Code Lid L x W x H mm Compartment Layout

OS RC001 Solid 370 x 370 x 85 _{1 tool compartment in front of case.}20 adjustable compartments,

OS RC001/CL Clear 370 x 370 x 85 As above. Polycarbonate lid.

OS RC002 Solid 370 x 370 x 85 _{1 tool compartment in front of case.}1 large compartment

OS RC003 Solid 370 x 370 x 130

1 large tool compartment, plus 3 compartment lift-out tray and with further compartments below, with capability to be divided by 4 with divider OS RC003/D

OS RC003/D Divider for OS RC003 and OS RC003/CL

Storage Case - Rola-Case

The ROLA•CASE drawer system offers an extensive selection of storage solutions that allows further expansion horizontally and or vertically when your storage needs arise. The choice of cases and accessories will allow for storage of the smallest micro components through to power tools and cordless equipment. The cases are manufactured from engineering polymers, ABS, Polycarbonate and Nylon 66. They are moulded with a 3 – 5mm wall section and use stainless steel for the hinge and latch spring to ensure extended product life.

Code Lid L x W x H mm Compartment Layout

OS RC003/QK Solid 370 x 370 x 130 1 large compartment, plus 3 compartment lift-out tray and with further compartments below, 1 tool compartment. Includes Quik Kit (OS QK001) OS QK001 Solid 310 x 210 x 50 10 small compartments, 1 large tool _{compartment in front of case.} OS QK001/CL Clear 310 x 210 x 50 As above. Clear case & lid

OS RC001 OS RC002/CL OS RC003/CL

OS RC003/QK

Quik Kit OS QK001

Storage Case - Rola-Case Drawer Options

Code W x D x H mm Drawer Layout Holds

OS RC2FR 419 x 460 x 250 2 x RC001 or RC002 series cases. OS RC2FX - Horizontal extension 2 drawer frame also available OS RC3FR 419 x 460 x 350 3 x RC001 or RC002 series cases. OS RC3FX - Horizontal extension 3 drawer frame also available OS RC3FR/2D 419 x 460 x 350 2 x RC003 series cases.

OS RC4FR 419 x 460 x 460 4 x RC001 or RC002 series cases. OS RC4FX - Horizontal extension 4 drawer frame also available OS RC5FR 419 x 460 x 571 5 x RC001 or RC002 series cases. OS RC5FR/4D 419 x 460 x 571 2 x RC001 or RC002 and 2 x RC003 series cases. OS RC7DC/DM 839 x 460 x 960 _{combination of RC001, RC002 & RC003 series cases.}Up to 14 x RC001 or RC002 series cases or a

OS RC2FR

OS RC7DC/DM OS RC3FR + OS RC3FX + 6 x OS RC001

Versatile carry case for the storage and transport of tools, small parts and components.

Code Lid Width mm Depth mm Height mm Compartments

FI 1H150 Clear 370 432 85 21

FI 1H151 Solid 370 432 85 21

Add to code: BLU = RE = eg. Blue case with clear lid = FI 1H150BLU

Storage Case - Ezi-Pak

3 A.B.S. base & clip 3 Clear polycarbonate lid 3 21 compartments

3 Removable dividers to create larger storage area

3 Easy grip handle 3 Base legs

3 Easy to open & close lid

Code Width mm Depth mm Height mm Capacity

FI 1H156 420 440 265 Holds 2 EZI-PAK cases

3 Super tough A.B.S. plastic 3 Full extension, heavy duty

drawer steel slides 3 Modular. Removable base

plate to add more units with ease for greater versatility 3 Moulded holes in base enables

mounting on workbench, in vehicles or onto castors for mobility

3 Ezi-Pak Storage Module System is self locking

Storage Case - Ezi-Pak Storage Module

Modular system that holds two Ezi-Pak carry cases but with removable base plate to add more units if required. Ideal for bench top, vehicles or add castors for a mobile system.

