastomer and Industrial Products, modern laboratories use a
wide range of equipment for testing. Genuine Hydril rubber replacement parts provide the quality and durability customers expect from their Hydril blowout preventers and diverters.
Hydril provides 24-hour-a-day field service after the sale. Hydril field
service and sales personnel are available around the clock. In addition, Hydril engineers consult at customer locations to solve technical problems.
A Certified Test Label is on every Hydril packing unit. The label indicates
the unit was tested at full pressure on pipe and 50 percent of pressure on open hole. Certifications of other tests are sent with the unit. Packaging resistant to both moisture and sunlight and a reinforced crate provide the best protection for shipping and storage. These measures ensure you will have the finest quality packing unit when you are ready to use it.
4
Annular Blowout Preventers
Hydril's complete line of annular blowout preventers is based on more than 55 years of application experience in all BOP types, sizes, and pressure ranges. There is a Hydril Annular BOP to meet most operational requirements in the petroleum industry today, both on the surface and subsea.
Hydril designs are durable for dependable and efficient operation. A standard annular BOP will strip drill pipe and tool joints. The packing unit life is reduced when used for stripping operations. It will also close off the annulus or open hole to full working pressure.
The Hydril Annular BOP provides quick, positive closing action with simplified controls to keep drilling fluids in the hole when a blowout threatens. The universal seal off feature of the annular blowout preventer permits closure and seal off on drill pipe, kelly, tool joints, or tubing and wireline as well as the open hole. Maintenance of the BOP is easy, rapid, and economical with the use of standard tools.
The Low Alloy Steel Pressure Vessel represents Hydril's
50 years of experience in producing BOPs to provide optimum strength and stress distribution control. Full-spectrum testing meeting or exceeding API require-ments ensures that the desired safety factors and reliability are provided in each unit.
Finite Element Analysis of the body design is the
most advanced, in-depth technique of pressure vessel design analysis and ensures a structurally sound body configuration.
Shell (Hydrostatic) Testing of the BOP body meets the
API accepted industry standards to provide a safe, reliable blowout preventer.
API 16A is the latest API specification covering drill
through equipment. Hydril is licensed to manufacture Blowout Preventers to these exacting standards. In addition, Hydril preventers may also be certified by such certifying authorities as Det Norske Veritas (DNV), American Bureau or Shipping (ABS), or Lloyds of London.
Operating Chambers are Pressure Tested to rated
working pressure of the BOP or 3000 psi, whichever is
greater. This ensures strength, reliability, safety, and
the ability to over-pressure the chambers in well-control situations.
Stainless Steel and Inconel-lined Ring Grooves are
available as options.
Hydril GX™
SIZES AND PRESSURE RATINGS OF ANNULAR BLOWOUT PREVENTERS
Bore Size
Working Pressure Ratings (psi)
(inches)
500
2,000
3,000
5,000
10,000
15,000
20,000
7-1/6
–
MSP
GK
GK
GK
GK
GK
9
–
MSP
GK
GK
–
–
–
11
–
MSP
GK
GK
GX
GX
–
13-5/8
–
–
GK
GX/GK
GX
GX
–
16-3/4
–
–
–
GK
–
–
–
18-3/4
–
–
–
–
GX
–
–
21-1/4
–
MSP
–
–
–
–
–
29-1/2
MSP
–
–
–
–
–
–
GX 13 5/8-10,000 psi Annular BOP Hydril MSP 21 1/4 2000 psi Latched Head BOP Hydril GK6
HYDRIL GX
®
ANNULAR BOP
The GX . . . the field proven flagship preventer
of Hydril's fleet
The GX offers extra performance and serviceability while retaining the field proven features of Hydril annular BOPs.
The GX delivers extended operating service with few packing unit changes, with a design that is simple and easy to maintain in both surface and subsea operations.
The GX will close on virtually any drill stem member or seal off the open bore. Operating volumes are lower, resulting in faster closing times and smaller accumulator requirements. Packing Unit fatigue and stripping life have been increased beyond previous industry levels for equiva-lent sized Annular BOPs.
The GX allows full control of packoff tightness during stripping operations, regardless of wellbore pressures.
The structural design, quality and testing of the GX continues Hydril's state-of-the-art advances.
Here are the field proven Hydril features the GX provides:
■ Simple design – only 2 moving parts, thus fewer areas
are subjected to wear meaning less maintenance and downtime.
■ Proven operating principle provides full packing unit
seal off at maximum working pressure on open hole, casing, drill pipe, tool joints, kelly or tubing.
■ Long piston design for optimum stability and reliable
operation.
■ Latched Head for fast and easy access to packing unit
and seals.
■ Opening Chamber Head to prevent inadvertent
contamination of the hydraulic system during packing unit replacement.
■ Four large pressure energized lip seals are used for
dynamically sealing piston chambers.
■ Replaceable Wear Plate eliminates metal to metal
contact between the packing unit inserts and the BOP head,making field repair fast and economical.
■ State-of-the-art structural design, quality and testing
for optimum reliability.
■ Stainless Steel Lined Connection Ring Grooves for
corrosion resistance.
■ Meets NACE MR-01-75 Material Standards for resistance
to sulfide stress cracking.
■ Fabricated from quench and tempered low alloy steel
suitable for service in both low and high temperature applications. GX 18 3/4"-10,000 psi LATCHED HEAD WEAR PLATE PACKING UNIT OPEN CHAMBER HEAD OPEN CHAMBER LIFTING SHACKLES CLOSING CHAMBER
Balanced Piston
Piston stability is assured by Hydril's time proven long
piston design with contact points providing a
length-to-diameter ratio approaching 1. This design eliminates
any tendency to cock and bind during operations with
off-center pipe or unevenly distributed accumulations
of sand or cuttings.
The GX piston is completely balanced. The opening
and closing chamber areas are of equal size. This
equalizes the hydrostatic forces exerted on the piston
by the control fluid column in subsea operations. The
result is a BOP that utilizes a constant closing
pressure regardless of water depth or mud weight.
This piston design is such that the closing pressure
requirements are virtually independent of well bore
pressures.
Contoured angular tapers on the piston bowl
compress and displace the reservoir of feedable
rubber in the back of the packing unit. This design
assures optimum rubber feeding and closing
efficiency. Movement of the piston to the open position
allows the packing unit to relax to full open bore.
Stripping
The design of the GX effectively controls
positioning of the inserts. When
stripping, the inserts remain fixed as the
rubber flows in and out, allowing
the alternating diameters of pipe and
tool joints to pass through the closed
packing unit.
This results in a dramatic increase of the GX
packing unit stripping life – to approximately
twice that of similar sized annular BOPs.
Extra Packing Unit Life
The heart of any annular BOP is its packing unit – and
the GX is no exception. Its packing unit has a greatly
increased reservoir of high-quality feedable rubber.
Because the reservoir of feedable rubber is larger, the
GX permits continuous rubber feeding as the bore
surface wears.
