ELECTRONIC

EXPERIMENTER'S

HANDBOOK

Publisher PHILLIP T. HEFFERNAN

Editor OLIVER P. FERRELL

Feature Editor W. STEVE BACON, W2CJR

Technical Editor L. JEROME STANTON, W2WHM Art Editor JAMES A. ROTH

Associate Editor MARGARET MAGNA

Technical Illustrator ANDRE DUZANT

Editorial Assistant NINA CHIRKO

Editorial Assistant PATTI MORGAN Editorial Consultant OLIVER READ, W4TWV Advertising Sales Manager LAWRENCE SPORN

Advertising Manager WILLIAM G. McROY, 2W4144

Advertising Service Manager ARDYS C. MORAN ZIFF-DAVIS PUBLISHING COMPANY

Editorial and Executive Offices (212 ORegon 9-7200)

One Park Avenue, New York, New York 10016

William B. Ziff, Chairman of the Board (1946-1953)

William Ziff, President

W. Bradford Briggs, Executive Vice President Hershel B. Sarbin, Vice President and General Manager

M. T. Birmingham, Jr., Vice President and Treasurer Robert P. Breeding, Circulation Director

Stanley R. Greenfield, Vice President

Phillip T. Heffernan, Vice President Midwestern and Circulation Office (312 WAbash 2-4911)

434 South Wabash Avenue, Chicago, Illinois 60605 Midwestern Advertising Manager JAMES WEAKLEY

Western Office (213 CRestview 4-0265) 9025 Wilshire Boulevard, Beverly Hills, California 90211

Western Advertising Manager, BUD DEAN

Cover photo by Bruti' Pendleton

'.

4ELECTRONIC

EXPERIMENTER'S

HANIPi7.(7)OF

HIGH FIDELIIl

UST for the fun of it, the Editors of POPULAR ELECTRONICS figured out how many hours it would take to build every project in this HANDBOOK. The average figure turned out to be 250 hours, but all agree that this is strictly guesswork. Obviously, there is no time limit on the enjoyment of building one, two, three, five, or ten of the projects described on the next 160 pages.

As in our previous seven annual editions, every project and circuit has been care- fully double-checked. Parts listings have been reverified so that all components are

known to be available at this writing. The author of each article was asked to bring

his project up to date where desirable. Known difficulties in building have been elim- inated and, where required, substitutions carefully outlined. In short, we've put to- gether a book we know you'll value and enjoy throughout 1964.

THE EDITORS
