ITEM DESCRIPTION UNIT QTY UNIT RATE AMOUNT
KD KD
DIVISION 2 - SITE WORKS Section 02315
Earth Work Excavation and Backfilling
2.1 Excavation for foundation in any type of soil even rock, up to required height including backfilling, shoring (if required), dewatering and removing of surplus excavated material from site to a place approved by the Municipality. Mechanical excavation shall be stopped 300mm above the Foundation level and completed manually.
M3 13308 2.250 29943.000
Compacted fill
2.2 Filling inside building (under slab on grade etc.) as per proposed levels, with approved quality imported filling material. Filling shall be compacted in layers (each layer shall not be more than 250mm thick) and compaction shall not be less than 98% of dry density. Selected excavated material may be used for filling but as per approval of the Engineer.
L.S L.S 6000.000 6000.000
Section 02360 Termite Control
2.3 Termilte Control/Soil treatment for the whole building area all as described
Total Carried to Collection 37443.000
ITEM DESCRIPTION AMOUNT
KD DIVISION 2 - SITEWORKS
COLLECTION
ITEM DESCRIPTION UNIT QTY UNIT RATE AMOUNT KD KD DIVISION 3 - CONCRETE Section 03300 Cast-in-place Concrete Plain Concrete
3.1 Plain concrete grade using sulphate resisting cement including all form work and laid as described (smooth face)
3.1.1 100 mm thick under Foundation M2 1,400 3.500 4900.000
3.1.2 50 mm thick under Ground beam & External steps
M2 710 2.200 1562.000
Reinforced Concrete
3.2 Vibrated reinforced concrete using sulphate resisting cement filled into formwork and tamped around reinforcement including all formwork, tie bolts and reinforcement etc. complete as described (Fair finish for all exposed faces)
3.2.1 Foundation: Col/Wall Footings etc. M3 785 95.500 74967.500
3.2.2 Column/wall Neck M3 190 100.000 19000.000
3.2.3 Ground Beam, External Steps/ramp etc. M3 345 95.000 32775.000
3.2.4 150mm thick slab on grade with turn down slab/edge thicnessing and including Isolation joints (with celotex and mastic fill). Construction joints shall be provided in case bay area is more than 25 m2.
M2 3,930 7.250 28492.500
3.3 Vibrated reinforced concrete using ordinary portland cement, filled into form work and tamped around reinforcement including all formwork, reinforcement etc. complete as described. (Fair finish for all exposed faces)
3.3.1 Walls M3 698 95.000 66310.000
Total Carried to Collection 237121.000
ITEM DESCRIPTION UNIT QTY UNIT RATE AMOUNT
KD KD
Section 03530 Concrete Topping
3.4 Minimum 50mm thick concrete topping with mesh reinforcement (Y8/200mm both direction)and laid over hollow core slab in proper shape with required expansion, construction and contraction joints. (K-300)
M2 11821 5.000 59,105.000
Section 03410
Plant Pre-cast Structural Concrete. 3.5 Vibrated precast prestressed reinforced concrete
with compressive strenght of 48Mpa (Cube strenght) using Ordinary portland cement finished fairface on all exposed surfaces including all formwork, reinforcemet, tension wires anchorage, lifting hooks, hoisting, placing in position, bedding neoprene bearing pads, perimeter gaskets, sealent, shims, dowels and connections all as specified
Note : The dimensions mention below are as per the drawings, and the dimensions shown in the drawings are for guidance only, It is contractor's responsibility to design all the precast concrete element, and all connections and accessories as specified.
The slab system shown in the drawing (Hollow core system) is for guide line only, The contractor to design complete slab system as hollow core system or Double T (TT) System, after consideration of all services passing fron the ceiling and take the approval from Engineer before commencing of the work.
3.5.1 Design, suplly and fixation of precast concrete columns.
L.S. L.S. 98,650.000 98,650.000
3.5.2 Design, suplly and fixation of rectangular beams, edge beams, spine beams.
3.5.3 Design, suplly and fixation of hollow core or Double TT, slab system.
L.S. L.S. 201,450.000 201,450.000
Total Carried to Collection 564655.000
ITEM DESCRIPTION UNIT QTY UNIT RATE AMOUNT
KD KD
3.5.4 Design, suplly and fixation of all staircases. L.S. L.S. 20,000.000 20,000.000
3.5.5 Design, suplly and fixation of parapet. M3 160 85.000 13,600.000
Section 03455
Glass Reinforced Concrete (GRC) Precast GRC panel fixed over external wall including galvanized steel support, anchors, dowels etc. complete as described
3.6 Decorative GRC panels over Stair windows M2 112 24.000 2,688.000
Section 03550 Concrete Screed
3.7 Approx. 100mm thick smooth surface sand cement and thin gravel screed with steel wiremesh (6mm dia @ 200mm c/c) all as described.
ITEM DESCRIPTION UNIT QTY UNIT RATE AMOUNT KD KD DIVISION 3 - CONCRETE COLLECTION Page No. 3-1 237121.000 Page No. 3-2 564655.000 Page No. 3-3 37900.500
ITEM DESCRIPTION UNIT QTY UNIT RATE AMOUNT
KD KD
DIVISION 4 - MASONRY Section 04200 Unit Masonry
4.1 Solid concrete block wall bedded in sand cement motar with gavanized steel ties including scaffolding up to any height etc. complete as described. 4.1.1 400 mm thick wall M2 72 12.250 882.000 4.1.2 300 mm thick wall M2 10 8.750 87.500 4.1.3 250 mm thick wall M2 75 7.300 547.500 4.1.4 200 mm thick wall M2 3,152 7.000 22064.000 4.1.5 150 mm thick wall M2 5,480 5.250 28770.000 4.1.6 100 mm thick wall M2 487 4.250 2069.750
Sand Lime Bricks
4.2 Sand lime bricks size 290 x 90 x 45cm Standard 34. Malaki from National Industries Company or equally approved (Colour to be as per the approval of Engineer In-Charge) bedded in sand cement mortar with galvanized steel ties including scaffolding up to any height etc. complete as described.
