ERES V
ERES V
ERES V
ERES V
ERES VIII
III
III
III
III
C
ONFERENCEC
HAIRMENC.A. Brebbia
Wessex Institute of Technology, UK
M. Maugeri
University of Catania, Italy
I
NTERNATIONALS
CIENTIFICA
DVISORYC
OMMITTEEOrganised by
Wessex Institute of Technology, UK
Sponsored by
WIT Transactions on The Built Environment
Y. Ariga G. Dundulis K. Fuchida P. Komodromos A. Martelli M. Maugeri M. Phocas E. Sapountzakis O. Sircovich Saar
Editorial Board
Transactions Editor
Carlos Brebbia
Wessex Institute of Technology Ashurst Lodge, Ashurst Southampton SO40 7AA, UK
Email: [email protected]
B Abersek University of Maribor, Slovenia
Y N Abousleiman University of Oklahoma, USA
P L Aguilar University of Extremadura, Spain
K S Al Jabri Sultan Qaboos University, Oman
E Alarcon Universidad Politecnica de Madrid, Spain
A Aldama IMTA, Mexico
C Alessandri Universita di Ferrara, Italy
D Almorza Gomar University of Cadiz, Spain
B Alzahabi Kettering University, USA
J A C Ambrosio IDMEC, Portugal
A M Amer Cairo University, Egypt
S A Anagnostopoulos University of Patras, Greece
M Andretta Montecatini, Italy
E Angelino A.R.P.A. Lombardia, Italy
H Antes Technische Universitat Braunschweig, Germany
M A Atherton South Bank University, UK
A G Atkins University of Reading, UK
D Aubry Ecole Centrale de Paris, France
H Azegami Toyohashi University of Technology, Japan
A F M Azevedo University of Porto, Portugal
J Baish Bucknell University, USA
J M Baldasano Universitat Politecnica de Catalunya, Spain
J G Bartzis Institute of Nuclear Technology, Greece
A Bejan Duke University, USA
M P Bekakos Democritus University of Thrace, Greece
G Belingardi Politecnico di Torino, Italy
R Belmans Katholieke Universiteit Leuven, Belgium
C D Bertram The University of New South Wales, Australia
D E Beskos University of Patras, Greece
S K Bhattacharyya Indian Institute of Technology, India
E Blums Latvian Academy of Sciences, Latvia
J Boarder Cartref Consulting Systems, UK
B Bobee Institut National de la Recherche Scientifique, Canada
H Boileau ESIGEC, France
J J Bommer Imperial College London, UK
M Bonnet Ecole Polytechnique, France
C A Borrego University of Aveiro, Portugal
A R Bretones University of Granada, Spain
J A Bryant University of Exeter, UK
F-G Buchholz Universitat Gesanthochschule Paderborn, Germany
M B Bush The University of Western Australia, Australia
F Butera Politecnico di Milano, Italy
J Byrne University of Portsmouth, UK
W Cantwell Liverpool University, UK
D J Cartwright Bucknell University, USA
P G Carydis National Technical University of Athens, Greece
J J Casares Long Universidad de Santiago de Compostela, Spain
M A Celia Princeton University, USA
A Chakrabarti Indian Institute of Science, India
H Choi Kangnung National University, Korea
A Cieslak Technical University of Lodz, Poland
S Clement Transport System Centre, Australia
M W Collins Brunel University, UK
J J Connor Massachusetts Institute of Technology, USA
M C Constantinou State University of New York at Buffalo, USA
D E Cormack University of Toronto, Canada
M Costantino Royal Bank of Scotland, UK
D F Cutler Royal Botanic Gardens, UK
W Czyczula Krakow University of Technology, Poland
M da Conceicao Cunha University of Coimbra, Portugal
L Dávid Károly Róbert College, Hungary A Davies University of Hertfordshire, UK
M Davis Temple University, USA
A B de Almeida Instituto Superior Tecnico, Portugal
E R de Arantes e Oliveira Instituto Superior Tecnico, Portugal
L De Biase University of Milan, Italy
R de Borst Delft University of Technology, Netherlands
G De Mey University of Ghent, Belgium
A De Montis Universita di Cagliari, Italy
A De Naeyer Universiteit Ghent, Belgium
W P De Wilde Vrije Universiteit Brussel, Belgium
L Debnath University of Texas-Pan American, USA
N J Dedios Mimbela Universidad de Cordoba, Spain
G Degrande Katholieke Universiteit Leuven, Belgium
S del Giudice University of Udine, Italy
G Deplano Universita di Cagliari, Italy
I Doltsinis University of Stuttgart, Germany
M Domaszewski Universite de Technologie de Belfort-Montbeliard, France
J Dominguez University of Seville, Spain
K Dorow Pacific Northwest National Laboratory, USA
W Dover University College London, UK
C Dowlen South Bank University, UK
R Duffell University of Hertfordshire, UK
A Ebel University of Cologne, Germany
E E Edoutos Democritus University of Thrace, Greece
G K Egan Monash University, Australia
K M Elawadly Alexandria University, Egypt
K-H Elmer Universitat Hannover, Germany
D Elms University of Canterbury, New Zealand
M E M El-Sayed Kettering University, USA
D M Elsom Oxford Brookes University, UK
F Erdogan Lehigh University, USA
F P Escrig University of Seville, Spain
D J Evans Nottingham Trent University, UK
J W Everett Rowan University, USA
M Faghri University of Rhode Island, USA
R A Falconer Cardiff University, UK
M N Fardis University of Patras, Greece
P Fedelinski Silesian Technical University, Poland
H J S Fernando Arizona State University, USA
S Finger Carnegie Mellon University, USA
J I Frankel University of Tennessee, USA
D M Fraser University of Cape Town, South Africa
M J Fritzler University of Calgary, Canada
U Gabbert Otto-von-Guericke Universitat Magdeburg, Germany
G Gambolati Universita di Padova, Italy
C J Gantes National Technical University of Athens, Greece
L Gaul Universitat Stuttgart, Germany
A Genco University of Palermo, Italy
N Georgantzis Universitat Jaume I, Spain
P Giudici Universita di Pavia, Italy
F Gomez Universidad Politecnica de Valencia, Spain
R Gomez Martin University of Granada, Spain
D Goulias University of Maryland, USA
K G Goulias Pennsylvania State University, USA
F Grandori Politecnico di Milano, Italy
W E Grant Texas A & M University, USA
D Gross Technische Hochschule Darmstadt, Germany
R Grundmann Technische Universitat Dresden, Germany
A Gualtierotti IDHEAP, Switzerland
