TEST STATION FOR PIC MICROCONTROLLER USING FPGA

BETTY GEORGE1,TINA RAJA2

1. PG Student [Applied Electronics], Dept. of ECE, MG University College of Engineering, Thodupuzha, Kerala, India. 2. Scientist/Engineer "SE", QDAC/QRAG/SR/ VSSC, Trivandrum, Kerala, India.

Accepted Date: 25/08/2015; Published Date: 01/09/2015

\

Abstract: - The PIC microcontroller’s are used in various applications, from control logic to fully integrated systems involving USB, Ethernet and LCD. It is of high importance that the PIC’s functionality is tested before realizing into application circuit. In industries, VLSI testers are used for testing purpose. Processor per pin architecture is employed in VLSI testers to serve the purpose. These systems are very complex, large and expensive. The proposed system has a standalone feature and mainly focuses on testing of the various modules in PIC18F6520. The programmer used to program the various modules of microcontroller is Microchip MPLAB. FPGA is the main controller of the proposed system. The implementation of FPGA is done using HDL in ModelSim platform and synthesis in Xilinx platform. Microsoft Visual Basic is used for the graphical user interface.

Keywords:PIC Microcontroller, FPGA

Corresponding Author: MR. BETTY GEORGE

Access Online On:

www.ijpret.com

How to Cite This Article:

Betty George, IJPRET, 2015; Volume 4 (1): 33-46

(2)

INTRODUCTION

Microcontroller is a small computer on a single integrated circuit containing a processor core, memory, and programmable input/output peripherals. Program memory is in the form of Ferroelectric RAM, NOR flash or OTP ROM is also often included on chip.Peripheral Interface Controller (PIC) is a family of microcontrollers made by Microchip Technology. To ensure the working of the device, it is required to test the device to its full functionality.

Device under test (DUT) is PIC18F6520 microcontroller. It is a 64 pin, flash memory incorporated microcontroller. Communication with the PIC is made possible using the SPI, UART, I2C protocols etc. There are 5 timers present that work as 8 bit or 16 bit timers or counters. Capture/Compare/PWM (CCP) modules are also present in the specified PIC. The data memory is 2048 Bytes and the data EPROM is 1024 Bytes. The operating frequency of the PIC is 40 Mhz and there is 17 interrupt sources.PIC 18F6520 uses 16 bit wide instructions and 8 bit wide data path.

In general, testing at manufacture side is carried out using VLSI tester. The test programs are developed in assembly language for testing the different modules of PIC 18F6520. For each module the expected response obtained from the simulator is stored in tester memory. The tester captures the response and compares the observed response with the expected response stored in the vector memory of the tester and gives PASS/FAIL.

The proposed system is meant to test the various modules of PIC microcontroller like ALU, byte oriented file register operations, byte oriented file register operations, literal operation, Timer modules, CCP modules, UART module, SPI of MSSP module and memory. For this FPGA is used as a main controller. In FPGA, the various protocols to test the microcontroller parallel interface to SRAM and RS232 interface to PC are implemented. This is done in VHDL using ModelSim and implemented in Xilinx. The PIC is programmed using MPLab from Microchip. The basic structure diagram for testing of a PIC microcontroller is as Fig.1.

(3)

Available Online at www.ijpret.com 35 The upper hand of the proposed system when compared to other testing method is its stand alone feature. The interfaces implemented in FPGA could be used for the communication between other devices such as test station and FPGA, as they are standard communication protocols. SPI and UART protocols are implemented and tested in the proposed system. Selectable frequency operation for the above mentioned communication protocols make it apt for the testing of microcontrollers. The memory implemented is employed for the storage of data captured from PIC.

SOFTWARE ENVIRONMENT

The implementation and synthesis of the main controller is done in ModelSim and Xilinx software platform. ModelSim is an HDL simulation environment by Mentor Graphics. It is used for the simulation of hardware description languages. The four basic flow in development of HDL design involves creating the working library, compiling of design, loading the simulator with design and running the simulation and debugging of results. Xilinx ISE is the software platform used for the programming of FPGA. Compiling of designs, retrieving RTL schematics, timing analysis etc is done using Xilinx ISE. MPLab from Microchip Technology helps in programming PIC as the specific PIC under consideration does not have an external memory interface. Microsoft Visual Basic forms the front end of the proposed system. Graphical user interface containing the test result is displayed in VB.