M2 1990 7.000 13930.000
Section 04225
Light Weight Concrete Unit Masonry 4.3 Light weight concrete block wall bedded in sand
cement mortar with galvanized steel ties including scaffolding up to any height etc. complete as described.(External wall)
Total Carried to Collection 99562.000
ITEM DESCRIPTION UNIT QTY UNIT RATE AMOUNT
KD KD
DIVISION 4 - MASONRY COLLECTION
ITEM DESCRIPTION UNIT QTY UNIT RATE AMOUNT KD KD DIVISION 5 - METALS Section 05500 Metal Fabrication 5.1 Steel Railing
5.1.1 900mm high steel pipe railing fixed over concrete with 25mm dia vertical steel post, 3 rows of 25mm dia horizontal steel pipe rail and 50mm dia steel pipe hand rail including anchors, dowels, fixing accssories and approved quality primer and alkyd paint etc. complete as described over Stairs
MR 205 18.700 3833.500
5.1.2 1000mm high steel pipe railing around openings fixed over concrete with 25mm dia vertical steel post and 50mm dia steel pipe hand rail including - ditto
MR 55 19.800 1089.000
5.1.3 200mm high steel pipe railing fixed over concrete over balconies with 25mm dia vertical steel post and 100mm dia steel pipe hand rail including - ditto.
MR 42 12.100 508.200
Access/Cat ladder:
5.2 Steel access ladder comprising 32 mm Dia.tubular section, stringer 25mm dia tubular sections rungs at 300mm centres including wall struts, welding, bolting, removable galvanized steel chain barrier and fixing to structure, the item include application of primer and akyd paint to the required thickness, overall height as shown in the drawings for different areas at roof level.
5.2.1 Cat ladder 3750 mm high (approx.) Nos 6 121.000 726.000
Total Carried to Collection 6464.700
ITEM DESCRIPTION UNIT QTY UNIT RATE AMOUNT
KD KD
Steel shed over roof water tank 5.3 Design, fabricate and install steel shade over
roof water tank. Contractor shall provide designed working/shop drawings for Engineer's approval
L.S. L.S. 1760.000 1760.000
Section 05810
Expansion Joints and Cover Assemblies
5.4 20mm wide expansion joint for footings, columns, beams, slabs, walls etc. horizontally and vrtically using bitumen impregnated joint filler including 20x20mm approved quality mastic/sealant over exposed joint face and covered the exposed faces of joints with 30mm thick aluminium cover plate including all accessories complete as described
Total Carried to Collection 21760.000
ITEM DESCRIPTION AMOUNT
KD DIVISION 5 - METALS
COLLECTION
Page No. 5-1 6464.700
ITEM DESCRIPTION UNIT QTY UNIT RATE AMOUNT
KD KD
DIVISION 6 - WOOD AND PLASTICS Section 06200
Finish Carpentary
6.1 Preaperation and fixing of two wooden stripes parallel to each other of white wood having the size 25 x 100 mm each.( fixing on the walls other than which is having marker board)
Total Carried to Collection 5265.000
ITEM DESCRIPTION AMOUNT
KD DIVISION 6 - WOOD AND PLASTICS
COLLECTION
ITEM DESCRIPTION UNIT QTY UNIT RATE AMOUNT
KD KD
DIVISION 7 - TH. & MOIST. PROTECTION Section 07110
Sheet Membrane Waterproofing
7.1 Polythylene sheet 1000 gauge under slab on grade M2 3930 0.550 2161.500
7.2 4mm thick waterproofing membrane under, over and around foundation concrete elements contact in soil with 6mm thick protection board over vertical surfaces including 50mm thick horizontal protection screed below foundation bed all as per MPW specificaions
L.S L.S 6750.000 6750.000
Section 07140
Fluid Applied Waterproofing 7.3 Rubberized waterproofing paint over external
wall along stone cladding
M2 220 0.800 176.000
Section 07110 & 07140
Waterproofing System (Toilets & Kitchen) 7.4 Under tiling in wet areas (Toilets and Kitchen)
including dressing up walls, which shall be including.
7.4.1 Two coats of fluid applied waterproofing paint M2 345 0.800 276.000 over concrete floor and wall
7.4.2 130-150mm thick foam concrete fill M2 345 1.950 672.750
7.4.3 20 mm thick sand cement screed M2 345 0.950 327.750
7.4.4 4 mm thick waterproofing membrane M2 345 2.000 690.000
Total Carried to Collection 11381.750
ITEM DESCRIPTION UNIT QTY UNIT RATE AMOUNT
KD KD
Section 07500 (Composite Roofing System) (Section 03520, 07110, 07140, 07200, 07320) 7.5 Roof Waterproofing System including testing and guarantee of the roofing system for any water leakage all as per specifications and Engineer's approval.
7.5.1 2 coats of fluid applied w.p. paint over concrete roofM2 3140 0.950 2983.000
7.5.2 50-150mm thick lightweight concrete, 600 kg/m3 density with ordinary portland cement laid to falls and cross falls.
M2 3140 2.000 6280.000
7.5.3 20mm thick cement sand screed (1:3) mortar laid over light weight concrete bed.
M2 3140 1.250 3925.000
7.5.4 Two layer of 4mm thick membrane roofing including 350-450 mm girth laid over roof with primer
M2 3140 3.850 12089.000
7.5.5 20mm thick cement sand screed (1:3) mortar laid over WP membrane
M2 3140 0.950 2983.000
7.5.6 75 mm thick extruded polysterene insulation M2 3140 3.100 9734.000
7.5.7 Filter fabric M2 3140 0.200 628.000
7.5.8 400x400x40mm Cement tile and
400x150x40mm skirting bedded in cement and sand mortar and laid over roof in 2.80x2.80m bay with 10cm wide gravel/aggregate strip filled with selected gravel at both direction all as per Engineer's approval and as described