R C Gupta National University of Singapore, Singapore
J M Hale University of Newcastle, UK
K Hameyer Katholieke Universiteit Leuven, Belgium
C Hanke Danish Technical University, Denmark
K Hayami University of Toyko, Japan
Y Hayashi Nagoya University, Japan
L Haydock Newage International Limited, UK
A H Hendrickx Free University of Brussels, Belgium
C Herman John Hopkins University, USA
I Hideaki Nagoya University, Japan
D A Hills University of Oxford, UK
W F Huebner Southwest Research Institute, USA
J A C Humphrey Bucknell University, USA
M Y Hussaini Florida State University, USA
W Hutchinson Edith Cowan University, Australia
T H Hyde University of Nottingham, UK
M Iguchi Science University of Tokyo, Japan
D B Ingham University of Leeds, UK
L Int Panis VITO Expertisecentrum IMS, Belgium
N Ishikawa National Defence Academy, Japan
J Jaafar UiTm, Malaysia
W Jager Technical University of Dresden, Germany
Y Jaluria Rutgers University, USA
C M Jefferson University of the West of England, UK
P R Johnston Griffith University, Australia
D R H Jones University of Cambridge, UK
N Jones University of Liverpool, UK
D Kaliampakos National Technical University of Athens, Greece N Kamiya Nagoya University, Japan
D L Karabalis University of Patras, Greece
M Karlsson Linkoping University, Sweden
T Katayama Doshisha University, Japan
J T Katsikadelis National Technical University of Athens, Greece E Kausel Massachusetts Institute of
Technology, USA
H Kawashima The University of Tokyo, Japan
B A Kazimee Washington State University, USA
S Kim University of Wisconsin-Madison, USA
D Kirkland Nicholas Grimshaw & Partners Ltd, UK
E Kita Nagoya University, Japan
A S Kobayashi University of Washington, USA
T Kobayashi University of Tokyo, Japan
D Koga Saga University, Japan
S Kotake University of Tokyo, Japan
A N Kounadis National Technical University of Athens, Greece
W B Kratzig Ruhr Universitat Bochum, Germany
T Krauthammer Penn State University, USA
C-H Lai University of Greenwich, UK
M Langseth Norwegian University of Science and Technology, Norway
B S Larsen Technical University of Denmark, Denmark
F Lattarulo Politecnico di Bari, Italy
A Lebedev Moscow State University, Russia
L J Leon University of Montreal, Canada
D Lewis Mississippi State University, USA
S lghobashi University of California Irvine, USA
K-C Lin University of New Brunswick, Canada
A A Liolios Democritus University of Thrace, Greece
S Lomov Katholieke Universiteit Leuven, Belgium
J W S Longhurst University of the West of England, UK
G Loo The University of Auckland, New Zealand
J Lourenco Universidade do Minho, Portugal
J E Luco University of California at San Diego, USA
H Lui State Seismological Bureau Harbin, China
Location Analysis, Sweden T Lyons Murdoch University, Australia
Y-W Mai University of Sydney, Australia
M Majowiecki University of Bologna, Italy
D Malerba Università degli Studi di Bari, Italy
G Manara University of Pisa, Italy
B N Mandal Indian Statistical Institute, India
Ü Mander University of Tartu, Estonia
H A Mang Technische Universitat Wien, Austria
G D Manolis Aristotle University of Thessaloniki, Greece
W J Mansur COPPE/UFRJ, Brazil
N Marchettini University of Siena, Italy
J D M Marsh Griffith University, Australia
J F Martin-Duque Universidad Complutense, Spain
T Matsui Nagoya University, Japan
G Mattrisch DaimlerChrysler AG, Germany
F M Mazzolani University of Naples “Federico II”, Italy
K McManis University of New Orleans, USA
A C Mendes Universidade de Beira Interior, Portugal
R A Meric Research Institute for Basic Sciences, Turkey
J Mikielewicz Polish Academy of Sciences, Poland
N Milic-Frayling Microsoft Research Ltd, UK
R A W Mines University of Liverpool, UK
C A Mitchell University of Sydney, Australia
K Miura Kajima Corporation, Japan
A Miyamoto Yamaguchi University, Japan
T Miyoshi Kobe University, Japan
G Molinari University of Genoa, Italy
T B Moodie University of Alberta, Canada
D B Murray Trinity College Dublin, Ireland
G Nakhaeizadeh DaimlerChrysler AG, Germany
M B Neace Mercer University, USA
D Necsulescu University of Ottawa, Canada
F Neumann University of Vienna, Austria
S-I Nishida Saga University, Japan
H Nisitani Kyushu Sangyo University, Japan
B Notaros University of Massachusetts, USA
R O O’Neill Oak Ridge National Laboratory, USA
M Ohkusu Kyushu University, Japan
G Oliveto Universitá di Catania, Italy
R Olsen Camp Dresser & McKee Inc., USA
E Oñate Universitat Politecnica de Catalunya, Spain
K Onishi Ibaraki University, Japan
P H Oosthuizen Queens University, Canada
E L Ortiz Imperial College London, UK
E Outa Waseda University, Japan
A S Papageorgiou Rensselaer Polytechnic Institute, USA
J Park Seoul National University, Korea
G Passerini Universita delle Marche, Italy
B C Patten University of Georgia, USA
G Pelosi University of Florence, Italy
G G Penelis Aristotle University of Thessaloniki, Greece
W Perrie Bedford Institute of Oceanography, Canada
R Pietrabissa Politecnico di Milano, Italy
H Pina Instituto Superior Tecnico, Portugal
M F Platzer Naval Postgraduate School, USA
D Poljak University of Split, Croatia
V Popov Wessex Institute of Technology, UK
H Power University of Nottingham, UK
D Prandle Proudman Oceanographic Laboratory, UK
M Predeleanu University Paris VI, France
M R I Purvis University of Portsmouth, UK
I S Putra Institute of Technology Bandung, Indonesia
Y A Pykh Russian Academy of Sciences, Russia
F Rachidi EMC Group, Switzerland
M Rahman Dalhousie University, Canada
K R Rajagopal Texas A & M University, USA
T Rang Tallinn Technical University, Estonia
J Rao Case Western Reserve University, USA
A M Reinhorn State University of New York at Buffalo, USA
A D Rey McGill University, Canada
D N Riahi University of Illinois at Urbana-Champaign, USA
WIT
eLibrary
Home of the Transactions of the Wessex Institute.
