ON/OFF ROAD 2006 POWER IS NOTHING WITHOUT CONTROL

(1)

Stefan Everts

Yamaha L&M Motocross Team

MX 1 WORLD CHAMPION 2005

ON/OFF ROAD

2006

_wwwwww POWER IS NOTHING WITHOUT CONTROL

..pp iirr ee llll ii.. cc oo

(2)

SCORPION MT 90 S/T - PAGE 03 MT 80 / MT 80 RS - PAGE 04

MT 60 - PAGE 05 MT 60 RS CORSA - PAGE 06

SCORPION MT 90 A/T - PAGE 07 MT 70 - PAGE 08

MT 40 TRAIL - PAGE 09 MT 21 RALLYCROSS - PAGE 10

SCORPION PRO - PAGE 11 MT 44 LAGUNACROSS - PAGE 12

SCORPION MT 410 - PAGE 13 MT 320 - PAGE 14

SCORPION MT 32F/MT 32 - PAGE 15

INDEX

SCORPION MT 450 - PAGE 16

SCORPION MT 480 - PAGE 17 MT 16 GARACROSS - PAGE 18

MT 18 - PAGE 19 MINICROSS - PAGE 20

MT 43 PROFESSIONAL - PAGE 21

Tyres Range

ENDURO STREET ENDURO STREET ENDURO ON/OFF ENDURO ON/OFF E. COMPETITION CROSS CROSS CROSS CROSS TRIAL ENDURO STREET ENDURO STREET ENDURO ON/OFF ENDURO ON/OFF CROSS CROSS CROSS CROSS MINICROSS

(3)

ON/OFF RO

AD

-ENDURO STREET

SCORPION MT90 S/T

MT 90 S/T

Carve out your route on any road

• High speed stability even when fully loaded thanks to carcass stiffness • Rolling confort and cornering stability on dirty roads

• High mileage and wet trust

Size Pirelli-Tread Pattern IP Codes

Footnotes Front 100/90 - 18 100/90 - 19 100/90 - 19 110/80 R 19 90/90 - 21 90/90 - 21 56P 57S 57H 59H 54S 54H M/C M/C M/C M/C M/C M/C TL TL TL TL Scorpion MT 90 S/T Scorpion MT 90 S/T Scorpion MT 90 S/T Scorpion MT 90 S/T Scorpion MT 90 S/T Scorpion MT 90 S/T 1232200 1114100 1005000 1013000 1114200 1005300 18”

Footnotes Rear 120/90 - 17 130/80 - 17 130/80 - 17 130/80 R 17 140/80 R 17 150/70 R 17 64S 65P 65S 65H 69H 69H M/C M/C M/C M/C M/C M/C TL TL TL TL Scorpion MT 90 S/T Scorpion MT 90 S/T Scorpion MT 90 S/T Scorpion MT 90 S/T Scorpion MT 90 S/T Scorpion MT 90 S/T 1079100 1232300 1114000 1012700 1012800 1012900 19” 21” 17”

(4)

ON/OFF RO

AD

-ENDURO STREET

SCORPION MT90 S/T

One tyre, any surface

• Dual purpose tyre for modern large displacement enduro bikes • Increased mileage obtained with special block distribution design • Optimized compound for wet and dry grip

Footnotes

Front

100/90 - 19 57H TL MT 80 0750700

19”

Footnotes Rear 130/80 R 17 65H TL MT 80 RS 0710700 M/C M/C 17”

MT 80 / MT 80 RS

(5)

ON/OFF RO

AD

-ENDURO STREET

MT 60

MT 60

On or off road? just have fun

• Street oriented on- off tyre for high performance Enduro bikes, with excellent off road performance

• Modern bias construction for exceptional comfort and stability, with loaded bike also

• Special on – off knob design for more grip and traction on all surfaces and in all weather conditions

Footnotes Front 90/90 - 19 90/90 - 19 100/90 - 19 90/90 - 21 90/90 - 21 90/90 - 21 52P 52T 57H 54S 54T 54H M/C M/C M/C M/C M/C M/C TL TL MT 60 MT 60 MT 60 MT 60 A * MT 60 MT 60 0995500 0282900 0282200 1123700 0283400 0281800 19”

Footnotes Rear 110/90 - 17 120/90 - 17 120/90 - 17 130/80 - 17 140/80 - 17 110/80 - 18 120/80 - 18 60P 64S 64T 65H 69H 58T 62T M/C M/C M/C M/C M/C M/C M/C TL TL TL MT 60 MT 60 MT 60 MT 60 MT 60 MT 60 MT 60 0998000 0947500 0283000 0284000 0281900 0282800 0283500 21” 17” 18” Special Version: A* Honda: Falcon 400 ccm

