Fiori 10 Installation Guide

(1)

SAP Fiori

Document Version: 1.0 - 2013-07-25

(2)

1 Prerequisites

1.1 Prerequisites Checklist

Before you can install and configure SAP Fiori apps, you must ensure that the prerequisite software is installed and Remote Function Call (RFC) connections are set up.

Prerequisites More Information

❑ SAP NetWeaver Application Server Advanced Business Application

Programming (AS ABAP) 7.0 SPS21 and above

● http://help.sap.com/nw_platform

● SAP Notes for SAP NetWeaver AS ABAP [page 5]

❑ For SAP Fiori applications based on SAP ERP:

SAP Enterprise Resource Planning (ERP) 6.0 SPS15 or above

● 6.0 SPS 15 and above 6.0 ● EnhP2 SPS 06 and above 6.0 ● EnhP3 SPS 05 and above 6.0 ● EnhP4 SPS 05 and above 6.0 ● EnhP5 SPS 03 and above 6.0 ● EnhP6 SPS 01 and above

7.00 SP 21 and above & SAP Note 1774246

● http://help.sap.com/erp ● SAP Notes for SAP ERP [page 6]

❑ For SAP Fiori applications based on SAP SRM:

● SAP SRM 7.0 SPS 02

For the My Shopping Cart and Track Shopping Carts applications:

● SAP SRM User Interface Add-On 1.0 SP 01

For the My Shopping Cart and Track Shopping Carts applications, special prerequisites apply:

Prerequisites for My Shopping Cart and Track Shopping Carts [page 7]

❑ SAP NetWeaver Gateway 2.0 SPS06 ● IW_BEP 2.0* (SP06)

● GW_CORE 200 (SP06) ● IW_PGW 100 (SP03)

● IW_FND 250 (SP06) with SAP Note 1812143

● JSON - IWFND 2.50 (NW 7.02) SP04 with SAP Note 1648418 (and the included note SAP Note 1650141)

● SAP Notes for SAP ERP [page 6] ● http://help.sap.com/nwgateway20

● SAP NetWeaver Gateway Installation Guide>Installation Prerequisites

● SAP NetWeaver Gateway Installation Guide

● SAP Netweaver Gateway Installation Guide>Installing SAP NetWeaver Gateway Components

(5)

Prerequisites More Information

● JSON -IWFND 2.40** (NW 7.00) ON 7.20 Kernel with SAP Note 1648418 (and the included note SAP Note 1650141)

● * IW_BEP 2.0 SP06 (with SAP Note 1799722 and SAP Note 1805831) is needed in the source ERP Central Component (ECC) system below NetWeaver 7.4. ● ** JSON - IWFND 2.40 (NW 7.00) ON 7.00 Kernel is not

supported - Atom only ❑ SAP UI5 for NetWeaver Add-On

● UISAPUI5 100 SP04 UI5 library 1.12 (if NW 7.0 or later)

● UI_INFRA 100 SP04 ● UI2_700 100 SP04

● UI2_701 100 SP04 (If NW 7.0 EHP1 or later)

● UI2_702 100 SP04 (If NW 7.0 EHP1 or later)

● UI2_731 100 SP04 (If NW 7.3 EHP1 or later, if NW 7.1 EHP3 or later)

● UI2_FND 100 SP04 ● UI2_SRVC 100 SP04

SAP Notes for SAP UI5 for NetWeaver Add-On [page 7]

❑ Define a Remote Function Call (RFC)

Destination from ECC or SRM to Gateway ●_{● Setting up a trusted connection between Gateway and}Creating RFC Connections ECC or SRM: Connection Settings SAP NetWeaver Gateway to SAP Systems

● Create a System Alias [page 53] ❑ RFC Destination from SAP NetWeaver

Gateway to ECC or SRM

❑ Register alias for the ECC or SRM RFC Destination to the SAP NetWeaver Gateway

1.2 SAP Notes for SAP NetWeaver AS ABAP

The following table lists the SAP Notes that must be applied to SAP NetWeaver Application Server Advanced Business Application Programming (AS ABAP):

SAP Note Number Description

SAP Note 1774246 Mobile Inbox: Inbox API

SAP Note 1799549 SAP WAPI_CREATE_OUTBOX: Optional parameter SAP Note 1805986 Additional parameter for SAP WAPI_ATTACHMENT_ADD SAP Note 1754533 Enhancement of WAPI trace

(6)

1.3 SAP Notes for SAP ERP

The following table lists the SAP Notes that must be applied to SAP Enterprise Resource Planning (ERP):

SAP Note 1799549 SAP WAPI_CREATE_OUTBOX: Optional parameter SAP Note 1805986 SAP WAPI_CREATE_OUTBOX: Optional parameter SAP Note 1754533 Enhancement of WAPI trace

SAP Note 1809628 Additional methods for IF_SWF_UTL_WAPI_FRAMEWORK For Approval apps:

(SAP_BASIS component): SAP Note 1774246

Mobile Inbox: Inbox API

Note

If IW_BEP software component version is Release 2 Support Package 06 or more or if IW_BEP software component version is Release 2 Support Package 05 or less AND SAP Note 1766501: Check Data Container Type Returned by DPC has been installed, then you must apply SAP Note 1799807: Suppress Message / IWBEP/CM_MGW_RT 157.

1.4 SAP Notes for SAP NetWeaver Gateway

The following table lists the SAP Notes that must be applied to SAP NetWeaver Gateway:

SAP Note Number Description Required For

SAP Note 1799722 IW_BEP Adjustments to Task Gateway for SP06 For SAP ERP systems using SAP NetWeaver 7.31 and below. For more information, see Installing SAP NetWeaver Gateway Components.

SAP Note 1805831 Workflow Support Decision options Nature (Positive/ Negative)

SAP Note 1866093 Patches for the Gateway SPS06 required for FIORI _{● Approve Requests} ● Approve Shopping

Carts

● Approve Requisitions ● Approve Purchase

(7)

1.5 SAP Notes for SAP UI5 for NetWeaver Add-On

The following table lists the SAP Notes that must be applied to SAP UI5 for NetWeaver Add-On

SAP Note 1759682 UI Add-on for SAP NetWeaver Central Note SAP Note 1666368 Installing UI Add-on 1.0 for SAP NetWeaver

SAP Note 1666369 Support Packages for UI Add-on 1.0 for SAP NetWeaver SAP Note 1852767 Patches for the NW UI Add-on SP04 required for SAP Fiori

1.6 Prerequisites for My Shopping Cart and Track Shopping

Carts

Additional prerequisites apply for the SAP Fiori My Shopping Cart and Track Shopping Carts applications. These applications do not use OData services for ABAP integration. Instead, they re-use SAP NetWeaver Gateway services from the SAP SRM User Interface Add-On.

The table below outlines the critical installation and configuration steps that you need to complete in your SRM system before installing these two SAP Fiori applications.

Prerequisites

❑ Install the central SAP NetWeaver Gateway components GW_CORE and IW_FND in your SAP SRM system. ❑ Install the SAP SRM User Interface Add-On 1.0 SP 01 in your SAP SRM system.

❑ Connect SAP NetWeaver Search and Classification (TREX) to your SAP SRM system and enable OCI5 for the catalogs.

❑ If you use the Lean Inbox in SAP SRM:

Activate the soft switch SRM_700_LOCAL_MENU in your SAP SRM system. ❑ Customize the SAP SRM User Interface Add-On.

For the complete list of prerequisites, see the appendix of the Master Guide for the SAP SRM User Interface Add-On.