Papers presented at ERES VIII are archived in the WIT elibrary in volume 120 of WIT Transactions on The Built Environment (ISSN 1743-3509). The WIT electronic-library provides the international scientific community with immediate and permanent access to individual papers presented at WIT conferences.
Visit the WIT eLibrary at www.witpress.com. WIT Press publishes leading books in Science and Technology.
Visit our website for the current list of titles. www.witpress.com
Engineering Structures
VIII
K Richter Graz University of Technology, Austria
S Rinaldi Politecnico di Milano, Italy
F Robuste Universitat Politecnica de Catalunya, Spain
J Roddick Flinders University, Australia
A C Rodrigues Universidade Nova de Lisboa, Portugal
F Rodrigues Poly Institute of Porto, Portugal
C W Roeder University of Washington, USA J M Roesset Texas A & M University, USA
W Roetzel Universitaet der Bundeswehr Hamburg, Germany
V Roje University of Split, Croatia
R Rosset Laboratoire d’Aerologie, France
J L Rubio Centro de Investigaciones sobre Desertificacion, Spain
T J Rudolphi Iowa State University, USA
S Russenchuck Magnet Group, Switzerland
H Ryssel Fraunhofer Institut Integrierte Schaltungen, Germany
S G Saad American University in Cairo, Egypt
M Saiidi University of Nevada-Reno, USA
R San Jose Technical University of Madrid, Spain
F J Sanchez-Sesma Instituto Mexicano del Petroleo, Mexico
B Sarler Nova Gorica Polytechnic, Slovenia
S A Savidis Technische Universitat Berlin, Germany
A Savini Universita de Pavia, Italy
G Schmid Ruhr-Universitat Bochum, Germany
R Schmidt RWTH Aachen, Germany
B Scholtes Universitaet of Kassel, Germany
W Schreiber University of Alabama, USA
A P S Selvadurai McGill University, Canada
J J Sendra University of Seville, Spain
J J Sharp Memorial University of Newfoundland, Canada
Q Shen Massachusetts Institute of Technology, USA
X Shixiong Fudan University, China
G C Sih Lehigh University, USA
L C Simoes University of Coimbra, Portugal
A C Singhal Arizona State University, USA
P Skerget University of Maribor, Slovenia
V Sladek Slovak Academy of Sciences, Slovakia
A C M Sousa University of New Brunswick, Canada
H Sozer Illinois Institute of Technology, USA
D B Spalding CHAM, UK
P D Spanos Rice University, USA
T Speck Albert-Ludwigs-Universitaet Freiburg, Germany
C C Spyrakos National Technical University of Athens, Greece
I V Stangeeva St Petersburg University, Russia
J Stasiek Technical University of Gdansk, Poland
G E Swaters University of Alberta, Canada
S Syngellakis University of Southampton, UK
J Szmyd University of Mining and Metallurgy, Poland
S T Tadano Hokkaido University, Japan
H Takemiya Okayama University, Japan
I Takewaki Kyoto University, Japan
C-L Tan Carleton University, Canada
E Taniguchi Kyoto University, Japan
S Tanimura Aichi University of Technology, Japan
J L Tassoulas University of Texas at Austin, USA
M A P Taylor University of South Australia, Australia
A Terranova Politecnico di Milano, Italy
A G Tijhuis Technische Universiteit Eindhoven, Netherlands
T Tirabassi Institute FISBAT-CNR, Italy
S Tkachenko Otto-von-Guericke-University, Germany
N Tosaka Nihon University, Japan
T Tran-Cong University of Southern Queensland, Australia
R Tremblay Ecole Polytechnique, Canada
I Tsukrov University of New Hampshire, USA
R Turra CINECA Interuniversity Computing Centre, Italy
S G Tushinski Moscow State University, Russia
J-L Uso Universitat Jaume I, Spain
E Van den Bulck Katholieke Universiteit Leuven, Belgium
Netherlands
R van Duin Delft University of Technology, Netherlands
P Vas University of Aberdeen, UK
R Verhoeven Ghent University, Belgium
A Viguri Universitat Jaume I, Spain
Y Villacampa Esteve Universidad de Alicante, Spain
F F V Vincent University of Bath, UK
S Walker Imperial College, UK
G Walters University of Exeter, UK
B Weiss University of Vienna, Austria
H Westphal University of Magdeburg, Germany
J R Whiteman Brunel University, UK
Z-Y Yan Peking University, China
S Yanniotis Agricultural University of Athens, Greece
K Yoshizato Hiroshima University, Japan
T X Yu Hong Kong University of Science & Technology, Hong Kong
M Zador Technical University of Budapest, Hungary
K Zakrzewski Politechnika Lodzka, Poland
M Zamir University of Western Ontario, Canada
R Zarnic University of Ljubljana, Slovenia
G Zharkova Institute of Theoretical and Applied Mechanics, Russia
N Zhong Maebashi Institute of Technology, Japan
Editors
C.A. Brebbia
Wessex Institute of Technology, UK
M. Maugeri
University of Catania, Italy
Earthquak
Earthquak
Earthquake Re
e Re
e Resistant
sistant
Engineering Struct
Engineering Struct
Engineering Struct
Engineering Struct
Engineering Structur
ur
ur
ureeeeesssss
ur
V
V
V
V
WIT Press
Ashurst Lodge, Ashurst, Southampton, SO40 7AA, UK Tel: 44 (0) 238 029 3223; Fax: 44 (0) 238 029 2853 E-Mail: [email protected]
http://www.witpress.com For USA, Canada and Mexico
Computational Mechanics Inc
25 Bridge Street, Billerica, MA 01821, USA Tel: 978 667 5841; Fax: 978 667 7582 E-Mail: [email protected] http://www.witpress.com
British Library Cataloguing-in-Publication Data A Catalogue record for this book is available from the British Library
ISBN: 978-1-84564-548-9 ISSN: 1746-4498 (print) ISSN: 1743-3509 (on-line)
The texts of the papers in this volume were set individually by the authors or under their supervision. Only minor corrections to the text may have been carried out by the publisher.