(6)

ON/OFF RO

AD

-ENDURO STREET

MT 60 RS CORSA

On or off road? pure adrenaline

• Radial tyre designed for super-moto and recreation bikes, with ensured light handlin • Optimized pattern design for street use also on wet

• More grip with cornering pleasure provided by the Corsa super-moto compound

Footnotes

Front

120/70 R 17 58V TL MT 60 R Corsa 0802800

17”

Footnotes

Rear

160/60 R 17 69V TL MT 60 RS Corsa 0802700

17”

(7)

ON/OFF RO AD -ENDURO ON/OFF SCORPION MT 90 A/T

MT 90 A/T

• Tread pattern with big central knobs for straight riding stability and general V-shape orientation for high grip in traction and braking

• Optimized high-speed stability even when fully loaded thanks to size optimized carcass

• Good wet/dry grip thanks to new silica-tread compound, offering both mileage and regular tread wear performance

Footnotes Front 110/80 - 18 80/90 - 21 90/90 - 21 90/90 - 21 58S 48S 54S 54V M/C M/C M/C M/C TL Scorpion MT 90 A/T Scorpion MT 90 A/T Scorpion MT 90 A/T Scorpion MT 90 A/T 1004500 1005100 1005200 1417500 18” 21”

Footnotes 120/80 - 18 140/80 - 18 150/70 R 18 150/70 R 18 62S 70S 70S 70V M/C M/C M/C M/C TL TL Scorpion MT 90 A/T Scorpion MT 90 A/T Scorpion MT 90 A/T Scorpion MT 90 A/T 1004600 1017100 1635900 1421900 Rear 18” New Product 2006

Accept any challenge

(8)

ON/OFF RO

AD

-ENDURO ON/OFF

MT 70

On the road with an off road attitude

• The continuous contact with the ground and the optimised traction on all surfa-ces, also at lean angles are guaranteed by the tread pattern

• Improved straight stability, good street performance and superior water dispersi-on thanks to the large central blocks

Footnotes Front 2.75 - 21 80/90 - 21 90/90 - 21 45R 48R 54R MT 70 MT 70 MT 70 0352700 0352600 0352000 21”

Footnotes Rear 4.10 - 18 110/80 - 18 130/80 - 18 60R 58R 66R MT 70 MT 70 MT 70 0352400 0352500 0352300 M/C M/C M/C 18” M/C M/C M/C

MT 70

(9)

ON/OFF RO

AD

-ENDURO ON/OFF

MT 40

TRAIL ON/OFF

From road to trail

• Strong puncture resistant carcass for safe off-road use, able to withstand hardest rocky terrain

• Good wet and dry performance, high grip during braking and superior tread life for on road use provided by the optimised compound

Footnotes Front 2.75 - 21 3.00 - 21 45R 51R MT 40 Trail On/Off MT 40 Trail On/Off 0245300 0245500 21”

Footnotes 4.60 - 17 4.00 - 18 4.10 - 18 90/90 - 18 120/80 - 18 62R 64T 60R 57P 62S reinf MT 40 Trail On/Off MT 40 Trail On/Off MT 40 Trail On/Off MT 40 Trail On/Off MT 40 Trail On/Off 0245600 0246500 0245700 0246900 0245200 Rear 17” 18”

MT 40 TRAIL ON/OFF

(10)

ON/OFF RO

AD

-ENDURO ON/OFF

MT 21 RALL

YCROSS

Turn off the road and go cross-country

• High stability and cornering precision thanks to the carcass stiffness

• Tread pattern optimised for use on dirt and gravel roads, cross-country racing and desert tours

• Lasting road performance and knob tearing resistance due to the special off-road compound

Footnotes Front 80/90 - 21 90/90 - 21 48P 54R MST MT 21 Rallycross MT 21 Rallycross 0341400 0341100 21”

Footnotes Rear 120/90 - 17 130/90 - 17 120/90 - 18 130/90 - 18 110/80 - 18 120/80 - 18 140/80 - 18 120/80 - 19 64R 68P 65R 69R 58P 62R 70R 63R M/C M/C M/C M/C M/C M/C M/C M/C MT 21 Rallycross MT 21 Rallycross MT 21 Rallycross MT 21 Rallycross MT 21 Rallycross MT 21 Rallycross MT 21 Rallycross MT 21 Rallycross 0342300 0697800 0342400 0697900 0341500 0342000 0341000 0341900 17” 18” 19” M/C M/C