The packing units reinforcing flanged steel inserts
are driven by the rubber during closure and quickly
reach a fixed position where they form a steel ring to
support the rubber from upward motion under wellbore
pressure.
Once the inserts reach their fixed position, rubber
continues to flow inward, effecting a positive seal off
on the drill string or the open bore.
The rubber is primarily in compression and is
there-fore resistant to tears, cuts and abrasions. The steel
inserts stabilize the rubber and control the flow pattern
to minimize rubber stress.
Packing unit life due to routine testing at full working
pressure has been increased beyond previous levels.
Because Hydril Company LP manufactures all its own
packing units, rigid quality control is assured and field
performance enhanced.
More Precise Control
Tool joints can be stripped through the closed packing
unit while a full seal is maintained on the pipe.
The GX packing unit design permits precise control
of packoff tightness, regardless of wellbore pressures.
This allows a slight drilling fluid leakage to be
achieved during stripping operations to provide
lubrication, optimize pull through forces and prolong
packing unit life.
The result is the ability to strip long strings of pipe
and tool joints in or out of the hole at higher wellbore
pressures.
8
HOW TO ORDER GX PACKING UNITS
The following information should be included when ordering a genuine Hydril packing unit replacement.
1. BOP Type: GX 2. Bore Size
3. Pressure Rating: 5000, 10,000, 15,000 psi.
4. Type of Material: (NR)–Natural Rubber; (NBR)–Nitrile Rubber 5. Certification: API 16A, Monogramed, other.
GX ENGINEERING DATA
BORE SIZE (inches) 11" 11" 13-5/8" 13-5/8" 13-5/8" 18-3/4"
WORKING PRESSURE (psi) 10,000 15,000 5,000 10,000 15,000 10,000
SHELL TEST PRESSURE (psi) 15,000 22,500 10,000 15,000 22,500 15,000
(Factory Test Only)
CLOSURE RANGE (inches) 11" to 0 11" to 0 13-5/8" to 0 13-5/8" to 0 13-5/8" to 0 18-3/4" to 0
CLOSING CHAMBER VOLUME (U.S. Gal.) 17.9 24.1 15.5 24.1 34.0 58
OPENING CHAMBER VOLUME (U.S. Gal.) 17.9 24.1 15.5 24.1 34.0 58
FULL PISTON STROKE (inches) 7.00 8.50 7.00 8.50 9.50 11.50
HEIGHT FLANGED BOTTOM 5M – – 52.32 – – –
10M 57.12 – 54.31 63.25 – 80.15 15M 59.44 – – 65.38 77.00 82.50 HUB BOTTOM 5M – – 51 – – – 10M – – – – – 76.38 15M – – – – 71.88 74.75 STUDDED BOTTOM 5M – – – – – – 10M – – – – – – 15M – – – – 64.12 68.44
WEIGHT FLANGED BOTTOM 5M – – – – – –
10M 21,385 – – 28,000 – 52,250 15M 22,085 – – 28,885 – 54,360 HUB BOTTOM 5M – – 14,375 – – – 10M – – – – – 50,620 15M – – – – – 50,500 STUDDED BOTTOM 5M – – – – – – 10M – – – – – – 15M – – – – – 50,840
PARTS LIST GX 11”, 13-5/8" and 18-3/4" BOPs ITEM PART GX 11" &13-5/8" GX 18-3/4"
NO. NAME Qty. Req'd. Qty. Req'd.
1 Head 1 1
*2 Head Gasket – 1
▲3 Packing Unit 1 1
4 Body 1 1
*5 U-Seal Ring, Inner 2 2
*7 Double U-Seal Ring, Middle 1 1 *8 Non-Extrusion Ring, Middle 2 2
9 Piston 1 1
*10 Double U-Seal Ring, Lower 1 1 *11 Non-Extrusion Ring, Lower 2 2
12 U-Seal Ring, Outer 1 –
*15 O-Ring, Head 1 1
16 Slotted Body Sleeve 1 1
17 Capscrew, Slotted Body Sleeve 12 12 *18 O-Ring, Jaw Operating Screw 16 20 19 Jaw Operating Screw 16 20 10 Head, Opening Chamber 1 1
21 Shoulder Screw 16 20
* These parts included in seal kit.
▲Recommended Spares for One Year Foreign Service, quantity 1 each.
Exploded View of GX, 11", 13-5/8" Exploded View of GX 18-3/4"
ITEM PART GX 11" &13-5/8" GX 18-3/4"
NO. NAME Qty. Req'd. Qty. Req'd.
22 Pipe Plug, Jaw Operating Screw 16 20
23 Radial Latch 16 20
24 Relief Fitting 1 1
25 Shackle, Anchor 4 4
26 Wearplate 1 1
27 Capscrew, Wearplate 6 6
28 Pulldown Bolt Assembly 4 4
▲ Complete Seal Kit
ACCESSORIES
Protector Plate 1 1
Protector Plate Screws 4 4
Chain Sling Assembly 1 1
Eyebolts for Piston 3 3
Eyebolts for Head 3 3
10
The GK Annular Blowout Preventer was designed especially for surface installations and is also used on offshore platforms and subsea. The GK is a universal annular blowout preventer with a long record of proven, quality performance.
Only Two Moving Parts (piston and packing unit) on the
Hydril Annular BOP mean few areas are subjected to wear. The BOP is safer and more efficient, requiring less maintenance and less downtime.
A Long Piston with a length to diameter ratio approaching
one eliminates tendencies to cock and bind during operations with off-center pipe or unevenly distributed accumulations of sand, cuttings, or other elements. This design enhances the ability of the packing unit to reopen to full bore position.
The Conical Bowl Design of the Piston provides a simple
and efficient method of closing the packing unit. With the piston serving as a sealing surface against the rubber packing unit, there is no metal-to-metal wear on the sealing surface and thus longer life results.
A Field Replaceable Wear Plate in the BOP Head serves
as an upper non-sealing wear surface for the movement of the packing unit, making field repair fast and economical.
Maximum Packing Unit Life is possible with the provision
for measuring piston stroke. This measurement indicates remaining packing unit life without disassembly and ensures the longest and safest use of the packing unit.
Two Choices of Packing Unit Rubber Compounds
permit more flexible applications.
The Screwed Head Design of the GK BOP is a simple,
efficient, and strong method of connecting the head to the body for safe operation with no loose parts to be lost down the hole or overboard.
The Latched Head Design is available on the GK,
13-5/8"-5000 and larger BOPs. It provides fast access to packing units and seals for minimum downtime with no loose parts to be lost down hole or overboard.
Large Pressure Energized Seals are used for
dynamically sealing piston chambers to provide safe operation, long seal life, and less maintenance.
Piston Sealing Surfaces Protected by Operating Fluid
lowers friction and protects against galling and wear to increase seal life and reduce maintenance time.
The Operating Chambers are Tested to Full BOP Working Pressure to ensure strength, reliability, and the
ability to over-pressurize the chambers in emergencies.