(3)

105

105 PRODUCT FINDER 20

ST

O

RA

GE

SHEL

VING

RA

CKING

Storage Case

Storage Case - Parts-Pak

Sturdy carry case for small parts and components. Featuring blue ABS base, black ABS clips and clear polycarbonate lid with easy grip handle. Great for tradesperson, builders, etc..

Code Ext. W x D x H mm Int. W x D x H mm Included Parts Trays

FI 1H161 425 x 420 x 110 415 x 355 x 100 (2)100 x 300mm (1)200 x 300mm

Code Width mm Depth mm Height mm Lift Out Tray

FI 1H135 400 230 145 No

FI 1H137 400 230 145 Yes

FI 1H140 465 300 180 Yes

Add to code: BLU = GRN = eg. Green utility box = FI 1H135GR

3 Designed and made in Australia 3 All plastic construction - copolymer 3 Handle & Clips - A.B.S.

3 Strong and durable 3 Lockable

3 Ideal for Tradesman / Handyman / First Aid kits and around the home 3 Weather proof

Tool Box - Utility

Code Width mm Depth mm Height mm Lift Out Tray Drawers

FI 1H127 400 230 250 1 2

FI 1H128 460 300 280 1 3

3 Designed and made in Australia 3 All plastic construction -

copolymer

3 Handle & Clips - A.B.S. 3 Strong and durable 3 Medium and large - Lockable 3 Ideal for Tradesman or

Handyman

Toolbox With Drawers & Lift Out Tray

Code Width mm Depth mm Height mm Cantilever Tray

FI 1H106 328 190 160 2

FI 1H107 400 230 203 3

FI 1H108 465 300 254 6

Toolbox With Cantilever

Code Width mm Depth mm Height mm Lift Out Tray

FI 1H105 290 150 115 1

FI 1H124 328 190 160 1

FI 1H125 400 230 203 1

FI 1H126 465 300 254 1 + 2 x storage boxes

Toolbox With Lift Out Tray

FI 1H124 FI 1H125 FI 1H126

FI 1H127

FI 1H106 FI 1H107 FI 1H108

1H030

Code Type Width mm Depth mm Height mm Compartments

FI 1H030 Small 188 118 31 5

FI 1H031 Small 188 118 31 1

3 For the handyman - stores nails, screws, bolts, nuts and washers

3 For the tradesman - stores and protects all small parts and components

3 For the office - stores drawing pins, paperclips and staples

Storage Box - Clear Plastic - Small

FI 1H090 Large 310 200 80 3 FI 1H095 Large 310 200 80 6 FI 1H092 Large 310 200 48 1 FI 1H093 Large 310 200 48 12 FI 1H094 Large 310 200 48 18 FI 1H097 XLarge 350 270 55 20 FI 1H092 FI 1H093 FI 1H095

Storage Box - Clear Plastic - Large

1H032

FI 1H032 Medium 195 136 66 1

FI 1H037A Medium 195 157 48 1

FI 1H037B Medium 195 157 48 6

FI IH037C Medium 195 157 48 14

Storage Box - Clear Plastic - Medium

1H037A

1H037B 1H037C

(4)

106

106 ST

O

RA

GE

SHEL

VING

RA

CKING

IDEAL FOR

3 Tool & equipment storage 3 General storage box 3 Photographic equipment 3 Computer & electronic equipment 3 Camping, 4WD and outdoor use

Code _{L x W x H mm}External _{L x W x H mm}Internal Weight _kg Volume _m3

TC 055055025 550 x 550 x 225 480 x 480 x 170 6.8 0.068 TC 055055031 550 x 550 x 310 480 X 480 X 245 7.8 0.092 TC 055055045 550 X 550 X 450 480 X 480 X 390 8 0.133 TC 055055067 550 X 550 X 670 480 X 480 X 605 10.5 0.200 TC 110055025 1100 x 550 x 225 1045 x 495 x 180 12 0.136 TC 110055031 1100 x 550 x 310 1045 x 495 x 260 14.5 0.185 TC 110055045 1100 x 550 x 450 1045 x 495 x 405 16 0.266 TC 110055067 1100 x 550 x 675 1045 x 495 x 630 21 0.399