MT 21 RALLYCROSS

(11)

ON/OFF RO AD -ENDURO COMPETITION SCORPION PRO

PRO

Dedicated to enduro

• Improved materials for restistance to tearing, cuts, abrasion and wear

• Balanced construction for the right compromise between strength to endure fatigue and softness when surmounting obstacles

• Optimised distribution and geometry of pattern’s knobs for the adequate traction and braking

Footnotes Front 90/90 - 21 90/90 - 21 54M 54R M+S M+S Scorpion PRO Scorpion PRO 1526600 1526300 21”

Footnotes Rear 120/90 - 18 140/80 - 18 65M 70M Scorpion PRO Scorpion PRO 1526500 1526400 M/C M/C M/C M/C M+S M+S 18”

(12)

ON/OFF RO

AD

-CROSS

MT 44 LA

GUNACROSS

For soft ground

• Maximum weight reduction thanks to the specialized polyester carcass • Good power transmission on soft and wet terrain and unique self-cleaning

per-formance assured by the paddle block desig

• Optimised steering precision and traction provided by the small hard knobs on front

Footnotes

Front

80/100 - 21 51R MT 44 Lagunacross 0992400

21”

Footnotes Rear 120/100 - 18 110/90 - 19 NHS NHS MT 44 Lagunacross MT 44 Lagunacross 0992500 0992600 M/C 18” 19” (68) (62)

MT 44 LAGUNACROSS

(13)

ON/OFF RO

AD

-CROSS

MT 44 LA

GUNACROSS

For extreme use in mud and sand

• Constant performances in long lasting racing conditions on muddy and sandy ter-rain thanks to special polyester carcass

• More ground contact to avoid "dig-in"-problems giving better power transmissi-on in deep mud due to the new paddle design

• Improved front wheel control and steering precision provided by the special u-shaped front central blocks with different spacing

Footnotes

Front

80/100 - 21 51R MST Scorpion MT 410 1305300

21”

Footnotes Rear 100/90 - 19 110/90 - 19 NHS NHS Scorpion MT 410 Scorpion MT 410 1305100 1305200 M/C 19”

MT 410

(14)

ON/OFF RO

AD

-CROSS

MT 320

For soft to medium terrain

• Reduced weight without compromising on stability and cornering behaviour pro-vided by the three-ply polyester carcass

• Sharper knobs for maximised traction on medium and soft terrain, mostly in cor-nering situation where it offers excellent power transmission

• Optimised braking control and steering precision given by the numerous front shoulder knobs bonding together

Footnotes Front 80/100 - 21 80/100 - 21 51R (51) NHS MT 320 MT 320 H * 0698200 1343500 21”

Footnotes 100/100 - 18 110/100 - 18 100/90 - 19 110/90 - 19 NHS NHS NHS NHS MT 320 MT 320 MT 320 MT 320 0699300 0699400 0700000 0700100 M/C Rear 18” 19” (59) (64) (57) (62) Special Version: H* Honda: XR 150 R Brazil

MT 320

(15)

OFF RO

AD

-CROSS

MT 32F/MT32

Choice of champions

• Increased heating resistance in race conditions and reduced weight without com-promising on stability and cornering behaviour given by the special polyester car-cas

• Maximum traction on intermediate terrain thanks to the tyre contour and knob design

• Optimised braking control and steering precision provided by aligned side knobs on front wheel

Footnotes Front 90/100 - 20 80/100 - 21 80/100 - 21 56R 51R 51R MST MST MST MT 32F MT 32F MT 32A 1586000 1585900 1596100 20” 21”

Footnotes 110/100 - 18 120/100 - 18 100/90 - 19 110/90 - 19 120/90 - 19 NHS NHS NHS NHS NHS MT 32 MT 32 MT 32 MT 32 MT 32 0249800 0249900 0992200 0992300 1402100 M/C M/C M/C Rear 18” 19” (64) (68) (57) (62)

MT 32F/MT 32

(16)

OFF RO

AD

-CROSS

SCORPION MT 450

MT 450

For medium to hard terrain

• Heating resistance under severe and long lasting racing conditions on medium to hard terrain

• Enlarged ground contact avoiding knob tear off and constant traction due to the new contour and twin-knob design

• Precise steering and better lean holding given by the more flexible knob structu-re and low section design

Footnotes Front 90/100 - 20 80/100 - 21 56R 51R MST Scorpion MT 450 Scorpion MT 450 1209000 1208900 20” 21”

