1 SCOPE
This specification, based on the Saudi Aramco Engineering Standard SAES-L-105 covers the selection of materials for the process piping and utility piping for the Khursaniyah Gas Plant Project
2 DEFINITIONS
SAUDI ARAMCO Saudi Arabian Oil Company BTJV Bechtel Technip Joint Venture CONTRACTOR BTJV CONSTRUCTION CONTRACTOR HOLD
3 REFERENCES
The requirements contained in the latest editions (unless a year is specified) of the following codes and standards form part of this specification
3.1 ASME (American Society Mechanical Engineers)
B31.1 Power Piping
B31.3 (2002) Process Piping
B31.8 Gas Transmission and Distribution Piping Systems B1.1 Unified Inch Screw Threads (UN and UNR Thread Form) B1-20.1 Pipe Threads, General Purpose (Inch)
B16.5 Pipe Flanges and Flanged Fittings NPS ½ Through NPS 24 Metric/Inch Standard
B16.9 Factory-Made Wrought Buttwelding Fittings
B16.10 Face to Face and End to End Dimension of Valves B16.11 Forged Steel Fittings, Socket-Welding and Threaded
B16.20 Metallic Gaskets for Pipe Flanges Ring-Joint, Spiral-Wound and Jacketed
B16.21 Nonmetallic Gaskets for Pipe Flanges
B16.25 Buttwelding Ends
APP CK D JK PS PS/R S ENG’G PSD S PSD S PSD S DE S CRIP T ION ISSU ED FOR APPR O VAL ISSU ED FOR D E S IGN IS S U E D FOR CONS T RUCTION JO/EW O B I-- 3 1 92 B I-- 3 1 92 B I-- 3 1 92 DA TE 05/0 9/0 5 08/0 1/0 6 24/0 4/0 6 REV. NO . A B 0 DISCIPLINE ENGINEER ________________ DATE ___________ PROJECT ENGINEER ________________ DATE ___________ CERTIFIED ________________ DATE ___________ CONSTRUCTION AGENCY ________________ DATE ___________ OPERATIONS ________________ DATE ___________ EDS D VERIF ICATIO N CONTROL NUMB E R BY: __ ___ ___ ___ ___ DAT E _ ___ ___ ___ ___ RT IF IC AT E NO . __ ___ __ ___ __ ED, FOR ALL QUIR E M E N TS, ATE ___ ___ ___ __ ___ WING A ND THE INFORMA TION CONTA INE D HE RE IN A R E THE S O L E P R O PERTY OF S A UDI AR AM CO. NO R EPROD UCTION IN FU LL OR IN PAR T SH AL L B E O B TAINED FROM THIS DOCUM ENT W ITH O U
T THE WRITTEN CONSENT OF ITS
B16.42 Ductile Iron Pipe Flanges and Flanged Fittings Classes 150 and 300
B16.47 Large Diameter Steel Flanges NPS 26 Through NPS 60 B16.48 Steel Line Blanks
B18.2.2 Square and Hex Nuts (inch Series) B36.10M Welded and Seamless wrought steel Pipe B36.19M Stainless Steel Pipe
3.2 API (American Petroleum Institute)
API 5L Specification for Line Pipe
API 6D Specification for Ball Valves and Pipe Line Valves API 594 Check Valves: Flanged, Lug, Wafer and Butt Welding API 598 Valve Inspection and testing
API 599 Steel and Ductile Iron Plug Valves
API 600 Steel Gate Valves Flanged and Butt Welding Ends
API 602 Compact Steel Gate Valves Flanged, Threaded, Welding, Extended Body Ends
API 607 Fire Test for Soft Seated Quarter Turn Valves
API 608 Metal Ball Valves – Flanged, Threaded and Welding Ends API 609 Butterfly Valves, Lug-Type and Wafer Type
3.3 ASTM (American Society for Testing and Materials)
As designated in the individual line classes according to material selected
3.4 BSI (British Standards Institute)
BS1868 Steel Check Valves (Flanged and Butt Welding) for the Petroleum, Petrochemical and Allied Industries.
BS1873 Steel Globe and Globe Stop and Check Valves (Flanged and Butt-Welding Ends) for the Petroleum, Petrochemical and allied Industries
BS5352 Steel Wedge Gate, Globe and Check Valves 50mm and smaller for the Petroleum, Petrochemical and Allied Industries. BS6755 Specification for fire Testing requirements, Part 2 – Testing of
APP CK D JK PS PS/R S ENG’G PSD S PSD S PSD S DE S CRIP T ION ISSU ED FOR APPR O VAL ISSU ED FOR D E S IGN IS S U E D FOR CONS T RUCTION JO/EW O B I-- 3 1 92 B I-- 3 1 92 B I-- 3 1 92 DA TE 05/0 9/0 5 08/0 1/0 6 24/0 4/0 6 REV. NO . A B 0 DISCIPLINE ENGINEER ________________ DATE ___________ PROJECT ENGINEER ________________ DATE ___________ CERTIFIED ________________ DATE ___________ CONSTRUCTION AGENCY ________________ DATE ___________ OPERATIONS ________________ DATE ___________ EDS D VERIF ICATIO N CONTROL NUMB E R BY: __ ___ ___ ___ ___ DAT E _ ___ ___ ___ ___ CE RT IF IC AT E R EV. NO . __ ___ __ ___ __ CO VER ED, FOR ALL A TI ON RE QUIR E M E N TS, E TI ON CERTIFIC ATE _ ____ ___ ___ ___ __ ___ DRA WING A ND THE INFORMA TION CONTA INE D HE RE IN A R E THE S O L E P R O PERTY OF S A UDI AR AM CO. NO R EPROD UCTION IN FU LL OR IN PAR T SH AL L B E O B TAINED FROM THIS DOCUM ENT W ITH O U
T THE WRITTEN CONSENT OF ITS
3.5 MSS (Manufacturers Standardization Society)
MSS SP-6 Standard Finishes for Contact Faces of Pipe Flanges and Connecting-End Flanges of Valves and Fittings
MSS SP-25 Standard Marking System for Valves, Fittings, Flanges and Unions
MSS SP-43 Wrought Stainless Steel Butt-Welding Fittings MSS SP-44 Steel Pipeline Flanges
MSS SP-75 Specification for High Test, Wrought, Butt Welding Fittings MSS SP-80 Bronze Gate, Globe, Angle and Check Valves
MSS SP-83 Class 3000 Steel Pipe Unions Socket Welding and Threaded MSS SP-95 Swaged Nipples and Bull Plugs
MSS SP-97 Integrally Reinforced Forged
3.6 SAMSS (Saudi Aramco Material System Specifications)
01-SAMSS-010 Fabricated Carbon Steel Piping
01-SAMSS-016 Qualification of Pipeline, In- Plant Piping and Pressure Vessel Steel for Resistance to HIC
01-SAMSS-024 Pipe Handling and Nesting
01-SAMSS-029 RTR (Fiberglass) Sewer Pipe and Fittings for Gravity Flow 01-SAMSS-031 Product Marking for Pipe of Less than Six Inch Nominal Size 01-SAMSS-034 RTR (Fiberglass) Pressure Pipe and Fittings
01-SAMSS-035 API Line Pipe
02-SAMSS-001 Piping Components for Low Temperature Service 02-SMASS-005 Butt Welding Pipe Fittings
02-SAMSS-011 Forged Steel Weld Neck Flanges for Low and Intermediate Temperature Service
04-SAMSS-001 Gate Valves 04-SAMSS-002 Globe Valves
APP CK D JK PS PS/R S ENG’G PSD S PSD S PSD S DE S CRIP T ION ISSU ED FOR APPR O VAL ISSU ED FOR D E S IGN IS S U E D FOR CONS T RUCTION JO/EW O B I-- 3 1 92 B I-- 3 1 92 B I-- 3 1 92 DA TE 05/0 9/0 5 08/0 1/0 6 24/0 4/0 6 REV. NO . A B 0 DISCIPLINE ENGINEER ________________ DATE ___________ PROJECT ENGINEER ________________ DATE ___________ CERTIFIED ________________ DATE ___________ CONSTRUCTION AGENCY ________________ DATE ___________ OPERATIONS ________________ DATE ___________ EDS D VERIF ICATIO N CONTROL NUMB E R BY: __ ___ ___ ___ ___ DAT E _ ___ ___ ___ ___ RT IF IC AT E NO . __ ___ __ ___ __ ED, FOR ALL QUIR E M E N TS, ATE ___ ___ ___ __ ___ WING A ND THE INFORMA TION CONTA INE D HE RE IN A R E THE S O L E P R O PERTY OF S A UDI AR AM CO. NO R EPROD UCTION IN FU LL OR IN PAR T SH AL L B E O B TAINED FROM THIS DOCUM ENT W ITH O U
T THE WRITTEN CONSENT OF ITS
04-SAMSS-005 Check Valves, Swing Type 04-SAMSS-035 General Requirements for Valves
04-SAMSS-048 Valve Inspection and Testing Requirements 04-SAMSS-051 Ball Valves, API 6D
09-SAMSS-107 Application of Composite Fluoropolymer/Ceramic Coatings to Fasteners
3.7 Saudi Aramco Standard Drawings
AA-0366865 Cathodic Protection, Electrical Insulating / Isolating Assemblies AC-036413 Raised Face Orifice Flange Assembly
AC-036630 Installation of Jack Screws for Flanged Joints
AC-036633 Spectacle Plates, Blinds & Spacers for Class 150 RF Flanges AD-036636 Spectacle Plates, Blinds & Spacers for Class 600 RF Flanges AD-036731 Spectacle Plates, Blinds & Spacers for Class 300 RF Flanges
3.8 Saudi Aramco Engineering Specifications
SAES-A-301 Materials Resistant to Sulphide Stress Corrosion Cracking SAES-H-002 Internal and External Coatings for Steel Pipelines and Piping SAES-L-105 Piping Material Selection
SAES-L-108 Selection of Valves
SAES-L-110 Limitations on Pipe Flanged Joints and Components SAES –L 130 Material for Low Temperature Service
3.9 NACE (National Association of Corrosion Engineers)
