Modeling Coordination as Resource Flow: An Object-Based
Approach
John Noll
Computer Engineering Department
Santa Clara University
500 El Camino Real
Santa Clara, CA 95053-0566
[email protected]
Bryce Billinger
Avaya Inc.
Denver, CO
[email protected]
AbstractWorkflow management systems provide guidance to individuals performing tasks in an organization. This is typically achieved via a central workflow engine that exe-cutes descriptions of organizational processes in order to guide and coordinate activities of individuals in the orga-nization.
In this paper, we present a process modeling approach in which processes are modeled as independent “process frag-ments” that represent activities performed by a single actor. Each fragment is a specification of the control flow from one activity to the next, that leads to the completion of a task. Coordination among concurrent activities performed by different actors is modeled as resource flow: dependen-cies among coordinated activities are represented by the re-sources shared by concurrent activities.
This allows processes performed by autonomous process performers distributed across a network to be coordinated without sacrificing individual autonomy.
Keywords:Workflow Modeling, Cooperative Work Support, Coordination, Software Process Modeling
1
Introduction
Workflow is the “automation of a business process, in whole or part, during which documents, information or tasks are passed from one participant to another for ac-tion, according to a set of procedural rules.” [1]
Workflow management systems provide active guid-ance, by providing prompts, instructions, and support-ing documents, to individual actors performsupport-ing tasks in processes. Initially, this was achieved by delivering documents to actors via email or other electronic means, hence the name “workflow”; in this case the routing of documents from actor to actor is specified by a simple, sequential process specification.
Contemporary workflow systems can execute more complex processes than simple sequential workflows.
These processes may involve iteration over a sequence of tasks, branching, and concurrent activities performed by multiple actors. The process descriptions are thus more complex, requiring specification of coordination and synchronization among concurrent activities, as well as both flow of control.
The conventional model of a workflow system is based on a client-server architecture. A central work-flow engine executes process descriptions to support the activities of actors that interact with the engine through client interfaces such as web-browsers or task-specific tools. As a centralized resource with global visibility of an organization’s active processes, the workflow en-gine can coordinate the activities of each actor in rela-tion to other actors, thus supporting collaborarela-tion and cooperation. A a database management system is of-ten employed to manage the data produced and modi-fied by the processes, and the data about the processes themselves. The advantages of this approach include synchronization of modifications to documents by con-current activities, and the ability to perform queries over the entire set of currently active processes.
This model has been employed to great success in workflow systems to support the business processes of companies and organizations. However, this model as-sumes all of an organization’s processes are managed by the workflow engine (or set of engines), all docu-ments are accessible to the engine and clients, and that all actors are connected to the engine through a client interface. Thus, the conventional client-server model presents obstacles when documents or actors involved in a processes are distributed in autonomous locations. In such cases, a central engine cannot control access to documents: this is the responsibility of the reposi-tory that contains the document (or other artifact). Sim-ilarly, the engine cannot support coordination based on the flow of control among the various activities, since this would require autonomous actors to submit to a
global control authority.
For example, open source software development can involve the concurrent activities of a large number of people working on a set of shared artifacts. However, each person is an independent, autonomous actor who performs work voluntarily, according to his or her abil-ities and resources. While they share a common goal, and may have well defined processes, each actor works independently without direction of a central authority. However, these actors could benefit from the kind of guidance and coordination support that workflow man-agement systems provide.
In this paper, we present a process modeling ap-proach that enables processes to be modeled as indepen-dent “process fragments” that represent activities per-formed by a single actor. Each fragment is a specifica-tion of the control flow from one activity to the next, that leads to the completion of a task. Coordination among concurrent activities performed by different ac-tors is modeled as resource flow: dependencies among coordinated activities are represented by the resources shared by concurrent activities.
2
Approach
Our goal is to model both control flow and coordina-tion with one simple, straightforward process modeling language. Our approach is based on the process
pro-gramming concept [9]: processes are modeled using a process programming language, called PML, that
re-sembles a conventional programming language in many ways. PML models control flow using familiar pro-gramming language constructs such as iteration, selec-tion, and branching. Processes in PML are modeled as sequences of actions. Actions are the atomic activi-ties of a process. Control constructs allow actions to be combined into tasks, which are linear sequences of actions; iterations, that specify a sequence of actions to be repeated; branches, specifying sequences of actions that can be performed concurrently; and selections in-dicating a choice of one of several possible actions. An example is shown in Figure 2. This is a PML descrip-tion of a simple software development process depicted in Figure 2.