HDL DEVELEOPMENT OF INTERFACES

UART

UART is an asynchronous serial communication protocol which accomplishes communication between slow and fast peripherals. Low cost and short distance characteristics of the protocol make it ideal for many applications. An UART module consists of a transmitter, baud rate generator and a receiver. A parallel to serial and serial to parallel conversion of data takes place in transmitter and receiver end respectively.

(4)

Fig.2 Structure diagram of UART.

Receiver module hold registers serves the purpose of holding data and shift registers are used for the shifting in of data. The start bit and top bit are checked for and not stored onto the memory. The memory implemented is used for the storage of data received.

Baud rate generator serves the purpose of generating sampling signals with frequency sixteen times that of the designated baud rate. In the proposed system, the baud rate is selectable.

SPI

SPI is s synchronous communication protocol. The protocol supports master and slave communication, specifically a single master. The clock signal for the communication is generated by the master is supplied to all slaves associated. The SPI is selectable in the case of a PIC microcontroller and so the SPI implemented onto the FPGA also possess a selectable frequency of operation.

(5)

Fig.3 Structure diagram of SPI.

Memory

Memory is implemented in order to collect data that are captured from PIC for the comparison purpose. The memory implemented for this particular proposed system is an array type consisting of 256 locations that are 8 bit wide.

Parallel Ports

Parallel ports are implemented to make the communication possible through the parallel ports. The parallel port is designed on the concept of capturing data from parallel ports of PIC.

TEST VECTOR DEVELOPMENT OF PIC

Test vector development of PIC is done. The PIC modules tested for are the byte oriented file register operations, bit oriented file register operations, literal operations, CCP modules, Timers modules, UART, SPI and memory. The DUT do not possess an external memory interface and thus the programming is done using MPLAB from Microchip.

Bit And Byte Oriented File Register Operations

(6)

CCP Modules

CAPTURE/COMPARE/PWM modules are 5 in number for PIC 18F6520. Each module contains a 16-bit register, which can operate as a 16-bit Capture register, a 16-bit Compare register or a Pulse Width Modulation (PWM) Master/Slave Duty Cycle register. In Capture mode, CCPR1H:CCPR1L captures the 16-bit value of the TMR1 or TMR3 registers when an event occurs on pin RC2/CCP1. In Compare mode, the 16-bit CCPR1 register value is constantly compared against either the TMR1 register pair value or the TMR3 register pair value. If a match occurs, an event occurs. Event is represented by change in value on the corresponding pin. In Pulse Width Modulation (PWM) mode, the corresponding pin produces up to a 10-bit resolution PWM output. Programs are written to PIC fulfilling the above conditions.

Timer Modules

PIC 18F6520 has 5 timer modules named as Timer 0, Timer 1, Timer 2, Timer 3 and Timer 4. Timers act as software selectable 8/16 bit timer or counter. There are several registers defined in PIC architecture that control the working of these timers or counters. Programming is done for each of the timer modules and testing is carried out.

UART

Universal Asynchronous Receiver Transmitter also called Serial Communications Interface (SCI) is one among the serial communication available in specified PIC. Each device has two UART modules which could be configured independently. Both full duplex communication as well as half duplex communication is made possible using UART module. Full duplex communication is made use for the communication of peripheral devices such as personal computer etc while half duplex communication is accomplished with peripheral devices such as A/D OR D/A circuits. Transmitter and receiver control registers are used to select the various conditions. Baud Rate Generator (BRG) is used to set the desired baud rate. Baud rate is set in the SPBRG register. A shift register forms the important part of both the transmitter and receiver block.

SPI

(7)

GRAPHICAL USER INTERFACE

Graphical user interface is formed in Microsoft Visual Basic platform. The values are captured by the test station via RS 232 protocol. The captured value is compared against the actual value and a PASS/FAIL is produced in the test station.

RESULTS

HDL implementation of interfaces is done in ModelSim platform. UART transmitter is given in Fig.4. Transmitter acts as a parallel to serial converter that takes in data from the memory in a parallel manner and converts the data into serial one and sends it out. State machines are used to realize the working and functionality of transmitter. There are 11 transmitter states in a transmitter state machine. Each state lasts for the defined baud clock cycle.

Fig.4 Transmitter

UART receiver’s working and functionality is realized using state machines. The receiver state machine also consists of 11 states. A start bit is polled for and when a bit is received, it is checked so as to ensure that the received bit is a start bit. Then after a baud clock cycle, the next bit is received and stored until the eighth bit is stored. The stop bit is checked. This process continues. Receiver implantation is given in Fig.5.