NACE MR 0175 (2002)
3.10 EEMUA (Engineering Equipment and Materials Users Associations)
EEMUA 144 90/10 Copper Nickel Alloy Tubes – Seamless and Welded EEMUA 145 90/10 Copper Nickel Alloy Flanges – Composite and Solid EEMUA 146 90/10 Copper Nickel Alloy Fittings
APP CK D JK PS PS/R S ENG’G PSD S PSD S PSD S DE S CRIP T ION ISSU ED FOR APPR O VAL ISSU ED FOR D E S IGN IS S U E D FOR CONS T RUCTION JO/EW O B I-- 3 1 92 B I-- 3 1 92 B I-- 3 1 92 DA TE 05/0 9/0 5 08/0 1/0 6 24/0 4/0 6 REV. NO . A B 0 DISCIPLINE ENGINEER ________________ DATE ___________ PROJECT ENGINEER ________________ DATE ___________ CERTIFIED ________________ DATE ___________ CONSTRUCTION AGENCY ________________ DATE ___________ OPERATIONS ________________ DATE ___________ EDS D VERIF ICATIO N CONTROL NUMB E R BY: __ ___ ___ ___ ___ DAT E _ ___ ___ ___ ___ CE RT IF IC AT E R EV. NO . __ ___ __ ___ __ CO VER ED, FOR ALL A TI ON RE QUIR E M E N TS, E TI ON CERTIFIC ATE _ ____ ___ ___ ___ __ ___ DRA WING A ND THE INFORMA TION CONTA INE D HE RE IN A R E THE S O L E P R O PERTY OF S A UDI AR AM CO. NO R EPROD UCTION IN FU LL OR IN PAR T SH AL L B E O B TAINED FROM THIS DOCUM ENT W ITH O U
T THE WRITTEN CONSENT OF ITS
4 DOCUMENT
CONFLICT
This document is supplementary to the mandatory requirement of Saudi Aramco engineering standards, materials systems specification and standard drawings.
If any conflict occurs between this document and the Saudi Aramco Standards, Specification and Standard drawings then the Saudi Aramco standards, specifications and standard drawings shall govern.
5 DESIGN
5.1 Codes and Standards
Engineering requirements for design of the piping system are in accordance with ASME B31.3, ASME B31.8 (as applicable) and the applicable SAES-L Specifications.
5.2 Material
Piping materials and limitations (pressure, temperature, diameter) are shown in attached piping classes.
All 316 stainless steel pipe, fittings and flanges shall be supplied dual grade 316/316L with chemical compositions of 316L grade materials but with the mechanical properties of 316 stainless steel.
Charpy impact testing shall be carried out on all carbon steel pipe and wrought piping components, irrespective of material grade, with wall thickness greater than 25mm. Testing shall be in accordance with ASME B31.3 with impact values being 34J min average and 27J min individual for a standard 10mm x 10mm specimen. Impact testing shall be carried out on base material, weld deposit and HAZ.
See BTJV Doc No 25136-000-3PS-P000-P0004 - General Supply Specification for Piping Material, for specific material requirements.
For carbon steel piping, the following services require PWHT after piping fabrication: a) All Caustic Soda solutions at all temperatures.
b) All Diglycolamine (DGA) solutions above 270 °F design temperature.
5.3 Piping
Components
5.3.1 Pipe
The minimum wall thickness/schedule shall be that shown on each piping class. Calculated thickness shall not be less than D/135
Nominal pipe sizes NPS ¼, 1¼, 2½, 3½, 5 and 22 shall not be used, except as required to mate with equipment connections. Where necessary to match a manufacturer’s equipment connection a reducer must be employed immediately to increase to the next available acceptable pipe size.
APP CK D JK PS PS/R S ENG’G PSD S PSD S PSD S DE S CRIP T ION ISSU ED FOR APPR O VAL ISSU ED FOR D E S IGN IS S U E D FOR CONS T RUCTION JO/EW O B I-- 3 1 92 B I-- 3 1 92 B I-- 3 1 92 DA TE 05/0 9/0 5 08/0 1/0 6 24/0 4/0 6 REV. NO . A B 0 DISCIPLINE ENGINEER ________________ DATE ___________ PROJECT ENGINEER ________________ DATE ___________ CERTIFIED ________________ DATE ___________ CONSTRUCTION AGENCY ________________ DATE ___________ OPERATIONS ________________ DATE ___________ EDS D VERIF ICATIO N CONTROL NUMB E R BY: __ ___ ___ ___ ___ DAT E _ ___ ___ ___ ___ RT IF IC AT E NO . __ ___ __ ___ __ ED, FOR ALL QUIR E M E N TS, ATE ___ ___ ___ __ ___ WING A ND THE INFORMA TION CONTA INE D HE RE IN A R E THE S O L E P R O PERTY OF S A UDI AR AM CO. NO R EPROD UCTION IN FU LL OR IN PAR T SH AL L B E O B TAINED FROM THIS DOCUM ENT W ITH O U
T THE WRITTEN CONSENT OF ITS
For nominal pipe sizes greater than NPS 24 pipe sizes shall, wherever possible, increase in increments of 6 inches up to and included NPS 48. Above NPS 48 nominal pipe sizes shall increase in increments of 4 inches.
Pipe sizes not included in ASME B36.10 / B36.19 shall not be used.
Carbon steel pipe NPS 6 and larger specified to API 5L shall be purchased in accordance with Saudi Aramco Material System Specification 01-SAMSS-035.
Carbon steel and low temperature carbon steel pipe shall be seamless up to and included NPS 24 and SAW/EFW larger than NPS 24.
API 5L pipe shall have a joint factor of 0.95. All other welded carbon steel pipe shall be 100% radiographed and have a joint factor of 1.0.
Stainless steel pipes shall be seamless up to NPS 12 and EFW for NPS 14 and larger, with 100% radiography and have a joint factor of 1.0.
All welded carbon steel pipe specified as NACE shall comply with the requirements of Saudi Aramco Material System Specification 01-SAMSS-016, Qualification of Pipeline, In- Plant Piping and Pressure Vessel Steel for Resistance to HIC.
All carbon steel, low temperature carbon steel and stainless steel pipes specified to NACE shall be supplied in accordance to NACE MR01-75 and Saudi Aramco Engineering Standards SAES-A-301, Material Resistant to Sulfide Stress Corrosion. All buried steel pipe shall be externally protected against corrosion per Saudi Aramco Specification SAES-H-002.
Reinforced Thermosetting Resin (RTR) pipe used above ground, if any, shall have external ultraviolet protection.
Chlorinated Polyvinyl Chloride (cPVC) piping material used above ground shall have external ultraviolet protection.
Galvanized pipe and couplings shall be supplied galvanized in accordance with ASTM A53, with threads free of galvanizing.
5.3.2 Flanges
Flat face flanges shall only be used to match cast iron valves or non-metallic flanges or to match flat face flanges on equipment. Flat face finish shall be in accordance with MSS-SP-6
Flange face finish of raised face flanges shall be as specified in ASME B16.5 and supplied in accordance with ASME B46.1.
All flanges Class 900 and above shall be supplied with Ring Type Joint.
Flange joints between spacers or blinds shall be fitted with jackscrews in accordance with Saudi Aramco standard drawing AC-036630
Orifice flanges shall be supplied complete with jackscrews and threaded tap plugs installed in accordance with Saudi Aramco Standard Drawing AC-036413.
APP CK D JK PS PS/R S ENG’G PSD S PSD S PSD S DE S CRIP T ION ISSU ED FOR APPR O VAL ISSU ED FOR D E S IGN IS S U E D FOR CONS T RUCTION JO/EW O B I-- 3 1 92 B I-- 3 1 92 B I-- 3 1 92 DA TE 05/0 9/0 5 08/0 1/0 6 24/0 4/0 6 REV. NO . A B 0 DISCIPLINE ENGINEER ________________ DATE ___________ PROJECT ENGINEER ________________ DATE ___________ CERTIFIED ________________ DATE ___________ CONSTRUCTION AGENCY ________________ DATE ___________ OPERATIONS ________________ DATE ___________ EDS D VERIF ICATIO N CONTROL NUMB E R BY: __ ___ ___ ___ ___ DAT E _ ___ ___ ___ ___ CE RT IF IC AT E R EV. NO . __ ___ __ ___ __ CO VER ED, FOR ALL A TI ON RE QUIR E M E N TS, E TI ON CERTIFIC ATE _ ____ ___ ___ ___ __ ___ DRA WING A ND THE INFORMA TION CONTA INE D HE RE IN A R E THE S O L E P R O PERTY OF S A UDI AR AM CO. NO R EPROD UCTION IN FU LL OR IN PAR T SH AL L B E O B TAINED FROM THIS DOCUM ENT W ITH O U
T THE WRITTEN CONSENT OF ITS
Flanges NPS 24 and smaller shall be supplied in accordance with ASME B16.5 and for sizes larger than NPS 24 in accordance with ASME B16.47 Series A.