Meets NACE MR-01-75 Material Standards for resistance
to sulfide stress cracking.
HYDRIL GK
®
ANNULAR
BLOWOUT PREVENTERS
Cutaway View of Screwed Head GK BOP With Packing Unit Fully Open
WEAR PLATE PACKING UNIT HEAD OPEN CHAMBER PISTON CLOSING CHAMBER
The GK BOP has been developed especially for use on surface installations but it is also used subsea. Standard operation requires both opening and closing pressure. Seal off is effected by hydraulic pressure applied to the closing chamber which raises the piston, forcing the packing unit into a sealing engagement. Any normal closing unit having a separate pressure regulator valve for the annular BOP and sufficient accumulator volume can be used to operate the GK.
The GK is designed to be well pressure assisted in maintaining packing unit seal off once initial seal off has been effected. As well pressure further increases, closure is maintained by well pressure alone. Exceptions are the GK 7-1/16"-15,000 and 20,000 psi which are not well pressure assisted and closing pressure must be maintained on the BOP to assure seal off. (Refer to the operators manual for closing pressure curves.)
Stripping Operations
During well control operations, drill pipe can be rotated and tool joints stripped through a closed packing unit, while maintaining a full seal on the pipe. Longest packing unit life is obtained by adjusting the closing chamber pressure just low enough to maintain a seal on the drill pipe with a slight amount of drilling fluid leakage as the tool joint passes through the packing unit. This leakage indicates the lowest usable closing pressure for minimum packing unit wear and provides lubrication for the drill pipe motion through the packing unit.The packing unit life is reduced when used for stripping operations.
The pressure regulator valve should be set to maintain the proper closing chamber pressure. If the pressure regulator
valve cannot respond fast enough for effective control, an accumulator (surge absorber) should be installed in the closing chamber control line adjacent to the BOP – precharge the accumulator to 50% of the closing pressure required. In subsea operations it is sometimes advisable to add an accumulator to the opening chamber line to prevent undesirable pressure variations with certain control system circuits.
Recommended test pipe for maximum packing unit life.
❍Reference only replaced by GX
OPERATION OF THE GK
®
BLOWOUT
PREVENTER
AVERAGE CLOSING PRESSURE (PSI) TO ESTABLISH INITIAL SEAL OFF IN GK BLOWOUT PREVENTERS FOR SURFACE INSTALLATIONS
Pipe ❍ ❍ O.D. 7-1/16- 7-1/16- 7-1/16- 7-1/16- 7-1/16- 13-5/8- 13-5/8- 13-5/8- 16-3/4 Inches 3M 5M 10M 15M 20M 9-3M 9-5M 9-10M 11-3M 11-5M 11-10M 3M 5M 10M 16-2M 16-3M 5M 18-2M* 6-5/8 – – – – – – – – – 350 – 700 600 – 350 450 – 500 5 – 400 – – – – – 350 450 450 500 800 650 700 400 500 – 550 4-1/2 350 400 350 2100 2200 400 450 380 450 450 500 900 650 700 500 500 600 600 3-1/2 400 450 550 2100 2200 500 600 570 550 525 700 1000 700 1200 600 600 650 650 2-7/8 400 450 750 2100 2200 550 650 760 650 800 800 1100 750 1400 700 700 750 700 2-3/8 500 500 850 2100 2200 650 750 860 750 900 1100 – 950 1400 800 800 850 740 1 90 600 600 900 – – 750 850 850 920 – – – 1000 1500 900 950 950 850 1 66 700 700 1000 – – 850 950 1000 950 – – – 1000 1500 1000 1000 1050 950 CSO 1000 1000 1150 – – 1050 1150 1150 1150 1150 1500 1200 1150 2200 1150 1150 1150 1150
The pressures above are a guideline. Maximum packing unit life will be realized by the use of the lowest closing pressure that will maintain a seal. For subsea applications, see the appropriate Operator's Manual for computation of best closing pressure.
BORE SIZE (inches) 11❍ 11❍ 13-5/8 13-5/8 13-5/8 13-5/8 HL 13-5/8 13-5/8❍ 13-5/8❍ 16-3/4▲ 16-3/4▲ 16-3/4 16-3/4 WORKING PRESSURE (psi) 10,000 *10/15,000 3000 3000 5000 5000 5000 10,000 10,000 2000 3000 5000 5000 HEAD TYPE LATCHED LATCHED SCREWED LATCHED SCREWED LATCHED SCREWED SCREWED LATCHED SCREWED SCREWEDSCREWEDLATCHED
OLD NOMINAL SIZE – – 12 12 – – – – – 16 16 – –
SHELL TEST PRESSURE Factory Only 15,000 22,600 6000 6000 10,000 10,000 7500 15,000 15,000 3000 45000 10,000 10,000 OPERATING CHAMBER TEST PRESSURE Factory Only 10,000 10,000 3000 3000 5000 5000 3000 10,000 10,000 3000 3000 5000 5000 • OPERATING
CHAMBER CLOSING 25.10 26.67 11.36 11.36 17.98 17.98 17.98 ††37.18 ††37.18 17.46 21.02 28.70 28.70
VOLUME (Gal.) OPENING 18.97 20.45 8.94 8.94 14.16 14.16 ††26.50 ††26.50 12.59 15.80 15.80 19.93 19.93 (For Full Piston Stroke)
FULL PISTON STROKE (inches) 8 8-1/2 7-1/8 7-1/8 8-1/2 8-1/2 8-1/2 ††10-1/2 ††10-1/2 8-1/2 9 10-1/2 10-1/2 BODY DIAMETER (inches) 58 64-3/4 40-1/2 45-1/4 45-1/2 47-3/4 44 61 63-1/2 46-1/4 48-1/2 53-1/2 54-1/2 CLEARANCE DIAMETER (inches) 60-3/4 69-3/4 47-1/2 47-1/2 52-1/4 52-1/4 48-1/2 68-1/8 68-1/8 53-1/4 55-1/2 59-1/2 59-1/2 FLANGED BOTTOM 10M:63-3/8 72-15/16 45-1/4 45-1/4 5M:54-1/8 5M:54-1/2 – 71-3/8 71-5/16 49-1/2 53-7/8 61-1/4 61-19/64
15M• 10M:56-3/16 10M:59-9/16
**HEIGHT (inches) STUDDED BOTTOM 10M:54-7/8 60-7/8 39-3/8 39-3/8 5M:46-1/2 5M• – 60-5/8 61-1/8 43-3/4 47-1/4 53 53-27/64
15M 10M:46-1/2 10M•
CIW HUB BOTTOM 10M:61 67-7/8 43 43 5M:51-1/2 5M:51-7/8 46 66-7/8 66-13/16 46-1/2 – 59-7/8 59-59/64
15M:60-1/4 10M:51-1/2 10M:51-7/8
FLANGED BOTTOM • • 8784 • 5M:13,800 5M:13,250 – 33,525 • 11,417 14,868 20,835 21,230 10M:14,500 10M:13,900
**WEIGHT (lbs.) STUDDED BOTTOM • 35,350 8522 • 5M:13,100 • – 32850 • 11,100 14,470 20,000 20,400
10M:
approximate CIW HUB BOTTOM • • 8650 • • • 9400 32,785 33,377 11,317 – 20,545 20.950
FLANGED 10M:BX158 BX158 RX57 RX57 5M:BX160 5M:BX160 – BX159 BX159 RX65 RX66 BX162 BX162
15M:BX158 10M:X159 10M:BX159
STANDARD RING GROOVE STUDDED 10M:BX158 BX158 RX57 RX57 5M:BX160 5M:BX160 – BX159 BX159 RX65 RX66 BX162 – 10M:BX159 10M:BX159
CIW HUB 10M:BX158 BX158 RX57 RX57 5M::BX160 5M:BX160 BX160 BX159 BX159 RX65 – BX162 BX162
15M:BX158 10M:BX159 10M:BX159
*15,000 psi Shell w/10,000 psi Packing Unit ▼1" NPT hydraulic connections are standard, 1-1/4" or -1 1/2" available on request.