Add to code: B = blue G = Grey. eg. Blue case = TC 055055025B

Case - Spacecase© Modular 550

TC 055036045 550 x 360 x 440 455 x 310 x 410 10.5 0.087

TC 055055045B 550 x 550 x 440 455 x 500 x 410 14 0.133

Case - Spacecase© Modular 550 Front Opening

Spacecase© Storage Containers

Spacecase© Storage Containers are made from a high strength UV stabilised polyethylene material; they are stackable and interlocking and have pad-lockable quality catches as standard.

They offer ideal protection against harsh environmental conditions as they are highly durable, impervious to most chemicals and moisture and will not dent or rust.

The range of Spacecase© Storage Containers provide ideal storage and transit protection for contents ranging from general purpose containers to more specialised packaging of equipment ranging from radio equipment, computing equipment, and various other specialised Defence equipment.

TC 062031031 620 x 310 x 310 570 x 260 x 250 5.75 0.060

TC 062031045 620 x 310 x 450 570 x 260 x 375 7.75 0.086

TC 062062045 620 x 620 x 450 570 x 570 x 380 10 0.058

TC 124062045 1240 x 620 x 450 1190 x 570 x 370 25 0.346

Case - Spacecase© Modular 620

TC 035034034 350 x 350x 340 320 x 320 x 300 3.5 0.042

TC 078038038 780 x 380 x 380 720 x 330 x 310 6.0 0.113

TC 070055037 700 x 550 x 370 650 x 500 x 320 9.0 0.142

TC 090040040 900 x 400 x 400 850 x 300 x 325 8 0.144

TC 090055040 900 x 550 x 400 850 x 490 x 325 12.5 0.198

TC 090TRAYB Black Tray to suit above TC 090055040

TC 120055040 1200 x 550 x 380 1150 x 460 300 15 0.251

TC 124028040 1240 x 280 x 400 1230 x 225 x 330 10 0.132

Case - Spacecase© General Containers

3 Tough plastic moulded cases (UV stabilised food grade polyethylene) 3 Resists dust, water, chemical, oil and rust

3 Lockable over-centred zinc plated catches 3 Stack, interlock and palletise (modular style only) 3 Standard colours blue and Grey, others to order

We can supply special colours and fittings. eg. stainless steel.

(5)

107

107 PRODUCT FINDER 20

ST

O

RA

GE

SHEL

VING

RA

CKING

Parts Storage

Storage Bins - Economy

Strong and durable Economy small parts storage bins equipped with removable dividers, for the storage of small parts and components. Ideal for repair centres, garages, electronic shops. Made from Polypropylene to resist solvents & oils. Up to a maximum of five dividers can be used to divide each bin and an initial quantity of dividers is supplied with each bin (see below).

Economy Parts Storage Bin Features:

3 Strong and durable 3 Fits standard metal shelving 3 Industrial and domestic

3 Ideal for repair centres, garages, electronic shops 3 Position dividers to suit your needs

3 Made from Polypropylene to resist solvents & oils

Code Ext. W x D x H mm Dividers maximum Dividers Supplied

FI 1H012PGRY 100 x 300 x 100mm 3 2 FI 1H017PGRY 100 x 400 x 100mm 3 2 FI 1H024PGRY 200 x 300 x 100mm 3 2 FI 1H025PGRY 200 x 400 x 100mm 3 2 FI 1H027PGRY 100 x 600 x 100mm 5 5 FI 1H028PGRY 200 x 600 x 100mm 5 5

FI 1H014PGRY Divider to suit 100mm wide Parts Trays FI 1H026PGRY Divider to suit 200mm wide Parts Trays