Galvanized flanges shall be supplied galvanized in accordance with ASTM A53, with threads and gasket contact area free of galvanizing.
5.3.3 Fittings
In Sour service socket weld or threaded fittings shall not be used. Butt weld fittings shall be used for all sizes.
For non sour services socket weld fitting shall normally be used for NPS 1½ and smaller and butt weld fittings for NPS 2 and larger.
Butt weld elbows shall be long radius.
Carbon steel and low temperature carbon steel butt weld fittings up to and including NPS 24 shall be seamless. Fittings greater than NPS 24 shall be EFW with 100% radiography of weld seam and have a joint factor of 1.0.
Stainless steel butt weld fittings up to and including NPS 12 shall be seamless. Fittings greater than NPS 12 shall be EFW with 100% radiography of weld seam and have a joint factor of 1.0.
Galvanized fittings shall be supplied galvanized in accordance with ASTM A53, with threads free of galvanizing.
Fitting Type Manufacturer’s Standard Aramco Standard Butt weld Fittings ASME B16.9 02-SAMSS-005 Forged Fittings ASME B16.11 None
Unions MSS SP-83 None
O’lets MSS SP-97 None
Butt Weld (High Yield) MSS SP-75 02-SAMSS-005
Swages MSS SP-95 None
Full couplings, where allowed, shall be used for connections of NPS 1½ and smaller pipes in straight runs. Quantities and supply shall be within Construction Contractor’s scope.
Unless otherwise stated, the wall thickness of butt welded fitting shall be equal to the thickness of connected pipe.
In general, all nipples of sizes NPS 1̕½ and smaller shall be seamless and cut from pipe and have a minimum wall thickness of schedule 80.
APP CK D JK PS PS/R S ENG’G PSD S PSD S PSD S DE S CRIP T ION ISSU ED FOR APPR O VAL ISSU ED FOR D E S IGN IS S U E D FOR CONS T RUCTION JO/EW O B I-- 3 1 92 B I-- 3 1 92 B I-- 3 1 92 DA TE 05/0 9/0 5 08/0 1/0 6 24/0 4/0 6 REV. NO . A B 0 DISCIPLINE ENGINEER ________________ DATE ___________ PROJECT ENGINEER ________________ DATE ___________ CERTIFIED ________________ DATE ___________ CONSTRUCTION AGENCY ________________ DATE ___________ OPERATIONS ________________ DATE ___________ EDS D VERIF ICATIO N CONTROL NUMB E R BY: __ ___ ___ ___ ___ DAT E _ ___ ___ ___ ___ RT IF IC AT E NO . __ ___ __ ___ __ ED, FOR ALL QUIR E M E N TS, ATE ___ ___ ___ __ ___ WING A ND THE INFORMA TION CONTA INE D HE RE IN A R E THE S O L E P R O PERTY OF S A UDI AR AM CO. NO R EPROD UCTION IN FU LL OR IN PAR T SH AL L B E O B TAINED FROM THIS DOCUM ENT W ITH O U
T THE WRITTEN CONSENT OF ITS
5.3.4 Valves
Valves shall comply with the requirements of the following SAMSS 04-SAMSS-001 Gate Valves
04-SAMSS-002 Globe Valves
04-SAMSS-003 Additional Requirements for Low Temperature Valves 04-SAMSS-005 Swing Check Valves
04-SAMSS-035 General Requirements for Valves
04-SAMSS-048 Valve Inspection and Testing Requirements 04-SAMSS-051 Ball Valves API 6D
All valves shall conform to 04-SAMSS-035 and inspection and testing shall comply with the requirements of 04-SAMSS-048.
All valves for use in low temperature applications shall comply to the requirements of 04-SAMSS-003 Additional Requirements for Low Temperature Valves.
Types of valves and valve trim shall be in accordance with the individual Piping Classes, based on service conditions.
All SW globe and check valves shall conform to API 602 as applicable except when full bore is required.
All ball valves shall be full bore.
Unless otherwise noted, face to face/end to end dimensions shall be in accordance with ASME B16.10 or API 6D whichever is applicable.
In steam service, Saudi Aramco specification shall be applied with added appendices as follows:
Gate 04-SAMSS-001 Appendix D Globe 04-SAMSS-002 Appendix D Swing Check 04-SAMSS-005 Appendix C
Stainless steel valves shall be supplied dual grade 316/316L for socket weld and butt weld valves and dual grade or standard grade for flanged valves. L grade valves are not acceptable alternatives.
Valves specified to NACE shall conform to the requirements of NACE MR0175-2002 and SAES-A-301.
Ball, butterfly and plug valves shall be fire-safe design, except where used on water/utility services. Welded bodies shall not be used.
APP CK D JK PS PS/R S ENG’G PSD S PSD S PSD S DE S CRIP T ION ISSU ED FOR APPR O VAL ISSU ED FOR D E S IGN IS S U E D FOR CONS T RUCTION JO/EW O B I-- 3 1 92 B I-- 3 1 92 B I-- 3 1 92 DA TE 05/0 9/0 5 08/0 1/0 6 24/0 4/0 6 REV. NO . A B 0 DISCIPLINE ENGINEER ________________ DATE ___________ PROJECT ENGINEER ________________ DATE ___________ CERTIFIED ________________ DATE ___________ CONSTRUCTION AGENCY ________________ DATE ___________ OPERATIONS ________________ DATE ___________ EDS D VERIF ICATIO N CONTROL NUMB E R BY: __ ___ ___ ___ ___ DAT E _ ___ ___ ___ ___ CE RT IF IC AT E R EV. NO . __ ___ __ ___ __ CO VER ED, FOR ALL A TI ON RE QUIR E M E N TS, E TI ON CERTIFIC ATE _ ____ ___ ___ ___ __ ___ DRA WING A ND THE INFORMA TION CONTA INE D HE RE IN A R E THE S O L E P R O PERTY OF S A UDI AR AM CO. NO R EPROD UCTION IN FU LL OR IN PAR T SH AL L B E O B TAINED FROM THIS DOCUM ENT W ITH O U
T THE WRITTEN CONSENT OF ITS
All butterfly valves in hydrocarbon service shall be flanged, API 609 Series B design. Soft seated ball and butterfly valves, and tight shut-off Gate and Globe valves with PTFE seat inserts shall be limited to a maximum design temperature of 250°F.
Gear Operated Valves :
Valves shall be actuated by gear operator as specified below:
Cl 150 ≥24” Cl 300 ≥16” Cl 600 ≥8” Gate Valve Cl 900 & Higher ≥6” Cl 150 ≥14” Cl 300 ≥10” Cl 600 ≥8” Cl 900 ≥6” Globe Valve Cl 1500 ≥4” Cl 150 ≥6” Cl 300 ≥4” Ball Valve Cl 600 & Higher ≥3”
Cl 150 Refer to Piping Class Plug Valves
Cl 300 Refer to Piping Class Butterfly Valves Cl 150/300 Refer to Piping Class
5.3.5 Branch Connections
Branch connections for metallic classes shall be in accordance with SAES-L-110 unless shown otherwise in the pipe classes. Welded branch connections shall be verified in accordance with ASME B31.3 para 304.3.
5.3.6 Threads
Threads for threaded pipes, fittings, flanges and valves shall be in accordance with ASME B1.20.1 taper threads.
PTFE (Teflon) tape shall not be used.
Seal welding of threaded joints shall be in accordance with SAES-L-110. 5.3.7 Gaskets
Asbestos in any form shall not be used in the manufacture and construction of gaskets.
APP CK D JK PS PS/R S ENG’G PSD S PSD S PSD S DE S CRIP T ION ISSU ED FOR APPR O VAL ISSU ED FOR D E S IGN IS S U E D FOR CONS T RUCTION JO/EW O B I-- 3 1 92 B I-- 3 1 92 B I-- 3 1 92 DA TE 05/0 9/0 5 08/0 1/0 6 24/0 4/0 6 REV. NO . A B 0 DISCIPLINE ENGINEER ________________ DATE ___________ PROJECT ENGINEER ________________ DATE ___________ CERTIFIED ________________ DATE ___________ CONSTRUCTION AGENCY ________________ DATE ___________ OPERATIONS ________________ DATE ___________ EDS D VERIF ICATIO N CONTROL NUMB E R BY: __ ___ ___ ___ ___ DAT E _ ___ ___ ___ ___ RT IF IC AT E NO . __ ___ __ ___ __ ED, FOR ALL QUIR E M E N TS, ATE ___ ___ ___ __ ___ WING A ND THE INFORMA TION CONTA INE D HE RE IN A R E THE S O L E P R O PERTY OF S A UDI AR AM CO. NO R EPROD UCTION IN FU LL OR IN PAR T SH AL L B E O B TAINED FROM THIS DOCUM ENT W ITH O U
T THE WRITTEN CONSENT OF ITS
Spiral wound and ring joint type gaskets shall be in accordance with ASME B16.20 5.3.8 Bolts
Bolts, cap screws and nuts shall be threaded in accordance with ASME B1.1.