Footnotes Rear 100/90 - 19 110/90 - 19 NHS NHS Scorpion MT 450 Scorpion MT 450 1209200 1209300 M/C 19”

(17)

OFF RO

AD

-CROSS

SCORPION MT 480

For hard terrain

• Good damping performance, optimised stability and better puncture-resistance on hard terrains or “supercross” races provided by the special stiff carcass with pet textile cord

• Reduced central knob height to prevent knobs bending under strong accelerati-on and to have a wider caccelerati-ontact area for grip also at lean angle

• Safe braking and maximum lateral grip, even on rock faces guaranteed by the front tyres knobs with different stiffness

Footnotes

Front

80/100 - 21 51R Scorpion MT 480 1030400

21”

Footnotes 100/90 - 19 110/90 - 19 NHS NHS (57) (62) Scorpion MT 480 Scorpion MT 480 1030500 1030600 M/C Rear 19”

MT 480

(18)

OFF RO

AD

-CROSS

MT 16 GARACROSS

All terrain

• Off-road tyre optimised for allround use and training • The tread design provides better self-cleaning • High wear resistance thanks to a special compound

Footnotes Front 3.00 - 21 80/100 - 21 51R 51R MST M/C MT 16 Garacross MT 16 Garacross 0249400 1418500 21”

Footnotes 4.00 - 17 4.00 - 18 4.50 - 18 110/100 - 18 120/100 - 18 120/90 - 19 NHS NHS NHS NHS NHS NHS 62M 64M 70M (64) (59) (66) MT 16 Garacross MT 16 Garacross MT 16 Garacross MT 16 Garacross MT 16 Garacross MT 16 Garacross 0249300 0248900 0249000 1418700 1418600 1426000 Rear 17” 18” 19”

MT 16 GARACROSS

(19)

OFF RO

AD

-CROSS

MT 18

For medium terrain in all conditions

• Off-road tyre for use on medium terrain or for training in all condition • High stability, cornering precision and good puncture resistance thanks to carcass

stiffness

• Long lasting off-road performance and knob tearing resistance provided by spe-cial off-road compound

Footnotes Front 80/100 - 21 80/100 - 21 51R 51R M+S MST MT 18 Heavy Duty MT 18 1565800 0698300 21”

Footnotes 100/100 - 18 110/100 - 18 120/100 - 18 120/100 - 18 140/80 - 18 100/90 - 19 110/90 - 19 NHS NHS NHS M+S M+S NHS NHS (59) (64) (68) 68M 70M (57) (62) M/C M/C MT 18 MT 18 MT 18 MT 18 Heavy Duty MT 18 Heavy Duty MT 18 MT 18 0699500 0699600 0699700 1565600 1565700 0700500 0700600 M/C M/C Rear 18” 19”

MT 18

(20)

OFF RO

AD

-MINICROSS

MINICROSS

For the joungest champions

Footnotes Front 2.50 - 10 60/100 - 12 60/100 - 14 70/100 - 17 70/100 - 19 70/100 - 19 NHS NHS NHS NHS NHS NHS 33J 36M 29M 40M 42M 42M MT 32A MT 32A MT 32A MT 32A MT 32A MT 18 1350900 1426100 1351300 1351400 1305000 1343600 10” 12” 14” 17” 19”

Footnotes 2.75 - 10 80/100 - 12 90/100 - 14 90/100 - 16 90/100 - 16 NHS NHS NHS NHS NHS 37J 50M 49M 51M 51M MT 320 MT 320 MT 320 MT 32 MT 18 1351000 1351100 1351200 1304900 0736600 Rear 10” 12” 14” 16”

MINICROSS

(21)

OFF RO

AD

-TRIAL

MT 43 PROFESSIONAL

Footnotes

Front

2.75 - 21 45P DP TL MT 43 Pro Trial 1414400

21”

Footnotes Rear 4.00 - 18 64P DP TL MT 43 Pro Trial 1414500 18”

For amateur

MT 43 PROFESSIONAL

(22)

(23)

POWER IS NOTHING WITHOUT CONTROL

SCORPION MX: THE CHOICE OF CHAMPIONS.

45 World Titles is Pirelli’s way of evolving the perfect tyre. The Scorpion MX range is this: the ultimate for any track, for any terrain, for any rider. SOFT 410: ideal on sand and mud. MIDSOFT 32: pure motocross. MIDHARD 454: the ultimate for intermediate terrain.

HA R D 486: unequalled on hard and stony

terrain. EXTRA: the best for training on all terrain.

(24)