No responsibility is assumed by the Publisher, the Editors and Authors for any injury and/or damage to persons or property as a matter of products liability, negligence or otherwise, or from any use or operation of any methods, products, instructions or ideas contained in the material herein.
© WIT Press 2011
Printed in Great Britain by CMP (UK) Ltd, Poole, Dorset.
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written permission of the Publisher.
Wessex Institute of Technology, UK
M. Maugeri
University of Catania, Italy
The 1st Earthquake Resistant Engineering Structures Conference was held in
Thessaloniki organised by the School of Engineering of Aristotle University and the Wessex Institute of Technology. Since then it has been reconvened in a series of outstanding locations and in collaboration with local institutions. The 2011 meeting was held in Tuscany in a region rich in the type of cultural and architectural heritage that needs to be protected against earthquakes.
The problem of protecting the built environment in earthquake-prone regions involves not only the optimal design and construction of new facilities, but also the upgrading and rehabilitation of existing structures including heritage buildings. The type of highly specialised retrofitting employed to protect Tuscany’s heritage, as well as other regions of the world, is an important area of research and appropriate to the conference objective of designing better earthquake resistant buildings. Major earthquakes and associated effects such as tsunamis continue to stress the need to carry out more research on the topics of this conference. The problems will intensify as population pressure results in buildings in regions of high seismic vulnerability. A better understanding of these phenomena is required to design earthquake resistant structures.
This Conference addressed these problems and continued to expand on the devel-opment of previous meetings in the series. Papers presented at ERES are an invalu-able record of the state of the art on the topic. Those published from 1993 to 2009 are now freely available on the Website administered by WIT Press (http:// library.witpress.com) where they are a permanent record demonstrating the quality of the research presented at the ERES conference series.
The present volume offers most of the papers presented at ERES/11, grouped in the following sections:
•
Ground motion•
Soil structure interaction•
Structural performanceThe Editors are indebted to the members of the International Scientific Advisory Committee and other colleagues for helping to select the papers included in this Volume. They are also grateful to all authors for the quality of their papers. The Editors
Section 1: The 2009 Abruzzo Earthquake: site effects and seismic isolation (Special session organised by Michele Maugeri)
Seismic action to withstand the structures: the case history of 2009 Abruzzo earthquake
M. Maugeri, G. Totani, P. Monaco & S. Grasso ... 3
Features, recent application and conditions for the correct use of seismic isolation systems
A. Martelli, M. Forni & G. Panza ... 15
Site effects and site amplification due to the 2009 Abruzzo earthquake
P. Monaco, G. Totani, F. Totani, S. Grasso & M. Maugeri ... 29
Application of seismic isolation in the retrofit of historical buildings
P. Clemente & A. De Stefano... 41
Section 2: Seismic isolation and energy dissipation Adaptable dual control systems for earthquake resistance
M. C. Phocas & T. L. Sophocleous... 55
Energy-based evaluation of seismic response of structures with passive and active systems
A. Yanik, U. Aldemir & M. Bakioglu ... 67
Vibrobase insulation of a building excited by the technical seismicity effect of tube railway operation
D. Makovička & D. Makovička Jr ... 79
Behaviour of steel reinforced concrete beam-column joints
Developing a 7.5-sec site-condition map for Japan based on geomorphologic classification
K. Wakamatsu & M. Matsuoka... 101
Coherency between ground motions synthesized for analysis input of a large span structure
X. Tao, H. Liu, J. Lu, X. Sun & H. Wang... 113
Role of hysteretic damping in the earthquake response of ground
N. Yoshida... 123
Ground-motion simulation for the eastern province of Saudi Arabia using a stochastic model
M. S. Fnais... 135
Section 4: Soil structure interaction
Nonlinear vibrations of piles in viscoelastic foundations
E. J. Sapountzakis & A. E. Kampitsis ... 151
Evaluation of response characteristics of buried pipelines during earthquakes
K. Fuchida ... 163
Dynamic interaction of adjacent tall building structures on deep foundations
M. A. Rahgozar & M. Ghandil... 173
Moment formulation for random eigenvalue problems in beams
B. W. Yeigh & J. A. Hoffman ... 185
Section 5: Structural performance
Safety evaluation for dams against different modes of surface faults induced by earthquakes
Y. Ariga... 197
Garigliano nuclear power plant: seismic evaluation of the turbine building
P. Palumbo, L. Gramiccia, S. Cardellicchio, E. Faccioli & M. Villani... 207
Seismic history analysis of asymmetrical adjacent buildings with soil-structure interaction consideration
M. Uranjek, B. Dolinšek & S. Gostič... 237
Analysis of seismic stability of shells of revolution using probabilistic methods
M. Danieli, J. Bloch & I. Halperin ... 249
Evaluating a rigid-plastic method to estimate the earthquake ductility demand on structures
M. C. Porcu & G. Carta ... 261
Comparison of buckling load for H-shaped compression members with different eccentric bracing methods
Y. Kimura & Y. Yoshino... 273
The effects of multiple vertical baffles on sloshing phenomenon in rectangular tanks
M. Hosseini & P. Farshadmanesh... 287
Masonry block construction in Haiti
L. Holliday, C. Ramseyer & F. H. Grant... 299
Interpretation of microseismic effects from response to large coal mine blasts
C. H. Dowding & J. E. Meissner ... 309
The 2009 Abruzzo Earthquake:
site effects and seismic isolation
(Special session organised by
Michele Maugeri)
Seismic action to withstand the structures:
the case history of 2009 Abruzzo earthquake
M. Maugeri
1, G. Totani
2, P. Monaco
2& S. Grasso
11
Department of Civil and Environmental Engineering, University of Catania, Italy
2
Department of Structural, Water and Soil Engineering, University of L’Aquila, Italy
Abstract
The evaluation of the seismic action which the structures must withstand is the most critical item of the full process of analysis, monitoring and mitigation of seismic risk. Seismic action has been recorded worldwide for moderate to severe earthquakes. In the last 30 years the recorded accelerations have significantly increased. One reason could be due to the increasing number of recorded stations and to the location of a considerable amount of recorded stations on soft soil, where significant site amplification can occur. By the way the recorded accelerations have exceeded the designed acceleration given by seismic codes. That particularly occurs in the case of strong earthquakes, where the evaluation of seismic action given by source mechanism gives, in some cases, a seismic design earthquake greater than that given by the probabilistic evaluation reported by the codes.