Where flange insulation assembly is required, bolt lengths shall be calculated to suit the application in accordance with Saudi Aramco Standard Drawing AA-036865. Bolts used in underground piping shall be ceramic fluoropolymer coated as per 09-SAMSS-107.
All stud bolts shall be threaded full length and supplied with two heavy series hexagon nuts.
All jack screws and hexagon headed bolts shall have threads extended to the underside of the head.
5.4 Piping
Material
Class Coding System
5.4.1 The piping class coding system consists of four alpha-numeric fields containing one or two characters each. Each field describes various features of the piping class. 5.4.1.1 First Field
The first field defines the pressure rating and consists of one or two numeric characters. Refer to paragraph 5.4.2.1
5.4.1.2 Second Field
The second field defines the pipe material and consists of two alpha characters. Refer to paragraph 5.4.2 2
5.4.1.3 Third Field
The third field defines the corrosion or erosion allowance and consists of one numeric character. Refer to paragraph 5.4.2.3
5.4.1.4 Fourth Field
The fourth field defines the service and consists of one alpha character. Refer to paragraph 5.4.2.4. The alpha character is also suffixed by numeric characters, which differentiate specific pipe class requirements based on service fluid.
An example of a complete piping line designator is “1CA2P03”. This designator specifies an ASME pressure class 150, impact tested carbon steel piping system with 3.2mm corrosion allowance, designed for general process service, with specific requirement for pipe class service fluids.
APP CK D JK PS PS/R S ENG’G PSD S PSD S PSD S DE S CRIP T ION ISSU ED FOR APPR O VAL ISSU ED FOR D E S IGN IS S U E D FOR CONS T RUCTION JO/EW O B I-- 3 1 92 B I-- 3 1 92 B I-- 3 1 92 DA TE 05/0 9/0 5 08/0 1/0 6 24/0 4/0 6 REV. NO . A B 0 DISCIPLINE ENGINEER ________________ DATE ___________ PROJECT ENGINEER ________________ DATE ___________ CERTIFIED ________________ DATE ___________ CONSTRUCTION AGENCY ________________ DATE ___________ OPERATIONS ________________ DATE ___________ EDS D VERIF ICATIO N CONTROL NUMB E R BY: __ ___ ___ ___ ___ DAT E _ ___ ___ ___ ___ CE RT IF IC AT E R EV. NO . __ ___ __ ___ __ CO VER ED, FOR ALL A TI ON RE QUIR E M E N TS, E TI ON CERTIFIC ATE _ ____ ___ ___ ___ __ ___ DRA WING A ND THE INFORMA TION CONTA INE D HE RE IN A R E THE S O L E P R O PERTY OF S A UDI AR AM CO. NO R EPROD UCTION IN FU LL OR IN PAR T SH AL L B E O B TAINED FROM THIS DOCUM ENT W ITH O U
T THE WRITTEN CONSENT OF ITS
5.4.2 Field Definition Tables 5.4.2.1 Pressure Rating
Symbol Nominal Pressure Rating or Class
(ASME B16.5/B16.47 Flange Class) 1 150 3 300 4 400 6 600 9 900 15 1500 25 2500 12 125 FF, ASME B16.1/150 FF ASME B16.5
Symbol Nominal Pressure Rating or Class (Specific Rating Designations)
80 Non-pressure 85 Pressure Class 75/150 RF 90 Class 3000, API 6A 95 Class 10000,API 6A 5.4.2.2 Line Material Symbol Material
CA Impact Tested Carbon Steel CB Killed Carbon Steel
CC Low Carbon Steel CS Carbon Steel CG Galvanized Carbon Steel CJ 1-1/4 Cr-1/2 Mo Alloy Steel CK 2-1/4 Cr-1 Mo Alloy Steel CL 5 Cr-1 Mo Alloy Steel CM 9 Cr-1 Mo Alloy Steel BC Copper Tubing BD 90-10 Cu-Ni DC Cast Iron, Grey
FE Glass Fiber Reinforced Epoxy LC Cement-Lined Carbon Steel LE Epoxy-lined Carbon Steel
LP Polypropylene-lined Carbon Steel
NM Monel 400
NR Incoloy 800 NT Carpenter20 (Alloy 20) PU CPVC(Chlorinated PVC) PV PVC (Poly Vinyl Chloride) SC Type 304 Stainless Steel SD Type 316/316L Stainless Steel SV AVESTA 254 SMO Stainless Steel
APP CK D JK PS PS/R S ENG’G PSD S PSD S PSD S DE S CRIP T ION ISSU ED FOR APPR O VAL ISSU ED FOR D E S IGN IS S U E D FOR CONS T RUCTION JO/EW O B I-- 3 1 92 B I-- 3 1 92 B I-- 3 1 92 DA TE 05/0 9/0 5 08/0 1/0 6 24/0 4/0 6 REV. NO . A B 0 DISCIPLINE ENGINEER ________________ DATE ___________ PROJECT ENGINEER ________________ DATE ___________ CERTIFIED ________________ DATE ___________ CONSTRUCTION AGENCY ________________ DATE ___________ OPERATIONS ________________ DATE ___________ EDS D VERIF ICATIO N CONTROL NUMB E R BY: __ ___ ___ ___ ___ DAT E _ ___ ___ ___ ___ RT IF IC AT E NO . __ ___ __ ___ __ ED, FOR ALL QUIR E M E N TS, ATE ___ ___ ___ __ ___ WING A ND THE INFORMA TION CONTA INE D HE RE IN A R E THE S O L E P R O PERTY OF S A UDI AR AM CO. NO R EPROD UCTION IN FU LL OR IN PAR T SH AL L B E O B TAINED FROM THIS DOCUM ENT W ITH O U
T THE WRITTEN CONSENT OF ITS
5.4.2.3 Corrosion Allowance
Symbol Corrosion Allowance
0 Zero Corrosion Allowance 1 1.6mm
2 3.2mm 3 4.8mm 4 6.4mm
9 Corrosion allowance as noted. Refer to SAE-L-033 for specific corrosion protection requirements 5.4.2.4 Service Symbol Service A Acid C Caustic D Drain/Sewer H Hydrogen
P Process (General Hydrocarbon) Q Chlorination Gas (Owner designator) T Wellhead piping (Owner designator) U Utility
W Water (Owner designator)
APP CK D JK PS PS/R S ENG’G PSD S PSD S PSD S DE S CRIP T ION ISSU ED FOR APPR O VAL ISSU ED FOR D E S IGN IS S U E D FOR CONS T RUCTION JO/EW O B I-- 3 1 92 B I-- 3 1 92 B I-- 3 1 92 DA TE 05/0 9/0 5 08/0 1/0 6 24/0 4/0 6 REV. NO . A B 0 DISCIPLINE ENGINEER ________________ DATE ___________ PROJECT ENGINEER ________________ DATE ___________ CERTIFIED ________________ DATE ___________ CONSTRUCTION AGENCY ________________ DATE ___________ OPERATIONS ________________ DATE ___________ EDS D VERIF ICATIO N CONTROL NUMB E R BY: __ ___ ___ ___ ___ DAT E _ ___ ___ ___ ___ CE RT IF IC AT E R EV. NO . __ ___ __ ___ __ CO VER ED, FOR ALL A TI ON RE QUIR E M E N TS, E TI ON CERTIFIC ATE _ ____ ___ ___ ___ __ ___ DRA WING A ND THE INFORMA TION CONTA INE D HE RE IN A R E THE S O L E P R O PERTY OF S A UDI AR AM CO. NO R EPROD UCTION IN FU LL OR IN PAR T SH AL L B E O B TAINED FROM THIS DOCUM ENT W ITH O U
T THE WRITTEN CONSENT OF ITS
ATTACHMENT 1
PIPING MATERIAL SERVICE CLASS INDEX
The Service Class Index serves as a guide to the Pipe Classes and summarizes each Pipe Class by listing the ASME Design Code, Primary Material, ASME Class and Flange Facing, Corrosion Allowance, Temperature Limits and Services, etc.
