SIMATIC Field PG M3
SIMATIC Programming device
Technical Presentation
SIMATIC Field PG M3
Perfect for
Project engineering Commissioning Service MaintenanceHighlights
Rugged, high-performance hardware Intel Core i processor technology
15,6“ Widescreen Display, 16:9 size, Full HD (1920x1080), LED Backlight
2x Gigabit Ethernet
Bluetooth
SIMATIC Engineering Software pre installed
Mobility due to powerful rechargeable battery (power for up to 3,5 h)
All interfaces integrated
Easy-to-replace hard disk unit
Interfaces
Terminal for external monitor or projector; transfer of analogue and digital pictures simultaneously possible; high quality of display in combination with digital flat screens
DVI-I
Standard connection to current S7 controllers or panels via Profibus
MPI/Profibus
Combined serial V.24 and TTY interface for connecting S5 modules
COM 1
2 full-fledged network access with high data transfer rate (10 / 100 / 1000 MBit)
2x Gigabit
Ethernet
Interfaces
Two interfaces on the side of the device – Even USB sticks with a "strange shape" can be connected
USB 2.0
High current-carrying capacity: Ideally suited for external data carriers such as hard disks etc.
USB 2.0
480 MBit/sec. maximum data transfer rate for peripheral devices and external data storage devices
USB 2.0
(5x)
For programming SIMATIC Micro Memory Cards, Memory Cards of S7-300, S7-400 and S7-1200 controllers and EPROMs of S5 controllers
Programming
interfaces
Interfaces & drives
Adapted for SMC and Multimedia cards (SDHC, MMC, xD, Memory Stick)
Cardreader
Fast wireless data transfer to PDA, mobile phones or digital cameras
Bluetooth
lateral HDD-slot for quick change of hard disk drive.
Harddisk
DVD-RW drive included
DVD-RW
Headphone output and microphone input of the high-definition audio interface. Optimal for Voice-over-IP headsets.
Audio
Can be connected to any telephone network in the world, for faxing and access to Internet
MODEM
Perfect for ISDN modem, Compact Flash Reader, interface cards, etc. (Express Card/54 / PC Card Types I,II )
Express Card/
PC Card
Wireless LAN
Industrial WLAN
Wireless Local Area Network
IEEE Standard
802.11a (5 GHz)
802.11b (2,4 GHz)
802.11g (2,4 GHz)
802.11n (2,4GHz/5GHz)
802.11a
Few faults – perfect with Scalance Industrial
WLAN products (11 MBit/s)
802.11b, g
Standard – Optimal for hotspots and
corporate networks
(11/54 MBit/s)
802.11n
Keyboard and touchpad
Rugged, high-quality touchpad with adjustable sensitivity, scrolling capability etc.
Touchpad
Easy to read status LED inform about device status independent to closed or open display e. g. battery or power supply operation, WLAN on/off or adjustment of display brightness
Status LED
Fast access to important functions such as locking the programming, displaying on-screen menu, WLAN on/off, touchpad on/off, hibernation, standby, display brightness
Hotkeys
Ergonomically designed keyboard. It corresponds to the key distance of a Standard desktop keyboard. Resistant-to-wear laser inscriptions
Mainboard – chipset – memory
Brand new Intel Core i processors
Intel Core i5-520 processor (2,4 GHz)
QM57 Chipset
DDR3 memory with 1066MHz
PCIe V2.0
Turbo Boost
max. 8GByte* RAM
Specials
2 TCPI/IP interfaces for parallel
working in 2 different networks
Brand new PC HW combined with
SIMATIC interfaces
Intel i5-M520 CPU
brand new Intel Core i processor technology
Intel Core i5 processor
2 physical cores
Intel® Hyper-Threading-technic provides
intelligent quadruple multitasking – each
core can run two tasks simultaneously
TurboBoost / Powersharing Technology
Effective to applications, which are not
using multithreading or Multicore
Depending on load the cores increase
their perfomance (up to 2,66GHz in Dual
Core mode, up to 2,93GHz in single core
mode)
Increase of integrated garphics frequency
is possible, if both cores are not working
to capacity
Performance
PassMark® Rating mit CD- und Disk-Mark
530 750 583 986 0 200 400 600 800 1000 Field PG M 2 Standard Field PG M 3 Standard Field PG M 2 Pre mium Fie ld PG M 3 Premium +42% +69%
Significantly increased performance compared to Field PG M2. Significant
positioning of Standard u. Premium version.
Mainboard – Graphics
Control of the integrated display and an external display with different resolutions (e.g. desktop via both screens)
Dual Display
15,6“ widescreen-display (16:9 formate), anti-glare with high luminance density Full HD resolution with up to 1920 x 1080 pixels
Optimized for working with SIMATIC Software based on TIA Portal.
Resolution
Brand new Intel shared memory graphics with high 2D and 3D performance. Support of DirectX 10 and Ready for Windows 7
Integrated
graphics
Replaceable hard disk
Easy-to-replace hard disk unit
Project engineering
Commissioning
Service
Maintenance
Use Cases:
Fast alteration of software
Software version factory hall A
Software version factory hall B
Separation of service and office
Service – hard disk (administrator)
Replaceable hard disk– optional accessory
SIMATIC Field PG M3 accessories Hard disk
kit and serial ATA adapter
For simple changing between different software versions
For creating a duplicate of the existing system
Separation of office and service environment
Use Cases
Simple creation of different software versions
Office environment or service software installation
Rapid creation of duplicates of the hard disk
If necessary, immediate continuation of work with the duplicate is possible
In combination with SIMATIC IPC Image & Partition Creator the perfect backup of
data in industrial automation.
Other special features
Ruggedness
Magnesium injection molding housing
Body completely made of Magnesium
palmrest made of plastics
Stable and torsion-resistant keyboard
assembly for optimized ergonomics
The tool for the SIMATIC
Ergonomic, stable handle
SIMATIC interfaces „on board“
15,6“ 16:9 display in HD ready or Full HD
resolution enables optimum, fatigue-free
working
SIMATIC Field PG M3 Software
Operating systems
Windows XP Professional (32-bit)
Windows 7 Ultimate* (32-bit)
As MUI versions easy to change between
diverse languages
Application software
(for Win XP)Nero Essential 7
Perfect creation of DVDs/CDs
Power DVD V7
Optimum replay of films on DVD
Windows 7SIMATIC Field PG M3 Engineering Software
SIMATIC Software
Already preinstalled:
STEP 7 Professional
STEP 7 Basic
STEP 7-Micro/WIN
WinCC flexible Advanced
STEP 5
(XP only)
Ready for immediate use
Optimally matching software – For
immediate productive use
Licenses for enabling the SIMATIC
software can be ordered with the Field
PG M3
Data backup concept
SIMATIC IPC Image & Partition Creator
Support of Solid-State Drives and compact flash
Field PG M3
SIMATIC IPC (since C-generation)
Hardware
“1ClickImage”
Differential partition backups or incremental file backups
Direct start in running operation w/o installation from USB-flash drive or CD
OS independent use
Scheduled/cyclical backup
Wizard for backup / recovery / deletion of data
Irretrievable, final deletion of data
Installation on HDD isn‘t necessary
Increasing/decreasing the size of existing system and data partitions w/o data loss
Backups may be made during operation („hot processing“)
SIMATIC IPC Image & Partition Creator V3.0
Compatible to 64-Bit operating systems