2.1
Coordination and Resource Flow
The key to our approach is the observation that prod-ucts are produced and consumed by concurrent activi-ties. This is depicted in Figure 2.1.
This figure shows the example process from Fig-ure 2, augmented with important resources that are pro-duced and used by some of the process activities. Note
process example { action Analyze {} branch { sequence code { action Design {} action Implement {} action Compile {} action Debug {} action Commit {} } sequence test { action WriteTestPlan {} action WriteTests {} action RunTests {} } } }
Figure 1: Development Process in PML
that these resource flows mimic the temporal dependen-cies among the tasks that produce and consume them. For example, the Analyze activity has a temporal prece-dence to the Design and Write test plan activities. These are represented by the solid arrows. The analysis prod-uct also flows from the Analyze task to both the Design and Write test plan activities. Similarly, the Commit task has a precedence relationship to the Run tests task, which is also reflected in the flow of the code resource. These resource flows are significant because they can be used to coordinate activities when the explicit tempo-ral relationships are removed from the process model. Suppose, for example, that the actors tasked with per-forming this process are widely distributed across the world: the Analyst is in Chicago, the Programmer in Hong Kong, and the Tester in India. It would still be possible for the process to be executed by a central workflow engine, with each actor connecting to the en-gine from a client interface or Web browser. However, they would be subject to disruptions caused by network partitions, server maintenance, and other interruptions in service. Further, if the actors belong to different orga-nizations, there may be issues of autonomy that would prevent their subjecting to a central administration.
If we remove the explicit control flow relationships that are reflected in resource relationships, we can par-tition the model into process fragments that can be per-formed by a single actor, independently of other actors, yet in coordination with there activities. Figure 2.1 de-picts this decomposition. The process has been divided
(Programmer) Debug Implement (Programmer) (Programmer) Design (Test Engr.) Write Plan (Test Engr.) Write Tests (Programmer) Commit (Test Engr.) Run Tests Analyze (Analyst)
Figure 2: A Simple Software Development Process.
(Programmer) Debug Implement (Programmer) (Programmer) Design (Test Engr.) Write Plan (Test Engr.) Write Tests (Programmer) Commit (Test Engr.) Run Tests code analysis Analyze (Analyst)
Figure 3: Resource Flow
process example { action Analyze { provides { analysis } } ... action Design { requires { analysis } provides { design } }
Figure 5: Modeling Resource Flow
into three fragments, each associated with one of the three actors in the original model (Analyst, Program-mer, Test Engineer).
We add constructs to PML to specify pre- and post-conditions on the state of resources (documents, data, and other artifacts) that are produced and consumed by activities in a process. The result is a process model-ing language that models both resource flow and control flow.
A generic object model is used to represent the ar-tifacts and deliverables in a process. Each action may have requires and provides clauses. These specify pre-and post-conditions surrounding the performance of an action. The requires clause specifies the resources that are required by the action; the provides clause speci-fies the state these resources will in when the action is completed. The syntax for the object model is of the
form object name.attribute. A unique object name spec-ifies an object within the process. The format for the requires and provides clauses are in the form clause
object name.attribute op value .
Figure 2.1 shows a part the PML specification of Fig-ure 2 augmented with requires and provides predicates. In this figure, the provides predicate of the Analyze ac-tion specifies that an analysis object (in this case, a doc-ument) will be produced by the Analyze activity. The requires predicate of the Design action specifies that an analysis document is required by this activity before it can be begin; the Design activity produces a design ob-ject, as specified by its provides predicate.
2.2
Process Enactment Operating System
The Process Enactment Operating System (PEOS) is the engine for executing PML process descriptions. PEOS comprises several components, as shown in Fig-ure 2.2. The virtual machine is the core of the sys-tem, responsible for executing compiled PML process descriptions.
The virtual machine is a stack based interpreter that runs a PML compiled program and computes which ac-tions are available at any given time.
The kernel provides an interface to the outside en-vironment for the virtual machine. It acts as an event dispatcher, for events submitted by actors, and events resulting from changes to objects required by processes under execution.
(Programmer) Debug Implement (Programmer) (Programmer) Design (Test Engr.) Write Plan (Test Engr.) Write Tests (Programmer) Commit (Test Engr.) Run Tests code analysis Analyze (Analyst)
Figure 4: Process Fragments
Resource I/F CVS Email WWW File System User Interface User Interface Tools Process Core
Kernel Virtual Machine
models process resource events state process resource events Process Model Repository Active Process Repository Resources create/update resource process events
Figure 6: PEOS Architecture
storage managers and repositories where resources are stored. These queries are simply compiled forms of the provides and requires predicates in a PML specification. Thus, if an action requires an object, and the artifact the object is bound to does not exist, the virtual machine will block execution of the process containing the ac-tion until the object (artifact) exists.
