CONVEYOR CALCULATION SHEET draft.xls

(1)

CALCULATION SHEET

No. PARAMETERS SYMBOL FORMULAR VALUVE Unit

BMCR I. INPUT DATA

1 INSTALLATION

Troughing Type 3 roll

Capacity Design Q 1,000 t/h

Conveying Length L 258.0 m

Lift H 17.9 m

Belt Width B 1,200 mm

Belt Speed v 1.68 m/s

Length of middle carrying roll I Idler length if 3 or 5 roll 465 mm

Troughing Angle λ 35 Degree

Incline Angle δ 4.8 Degree

2 MATERIAL

Material Name MEDIUM

Density ρ 1.50

Lump Size mm

Temperature 35

Surcharge Angle β 15 Degree

3 CONVEYOR BELT

Friction Coefficient of Pulleys μ 0.30

-Friction Coefficient of Pulleys at Start-Up 0.35

-Angle of Wrap 1 at Pulley Drive 1 210 Degree

Angle of Wrap at Snub Pulley 1 0 Degree

Angle of Wrap 2 at Pulley Drive 2 210 Degree

Angle of Wrap at Snub Pulley 2 0 Degree

Drive factor 0.50

-Drive factor at Start-Up 0.38

-Drive factor at Pulley -Drive 2 0.50

Drive factor at Pulley Drive 2 at Start-Up 0.38

4 FACTORS

Gravitational Acceleration g 9.81

Effective Degree of Filling φ 0.70

- Degree of Filling Normal working conditions 1

- Gradient of the installation 0.70

-Width Factor 277 kg/m

Length Factor 52

Working Conditions Factor 1

-Efficiency of the drive η For drives with fluid couplings 0.90

-II. DESIGN

1 CAPACITY

Loading width of outer rolls 282.50 mm

Load stream width b 1,030.00 mm

Cross-Sectional Area of load Stream A 0.1705

Cross-Sectional Area of load Stream for 5 roll NA

- Troughing Angle 2 0 Degree

Conveying Capacity

- Theoretical value 1,546.86 t/h

- Effective value 1,082.80 t/h

2 POWER REQUIREMENTS

Power for empty & load over the Horizontal 28.18 kW

Power for Lift or Fall 48.77 kW

Power for trippers, skirtboard friction, ploughs 0.00 kW

Power at Drive Pulley 76.95 kW

Required Motor power 85.50 kW

Slected Motor 110 kW

3 BELT TYPE

Friction Value Factor μ = 0.3 15

Breaking Strength Loss at Joint Factor Number of plies 0.75

Belt breaking strength k 916.12 N/mm

Material (carcase) EP

Nominal Breaking Strength Belt Class 1,000 N/mm

Number of Plies 4 ply

Carrying side Cover thickness 8 mm

Pulley side Cover thickness 4 mm

Cover Quality X

- Belt weight 25.40 kg/m

- Carcase thickness d 5.80 mm

4 PULLEY DIAMETER

Drive Pulley Calculation 626.40 mm

- Type of Belt Material Contruction SUPERFORT (Multiply Belt EP)

- Belt Material Factor 108

t/m3 o_C μA α₁ α12 α2 α₂₁ c1 c1A c₂ c2A m/s2 φ = φ1 * φ2 φ1 φ2 CB C_L m-1 kf I₁ m2 A5 m2 Q_m Qm' Qm' = Qm*φ P1 P2 P3 PT PT = P1+P2+P3 PM P_N CR C_V k_N Cv D'Tr D'Tr=d*CTr CTr

(2)

Tail Pulley, Tension Pulley B 500 mm

Snub Pulleys, Bend Pulleys etc. C 400 mm

Pulley revolutions 51 R/min

5 IDLER

Values for Idler Spacing

- Belt sag ratio 0.01

- Carrying side Application 1.2m 1.2 m

- Return side 2.0 m

Idler Diameter 133.0 mm

- Idler Rotation Not be greater than 650 rpm 241 r.p.m

Idler Length 465 mm

Mass of one set of carrying idler rollers 22.3 kg

Mass of one set of return idler rollers 19.3 kg

III. CALCULATION

1 Peripheral Force at Steady state working

Length Factor C 1.37

Friction Factor f 0.02

Mass of the rotating carrying and return idlers 28.23 kg/m

Mass of the belt 25.40 kg/m

Mass of the load 165.34 kg/m

Main Resistance 12,331.91 N

Secondary Resistance 4,562.81 N

Slope Resistance 29,034.23 N

Special Resistance 0.00 N

- Resistance caused by forward tilt of idler rollers 0.00

+ Carrying side + Return side

- Resistance from skirt places beyond - Resistance due to sideways discharge - Resistance due to trippers

- Resistance from skirting material beyond - Resistance to motion of bunker drag-out belts

Peripheral Force at Steady state working 45,928.94 N

Drive Motor at Pulley 77.16 kW

Required Motor Power 85.73 kW

Motor Power on Braked Installation NA kW

Installed Motor Power Selected Motor Power 110 kW

Min. Belt Tension for Control 28,068 N

2 Peripheral Force at Non-Steady state working

Type of Coupling Hydraulic Coupling

Start-up Factor 1.50

Pre Non-steady state 68,893.41 N

Peripheral Force at Start-Up (Non-steady state) 68,893.41 N

Acceleration 0.368

- Reduced mass of idlers 25.41 kg/m

- Reduced mass of drive elements 0.00 kg/m

- Reduced mass of non-driven (bend pulleys etc.) 0.00 kg/m

Acceleration Time 4.56 s

Acceleration Distance 3.83 m

3 Peripheral Force on Braking state

Braking time s

Acceleration #DIV/0!