Class Name Rev Max Pipe Size Design Code Service Press/Temp Limit psig@°F Flange Rating & Facing Corr Allow mm
Pipe Material Fittings Valve Body Valve Trim Gasket
12BD0U01 2
4 ASME B31.3
Fire Water (FW) Utility Water (UW)
200 @ 32
200 @ 200 PN 20 FF 0 90/10 Cu/Ni 90/10 Cu/Ni Bronze Bronze Full Face Synthetic Fibre
12CG0U01 2
12 ASME B31.3
Air (A)
Instrument Air (IA) Nitrogen (N) 150 @ 32 150 @ 230 Cl 125 FF ≥ ≤ 4” -1.63” - 0 Galv. CS ≤ 3 A106-B ≥ 4 A105N- Galv A234-WPB A105N A216-WCB
Trim 8 Full Face
Synthetic Fibre
12FE0A06 2
36 ASME B31.3
Acid Sewer (AS)
130 @ 32 130 @ 200
Cl 125 FF
0 RTR Epoxy RTR Epoxy A216-WCB
Epoxy Lined
Alloy 20 Full Face
Elastomer 12FE0U16
2
68 ASME B31.3
Acid Hydrocarbon (AH) Boiler Blow Down (BBD) Cooling Water Supply (CWS) Cooling Water Return (CWR)
Drinking Water (DW)
Oily Water (OW)
Oily Water Sewer (OWS)
Oil & Oil Products (P) Process Water (PW) Gravity Storm Water Sewer(SCR)
Storm Sewer (SR) Sanitary Sewer (SWS) Treated Water (TW) Utility Water (UW) Waste Water (WW) Underground 145 @ 32 145 @ 200 130 @ 240 Cl 125 FF
0 RTR Epoxy RTR Epoxy A216-WCB
Epoxy Lined
Bronze Full Face
Class Name Rev Max Pipe Size Design Code Service Press/Temp Limit psig@°F Flange Rating & Facing Corr Allow mm
Pipe Material Fittings Valve Body Valve Trim Gasket
12LE0U01 2
68 ASME B31.3
Bio Sludge (BS) Oily Sludge (OS) Oily Water (OW)
Oily Water Sewer (OWS) Oil & Oil Products (P) Process Water (PW) Sewer (Storm) (SR) Sanitary Sewer (SWS) Treated Water (TW) Utility Water (UW) Water (W) Waste Water (WW) 195 @ 32 195 @ 150 130 @ 240 Cl 125
FF 0 FBE lined CS FBE lined CS A216-WCB Epoxy Lined Bronze Full Elastomer Face
12PU0U16 2
10 ASME B31.3
Drinking Water (DW)
150 @ 32
150 @ 73 Cl 125 FF 0 CPVC CPVC CPVC/ DI Epoxy Lined CPVC/ Bronze Full Face Elastomer
15SD0P01 2
12 ASME B31.3
Oil & Oil Products (P) SOUR – MR0175-2002 1840 @ -100 1840 @ 160 Cl1500 RTJ 0 SS A312-316/316L A182-F316/316L A403-WP316/316L A182-F316/316L A351 CF8M Trim 12 316SS Ring 15SD0U01 2 6 ASME B31.3 Chemical (C) 3600 @-50
2480 @ 450 Cl1500 RTJ 0 SS 316/316L A312- A182-F316/316L A403-WP316/316L A182-F316/316L A351 CF8M Trim 12 316SS Ring
1CA1P03 2
60 ASME B31.3
Oil & Oil Product (P) SOUR - MR0175-2002
265 @ -50
125 @ 650 Cl 150 RF 1.6 ITCS A671-CC65 A333-6
Cl22
A350-LF2N Cl 1
A420-WPL6 A350-LF2N Cl1/ A352-LCB Trim 12 Sp Wound 316SS/Graph
1CA2P03 2
68 ASME B31.3
Oil & Oil Products (P) Relief Line (RL) Sour Water (SOW)
265 @ -50
192 @ 425
125 @ 650
Cl 150
RF 3.2 ITCS A671-CC65 A333-6
Cl22
A350-LF2N Cl 1
Class Name Rev Max Pipe Size Design Code Service Press/Temp Limit psig@°F Flange Rating & Facing Corr Allow mm
Pipe Material Fittings Valve Body Valve Trim Gasket
1CA4P03 2
68 ASME B31.3
Blow Down (BD) Relief Line (RL)
Oil & Oil Products (P)
SOUR - MR0175-2002 265 @ -50 185 @ 450 140 @ 600 125 @ 650 Cl 150
RF 6.4 ITCS A671-CC65 A333-6
Cl22
A350-LF2N Cl 1
A420-WPL6 A182-F316/316L / A352-LCB Trim 12 Sp Wound 316SS/Graph
1CC1P01 2 60 ASME B31.3 Diesel Chemical (C) Fuel Gas (FG)
Fuel Gas Low Pressure (FGL) Methanol (M)
Nitrogen (N)
Oily Water Sewer (OWS) Oil & Oil Products (P) Process Air (PA) Process Water (PW) Relief Lines (RL) Utility Water (UW) Vent Gas (VG) 285 @ 32 260 @ 200 110 @ 700 Cl150 RF 1.6 CS A106-B API 5L-B SAW A105N A234-WPB A105N A216-WCB Trim 8 Sp Wound 316SS/Graph 1CC2C04 2 12 ASME B31.3 Caustic (CA) PWHT 285 @ 32 260 @ 200 Cl150 RF 3.2 CS A106-B A105N A234-WPB A105N A216-WCB Trim 9 Sp Wound 316SS/Graph 1CC2P01 2 60 ASME B31.3 15psi LP Condensate (15C) 60 psi LP Condensate (60C) Boiler Feed Water (BFW) Oil & Oil Products (P) Relief Line (RL)
Steam Condensate (SC) Utility Air (UA)
285 @ 32
192 @ 425
110 @ 700
Cl150
Class Name Rev Max Pipe Size Design Code Service Press/Temp Limit psig@°F Flange Rating & Facing Corr Allow mm
Pipe Material Fittings Valve Body Valve Trim Gasket
1CC2P03 2
84 ASME B31.3
Acid Hydrocarbon (AH)
Boiler Blow Down (BBD)
Blowdown (BD)
Fuel Gas Low Pressure (FGL) Oil & Oil Product (P)
Relief Line (RL) Sulfur (SF) Sour Water (SOW) Vent Gas (VG) SOUR - MR0175-2002 285 @ 32* 185 @ 450 110 @ 700 *28°F min for W/T <23.8mm Cl150
RF 3.2 CS API 5L-B SAW A106-B A105N A234-WPB A105N A216-WCB Trim 12 Sp Wound 316SS/Graph
1CC2P07 2
68 ASME B31.3
Diglycolamine (DGA) Oil & Oil Product (P) (Amine Service) SOUR - MR0175-2002 PWHT at design conditions >270°F 285 @ 32 275 @ 135 110 @ 700 Cl150 RF 3.2 CS A106-B API 5L-B SAW A105N A234-WPB A105N A216-WCB Trim 12 Sp Wound 316SS/Graph 1CC2P09 2 36 ASME B31.3 Process (P) Vent Gas (VG) JACKETED 285 @ 32 200 @ 400 152 @ 550 Cl150
RF 1.6 Out 3.2 In CS A106-B A105N A234-WPB A105N A216-WCB Trim 12 Sp Wound 316SS/Graph
1CC4A09 2
6 ASME B31.3
Sulphuric Acid (SA)
275 @ 32
200 @ 200 Cl150 RF 6.4 CS A106-B A105N A234-WPB B462 UNS N08020
A216-WCB Alloy 20 Sp Wound Alloy 20/PTFE 1CC4P03 2 84 ASME B31.3 Blow Down (BD) Oil & Oil Product (P) Relief Lines (RL) Sour Water (SOW)
275 @ 32* 185 @ 450 110 @ 700 *2°F min for
Cl150
Class Name Rev Max Pipe Size Design Code Service Press/Temp Limit psig@°F Flange Rating & Facing Corr Allow mm
Pipe Material Fittings Valve Body Valve Trim Gasket
1CC4P07 2
48 ASME B31.3
Diglycolamine (DGA) Oil & Oil Product (P) (Amine Service) SOUR - MR0175-2002 PWHT at design conditions >270°F
275 @ 32
110 @ 700 Cl150 RF 6.4 CS API 5L-B SAW A106-B A105N A234-WPB A182-F316/316L A216-WCB Trim 12 Sp Wound 316SS/Graph
1CC4P1 2 36 ASME B31.3 Sulfur (SF) JACKETED 275 @ 32 200 @ 400 152 @ 550 Cl150 RF 3.2 In <6” 6.4 In ≥8 1.6 Out CS A106-B A105N A234-WPB A182-F316/316L A216-WCB Trim 12 Sp Wound 316SS/Graph 1CJ4P01 2 68 ASME B31.3
Oil & Oil Products (P) Refractory Lined 280 @ 32 95 @ 750 Cl150 RF 6.4 1¼Cr-½Mo A335-P11 A691-1¼Cr Cl42 A182-F11 Cl2
A234-WP11 Cl1 A182-F11 Cl 2 A217-WC6 Trim 5 Sp Wound 316SS/Graph