Also in the case of the moderate ML = 5.8 Abruzzo earthquake, the recorded
acceleration exceeded the provisions given by Italian Code. Mainly two factors could explain that. One factor is related to the different results obtained by the probabilistic evaluation of seismic action given by the codes and the deterministic seismic action evaluated by source modelling of the scenario earthquake. The second factor is related to the role of site amplification, which is higher for small to moderate earthquakes and lower for severe scenario earthquakes. These two factors are discussed for the case of the Abruzzo 2009 earthquake, where, because of the normal fault mechanism, severe vertical components of the acceleration were recorded; also significant site effects occurred, particularly in the Aterno valley.
1 Introduction
The seismic prevention of damage is a challenge for the third millennium. In spite of the tremendous work on analytical and experimental studies to reduce seismic risk it was increasing exponentially in the past century.
The evaluation of the seismic action to which the structures must withstand is the most critical item of the full process of analysis, monitoring and mitigation of seismic risk. Seismic action has been recorded worldwide for moderate to severe earthquakes. In the last 30 years the recorded accelerations have been significantly increased. One reason could be due to the increasing number of recorded stations and to the location of considerable amount of recorded stations on soft soil, where significant site amplification can occur. Due to the increased values of recorded acceleration, the design acceleration given by the codes has been significantly increased; also some other parameters such velocity and displacement have been included in the Code for the design of buildings and infrastructures.
By the way the recorded accelerations trend is still higher than the design acceleration given by National and International Codes, so the structures must withstand with acceleration greater than that used for the design.
That particularly occurs in the case of strong earthquakes, where the evaluation of seismic action given by source mechanism gives, in some cases, a seismic design earthquake greater than that given by the probabilistic evaluation reported by the codes, as it will be explained in the following section 2.
Also in the case of the moderate ML = 5.8 Abruzzo earthquake, the recorded
acceleration exceeded the provisions given by Italian Code, as it will be shown in the section 3. Mainly two factors could explain that. One factor is related to the different results obtained by the probabilistic evaluation of seismic action given by the codes and the deterministic seismic action evaluated by source modelling of the scenario earthquake. By the way, the Abruzzo earthquake was characterised by a normal fault, which gave in the central area a significant vertical component, which is in general underestimated by the Codes.
The second factor is related to the role of site amplification, which is higher for small to moderate earthquakes and lower for severe scenario earthquakes. The amplification factor is discussed in the section 4. Amplification factors are comparable with the stratigraphic amplification factors given by the Italian Code [1], while in the Aterno valley the amplification factors exceed those given by the Code.
2 Seismic action recorded during recent earthquakes
In the last 20 years the seismic acceleration recorded during strong earthquakes has been increased considerably. Maugeri et al. [2] show that for severe earthquakes the acceleration recorded exceeds almost 0.8g (Table 1). Thus, do dot means that the seismicity has been increased in the last period. The increasing in the acceleration recorded could depends on the increasing number on recorded stations and also to the fact that these recorded stations have been
Table 1: Acceleration recorded during destructive earthquakes in the last 20 years ([2], modified).
g
located recently in soft soil deposits, while in the past they were located on rock. Higher values of acceleration than those reported in Table 1 have been recorded during recent acceleration such as the 2004 Niigata Chuetsu [3], the 2007 Peru and the 2011 Sendai earthquakes, where the acceleration exceeded 2g.
Because of the increasing of the recorded acceleration, the National seismic codes increased the design acceleration, year by year, as reported in Table 2.
Table 2: Peak ground accelerations and design criteria [4].
Geotechnics (Liquefaction, Landslide, Soil structure interaction) Structures (Buildings, Bridges)
Equivalent Liner analysis Nuclear power facilities Seismicity Year Geotechnics (Liquefaction, Landslide, Soil structure interaction) Structures (Buildings, Bridges)
Equivalent Liner analysis Nuclear power facilities Seismicity Year 70 75 80 85 90 95 00 05 10 1570 75 80 85 90 95 00 05 10 15 200-300 gal 400-500 gal 600-800 gal Strengthening Linear
analysis Non-linear analysis Vibration control
Isolation Pseudo-static analysis (Fs>1.2) • Equivalent linear analysis • Permanent displacement analysis • Performance-based design
• Hazard map. Risk map
Pseudo static analysis • Effective stress-based analysis recorded >0.8 Amax
To allow the structures to withstand with these increased accelerations, the methods of analysis to be used have been refined. The pseudo-static analysis is commonly used up to 0.3g for structures (buildings and bridges) and about up to 0.4g for geotechnical analysis. For an acceleration level of 0.4-0.5g, from pseudo-static analysis it is more convenient to move to non linear analysis for structures and linear equivalent analysis for geotechnical works. For acceleration levels of about 0.6-0.8g, vibration control by isolation, are required for structures [5] and permanent displacement analysis and performance based design are required for geotechnical works. Perhaps in the near future (2010-2015), the design acceleration will be still increased, particularly for nuclear power facilities and for strategic buildings (hospitals, fire stations, etc.). It must be also considered that the expected acceleration given by National Codes is given by a probabilistic approach. For instance in Italy, according to the Italian Regulation [1], the design acceleration is that which has a probability of exceedance less than 10% in 50 years, which correspond to a return period of 475 years. In different countries also a big earthquake with a longer return period up to 2375 years is considered. An alternative way to evaluate the seismic action to which the buildings must withstand is given by the deterministic analysis based on the maximum credible earthquake. In this case a source mechanism will be modelled, the shear wave propagation attenuation is taken into consideration, as well as the amplification given at the surface by site effects. These two ways of evaluation of seismic action could lead to different results. For instance in the case of the seismic risk evaluation of the city of Catania (Italy), the probabilistic evaluation according to Italian Code gives an expected acceleration (Figure 1), considerably lower than the acceleration given by the deterministic approach (Figure 2).