Related Links

Master Guide for SAP SRM User Interface Add-On 1.0

Configuration Cookbook for the SAP SRM User Interface Add-On (SRM Community) SAP SRM User Interface Add-On on SAP Help Portal

(8)

The following table lists the SAP SRM services used by the SAP Fiori My Shopping Cart and Track Shopping Carts applications. These services are provided by the SAP SRM User Interface Add-On.

(9)

2 Install

2.1 Setup Checklist

This checklist lists, in order, the tasks that must be performed to install and configure the SAP Fiori applications. It also provides links to related information and instructions.

Task More Information

1 Install

❑ Deploy the SAP Fiori packages on the SAP Business

Suite back-end system ● See Integration and SAP UI5 Components _{for SAP Fiori Applications [page 10]} ● See Install Add-On Components [page

10] ❑ Install Add-On Components on SAP NetWeaver

Gateway

2 Configure SAP Business Suite Components To configure SAP Business Suite Components:

● Define Users and Authorizations [page 12]

● Configure the Back-End Event Publisher [page 13]

● Specify Connection Settings to SAP NetWeaver Gateway [page 14] 3 Configure SAP NetWeaver Gateway Settings

❑ Define Users and Authorizations ❑ Specify Language Settings

4 Configure SAP Netweaver Gateway Components

❑ Activate Gateway and UI5 Services in SICF See Activate Gateway and UI5 Services in SICF [page 15]

❑ Configure App-Specific Gateway Services See Activate Gateway and UI5 Services in SICF [page 15]

5 Configure Specific Apps See the configuration instructions specific to your application:

● Configure Employee Apps [page 21] ● Configure Manager Apps [page 28] ● Configure Sales Rep Apps [page 38] ● Configure Purchasing Agent Apps [page

46]

Note

(10)

You must also activate Standard Mode (Odata) Services for the following Manager approval applications:

Approve Requests Approve Leave Requests Approve Shopping Requests Approve Purchase Orders Approve Purchase Requisitions Approve Purchase Contracts For more information, see Activate and Maintain Services.

6 Access the applications Access SAP Fiori Apps [page 17]

2.2 Install Add-On Components

To install the appropriate integration and SAP UI5 components on your SAP NetWeaver Gateway 2.0 server, perform the following steps:

1. Execute the transaction SAINT to access the add-on installation tool.

For more information on using SAINT, read the SAP Add-On Installation Tool documentation. 2. Start the installation in the add-on installation tool.

Related Links

Integration and SAP UI5 Components for SAP Fiori Applications [page 10]

The following table lists the UI and integration components for each SAP Fiori application. The UISRA* components need to be installed on the Gateway server and the SRA* components on the backend server.

2.2.1 Integration and SAP UI5 Components for SAP Fiori

Applications

The following table lists the UI and integration components for each SAP Fiori application. The UISRA* components need to be installed on the Gateway server and the SRA* components on the backend server.

Table 1: Scenario-Specific UI5 and OData Components

Application Product Version on SAP

Service Marketplace

UI Component OData Component in

SAP Business Suite

Employee

(11)

Application Product Version on SAP Service Marketplace

SAP Business Suite

My Shopping Cart FIORI SHOPCARTCRE UISRA014 100 Uses SRM component SRMNXP01 100 Track Shopping Carts FIORI SHOPCARTTRK UISRA011 100 Uses SRM component

SRMNXP01 100 My Travel Requests FIORI TRAVELREQCRE UISRA004 100 SRA004 600

My Leave Requests FIORI LEAVEREQCRE UIHCM002 100 GBHCM002 (SP07) + SAP Notes

My Paystubs FIORI PAYSLIPLOOK UISRA006 100 SRA006 600

My Benefits FIORI MYBENENRO UISRA007 100 SRA007 600

Manager

My Spend FIORI MYDEPTSPEND UISRA012 100 SRA012 600

Approve Requests FIORI GENERICINBX UIGIB001 100 Included in IW_PGW 100 (SP03)

Approve Leave Requests FIORI LEAVEREQAPPR UIHCM003 100 GBHCM003 600 (SP06) + SAP Notes

Approve Shopping Carts FIORI SHOPCARTAPPR UISRM001 100 GBSRM001 700 (SP07) + SAP Notes

Approve Travel Expenses FIORI TRAVELEXPAPPR UISRA008 100 SRA008 600 Approve Travel Requests FIORI TRAVELREQAPPR UISRA009 100 SRA009 600 Approve Purchase Orders FIORI

PURCHASEORDAPPR

UIAPP002 100 GBAPP002 600

Approve Timesheets FIORI TIMESHTAPPR UISRA010 100 SRA010 600 Approve Purchase

Contracts

FIORI

PURCHASECONTAPPR

UISRA001 100 SRA001 600

Approve Requisitions FIORI

PURCHASEREQAPPR

UIAPP001 100 GBAPP002 600

Sales Representatives Check Price and Availability

FIORI PRICECHECK UISRA016 100 SRA016 600 Create Sales Orders FIORI ORDERCRE UISRA017 100 SRA017 600 Track Sales Orders FIORI ORDERSTSTRK UISRA018 100 SRA018 600

Track Shipments FIORI SHIPTRK UISRA019 100 SRA019 600

Change Sales Orders FIORI ORDERCHG UISRA018 100 SRA018 600 Customer Invoices FIORI INVOICEBILL UISRA021 100 SRA021 600 Purchasing Agent

(12)

Application Product Version on SAP Service Marketplace

SAP Business Suite

Order from Requisitions FIORI ORDERPOREQ UISRA013 100 SRA013 600 + SAP Notes Track Purchase Order FIORI TRACKPO UISRA020 100 SRA020 600 + SAP Notes

Note

For some SAP Fiori applications, you must also implement SAP Notes to complete the installation. For more information, see the sections for the individual applications.

Related Links

Configure Employee Apps [page 21]

Employee Apps are used to submit requests for leave and travel, view paystubs and benefits, manage time entry data, and create shopping carts.

Configure Manager Apps [page 28]

Manager apps are used to approve requests for leave and travel, purchase orders, requisitions, shopping carts, timesheets, and purchase contracts. The apps can also be used to view budget and spend information.

Configure Sales Rep Apps [page 38]

Sales representatives use the apps to check price and availability; create, track, and change sales orders; track shipments, and view information about customer invoices.

Configure Purchasing Agent Apps [page 46]

The purchasing agent uses the apps to perform tasks such as ordering from requisitions and tracking purchase orders.

2.3 Configure SAP Business Suite Components

2.3.1 Define Users and Authorizations

Set up users and assign authorizations to your users in the back-end system. The following SAP Fiori apps include business roles:

● Approve Requests ● Approve Leave Request ● Approve Shopping Cart ● Approve Requisition ● Approve Purchase Order ● My Leave Requests

● Approve Purchase Contracts

These roles, in addition to the personalization settings, ensure that managers are authorized to display the correct data for their organizational entities and perform the approval activities.

(13)

a) When you enter the authorization maintenance for the role, use the role template /IWBEP/RT_MGW_USR. It contains the authorization for the OData Channel RFC function group /IWBEP/FGR_MGW_CLIENT_IF. b) Add the authorization object S_RFCACL (authorization for a trusted RFC destination between SAP

NetWeaver Gateway and SAP back-end systems). c) Maintain the correct authorization values.

d) Generate the profile.

2. Assign this technical role to the application users.

3. Copy the application-specific SAP roles in the table below into the customer namespace and maintain the authorization values correctly.