▲Information Only †Older models may have 8-5/16" bore
• Available on Request ††Older models have 9-3/4" piston stroke with 34.53 gallon closing chamber volume and 24.66 opening chamber volume **With standard studded top connection rated to BOP working Pressure ❍Reference only replaced by GX
12
WEIGHT (Lbs.) OF GK 2000, 3000 and 5000 PSI GK ENGINEERING AND DIMENSIONAL DATA
BORE SIZE (inches) 7-1/16 7-1/16 7-1/16 7-1/16 7-1/16 †9 †9 9 11 11 11 11
WORKING PRESSURE (psi) 3,000 5,000 10,000 15,000 20,000 3,000 5,000 10,000 3,000 5,000 5,000 10,000 HEAD TYPE SCREWED SCREWED SCREWED SCREWED SCREWED SCREWED SCREWED SCREWED SCREWED SCREWED LATCHED SCREWED
OLD NOMINAL SIZE 6" 6" – – – 8" 8" – 10 10 10 –
SHELL TEST PRESSURE Factory Only 6000 10,000 15,000 22,500 30,000 6000 10,000 15,000 6000 10,000 10,000 15,000 OPERATING CHAMBER TEST PRESSURE Factory Only 3000 5000 10,000 15,000 20,000 3000 5000 10,000 3000 5000 5000 10,000 • OPERATING
CHAMBER CLOSING 2.85 3.86 9.42 11.2 10.9 4.33 6.84 15.90 7.43 9.81 9.81 25.10
VOLUME (Gal.) OPENING 2.24 3.30 7.08 7.50 7.20 3.41 5.80 11.95 5.54 7.98 7.98 18.97
(For Full Piston Stroke)
FULL PISTON STROKE (inches) 4-1/8 4-1/2 5-1/2 5-1/2 5-1/2 5-3/4 5-3/4 6-3/4 6-1/8 7-1/8 7-1/8 8
BODY DIAMETER (inches) 26 29-1/4 43-3/4 50 55 28 34 50-1/2 33-3/4 37-1/2 42-1/4 56-1/2
CLEARANCE DIAMETER (inches) 32-1/4 35-3/4 49-1/2 61 58 34-1/2 41 56-3/4 40 44-1/4 44-1/4 61-1/2
FLANGED BOTTOM 32 36-7/8 10M:48-1/8 54-1/8 59 37-7/8 41-3/4 55-3/4 39-3/4 5M:47-13/16 5M:48-1/4 10M:63-1/2
15M:48-3/4 10M:48-9/16 10M:49 15M:65-13/16
**HEIGHT (inches) STUDDED BOTTOM 27-3/4 30-3/4 • 45-7/8 48-5/8 32-3/4 34-3/4 48-1/2 34-3/8 5M:39-5/8 5M:40-1/16 10M:55 10M:40-1/4 10M:40-11/16 CIW HUB BOTTOM 31-1/8 34-7/8 10M:47-1/8 • – 5M:36-7/8 • – 38-1/8 5M:44-7/8 45-5/16 10M:61-1/8
15M• 10M• – 15M:61
FLANGED BOTTOM 2715 4000 12200 14250 23000 3500 6000 18540 5500 5M:8200 • 10M:26140
10M• 15M•
**WEIGHT (lbs.) STUDDED BOTTOM 2585 3785 • • 22000 3300 5700 18340 5140 5M:7750 • 25460
10M•
approximate CIW HUB BOTTOM 2505 3850 11900 • – 5M:3450 • – 5350 5M:7920 • 10M:26000
10M• 15M:26100
FLANGED RX45 RX46 10M:BX156 BX156 BX156 RX49 RX50 BX157 RX53 5M:RX54 5M:RX54 10M:BX158
15M:BX156 10M:BX158 10M:BX158 15M:BX158
STANDARD RING GROOVE STUDDED RX45 RX46 – BX156 BX156 RX49 RX50 BX157 RX53 5M:RX54 5M:RX54 10M:BX158 10M:BX158 10M:BX158
CIW HUB RX45 BX156 BX156 – – RX49 • – RX53 5M:RX53 5M:RX53 10M:BX158
15M:BX158
*Compact Model ▼Available on Request
TYPE GK BLOWOUT PREVENTERS
GK* GK* GK GK GK GK GK GK GK GK GK GK GK GK GK GK 7-1/16 7-1/16 9 9 11 11 11 13-5/8 13-5/8 13-5/8 13-5/8 13-5/8 16-3/4 16-3/4 16-3/4 16-3/4
3000 5000 3000 5000 3000 5000 5000 3000 3000 5000 5000 5000 2000 3000 5000 5000 Screwed Screwed Screwed Screwed Screwed Screwed Latched Screwed Latched Screwed Latched HL* Screwed Screwed Screwed Latched
Head Head Head Head Head Head Head▼ Head Head▼ Head Head Head Head Head Head
BOP Assembly FLANGED 2715 4000 3560 6000 5300 8250 8784 9550 13800 13250 9400 11417 14868 20830 –
STUDDED 2580 3830 3420 5740 5140 7800 8522 – 13100 – – 11100 14470 2000 –
BOP Head 546 1080 803 1308 1220 1835 2305 2160 3455 2585 2990 4064 5210 6641 3698
PACKING UNIT Natural Rubber 109 135 125 198 206 305 305 355 355 470 470 470 530 560 675 675
Nitrile Rubber 111 138 131 205 213 311 311 361 361 480 480 480 540 572 685 685
Piston 610 793 610 1054 1042 1380 1380 1680 1680 2455 2455 2060 2460 2878 3300 3300
BOP Body FLANGED 1240 2060 1855 3620 2600 4645 4135 4840 7120 7120 3983 5250 7146 9710 –
STUDDED 1000 1925 1710 2990 2400 4112 3910 – – – – 4860 6980 – –
ACCESSORIES FOR HYDRIL GK BLOWOUT PREVENTERS
Chain Sling Assembly 1 Eyebolts – Piston 2 Eyebolts – Head 2 Protector Plate 1 Protector Plate Screw 4
PARTS LIST – HYDRIL GK BLOWOUT PREVENTERS
GK- GK- GK- GK- GK- GK- GK- GK- GK- GK- GK- GK- GK- GK- GK- GK-7-1/16 7-1/16 9 9 11 11 11 13-5/8 13-5/8 13-5/8 13-5/8 13-5/8 16-3/4 16-3/4 16-3/4 16-3/4
3000 5000 3000 5000 3000 5000 5000 3000 3000 5000 5000 5000 2000 3000 5000 5000 Item Screwed Screwed Screwed Screwed Screwed Screwed Latched Screwed Latched Screwed Latched Screwed Screwed Screwed Screwed Latched
No. Part Name Head Head Head Head Head Head Head Head Head Head Head Head Head Head Head Head
1 Head 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
t2 Packing Unit Natural, Nitrile or
Neoprene Rubber 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