1CS1U05 2 60 ASME B31.3 15 psi LP Steam (15S) 60 psi LP Steam (60S) Steam (S) 285 @ 32 257 @ 210 95 @ 750 FV @ 308 Cl150 RF 1.6 CS A106-B API 5L-B SAW A105N A234-WPB A105N A216-WCB Trim 5 Trim 8 Sp Wound 316SS/Graph 1CS1U15 2 24 ASME B31.1 60 psi LP Steam (60S) 285 @ 32 257 @ 210 110 @ 700 FV @ 308 Cl150
RF 1.6 CS SA106-B SA105N SA234-WPB SA105N SA216-WCB Trim 5 Trim 8 Sp Wound 316SS/Graph
1CS2U16 1
48 ASME B31.3
Cooling Water Return (CWR) Cooling Water Supply (CWS)
285 @ 32
257 @ 210
200 @ 400
Cl150
Class Name Rev Max Pipe Size Design Code Service Press/Temp Limit psig@°F Flange Rating & Facing Corr Allow mm
Pipe Material Fittings Valve Body Valve Trim Gasket
1FE0U16 2 24 ASME B31.3 Firewater (FW) Underground 200 @ 32
200 @ 200 Cl 150 FF 0 RTR Epoxy RTR Epoxy A216-WCB Epoxy Lined Bronze Full Elastomer Face
1LE0U16 2 24 ASME B31.3 Firewater (FW) 200 @ 32 200 @ 200 Cl 150 FF
0 FBE lined CS FBE lined CS A216-WCB
Epoxy Lined
Bronze Full Face
Synthetic Fibre 1NT0P01 2 24 ASME B31.3 Sulfur (SF) 290 @ 32 195 @ 150 Cl150 RF 0 Alloy 20 B464 UNS N08020
B366 UNS N08020 A351-CN7M Trim 13
1SD0P01 2
42 ASME B31.3
Blow Down (BD) Oil & Oil Product (P) Relief Line (RL) Relief Lines Cold (RLC) Vent Gas (VG) SOUR - MR0175-2002 275 @ -148 195 @ 400 Cl150 RF 0 SS 316/316L A312-SS A358-316/316L Cl 1 A182-F316/316L
A403-WP316/316L A182-F316/316L A351 CF8M Trim 12 Sp Wound 316SS/Graph
1SD0P03 2
48 ASME B31.3
Blow Down (BD)
Oil & Oil Product (P) Relief Lines Cold (RLC)
275 @ -148 195 @ 400 182 @ 450 Cl150 RF 0 SS A312-316/316L SS A358-316/316L Cl 1 A182-F316/316L A403-WP316/316L A182-F316/316L A351 CF8M Trim 12 Sp Wound 316SS/Graph 1SD0P05 2 1 ASME B31.3 Steam Tracing 275 @ 32 195 @ 400 Cl150 RF 0 SS A312-316/316L A182-F316 1SD0P07 2 48 ASME B31.3 Diglycolamine (DGA) Oil & Oil Product (P) SOUR - MR0175-2002 275 @ 32 195 @ 400 Cl150 RF 0 SS A312-316/316L SS A358-316/316L Cl1 A182-F316/316L A403-WP316/316L A182-F316/316L A351 CF8M Trim 12 Sp Wound 316SS/Graph
Class Name Rev Max Pipe Size Design Code Service Press/Temp Limit psig@°F Flange Rating & Facing Corr Allow mm
Pipe Material Fittings Valve Body Valve Trim Gasket
1SD0P09 2
48 ASME B31.3
Blow Down (BD) Oil & Oil Product (P) Relief Lines Cold (RLC) *Extended Bonnet Valves
275 @ -250 275 @ -148.1 188 @ 425 Cl150 RF 0 SS 316/316L A312-SS A358-316/316L Cl 1 A182-F316/316L
A403-WP316/316L A182-F316/316L A351 CF8M Trim 12 Sp Wound 316SS/Graph
1SD0U01 2 24 ASME B31.3 Air (A) Chemical (C) Demin. Water (DMW) Drinking Water (DW)
Fuel Gas Low Pressure (FGL) Instrument Air (IA)
Lube Oil (LO)
Sewer (Storm) (SR) Treated Water (TW) Water (W) 275 @ 32 195 @ 400 Cl150 RF 0 SS A312-316/316L SS A358-316/316L Cl1 A182-F316/316L A403-WP316/316L A182-F316/316L A351 CF8M Trim 12 Sp Wound 316SS/Graph 3CA1P01 2 68 ASME B31.3 Blow Down (BD) Fuel Gas (FG) Oil & Oil Product (P) Refrigerants (R)
695 @ -50
640 @ 300
525 @ 650
Cl300
RF 1.6 ITCS A671 CC65 A333-6
Cl22
A350-LF2N Cl 1
A420-WPL6 A350-LF2N Cl1 A352-LCB Trim 12 Sp Wound 316SS/Graph
3CA1P03 2
60 ASME B31.3
Blow Down (BD) Oil & Oil Product (P) Refrigerants (R) SOUR - MR0175-2002 695 @ -50 525 @ 650 Cl300 RF 1.6 ITCS A333-6 A671 CC65 Cl22 A350-LF2N Cl 1 A420-WPL6 A350-LF2N Cl1 A352-LCB Trim 12 Sp Wound 316SS/Graph 3CA2P01 2 60 ASME B31.3
Oil & Oil Products(P)
695 @ -50
525 @ 650 Cl300 RF 3.2 ITCS A671 CC65 A333-6
Cl22
A350-LF2N Cl 1
Class Name Rev Max Pipe Size Design Code Service Press/Temp Limit psig@°F Flange Rating & Facing Corr Allow mm
Pipe Material Fittings Valve Body Valve Trim Gasket
3CA2P03 2
60 ASME B31.3
Oil & Oil Products(P) Refrigerants (R) SOUR- MR0175-2002
695 @ -50
525 @ 650 Cl300 RF 3.2 ITCS A671 CC65 A333-6
Cl22
A350-LF2N Cl 1
A420-WPL6 A350-LF2N Cl1 A352-LCB Trim 12 Sp Wound 316SS/Graph
3CA4P03 2
60 ASME B31.3
Blow Down (BD)
Oil & Oil Products (P)
SOUR- MR0175-2002
695 @ -50
525 @ 650 Cl300 RF 6.4 ITCS A671 CC65 A333-6
Cl22
A350-LF2N Cl 1
A420-WPL6 A182-F316/316L A352-LCB Trim 12 Sp Wound 316SS/Graph
3CC1P01 2
48 ASME B31.3
Methanol (ME) Oil & Oil Product (P) Relief Line (RL) Vessel Trim (VT) 740 @ 32 530 @ 700 Cl300
RF 1.6 CS A106-B API 5L-B SAW A105N A234-WPB A105N A216-WCB Trim 8 Sp Wound 316SS/Graph
3CC2P01 2
48 ASME B31.3
Boiler Feed Water (BFW) Oil & Oil Products (P)
250 psi MP Steam Condensate (250SC) Vessel Trim (VT) 740 @ 32 635 @ 400 290 @ 470 Cl300 RF 3.2 CS A106-B API 5L-B SAW A105N A234-WPB A105N A216-WCB Trim 8 Sp Wound 316SS/Graph 3CC2P03 2 48 ASME B31.3 Blow Down (BD) Oil & Oil Products (P) Fuel Gas (FG) Relief Line (RL) Sour Water (SOW) SOUR - MR0175-2002 740 @ 28 635 @ 400 620 @ 450 *28°F min for W/T <23.8mm Cl300 RF 3.2 CS A106-B API 5L-B SAW A105N A234-WPB A105N A216-WCB Trim 12 Sp Wound 316SS/Graph
Class Name Rev Max Pipe Size Design Code Service Press/Temp Limit psig@°F Flange Rating & Facing Corr Allow mm
Pipe Material Fittings Valve Body Valve Trim Gasket
3CC2P07 2
48 ASME B31.3
Diglycolamine (DGA) Oil & Oil Products (P) (Amine Service) SOUR - MR0175-2002 PWHT at design conditions >270°F 740 @ 32 635 @ 400 620 @ 450 Cl300
RF 3.2 CS A106-B API 5L-B SAW A105N A234-WPB A105N A216-WCB Trim 12 Sp Wound 316SS/Graph
3CC4P03 2
48 ASME B31.3
Blow Down (BD)
Oil & Oil Products (P)
Relief Line (RL) SOUR- MR0175-2002 720 @ 32* 617 @ 450 585 @ 550 *21°F min for W/T <20.6mm Cl300 RF 6.4 CS A106-B API 5L-B SAW A105N A234-WPB A182-F316/316L A216-WCB Trim 12 Sp Wound 316SS/Graph 3CC4P07 2 48 ASME B31.3 Diglycolamine (DGA) Oil & Oil Products (P) (Amine Service) SOUR- MR0175-2002 PWHT at design conditions >270°F 720 @ 32 655 @ 300 585 @ 550 Cl300
RF 6.4 CS API 5L-B SAW A106-B A105N A234-WPB A182-F316/316L A216-WCB Trim 12 Sp Wound 316SS/Graph
