The Nederman Design Guide
This Design Guide is especially produced for consulting engineers. The purpose is to facilitate the planning and design of capture at source extractionsolutions and supply systems. At your service you also have a unique set-up of software and design tools.
More information about our standard products can be found in the Nederman Product Catalogue.
Nederman
Design Guide
Introduction
High, mid and low vacuum ... 2
Applications with explosion risks ... 3
Application areas ... 4–5 Nederman Tools for Consulting Engineers ... 7
Guides ... 8
Extraction solutions industrial applications ...8-9 Exhaust extraction systems ... 10
Hose and cable reels ... 11
Low vacuum solutions ... 12
Arms ... 15
Filters ... 22
Filter cartridges ... 25
Oil mist filters ... 28
Fans and control equipment ... 31
High vacuum solutions ... 39
Vacuum units ... 44 Arms ... 51 Valves ... 53 Starters ... 55 Dust collectors ... 56 Pre-separators ... 61
Dust extraction kits ... 63
Ducting Accessories ... 64
Mid vacuum solutions. ... 67
Vacuum units ... 68
Filters ... 70
Compact vacuum units ... 71
Starters ... 72
Accessories ... 73
Vehicle exhaust systems ... 75
Accessories ... 75
Stationary vehicles ... 76
Vehicles in motion ... 80
Emergency vehicles ... 89
Hose and Cable Reels. ... 98
Capturing at source
The most efficient way to capture air pollution in industry is as close to the source as possible. One avoids extracting large air volumes and above all the pollutant is not spread around in the room. This is what we refer to as “captur-ing at source”. Contaminants may be in the form of solid waste, dust, fume, mist and gas, produced, for example, in a metalworking process such as welding or grinding or in a handling process involving foodstuffs or chemicals. The extraction of exhaust fumes from car and truck engines is another typical example of solving problems at source.
Optimal solutions
Capture at source technology can be divided in two main categories:
• High vacuum = high speed extraction - low air volume
• Low vacuum = low speed extraction - high air volume
Sometimes we also refer to mid vacuum. This technique is applied in applications with light dust and shavings where the extraction capacity can be adjusted in order to save energy and reduce noise.
Nederman masters the whole spectra of vacuum technologies – from high to low vacuum. Therefore, we always can offer the most practical and cost-effective solution from our extensive range of products and systems. See also product guides on pages 8-11
High, mid or low vacuum – we master them all
High vacuum Low vacuum
Type of contaminant Airborne particles and solid waste Airborne particles
High vacuum
High vacuum, i.e.high speed extraction is done very close to the source or directly on the source. Typical applications are floor and machine cleaning, extraction from high speed tools such as grinders, cutters, sanders and suction from welding guns. The high vacuum technology allows solutions with flexibility over the whole working area combined with low air volumes.
Low vacuum
Low vacuum, i.e low speed extraction, allows capturing the pollutants at a greater distance due to the higher air flow. Low speed capturing is recommended for extraction of fumes, dust exhaust and other airborne particles. The extraction is carried out with extraction arms, exhaust nozzles, enclosures and canopies over machines.
The consequences of fires or explosions can be extensive and include rupture of afilter systems and recirculation of contaminated air with subsequent health risks and damage to plant. Although it is impossible to completely eliminate the risk of creating explosive mixtures, it is possible to reduce the risk of ignition and the effects of an explosion.
Directives for explosive applications
Within the EU, harmonized regulations have been in force since 1994, whereby employers are required to assess the risk of creating an explosive atmosphere in their production environments. Two other directives became mandatory in 2003 concerning explosive applications:
European Directive 99/92/EC/ATEX 137
This directive states that it is the responsibility of the user/ employer, to assess and classify the working environment. Thus, the risk of working in a potentially explosive atmosphere is the first criterion that has to be examined when choosing an extraction arm, filter or fan for any operation or process. The Nederman Risk Assessement Report will be the basis for the choice of products for which we, as manufacturer and supplier, will be responsible with regard to product compliance.
European Directive 94/9/EC/ATEX 100a
The European Directive 94/9/EC applies to the equipment manufacturers and harmonizes the technical and legal standards to which equipment for use in potentially explosive atmospheres is manufactured.
Nederman offers a range of Ex approved and marked products which are manufactured according to these requirements.
Risk Evaluation Form
The Nederman Risk Assessment Report (published on www.nederman.com), filled in by the customer, qualifies and quantifies the pertinent aspects of the production process, including, for example, the type and composition of the dust, the air flow requirements and the extraction system. We then recommend suitable equipment for the described application and guarantee its functionality with respect to the information supplied. Each project is individually documented in detail for future reference. Where dust is concerned, assessment is based on the risk of combustible dust being present in the atmosphere, classified on a scale from continuous presence of explosive concentrations to unlikely presence with limited short term risks. A similar scale is used for assessing the risks involved when dealing with gases.
Applications with explosive risks
What is a dust explosion?
An explosion is the rapid combustion of a mixture of dust and gas – usually air. Dust concentrations have to be high enough to feed the combustion chain reaction.The speed of the resulting shock wave is less than 340 m/s. If the mixture is highly turbulent there could be a more violent explosion and the shock wave could reach 2,000 m/s, causing extensive damage. Potential ignition sources are also important to assess. For example, sparks from grinding or welding, electrical sparks, and glowing material from the work process.
Examples of different types of explosive dust
Organic dust in the food industry: Baking flour, soup powder, spices, flavouring Synthetic organic dust: Powder paint, plastic, grinding dust Metal dust: Aluminium, magnesium, titanium, and chromium Pharmaceutical dust: A great number of powders
Vehicle repair shop
Exhaust rail system
Portable high vacuum unit Exhaust hose reel Windscreen arm E-PAK
Hose and cable reels FilterMax
Body work arm
Nederman offers practical and cost-effective products and complete systems for a wide range of applications and industries. These can be regarded from three main aspects: • type of contaminants
• the operations or processes carried out • the materials worked on or handled.
• Aerospace • Automotive
• Building and construction • Chemical and pharmaceutical • Composites
• Education and training • Electronics
• Emergency stations • Engineering • Food and beverage • Glass and ceramics • Heavy engineering • Joinery and carpentry • Laboratories
• Medical and veterinary • Metal fabrication • Military
• Museums and conservation • Painting
• Paper and printing • Recycling • Schools
• Textiles and clothing • Transportation
• Vehicle Inspection Centres • Vehicle Repair shops • Welding
• Workshops
Covering most industries and application areas
Hose and cable reels Exhaust hose reel Exhaust rail system
Metal fabrication industry
- Welding- Machining
Metal fabrication industry
- Oil mist filtrationOriginal extraction arm Hose and cable reels Portable high vacuum unit E-PAK or L-PAK
FilterMax NEX HD extraction arm
FilterBox On-torch fume extraction FilterCart Extraction arms FilterMax Oil mist filter
Bench top extraction
Portable high vacuum unit Modular filter system
Cleaning outlets
Wood work shop in schools
Machine extractions - directly from extraction outlets or existing extraction points on the machine
Mid Vacuum unit and filter unit
Food/Pharma industries
Hose reels for hygienic demands FilterBox
NEX Extraction arm Bench top extractor arms
Based on more than 60 years experience of extraction solutions, Nederman offers a set-up of tools and services especially developed for consulting engineers. With these your planning and design of dust and fume extraction systems will be considerably easier and more cost-effective. Our services include everything from complete project design and specifications to installation, maintenance and after-sales service.
NEDQuote
NEDQuote is a powerful design and calculation program developed by Nederman. It offers a unique opportunity to test different set-up scenarios and design complete installa-tions. The following basic planning data is all we require in order to present a complete solution:
• the type of operation or process • the number of extraction points
• the floor area and height of the premises.
Solutions can be displayed in 2 or 3 dimensional drawings and include full product specification lists, pressure drop diagrams and pricing alternatives from single product to project level.
Ready-to-use symbols and product templates
Visuals/graphics, including product and parts
specifications, of Nederman products in DWG/DXF format for 2-D and 3-D presentation. The drag-and-drop scale symbols can be used for all design and documentation applications.