T = 0.0 sec T = 0.3 sec T = 0.6 sec
Figure 1: Probabilistic evaluation of spectral acceleration at the city of Catania (Italy) for different periods T [6].
Figure 2: Deterministic evaluation of spectral acceleration at the city of Catania (Italy) for different periods T [6].
In general in Italy when you are dealing with a maximum credible earthquake with a magnitude M = 7.0 or greater, as in the case of the city of Catania, the deterministic approach gives a spectral acceleration value bigger than the probabilistic approach. On the opposite, when you are dealing with a maximum credible earthquake with a magnitude M = 5.5 or lower, is the probabilistic approach which gives a spectral acceleration value greater than the deterministic approach.
In Table 3 is reported the comparison between expected probabilistic evaluation of peak acceleration, with a probability of exceedance less than 10% in 50 years, and the observed acceleration during destructive earthquakes [7]. It is possible to see that observed acceleration exceeds always the expected probabilistic values, particularly for the case of the 2003 Bam (MW=6.6), the
2010 Haiti (MW=7.0) and the 2011Sendai (MW=9.0) earthquakes.
Table 3: Comparison between expected probabilistic evaluation of peak acceleration (% g), with a probability of exceedance less than 10% in 50 years, and the observed acceleration during destructive earthquakes [7]. EXPECTED OBSERVED KOBE 0.4-0.48 0.7-0.8 GUJARAT 0.16-0.24 0.5-0.6 BOUMERDES 0.08-0.16 0.3-0.4 BAM 0.16-0.24 0.7-0.8 E-SICHUAN 0.16-0.24 0.6->0.8 HAITI 0.08-0.16 0.3-0.6 SENDAI 0.24-0.32 1.1-2.9
3 Seismic acceleration recorded during the April 6, 2009
Abruzzo earthquake
According to Italian Institute of Geophysics and Volcanology (INGV), the main shock of the L’Aquila earthquake has been on April 6, 2009, at 3.32 a.m. (ML =
5.8 and Mw = 6.3). The epicentre was located at few kilometres W-SW from the
town of L’Aquila. Maximum MCS intensity was: I= X at Onna I=IX at L’Aquila (73,000 inhabitants). Focal depth was about 8,8 km. 308 deaths, 1600 injured, 40,000 homeless, damages about 30 billions €, plus the intangible value of monuments. The main shock, foreshocks and aftershocks locations around the city of L’Aquila are reported in Figure 3.
Figure 3: Foreshocks, main shock and aftershocks locations around the city of L’Aquila, after INGV.
Most of the deaths took place in vulnerable masonry houses which were subjected to unusually strong motions. Several reports on the main features of the recorded ground motions were compiled by different teams, among which the group of Italian investigators ([8, 9]) under the umbrella of Italian Geotechnical Association (AGI) and the National Network of Earthquake Engineering Laboratories (ReLUIS) project; detailed reports was also produced by the Geo-Engineering for Extreme Events Reconnaissance (GEER) project [10] on seismological and geotechnical aspects of the earthquake and by Aydan et al. [11] on the damage occurred. The effects on the physical environment are reported, with reference to fractures, to large deformations, to rock falls, to sink
Figure 4: Location of the acceleration stations at the Aterno valley, recording the Abruzzo April 6, 2009 earthquake [13].
holes and to liquefaction. The soil liquefaction occurred at Vittorito is reported in detail by Monaco et al. [12].
Four accelerometric stations (AQG, AQA, AQV, AQM) were located across the Aterno valley (Figure 4) and recorded peak values ranging from about 0.4 to 0.6g; the station AQK was located in the city and recorded a peak value of about 0.35g. In table 4 are reported the recorded ground motion parameters in terms of maximum Peak Ground Acceleration (PGA) and Peak Ground Velocity (PGV) for the three components of each four stations considered. As regards the PGA, the recorded maximum value is 0.65g for the EW component of the AQV recording station, located on the alluvial soil, in the middle of the Aterno Valley. Table 4: Recorded ground motion parameters in terms of maximum Peak
Ground Acceleration (PGA) (g) and Peak Ground Velocity (PGV) (cm/s). AQG NS AQG EW AQG UP AQA NS AQA EW AQA UP AQV NS AQV EW AQV UP AQK NS AQK EW AQK UP PGA 0.51 0.47 0.24 0.45 0.40 0.47 0.54 0.65 0.52 0.35 0.33 0.37 PGV 35.9 31.2 10.4 24.5 32.0 9.39 40.4 36.7 12.5 36.3 30.3 19.8
Also, the strong portions of vertical and horizontal motions occurred almost simultaneously due to the short travel paths of P and S waves from the fault to the ground surface. This is evident because the severe horizontal motion start only about 1s after the vertical one, with a predominant period of 0.4-0.7s for S waves, while for P waves the predominant period is in the range 0.1-0.2s. These features are similar to fundamental frequencies of vibration of
one-to-eight-story buildings in L’Aquila and can be particularly dangerous for the weak non-ductile systems, such as the many old masonry structures in the area. The predominant frequency is between 1 and 2.5 Hz for the horizontal components; in particular for the AQV horizontal components it is 2 Hz. A comparison between the response spectra of AQV and AQG horizontal E-W and N-S components shows that for AQV station resting on soil formation there are some peaks ranging from a period T=0.15-0.5 s and for AQG station resting on soft rock the predominant period is T=0.25s for E-W component and it is ranging from T= 0.2-0.5s for N-S component.