Application Role

SAP Approve Requests No role provided, but authorization must be assigned for usage of the service

Approve Leave Request SAP_GBHCM_LEAVE_APPROVAL_MGR Approve Shopping Cart SAP_GBSRM_CART_APPROVAL_MANAG Approve Purchase Requisition SAP_GBAPP_PR_APPROVAL_MANAGER Approve Purchase Order SAP_GBAPP_PO_APPROVAL_MANAGER

My Leave Requests SAP_GBHCM_LEAVE_REQUEST_EMPL and also the Gateway role SAP_HCM002_HCM_LVRQ_CR Approve Purchase Contracts SAP_SRA01_PC_APPROVAL_MANAGER

○ Alternatively, create a customer role based on SU22 entries of the SAP R3TR/IWSV service (S_SERVICE). 4. Assign the new role(s) to the application users.

For more information about users and authorizations, see User Management.

2.3.2 Configure the Back-End Event Publisher

Specify the settings for the OData Channel in the BEP component (IW_BEP).

Depending on your underlying SAP NetWeaver release, the configuration settings for OData Channel and the structure in the Implementation Guide (IMG) may differ. For more information, see Backend Event Publisher (BEP)

Configuration.

Note

This step is not relevant for the My Shopping Cart and Track Shopping Carts applications. Related Links

(14)

2.3.3 Specify Connection Settings to SAP NetWeaver

Gateway

Specify the settings that can be used by the OData Channel and the BEP component to establish the connection from your ERP system to SAP NetWeaver Gateway.

Depending on your underlying SAP NetWeaver release the configuration settings for OData Channel and the structure in the Implementation Guide (IMG) may differ. See OData Channel Configuration in the SAP Library for more details, available via the web link in Related Links.

For more information on connection settings, see the Connection Settings on the Backend System topic in the SAP

Library for SAP NetWeaver Gateway on the SAP Help Portal, available via the links in Related Links.

Related Links

OData Channel Configuration

Connection Settings in the Backend System SAP NetWeaver Gateway

2.4 Configure SAP NetWeaver Gateway Components

2.4.1 Configure App-Specific Gateway Services

To configure gateway services, go to the IWFND maint_service transaction, add the service for the application, and check that it is activated.

1. In your Gateway system, go to transaction /IWFND/maint_service.

Note

You must repeat the following steps (2 to 6) for each SAP Fiori application you installed. 2. Select Add Service.

3. Enter the system ALIAS for the target ERP system that you defined when configuring the connection between Gateway and the ERP system.

4. Select Get Services, then select the service for the application that you want to configure. 5. Click the Technical service name.

6. In the Add Service window, select local object and validate. 7. Return to the main_service main screen.

8. Check that all SAP Fiori services are activated. Related Links

Gateway Services for Applications [page 15]

This table lists the SAP NetWeaver Gateway services required for SAP Fiori applications. Activate and Maintain Services

(15)

2.4.2 Activate Gateway and UI5 Services in SICF

To activate the required Gateway services, go the required transaction, and check the services are active: 1. In your Gateway system, go to transaction SICF.

2. Select Execute.

3. Navigate to sap opu odata sap .

4. Check that all Gateway services for all SAP Fiori applications are active: ○ Right-click each service. Activate Service should be inactive (grayed out). ○ If Activate Service is active, right-click each service and select Activate Service. 5. Navigate to sap bc ui5_ui5 sap .

6. Check that all ICF nodes for the installed applications are active:

○ Right-click each service. Activate Service should be inactive (grayed out). ○ If Activate Service is active, right-click each service and select Activate Service. Related Links

Gateway Services for Applications [page 15]

This table lists the SAP NetWeaver Gateway services required for SAP Fiori applications. SICF Services for UI Applications [page 16]

This table lists the relevant SICF services for the UI applications of SAP Fiori applications.

2.5 Components and Services

2.5.1 Gateway Services for Applications

This table lists the SAP NetWeaver Gateway services required for SAP Fiori applications.

Application Name External Service Name

Employee

My Travel Requests sra004_srv

My Leave Requests leaverequest, version 2

My Paystubs sra006_srv

My Benefits sra007_benefits_srv

My Timesheet sra002_timesheet_srv

My Shopping Cart Uses services from the SAP SRM User Interface Add-On (namespace /SRMNXP/)

Track Shopping Carts Uses services from the SAP SRM User Interface Add-On (namespace /SRMNXP/)

(16)

Application Name External Service Name

Approve Leave Requests leaveapproval

Approve Shopping Carts cartapproval, version 2

Approve Purchase Orders gbapp_poapproval

Approve Requisitions gbapp_prapproval

Approve Requests taskprocessing

Approve Travel Requests sra009_srv

Approve Timesheets sra010_timesheet_approval_srv Approve Purchase Contracts sra001_contract_approval_srv

Approve Travel Expenses sra008_srv

Approve Purchase Contracts sra001_pcapproval

My Spend sra012_spend_srv

Sales Representatives

Check Price and Availability sra016_price_avail_srv

Customer Invoices sra021_srv

Change Sales Orders sra018_so_tracking_srv

Create Sales Orders sra017_salesorder_create_srv

Track Sales Orders sra018_so_tracking_srv

Track Shipments sra019_shipment_tracking_srv

Purchasing Agent

Order From Requisitions sra013_po_from_pr_srv Track Purchase Order sra020_po_tracking_srv

2.5.2 SICF Services for UI Applications

This table lists the relevant SICF services for the UI applications of SAP Fiori applications.

Application Name Service Name

Launch Page for Tile CHIPs /ui2/launchpage Employee

My Travel Requests ui5_fi_trreq_cr

My Paystubs ui5_hcm_ps_mon

My Benefits ui5_hcm_ben_ovw

My Leave Requests ui5_hcm_lr_cr

(17)

Application Name Service Name

My Shopping Cart ui5_srm_sc_cr

Track Shopping Cart ui5_srm_sc_mon

Manager

Approve Leave Requests ui5_hcm_lr_apv

Approve Shopping Carts ui5_srm_sc_apv

Approve Purchase Orders ui5_mm_po_apv

Approve Requisitions ui5_mm_pr_apv

Approve Travel Requests ui5_fi_trreq_apv

Approve Timesheets ui5_hcm_tsa

Approve Purchase Contracts ui5_mm_pc_apv Approve Travel Expenses ui5_fi_trex_apv

Approve Requests ui5_ca_all_apv

My Spend ui5_co_spe_mon

Sales Representative

Check Price and Availability ui5_scm_pa_chk

Customer Invoices ui5_sd_inv_mon

Change Sales Orders ui5_sd_so_man

Track Shipments ui5_sd_ship_mon

Create Sales Order ui5_sd_so_cr

Track Sales Order ui5_sd_so_mon

Purchasing Agent

Order From Requisitions ui5_mm_popr_cr

Track Purchase Order ui5_mm_po_tr

2.6 Access Apps

2.6.1 Access SAP Fiori Apps

Users can access SAP Fiori applications directly or via the home page (the launch page). Related Links

SAP Fiori App URLs [page 18]

To open a SAP Fiori application directly, use the relative URL listed in this table. Add Apps to the User's Home Page [page 19]

You define which SAP Fiori applications appear on a user's home page (launch page) by assigning users to predefined roles.

(18)

2.6.1.1 SAP Fiori App URLs

To open a SAP Fiori application directly, use the relative URL listed in this table.

