The range Point to highlight 90 series towards 90+ series

PUSH BAR 90+

PUSH BAR 90+

Push Bar 90+

1 - Series Push Bar 90+

The range

Point to highlight

90 series towards 90+ series

2 – Marketing tools on a CD

CE EN1125 certificate in PDF format

Fire test certificate in PDF format

English documentations in PDF format

technical file in DWG format

:

c

New aesthetic

d

Complete range :

• 1 side point version

• Vertical version

• 3 points version, side + vertical

e

Safety

60 mm touch pad projection = maximum free

passage.

f

Safety :

Trigger bolt to block the bolt in door closed position

g

Dogging version with cylinder:

For non- fire rated doors

h

Easy to fit :

• No handed

• Same fixing holes than 90 Push bar

• 2 hours fire rated

• 240 Hours salt spray resistance

Toward the new Push Bar 90+

Push Bar 90+

Push Bar 90+

Technical evolution

1 – Push Pad and support

 No visible screws or fixing hole ( on the back plate ) .

 Silent aluminium pad

 Pad and pad support in aluminium

 Adjustment cutting : till 400 mm

2 - Push Bar 90+ head

 Similar for 1-2-3 points versions



Side fixing cover

 Head cover and end fixing bracket cover in zamack



Bigger trigger bolt for easy striker plate adjustment

3 - Vertical

 Epoxy coated rods covers

 Top and bottom latches working by pulling and with

anti-picking device

4 - Fitting

 Fixing dimensions unchanged

 Compatible with EN3000 / EN2000

5 – Finishing and accessories

3 mains epoxy finish:

Silver, new silver metallic finish RAL 9022

Black, and white.

Dogging version for European cylinder

Striker plates support.

1

2

3

Push Bar 90+

 For single of double leaf door

 for timber, metal, PVC and glass doors

Push Bar 90

1 point,

2 points Vertical

Push Bar 90+

Push Bar 90+

1 point,

2 points Vertical,

Outside trims

EN3000/PR2E series

+ EN2000 series

Outside trims compatibility

• Exact retrofitting with 90 series.

.

Push Bar 90+

1 point

2 points

3 points

Push Bar 90+

The changes :

–

The code item numbers

–

The design, the metallic aluminium silver finish

–

The cutting adjustment of push bar

–

The packaging, the installation notice.

The similar points with 90 series :

–

EN1125 approved

–

Applications,

–

Fixing dimensions

–

Compatibility with Outside trims

To note :

Push Bar 90+

THE FITTING INSTRUCTIONS

//

1. Axe horizontal = 1 035 mm du sol fini. 1. Horizontal axis = 1035mm from

finished floor.

2. Axe A (côté ouverture) 2. Axis A (on opening side)

1 ou 3 pointsÎ 1 or 3 points versionÎ

A1= 44 mm du bord de l’huisserie (recouvrement) A1= 44 mm from the edge of the frame.

A2= 22 mm du bord de l’huisserie (affleurant) A2= 22 mm from the edge of the frame.

2 pointsÎ A2 bis= 45 mm 2 points version Î A2 bis= 45 mm

Axe B= minimum 30 mm du bord de l’huisserie. Axis B= 30mm minimum from the edge of

the frame.

3. Pointer et percer: 3. Mark and drill the door:

H3 pour portes standard H3 for standard doors

H3 et H4 pour portes COUPE-FEU H3 and H4 for fire-rated doors

F1 Ø 15mm avec ensemble extérieur F1 Ø 15mm with an outside trim

4. Gabarit B sur l’Axe B (côté paumelles): 4. B template on the A axis (hinge side):

Pointer et percer H5. Mark and drill the door H5.

5. Relever la distance A-BÎÎÉÉtape 2tape 2 5. Measure the distance A - B ÎÎStepStep22

Loquets haut et bas ÎÎÉÉtapes 5 et 6tapes 5 et 6 Top and bottom latch ÎÎSteps 5 et 6Steps 5 et 6

1. Gabarit D1 pour portes avec recouvrement (A93). 1. D1 template for overlapping doors (A93).

Gabarit D2 pour portes affleurantes. Tracer (A96). D2 template for flushed doors.

Draw (A96).

Pré percer aux emplacements indiqués(H1, H2, H8, H9) Pre-drill as indicated (H1, H2, H8, H9) 2. Gabarit E (loquet bas+gâche basse A92): 2. E template (bottom latch and striker A92):

Positionner le gabarit par rapport au sol fini. Tracer. Position the template to the finished floor. Draw.

Pré percer aux emplacements indiqués(H1, H2, H8, H9) Pre-drill as indicated (H1, H2, H8, H9) 3. Repère C Visser le support de cache tringle. 3. Mark C Screw the rod cover retainers clips.