As regards the AQK station, located in stiff soil on the city of L’Aquila, the maximum recorded peak ground acceleration in the NS component, is 0.35g; it must be stressed that L’Aquila is located in the vicinity of the normal fault, and because of that the recorded vertical acceleration (UP) of 0.37g is slight bigger than the horizontal one in NS component. It could be interesting to compare the recorded accelerations with those predicted by the new Italian Code [1], at L’Aquila city. According to this Code, the peak ground acceleration, is ag =
0.250 – 0.275g as can be read in the specific site by the regulation.
4 Evaluation of site effects
Seismic response analyses were carried out at the AQV station, located on alluvial soil in the middle of Aterno valley [14]. The subsoil model was built according to the geotechnical data available for AQV station subsoil conditions reported in Figure 5; Figure 5b shows the Vs profile measured by D-H; Figure 5c shows the modified Vs profile according to the discontinuity given by the
(a) (b) (c)
Figure 5: Shear wave profiles at AQV recording station: (a) Soil stratigraphy; (b) shear wave velocity profile obtained by Down Hole (D-H) test; (c) modified shear wave profile.
Vs (m/s) 0 5 10 15 20 25 30 35 40 45 50 0 500 1000 De p th ( m ) 0 500 1000 1500 VS (m/s) 50 45 40 35 30 25 20 15 10 5 0 de pt h ( m ) silty clay gravel in silty/clay matrix alternaces of silty sands, sandy silts and gravels limestone 1250 m/s 600 m/s
AQV
stratigraphy and of general increasing of the Vs with depth. The unit weight was increased with depth and with soil type from 19.00 up to 22.00 kN/m3. The bedrock was located at a depth of 46 m, where the shear waves velocity becomes higher than 800 m/s. The shear modulus decay and damping ratio increasing with shear strain, evaluated by Resonant Column Test, are reported in Figure 6, referring to different localities. The input accelerograms are reported by [14]. 0 0.2 0.4 0.6 0.8 1 0 .0 0 01 0 .0 0 1 0 .0 1 0 .1 1 S he ar S tra in (% ) G/ G ma x 0 2 4 6 8 1 0 1 2 1 4 1 6 1 8 2 0
Tempera S 1-C2 U niFI - S hear Modulus R oi o P iano S 3-C3 U niFI - Shear Modulus R oi o P iano S 3-C1 U niC T - Shear Modulus Tempera S 1-C2 U niFI - D amping Rat io R oi o P iano S 3-C3 U niFI - Dam pi ng R at io R oi o P iano S 3-C1 U niC T - Dam pi ng Rat io
Figure 6: Normalised shear modulus and damping ratio versus shear strain from RC – TS Roio Piano and Tempera tests.
The recorded (Table 4) and the computed values of maximum acceleration show an average amplification factor of about Ss = 2.5, which is considerable
higher for soil type B than the Ss= 1.14 given by the Italian regulation code and
the Ss = 1.20, given by the Eurocode. It must be stressed that, while the horizontal acceleration at the bedrock was in some agreement with the predicted one by the Italian Regulation, the vertical component of acceleration was much higher than that recommended by the Italian Code for the design of geotechnical structures (slope, earth retaining wall, etc.). In general it is recommended by Italian Code and Eurocode 8, to consider a vertical acceleration equal to 50% of the horizontal one. Because of the occurrence of a normal fault in the proximity of L’Aquila City, the recorded vertical acceleration was much higher than that recommended by the Regulations and its value was very similar to horizontal acceleration in the AQK station, located in the city of L’Aquila. This last aspect, which is outside the scope of this paper, must be considered by the Code in the future for a better design of geotechnical structures and of buildings resting on the proximity of normal faults.
Site amplification, performed by EERA code [15], was carried out by all the normalized shear modulus and damping ratio reported in Figure 6 and for different curves given by literature, such as that reported by Kokusho and Esashi [16]. The results reported in figure 7 show that the site responses, evaluated by normalized shear modulus and damping ratio results obtained at Roio Piano and Tempera localities, are in good agreement with the recorded values of
Figure 7: Results of site response analyses evaluated by normalized shear modulus and damping ratio obtained at Roio Piano and Tempera localities.
acceleration. Also using normalized shear modulus and damping ratio the given by Kokusho and Esashi [16], the results are slight lower, but sufficiently closed to the recorded one.
Seismic response analyses in the historical centre of L’Aquila have been carried out by Monaco et al. [17]. The site response analysis, performed at the historical building named Palazzo Camponeschi, was made at two layered soil with an inverse shear wave velocity profile, characterized by Vs = 800-1000 m/s for the upper layer, with a thickness of about 100m, and by Vs = 600-700 m/s for the second layer, resting over the bedrock, placed at a depth of 300 m.
The soil shear wave profile was measured by the Seismic Dilatometer (SDMT) in a non-penetrable soil [18]; for the upper layer made by Breccias, the normalized shear modulus and damping ratio were selected by literature results measured in similar soils, for the second layer made by lacustrine silt were obtained by Resonant Column Test performed at Roio Piano [19].
The results, performed by the EERA code [15] show that the spectral acceleration Sa is greater than that given by the Italian regulation NTC [1]
particularly for a period ranging between 0.2s and 0.4s, which is the fundamental period more representative for masonry buildings present in the area.
5 Conclusions
The key-point for the evaluation of the seismic risk is the evaluation of the seismic hazard, related to the evaluation of the seismic action by probabilistic or deterministic approaches. By the way in general for low seismicity area the 2009 Abruzzo earthquake.
was underlined by De Luca et al. [20], before the occurrence of the destructive The evidence of low frequency amplification in the city of L’Aquila
probabilistic approach is overestimated the seismic action, while for very high seismicity area it underestimate the seismic action, as in the case of the city of Catania. In the case of the Abruzzo earthquake, acceleration bigger than that given by Italian Regulation was recorded. Thus, mainly because the soil amplification was in the soft soil of Aterno Valley greater than that given by Italian Regulation. Also in the centre of L’Aquila city, the spectral acceleration given by Italian Regulation is too simple for the evaluation of the soil response in a soil with inverse profile of velocity.