Note

If you want to embed the SAP Fiori application into an existing portal page, add the URL parameter backToHome=true . This enables the user to return to the portal page from the application. Example:

/sap/bc/ui5_ui5/sap/ui5_hcm_lr_cr/index.html?backToHome=true

Table 2: Relative URLs for SAP Fiori Applications

Application URL

Employee

My Benefits /sap/bc/ui5_ui5/sap/ui5_hcm_ben_ovw/index.html My Leave Requests /sap/bc/ui5_ui5/sap/ui5_hcm_lr_cr/index.html My Pay Stubs /sap/bc/ui5_ui5/sap/ui5_hcm_ps_mon/index.html

My Shopping Cart /sap/bc/ui5_ui5/sap/ui5_srm_sc_mon/index.html?create=true My TimeSheet /sap/bc/ui5_ui5/sap/ui5_hcm_ts_man/index.html

My Travel Requests /sap/bc/ui5_ui5/sap/ui5_fi_trreq_cr/index.html Track Shopping Carts /sap/bc/ui5_ui5/sap/ui5_srm_sc_mon/index.html Manager

Approve Leave Requests /sap/bc/ui5_ui5/sap/ui5_hcm_lr_apv/index.html Approve Purchase Contracts /sap/bc/ui5_ui5/sap/ui5_mm_pc_apv/index.html Approve Purchase Orders /sap/bc/ui5_ui5/sap/ui5_mm_po_apv/index.html

Approve Requests The target URL depends on your custom workflow scenario. For more information, see Configure Launch Settings for Custom Workflows [page 51].

Approve Requisitions /sap/bc/ui5_ui5/sap/ui5_mm_pr_apv/index.html Approve Shopping Carts /sap/bc/ui5_ui5/sap/ui5_srm_sc_apv/index.html Approve Timesheets /sap/bc/ui5_ui5/sap/ui5_hcm_ts_apv/index.html Approve Travel Expenses /sap/bc/ui5_ui5/sap/ui5_fi_trex_apv/index.html Approve Travel Requests /sap/bc/ui5_ui5/sap/ui5_fi_trreq_ap/index.html My Spend /sap/bc/ui5_ui5/sap/ui5_co_spe_mon/index.html Sales Representatives

Change Sales Orders /sap/bc/ui5_ui5/sap/ui5_sd_so_mon/index.html?change=true Check Price and Availability /sap/bc/ui5_ui5/sap/ui5_sd_prav_mon/index.html

(19)

Application URL

Create Sales Orders /sap/bc/ui5_ui5/sap/ui5_sd_so_cr/index.html Customer Invoices /sap/bc/ui5_ui5/sap/ui5_sd_inv_mon/index.html Track Sales Orders /sap/bc/ui5_ui5/sap/ui5_sd_so_mon/index.html Track Shipments /sap/bc/ui5_ui5/sap/ui5_sd_ship_mon/index.html Purchasing Agent

Order From Requisitions /sap/bc/ui5_ui5/sap/ui5_mm_pr_cr/index.html Track Purchase Orders /sap/bc/ui5_ui5/sap/ui5_mm_po_trR/index.html

2.6.1.2 Add Apps to the User's Home Page

You define which SAP Fiori applications appear on a user's home page (launch page) by assigning users to predefined roles.

Note

All SAP Fiori applications are preconfigured in the launch page catalog, except for the Approve Requests application. If you are using Approve Requests to process custom approval workflows or workflows delivered by SAP, you need to add the application to the launch page catalog yourself.

1. In your SAP NetWeaver Gateway system, call transaction PFCG (Role Maintenance). 2. Assign users to the predefined launch page role for your SAP Fiori application.

Table 3: SAP Fiori Roles for the Launch Page

Application Role for Launch Page

Employee

My Benefits SAP_SRA007_HCM_BEN_OVW

My Leave Requests SAP_HCM002_HCM_LVRQ_CR

My Pay Stubs SAP_SRA006_HCM_PS_MON

My Shopping Cart SAP_SRA014_SRM_SC_CR

My TimeSheet SAP_SRA002_HCM_TS_MAN

My Travel Requests SAP_SRA004_FI_TRREQ_CR Track Shopping Carts SAP_SRA011_SRM_SC_MON Manager

Approve Leave Requests SAP_HCM003_HCM_LVRQ_APR Approve Purchase Contracts SAP_SRA001_MM_PC_APV Approve Purchase Orders SAP_APP002_MM_PO_APR

(20)

Application Role for Launch Page

Approve Requests The role depends on your custom settings. For more information, see Configure Launch Settings for Custom Workflows [page 51].

Approve Requisitions SAP_APP001_MM_PR_APR Approve Shopping Carts SAP_SRM001_SRM_SHOP_APR Approve Timesheets SAP_SRA010_HCM_TS_APV Approve Travel Expenses SAP_SRA008_FI_TREX_APV Approve Travel Requests SAP_SRA009_FI_TRREQ_AP

My Spend SAP_SRA012_CO_SPE_MON

Sales Representatives

Change Sales Orders SAP_SRA003_SD_SO_CHG Check Price and Availability SAP_SRA016_SD_PRAV_MON Create Sales Orders SAP_SRA017_SD_SO_CR Customer Invoices SAP_SRA021_SD_INV_MON Track Sales Orders SAP_SRA018_SD_SO_MON Track Shipments SAP_SRA019_SD_SHIP_MON Purchasing Agent

Order From Requisitions SAP_SRA013_MM_PR_CR Track Purchase Orders SAP_SRA020_MM_PO_TR Users see the tiles for the assigned SAP Fiori applications on the home page.

To call the home page, enter the following URL: https://<server> : <port>/sap/bc/ui5_ui5/ui2/ launchpage/home.html.

The launch page is part of the User Interface Add-On for SAP NetWeaver. For more information about setting up the launch page, see the documentation on SAP Help Portal at http://help.sap.com/nw-uiaddon >

Application Help > User Interface Add-On 1.0 SPS04 for SAP NetWeaver.

For more information about setting up user roles, see the documentation for SAP NetWeaver Platform on SAP Help Portal at http://help.sap.com/nw_platform. Search for Configuration of User and Role Administration. Related Links

User Interface Add-On 1.0 SPS04 for SAP NetWeaver SAP NetWeaver Platform

(21)

3 Employee Apps

3.1 Configure Employee Apps

Employee Apps are used to submit requests for leave and travel, view paystubs and benefits, manage time entry data, and create shopping carts.

Table 4: Employee Apps

App Description Configuration

information

My Leave Requests Create and submit leave requests on a desktop or mobile device. Track the status of your requests, and see your current leave balance.

My Leave Requests [page 27]

My Paystubs Check and manage, at any time through mobile devices or desktop, a digital version of all your pay stubs issued by the company for each payroll period.

See My Paystubs [page 21]

My Shopping Cart A one-stop desktop and mobile solution to employees' enterprise shopping needs; use the app to create the cart, and select approvers. The app leverages the powerful SAP(R) Supplier Relationship Management (SRM) catalog search capability to enable easy shopping and workflow approval.

See My Shopping Cart [page 23]

Track Shopping Carts Track the status of your shopping cart. Track Shopping Carts [page 25]

My Timesheet Manage your time entry data quickly, efficiently, anywhere, at any time on desktop or mobile device.

See My Timesheet [page 26]

My Travel Requests Manage - create, submit, edit, and check status - your travel requests on desktop as well as on mobile device.

Apply the corrections contained in SAP Note 1887701..

My Benefits View an overview of your enrolled benefit plans throughout the year, and all the details of all benefits offered by the company.