Fig.5 Receiver

(8)

Available Online at www.ijpret.com 40 between the slave and the master. A signal SS defines the working frequency of the device. For SS=”00”, the clock frequency selected is Fosc/4, for SS=”01” clock frequency is Fosc/16 and for SS=”11”, clock frequency is Fosc/64.

Fig.6 SPI

Memory is also implemented so that the values are stored temporarily. Memory read and memory write signals are defined. The writing onto the memory is done if and only if the memory has free space similarly; reading from the memory is only possible when the memory is occupied. These two conditions are accomplished using full and empty signals. Fig.7 is the memory implementation.

Fig.7 Memory

Synthesis is done using Xilinx ISE 10.4. The device used is Spartan3xc3s400. The design summary report in table 1 shows the utilization of slices flip flops etc.

Logic Utilization Used Available Utilization

Number of slices 1494 3584 41%

Number of slice flip flop’s 599 7168 8%

Number of 4 input LUT’s 2841 7168 39%

Number of bonded IOB’s 19 141 13%

Number of GCLK’s 2 8 25%

(9)

Available Online at www.ijpret.com 41 RTL schematic generated for the Xilinx synthesis is as in Fig.8

Fig. 8 RTL Schematic

Test vector development of the PIC is done. The CCP modules are checked for. The various registers used for capture mode are T3CON, T1CON, PIE1 etc. The value in the timer module is captured when an event occurs. The event could either b a falling edge or rising edge etc at the corresponding pin. Fig.9 defines the test vector development for capture mode.

Fig.9 Capture

(10)

Fig.10 Compare

Timer modules are five in number and their operation as 8/16 bit timer or counter is validated. Fig 11 gives the test vector development for Timer 0. Control registers are used to set the device Timer 0. When an overflow occurs, an interrupt is generated.

Fig.11 Timer 0

(11)

Fig.12 Timer 1

Timer 2 is an 8-bit timer. An 8 bit period register is also associated with the Timer 2 module. It is both readable and writable. An interrupt occur when the value of Timer 2 and the period register matches. It is also used as a time base for PWM module. . Fig 13 gives the test vector development for Timer 2.

Fig.13 Timer 2

(12)

Fig.14 Timer 3

Timer 4 acts as 8-bit timer. The Timer is both readable and writable. Programmable prescaler and postscaler is present. Interrupt is generated when a match occurs between the values of timer register and period register. Fig 15 gives the test vector development for Timer 4.

Fig.15 Timer 4

(13)

Fig.16 UART

SPI module of PIC consists of the hold register and shift register. If the PIC specified acts as the master, the SPI module needed to work in three different frequencies such as Fosc/4, Fosc/16 and Fosc/64. The test vector generation of SPI is given in Fig.17.

Fig.17 SPI

The graphical user interface is implemented using Microsoft VB as in Fig.18. The expected value is stored onto a file which is compared against the obtained value. The programming is done to capture values from the RS232 port of the test station. A PASS or FAIL message indicates the functionality of the device.

(14)

CONCLUSION

PIC is used in wide range of applications such as commercial, industrial and automotive applications. It is important that the device is tested prior to wiring in the application circuit. PIC microcontroller 18F6520 is tested for its precision using a standalone system. The main controller used is an FPGA onto which the communication protocols are implemented. FPGA device could be used for the communication between test station and a peripheral device that has any one of the communication protocol implemented on the controller. It also acts as a temporary storage of data. The graphical user interface indicates whether the PIC has passed or failed to meet the need.

REFERENCES

1. Dr G.B.Wakle, I. Aggarwal and S. Gaba, “Synthesis and Implementation of UART using VHDL

Codes”, International Symposium on Computer, Consumer and Control, pp.1-3, June 2012.

2. Y. Wang and K. Song, “A New Approach to Realize UART,” in Electronic and Mechanical Engineering and Information Technology (EMEIT), International Conference, vol. 5, pp. 2749 – 2752, 2011.

3. T.P.Blessington, B.B.Murthy, G.V.Ganesh and T.S.R Prasad, “Optimal Implementation of UART-SPI Interface in SOC”, Devices, Circuits and Systems (ICDCS), International Conference, pp.673-67, 2012.

4. S. Yu, L. Yi, W. Chen, and Z. Wen, “Implementation of a Multichannel UART Controller Based on FIFO Technique and FPGA,” in Industrial Electronics and Applications.ICIEA,2nd IEEE Conference, pp. 2633 –2638, 2007.

5. Motorola Inc., “SPI Block Guide V03.06,” February 2003.