References
[1] NTC (2008). Norme Tecniche per le costruzioni. D. M. 14/01/2008 by the Ministry of Public Works of Italy. G.U. 04/02/2008.
[2] Maugeri M., Castelli F., Massimino M.R. (2006). Analysis, modeling and seismic improvement of foundations of existing buildings. Italian Geotechnical Journal. No. 4-2006, pp. 52-122 (in Italian with extended abstract in English).
[3] Ishihara K. (2009). Perspectives in geotechnics for vastly strong earthquake shaking”. Special discussion session-future directions of performance-based design. Proc.1st International Conference on Performance-Based Design in Earthquake Geotechnical Engineering, IS- Tokyo, June 15-17, 2009. [4] Ishihara K. (2008). Challenges in perspective in geotechnics for intense
earthquake shaking”. Invited Lecture. Seismic Engineering International Conference commemorating the 1908 Messina and Reggio Calabria Earthquake, Reggio Calabria.
[5] Martelli, A., Forni M., Panza G. (2011). Features, recent application and conditions for the correct use of seismic isolation systems. Earthquake Resistant Engineering Structures (ERES 2011). Chianciano Terme (Italy). September 07-09, 2011.
[6] Faccioli E., Pessina V., Vecchiotti M. (2002). Risk-UE WP2 meeting 23-25 Jan 2002, Barcelona.
[7] Peresan A., Vaccari F. (2011). Integrated seismic hazard assessment: a neo-deterministic time-dependent approach. Workshop Seismic Information System for Monitoring and Alert. ASI, Rome. May 4, 2011.
[8] Simonelli A. L., Sica S., Moccia F., Penna A., Lucadamo C., Mitrione A., Mosca P., Moscato T., Rotella M., Spatola M. G., Zarra S. (2009). Rapporto preliminare sugli effetti indotti sull’ambiente fisico dalla sequenza sismica dell’aquilano - Ver. 1.5, Working group AGI-ReLUIS, www.reluis.it.
[9] Monaco P., Totani G., Barla G., Cavallaro A., Costanzo A., D’onofrio A., Evangelista L., Foti S., Grasso S., Lanzo G., Madiai C., Maraschini M., Marchetti S., Maugeri M., Pagliaroli A., Pallara O., Penna A., Saccenti A., Santucci De Magistris F., Scasserra G., Silvestri F., Simonelli A.L., Simoni G., Tommasi P., Vannucchi G., Verrucci L. (2009). Geotechnical Aspects of 2009 L’Aquila Earthquake. Proc. Earthquake Geotechnical Engineering
Satellite Conference, 2-3 October 2009 in Alexandria, Egypt. (Invited Lecture).
[10] Stewart J. P. (Ed.), Di Capua G., Kayen R. E., Scott Kieffer D., Button E., Biscontin G., Scasserra G., Lanzo G., Tommasi P., Pagliaroli A., Silvestri F., d’Onofrio A., Simonelli A.L., Puglia R., Mylonakis G., Athanasopoulos G., Vlahakis V. - GEER Association Report No. GEER-016, (Version 1. May 6, 2009), Preliminary Report on the Seismological and Geotechnical Aspects of the April 6 2009 L’Aquila Earthquake in Central Italy, www.geerassociation.org.
[11] Aydan O., Kumsar H., Toprak S., Barla G. (2009). Characteristics of 2009 L’Aquila earthquake with an emphasis on earthquake prediction and geotechnical damage. Personal communication of the draft.
[12] Monaco P., Santucci De Magistris F., Grasso S., Marchetti S., Maugeri M., Totani G. (2011). Analysis of the liquefaction phenomena in the village of Vittorito (L’Aquila). Bull Earthquake Eng (2011) 9, pp. 231–261. DOI 10.1007/s10518-010-9228-0. ISSN: 1570-761X (print version), ISSN: 1573-1456 (electronic version).
[13] Di Capua G, Lanzo G, Luzi L, Pacor F, Paolucci R, Peppoloni S, Scasserra G, Puglia R (2009): “Caratteristiche geologiche e classificazione di sito delle stazioni accelerometriche della RAN ubicate a L’Aquila”. Report S4 Project (http://esse4.mi.ingv.it/), June 2009.
[14] Maugeri M., Simonelli A.L., Ferraro A., Grasso S., Penna A. (2011). Recorded ground motion and site effects evaluation for the April 6, 2009 L’Aquila earthquake. Bull Earthquake Eng (2011) 9, pp.157–179. DOI 10.1007/s10518-010-9239-x. ISSN: 1570-761X (print version), ISSN: 1573-1456 (electronic version).
[15] EERA (2000). http://gees.usc.edu/GEES/Software/EERA2000/Default.htm [16] Kokusho T., Esashi Y. (1981). Cyclic triaxial tests on sands and coarse
materials, X ICSMFE, Vol. 1, 673-676, (1981).
[17] Monaco P., Totani G., Totani F., Amoroso A., Maugeri, M., Grasso, S. (2011). Modello di sottosuolo e analisi di risposta sismica locale nel centro storico dell’Aquila. XIV Convegno ANIDIS – L’Ingegneria Sismica in Italia – Bari, 18-22 settembre 2011.
[18] Totani, G., Monaco, P., Marchetti, S. and Marchetti, D. (2009). VS measurements by seismic dilatometer (SDMT) in non-penetrable soils. Proc. 17th ICSMGE, Alexandria, Egypt, Vol. 2, 977-980. M. Hamza et al. (eds). IOS Press.
[19] Gruppo di Lavoro (2010). La Microzonazione Sismica dell’area aquilana. 3 Vol. + DVD. Regione Abruzzo. In print.
[20] De Luca, G., Marcucci, S., Milana, G. and Sanò, T. (2005). Evidence of low-frequency amplification in the city of L’Aquila, Central Italy, through a multidisciplinary approach including strong- and weak-motion data, ambient noise, and numerical modeling. Bull. Seism. Soc. Am., 95(4), 1469-1481.