See My Benefits [page 25]

3.2 My Paystubs

(22)

Tasks More Information

1 ❑ Apply the fix in SAP Note 890828 SAP Note 890828, HRBG & HRUS: ABAP dump in class CL_HR_PAY_RESULT_GB/US, is available from the SAP Service Marketplace.

Note

You need to deploy this fix only if it has not yet been deployed.

2 ❑ Deploy the business add-in (BAdI), XSS_REM_INTERFACE using the classic BAdI

implementation.

The XSS_REM_INTERFACE BAdI is required to filter pay stub statements after a payroll run. This BAdI, which is present in the ECC system, belongs to the software component EA-HRRXX. Ensure that the following method of the BAdI is implemented:

IF_EX_XSS_REM_INTERFACE~PROVIDE_FILTERED_R GDIR. Deploy the BAdI as a classic BAdI.

For instructions on how to activate BAdI implementations, see Steps To Activate BAdI Implementations.

3 ❑ Configure parameters to allow employees to view the salary statement as a PDF-based form. Your employees can print the salary statement from the web application or save it.

Pay stubs are displayed in SAP Firoi in the same manner as they are displayed in Employee Self-Service (ESS) Applications.

Note

SAP Fiori does not support Concurrent Employment.

Note

If you launch the application from an icon on the home screen of an iPhone or an iPad, it opens full-screen in a browser instance that does not contain a back button.

Refer to the following document in the SAP Library for detailed information: Business Package for

Employee Self-Service (SAP ERP) 1.0 and expand the pages as follows: Employee Self-Service (ESS) Applications Benefits and Payment Salary Statement

(23)

3.3 My Travel Requests

To enable the SAP Fiori My Travel Requests application, you must perform a required configuration task. The following SAP Note must be applied:

● SAP Note 890828 HRGB & HRUS: ABAP dump in class CL_HR_PAY_RESULT_GB/US

3.4 My Shopping Cart

To enable the SAP Fiori My Shopping Cart app, you must ensure that all prerequisites are in place and perform a number of configuration tasks.

Related Links

Prerequisites for My Shopping Cart and Track Shopping Carts [page 7]

3.4.1 SRM Services Used by My Shopping Cart and Track

Shopping Carts

The following table lists the SAP SRM services used by the SAP Fiori My Shopping Cart and Track Shopping Carts applications. These services are provided by the SAP SRM User Interface Add-On.

To select these services in the service catalog, filter for the namespace /SRMNXP/ .

External Service Name Service Description

ACC_ASS_SEARCH_HELP Account assignment search help

ACC_ASSIGN_CATEGORY Service for account assignment category description ACC_ASSIGN_FLD_METADATA Service for account assignment file metadata

ACC_ASSIGN_SRH Account assignment search help service

APPROVAL_SERVICE Approval service

APVR_SRCHLP Search help for approver and reviewer

CATALOG_LAUNCH_DETAILS Catalog launch details

COUNTRY_SH_SERVICE Service for country search

CROSS_CATALOG_SEARCH Cross catalog search

(24)

External Service Name Service Description

CUR_EXCH_RATE_SERVICE Service for currency exchange rates

DOMAIN_VALUES Domain values

GETDEFUSRSET Service for getting default user settings GRECIPIENT_SH_SERVICE SH for goods recipient

ITEMHISTORY_SERVICE Item history service

LANGUAGE Service for language

LOGICAL_SYSTEM Service for logical system

NOTES_SERVICE Service for notes

ORDERTRACK_SERVICE Order track service

PC_SH_SERVICE Service for product category search help

PERSONAL_MARKERS Personal marker service

PLANT_SH_SERVICE Search help for plant

PRICE_SCALES Item price scales

PRO_DET_IMAGES_SERVICE Product details image service

PRO_DET_SERVICE Service for product details

PRODUCT_MASTER Service for product master

PRODUCT_TYPE Service for product type

REC_ORDERS Data provider for recent orders

REGION_SH_SERVICE Service for region search

REVIEW Review service for rating and review

SEARCH_TERMS_SERV Search terms service

SHIP_ADDR_SH_SERVICE Service for shipping address

SHOPPING_CART Service for shopping cart

SRCH_FILTER Search filter model

SRMSHOPPING_CART SRM shopping cart PDO service

STLOCATION_SH_SERVICE Search help for storage location SUPPLIER_SH_SERVICE Service for supplier search help

USER_CATALOG_LIST User catalog provider

USERS_LIST User list under one user name

(25)

3.5 Track Shopping Carts

To enable the SAP Fiori Track Shopping Carts app, you must ensure that all prerequisites are in place and perform a number of configuration tasks.

Related Links

Prerequisites for My Shopping Cart and Track Shopping Carts [page 7]

3.6 My Benefits

To enable the SAP Fiori My Benefits application, you must must perform a number of configuration tasks.

1 ❑ Activate HR-BEN business function _{Software component dependencies are already maintained} in PPMS, so the SAINT tool takes care of the dependency validation.

Because the SAP Fiori My Benefits application relies on the configuration data available for Standard HR Benefits module, it is a mandatory prerequisite for the application to have HR Benefits (HR-BEN) available and configured. 2 ❑ Map communication types Map 0105 communication type for the employee PERNR to

the system user ID.

3 ❑ Install Gateway Server Components For more information see: Integration and SAP UI5 Components for SAP Fiori Applications [page 10] 4 ❑ Enable the SICF Services for the

Gateway

Service name: SRA007_BENEFITS_SRV 5 ❑ Enable the SICF Services for UI5 Service name: UI5_HCM_BEN_OVW 6 ❑ Ensure that the User Role is shipped

with the application.

Role: SAP Standard MSS 7 ❑ Deploy the Business Add-in

SRA007_BADI_BENEFITS

For instructions on how to activate BAdI implementations, see Steps To Activate BAdI Implementations and Deploy Business Add-In XSS_REM_INTERFACE.

8 ❑ Verify IMG Configuration In the back-end system, call transaction SIMGH and open the

(26)

3.7 My Timesheet

To enable the SAP Fiori My Timesheet application, you must ensure that all prerequisites are set up and perform a number of configuration tasks.

Note

Ensure that you check the Prerequisites Checklist [page 4] and the Setup Checklist [page 9] before configuring My Timesheet.

1 ❑ Ensure application-specific prerequisite software is installed.

Install and configure ERP Central Component (ECC) 6.0. For more information, see the SAP Help Portal. 2 ❑ Confirm the Gateway Server

components are installed.

In addition to installing the components in the installation and configuration instructions (see Integration and SAP UI5 Components for SAP Fiori Applications [page 10]), install and configure the ECC EA-HR600 component. If the add-on EA-HRGXX level is 604, reference SAP Note 1158538.

3 ❑ Start app-specific SICF services for the Gateway.

In addition to installing the components in the installation and configuration instructions (see Setup Checklist [page 9]) Ensure Gateway service

SRA002_TIMESHEET_SRV is activated. For more information see, Configure App-Specific Gateway Services [page 14].

4 ❑ Set the Business Suite Roles for the app.

My Timesheet uses the Data Entry Profile (DEP) to determine the usage and behavior for the client. The System Administrator maintains the DEP for each user in the CVR parameter.

To set the DEP, from the SAP GUI, go to System User Profile Own Data .

If no DEP is set, the default DEP, ESS, is used. If no default DEP is found, the client receives an error message.

5 ❑ Deploy the required Business Add-Ons (BAdIs) for the application.

Deploy the following BAdIs:

● BADI_SRA002_FIELDRANKINGS - Determines the order in which cost objects are given importance for display in the cost assignment.