JPM PUSH BAR 90+

FERMETURES ANTI-PANIQUE EN APPLIQUE 1/2/3 POINTS

RIM PANIC EXIT DEVICE 1/2/3POINTS

N01-154 Ind. C

2

CONTENU DE LA BOITE /

CONTENT OF THE PACKAGE

1

PREPARATION DE LA PORTE

DOOR PREPARATION

MISE A LONGUEUR DE L’ANTI-PANIQUE /

ADJUSTMENT OF THE PANIC EXIT DEVICE

L Partie active de la barre = 60% minimum de la largeur effective de la porte.

L For the active regulation, it is compulsory that the active bar covers at least 60% of the door width.

M4x15

Recoupe : AB+ 4 mm ÎÎA1, A2, A2bisA1, A2, A2bis Éviter la disqueuse ou meuleuse. Utiliser 1 boîte à onglet pour faciliter la coupe de la barre.

Coupe à l’équerre et ébavurée. Évacuer la limaille.

Cut : AB + 4 mm ÎÎA1, A2, A2bisA1, A2, A2bis

Avoid the grinding machine. Use a mitre box to facilitate the cut of the bar. Cross to the square and deburred.

Evacuate the filings.

1 point: barre, capots, sachet visserie, gâches. 1 point: bar, covers, screw set, strikers.

2/3 points: barre, capots, sachet visserie, gâches, tringles, cache-tringles, loquets.2/3 points: bar, covers, screw set, strikers, rods, rod covers, top and bottom latches.

Les caractéristiques de sécurité de ce produit sont essentielles pour satisfaire à l'EN1125. Aucune modification d'aucune sorte, autre que celles décrites dans ces instructions, n'est permise. L’utilisation de ce produit certifié est limitée à une porte dont les caractéristiques n’excèdent pas : - Hauteur maximale 2 300mm - Largeur maximale 1 300mm

- Poids de la porte : maximum 200 kg.

The characteristics of security are essential to satisfy to EN1125 requirements. No modification, except the ones described in the present instructions are allowed. The use of this certified product is limited to one door which characteristics do not exceed:

-Maximum height 2300 mm - Maximum width 1300 mm - Maximum weight of the door 200 kg.

0

M4x15 A Distance AB + _{4 mm} 40 Route de Paris AVERMES F 03000 MOULINS 08 3 7 6 1 1 4 2 2 B 0333 CPD40 - 250033 EN1125: 1997 / A1 : 2001

H5/H6 H9 H4 H3 H3 H4 M3x6 Auto taraudeuse Thread cutting screws

N01-154 Ind. C

5

3

POSE DU FOUILLOT

/ INSTALLATION OF THE FOLLOWER

4

INSTALLATION DE LA BARRE /

FIXING OF THE BAR

POSE DU LOQUET HAUT + GÂCHE HAUTE

/ INSTALLATION OF THE TOP LATCH + STRIKER

6

L IMPORTANT : Dans la cadre d’un remplacement de produit, les gâches et loquets sont à changer. L WARNING: In case of a push bar 90 replacement, strikers and latches must be changed.

POSE DU LOQUET BAS + GÂCHE BASSE

/ INSTALLATION OF THE BOTTOM LATCH + STRIKER

L Cas d’utilisation avec série EN3000/EN2000/PR2E.

L Only in case of a use with an outside trim EN3000/EN2000/PR2E.

H9 H8 H2/H1 H8 H2/H1 L Vérifier le bon fonctionnement de la Push Bar 90+. L Check if the Push Bar 90+ works correctly.

Sol fini / Finished floor

Porte Coupe-feu

Fire rated door

Portes standard

Standard doors

H8/H9 M5x35 CZ Ø 4,2x32

H1/H2 M4x35 CZ Ø 4,2x32

Porte Coupe-feu

Fire rated door

Portes standard Standard doors H3 M6x30 Ø 5,5x32 H4 M6x30 H5/H6 M6x30 Ø 5,5x32 F1 F2 Ø 15 Ø 30 Ø 15 Ø 30 Gâche / Striker H1/H2 M4x35 Ø 3,5x16 Gabarit / Template Gâche / Striker

A1 A98

A2 A99

A2 bis A99

Double vantail / Double leaf

Anti-panique

Panic Exit Device

Porte / Door

Recouvrement / Overlapped Affleurant / Flushed

L IMPORTANT : Dans la cadre d’un remplacement de produit, les gâches et loquets sont à changer. L WARNING: In case of a push bar 90 replacement, strikers and latches must be changed.

Gâches hautes/ Top strikers

A93 A96

Î D1 Î D2

L Vérifier les positions: gâche + loquet.

L Check positions: striker + latch.