M2 3140 3.850 12089.000
Section 07840 Fire Stopping
7.6 Fire stopping over all openings around the perimeter of Fire Zone as described.
L.S L.S
Total Carried to Collection 50711.000
ITEM DESCRIPTION AMOUNT
KD DIVISION 7 - THERMAL & MOIST.PROTECTION
COLLECTION
Page No. 7-1 11381.750
ITEM DESCRIPTION UNIT QTY UNIT RATE AMOUNT
KD KD
DIVSION 8 - DOORS AND WINDOWS Section 08110
Metal Door and frame
8.1 Hollow metal door and frame with all required weather sealing, fixing accessories, sealant with backup rod and fixing to concrete or block wall including required fire rating, glazing and Hardware etc. complete as described
8.1.1 Door Type FD1, size 1100x2200mm Nos 6 190.000 1140.000
8.1.2 Door Type FD2, size 2000x2200mm Nos 7 420.000 2940.000
8.1.3 Door Type FD3, size 1800x2200mm Nos 10 410.000 4100.000
8.1.4 Door Type D02, size 2000x2200mm Nos 6 430.000 2580.000
8.1.5 Door Type D03, size 1000x2200mm Nos 13 190.000 2470.000
Section 08210, 06100,06200
Wood door and Frame, Rough Carpentry Finish Carpentry
8.2 Solid core flush timber teak veneered doors hanging to wood frames, fixed to concrete or block, including sub-frames/timber packings and fixings etc. complete as described. The item includes frames, finishes, Glazing, Fire Rating, Hardware etc., complete as described
8.2.1 Door Type D01, size 1100x2200mm Nos 52 240.000 12480.000
8.2.2 Door Type D04, size 1000x2200mm Nos 37 233.000 8621.000
8.2.3 Door Type D05, size 1000x2200mm Nos 38 233.000 8854.000
8.2.4 Door Type D07, size 1100x2200mm Nos 6 240.000 1440.000
8.2.5 Door Type D10, size 1800x2200mm Nos 5 430.000 2150.000
8.2.6 Door Type D16, size 1100x2200mm Nos 18 240.000 4320.000
8.2.7 Door Type D17, size 1000x2200mm Nos 6 233.000 1398.000
Total Carried to Collection 55431.000
ITEM DESCRIPTION UNIT QTY UNIT RATE AMOUNT
KD KD
Section 08520
Aluminum Doors and Windows Powder coated extruded section aluminium Doors and Windows including glazing as required, frames, fly screens, mullions, loacation angles, shims and plates, heads, sills and jambs, glazing and glazing beads, weather stripping, caulking, pointing, sealing, sub frames, all hard ware, etc. complete and fixing to concrete or block work as described.
8.3 Aluminium Door:
8.3.1 Door Type D06, size 1800x2200mm Nos 8 320.000 2560.000
8.3.2 Door Type D08, size 1100x2200mm Nos 6 205.000 1230.000
8.3.3 Door Type D11, size 7100x2200mm No 1 1313.000 1313.000
8.3.4 Door Type D12, size 11800x3000mm Nos 2 2677.000 5354.000
8.3.5 Door Type D13, size 1100x2200mm Nos 2 247.000 494.000
8.3.6 Door Type D14, size 3200x2200mm Nos 4 588.000 2352.000
8.3.7 Door Type D15, size 3800x2200mm Nos 6 704.000 4224.000
8.3.8 Door Type D18, size 1800x2200mm Nos 2 325.000 650.000
8.3.9 Door Type D19, size 2000x2200mm Nos 22 320.000 7040.000
8.3.10 Door Type D21, size 1600x2200mm Nos 2 294.000 588.000
Notes: Door D09 included in the toilet partition, Div-10
8.4 Aluminium Windows
8.4.2 Window Type W02, size 25700x1600mm Nos 3 3360.000 10080.000
Total Carried to Collection 43445.000
ITEM DESCRIPTION UNIT QTY UNIT RATE AMOUNT
KD KD
8.4.3 Window Type W03, size 3200x1600mm Nos 8 677.000 5416.000
8.4.4 Window Type W04, size 3200x700mm Nos 6 340.000 2040.000
8.4.5 Window Type W05, size 4800x1600mm Nos 65 782.000 50830.000
8.4.6 Window Type W06, size 21500x1600mm Nos 1 2835.000 2835.000
8.4.7 Window Type W07, size 1600x1600mm Nos 12 195.000 2340.000
8.4.8 Window Type W08, size 800x1600mm Nos 8 100.000 800.000
8.4.9 Window Type W09, size 2550x1600mm (internal) Nos 4 368.000 1472.000
8.4.10 Window Type W12, size 2000x1200mm (internal) No 1 184.000 184.000
8.4.11 Window Type W13, size 7100x2200mm (internal) No 1 1240.000 1240.000
Section 08600 Skylight
8.5 Aluminum framed double glazed skylight with complete waterproof installation
8.5.1 Skylight size 4000x1000mm, Type W10 Nos 2 1890.000 3780.000
8.5.2 Skylight size 7300x1500mm, Type W11 No 1 7500.000 7500.000
Shutter
Total Carried to Collection 80437.000
ITEM DESCRIPTION AMOUNT
KD DIVISION 8 - DOORS AND WINDOWS
COLLECTION
Page No. 8-1 55431.000
Page No. 8-2 43445.000
ITEM DESCRIPTION UNIT QTY UNIT RATE AMOUNT
KD KD
DIVISION 9 - FINISHES Section 09200 Lath and plaster
9.1 20mm thick cement and sand plaster (with mesh fabric) applied to internal wall and ceiling, stairs and shafts (concrete or block wall) including under coat, metal lath, corner beads, stop beads etc. complete as described.
M2 20,360 2.250 45810.000
Section 09260 Gypsum Board
9.2 100 mm thick and 2200mm high metal stud partition comprising 12.5 mm thick waterproof quality gypsum wall board on both sides with sound attenuation blanket including metal furring channels, head and sill runners, caulking, leveling shims etc. all as described
M2 250 6.500 1625.000
Section 09310 Ceramic Tiles
9.3 Non slip ceramic floor tiles on and including cement & sand setting bed, sand cushion and joints grouted in waterproof grout over concrete floor all as described.
(Prime cost for all the ceramic are 2.5 KD/M2, similar to L& M artificial marble tiles ,Eagle ceramic tiles or equally approved, sizes mention here are only for reference , contrcator can use standard sizes of ceramic)
9.3.1 Non-slip decorative ceramic tile for wet areas, type CT1, size 600x600x10mm
M2 345 7.000 2415.000
9.3.2 Acid resistant ceramic tile, type CT2, size 600x600x10mm
M2 1,236 7.500 9270.000
9.3.3 Non-slip decorative ceramic tile with border, type CT4 & CT7, size 600x600x10mm
Total Carried to Collection 107252.000
ITEM DESCRIPTION UNIT QTY UNIT RATE AMOUNT
KD KD
9.3.4 Ditto-but with pattern and different color for Corridoors
M2 240 7.250 1740.000
9.3.5 Non-slip ceramic tile, type CT5 for store and service area, size 300x300x9mm
M2 553 6.500 3594.500
9.4 Ceramic Skirting - Ditto
9.4.1 Coved ceramic skirting, 600x100x10mm MR 3,475 2.000 6950.000
9.4.2 Coved ceramic skirting, 300x100x9mm MR 442 2.500 1105.000
9.5 Wall ceramic tiles fixed on concrete or block work on and including cement and sand backing and joints grouted in waterproof grout, all as described.