Available via our website.
www.nederman.com
The Nederman international website, with a special area for Engineering Consultants, contains extensive product and application information.
Nederman Extraction Solutions in Industrial Applications
The table gives a brief overview of the Nedermanproducts and systems. When designing a system it is im-portant to take into account all the parameters i.e. type of contaminants, number of extraction points, work space area, air flow, air volumes and temperature of the
ex-tracted air at the inlet. Other parameters to consider are required filtration effici ency, possible recirculation of air and potential safety hazards etc. On the following pages you find detailed information.
Extraction Arms
to be combined with fans or central filter/fan systems Fans Filters Central/fixed units Portable and Mobile units
LO W VA CUUM Non-e xplosiv e applications Light to medium
duty applications Medium to heavy duty applications applicationsSpecial working areaExtended
HIGH VA CUUM Non-e xplosiv e applications HIGH/L O W VA CUUM Explosiv e and/or h ygienic applications T Rail System Length up to 50 m Extension arm Max length: 4.2 m and 6.0 m Bodywork arm 700 - 1000 m3/h 5 m Windscreen Arm
(for car windscreen adhesive extraction Max 800 m3/h 4 m N fans 500 – 4000 m3/h NCF fans 1600 – 17000 m3/h NEX HD 1000 – 1900 m3/h 2 – 5 m Standard 600 – 900 m3/h 2 – 3 m Original 700 – 1000 m3/h 2 – 5 m Telescopic 600 – 1000 m3/h 0.9 – 1.6 m NEX MD 900 – 1300 m3/h 2 – 5 m
Swing arms Extraction nozzles
NEX DX EX ΙΙ 2D (Dust) 900 – 1700 m3/h 2 – 5 m NEX D EX ΙΙ 3D 900 – 1700 m3/h 2 – 5 m NEX S
EX ΙΙ 2D/G (Dust and Gas) (Acid proofed design) 700 – 1700 m3/h 2 – 4 m
NCF EX fans
Extraction Arms
to be combined with fans or central filter/fan systems Fans Filters Central/fixed units Portable and Mobile units
LO W VA CUUM Non-e xplosiv e applications Light to medium
duty applications Medium to heavy duty applications applicationsSpecial working areaExtended
HIGH VA CUUM Non-e xplosiv e applications HIGH/L O W VA CUUM Explosiv e and/or h ygienic applications OIL MIS T
Type of contaminant Vacuum kPa Airflow m3/h per extraction point Particle velocity m/s
Low vacuum Airborne particles 1 – 3 up to 1900 m3/h up to 25
Mid vacuum Airborne particles and light waste 6 – 12 200 – 600 m3/h 15 – 20
High vacuum Airborne particles and solid waste 15 – 50 80 – 400 m3/h 20 – 90
FilterMax DF
2200 – 13000 m3/h
FilterMax F
1500 – 10000 m3/h FilterMax SFC(Safety recirc. filter) 2000 – 4000 m3/h FilterMax C25 1500 – 3000 m3/h E-PAK 150 – 860 m3/h FlexPAK800 – 1300 m3/h RBU-systems 1300 – 3200 m3/h VAC Systems 1500 – 5000 m3/h L-PAK 150 – 400 m3/h C-PAK
1500 – 2500 m3/h FlexFilterModular filters 1600 m3/h Midvac (Medium vacuum) 1000 – 2600 m3/h P-series cleaning equipment
for dry dust FilterBox
MFS Modular Filters
FilterMax DX
(Low vacuum) with safety devices for explosive applications 3600 – 7200 m3/h
NOM Oil mist filter and fan units
400 – 2800 m3/h 0.37 – 2.2 kW
FlexFilter EX
(High vacuum) with safety devices for explosive applications 2200 – 5000 m3/h Modular filters 1600 m3/h P 221 EX FilterCart/ FilterCart Carbon
for odour solvents
FilterBox
FE 840/841
ALU 150/250 is a robust, tailor-made, exhaust extraction systems.
• ALU 150: for cars
• ALU 250: for heavy goods vehicles, construction plant and military use
Nederman Exhaust Extraction Systems
• Rail length: 2.5 – 100 m • Hose 5 m long, Ø 100 mm • Temp: up to +150°C • Manual disconnection • Trolley moved by hand • Large variety of nozzles
available
Vehicles in motion Nederman MagnaSystem PTS
• Emergency stations
Vehicles in motion Nederman ALU 150/250 Nederman ALU-FLOWLINE
• Car / truck manufacturing • Vehicle inspection
centre
Stationary cars Single & Twin exhaust extractors Reels Track Arm
• Workshops
With balancer With suspesion
cord Twin with suspen-sion cords
Manual with spring Ø 75 – 150 mm Length: 5 – 10 m Motor driven Ø 100 – 150 mm Length: 7.5 – 10 m Operating area: 180° MAGNARAIL
The ultimate solu-tion with outstanding performance. Serves up to 4 vehicles at a time. MAGNATRACK HS For high-frequency/high-speed applications. MAGNATRACK S An economical alternative for lower speed and lower
MAGNATRACK B
For stations with less usage demands. Serves 1 vehicle at a time.
MAGNASTACK
The reliable solution for vertical exhaust stacks. Serves 1 vehicle at a time.
PTS - Pneumatic Track System
Perfect for stations where vehicles vary (used in more than one station). Serves • For continuous production lines
• Based on the ALU150 system • With motorized return in a separate track • Motorized hose hoist
• Rail length: 2.5 – 100 m • Temp: up to +150°C
• Manual or automatic disconnection • Large variety of nozzles available For Stationary vehicles:
• Hose 5 m long, Ø 150 mm Vehicles in motion:
• Hose 6 m long, Ø 100 (cars), Ø 150 mm (trucks)
Stationary cars/
Vehicles in motion Rail System 920/400 Rail System 920/1500
• Workshops • Vehicle inspection
centre
Application Guide Hose and Cable Reels
Hose &
cable reels Series
Air Water / High pr
essur
e w
ater
Oil Grease Oxy
gen / A cetylene / LPG Vacuum Electricity 882 883 888 893 889 884 Hose &
cable reels Series
Air Water / High pr
essur
e w
ater
Oil Grease Oxy
gen / A cetylene / LPG Vacuum Electricity 886 881 876 782 793
Generally speaking, low vacuum products and systems are used for extraction purposes where the air is contaminated with small, light and low velocity particles that can be regarded, for design purposes, as acting like a gas. Welding fume and baking flour dust are good examples of potentially hazardous substances that are best dealt with at source. This means that:
• their removal uses high volumes of air, 600 – 2000 m³/h • they are extracted via large diameter ducting at relatively
low speeds, around 10 – 25 m/s
• the pressure drops that have to be overcome are low, normally in the region of 1 – 3 kPa.
Typical applications for low vacuum solutions
• engineering processes such as welding • grinding and oil mist recycling
• food and pharmaceutical processes involving the handling of powders or chemicals. In these last instances there is often a latent explosion risk and specially adapted prod-ucts are available for dealing with such situations.
Bench top applications
Bench top extraction of fumes, vapours and light dust is often used in small-scale or light industrial applications such as soldering and gluing or working with solvents. Schools, laboratories, health clinics and medical research institutions are some of the workplaces that can benefit from these solutions. Detailed product information about bench top extraction can be found in the Nederman Product Catalogue.
NEDQuote
NEDQuote is a powerful design and calculation program, and a unique tool in which different set-up scenarios for arms, filters and fans can be investigated. See Nederman Customer Support for further details.
Capture at source – Low vacuum solutions
Fume Dust Air volume m³/h Duct diameter mm Air velocity m/s Duct
diameter mm velocity m/sAir up to 600 125 10-15 100 15-25 700-1100 160 10-15 125 15-25 1100-1700 200 10-15 160 15-25 1700-2600 250 10-15 200 15-25 2600-4200 315 10-15 250 15-25 4200-6800 400 10-15 315 15-25 6800-12000 500 10-15 400 15-25
How to dimension
In the dimensioning example it is assumed that only 50% of the extractors are in operation simultaneously. The calculation then provides the approximate maximum airflow and vacuum requirements so that a suitable fan can be chosen. If a careful analysis of frequency of use is carried out, and dampers and inverter equipment are installed, it will often be possible to further reduce the size of the fan.