3CS1U05 2 48 ASME B31.3 250 psi MP Steam (250S) Steam (S) 740 @ 32 530 @ 700 505 @ 750 FV @ 416 Cl300 RF 1.6 CS A106-B API 5L-B SAW A105N A234-WPB A105N A216-WCB Trim 8 Sp Wound 316SS/Graph 3CS1U15 2 48 ASME B31.1 250 psi MP Steam (250S) Steam (S) 740 @ 32 530 @ 700 FV @ 416 Cl300
RF 1.6 CS A106-B API 5L-B SAW A105N A234-WPB A105N A216-WCB Trim 8 Sp Wound 316SS/Graph
3SD0P01 36 ASME B31.3 720 @ -148
Class Name Rev Max Pipe Size Design Code Service Press/Temp Limit psig@°F Flange Rating & Facing Corr Allow mm
Pipe Material Fittings Valve Body Valve Trim Gasket
3SD0P03 2
42 ASME B31.3
Methanol (ME) Oil & Oil Products (P) Refrigerant (R) Relief Line Cold (RLC)
720 @ -148
515 @ 400 Cl300 RF 0 SS 316/316L
A312-A358-316/316L
A182-F316/316L
A403-WP316/316L A182-F316/316L A351 CF8M Trim 12 Sp Wound 316SS/Graph
3SD0P07 2
24 ASME B31.3
Diglycolamine (DGA) Oil & Oil Products (P) Water (W) SOUR- MR0175-2002 720 @ 32 515 @ 400 Cl300 RF 0 SS A312-316/316L 358-316/316L A182-F316/316L A403-WP316/316L A182-F316/316L A351 CF8M Trim 12 Sp Wound 316SS/Graph 3SD0P09 2 42 ASME B31.3 Methanol (ME) Oil & Oil Products (P) Refrigerant (R) Relief Line Cold (RLC) *Extended Bonnet Valves
720 @ -250 720 @ -148.1 560 @ 300 Cl300 RF 0 SS 316/316L A312-A358-316/316L A182-F316/316L
A403-WP316/316L A182-F316/316L A351 CF8M Trim 12 Sp Wound 316SS/Graph
3SD0U01 2 24 ASME B31.3 Chemical (C) Demin Water (DMW) 720 @ 32 515 @ 400 Cl300 RF 0 SS 316/316L A312-A358-316/316L A182-F316/316L
A403-WP316/316L A182-F316/316L A351 CF8M Trim 12 Sp Wound 316SS/Graph
6CA1P01 2
36 ASME B31.3
Fuel Gas (FG) Oil & Oil Product (P) Refrigerant (R) 1390 @ -50 1045 @ 650 Cl600 RF 1.6 ITCS A333-6 A671-CC65 Cl22 A350-LF2N Cl 1 A420-WPL6 A350-LF2N Cl1/ A352-LCB Trim 12 Sp Wound 316SS/Graph 6CA1P03 2 36 ASME B31.3 Fuel Gas (FG) Oil & Oil Product (P) Sour Water (SOW)
1390 @ -50
1045 @ 650 Cl600 RF 1.6 ITCS A671-CC65 A333-6
Cl22
A350-LF2N Cl 1
Class Name Rev Max Pipe Size Design Code Service Press/Temp Limit psig@°F Flange Rating & Facing Corr Allow mm
Pipe Material Fittings Valve Body Valve Trim Gasket
6CA2P01 2
36 ASME B31.3
Methanol (ME) Oil & Oil Products (P)
Vent Gas (VG)
1390 @ -50
1045 @ 650 Cl600 RF 3.2 ITCS A671-CC65 A333-6
Cl22
A350-LF2N Cl 1
A420-WPL6 A350-LF2N Cl1 A352-LCB Trim 12 Sp Wound 316SS/Graph
6CA2P03 2
36 ASME B31.3
Blow Down (BD)
Methanol (ME)
Oil & Oil Products (P)
Sour Water (SOW)
SOUR - MR0175-2002
1390 @ -50
1045 @ 650 Cl600 RF 3.2 ITCS A671-CC65 A333-6
Cl22
A350-LF2N Cl 1
A420-WPL6 A350-LF2N Cl1/ A352-LCB Trim 12 Sp Wound 316SS/Graph
6CA4P01 2
36 ASME B31.3
Blow Down (BD) Oil & Oil Products (P)
1390 @ -50
1045 @ 650 Cl600 RF 6.4 ITCS A671-CC65 A333-6
Cl22
A350-LF2N Cl 1
A420-WPL6 A182-F316/316L A352-LCB Trim 12 Sp Wound 316SS/Graph
6CA4P03 2
36 ASME B31.3
Blow Down (BD) Oil & Oil Products (P) SOUR - MR0175-2002 1390 @ -50 1045 @ 650 Cl600 RF 6.4 ITCS A333-6 A671-CC65 Cl22 A350-LF2N Cl 1 A420-WPL6 A182-F316/316L A352-LCB Trim 12 Sp Wound 316SS/Graph 6CC1P01 2 42 ASME B31.3 Fuel Gas (FG) Methanol (ME) Oil & Oil Products (P) Process Water (PW)
1480 @ 32
1060 @ 700 Cl600 RF 1.6 CS A106-B A671-CC65
Cl22
A105N
A234-WPB A105N A216-WCB Trim 8 Sp Wound 316SS/Graph
6CC1P03 2
48 ASME B31.3
Blow Down (BD) Oil & Oil Products (P)
1480 @ 32 1060 @ 700 Cl600 RF 1.6 CS A106-B A671-CC65 Cl22 A105N A234-WPB A105N A216-WCB Trim 12 Sp Wound 316SS/Graph
Class Name Rev Max Pipe Size Design Code Service Press/Temp Limit psig@°F Flange Rating & Facing Corr Allow mm
Pipe Material Fittings Valve Body Valve Trim Gasket
6CC2P01 2
24 ASME B31.3
600 psig HP Steam Cond. (600C)
Boiler Feed Water (BFW) Oil & Oil Products (P) Steam Condensate (SC)
1480 @ 32 1276 @ 375 1060 @ 700
Cl600
RF 3.2 CS A106-B A105N A234-WPB A105N A216-WCB Trim 8 Sp Wound 316SS/Graph
6CC2P03 2
60 ASME B31.3
Oil & Oil Products (P) Relief Line (RL) Sour Water (SOW) SOUR - MR0175-2002
1480 @ 32
1060 @ 700 Cl600 RF 3.2 CS A106-B A671-CC65
Cl22
A105N
A234-WPB A105N A216-WCB Trim 12 Sp Wound 316SS/Graph
6CC2P07 2
24 ASME B31.3
Diglycolamine (DGA) Oil & Oil Products (P) SOUR - MR0175-2002 PWHT at design conditions >270°F) 1480 @ 32 1060 @ 700 Cl600 RF 3.2 CS A106-B A105N A234-WPB A105N A216-WCB Trim 12 Sp Wound 316SS/Graph 6CC4P03 2 48 ASME B31.3
Oil & Oil Products (P) SOUR – MR0175-2002 1440 @ 32 1060 @ 700 Cl600 RF 6.4 CS A106-B A671-CC65 Cl22 A105N A234-WPB A182-F316/316L A216-WCB Trim 12 Sp Wound 316SS/Graph 6CC4P07 2 48 ASME B31.3 Diglycolamine (DGA) Oil & Oil Products (P) SOUR - MR0175-2002 PWHT at design conditions >270°F) 1440 @ 32 1060 @ 700 Cl600 RF 6.4 CS A106-B A671-CC65 Cl22 A105N
Class Name Rev Max Pipe Size Design Code Service Press/Temp Limit psig@°F Flange Rating & Facing Corr Allow mm
Pipe Material Fittings Valve Body Valve Trim Gasket
6CJ1P01 2 36 ASME B31.3 600 psi HP Steam (600S) Superheated Steam (S) 725 @ 32 725 @ 560 690 @ 770 192 @: 1050 FV @ 450 Cl600 RF 1.6 1¼Cr-½Mo A335-P11 A691-1¼Cr Cl42 A182-F11 Cl2
A234-WP11 Cl1 A182-F11 Cl 2 A217-WC6 Trim 5 Sp Wound 316SS/Graph
6CS1U05 2 36 ASME B31.3 600 psi HP Steam (600S) Steam (S) 870 @ 32 870 @ 500 725 @ 710 FV @ 450 Cl600 RF 1.6 CS A106-B A671-CC65 Cl22 A105N
A234-WPB A105N A216-WCB Trim 5 Sp Wound 316SS/Graph
6CS1U15 2 24 ASME B31.1 600 psi HP Steam (600S) 725 @ 32 725 @ 560 FV @ 450 Cl600 RF 1.6 CS SA106-B SA105N SA234-WPB SA105N SA216-WCB Trim 5 Sp Wound 316SS/Graph 6SD0P01 2 24 ASME B31.3 Methanol (ME) Oil & Oil Products (P) Refrigerant (R) Relief Line Cold (RLS)
1440 @ -148 990 @ 450 Cl600 RF 0 SS A312-316/316L SS A358-316/316L Cl1 A182-F316/316L A403-WP316/316L A182-F316/316L A351 CF8M Trim 12 Sp Wound 316SS/Graph 6SD0P03 2 42 ASME B31.3 Blow Down (BD) Oil & Oil Products (P) SOUR - MR0175-2002 1440 @ -148 990 @ 450 Cl600 RF 0 SS A312-316/316L SS A358-316/316L Cl1 A182-F316/316L A403-WP316/316L A182-F316/316L A351 CF8M Trim 12 Sp Wound 316SS/Graph 6SD0P07 2 24 ASME B31.3 Diglycolamine (DGA) Oil & Oil Products (P) Sour Water (SOW) SOUR – MR0175-2002 1440 @ 32 990 @ 450 Cl600 RF 0 SS A312-316/316L SS A358-316/316L Cl1 A182-F316/316L A403-WP316/316L A182-F316/316L A351 CF8M Trim 12 Sp Wound 316SS/Graph