9.5.1 300x300x6mm ceramic tile over corridor wall 1200mm high
M2 1,270 5.150 6540.500
9.5.2 300x300x6mm ceramic tile with border for wet areas
M2 1,375 5.500 7562.500
9.5.3 Ditto but for laboratory areas (acid resistant) M2 1,665 6.000 9990.000 9.5.4 300x300x 6mm ceramic tile for storage areas at
F.F
M2 154 5.150 793.100
Section 09420 Terrazzo
9.6 Precast Terrazzo floor tile, size 300x300x30mm on and including cement and sand setting bed and backing with joints grouted in white/colured cement including grinding, polishing etc.complete as described
9.7 Precast Terrazzo Skirting, size 300x100x30mm on and including cement and sand setting bed and backing with joints grouted in white/colured cement including grinding, polishing etc.complete as described
MR 362 3.500 1267.000
Total Carried to Collection 42542.600
ITEM DESCRIPTION UNIT QTY UNIT RATE AMOUNT
KD KD
Section 09510 Acoustic tile Ceiling
9.8 Acoustic tile ceiling, size 600x1200x15mm including all frame work, suspension system, access panels etc. complete as described
M2 216 6.000 1296.000
Section 09513 Metal Suspended Ceiling
9.9 Metal tile / ribed crrugated sheet with anti bacterial paint ceiling including all frame work, suspension system, access panels etc. complete as described for wet areas
M2 345 8.500 2932.500
Section 09260, 09535
Gypsum Board Ceiling / Acoustic tile Ceiling
9.10 Combination of 12.5mm thick Gypsum board ceiling with emulsion paint finish and 600x600x15mm acoustic tile ceiling including all frame work, suspension system, access panels etc. complete as described
M2 8,755 7.500 65662.500
Section 09260
Glass Fiber Reinforced Gypsum (GRG) Ceiling 9.10 GRG Ceiling
9.10.1 20mm thick Decorative GRG ceiling with emulsion paint finish including all frame work, suspension system, access panels etc. complete as described
M2 220 6.000 1320.000
Section 09260 Gypsum Board Ceiling
9.10.2 12.5mm thick waterproof qualityGypsum board ceiling with waterproof paint for wet areas all as shown and described.
M2 695 6.500 4517.500
Total Carried to Collection 123331.200
ITEM DESCRIPTION UNIT QTY UNIT RATE AMOUNT
KD KD
Section 09600 Granite & Marble 9.11 Stone & Marble:
9.11.1 Natural Granite steps for external entrances, 30mm thick and 300mm wide Treadx 20mm thick and 160mm high Riser all as described.
MR 51 15.000 765.000
9.11.2 3cm thick granite flooring tiles for Main & Rear Entrances, type M-5,
M2 120 35.000 4200.000
9.11.3 400x400x30mm thick Italian carrara marble tile for stair hall and landings
M2 395 20.000 7900.000
9.11.4 Italian carrara marble Steps, 30mm thick and 300mm wide Tread x 20mm thick and 160mm high Riser
MR 960 13.000 12480.000
9.11.5 Italian carrara marble Skirting for Stair, 160mm highx20mm thick
MR 547 5.000 2735.000
9.11.6 30mm thick Italian carrara marble threshold MR 36 4.000 144.000
9.11.7 12mm thick synthetic marble (L.G. , Corrian or equally approved) wash basin counter fixed over galvanized steel supports including marble fascia, back spalsh, cut out for wash basin, all required accessories, sealant etc. complete as described. 30mm thickx600mm wide and 7220mm long with 7 Bowls
Nos 6 750.000 4500.000
9.11.8 Ditto- but 1200mm with 1 Bowl No 1 160.000 160.000
Section 09680 Carpet Tiles
9.12 Carpet tiles laid over screed floor with approved quality additives. (screed measured separately )
M2 225 7.000 1575.000
Total Carried to Collection 34709.000
ITEM DESCRIPTION UNIT QTY UNIT RATE AMOUNT
KD KD
Section 09710 , 09842 Acoustical Wall Panel / Stretched fabric acoustic panels. 9.13 Combination of acoustic wood panel and
Proprietary make "Streched Fabric" Acoustic wall panel inside Seminar hall, Library/Office, Vocal room and instrument music including all fittings and accessories as decribed
M2 520 46.000 23920.000
(lower 1mt. Height from flooring wooden acoustic panel and fabric panels to be up to the ceiling from top of the wood panels)
Section 09800 Epoxy
9.14 Epoxy finish over screed, Type CO-2 (Screed measured separately in Div-3) min 300 micron dry thick
M2 215 3.000 645.000
Section 09900 Painting
9.15 Prepare and apply 3 coats paint of approved colour over plastered surface (wall and ceiling) including preparation of surfaces, undercoat, sealcoat etc. complete as described
9.15.1 Emulsion paint M2 13,140 1.200 15768.000
9.15.3 Texture paint system as specified including two coats of Polyurethane protection layers (NIC texture paint system or equally approved)..
M2 2,184 2.600 5678.400
Total Carried to Collection 27375.900
ITEM DESCRIPTION AMOUNT
KD DIVISION 9 - FINISHES COLLECTION Page No. 9-1 107252.000 Page No. 9-2 42542.600 Page No. 9-3 123331.200 Page No. 9-4 34709.000 Page No. 9-5 27375.900
ITEM UNIT QTY UNIT RATE AMOUNT
KD KD
DIVISION 10 - SPECIALTIES Section 10100
Visual Display Board
10.1 Wall mounted marker board and tack board with silver anodising frame with plastic rounded corners, elegant alluminium tray ,fixing etc. complete as described
10.1.1 Marker board having the size 2.5 mt x 1.25 mt for general class room
Nos 50 50.000 2500.000
10.1.2 Ditto - but for computer lab,sientific club,physics lab chemistry lab, biology lab, geology lab, art club room, electronic workshop, car mechanic work shop
Nos 22 50.000 1100.000
10.1.3 Marker board having the size 1.30 mt x 1.25 mt for general class room.
Nos 100 30.000 3000.000
10.1.4 Ditto - but for computer lab,sientific club,physics lab chemistry lab, biology lab, geology lab, art club room, electronic workshop, car mechanic work shop.