N01-154 Ind. C

7

POSE DE LA TRINGLERIE

/ INSTALLATION OF THE RODS

8

_{L IMPORTANT : Dans la cadre d’un remplacement de produit, les cache-tringles sont à changer.}

L WARNING: In case of a Push Bar 90 replacement, rod covers must be changed.

POSE DES CACHE-TRINGLES + CAPOTS

/ INSTALLATION OF THE ROD COVERS + CASE COVERS

Coupe Cut Tiges hautes / Top rod Î L= X-10mm Tiges basses / Bottom rod Î L= Y-10mm

Loquet haut/ bas

Top/bottom latches

L IMPORTANT : Dans la cadre d’un remplacement de produit, les tringles sont à changer.

L WARNING: In case of a Push Bar 90 replacement, rods must be changed.

Haut Î L=X

Top Î L=X

Bas Î L=Y

BottomÎ L=Y

L Vis auto taraudeuses

L Thread cutting screws

L IMPORTANT :

Vérifier le bon fonctionnement de la Push Bar 90 +.

L WARNING :

Check if the Push Bar 90+ works correctly.

c

d

e

H M6 M3x6 M4x15 M3x8 M4x6 3.9x16

2 points haut et bas: zoom

2 points top and bottom: zoom

Fixation + contrôle de fonctionnement

Fixing + check if it works correctly

3 points latéral, haut et bas

3 points lateral, top and bottom

3.9x16 M3x6

d

c

maximum

e

maximum

d

e

e

9

ENTRETIEN

/ MAINTENANCE

L IMPORTANT : graissage des gâches toutes les 20000 manoeuvres. L WARNING : grease the strikes after 20000 openings.

renouveler l’opération tous les ans. repeat this operation each year.

N01-154 Ind. C

Y

X

10

VUE D’ENSEMBLE

/ GENERAL VIEW

H5/H6 M3x6 M4x15 M3x8 M4x6 3.9x16 3.9x16 M3x6 H3 H4 H9 H8 H9 H8 L Vis auto taraudeuses

I DOOR CARACTERISTICS I

Height : 2300 mm.

width 1200 mm.

Weight : 200kg.

Touch Bar

Type B

Adjustable on site

Active pad length 775mm or 1080mm adjustable till 400 mm

.

Fixing center distance

90 mm (45 mm from the follower)

Spindle

Cross type ( only for outside trim use )

Material

Touch pad and support : epoxy coated.

Rod covers and top an bottom covers : steel epoxy coated .

Head cover and end bracket cover : zamack epoxy coated

Under plate : steel zinc plated

Push Bar 90+

I INSTALLATION I

CE EN 1125 approved by AFNOR

Certificate CE0333 CPD40-250033

Fire rated doors

> Single leaf (1 side point, 3 points, side and vertical )

Testing door Certificate Efectis France n° 85-G7-T7

> Double leaf ( vertical )

Testing door Certificate Efectis France n° 88-U238

A98

A99

I DIMENSIONS I

Configurations

Available on request

Over lapping door

Flush door

Dimensions

Side type

A98000

A99000

A13300

PVC support

S02532-01-0A

S02532-02-0A

Push Bar 90+

Configuration

Available on request

Push Bar 90+

I SIDE STRIKES AND SUPPORT I

- Top strike

Overlapping doors

(timber, steel, PVC doors)

Flush doors ( aluminium

doors )

- Bottom strike

I OUTSIDE TRIMS I

> Modularity

PUSH BAR 90+ series can be combined with an outside trim EN3000 or PR2E.

Center distance : 90 mm ( 45mm from each follower side)

Single European profile cylinder 40mm (30/10) or Swiss profile on request.

Push Bar 90 +

I OPTIONS I

¾Dogging (non- doors only)

Activated by single European cylinder ( 40mm)

.

¾Kits

Glass door kit

KG9000.

Extension kit

S91000 For door height > 2 300 mm Threaten rods (865 mm) and rod covers (867 mm).

with connexion and fixing device and Isophonic joint.

Door thickness 55 à 115mm

KE2000

screws and cross spindle

¾Door selector

Series 914000

SINGLE LEAF DOOR

DOUBLE LEAF DOOR

I ITEM CODE NUMBERS I

1 side point

Standard

Dogging

900 mm width door

PJ1000

PJ1001

1200 mm width door

PJ1100

PJ1101

2 Vertical points

900 mm width door

PJ2000

PJ2001

1200 mm width door PJ2100

PJ2101

3 points side and vertical

900 mm width door

PJ3000

PJ3001

1200 mm width door PJ3100

PJ3101

I FINISHES I

Silver -08, black-02, white -03.

> Other epoxy coated on request, more than 100 colours ( RAL number to precise ).