Dimensioning the ducting
The following simplified dimensioning procedure can be used for any extraction system:
1. Draw a simple sketch
Mark the proposed locations of the extractors, the filter (if any) and the fan. Note the length of the ducting and how many 90° bends are required. In this example it has been assumed that there are 5+5+5+5+5 m of ducting and 5 bends.
2. Choose extraction arms
Two 4 m and two 2 m NEX HD arms have been chosen.
3. Calculate the total airflow required
The arms will be used for heavy welding, requiring 1200 m³/h per arm. This means a potential maximum airflow of 4800 m³/h if in operation simultaneously. In practice, however, it is most probable that only 2 arms will be in operation at the same time, which means that the design airflow rate will only be 2400 m³/h (1200 m³/h + 1200 m³/h = 2400 m³/h, 50% use).
4. Calculate the required vacuum
Determine the required vacuum by carrying out the following steps:
a) Read off the pressure drops for the 4 m and 2 m NEX HDs working at 1200 m³/h. The model requiring the greatest vacuum will provide the dimensioning value. In this case, it is 340 Pa for the 4 m arm.
Note! Only one arm shall be calculated.
b) Add 5 Pa for every metre of duct, measured from the arm furthest away from the fan. 20 metre of duct in this example.
c) Add a further 15 Pa for every 90° bend. 5 bends in this example. d) Add 1200 Pa for the filter, FilterMax F, single module. (With a filter area of 60 m² and an operational load of 40 m³/m²h the filter unit can handle an airflow of 2400 m³/h). See page 25 for suitable filter cartridge. The required vacuum is: 340 + (20 x 5) + (5 x 15) + 1200 = 1715 Pa A= Filter B= Fan
5. Choose the fan
x= airflow y= static pressure
The required fan capacity is 2400 m³/h at 1715 Pa. A suitable fan is the NCF 30/25.
In this example, the following duct dimensions are required:
Airflow, m³/h Duct, mm From arm 1 to arm 2 1200 200 From arm 2 to arm 3 2400 250 From arm 3 to arm 4 2400 250 From arm 4 to filter 2 400 250 From filter to fan 2 400 315 From fan to outlet 2400 315
The connection from the extractor arm to the main duct should always be at least 160 mm in diameter.
For more precise dimensioning of ducting, please contact your supplier.
Note!
When using the NEDQuote design and calculation program, different installation set-ups can be quickly investigated to determine an optimum solution.
Always check that there is a sufficient incoming air supply to the workplace. In a common ducting system, with one fan serving several extractors, there is a risk of temporary fluctuations in suction capacity and pressure drop, but these problems are easily overcome by using dampers and frequency controlled fan.
How to dimension High Vacuum Systems see page 40. N2 9 NCF30/25 NCF 30/15
Extraction arms for use in non-explosive environments
Positioning of extraction arms Standard Telescopic Original NEX MD NEX HD
Light applications
Extraction of fumes, vapours and dust. Schools, limited spaces, small booths.
Required airflow: 600 – 900 m3/h
X X X
Medium applications
Extraction of fumes, vapours and dust. Small workshops, metal fabrication
shops Required airflow: 900 – 1300 m3/h X X X Heavy applications
Extraction of heavy smoke, vapours and dust. Heavy engineering workshops, welding, laser cutting, grinding with spatter.
Required airflow: 1300 – 1900 m3/h
X X
Standard Telescopic Original NEX MD NEX HD
Recommended airflows m3/h 600-900 600-1000 700-1000 900-1300 1000-1900
Maximum fume temperature °C 70 70 70 70 120
Noise level at hood dB(A) 67 70 63-75 * 63
Damper Optional Optional Standard Standard Standard Hose material PVC covered
Aluminium foil Polyester fabric PVC covered Polyester fabric PVC covered Polyester fabric PVC covered PVC covered Polyester fabric Glass fibre reinforced PVC, Connection diameter mm 160 150/160 150/160 150/160 200
Note Built in wall
bracket 360° swivel 360° swivel 360° swivel 360° swivel
The Nederman range of extraction arms covers a wide variety of applications for use in both explosive and non-explosive environments. The different models meet the requirements of the relevant European Directives, such as Directive 98/37/EC concerning safety of machinery and Directive 94/9/EC, commonly known as the ATEX 100a Directive, concerning the use of equipment and protective systems in potentially explosive atmospheres.
Before an extraction arm is chosen, it is the responsibility of the user/employer, according to European Directive
99/92/EC, or ATEX 137, to assess and classify the working environment. The resulting classification will be the basis for the choice of arm for which Nederman, as manufacturer and supplier, will be responsible with regard to product compliance.
All Nederman arms are highly flexible, and simple to position, extend and retract. Different attachments are available for wall, ceiling or extension bracket mounting as well as a number of accessories, including hoods and dampers to improve efficiency.
General specifications
Nederman Standard Nederman Telescopic Nederman Original Nederman NEX MD Nederman NEX HD
Reach Weight Description Part no.
2 m 11 kg Standard arm 2 m 10500238 3 m 13 kg Standard arm 3 m 10500338
Nederman Standard Extraction Arm
Pressure drop Standard Arm
Dimensions Standard Arm Dimensions Telescopic Arm
Pressure drop Telescopic Arm
Reach Weight Description Part no.
0.9 -1.6 m 12 kg Telescopic arm with Metal Hood 10502531 0.9 -1.6 m 12 kg Telescopic arm with Original hood 10502331
Accessories Part no.
Wall Bracket 10550635
Wall Bracket, 1 m 10550735 Wall Bracket, 2 m 10550835 Spot Light/Fan Switch, 24 V, 20 W Original Hood 10551235 Spark Protection Original Hood 10551335 Metal hood with damper 10321542 Spot Light/Fan Switch, 24 V, 20 W, Metal Hood 10507435 Fan Switch, Metal Hood 10371080 Spark Protection, Metal Hood 10373118
Nederman Telescopic Arm
x = Airflow m³/h y = Static pressure Pa A= 3 m, B= 2 m
Accessories Part no.
Damper 10500438
x = Airflow m³/h y = Static pressure Pa
Reach Weight Description Part no.
2 m 11 kg Original arm 2 m 10554235 3 m 13 kg Original arm 3 m 10554335 4 mV 16 kg Original arm 4 m Vertical 10554435 4 mH 16 kg Original arm 4 m Horizontal 10554535 5 m 18 kg Original arm 5 m 10554935
Accessories Part no.
Wall Bracket 10550635
Wall Bracket, 1 m 10550735 Wall Bracket, 2 m 10550835 Spot Light/Fan Switch, 24 V, 20W Original Hood 10551235 Spark Protection Original Hood 10551335 Metal hood with damper 10321542 Spot Light/Fan Switch, 24 V, 20 W, Metal Hood 10507435 Fan Switch, Metal Hood 10371080 Spark Protection, Metal Hood 10373118
Reach Weight Description Part no.
2 m 16 kg NEX MD arm 2 m 10561032 3 m 20 kg NEX MD arm 3 m 10561132 4 m 27 kg NEX MD arm 4 m 10561232 5 m 32 kg NEX MD arm 5 m 10561332
Accessories Part no.