Nos 48 30.000 1440.000
Section 10170 Toilet Partition/Cubicle
10.2 Proprietary make Plastic toilet partition, cubicles including doors, front panels, divisions, end panels with all required hardware and accessories as described.
10.2.1 Toilet partition/cubicle 13mm thick with five (5) doors, size 12750x2200mm (Door TypeD09)
Nos 12 1700.000 20400.000
Section 10651 Operable Panel Partition
10.3 Proprietary make "Manually Operated" Operable Partition over Class room, size 8500x3500m including all fittings, accessories and hardware all as described.
Nos. 4 2400.000 9600.000
Total Carried to Collection 38040.000
ITEM UNIT QTY UNIT RATE AMOUNT
KD KD
Section 10800 Toilet Accessories
10.4 Supply and fix toilet accessories including all component parts, assembling, plugging, screwing or otherwise fixing and making good all as described.
10.4.1 Waste Receptacle (WR) Nos 76 40.000 3040.000
10.4.2 Toilet Paper Dispenser (TPD) recessed Nos 70 15.000 1050.000
10.4.3 Paper Towel Dispenser (PTD) Nos 22 12.000 264.000
10.4.4 Robe Hook (RH) Nos 70 10.000 700.000
10.4.5 Soap Dispenser Vertical (SDV) wall mounted Nos 39 10.000 390.000
10.4.6 St.steel framed mirror (FM), size 7600x900mm Nos 6 300.000 1800.000
10.4.7 Ditto but size 1870x900mm No 1 120.000 120.000
10.4.8 St.steel framed mirror (FM), size 700x1000mm Nos 10 75.000 750.000
10.4.9 St.Steel Grab Bar (GB) Nos 52 2.500 130.000
10.4.10 Folding Shower Seat (FSS) No 1 200.000 200.000
10.4.11 Utility Shelf, Mop and Broom Holder (MH) Nos 6 10.000 60.000
10.4.12 Hot Air Dryer (HD) Nos 6 135.000 810.000
Notes: Flexible hose with spray nozzle included with WC in Div-15, Mechanical
Total Carried to Collection 9314.000
ITEM DESCRIPTION AMOUNT
KD DIVISION 10 - SPECILITIES
COLLECTION
Page No. 10-1 38040.000
ITEM DESCRIPTION UNIT QTY UNIT RATE AMOUNT
KD KD
DIVISION 12 FURNISHINGS Section 12357
Kitchen Casework/Cabinet
12.1 Kitchen area base and wall units complete with double doors, adjustable shelves, sides, tops, bottoms, backs, skirting and all required accessories, hardware, fixings, components, support legs, sealing, plugging, screwing, making good, all as as per Engineer's approval. 12.1.1 Base unit size 600mm deep x 850mm high set in
range including sink units with dustbin, shaped corner units and 3mm thick stainless steel top with cutout for sinks and recesses for appliances(Sink measured separately in Div-15, Mechanical.)
MR 12
12.1.2 Wall Unit size 400x600mm high - ditto MR 12
Section 12358 Laboratory Casework
Supply and fix Laboratory Casework for Biology Lab 1 & 2, Geology Lab 1 & 2, Chemistry Lab 1 & 2 and Physics Lab 1 & 2, with all required fittings, weather sealing, fixing accessories, sealant with backup rod and fixing to concrete, block work or gypsum board including all required hardware and accessories as described.
12.2 BASE CABINETS:
12.2.1 Base cabinet type CK055PHX Nos 240
12.2.2 Base cabinet type CD0455PHX Nos 64
12.2.3 Base cabinet type CB050PHX Nos 8
Total Carried to Collection
ITEM DESCRIPTION UNIT QTY UNIT RATE AMOUNT
KD KD
12.2.5 Base cabinet type CA060PHX Nos 20
12.2.6 Base cabinet type CB060PHX Nos 6
12.2.7 Base cabinet type CA045PHX Nos 4
12.2.8 Base cabinet type CB045PHX Nos 14
WALL CABINETS:
12.3 Wall cabinet type S2PND090-30 Nos 32
STORAGE CABINETS:
12.4 Storage cabinet type Q2PND120-40 Nos 14
12.5 WORKTOP COUNTERS:
12.5.1 Worktop counter type 16TRE60 MR 382
12.5.2 Worktop counter type 24MEL75 MR 9
12.6 SINK CABINETS:
12.6.1 Sink cabinet type CS060PHX Nos 44
12.6.2 Sink cabinet type CS120PHX Nos 4
12.7 MISCELLANEOUS CABINETS/COUNTERS:
12.7.1 Type KB46 Nos 70
12.7.2 Type COD028 Nos 70
12.7.3 Type LE2WP Nos 238
12.7.4 Type JCWSO Nos 14
12.7.5 Type PPSINK Nos 52
12.7.6 Type LMXSO Nos 40
12.7.7 Type LGISO Nos 32
FUME HOOD WITH BASIC CABINET:
12.8 Type FC120 Nos 2
SAFETY SHOWER
Total Carried to Collection
ITEM DESCRIPTION AMOUNT
KD
DIVISION 12 FURNISHINGS
COLLECTION Page No. 12-1
ITEM DESCRIPTION UNIT QTY UNIT RATE AMOUNT
KD KD
DIVISION 14- CONVEYING SYSTEM Electrical Passenger Elevator. 14.1 Supply, Install & Commissioning Duplex
Electrical Passenger Elevator for 3 stops, 1600Kg. ( 21 Passengers) Loading capacity, Complete with all necessary requirement as per contract and Fire Brigade specification as shown on the drawing. Including Fire Brigade approval.
Nos 2
14.2 Allows for electrical works (power, control, fire alarm, etc.) associated with Elevators Equipments, and System, Including cabling, wiring, switching, elevator control panels with all accessories and all other related works as per specification and Kuwait Fire Brigade..