Each actor in deploys a copy of PEOS to support his own processes. These copies monitor the environment for changes in resource state, in order to coordinate the activities of actors with other actors. The resulting en-actment environment is depicted in Figure 2.2. In this figure, the Analyst runs an instance of the Analyze pro-cess to create a new analysis document, which he posts to a web site for distribution to other interested parties. This creation event (step 2) is detected by the Program-mer’s PEOS engine (step 3); this triggers the creation of an instance of the Design and Implement process (step 4) on the Programmer’s behalf. After completing the Commit action (step 5), a modification event (step 6) is detected by the Test Engineer’s PEOS engine, which
creates an instance of the Test process (step 7).
3
Related Work
Process modeling approaches can be divided into four main categories, based on the control-flow model used.
3.1
Procedural Control Flow
Procedural modeling approaches resemble high-level programming languages; some are even based on pro-gramming languages. For example, APPL/A [11] ex-tends the ADA programming language with constructs specific to process and coordination modeling.
One of the main differences among procedural mod-eling languages is the fact that they depend on specific types of repositories. JIL is closely associated with the Pleiades object management system [12]. In MVP-L, a relational database is used to store product (artifact) objects [4]. In APPL/A, the repository used is “Triton, a persistent object system built on top of the EXODUS storage manager” [11]. The resource model for all of these examples is dependent on the specific object man-ager. Thus, the resource model is tightly coupled to its underlying implementation. This makes the coordina-tion of users crosses boundaries, such as a organizacoordina-tions or network difficult.
A rule-based control flow model comes from rule based programming languages. Rule-based models log-ical statements to determine which actions can be exe-cuted at any given time. The Merlin project is based on PROLOG and uses these rules to model processes [7]. Marvel also uses rules to model processes, with a object-oriented database in the back-end to keep the data [3]. A rule-based modeling language is a very pow-erful way to model processes; however, because the se-quence of activities is not explicitly represented, rule-based models can be difficult to understand.
The graph-based process models represent the rela-tionships among activities and resources with graphs. The Petri Net is one of the most used graph-based modeling examples. The projects SPADE/SLANG and
1: run Analysis_proc() 2: create(analysis) 3: notify(analysis) 5: commit(code) 7: run Test_proc(code) 6: notify(code) Web Server SCCS Analyst Test Engineer 4: run Design_proc(analysis) Programmer
Figure 7: Distributed Workflow Execution
PROMO are based on Petri-Nets [2, 6]. The benefit of graph-based models is they are a close match to the con-ceptual notion of a process as a sequence of activities, and are thus easy to create and understand. The graph-based control flow model is the closest model to the procedural model. While graph-based models may be easy to read and understand, their flaw is they are not as powerful as other process models. Because graph-based models do not have all of the capabilities as other process modeling languages.
Agent-based process modeling is a radically differ-ent approach to modeling process flow. An agdiffer-ent is a program that is design to make an intelligent decision of what to do next based on its current state. Agents can be distributed and can act independently of other agents. In agent-base workflow, agents are given goals that con-form to the objectives of the overall process; they then develop a work plan to achieve those goals. For ex-ample, the DartFlow project uses the World Wide Web and transportable agents to model process flow [5]. The Agent-based Process Management System (APMS) and the METEOR project use agents as a framework for workflow management [8, 10]. The work with agents has tended toward addressing control flow and has arated the data and resources from the model. The sep-aration is due to the fact that agent-based models are focused on a process state and not the process model. For agent-based processes, the process model can be an
ever changing model. The agent should be able to use the process state and the current environment, such as a process model, to intelligently determine the next state.
4
Conclusion
We have described a process modeling approach that combines the advantages of procedural process descrip-tions with the ability to decouple concurrent activi-ties so they can be distributed among independent, au-tonomous actors.
This approach has several benefits. Using this ap-proach, no direct communication is required between coordinated instances of execution engines; coordina-tion is achieved by indirect communicacoordina-tion through the resources shared among the concurrent activities. This means that an actor can even coordinate with another actor that is not following an explicit process, as long as the resources produced or modified by that are ac-cessible.
Also, products and other artifacts involved in the pro-cess are acpro-cessed from their native storage managers, making it possible for PEOS to co-exist with legacy sys-tems, and to enact processes that cross organizational as well as geographic boundaries.
Finally, because each actor runs a separate copy of the execution engine, PEOS maintains complete auton-omy of participating individuals.