Wall Bracket for 2 and 3 m arm 10372215 Wall Bracket for 4 and 5 m arm 10372722 Wall Bracket, 1 m 10512732 Wall Bracket, 2 m 10512832 Spot Light/Fan Switch, 24 V, 20 W Original Hood 10551235 Spark Protection Original Hood 10551335
Nederman Original Extraction Arm Nederman NEX MD Extraction Arm
Pressure drop Original Extraction Arm
Dimensions Original Extraction Arm Dimensions NEX MD Extraction Arm
x = Airflow m³/h y = Static pressure Pa
A = 5 m, B = 4 m 2 horizontal, C = 4 m vertical, D = 3 m, E = 2 m
700 900 1100 1200 1300
Pressure drop NEX MD Extraction Arm
x = Airflow m³/h y = Static pressure Pa
Pressure drop NEX HD Extraction Arm
Dimensions NEX HD Extraction Arm
x = Airflow m³/h y = Static pressure Pa
A = 5m, B = 4m, C = 3m, D = 2m
Nederman NEX HD Extraction Arm
Reach Weight Description Part no.
2 m 17 kg NEX HD arm 2 m 10560232 3 m 21 kg NEX HD arm 3 m 10560332 4 m 28 kg NEX HD arm 4 m 10560432 5m 33kg NEX HD arm 5 m 10560532
Accessories Part no.
Wall Bracket for 2 and 3 m arm 10372215 Wall Bracket for 4 and 5 m arm 10372722 Wall Bracket, 1 m 10512732 Wall Bracket, 2 m 10512832 Spot Light/Fan Switch, 24V, 20W 10512432
Fan Switch 10512532
Spark Protection 10512632
Recommended airflows Max 2000 m3/h
Recommended maximum negative pressure 3000 Pa Connection diameter 200 mm Maximum load on outer arm 4.2 m 100 kg Maximum load on outer arm 6.0 m 60 kg Recommended installation height from floor 2.7-3.0 m
Description Recovery
rate by weight
Weight Part no.
Extension Arm 4.2 m 100 % 73 kg 10506635 Extension Arm 6.0 m 100 % 93 kg 10507735
Accessories Weight Materials Part no.
Cable for light kit - - 10345292 Suspension for Exhaust
Hose Reel 2 kg painted steelPowder 20374358
Description Max temp of
extracted air Weight Part no.
Duct kit 4.2 m Fume 120 C˚ 8 kg 10374376 Duct kit 4.2 m Exhaust 150 C˚ 12 kg 10374375 Duct kit 6.0 m Fume 120 C˚ 13 kg 10374360 Duct kit 6.0 m Exhaust 150 C˚ 17 kg 10374374
Description Recovery rate by
weight Materials
Duct kit 4.2 m
Fume 92% Galvanised steel duct, PVC coated glass fibre hose
Duct kit 4.2 m
Exhaust 57% Galvanised steel duct, NR-B hose
Duct kit 6.0 m
Fume 95% Galvanised steel duct, PVC coated glass fibre hose
Duct kit 6.0 m
Exhaust 71% Galvanised steel duct, NR-B hose Used when extra reach is needed. Combinations, see below. Made of robust steel profiles, flexible in all directions. The duct kit must be ordered separately.
Nederman Extension Arm
Extraction arms for use in explosive environments
The NEX range of extraction arms is specially designed forworking environments with fumes, vapours or explosive dust and also where the hygienic demands are high and large airflows are required. Typical workplaces can be found in the following industries:
• pharmaceutical • food process • technical chemical
Applications include control, measuring, weighing, filling, blending, mixing emptying and packaging. See the table below for application categories and suitable arms. All arms are approved for environments where there is a risk of explosion according to European Directive 94/9/EC or ATEX 100a Directive
NEX D NEX DX NEX S
Marking: EX II 3 D
II – Group II above ground, not mining 3 – Equipment category 3 working in zone 22 D – To be used in environments with explosive dust
Marking: EX II 2 D
II – Group II above ground, not mining 3 – Equipment category 2 working in zone 21 D – To be used in environments with explosive dust
Marking: EX II 2 D/G
II – Group II above ground, not mining 3 – Equipment category 2 working in zone 1/21 D – To be used in environments with explosive dust G – To be used in environments with explosive gas
NEX D NEX DX NEX S
Recommended airflows m3/h 900-1700 900-1700 600-1100 (Ø 125 mm)
900-1700 (Ø 160 mm)
Maximum fume temperature °C 70 70 70
Noise level at hood dB(A) 55-80 55-80 65-70
Damper Optional Optional No
Hose material PVC Antistatic Polyurethane Antistatic Polyurethane Connection diameter mm 150/160 150/160 125 and 160
Note 360° swivel 360° swivel 180° swivel
General specifications
Pressure drop Extension Arm Dimensions Extension Arm
x = Airflow m³/h y = Static pressure Pa
A = Extension Arm bent 40˚ (to its limit) B= Extension Arm bent 90˚
C = Extension Arm is straight.
Reach Weight Description Part no.
2 m 17 kg NEX D arm 2 m 10500232 3 m 21 kg NEX D arm 3 m 10500332 4 m 28 kg NEX D arm 4 m 10500432 5 m 33 kg NEX D arm 5 m 10500532 2 m 17 kg NEX D arm 2 m, with damper 10501232 3 m 21 kg NEX D arm 3 m, with damper 10501332 4 m 28 kg NEX D arm 4 m, with damper 10501432 5 m 33 kg NEX D arm 5 m, with damper 10501532
Accessories Part no.
Wall Bracket for 2 and 3 m arm 10372215 Wall Bracket for 4 and 5 m arm 10372722
Nederman NEX D Extraction Nederman NEX DX Extraction Arm
Reach Weight Description Part no.
2 m 17 kg NEX DX arm 2 m 10502232 3 m 21 kg NEX DX arm 3 m 10502332 4 m 28 kg NEX DX arm 4 m 10502432 5 m 32 kg NEX DX arm 5 m 10502532 2 m 17 kg NEX DX arm 2 m, with damper 10503232 3 m 21 kg NEX DX arm 3 m, with damper 10503332 4 m 28 kg NEX DX arm 4 m, with damper 10503432 5 m 32 kg NEX DX arm 5 m, with damper 10503532
Pressure drop NEX D Arm Pressure drop NEX DX Arm
x = Airflow m³/h y = Static pressure Pa A = 5 m, B = 4 m, C = 3 m, D = 2 m x = Airflow m³/h y = Static pressure Pa A = 5 m, B = 4 m, C = 3 m, D = 2 m
Accessories Part no.
Wall Bracket for 2 and 3 m arm 10372215 Wall Bracket for 4 and 5 m arm 10372722
Reach Weight Description Part no.
2 m 13 kg NEX DX arm 2 m, Diameter 125 mm 10520232 3 m 17 kg NEX DX arm 3 m, Diameter 125 mm 10520332 4 m 22 kg NEX DX arm 4 m, Diameter 125 mm 10520432 2 m 13 kg NEX DX arm 2 m, Diameter 160 mm 10521232 3 m 17 kg NEX DX arm 3 m, Diameter 160 mm 10521332 4 m 22 kg NEX DX arm 4 m, Diameter 160 mm 10521432
Nederman NEX S Extraction Arm
Pressure drop NEX S Arm
x = Airflow m³/h, y = Static pressure Pa
A = 4 m Ø 125 mm, B = 3 m Ø 125 mm, C = 2 m Ø 125 mm D = 4 m Ø 160 mm, E = 3 m Ø 160 mm, F = 2 m Ø 160 mm
The first step towards effective and safe removal of fumes, gases and dust from the workplace is choosing the most suitable extraction arm. The next step is to consider how the contaminants are to be removed from the extracted air so that it can be returned to the atmosphere or recycled without negative impact on the environment or workplace. These situations are often governed by stringent regulations with significant economic penalties if they are not observed. Filter systems must therefore be chosen to fulfil a number of basic requirements and the first main division of types is with regard to their use in explosive or non-explosive en-vironments. The production environment must be assessed and classified according to current directives. The filters in this handbook are for stationary installation; there is also an extensive choice of mobile filter units, see the Nederman Product catalogue for further details.
The Nederman FilterMax System
This is a modular system of filter units designed to deal with all types of fume and dust resulting from mechanical working or handling of a wide range of materials.
If additional workplaces are added to the extraction system, increasing airflow requirements, then new modular sections can be easily added.
There is also a compact stand-alone unit, C 25, for low vol-ume applications where space is limited.