● BADI_SRA002_PICKLIST_TXTFILTER - Extends the text search used by the Cost Assignment search. The default is to search for the text in field IDs and descriptions. This BAdI extends the search across other cost object attributes.

(27)

● BADI_SRA002_QUICKENTRY_BEGDA - Determines the beginning date for calculating missing entries for Auto Entry and the My Timesheet app tile. ● BADI_SRA002_QUICKENTRY_PROJ - Determines

the proposed Cost Assignment objects in Auto Entry.

● BADI_SRA002_WCSTATUSES - Determines the handling of CATS statuses highlighted in the monthly calendar. Allows for mapping other statuses to the three statuses used in My Timesheet.

For more information, see Steps to Activate BAdI Implementations.

3.8 My Leave Requests

To enable the SAP Fiori My Leave Requests application, you must perform a number of configuration tasks:

1 ❑ Ensure that the prerequisite SAP Notes have been applied.

In addition to the notes specified in the Prerequisites Checklist [page 4], the following notes must be applied:

● For component GBHCM002:

SAP Note 1625476: Release Information: SAP Leave Request 2.0.0

SAP Note 1621488: ESS LEA: Customizing attributes are not correctly fetched

SAP Note 1803429: HCM Leave Request App version 2

● For component GBHCM002 (SP08):

SAP Note 1852791: Checkman correction in class /GBHCM/CL_ELR_BEA_AUNIT SAP Note 1851674: Short dump when getting TimeAccount

SAP Note 1846479: Leave requests cannot be created or approved/rejected

(28)

4 Manager Apps

4.1 Configure Manager Apps

Manager apps are used to approve requests for leave and travel, purchase orders, requisitions, shopping carts, timesheets, and purchase contracts. The apps can also be used to view budget and spend information.

Table 5: Manager Apps

Information

My Spend My Spend provides accurate budget and spend information anywhere and anytime.

My Spend [page 35] Approve Requests Approve, reject, or forward various approval requests

from a desktop or mobile device. Define the approval tasks that are supported by the app. You can add your own approval tasks using the workflow infrastructure, or use the approval workflows provided with the app.

Approve Requests [page 29]

Approve Leave Requests Approve or reject leave requests from direct reports using a desktop or mobile device. Key information for the approval decision is available, including a team calendar that shows overlapping leave requests.

Approve Leave Requests [page 36]

Approve Travel Expenses Review and approve employees' travel expenses on the go or in the office. View details on each receipt, and receive alerts if expenses exceed the budget limits defined in the company travel policy.

Approve Travel Expenses [page 33]

Approve Shopping Carts _{View pending shopping cart requests and approve} entire carts or individual cart items. If necessary, forward approvals to a different employee for further processing.

Approve Shopping Carts [page 29]

Approve Purchase Orders View pending purchase orders and approve them. If necessary, forward approvals to a different employee for further processing.

Approve Purchase Orders [page 30]

Approve Requisitions View pending purchase requisitions and approve them. If necessary, forward approvals to a different employee for further processing.

Approve Requisitions [page 32]

Approve Travel Requests Approve or refuse travel requests on desktop as well as on mobile devices.

No further configuration required.

Approve Timesheets View all pending approvals for employees’ timesheets and approve timesheets.

Approve Timesheets [page 34]

Approve Purchase Contracts

View pending purchase contracts and approve them. If necessary, forward approvals to a

different employee for further processing.

See Approve Purchase Contracts [page 31]

(29)

4.2 Approve Requests

To enable SAP Fiori Approve Requests, you must perform a number of configuration tasks.

1 ❑ Ensure that all application-specific prerequisites are in place.

You must configure the approval workflow that defined the task type(s) to be used for Approve Requests.

❑ Ensure the prerequisite SAP Notes have been applied after the installation of the integration add-ons.

See the Prerequisites Checklist [page 4] for the SAP Notes that apply to all of the following:

Approve Requests Approve Leave Requests Approve Shopping Carts Approve Purchase Orders Approve Purchase Requisitions Approvel Purchase Contracts 2 ❑ Ensure that you have configured the

connection between SAP NetWeaver Gateway and your back-end system.

Specify Connection Settings to SAP NetWeaver Gateway [page 14]

3 ❑ Ensure that you have activated the Gateway services for the task.

Activate Gateway and UI5 Services in SICF [page 15] 4 ❑ Check that you have connected the

Gateway service for the task to your backend system.

See Activate and Maintain Services.

5 ❑ Define a scenario for your custom approval

workflow. 1. Define a scenario ID._{2. Assign user roles for which you want to enable the} workflow.

3. Assign the task ID of the approval workflow you have already defined in SAP Business Workflow. For more information, see Define an Approval Scenario [page 48].

6 ❑ Assign task decisions to your approval workflow.

See Configure Task Decisions [page 53]. 7 ❑ Configure the launch settings for your

custom approval workflow.

For more information, see Configure Launch Settings for Custom Workflows [page 51].

4.3 Approve Shopping Carts

(30)

You must configure the approval workflow that defined the task type(s) to be used for Approve Shopping Carts.

❑ Ensure the prerequisite SAP Notes have been applied after the installation of the integration add-ons.

Approve Requests Approve Leave Requests Approve Shopping Carts Approve Purchase Orders Approve Purchase Requisitions

The following SAP Notes apply to Approve Shopping Carts:

● GBSRM001 component: SAP Note 1625382: Release Information: SAP Cart Approval 2.0.0 ● GBSRM001 SP08:

SAP Note 1792098: Collective Note: HTML5 WF Inbox - GW Services for SRM

SAP Note 1842502: CAA: Information for limit item is not retrieved

2 ❑ Ensure that you have configured the connection between SAP NetWeaver Gateway and your back-end system.

5 ❑ Define a scenario for your approval

3. Assign the task ID of the shopping cart approval workflow you have already defined in SAP Business Workflow.

For more information, see Define an Approval Scenario [page 48].

4.4 Approve Purchase Orders

(31)

You must configure the approval workflow that defined the task type(s) to be used for Approve Purchase Orders.

Note

If you are using the release strategy in SAP

Materials Management Purchasing (MM-PUR), you need to set up a connection between the release strategy and SAP Business Workflow.

2 ❑ Ensure the prerequisite SAP Notes have been applied after the installation of the integration add-ons.

Apply the following SAP Note for Approve Purchase Orders (Component GBAPP002): SAP Note 1309042 3 ❑ Ensure that you have configured the

3. Assign the task ID of the purchase approval workflow you have already defined in SAP Business Workflow.

4.5 Approve Purchase Contracts

(32)

You must configure the approval workflow that defined the task type(s) to be used for Approve Purchase Contracts.

Note

Approve Requests Approve Leave Requests Approve Shopping Carts Approve Purchase Orders Approve Purchase Requisitions Approve Purchase Contracts 3 ❑ Ensure that you have configured the

3. Assign the task ID of the purchase approval workflow you have already defined in SAP Business Workflow.

4.6 Approve Requisitions

(33)

You must configure the approval workflow that defined the task type(s) to be used for Approve Requisitions.

Note

Approve Requests Approve Leave Requests Approve Shopping Carts Approve Purchase Orders Approve Requisitions 3 ❑ Ensure that you have configured the

3. Assign the task ID of the purchase requisition approval workflow you have already defined in SAP Business Workflow.

4.7 Approve Travel Expenses

To enable the SAP Fiori Approve Travel Expenses application, you must must ensure all prerequisites are in place and perform a number of configuration tasks.