3 Piston 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
**4 Slotted Body Sleeve 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
5 Body 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 *6 Head Gasket 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 *7 Head Seal – – – – – – 1 – 1 – 1 – – – – 1 *8 U-Seal, Upper 2 2 2 2 2 2 2 2 2 2 2 – 2 2 – – *9 U-Seal, Middle 2 2 2 2 2 2 2 2 2 2 2 – 2 2 – – *10 U-Seal, Lower 2 2 2 2 2 2 2 2 2 2 2 – 2 2 – –
*11 Double U-Seal, Upper – – – – – – – – – – – 1 – – 1 1
*12 Non extrusion Ring, Upper – – – – – – – – – – – 2 – – 2 2
*13 Double U-Seal, Middle – – – – – – – – – – – 1 – – 1 1
*14 Non extrusion Ring, Middle – – – – – – – – – – – 2 – – 2 2
*15 Double U-Seal, Lower – – – – – – – – – – – 1 – – 1 1
*16 Non extrusion Ring, Lower – – – – – – – – – – – 2 – – 2 2
17 Pipe Plug, Piston Indicator 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
18 Capscrew, Slotted Body Sleeve 10 12 10 10 12 12 12 12 12 6 6 6 – 12 7 7
19 Head Lock Screw 1 1 1 1 1 1 – 1 – 1 – 1 1 1 1 –
20 Lock Collar – – – – – – – – – – – 1 – – 1 –
21 Jaw – – – – – – 16 – 16 – 20 – – – – 20
22 Jaw Operating Screw – – – – – – 16 – 16 – 20 – – – – 20
23 Capscrew, Jaw Holding – – – – – – – – – – 20 – – – – 20
*24 Seal, Jaw Holding Capscrew – – – – – – – – – – 20 – – – – 20
*25 Non extrusion Ring, Jaw – – – – – – – – – – 20 – – – – 20
Holding Capscrew
*26 O-Ring, Jaw Operating Screw – – – – – – 16 – 16 – 20 – – – – 20
27 Relief Fitting – – – – – – 1 – 1 – 1 – – – – 1
29 Wear Plate 1 1 1 1 1 1 1 1 1 1 1 – – 1 1 1
30 Cap Screw, Wear Plate 6 6 6 6 6 6 6 6 6 6 6 – – 6 6 6
31 Spacer Sleeve – – – – – – 16 – 16 – – – – – – –
32 Sleeve Screw – – – – – – 16 – 16 – – – – – – –
33 Pipe Plug – – – – – – 16 – 16 – – – – – – –
34 Head Clamp – – – – – – 4 – 4 – – – – – – 2
35 Head Clamp Cap Screw – – – – – – 4 – 4 – – – – – – 2
▼ Complete Seal Kit – – – – – – – – – – – – – – – –
* These parts included in Seal Kit. ** Older model BOPs equipped with welded type sleeve.
▼Recommended spares for One Year Foreign Service, quantity 1 each.
GK-13-5/8 5000 HL Screwed Head
Hydril's new Compact GK Annular BOPs are lighter and
shorter than previous models. They are designed for use on surface installations, both drilling and workover applications. The new compact models incorporate the following features that have given the GK a long record of proven and quality performance.
Only Two Moving Parts (piston and packing unit) mean
few areas are subject to wear. The GK is safer and more efficient, requiring less maintenance and less downtime.
The Long Piston has a length to diameter ratio
approach-ing one. This eliminates tendencies to cock and bind durapproach-ing operations with off-center pipe or accumulations of sand, cuttings, or other elements that are unevenly distributed.
Conical Bowl Design of the Piston provides a simple and
efficient method of closing the packing unit. With the piston serving as a sealing surface against the rubber packing unit, no metal-to-metal wear occurs on the sealing surface, result-ing in longer life.
Field Replaceable Wear Plate in the BOP Head serves as
an upper non-sealing wear surface for the movement of the packing unit, making field repair fast and economical.
Maximum Packing Unit Life is possible with the provision
for measuring piston stroke. This measurement indicates remaining packing unit life without disassembly and ensures the longest and safest use of the packing unit.
Two Choices of Packing Unit Rubber Compounds
per-mit more flexible applications.
Screwed Head Design is a simple, efficient, and strong
method of connecting the head to the body for safe opera-tion, preventing loose parts from falling down the hole or overboard.
Large Pressure Energized Lip Seals dynamically seal the
piston chambers, allow safe operation, provide long seal life, and require less maintenance.
Piston Sealing Surfaces Protected by Operating Fluid
lowers friction and protects against galling and wear to increase seal life and to reduce maintenance time.
Operating Chambers are Tested to Full BOP Working Pressure to ensure strength, reliability, and the ability to
overpressure the chambers in emergencies.
Stainless Steel Connection Ring Grooves are optional. NACE MR-01-75 Material Standards for resistance to
sul-fide stress cracking are standard.