Dimensioning example
Light welding requires handling a load of 50 m³/m²h. In a FilterMax DF with a single module the filter area is 72 m², which means that it can filter 3600 m³/h (50 m³/m²h x 72 m²). This is equivalent to the volumes of extracted air from 3 or 4 welding stations in simultaneous operation. It could be advantageous to consider a twin module set-up to ensure sufficient capacity and longer cartridge life.
Note:
The welding shop in the example might have a total of 15 welding stations, but with a usage frequency of 15%, the filter suggested will be sufficient.
When designing filter systems it is always important to take into account additional parameters such as the temperature of the extracted air at the inlet, the required filtration ef-ficiency, possible recirculation of air and potential safety hazards.
Nederman FilterMax C25
For further information see the Nederman Product Cata-logue.
Nederman FilterMax F 30, 60 and 90
The filter handles the air polution from metal industries as well as non explosive dust from other industries. Integrated pre-seperator for coarse particles, sparks, etc. A wide range of cartridges for different purposes are available. Protection class IP54. In- and outdoor installation.
Nederman FilterMax DF 40, 80 and 120
The filter handles the air polution from metal industries as well as non explosive dust from other industries. A wide range of cartridges for different purposes are available. Pro-tection class IP54. In- and outdoor installation.
Nederman FilterMax SFC
FilterMax SFC gives increased safety against release of dangerous dust into the atmosphere. If the filtered air is re-circulated a FilterMax SFC is vital to maintain a safe work environment. In combination with a pressure switch the FilterMax SFC can work as an emmission alarm as well as a safety filter. FilterMax SFC can be used as a heavy duty general filter cabinet in applications such as vehicle exhaust or fine dust. One FilterMax SFC module filters the air from one FilterMax F or FilterMax DF module. The maximum capacity is 4000 m³/h, at heavy loads this is reduced down to 2000 m³/h. For general filtration of dust or fume the capacity is 2000 m³/h. The FilterMax SFC cabinet can be equiped with straight inlets or a combinations of 90° and straight inlets.
Nederman FilterMax DX 3000, 6000 and 9000
Designed for extraction of dry powder or dust with explo-sion risk applications or if exploexplo-sion protection is demand-ed accordingly to the ATEX directive. Ndemand-ederman’s Dustline serie includes FilterMax DX and extraction arms and fans for explosive environments. Food, medical or chemical in-dustries are likely users for this application. Protection class IP65.
Low Vacuum Filters
General technical data
Compressed air pressure: 4-6 bar.
Compressed air use: 70 N litres/min at 30 sec intervals (35 N-litres/ pulse).
Supply voltage: 100V, 110V, 230V AC 50/60 Hz. Process air: 0° to +60°C, non condensing air. Ambient temperature: -20°C to +60°C. Dimensioned pressure drop: 1200 Pa.
Filter models Airflow m3/h Cartridges Filter area m2 Part no. indoor Part no. outdoor
FilterMax C25*
A compact stand-alone filter with built-in fan and control equipment. For dry dust and fume.
C25 - Single module 1500-2750 4 48 –* –*
FilterMax DF
The basic version of the FilterMax modular range. For dry dust and fume.
DF40 - Single module 2200-4300 6 72 12620167 12620467 DF80 - Double module 4300-8600 12 144 12620267 12620567 DF120 - Triple module 8600-13000 18 216 12620367 12620667
FilterMax F
Equipped with pre-separator for applications where there is a risk of sparks reaching the filter cartridges. For dry dust and fume.
F30 - Single module 1500-3500 6 60 12603067 12603567 F60 - Double module 3000-7000 12 120 12606067 12606567 F90 - Triple module 4500-10000 18 180 12609067 12609567
FilterMax SFC
For filtering exhaust fume or fine dust, or for recycling air from FilterMax DF or F models. When used in recycling applications the SFC model can also function as a back-up filter in case of collapse of the primary filter unit.
Single module 2000-4000 12 bags 9 12373910 12373914 Double module 4000-8000 24 bags 18 2 x 12373910 2 x 12373914 Triple module 6000-12000 36 bags 27 3 x 12373910 3 x 12373914 *) For further information see the Nederman Product Catalogue.
Filters for non-explosive dust and fumes
FilterMax F System parts Part no.
Container kit 2 x 40 l. Indoor installation (including adapter)
12372140 Container kit 2 x 40 l.
Outdoor installation (incl adapter) 12373881
Container kit 2 x 100 l. Indoor installation (incl adapter and extension legs)
12372067 Container kit 2 x 100 l.
Outdoor installation
(incl adapter and extension legs)
12373897
Filter Max F System parts Part no.
Filter PW-NS-75-10-6. For fumes and fine particles, 99 % at 0.5 um, 10 m2
12373161
Filter PW PTFE-75-10-6 (6 pack) PTFE coated. For fine/medium particles, 99,9 % at 0.5 um, washable
12373162 FilterMax C25 FilterMax DF/F FilterMax SFC
Nederman FilterMax DF System parts Part no.
Rotary air lock kit DF
indoor installation 12373574 Rotary air lock kit DF
outdoor installation 12373573 Dust container kit 50l
indoor installation 12373549 Dust container kit 50l
outdoor installation 12373550 Dust container kit 100l
indoor installation 12373572 Dust container kit 100l
outdoor installation 12373571
Filter PW-NS-95-12-6 for fumes/fine
particles, 99 % at 0.5 um, 12 m2. 12373301
Filter- PW-PTFE-95-12-6 (6 pack) PTFE coated.
For fine/medium particles, 99.9 % at 0.5 um, 12 m2.
12373558
Filter-PWA-PTFE-95-10-6 (6 pack) Antistatic, PTFE coated.
For inigtion sensitive medium/ coarse particles, 99.9 % at 0.5 um, 10 m2.
12373337
Nederman FilterMax F/DF Common Parts Part no.
Air outlet Ø 315 mm indoor 12372057 Air outlet Ø 400 mm indoor 12372058 Air outlet Ø 500 mm indoor 12372059 Air inlet Ø 250 mm indoor 12372070 Air inlet Ø 315 mm indoor 12372071 Air inlet Ø 400 mm indoor 12372072 Air inlet Ø 500 mm indoor 12372073 Air inlet Ø 250 mm outdoor 12373561 Air inlet Ø 315 mm outdoor 12373562 Air inlet Ø 400 mm outdoor 12373563 Air inlet Ø 500 mm outdoor 12373564 Air outlet Ø 315 mm outdoor 12373565 Air outlet Ø 400 mm outdoor 12373566 Air outlet Ø 500 mm outdoor 12373567
FilterMax SFC System Parts Part no.
Straight inlet for one module,
rectangular round Ø 315 mm 12373911
Straight inlet for one module,
rectangular round Ø 500 mm 12373918
90° inlet/outlet section 12373915
90° inlet/outlet bottom section 12373912
Bag filter EU8/F95, 9 m2
filterpockets 12373916
90° inlet/outlet section 12374231
Nederman FilterMax F/DF – Parts Part no.
Pressure switch 12372142
Filter regulator, compressed air 12372064
Pressure gauge kit 12372063
Shut off valve, compressed air 12372083
dP Control kit FilterMax DF/F/ DX
(Accessory) 12373603 dP Control kit FilterMax C25 12373321
Filter model Airflow, m³/h Carftridge area, m²Filter Model Relief direction Part no.
FilterMax DX With integrated control system. For applications where there are explosion risks. For dry dust and fume.
2400-3600 6 60 DX3000 TR Upwards 12610167 4800-7200 12 120 DX6000 TR Upwards 12610267 DX6000 SR Backwards 12610367 DX6000SR/TR Up- and backwards 12610667 7200-10800 18 180 DX9000 SR Backwards 12610467 DX9000 SRII Backwards x 2 12610567 DX9000 SR/TR Up- and backwards 12610767
FilterMax DX System parts Part no.