(34)

1 ❑ Ensure configuration table SRA008_T_CONFIG is maintained.

Configuration table SRA008_T_CONFIG must be maintained for a workflow decision key in case of a custom workflow for travel expense approval.

A node for this task is provided in the Implementation Guide (IMG).

2 ❑ Ensure configuration table

SRA008_T_TASKTYP is maintained.

Configuration table SRA008_T_TASKTYP must be maintained for the task type used for approving the travel expense.

A node for this task is provided in the IMG. 3 ❑ Ensure that the Travel Management

module is installed and configured.

The app relies on configuration data available for the Travel Management module, so it is mandatory to have the module installed and configured.

Note

The Approve Travel Expenses app works only on a system whose workflows do not use the Check Trip Facts task.

4.8 Approve Timesheets

To enable the SAP Fiori Approve Timesheets application, you must must perform a number of configuration tasks.

1 ❑ Activate EA-HR business function Software component dependencies are already maintained in PPMS, so the SAINT tool handles the dependency validation.

2 ❑ Install Gateway Server Components

Install Gateway Server Components - Gateway: SRA010 and UI: UISRA010 using the add-on installation tool (transaction SAINT). For more information, see Install Add-On

Components [page 10]. 3 ❑ Enable the

SRA010_TIMESHEET_APPROVAL SICF Services for the Gateway

See Activate Gateway and UI5 Services in SICF [page 15]

4 ❑ Enable the UI5_HCM_TSA SICF Services for UI5

See Activate Gateway and UI5 Services in SICF [page 15] 5 ❑ Ensure that the SAP Standard MSS

Role is included with the application.

(35)

6 ❑ Implement BAdI

SRA010_BADI_TIMESHEET_APV (Optional)

The BAdI has 4 methods: GET_SUMMARY, TIME_PENDING_GET_ENTITYSET, REJ_REASON_GET_ENTITYSET, APPROVE_REJECT_ACTION.

You implement this BAdI if you want any custom implementation logic for any of the standard process of obtaining the following: summary of timesheet entries, pending timesheet entries, approved/rejected timesheet entries, retrieving possible reasons for rejection.

4.9 My Spend

To enable the SAP Fiori My Spend application, you must perform a number of configuration tasks.

1 ❑ Configure users. See Set Up Personalization [page 35].

4.9.1 Set Up Personalization

SAP Fiori My Spend uses the personalization framework included with the EA-FIN business function. The Administrator defines Personalization for users. To configure for individual users, perform the following steps:

1. From Integration with other mySAP.com components, go to transaction SPRO Business Packages/ Functional Packages Manager Self-Service (mySAP ERP) Personalization Personalization DataCollective Processing .

2. The following personalization dialog boxes are relevant, and values must be maintained for the following monitors:

○ Cost Center: DIA_CCMONITOR ○ Internal Order: DIA_IOMONITOR

Note

You do not need to create groups if a user has only one cost center or one project. For multiple single and/or interval departments and projects, you still need to create corresponding groups and assign in MSS. There are additional authorization checks during the data read. SRS only retrieves the data for the authorized objects. For example, the department manager for the Cars business unit should only see his own cost centers. You can link his user ID to the relevant cost center groups.

(36)

Note

Note that only one group from Personalization configuration is supported. If multiple groups are

maintained for a particular user, the first group maintained for the user is used for data display on the iPad. This is valid for all three master data elements (Cost Center, Cost Element, and Internal Order).

4.10 Approve Leave Requests

To enable SAP Fiori Approve Leave Requests, you must perform a number of configuration tasks.

1 ❑ Ensure that the application-specific

prerequisites are in place. ● You must configure the approval workflow that _{defined the task type(s) to be used for Approve} Leave Requests.

● Each application user must be mapped to a valid personnel number with the necessary

authorizations. ❑ Ensure the prerequisite SAP Notes have

been applied after the installation of the integration add-ons.

The following SAP Notes must be applied for Approve Leave Requests:

● For the component GBHCM003: SAP Note 1621475:

SAP Note 1525104 SAP Note 1555377 SAP Note 1487720 SAP Note 1538601

● For the component GBHCM003 SP07: SAP Note 1854502

SAP Note 1793784 SAP Note 1846661 SAP Note 1849088 SAP Note 1883884

(37)

2 ❑ Ensure that you have configured the connection between SAP NetWeaver Gateway and your back-end system.

workflow. 1. Define a scenario ID._{2. Assign user roles for which you want to enable} the workflow.

3. Assign the task ID of the leave request approval workflow you have already defined in SAP Business Workflow.

(38)

5 Sales Rep Apps

5.1 Configure Sales Rep Apps

Sales representatives use the apps to check price and availability; create, track, and change sales orders; track shipments, and view information about customer invoices.

Table 6: Sales Rep Apps

Information

Check Price and Availability

Check the price and availability of any given material for customers, based on quantity and requested delivery date.

Check Price and Availability [page 44] Create Sales Orders Create sales orders on desktop and mobile devices.

Sales representatives can reorder using a customer's previously placed orders and select individual products to add to a new order.

Create Sales Orders [page 38]

Track Sales Orders Manage the sales orders for customers by checking the status of order items and delivery schedules on both desktop and mobile devices.

Track Sales Orders [page 41]

Change Sales Orders Change sales orders on desktop and mobile devices. You can also change the address of a shipment to expedite delivery of items to customers.

Change Sales Orders [page 43]

Track Shipments Provide precise shipment information to customers from a desktop or mobile device.

Track Shipments [page 44]

Customer Invoices View customers unpaid, past due and disputed invoices or memos on a desktop of mobile device.

Customer Invoices [page 43]

5.2 Create Sales Orders

To enable the SAP Fiori Create Sales Orders application , you must perform a number of configuration tasks.

1 ❑ Ensure that an employee master record is created.

See Employee Master Record Creation [page 40] 2 ❑ Configure user information for

the application.

To configure user information for Create Sales Orders, call transaction SIMGH, and open the Create Sales Orders node.

3 ❑ Define Configuration Parameters In the Define Configuration Parameters menu option, the following configuration parameters in Create

(39)

Sales Orders application are maintained: See Configuration Parameters for Sales Orders Applications [page 40].

To change the value of any of the parameters, execute the activity and edit the parameter value. 4 ❑ Deploy the required Business

Add-Ins (BAdI)

● Customer Association to Employee - This BAdI is used in the Create Sales Orders add-on. You can find the BADI_SRA017_USER_TO_CUSTOMER in enhancement spot

ES_SRA017_SALESORDER_CREATE. You can use it to implement a method for associating

employees to customers.

SRA017_SO_USR_TO_CUSTOMER is activated in the standard system. In this implementation the customers are associated with the employee by reading the employee responsible in the partner function of the customer master.

● Retrieve Product Image- This BAdI is used in the Create Sales Orders add-on. You can find the BADI_SRA017_PROD_IMG_RETRIEVER in enhancement spot

ES_SRA017_SALESORDER_CREATE. There is no default implementation of this BAdI.

Implementation needs to support following parameters:

○ IV_MATERIAL – Material ID. This parameter is mandatory.

○ IV_IMAGE_REQUIRED – This flag is used to indicate whether the image should be returned or only the metadata of the image. This is optional parameter.

○ EV_MIME_TYPE – This should contain the type of image. This is optional information. ○ EV_IMAGE_XSTRING – This field contains the

image in XSTRING format .