Item
Part Number
Number
Qty. Description
7 1/16" - 3,000
7 1/16" - 5,000
13 5/8" - 3,000
13 5/8" - 5,000
-
1
Assembly
3117010-0103
3117020-0103
3128982
3129009
1
1
Body
3117011-01
3117021-01
3128984
3129004
2
1
Head
3117013-03
3117023-03
3128988
3129023
3
1
Piston
3117025
3117025
3128992
3129027
4
1
Sleeve
3117027
3117027
3129033
3129029
5
6
Sleeve Retainer
3117028
3117028
-
-6
6
Cap Screw
1900125-10012
1900158-10012
1920026-12012
1920026-12012
7
1
Wear Plate
1002036
1002036
1001788
1001788
8
6
Cap Screw
1920026-08007
1920026-08007
1900097-08006
1900097-08006
9
1
Lock Screw
190049-12012
190049-12012
1002191-1
1002149
10
1
Lock Washer
1003700
1003700
-
-11
1
Packing Unit
1003252-02
1003252-02
1003262-02
1003263-02
12
4
Hoist Ring
1920752-3
1920752-3
1920752-5
1920752-7
13*
12
Studs
1900096-09050
1900096-11066
1900491-11054
1900491-13066
14*
12
Nuts
1900035-09
1900035-11
1900490-11
1900490-13
15*
1
Seal Kit
1002016
1002016
3130390
3130391
*Not pictured
5 6 8 9 2 3 1 4 7 10 11 1214
HYDRIL GK
®
COMPACT ANNULAR
Comparison Chart between Standard GK and Compact GK
Standard Compact Standard Compact Standard Compact Standard Compact GK 7 1/16-3000 GK 7 1/16-3000 GK 7 1/16-5000 GK 7 1/16-5000 GK 13 5/8-3000 GK 13 5/8-3000 GK 13 5/8-5000 GK 13 5/8-5000 Overall Height
32"
31.9"
36.88
33.66"
45.25"
41.4
54 1/8
49.83
Body Diameter
26"
25.25"
29.25"
26"
40.5"
41"
45.25"
43.88"
Weight - lbs
2715
2600
4000
3000
8784
7300
13800
11200
Close Volume - gal
2.85
2.86
3.86
2.86
11.36
11.36
17.98
17.98
Open Volume - gal
2.24
2.25
3.3
2.25
8.94
8.94
14.16
14.16
15
PARTS LIST / SPECIFICATIONS
7 1/16" - 3,000 7 1/16" - 5,000 13 5/8" - 3,000 13 5/8" - 5,000 Bore 7 1/16 in 179.4 mm 7 1/16 in 179.4 mm 13 5/8 in 346 mm 13 5/8 in 346 mm Working Pressure 3000 psi 207 bar 5000 psi 345 bar 3000 psi 207 bar 5000 psi 345 bar Operator Pressure 3000 psi 207 bar 3000 psi 207 bar 3000 psi 207 bar 3000 psi 207 bar Volume to Close 2.86 gal 10.8 liter 2.86 gal 10.8 liter 11.36 gal 43 liter 17.98 gal 68.1 liter Volume to Open 2.25 gal 8.52 liter 2.25 gal 8.52 liter 8.94 gal 33.8 liter 14.16 gal 53.6 liter BOP Assembly 2,600 lb 1,180 kg 3,000 lb 1,361 kg 7,300 lb 3,313 kg 11,200 lb 5,083 kg Weight Head 450 lb 209 kg 550 lb 250 kg 2,200 lb 998 kg 2,200 lb 998 kg
Piston 595 lb 270 kg 595 lb 270 kg 1,320 lb 599 kg 3,000 lb 1,362 kg Hydraulic Shell Test Pressure (Factory Test Only) 6,000 psi 414 bar 10,000 psi 690 bar 6,000 psi 414 bar 10,000 psi 690 bar Hydrostatic Chamber Test Pressure (Factory Test Only) 5,000 psi 345 bar 5,000 psi 345 bar 4,500 psi 310 bar 5,000 psi 345 bar Top & Bottom Connection Ring Groove X-45 - X-46 - R-57 - BX-160 -Hydraulic Connection, Open & Close 1-in NPT - 1-in NPT - 1-in NPT - 1-in NPT -Lift Eye Safe Working Load Per Shackle 5,000 lb 2.27 tonne 5,000 lb 2.27 tonne 8,000 lb 3.63 tonne 15,000 lb 6.81 tonne Packing Unit Closure Range (CSO to in/mm) 7 1/16 in 179.4 mm 7 1/16 in 179.4 mm 13 5/8 in 346 mm 13 5/8 in 346 mm
A - Height 31.19 in 792 mm 33.66 in 855 mm 41.40 in 1,052 mm 49.83 in 1,266 mm B - Width 25.25 in 641 mm 26.00 in 660 mm 41.00 in 1,041 mm 43.88 in 1,115 mm C - Bottom to Center Raduis Hoist Ring 21.25 in 540 mm 23.26 in 591 mm 29.33 in 745 mm 33.19 in 843 mm D - Top to Center Hoist Ring 9.94 in 252 mm 10.40 in 264 mm 12.07 in 307 mm 16.64 in 423 mm E - Bottom to Center Close Port 14.13 in 359 mm 16.13 in 410 mm 18.75 in 476 mm 22.70 in 577 mm F - Center Close port to Center Open Port 8.44 in 214 mm 8.44 in 214 mm 10.13 in 257 mm 12.00 in 305 mm G - Piston Stroke 4.125 in 105 mm 4.125 in 105 mm 7.12 in 181 mm 8.50 in 216 mm H - Center Radius to Center Radius Hoist Rings 35.44 in 900 mm 36.19 in 919 mm 35.44 in 900 mm 36.19 in 919 mm
Operating Data Dimensions
H
B
D
C
A
G
F
E
16
HYDRIL MSP
™
DIVERTERS/BLOWOUT PREVENTERS
Hydril MSP-2000 psi
The MSP Annular Blowout Preventer is applicable to subsea or surface installations requiring a 2000 psi universal blowout preventer. As proven by its many field installations, it will deliver long, dependable service life. This BOP will seal off drill pipe, kelly, tool joints or tubing and wireline or completely shut off the open hole to full rated pressure.
The following outstanding features of the MSP BOP make it qualified to meet the industry's need for simple and reliable blowout protection. A helicopter lift model of the MSP 21-1/4–2000 is also available.
The Screwed Head Design of the MSP BOP is a simple,
efficient, and strong method of connecting the head to the body for safe operation with no loose parts to be lost down the hole or overboard.
The Latched Head Design which is optional on the MSP
21-1/4–2000 BOP provides fast, positive access to the packing unit and seals for minimum maintenance time.
Only Two Moving Parts (piston and packing unit) on the
Hydril Annular BOP mean few areas are subjected to wear. The BOP is thus a safer and more efficient mechanism requiring less maintenance and less downtime.
Back to Front Feedable Rubber on the Packing Unit
enables the packing unit to close and seal on almost any shape in the drillstring or close off the open bore and to strip tool joints under pressure. This safety feature permits confi-dent closure of the BOP at the initial indication of a kick with-out the delay of locating the tool joint.
The Conical Bowl Design of the Piston provides a simple
and efficient method of closing the packing unit. With the piston serving as a sealing surface against the rubber packing unit, there is no metal-to-metal wear on the sealing surface and thus longer equipment life results.
A Field Replaceable Wear Plate in the BOP Head serves
as an upper non-sealing wear surface for the movement of the packing unit, making field repair fast and economical.
Hydril MSP 29-1/2-500 psi
The MSP 29-1/2"-500 psi, developed for use on surface installations, is a large bore annular type diverter whose 29-1/2" bore permits hole to be drilled full bore with diverter protection. Its large bore permits the setting of large size surface casing without removing the diverter. Thus it is always ready for venting gas flows. Utilizing computerized finite element techniques, the original design of the MSP 29-1/2"-500 has been revamped to provide a unit made up of fewer parts to reduce cost. This unit may be ordered for use in standard service (temperate climates) or for use in cold environments such as the North Sea, Siberia, and Alaska where low temperature metallurgy may be required.