LS LS
14.3 Emergency Diesel Generator 45 KW for Fire Brigade operation and in case of power failure complete with all accessories
Nos. 4
14.4 Allow for interlocking the elevators control with the building managements system.
LS LS
14.5 Any other item (s) not mentioned either above or in the specification but it’s necessary for the optimum operation of the system in according with the specification and Kuwait Fire Brigade requirements.
LS LS
14.6 Allow for builder’s works required for the elevator.
LS LS
14.7 Allow for submitting shop working drawing, coordination drawing, builder works drawing, as-built drawing, operation & maintenance manual, etc.
LS LS
14.8 Allow for testing & commissioning of the elevators in accordance with specification and Kuwait Fire Brigade including handing over to Kuwait Fire Brigade.
LS LS
Total Carried to Collection
ITEM DESCRIPTION AMOUNT
KD
DIVISION 14 CONVEYING SYSTEM
COLLECTION Page No. 14-1
ITEM UNIT QTY UNIT RATE AMOUNT
KD KD
DIVISION - 15 MECHANICAL WORKS DRAINAGE
The following BOQ is for guidance only. Contractor shall verify the quantities as per tender documents without increase in price. Include in price all adjustment required by code or as per coordination with other disciplines. Contractor responsible to get approvals all authorities having jurisdictions for shop drawings. Contractor must attach a breakdown analysis for lump sum items.
15.1 High density polyethylene tempered (HDPE) to
DIN 19535 / 19637 and DIN 8075 drainage piping for underground and above ground drainage system in all aspect as specified.
15.1.1 Dia 50mm MR 409 3.150 1288.350
15.1.2 Dia 75mm MR 170 4.200 714.000
15.1.3 Dia 100mm MR 778 5.250 4084.500
15.1.4 Dia 150mm MR 433 8.400 3637.200
15.2 Polished bronze rain water shoe
Dia 4" Nos 28 36.750 1029.000
15.3 Adjustable floor cleanouts with galvanized cast
iron body, gas and water tight ABS tapered thread plug, with nickel bronze top
Dia 4" Nos 51 47.250 2409.750
15.4 Adjustable floordrain cleanouts with galvanized
cast iron body, gas and water tight ABS tapered thread plug,with nickel bronze top
15.4..1 Dia 4" Nos 85 47.250 4016.250
15.4.2 Dia 3" Nos 3 47.250 141.750
15.5 Vent Hood Caps
15.5.1 Dia 4" Nos 2 15.750 31.500
ITEM UNIT QTY UNIT RATE AMOUNT
KD KD
15.6 Gco
Dia 6" Nos 1 47.250 47.250
15.7 Dia 3" Planter drain Nos 2 31.500 63.000
15.8 Roof Rain water outlets
15.8.1 Dia 6" Nos 8 78.750 630.000
15.8.2 Dia 4" Nos 2 31.500 63.000
15.9 Dia 3"Funnel floor drain Nos 18 68.250 1228.500
15.10 Toilet & kitchen fixtures as shown on the on arch
drawings with chrome fittings of drainage accessories, flexible hoses etc.
15.10.1 Ewc Nos 50 105.000 5250.000
15.10.2 Awc Nos 12 105.000 1260.000
15.10.3 Ablution hose Nos 62 5.250 325.500
15.10.4 Wash basin (counter) Nos 42 94.500 3969.000
15.10.5 Wash basin (pedstal) Nos 8 94.500 756.000
15.10.6 Pantry sinks-single bowl Nos 7 126.000 882.000
15.10.7 LabSink-Single bowl Nos 65 262.500 17062.500
15.10.8 LabSink-double bowl Nos 2 315.000 630.000
15.10.9 Shower Trays Nos 1 105.000 105.000
15.10.10 Drinking Fountain (Type-A) Nos 6 294.000 1764.000
15.11 Cleaning, flushing and painting of all the drainage piping as per colour codes.
L.S. L.S.
15.12 Builders work like including connecting pipes and gullys through cement pipes to manhole and covers for particular application and installation of toilet
L.S. L.S. DESCRIPTION
ITEM UNIT QTY UNIT RATE AMOUNT
KD KD
WATER SUPPLY
Supply, installation, testing and commissioning of the following items & piping networks for buildings for hot and cold water supply system with fittings, valves, equipments, support and requiredpipe,fittings, valves, equipment, supports with pipe, accessories in all aspect as specified. NOTE :
All exposed water supply piping on roof and inside roof shall be poly propylene, as per specification.
15.13 Water supply piping network from water tank to
Including risers, with all accessories like gate valve, check valve.
15.13.1 Dia 3" MR 20 18.900 378.000 15.13.2 Dia 2" MR 164 8.400 1377.600 15.13.3 Dia 1 1/2" MR 170 7.350 1249.500 15.13.4 Dia 1 1/4" MR 150 6.300 945.000 15.13.5 Dia 1" MR 193 5.250 1013.250 15.13.6 Dia 3/4" MR 678 4.200 2847.600 15.13.7 Dia 1/2" MR 520 3.150 1638.000
15.14 Polythelene water tanks (Shaded) including all
accessories, fittings (float switches,inlet valve, drain valves, over flow and drain pipe up to required length etc) Cat and mouse water level indicator including all galvanized steel
supports,frames and bases etc. complete 3000 gallon each.
Nos 5 840.000 4200.000
15.14.1 Ditto - But Capacity 2000 gallon capacity for brackish water supply
Nos 2 420.000 840.000
15.15 Electric water heater pressure type with
concealed valve, pressure and temperature relief valves, all fittings and accessories.
15.15.1 Unit Boiler 120 liter Nos 6 126.000 756.000
15.15.2 Unit boiler of capacity 80 liters/each Nos 6 89.250 535.500
15.15.3 Unit boiler of capacity 50 liters/each Nos 7 78.750 551.250 DESCRIPTION
ITEM UNIT QTY UNIT RATE AMOUNT
KD KD
15.16 Water filters
15.16.1 Central water filters of capacity 10 m3/hr Nos 1 997.500 997.500
15.16.2 Unit filters for kitchen - Dia 1/2" Nos 10 21.000 210.000
15.17 Booster pump set with pressure tank 200 ltr. Minimum capacity including all acccessories having capacity 40 Gpm @ 4 bar.
Nos 1 1312.500 1312.500
Notes :
All the above rates to be including of the following :
Submitting as-built drawings, providing all operation, instruction and maintenance materials etc..