○ EV_IMAGE_AVAILABLE – This flag should return whether image is available or not. For more information, see Implement a Business Add-On [page 48].

(40)

5.2.1 Employee Master Record Creation

To use the application, you must have implemented either Human Capital Management (HCM) or Sales and Distribution (SD) so that an employee master record has been created.

An employee master record is created in either of the following cases:

● You have implemented HCM and maintained your employees in the HCM personnel records. The employee personnel record in HCM has the infotype Communication, with a subtype of System User Name (SY-UNAME) (Infotype 0105, Subtype 0001)

● If you have not implemented HCM, you must implement the SD configuration around Use Sales Employees with HR (Tcode: PULT). This IMG setting copies the appropriate HMC tables from the 000 Client and allows the setup of the Employee Record with the Infotype Communication and a Subtype of System User Name (SY-UNAME) (Infotype 0105, Subtype 0001). See SAP Note 854390 for more information.

Either of the above cases produces an employee master record, which associates the USERID of the employee with the personnel number assigned as a partner function sales employee in the customer master.

5.2.2 Configuration Parameters for Sales Orders

Applications

The accompanying table lists the configuration parameters for the Sales Orders apps.

Parameter Description

Document Type (DOCTYPE) By default Track Sales Orders is configured to use the standard order document type (technical key TA resp. OR). Changing the document type to something other than a sales order may significantly impact the functionality of the application

Order Period (ORDPERIOD) The order period defines how many days into the past sales orders are retrieved. The suggested value is 30 days.

Search Period (SEAPERIOD) The search period defines how many days into the past search is looking for sales orders matching the search criteria. The suggested value is 90 days .

Product Search Limit (PRODUCT / SEARCH_LIMIT)

The product search limit defines how many products in the material master are returned that match the search criteria. The suggested value is 100 products.

Pricing Condition (LIST_PRICE / PRICING_CONDITION)

The value of the list price parameter determines the pricing conditions during the price and availability check and the order creation. The suggested value is PR00.

Ship To Party (SHIP_TO / PARTNER_ROLE) The value of the ship-to party parameter defines which partner role in the customer master is used for the ship-to party. The suggested value is WE.

Sold To Party (SOLD_TO / PARTNER_ROLE) The value of the sold-to party parameter defines which partner role in the customer master is used for the sold-to party. The suggested value is AG.

(41)

Parameter Description

Forwarding Agent (FORWARDING_AGENT / PARTNER_ROLE)

The value of the forwarding agent parameter defines which partner role in the custonemr master is used for the forwarding agent. The

suggested value is SP.. Notes To Receiver (NOTES_TO_RECEIVER /

SO_TEXT_ID)

The value of the notes to receiver parameter contains the text ID for the location of the text object. The suggested value is 001.

Shipping Instructions

(SHIPPING_INSTRUCTIONS / SO_TEXT_ID)

The value of the shipping instructions parameter contains the text ID for the location of the text object. The suggested value is 0012.

5.3 Track Sales Orders

To enable the SAP Fiori Track Sales Orders application, you must perform a number of configuration tasks.

1 ❑ Ensure that an employee master record is created.

See Employee Master Record Creation [page 40] 2 ❑ Configure user information for the

application.

To configure user information for Track Sales Orders, call transaction SIMGH and open the Track Sales Orders node.

3 ❑ Define Configuration Parameters In the Define Configuration Parameters menu option, you can assign values for the following configuration parameters in Track Sales Orders:

● Document Type (DOCTYPE) ● Order Period (ORDPERIOD) ● Search Period (SEAPERIOD)

For more information on the parameters, see Configuration Parameters for Sales Orders Applications [page 40].

To change the value of any of the parameters, execute the activity and edit the parameter value. 4 ❑ Deploy the required Business

Add-Ins (BAdI)

● Customer Association to Employee

(BADI_SO_USR_TO_CUSTOMER) - This BAdI is used in the Track Sales Orders add-on. BADI_SO_USR_TO_CUSTOMER is located in enhancement spot ES_SDRA_SO. Use it to implement a method for associating employee to customers. A BAdI implementation,

SRA018_SO_USR_TO_CUSTOMER, is activated in the standard system. In this implementation the

(42)

customers are associated with the employee by reading the employee responsible in the partner function of the customer master.

● Get Contacts Info (BADI_SO_CONTACTS) - This BAdI is used in the Track Sales Orders add-on. BADI_SO_CONTACTS is located in the

enhancement spot ES_SRA_SO. Use it to implement a method for contact information selections (for example, title, name, phone number, and email address) displayed in the contacts tab of the Track Sales Orders application. The application can display two contacts for each customer. These can be contacts such as a dispute coordinator maintained in the partner functions of the customer master.

For more information, see Implement a Business Add-On [page 48].

5.3.1 Status Aggregation

There are two status fields: one for scheduled deliveries and one for the order item.

5.3.1.1 Status of Scheduled Delivery of an Order Item

A delivery schedule can have a status of Open, Shipped, or In Process.

There is no direct link between a scheduled delivery and a delivery document and its goods issue: they are only linked to the order item. Delivery documents and goods issue quantities are dynamically allocated to scheduled delivery, based on dates.

● A delivery schedule has the status Open if there is no delivery document assigned/allocated to it.

● A delivery schedule has the status Shipped if the net goods issue quantity (goods issues minus goods issues cancellations) is equal to its confirmed quantities.

● In all other situations the delivery schedule has the status In Process.

5.3.1.2 Status of an Order Item

The status of an order item is determined by looking at the status of its delivery schedules

Fiori 10 Installation Guide

SAP Fiori

Document Version: 1.0 - 2013-07-25

Table of Contents

1

Prerequisites

1.1

Prerequisites Checklist

1.2

SAP Notes for SAP NetWeaver AS ABAP

1.3

SAP Notes for SAP ERP

Note

1.4 SAP Notes for SAP NetWeaver Gateway

1.5

SAP Notes for SAP UI5 for NetWeaver Add-On

1.6 Prerequisites for My Shopping Cart and Track Shopping

Carts

2

Install

2.1

Setup Checklist

Note

2.2 Install Add-On Components

2.2.1

Integration and SAP UI5 Components for SAP Fiori

Applications

Note

2.3 Configure SAP Business Suite Components

2.3.1

Define Users and Authorizations

2.3.2 Configure the Back-End Event Publisher

Note

2.3.3 Specify Connection Settings to SAP NetWeaver

Gateway

2.4 Configure SAP NetWeaver Gateway Components

2.4.1 Configure App-Specific Gateway Services

Note

2.4.2 Activate Gateway and UI5 Services in SICF

2.5 Components and Services

2.5.1

Gateway Services for Applications

2.5.2 SICF Services for UI Applications

2.6 Access Apps

2.6.1

Access SAP Fiori Apps

2.6.1.1

SAP Fiori App URLs

Note

2.6.1.2

Add Apps to the User's Home Page

Note

3

Employee Apps

3.1

Configure Employee Apps

3.2 My Paystubs

Note

Note

Note

3.3 My Travel Requests

3.4 My Shopping Cart

3.4.1 SRM Services Used by My Shopping Cart and Track

Shopping Carts

3.5 Track Shopping Carts

3.6 My Benefits

3.7 My Timesheet

Note

3.8 My Leave Requests

4 Manager Apps

4.1 Configure Manager Apps

4.2 Approve Requests

4.3 Approve Shopping Carts

4.4 Approve Purchase Orders

Note

4.5 Approve Purchase Contracts

Note

4.6 Approve Requisitions

Note

4.7 Approve Travel Expenses