This MSP provides an effective means of rerouting the flow of shallow, low-pressure gas. The MSP 29-1/2"-500 can be used either as a diverter or a 500 psi annular BOP.
Only Two Moving Parts (piston and packing unit) on the
Hydril Annular Diverter mean few surfaces are subjected to wear. The Diverter is thus a safer and simpler mechanism requiring less maintenance and less downtime.
Back to Front Feedable Rubber on the Packing Unit
enables the packing unit to close and seal on almost any shape in the drillstring or close off the open bore and strip tool joints under pressure. This safety feature permits confident closure of the MSP-29-1/2"-500 at the initial indica-tion of kick without the delay of locating the tool joint.
The Conical Bowl Design of the Piston provides a simple
and efficient method of closing the packing unit. With the piston serving as a sealing surface against the rubber packing unit, there is no metal-to-metal wear on the sealing surface and thus longer equipment life results.
The MSP Diverter/BOP has been developed as a simple, reliable unit for moderate pressure drilling service, remedial work, and well servicing. It can be used on surface and subsea installations. MSP 21-1/4"-2000 operation requires both opening and closing pressure. The MSP 29-1/2"-500 requires only closing pressure. Seal off is effected by hydraulic pressure applied to the closing chamber that raises the piston, moving the packing unit radially inward into a sealing engagement. Any normal closing unit having a separate regulator valve for the annular BOP and sufficient accumulator volume can be used to operate the MSP.
STRIPPING
Cylindrical pipe sections can be rotated and standard size tool joints can be safely stripped though the closed blowout preventer packing unit. The pressure applied to the closing chamber should be low enough to allow a slight leakage of drilling fluid as the tool joint passes through the closed packing unit. The drilling fluid lubricates and cools the packing unit, reducing wear caused by rotation or stripping of pipe. Overall packing unit life is reduced when used in stripping operations.
The operation/maintenance manual for the specific MSP model provides specifications and functional guidelines.
Operation as a Diverter
When using the MSP as a Diverter during top hole drilling, the primary purpose is to divert well flows away from the rig and personnel. This application avoids shutting in the well, but instead permits routing of the flow to a safe distance on the down wind side of the rig.
In this application, the MSP is attached directly to the drive or conductor pipe. Vent lines typically are installed directly below the diverter. The lines should be sized in accordance with API standards to prevent excessive well bore back pressure buildup. This may be accomplished by using a Hydril drilling spool between the diverter and the conductor pipe.
The Hydril SXV Spool, described on page 38 of this catalog provides integral venting without external valves.
If valves are to be used in the diverter system, standards set forth in API RP64 (Recommended Practice for Diverter Systems Equipment and Operation) should be followed.
Operation as a BOP
When using the MSP as an Annular Blowout Preventer, it may be hooked up as shown (above, right). In this mode, well control operations can be conducted within the MSP's working pressure range
In either mode, pressure applied to the closing chamber raises the piston closing the packing unit to effect the seal between the packing unit and pipe. Well pressure or test pressure also acts on the MSP 21-1/4"-2000 piston below the sealed off packing unit and further increases the closing force acting on the packing unit. The MSP 29-1/2"-500 is
not wellbore assisted.
OPERATION OF THE MSP
™
DIVERTER/BOP
FLOW LINE BELL NIPPLE MSP CLOSE OPEN VENT LINE DRILLING SPOOL DRIVE OR CONDUCTOR PIPE FULL OPENING VALVE
(AUTOMATICALLY OPENS
BEFORE DIVERTER IS CLOSED) DRIVEOR
CONDUCTOR PIPE MSP FLOW LINE BELL NIPPLE HYDRAULIC POWER FLUID SUPPLY HYDRAULIC POWER FLUID SUPPLY
18
PARTS AND ACCESSORIES FOR HYDRIL TYPE MSP-2000 BOPs
▼Older model BOPs have welded sleeve field replacement kit available on request. Field welding is not recommended. * Three parts in Seal Kit
❍Recommended Spares for One Year Foreign Service, quantity 1 each.
7-1/16- 9- 11- 21-1/4- 21-1/4- 7-1/16- 9- 11- 21-1/4-
21-1/4-2000 2000 2000 2000 2000 2000 2000 2000 2000 2000
Item Screwed Screwed Screwed Screwed Latched Item Screwed Screwed Screwed Screwed Latched
No. Part Name Head Head Head Head Head No. Part Name Head Head Head Head Head
Standard Assembly 1 1 1 1 1 1 *21 Non extrusion Washer – – – – 20 – 1 Preventer Head 1 1 1 1 1 1 *22 O-Ring, Jaw Operating Screw – – – – 20 – 2 Pipe Plug Piston Indicator 1 1 1 1 1 1 23 Relief Fitting – – – – 20 –
3 Lock Collar 1 1 1 1 – 1 *24 Head O-Ring – – – – 1 –
4 Head Lock Screw 1 1 1 1 – 1 *25 Double U-Seal, Lower – – – – – 1
*5 Head Gasket 1 1 1 1 1 1 *26 Non extrusion, Lower – – – – – 2
❍6 Packing Unit *27 Double U-Seal, Inner – – – – – 1
Natural Rubber or 1 1 1 1 1 1 *28 Non extrusion Ring, Lower – – – – – 2
or Nitrile Rubber 29 Body Sleeve, Inner ▼1 ▼1 ▼1 ▼1 ▼1 1
*7 U-Seal, Upper 2 2 2 2 2 – 30 Sleeve Clamping Plate – – – – – 1
8 Piston 1 1 1 1 1 1 *31 Double U-Seal Ring, Upper – – – – – 1
*9 U-Seal, Lower 2 2 2 2 2 – *32 Non extrusion Ring, Upper – – – – – 2
*10 U-Seal, Inner 2 2 2 2 2 – 33 Wear Plate 1 1 1 1 1 –
11 Body 1 1 1 1 1 1 34 Capscrew, Wear Plate 6 6 6 6 6 –
12 Body Sleeve Outer 1 1 1 1 1 1 35 Capscrew Inner Body Sleeve – – – 16 16 – 13 Cap Screw Outer Body Sleeve 8 8 8 16 16 16 M– Complete Seal Kit – – – – – – *14 O-Ring, Body Sleeve 1 1 1 1 1 1 ACCESSORIES
15 Head Clamp – – – – 4 – Chain Sling Assembly 1 1 1 1 1 1
16 Head Clamp Screws – – – – 4 – Eyebolts for Piston 2 2 2 2 2 2
17 Jaws – – – – 20 – Eyebolts for Head 2 2 2 2 2 2
18 Jaw Operating Screw – – – – 20 – Cap Screw (Hex Head) 4 4 4 4 4 – 19 Cap Screw, Jaw Holding – – – – 20 – Protector Plate 1 1 1 1 1 – *20 Seal, Jaw Holding Capscrew – – – – 20 – Piston Assembly Tool – – – – – 4
21-1/4-2000 HL Screwed Head 21-1/4-2000 HL Screwed Head
HYDRIL MSP
™
BLOWOUT
PREVENTERS
INITIAL CLOSING PRESSURE (PSI)
REQUIRED FOR MSP 29-1/2”-500 BOP/DIVERTER
Closing Pressure 500 psi Wellbore
12” Pipe 5” Pipe CSO
950 psi 1350 psi 1500 psi
AVERAGE CLOSING PRESSURE (PSI)
REQUIRED TO ESTABLISH INITIAL SEAL OFF IN MSP-2000 FOR A SURFACE INSTALLATION
OUTSIDE DIAMETER OF PIPE
BOP Size 5-1/2” 4-1/2” 3-1/2” 2-7/8” 2-3/8” 1.90” 1.65” Complete Shut Off
7-1/16”-2000 – 350 400 *400 500 600 700 1,000
9”-2000 – 400 *500 550 650 750 850 1,050
11”-2000 350 450 *550 650 750 850 850 1,150
21-1/4”-2000 500 *700 600 650 700 800 900 1,100
*Recommended test pipe size for maximum packing unit life. **WEIGHT (lbs.)