Class Name Rev Max Pipe Size Design Code Service Press/Temp Limit psig@°F Flange Rating & Facing Corr Allow mm
Pipe Material Fittings Valve Body Valve Trim Gasket
6SD0P09 2
24 ASME B31.3
Methanol (ME) Oil & Oil Products (P) Refrigerant (R) Relief Line Cold (RLS) *Extended Bonnet Valves
1440 @ -250 1440 @ -148.1 1120 @ 300 Cl600 RF 0 SS 316/316L A312-SS A358-316/316L Cl1 A182-F316/316L
A403-WP316/316L A182-F316/316L A351 CF8M Trim 12 Sp Wound 316SS/Graph
6SD0U01 2 24 ASME B31.3 Chemical (C) Demin Water (DMW) 1440 @ 32 990 @ 450 Cl600 RF 0 SS 316/316L SS A312-A358-316/316L Cl1 A182-F316/316L
A403-WP316/316L A182-F316/316L A351 CF8M Trim 12 Sp Wound 316SS/Graph
9CA1P01 2
24 ASME B31.3
Oil & Oil Products (P)
2085 @ -50 1570 @ 650
Cl900 RTJ
1.6 ITCS A333-6 A350-LF2N Cl 1
A420-WPL6
A350-LF2N Cl1/ A352-LCB
Trim 12 Soft Iron Ring
9CA1P03 2
24 ASME B31.3
Oil & Oil Products (P) SOUR - MR0175-2002
2085 @ -50 1570 @ 650
Cl900 RTJ
1.6 ITCS A333-6 A350-LF2N Cl 1
A420-WPL6
A350-LF2N Cl1/ A352-LCB
Trim 12 Soft Iron Ring
9CA2P03 2
24 ASME B31.8
Oil & Oil Products (P) Sour Water (SOW) SOUR - MR0175-2002
2085 @ -50 1570 @ 650
Cl900 RTJ
3.2 ITCS A333-6 A350-LF2N Cl 1
A420-WPL6
A350-LF2N Cl1/ A352-LCB
Trim 12 Soft Iron Ring
9CA4P01 2
24 ASME B31.3
Oil & Oil Products (P)
2085 @ -50 1570 @ 650
Cl900 RTJ
6.4 ITCS A333-6 A350-LF2N Cl 1
A420-WPL6
A350-LF2N Cl1/ A352-LCB
Trim 12 Soft Iron Ring
9CC2P01 2 24 ASME B31.3 Steam Condensate (SC) 2220 @ 32 1590 @ 700 Cl900 RTJ 3.2 CS A106-B A105N A234-WPB A105N A216-WCB
Class Name Rev Max Pipe Size Design Code Service Press/Temp Limit psig@°F Flange Rating & Facing Corr Allow mm
Pipe Material Fittings Valve Body Valve Trim Gasket
9CC2P03 2
24 ASME B31.3
Oil & Oil Products (P) Relief Line (RL) SOUR – MR0175-2002
2220 @ 32
1590 @ 700 Cl900 RTJ 3.2 CS A106-B A105N A234-WPB A105N A216-WCB Trim 12 Soft Iron Ring
9CC2P07 2
24 ASME B31.3
Diglycolamine (DGA) Oil & Oil Products (P)
SOUR - MR0175-2002 PWHT at design conditions >270°F)
2220 @ 32
1590 @ 700 Cl900 RTJ 3.2 CS A106-B A105N A234-WPB A105N A216-WCB Trim 12 Soft Iron Ring
9CC4P03 2
24 ASME B31.3
Oil & Oil Products (P) Relief Line (RL) SOUR – MR0175-2002 1930 @ 32 1590 @ 700 Cl900 RTJ 6.4 CS A106-B A105N A234-WPB A105N A216-WCB
Trim 12 Soft Iron Ring
9CS1U05 2 24 ASME B31.3 Steam (S) 1420 @ 32 1420 @ 700 FV @ 450 Cl900 RTJ 1.6 CS A106-B A671-CC65 Cl22 A105N A234-WPB A105N A216-WCB Trim 5 Sp Wound 316SS/Graph 9NR1P01 2 ASME B31.3 Superheated Steam (S) 725 @ 32 725 @ 1050 FV @ 450 Cl900 RTJ 0 Alloy B407 UNS 800 N08800 B564 UNS N08800
B366 CNRIC B564 UNS N08800A494 CY-40 Trim 5 Nickel 201 Ring
9SD0P01 2
24 ASME B31.3
Oil & Oil Products (P) SOUR – MR0175-2002 1550 @ -148 900 @ 450 Cl900 RTJ 0 SS 316/316L A312-SS A358-316/316L Cl1 A182-F316/316L
A403-WP316/316L A182-F316/316L A351 CF8M Trim 12 316SS Ring
9SD0P03 2
6 ASME B31.3
Methanol (ME) Oil & Oil Products (P)
1440 @ -148 1400 @ 700 Cl900 RTJ 0 SS A312-316/316L A182-F316/316L A403-WP316/316L A182-F316/316L A351 CF8M Trim 12 316SS Ring
Class Name Rev Max Pipe Size Design Code Service Press/Temp Limit psig@°F Flange Rating & Facing Corr Allow mm
Pipe Material Fittings Valve Body Valve Trim Gasket
9SD0P09 2
24 ASME B31.3
Methanol (ME) Oil & Oil Products (P) *Extended Bonnet Valves
1450 @ -250 1450 @ -148.1 1355 @ 600
Cl900
RTJ 0 SS 316/316L A312- A182-F316/316L A403-WP316/316L A182-F316/316L A351 CF8M Trim 12 316SS Ring
80CG0D01 2
4 ASME B31.3
Vent Gas (VG)
285 @ 32
APP CK D JK PS PS ENG’G PSD S PSD S PSD S DE S CRIP T ION ISSU ED FOR APPR O VAL ISSU ED FOR D E S IGN IS S U E D FOR CONS T RUCTION JO/EW O B I-- 3 1 92 B I-- 3 1 92 B I-- 3 1 92 DA TE 05/0 9/0 5 08/0 1/0 6 24/0 4/0 6 REV. NO . A B C DISCIPLINE ENGINEER ________________ DATE ___________ PROJECT ENGINEER ________________ DATE ___________ CERTIFIED ________________ DATE ___________ CONSTRUCTION AGENCY ________________ DATE ___________ OPERATIONS ________________ DATE ___________ EDS D VERIF ICATIO N CONTROL NUMB E R BY: __ ___ ___ ___ ___ DAT E _ ___ ___ ___ ___ CE RT IF IC AT E R EV. NO . __ ___ __ ___ __ CO VER ED, FOR ALL A TI ON RE QUIR E M E N TS, E TI ON CERTIFIC ATE ___ _ ____ ___ ___ ___ __ ___ DRA WING A ND THE INFORMA TION CONTA INE D HE RE IN A R E THE S O L E P R O PERTY OF S A UDI AR AM CO. NO R EPROD UCTION IN FU LL OR IN PAR T SH AL L B E O B TAINED FROM THIS DOCUM ENT W ITH O U
T THE WRITTEN CONSENT OF ITS
ATTACHMENT 2
APP CK D JK PS PS ENG’G PSD S PSD S PSD S DE S CRIP T ION ISSU ED FOR APPR O VAL ISSU ED FOR D E S IGN IS S U E D FOR CONS T RUCTION JO/EW O B I-- 3 1 92 B I-- 3 1 92 B I-- 3 1 92 DA TE 05/0 9/0 5 08/0 1/0 6 24/0 4/0 6 REV. NO . A B C DISCIPLINE ENGINEER ________________ DATE ___________ PROJECT ENGINEER ________________ DATE ___________ CERTIFIED ________________ DATE ___________ CONSTRUCTION AGENCY ________________ DATE ___________ OPERATIONS ________________ DATE ___________ EDS D VERIF ICATIO N CONTROL NUMB E R BY: __ ___ ___ ___ ___ DAT E _ ___ ___ ___ ___
PROJECT SPECIFICATION DWG.TYPE PLANT .NO INDEX DRAWING NO. SHT. NO. REV. NO.
ON CE RT IF IC AT E T HAT R EV. NO . __ ___ __ ___ __ S CO VER ED, FOR ALL TIFIC A TI ON RE QUIR E M E N TS, E TI ON CERTIFIC ATE ___ ___ _ ____ ___ ___ ___ __ ___ THIS DRA WING A ND THE INFORMA TION CONTA INE D HE RE IN A R E THE S O L E P R O PERTY OF S A UDI AR AM CO. NO R EPROD UCTION IN FU LL OR IN PAR T SH AL L B E O B TAINED FROM THIS DOCUM ENT W ITH O U
T THE WRITTEN CONSENT OF ITS