Builders work related to all plumbing works including trenches, patching, chipping works etc.
Electrical works related to all Plumbing services Testing and commissioning of all plumbing services
ITEM UNIT QTY UNIT RATE AMOUNT
KD KD
FIRE FIGHTING
The tender drawing is for guidance only. Contractor should arranage the layout coordinated with all disciplines, submit calculation, catalogues for material and equipment for engineers approval and KFB. The BOQ is for guidance only. Contractor should quote for lump sum price including approval of KFB.
15.18 Black steel piping network suitable for welding
type joints to schedule 40 seamless ( for sprinkler system from tank to pumps, pump rooms, by pass, risers etc. complete with all fittings, flanges blank flanges,unions, fixation materials, supports and hangers.
Dia 65mm MR 30 15.750 472.500
15.19 Galvanised steel piping suitable for threaded
type joints to schedule 40 seamless complete with all fittings, flanges blank flanges,unions, fixation materials, supports and hangers.
15.19.1 Dia 50mm MR 222 12.600 2797.200
15.19.2 Dia 40mm MR 24 8.400 201.600
15.19.3 Dia 32mm MR 35 7.350 257.250
15.20 Painting of all fire fighting piping (2 coats of primer and 2 coats of final finish painting) as per colour codes, labelling, flow direction marking and tags for valves.
L.S. L.S. 525.000 525.000
15.21 FHC
80cm x 160cmx40 cm including 25mm fire hose reel 30m long manual swing type fire
extinguisher as specified 6 kg Dry powder and 2 gallons water/gas
Nos 18 288.750 5197.500
15.22 FC
Fire extinguisher cabinet with 6 kg Dry powder
and 2 gallons water/gas Nos 2 84.000 168.000
ITEM UNIT QTY UNIT RATE AMOUNT
KD KD
15.23 Automatic air vents
Dia 25mm Nos 2 26.250 52.500
Fire Pumps and Accessories
15.24 Electrical fire pumps of type vertical multistage
with all accessories and 2 years maintenance in all aspect including pressure tanks (approval to be done)
15.24.1 Capacity of 200 gpm@ 5.5 bar-20 K.W Nos 2 2625.000 5250.000
15.24.2 Valves and fittings L.S. L.S.
15.24.3 Suction pipe from firewater tank to pumps including all fittings, connection to all valves, mater, strainers, header
L.S. L.S.
Notes :
All the above rates to be including of the following :
Submitting as-built drawings, providing all operation, instruction & maintenance materials etc.
Electrcial works related to all firefighting services
Testing & commissioning of all firefighting services
Builders work related to all firefighting works DESCRIPTION
ITEM UNIT QTY UNIT RATE AMOUNT
KD KD
HVAC - GENERAL NOTES
The following BOQ is for guidance only. Contractor is responsible to get approval from all local authorites.
The BOQ is for guidance only. Contractor should quote for lump sum price including approval of MEW . Include in quotation all catalogues for equipments.
Duct Work
15.25 Glavanized sheet metal duct work complete with required volume control dampers, joints, test holes/back draft dampers, air turning devices, duct access doors. As specified , shown and required for functioning the system..
Kgs. 31000 1.694 52503.150
Duct Insulation
15.26 Perform iinsulation material secured around duct work complete with finishing and aluminium cladding etc. as specified.
M2 4500 3.033 13650.525
15.27 Perform internal acoustic lining material secured on internal surface of duct as specified.
L.S. L.S. 1575.000 1575.000
Air Outlets and Inlets
15.28 Air Outlets and Inlets, include on diffusers, Linear bar grilles, registers, exhaust air valves, louvers, 4' thick filter grilles etc. complete as specified.
L.S. L.S. 12600.000 12600.000 DESCRIPTION
ITEM UNIT QTY UNIT RATE AMOUNT
KD KD
15.29 Exhaust Fans complete with bird screen, back draft damper and other accessories as specified.
15.29.1 E.F -01 , 2700 cfm Nos 1 5985.000 5985.000 15.29.2 E.F -02 , 200 cfm Nos 1 15.29.3 E.F -03 , 2925cfm Nos 1 15.29.4 E.F -04 , 300 cfm Nos 1 15.29.5 E.F -05,06 , 400cfm Nos 2 15.29.6 E.F -07, 400cfm Nos 1 15.29.7 E.F -08 , 600 cfm Nos 1 15.29.8 E.F -09 , 200 cfm Nos 1 15.29.9 E.F -10 , 400 cfm Nos 1 15.29.10 E.F -11 , 400 cfm Nos 1 15.29.11 E.F -12,13,14,17,18,19 , 200 cfm Nos 6 15.29.12 E.F -15-16 , 200 cfm Nos 2 15.30 Package Units
Package Unit complete with all accessories like filters ,mixing box etc as specified @ 115F
15.30.1 PU-GF1&GF6 , 262800 BTU/Hr, 8750 cfm. Nos 2 3780.000 7560.000
15.30.2 PU-GF2&GF3&PU-GF5&GF8, 280000
BTU/Hr, 10000cfm Nos 4 3780.000 15120.000
15.30.3 PU-GF4&GF7, 200000 BTU/Hr, 7500cfm. Nos 2 3780.000 7560.000
15.30.4 PU-FF1&FF9, 280000 BTU/Hr., 10000 cfm Nos 2 3780.000 7560.000
15.30.5 PU-FF2&FF10, 262800 BTU/Hr. 8750cfm. Nos 2 3780.000 7560.000
15.30.6 PU-FF3 to FF8 , 262800 BTU/Hr. , 8750 cfm Nos 6 3780.000 22680.000
15.30.7 PU-SF1&SF6 , 315000 BTU/Hr.,12500 cfm Nos 2 3780.000 7560.000
15.30.8 PU-SF2&SF5, 280000 BTU/Hr. , 10000 cfm Nos 2 3780.000 7560.000
15.30.9 PU-SF3 ,271800 BTU/Hr., 9000 cfm Nos 1 3780.000 3780.000
15.30.10 PU-SF4 , 262800 BTU/Hr., 8750 cfm Nos 1 3780.000 3780.000
15.31 Automatic Control Sequence
Electrical type wall mounted thermostats Nos 24 52.500 1260.000
Total Carried to Collection 97965.000
ITEM UNIT QTY UNIT RATE AMOUNT
KD KD
15.32 Refrigrant Piping / Condensate Drainnage piping Complete With Insulation , Hangers and cladding and insulation
L.S. L.S. 1260.000 1260.000
15.33 Civil works related to A/C such as foundations, steel walkways over the piping on roof, openings and supporting structures, etc.