Over-run distance 0.00 m

Reduced mass of the non-braked elements or pulleys kg

Non-braked elements force #DIV/0! N

Peripheral Force #DIV/0! N

4 Individual Resistances Main Resistance 12,331.91 N Secondary Resistance 4,562.81 N Friction Resistance - Carrying side 10,596.06 N - Return side 1,774.22 N Slope Resistance - Carrying side 33,494.44 N - Return side 4,460.21 N Inertial Resistance - Carrying side 19,724.02 N - Return side 3240.45 N 5 Belt Tension

A Drive System Single Pulley Head Drive

Runing - Steady state working

- Distribution for Head and Tail Drive NA

- Distribution for Dual Pulley Head Drive NA

-Total Peripheral Force 45,928.94 N

nT

hrel hrel = h/Io

Io Iu Iu = (2-3)*Io DR nR LR m_Ro mRu FU m'R m'G m'L F_H FN FSt FS F_S FSO FSU FSch FL FB FMf FBa FU PT PM PM PN Tmin FA k_A F'A FA aA m/s2 m'_Red m'Ared m'red tA sA tB aB m/s2 s_B mred FT FB FH FN Fo Fu Fsto Fstu Fao Fau x1 x1 = Fo/Fu x₂ FU

(3)

- Peripheral Force Pulley 2 NA N Total Power 77.16 kW - Motor 1 77.16 kW - Motor 2 NA kW Tension 22964.47 N Tension 20278.47 N Tension 20278.47 N Tension 68931.78 N Control 68893.41 N

Start Up - Non Steady state working

- Distribution for Head and Tail Drive NA

- Distribution for Dual Pulley Head Drive NA

-Total Peripheral Force 68893.41 N

- Peripheral Force Pulley 1 68893.41 N

- Peripheral Force Pulley 2 NA N

Total Power 115.74 kW - Motor 1 115.74 kW - Motor 2 NA kW Tension 26455.07 N Tension 27009.52 N Tension 27009.52 N Tension 95386.85 N Control 95348.48 N Braking state

B Belt Tension Correction (1st Adjustment) Correction with Fixed Take-up

Belt tension at rest 33113.30 N

Average belt tension at start-up T 43965.24 N

Correction value for Fixed Take-up 10851.94 N

Belt Tension Correction 79783.72 N

33816.41 N

31130.41 N

Check conditional Satisfied

Correction with Moveable Take-up

Location of Take-up Installed at the Tail

Take-up Tension 40556.94 N

Take-up Weight 4134.24 kg

Correction value for Moveable Take-up 6731.05 N

29695.52 N

27009.52 N

C Control of Minimum Belt Tension (2st Adjustment) 28067.97 N

Take-up Type Moveable Take-up

Belt Tension at Carrying side minimum 27009.52 N

Correction value 1058.44 N

30753.96 N 28067.97 N 28067.97 N 96445.29 N 27513.51 N 28067.97 N 28067.97 N

Belt Safety Factor

Steady state 11.73

-Non-Steady state 9.33

-Take-up Travel

Elongation value of the belt 10.50

-Rest state 1149.45 mm

Steady state 1675.07 mm

Non-Steady state 1843.83 mm

Troughing Trainsition 1686.31 mm

- Factor for carcase x Textile belt x=8 8.00

- Portion of belt in contact w/ side idler rollers s ST. belt x=16 367.50 mm

- Lift of Pulley h 64.55 mm

Reduced transition length 1169.88 mm

Convex Vertical Curve

- Factor for carcase x Textile belt x=125 125.00

- Convex Radius steel cord belt x=400 26.35 m

- Curve Length L 71519.14 m

- Deviation per idler α 2.00 Degree

- Number of Idlers in Curve z 3.00 Pieces

- Idler Picth Io 23839.71 m

Concave Vertical Curve

- Length from loading to curve Lx 40.00 m

- Belt tension at start of curve Tx 29710.77 N

- Concave Radius Ra 145.56 m FU2 PT P1 P2 T2 T2 = FU*c T3 T₄ T₁ T₁ x1A x1 = Fo/Fu x2A FUA FU1A FU2A PTA P_1A P2A TA2 T2 = FU*c TA3 TA4 T_A1 TA1 TM ∆T ∆T = T - T_M T1 T2 T3 T4 ∑T = ∑T_A FV GV GV = FV/g ∆T ∆T = TAi - Ti T₁ T2 T3 T4 TAi = Ti Tmin ∆T ∆T = T_min - T_i T1 T2 T₃ T4 TA1 TA2 T_A3 TA4 Tmin ≤ Ti S_B SA sp kD sp sp sp LM Lred Re