Rotary air lock kit DX 12374525
Relief duct adapter 12372765 Dust container kit 50 l. Incl. adapter
and extension legs Filter-PWA-95-10-6 ( 6 pack). Antistatic. For coarse dust. 99 % at 5 μm, washable, 10 m2
12372663
Filter-PWA-95-12-6 ( 6 pack). Antistatic.
For medium dust, 99 % at 5 μm, washable, 1 m2
12373757
Filter-PWA PTFE-95-10-6 ( 6 pack). Antistatic.
For fine dust, 99.9 % at 5 μm, 10 m2
12373337 Filter PW-NS-95-12-6.
For fumes and fine particles, 99 % at 5 um, 12 m2 ONLY for dust with
MIE>100 mJ 12373301 Inlet / Outlet DX Ø 250 mm 12372664 Inlet / Outlet DX Ø 315 mm 12372665 Inlet / Outlet DX Ø 400 mm 12372666 Inlet / Outlet DX Ø 500 mm 12372667 Isolation valve Ø 500 mm 12374396 Isolation valve Ø 400 mm 12374397 Isolation valve Ø 315 mm 12374398 Isolation valve Ø 250 mm 12374399
Filter Cartridges
A number of different types of filter cartridges are available to deal with the contaminants. These are chosen depending on the source of the contaminant and the required degree of filtration. The type and intensity of the operations will determine the life of the cartridge, typically around 6000 hours of continual use. Filter cartridges are chosen depending on specific filtration requirements defined by particle characteristics and required efficiency.Cartridges are cleaned using powerful, pulsed shockwaves. The DF, F and DX units are fitted with automatic control systems for cleaning during and after operation. All FilterMax filters are available for indoor and outdoor use (except the C25 – indoor use only).
Contaminant Type Filtration
Fumes and fine particles (Light and heavy welding, heavy load dust)
Basic PolyWeb 99% at 0.5 μm Medium to coarse particles
(Dry dust and grinding, heavy load dust)
PolyWeb 99% at 0.5 μm Fine to medium particles, sticky
(Heavy load dust, oxy-fuel cutting, light/medium/heavy plasma cutting)
PolyWeb PTFE 99.9% at 0.5 μm Medium to coarse particles
Ignition sensitive (Dry dust and grinding, heavy load dust)
PolyWeb
Antistatic 99 % at 0.5 μm Medium to coarse particles, sticky
Ignition sensitive
(Dry dust and grinding, heavy load dust)
PolyWeb Antistatic PTFE
99.9% at 0.5 μm
All cartridges are washable except Basic PolyWeb
Cartridge guide
Operation Filter load
m3/m2h Notes
Dry dust and grinding 60 Fire risk working on oily steel Light welding 50 ”
Heavy welding 40 ”
Heavy load dust 40 Requires dust feeder Oxy-fuel cutting 30 High fire risk pre-separator
required Plasma cutting:
Light cutting 30 Fire risk pre-separator required Medium cutting 25 ”
Heavy cutting 15 ”
Filters for explosive dust and fumes
Assembly dimensions for different inlet and outlet sizes (mm)
Assembly dimensions for different inlet and outlet sizes (mm)
NB! The height dimensions for the filter are only valid when using the 40 litres containers.
Dimensions FilterMax F30, F60 and F90 Dimensions FilterMax DF40, DF80 and DF120
Ø 250 Ø 315 Ø 400 Ø 500 A - 2375 2440 2565 B - 3300 3365 3490 C - - 4290 4415 D 2450 2560 - -E 3370 3480 3540 -F - 4410 4470 4600 G - 1430 1445 1465 H 275 325 395 445 Ø 250 Ø 315 Ø 400 Ø 500 A - 2615 2685 2810 B - 3535 3605 3730 C - - 4525 4650 D 2590 2700 - -E 3510 3620 3690 -F - 4540 4610 4740 G - 1195 1195 1195 H 270 315 390 440
Ø 250 Ø 315 Ø 400 Ø 500 A - 2615 2685 2810 B - 3535 3605 3730 C - - 4525 4650 D 2590 2700 - -E 3510 3620 3690 -F - 4540 4610 4740 G - 1195 1195 1195 H 270 315 390 440
Assembly dimensions for different inlet and outlet sizes (mm)
Inlet Outlet
FilterMax DX 3000 Ø 230/315 mm Ø 315/400 mm FilterMax DX 6000 Ø 315/400 mm Ø 400/500 mm FilterMax DX 9000 Ø 400/500 mm Ø 500 mm
FilterMax SFC 40 with and without raincover.
Dealing with oil mist
Oil mist is the aerosol that is often formed when oil is used as a coolant/lubricant during the machining of metal com-ponents. The mist comprises drops of oil, or oil and water emulsion. It is well known than prolonged and repeated exposure to oil products can be detrimental to health, which means that good ventilation must be ensured under all working conditions. Precipitation of oil mist on machinery, equipment and the workplace floor can be both detrimental and dangerous.
Mineral oil-based metalworking fluids are known as neat cutting oils or straight oils. They normally contain a number of undisclosed additives that can affect the viscos-ity of the oil. Emulsions normally contain 5 – 10% water-soluble oil and 90 – 95% water.
The Nederman range of oil mist filters NOM is designed for use in conjunction with machining work where emul-sions are used as the coolant/lubricant. They can also be used in the metalworking press industry. Contact Nederman for further information.
If straight oil is used the load must be moderate and limited to 8 – 100 mg/m³ in the aerosol phase. The viscosity of the coolant and degree of contamination will also affect the ef-ficiency of the filter system and its working life.
Coolant viscosity ranges and suitability
NOM Oil Mist Filters have a unique filter concept using one of the most advanced filter media on the market offering trouble-free operation and low maintenance costs. 99.97% filtration efficiency is guaranteed when a HEPA filter is used. A high level of filtration combined with a gravity drip self-cleaning function ensures protection for both personnel and equipment.
The filter units are simple to install, even in limited spaces. All models are machine-mountable. Compact or stand-alone models are available. In processes where oil smoke frequently occurs, the NOM Oil Mist Filter can be used to handle the oil mist deriving from swarf and chips created, for example, by CNC machines.
Oil Mist Filters
Viscosity
mm2/s Emulsion Straight oil
0 - 50 Suitable Suitable* 50 - 100 Suitable Contact Nederman 100 - 200 Contact Nederman Contact Nederman 200 + Contact Nederman Contact Nederman *EU regulations specify 7 – 25 mm2/s
off. The smoke comprises submicron-size particles or par-tially combusted oil. This often occurs, for example, in hot bar press applications, and when gear cutting and die-cast-ing aluminium. Contact Nederman for further information.
Recommended capacity
Investigate the routines to get full information regarding number of machines operating at the same time, size of machines,working hours a day (shift) and the cycle time. Calculate the airflow capacity from a typical situation For frequently openings of the door (manually handling of tools, item, etc) an increased airflow is required in the opening period due to increased open areas.
For automatic machines with normally closed doors it is necessary to delay opening of the door.
It is of primary importance to generate well balanced under-pressure so the oil-mist is removed and the bigger droplets of oil or emulsion stay back in the machine for recycling. Recommended air velocity 0.2 m/s through closed machines
Example:
Scrap openings and other openings and gaps in a closed machine might give an area like 1.0 m².
1.0 m2 x 0.2 m/s x 3600sek = 800 m3/h
A totally open machine needs a column hood.
Recommendation for emulsions
Pay attention to the viscosity (viscosity >200mm²/s, bal-ance the airflow carefully) Make sure the filter never is running with clean air through the filters. Never leave the dirty filters unused for a longer period time. If filter is left unused or running with clean air, water will dry out from the emulsion which will crystallize on the filter surface,and might block the filter. (Nedermans filters can be cleaned with lukewarm water and dishing detergent like Fairy, if necessary)
Recommendations for straight oil
Applications with straight oil and high workload need a well balanced down time period for at least 2 x30 min/24 hours for draining the filters.
Nederman NOM 4
The NOM 4 is designed for single CNC machines with limited oil mist, enclosed cabinet.