Code Ext. W x D x H mm Int. W x D x H mm Dividers Supplied

NA IH344 105 x 424 x 100 92 x 390 x 98 2

NA IH335 105 x 324 x 100 92 x 290 x 98 3

NA IH348 203 x 424 x 100 190 x 390 x 98 2

NA IH338 203 x 324 x 100 190 x 290 x 98 2

NA IH301 Divider for NA IH344 & NA IH335 NA IH302 Divider for NA IH348 & NA IH338

IH348 IH344 IH338 IH335

Storage Bins - Utility

Nally utility bins offer a cost effective, space saving solution for the storage and handling of a wide range of component parts. They are light in weight, yet strong enough to give a long service life in tough manufacturing, assembly line and engineering applications. Internal divider options give maximum storage flexibility and strong, integral hand grips make for easy handling.

An easy to change labelling facility is incorporated and all Nally utility bins can be stacked or nested when empty to save valuable storage space. Great for automotive spares, cutting tools, electronic components, plumbing & hardware fittings and general parts. Up to a maximum of three dividers can be used to divide each bin and an initial quantity of dividers is supplied with each bin (see chart below). Available in Grey only.

Code Type Vol. litre Ext. W x D x H mm Dividers *Louvres

NA IH1000 N5 0.5 100 x 120 x 60 No 2 NA IH1001 N10 1.0 100 x 178 x 85 No 3 NA IH1002 N20 2.5 135 x 225 x 125 No 4 NA IH1003 N30 6.0 205 x 280 x 165 1 5 NA IH1004 N40 12.0 410 x 280 x 165 1-2 5 NA IH1006 N60 24.0 410 x 440 x 210 1-2 6

Add to bin code: BLU = GRN = RE = YE= eg. N10 blue bin = NA IH100BLU NA IH1015 Divider for NA IH1003 & NA IH1004

NA IH1020 Divider for NA IH1006

*Louvres = The number of rows of louvres (on louvre panels) occupied by the bin.

Storage Bins - Shelf / Hang / Stack

An integrated small parts storage system, these storage bins offer you optimum storage versatility, and easy parts access.

Developed with the assistance of leading edge computer technology these storage bins are made from tough durable polypropylene, are light in weight, yet strong enough to withstand the rough and tumble of everyday use in busy work environments. Bins can be mounted on louvred panels, hanging strips or can remain free standing.

Available in four colours (Red, Blue, Green, Yellow) and six sizes.

3 Warehouses 3 Storerooms 3 Workshops 3 Manufacturing Plants 3 Hospitals 3 Laboratories 3 Schools 3 Service Stations 1H012 1H017 1H024 1H025 1H027 1H028

Storage Bins - EasyFit - Stainless - Chrome

EasyFit Chrome Wire Baskets are a range of wire baskets designed to enhance the ability to store sterilised medical supplies. The baskets are designed to interchange with the Plastic Micro Bin range, which is used extensively throughout medical facilities. Each Chrome Wire Basket features a fine mesh of 8 x 8 mm which is more effective in retaining smaller items and has a double wire on the top edge to ensure there are no sharp edges. The Chrome Wire Baskets can rest on shelves or fit onto louvred panel.

Code Finish Model W x D x H mm Mesh Size mm Divider Available

DE 179800 Chrome W5 108 x 113 x 60 8 x 8 No DE 179801 Stainless W5 108 x 113 x 60 8 x 8 No DE 179802 Chrome W10 108 x 171 x 85 8 x 8 No DE 179803 Stainless W10 108 x 171 x 85 8 x 8 No DE 179804 Chrome W20 143 x 218 x 125 8 x 8 No DE 179805 Stainless W20 143 x 218 x 125 8 x 8 No DE 179806 Chrome W30 210 x 273 x 165 8 x 8 Yes DE 179807 Stainless W30 210 x 273 x 165 8 x 8 Yes DE 179808 Chrome W40 418 x 273 x 165 8 x 8 Yes DE 179809 Stainless W40 418 x 273 x 165 8 x 8 Yes DE 179810 Chrome W60 418 x 450 x 215 8 x 8 Yes DE 179811 Stainless W60 418 x 450 x 215 8 x 8 Yes