approximate
MSP ENGINEERING DIMENSIONAL DATA
HL
BORE SIZE (inches) 7-1/16 †9 11 *20-3/4 *20-3/4 21-1/4 21-1/4 21-1/4 29-1/2
WORKING PRESSURE (psi) 2000 2000 2000 2000 2000 2000 2000 2000 500
HEAD TYPE SCREWED SCREWED SCREWED SCREWED LATCHED SCREWED LATCHED SCREWED LOCKRING
OLD NOMINAL SIZE 6” 8” 10” 20” 20” 20” 20” 20” 29-1/2”
SHELL TEST PRESSURE Factory Only 4000 4000 4000 3000 3000 3000 3000 3000 800
OPERATING CHAMBER TEST PRESSURE Factory Only 3000 3000 3000 3000 3000 3000 3000 3000 2275
• OPERATING
CHAMBER CLOSING 2.85 4.57 7.43 31.05 31.05 31.05 31.05 31.75 60
VOLUME (Gal.) OPENING 1.98 2.95 5.23 18.93 18.93 18.93 18.93 19.25 –
(For Full Piston Stroke)
FULL PISTON STROKE (inches) 4-1/8 5-3/4 6-1/8 11-1/4 11-1/4 11-1/4 11-1/4 11-1/2 13-9/16
BODY DIAMETER (inches) 25-3/8 27-1/2 32-3/4 52-3/4 56-5/8 52-3/4 56-5/8 52-1/2 75
CLEARANCE DIAMETER (inches) 29-/78 32 37-1/4 58-3/4 58-3/4 58-3/4 58-3/4 61-1/4 82.5
FLANGED BOTTOM 25-3/4 30-1/4 31-3/4 3M: 54-1/4 3M: ▲ 52 1/2 52 1/2 48 –
**HEIGHT (inches) STUDDED BOTTOM – – – – – ▲ 46 – –
CIW HUB BOTTOM – – – 3M: 50-1/2 3M: ▲ 51 ▲ 48 –
FLANGED BOTTOM 1850 2450 3520 ▲ ▲ 15100 16320 – 24500
STUDDED BOTTOM – – – – – ▲ 15290 – –
CIW HUB BOTTOM – – – ▲ ▲ 15000 ▲ 12700 –
FLANGED RX-45 RX-49 RX-53 3M: RX-74 3M: RX-74 RX-73 RX-73 – R-95
STANDARD RING GROOVE STUDDED – – – – – ▲ RX-73 – –
CIW HUB – – – 3M: RX-73 3M: RX-73 RX-73 ▲ RX-73 –
* 21-1/4-2000 BOP w/3000 psi Bottom ▲Available on request. *MSP 29-1/2”-500 Blowout Preventers are furnished with 11/4” NPT Closing Ports. 1-1/2” NPT ports are ** With Standard Studded Top Connection rated to working pressure of BOP. available on special request.
20
STUD BOLTS
Bolting is in accordance with API 16A. Bolting material shall be of a quality and strength not less than specified by ASTM A-193. Grade B7. Nuts shall be of a quality not less than ASTM A-194. Grade 2H.
PARTS LIST AND WEIGHTS–MSP 29-1/2"-500 DIVERTER
Approx. Item No. Net Weight
No. Part Name Req'd. Lbs.
– Diverter Assembly 1 24.010
1 Head 1 47100
▼2 Packing Unit - Natural
Nitrile 1 2145
Neoprene
3 Piston 1 3611
**4 Double U-Seal, Outer 1 12.5
**5 U-Seal, Inner 2 2.5
6 Body 1 11.050
**7 U-Seal Piston 2
8 Pipe Plug 2
9 Lock Ring – Square 6 16
10 Lock Ring – Beveled 6 17
11 Hex Head Cap Screw 12 31
12 Lever Assembly – not shown 1 13 Pointer Assembly – not shown 1
14 Cap Screw – not shown 1
15 Washer – not shown 1
16 Pipe Plug – not shown 1
*17 3-Piece Lock Ring Set – not shown 1
18 Welded Body Sleeve – not shown 1 1205 **19 O-Ring, Body Sleeve – not shown 1
20 Non-Extrusion Ring, Outer 2
21 O-Ring, Head 1 1.5
▼– Seal Set – Complete – 11.5
ACCESSORIES
– Lifting Ear – Piston 2 2.25
– Cap Screw 2 .44
– Eyebolt – Head 2 2.25
– Head Assembly Tool 1
consisting of:
Beam, Upper 1 100
Beam, Lower 1 100
Pulldown Studs, Long 2 9
Pulldown Studs, Short 2 6.2
Pulldown Nut 4 .81
Washer 4 .10
▼Recommended Spares for One Year Foreign Service, quantity 1 each. * Older model diverters may have 3-piece lock ring.
** Included in Seal Kit.
MSS* RING JOINT FLANGE CONNECTIONS FOR MSP 29-1/2”-500
BOLTS & STUDS
Max FLANGE SEAL RING *LENGTH Bolt FLANGE Nominal Bore Service Size Stud Circle
TYPE* Size Dia. Pressure O.D. Thickness Pitch Dia. API No. Thread Bolts Studs Dia. Inches Inches Rating Inches Inches “C” Inches Ring No. Required Form “A" “B” Inches 30”-300 MSS 30” 29 1/2” 720 WOG 43” 4 1/8” 33-3/4” R-95 28 1-3/4”-8 UN 12-7/8” 9-1/2” 39-1/4”
30”-600 MSS 30” 30” 1440 WOG 44-1/2” 5” 33-3/4” R-95 28 2”-8 UN 15-3/4” 10-1/2” 40-1/4” Manufacturer’s Standardization Society of the Valve and Fitting Industry.