Nederman NOM 11, NOM 18 and NOM 28
These filters are designed for applications with need for larger airflow capacities. In all metal fabrication with oil mist troubles, these filters will fit into a central system, connected to each machine. All units are equipped with pressure gauge for control of filters as well as a indication for need of cleaning (self draining).
Model Fan Voltage
V Phase HEPA filter Power kW Current A Filterarea m2 Max. airflow m3/h Part no.
NOM 4 x 230 1 0.37 3.15 3 400 12610368 NOM 4 x 230 1 x 0.37 3.15 3 400 12610468 NOM 4 x 400/230 3 0.37 1.0/1.75 3 400 12610568 NOM 4 x 400/230 3 x 0.37 1.0/1.75 3 400 12610668 NOM 4 3 400 12611168 NOM 4 x 3 400 12611268 NOM 11 x 230 1 0.75 5 8.5 1100 12620168 NOM 11 x 230 1 x 0.75 5 8.5 1100 12620268 NOM 11 x 400/230 3 0.75 1.73/3.0 8.5 1100 12620568 NOM 11 x 400/230 3 x 0.75 1.73/3.0 8.5 1100 12620668 NOM 11 8.5 1100 12621168 NOM 11 x 8.5 1100 12621268 NOM 18 x 230 1 1.1 6.7 14 1800 12630168 NOM 18 x 230 1 x 1.1 6.7 14 1800 12630268 NOM 18 x 400/230 3 1.1 2.5/4.3 14 1800 12630568 NOM 18 x 400/230 3 x 1.1 2.5/4.3 14 1800 12630668 NOM 18 14 1800 12631168 NOM 18 x 14 1800 12631268 NOM 28 x 400/230 3 2.2 4.56/7.9 21 2800 12640568 NOM 28 x 400/230 3 x 2.2 4.56/7.9 21 2800 12640668 NOM 28 21 2800 12641168 NOM 28 x 21 2800 12641268
NOM4 NOM11 NOM18 NOM28
Recommended installation
During operation with closed door the airflow can be reduced, i.e. with a motorized damper. Before the end of the cycle the airflow can be increased by opening of the damper. The reduced airflow will reduce the amount of extracted oil mist and oil vapors. The damper control could be connected to a dedicated output from the machine control system or from a signal from the coolant pump system.
The position of the outlet in the CNC machine should be protected from direct oil injections, as from the chuck. Install adjustable dampers for each machine.
Dimensions
NOM 28
NOM 11 NOM 18
NOM 4
*) Measure depending on extension legs position
Low Vacuum Fans
Voltage
V Phase current Rated A
Power
kW Airflow m3/h Ø in/out mm Connection Weight kg Fan bracket included Model Part no.
115/230 1 8.7/4.4 0.55 400-1200 160/160 15 No N16 14510121 230/400 3 2.4/1.4 0.55 500-1250 160/160 13 No N16 14510521 115/230 1 13.6/6.5 0.75 400-1500 160/160 17 No N24 14510122 230/400 3 3.7/2.2 0.9 400-1750 160/160 17 No N24 14510422 230/400 3 7.9/4.6 2.2 500-4000 200/250 29 No N40 14510123 230/400 3 5.7/3.3 1.5 500-2500 200/250 25 No N40 14510623 230/400 3 7.9/4.6 2.2 500-3000 160/160 32 Yes N29 14510129 230/400 3 7.9/4.6 2.2 500-3000 160/160 32 No N29 14510829 230/400 3 5.7/3.3 1.5 500-1500 160/160 28 Yes N29 14520129 230/400 3 5.7/3.3 1.5 500-1500 160/160 28 No N29 14520929 Dimensions N Fans Dimensions N A B C D N16 478 457 321 160 N24 478 457 341 160 N40 493 582 482 250
N29 635 643 475 160 x = Airflow m³/h y = Static pressure Pa
Fan diagram N Fans
Nederman fans are designed for use in all types of industrial processes and ventilation systems, and are constructed for both indoor and outdoor use. The choice of fan depends on the pressure drops and flow requirements of the system in question. In some cases it might be more economical to choose a number of smaller fans instead of one central fan for space reasons or when loading conditions are difficult to specify.
The first design criterion is whether or not the environment can be subject to explosions. The production environment must be assessed and classified according to current directives.
The size of the fan will be determined by the vacuum required to overcome the pressure drops in the extraction arms, filters and ducting and by the airflows required to maintain the correct transportation speeds of the contaminated air. To reduce power costs and increase efficiency, the use of fan starters, dampers and fan inverters is recommended. These will minimize the required airflows in the system and optimize the fan speed at different work loads.
Sound absorbers are available for use with NCF range fans. Contact your local Nederman office or Nederman sales representative for details.
Nederman NCF Fans
x = Airflow m³/h y = Total pressure Pa
Fan diagram NCF Fans
Voltage
V Phase current Rated-A
Power
kW Airflow,m3/h Ø inlet/outlet, Connection
mm
Weight
kg Model Part no.
230Δ/400Y 3 7.9/4.55 2.2 1100 - 4400 285/288x205 67 NCF 30/15 14520128 230Δ/400Y 3 24.0/13.8 7.5 5700 - 14400 500/453x322 123 NCF 120/15 14520328 400Δ/690Y 3 13.8/8.0 7.5 5700 - 14400 500/453x322 123 NCF 120/15 14521128 230Δ/400Y 3 13.6/7.8 4 1700 - 6500 320/322x229 105 NCF 30/25 14520428 400Δ/690Y 3 13.8/8.0 4 1700 - 6500 320/322x229 105 NCF 30/25 14521228 230Δ/400Y 3 17.9/10.3 5.5 2000 - 6700 285/288x205 110 NCF 40/25 14520528 400Δ/690Y 3 10.3/6.0 5.5 2000 - 6700 285/288x205 110 NCF 40/25 14521328 230Δ/400Y 3 17.9/10.3 5.5 1800 - 5900 285/256x183 112 NCF 50/25 14520628 400Δ/690Y 3 10.3/6.0 5.5 1800 - 5900 285/256x183 112 NCF 50/25 14521428 230Δ/400Y 3 24.0/13.8 7.5 2300 - 9100 360/361x256 150 NCF 80/20 14520728 400Δ/690Y 3 13.8/8.0 7.5 2300 - 9100 360/361x256 150 NCF 80/20 14521528 230Δ/400Y 3 46.1/26.5 15 3500 - 12400 360/361x256 232 NCF 120/25 14520828 400Δ/690Y 3 26.5/15.3 15 3500 - 12400 360/361x256 232 NCF 120/25 14521628 230Δ/400Y 3 56.5/32.5 18.5 4600 - 17900 455/453x322 292 NCF 160/25 14520928 400Δ/690Y 3 32.5/18.8 18.5 4600 - 17900 455/453x322 292 NCF 160/25 14521728 Dimensions NCF A B C D E F G H I J NCF 30/15 705 708 529 280 201 Ø 250 216 234 Ø 10 (6x) 450 NCF 30/25 785 791 612 314 225 Ø 315 269 289 Ø 12 (6x) 500 NCF 40/25 880 883 652 278 201 Ø 250 329 337 Ø 12 (6x) 560 NCF 50/25 785 773 643 251 178 Ø 250 255 337 Ø 12 (4x) 450 NCF 80/20 880 883 703 353 252 Ø 400 329 337 Ø 12 (6x) 560 Dimensions NCF Fans
Nederman NCF DX Fans
A new assortiment of NCF DX models are currently being introduced. For more information about this product, please contact your nearest Nederman dealer.
Fan diagram NCF DX Fans
x = Airflow m³/h y= Total pressure Pa NCF DX 40/25 NCF DX 50/25 NCF DX 80/25 NCF DX 120/25 NCF DX 160/25 Part no. 14530128 14530228 14530328 14530428 14530528 Voltage 400VΔ 400VΔ 400VΔ 400VΔ 400VΔ Frequency 50 Hz 50 Hz 50 Hz 50 Hz 50 Hz Phase 3~ 3~ 3~ 3~ 3~
Accessories for NCF fans
Inlet adaptor Part no.
Model Duct, mm NCF 30/15 Ø 250 14374438 NCF 120/15 Ø 500 14374441 NCF 30/25 Ø 315 14374439 NCF 40/25 Ø 250 14374438 NCF 50/25 Ø 250 14374438 NCF 80/20 Ø 400 14374440 NCF 120/25 Ø 400 14374440 NCF 160/25 Ø 500 14374441
Outlet adaptor Part no.
Model Fan outlet, mm Duct, mm
NCF 30/15 288x205 Ø 315 14374442 NCF 120/15 453x322 Ø 500 14374445 NCF 30/25 322x229 Ø 400 14374443 NCF 40/25 288x205 Ø 315 14374442 NCF 50/25 256x183 Ø 250 14374446 NCF 80/20 361x256 Ø 400 14374444 NCF 120/25 361x256 Ø 400 14374444 NCF 160/25 453x322 Ø 500 14374445
Flexible inlet adaptor Part no.
Model Duct, mm NCF 30/15 Ø 250 14374447 NCF 120/15 Ø 500 14374450 NCF 30/25 Ø 315 14374448 NCF 40/25 Ø 250 14374447 NCF 50/25 Ø 250 14374447 NCF 80/20 Ø 400 14374449 NCF 120/25 Ø 400 14374449 NCF 160/25 Ø 500 14374450
Flexible outlet adaptor Part no.
Modell Fan outlet, mm Duct, mm
NCF 30/15 288x205 Ø 315 14374451 NCF 120/15 453x322 Ø 500 14374454 NCF 30/25 322x229 Ø 400 14374452 NCF 40/25 288x205 Ø 315 14374451 NCF 50/25 256x183 Ø 250 14374455 NCF 80/20 361x256 Ø 400 14374453 NCF 120/25 361x256 Ø 400 14374453 NCF 160/25 453x322 Ø 500 14374454
Anti vibration mountings Part no.
AM 25, 30/15 14374435
AM 30, 30/25, 40/25, 50/25, 80/20, 120/15 14374436 AM 50, 120/25, 160/25 14374437
Inlet guard net for fan Part no.
d315, 30/15, 40/25, 50/25 14374456
d315, 30/25 14374457
d400, 80/20, 120/25 14374458 d500, 120/15, 160/25 14374459
Outlet guard net for fan Part no.
30/15, 40/25 14374460 30/25 14374461 80/20, 120/25 14374462 120/15, 160/25 14374463 50/25 14374464 Fan with
Sound Enclosure WxDxH, mmSize Weight, kg Part no.
SE NCF 30/15 230/400V 2.2kW 50Hz 1100x1200x1300 267 14540128 SE NCF 120/15 400/690V 7.5kW 50Hz 1300x1400x1500 403 14541128 SE NCF 30/25 400/690V 4kW 50Hz 1100x1200x1300 305 14541228 SE NCF 40/25 400/690V 5.5kW 50Hz 1100x1200x1300 310 14541328 SE NCF 50/25 400/690V 5.5 kW 50Hz 1100x1200x1300 312 14541428 SE NCF 80/20 400/690V 7.5kW 50Hz 1100x1200x1300 350 14541528 SE NCF 120/25 400/690V 15kW 50Hz 1300x1400x1500 512 14541628 SE NCF 160/25 400/690V 18.5kW 50Hz 1300x1400x1500 572 14541728
Airflow control
Fans designed to handle full-time use of all extraction arms in an installation risk being over-dimensioned. This is because the frequency of use at each workplace is generally significantly lower than a theoretical maximum design load. To deal with these situations there are Nederman solutions that offer considerable savings in power and maintenance costs. Noise levels will also be reduced if airflows can be kept to a minimum.
Nederman Fan Starter/Fan Contactor
The cost-effectiveness of the extraction system can be improved if the fan only operates when work is being carried out. A fan contactor can be activated via a sensor clamp attached to the earth cable of welding equipment or a switch in the hood.Installing a fan starter: • reduces power costs
• minimizes the volume of heated air extracted air from the premises
• allows a stop delay of up to 5 minutes to ensure extraction of remaining dust and fumes
Fan Starter
400V/50Hz Motor powerkW Dimensions mm For fan model Part no.
Fan Starter 5.5 2.2 - 5.5 400 x 400 x 200 N29, N40 NCF 30/15 NCF 30/25 NCF 40/25 NCF 50/25 14514837 Fan Starter 5.5 PTC 4- 5.5 400 x 400 x 200 NCF DX 40/25 14515637 Fan Starter 11 4 - 11 500 x 500 x 250 NCF 40/25 NCF 50/25 NCF 80/20 NCF120/15 14514937 Fan Starter 11 PTC 4 - 11 500 x 500 x 250 NCF DX 40/25 NCF 50/25 NCF 80/25 14515737 Fan Starter 18.5 15 - 18.5 500 x 500 x 250 NCF 120/25 NCF 160/25 14515037 Fan Starter 18.5 PTC 15 - 18.5 500 x 500 x 250 NCF DX 120/25 14515837 Fan Starter 22 18.5 - 22 500 x 500 x 250 NCF 160/25 14515537 Fan Starter 22 PTC 18.5 - 22 500 x 500 x 250 NCF DX 160/25 14515937
A conventional direct or Y/D- starter for NCF fans. Further details on request.
• Power 2.2 to 22kW • Protection class IP65 • Motor overload protector included • Transformer 150VA included • Control Voltage 24V AC • Time relay for delayed fan stop when remote started
Nederman Fan Inverter
The Nederman Fan Inverter detects the pressure changes in the extraction system and adjusts the speed of the fan accordingly.
The fan inverter:
• ensures the correct airflow for any given combination of extractors in use
• reduces noise levels that would otherwise occur if the system were under-loaded
• activates the frequency controller via a timer, switching on and off depending on working hours
The inclusion of manual or automatic dampers in the extraction system will also significantly improve its overall efficiency and reduce running costs. The diagram shows typical power savings in an extraction system when a fan inverter is installed.
Typical power savings with Nederman Fan Inverter
A modern frequency control for N series fans and NCF fans in process ventilation systems. Further details on request. • Range 1.1 - 37 kW • IP 54 (NEMA12) enclosure • Built-In RFI-filter Class B • Built-In motor overload protector • Built-In Fan Timer – real time clock for start and stop of system • Built-In pressure transducer and PID controller for constant pressure, in extraction system. Keep constant airflow in extractors. Energy saving, noise reduction • Pre-programmed for easy and quick commissioning • Clear text display, multi language
• Parameter locking for security • Diagnostics in the display • Energy counter
* In many applications the maximum fan power output is not required and gives the possibility to use one size smaller Fan Inverter.
Fan Inverter Motor power kW
Dimensions
mm For fan model Part no.
Fan Inverter 1,1 1,1 461 x 222 x 234 N24 14517837 Fan Inverter 1,5 1,5 461 x 222 x 234 N29*N40* NCF 30/15* 14517937 Fan Inverter 2,2 2,2 461 x 222 x 234 N29 N40 NCF 30/15 14518037 Fan Inverter 3,0 3,0 461 x 222 x 234 N29 N40 NCF 30/15 14511837 Fan Inverter 4,0 4,0 461 x 222 x 234 NCF 30/25 14511937 Fan Inverter 5,5 5,5 461 x 222 x 234 NCF 40/25 NCF 50/25 14512037 Fan Inverter 7,5 7,5 561 x 222 x 246 NCF 120/15 NCF 80/20 14512137 Fan Inverter 11 11 561 x 222 x 246 NCF 120/25* Fan Inverter 15 15 629 x 267 x 354 NCF 120/25,NCF 160/25* 14512637 Fan Inverter 18,5 18,5 629 x 267 x 354 NCF 160/25 14515137 Fan Inverter 22 22 760 x 267 x 285 NCF 240/25* 14515237 Fan Inverter 30 30 760 x 267 x 285 NCF 240/25 14515337 Fan Inverter 37 37 760 x 267 x 285 14515437
x= number of extractors open, y= fan power kW The grey area indicates saved power consumption