L.S. L.S. 2625.000 2625.000
15.34 Allow for electrical works ( power, control and fire alarm) associated with HVAC works including cabling, wiring, switching, motor control panels with accessories and all other related works.
L.S. L.S. 3675.000 3675.000
Total Carried to Collection 7560.000
ITEM UNIT QTY UNIT RATE AMOUNT
KD KD
DIVISION - 15 MECHANICAL WORKS MEDICAL GAS SYSTEM,
The following BOQ is for guidance only. Contractor shall verify the quantities as per tender documents without increase in price.
Include in price all adjustment required by code or as per coordination with other disciplines.
Contractor responsible to get approvals all authorities having jurisdictions.
Contractor must attach a breakdown analysis for lumpsum items.
15.35 Supply and Installation of Medical Grade, Degreased Copper Pipes as per specification complete with all fixtures,insulation.
15.35.1 Dia 3" MR 78 31.500 2457.000 15.35.2 Dia 2" MR 72 26.250 1890.000 15.35.3 Dia 1 1/4" MR 108 21.000 2268.000 15.35.4 Dia 1" MR 70 15.750 1102.500 15.35.5 Dia 3/4" MR 120 12.600 1512.000 15.35.6 Dia 1/2" MR 80 10.500 840.000 Control valves
15.36 Supply and Installation of Medical Grade, Degreased Control valves as per specification complete with all fixtures,insulation.
15.36.1 Dia 2" Nos 20 84.000 1680.000
15.36.2 Central Gas regular 3Ø Nos 1 126.000 126.000
15.36.3 Regulating valve Ø 2" Nos 2 52.500 105.000
15.37 Gas Cylinders
Supply and Installation of Medical Grade GS12 gas cylinders
15.37.1 Gas Cylinders (spare) Nos 8 52.500 420.000
Total Carried to Collection 12400.500
ITEM UNIT QTY UNIT RATE AMOUNT
KD KD
15.38 Builders work related to Medical Gas euipment and Piping
L.S. L.S. 525.000 525.000
15.39 Testing and commissioning of all medical gas services
L.S. L.S. 315.000 315.000
Building Automation System (BAS) for Complete Project
15.40 Full building automation system (BAS) complete with controller (Lontalk) type and (Bac) net, protocols and all control panels,wiring, sensors,devices, transformers etc. as as per BAS specifications and system points list schedules for each equipment as per BAS drawings.
L.S. L.S. 26250.000 26250.000
(This includes the connection of all services (plumbing, fire fighting, HVAC) to BAS system as per specification and drawings)
ITEM DESCRIPTION AMOUNT KD DIVISION - 15 MECHANICAL WORKS
COLLECTION Page No. 15-1 17352.300 Page No. 15-2 34035.750 Page No. 15-3 16331.700 Page No. 15-4 2520.000 Page No. 15-5 9619.050 Page No. 15-6 5302.500 Page No. 15-7 80328.675 Page No. 15-8 97965.000 Page No. 15-9 7560.000 Page No. 15-10 12400.500 Page No. 15-11 27090.000
Item Description Unit Price
No. KD. Fils
DIVISION 16 - ELECTRICAL General Consideration for all items:
16.1
The price for all the following items shall include the supply of all materials and equipment unless other wise specified, delivery to site installations , connections , testing, commissioning and making ready for work complete with all necessary cables, wiring, earthing, conduits, draw and outlet boxes , switches, push-buttons, cable trays, trenches, supply steel frames, angles, beams, rods fixation, etc…. and all necessary accessories and components for complete and perfect installation ready for work.
16.2
All works shall be carried out according to drawings, particular and general specifications, contract conditions and to the latest rules and regulations of MOE (E&W), MPW, MOC, Kuwait Fire Brigade and any other concerned authorities, and as approved by these authorities and approved by the Engineer.
All works shall be carried out to comply with the BAS (Building Automation System) requirements.
16.3
The Contractor is reffered to the specifications and Drawings for all details related to this section of the works and here is to include for complying with all the requirements contained therein, wheather or not they are specifically mentioned within the items.
16.4
BUILDER WORK:
All necessary Builder works required by the Engineer for Electrical installation i.e. Manholes, handholds, earth pits, ducts, trenches, cable tiles … etc.
including supply and install 6" & 4" PVC ducts for MLTP, MSB's DB's cables as per shown in drawing and as per MOE (E&W) regulation. Including all ducts between ( LT, Panel and
Transformer ) and H.T. duct for MOE (E&W) intake cable. And all civil work as per Drawings, Specification and the Approval of the Engineer.
L.S. L.S. 9900.000
Item Description Unit Price
No. KD. Fils
Section 16426 Distribution Equipment
Supply, install and connect the following electrical board or S/Fs or DBs, including all cables, cable trays, access conduit, wiring, boxes, W/T Enclosure, earthing, labels name plates , wire and cables markers , foundation trenches , and All required for the connection with the Central Control Management and Monitoring System, etc., as MPW, MOE (E&W) requirements and as shown in the drawings.
The Contractor Must Submit Detail For The Separate Phase Wire To Feed The Backup Battery For Approval, and He is Obligee to Achieve The Engineer Satisfaction.
16426 : Main Switch Board 16.5
Supply, install and connect the following main switch board (MSB), Sub-Main switch Boards (SMSB) complete with Conduits,wiring, earthing, cable glands, meters and all accessories as necessary, testing and commissioning to be ready for good working and all acording to drawings, specification and the Engineer approval.
16.5.01 MSB - A-G-1 No 1 3300.000 16.5.02 MSB - A-G-2 No 1 2640.000 16.5.03 MSB - PU-G No 1 3168.000 16.5.04 MSB - A-F-1 No 1 2420.000 16.5.05 MSB - A-F-2 No 1 2420.000 16.5.06 MSB - PU-F No 1 3300.000 16.5.07 MSB - A-S-1 No 1 2750.000 16.5.08 MSB - A-S-2 No 1 2970.000 16.5.09 MSB - A-PU-S NO 1 2805.000 16.5.10 MSB - A-R No 1 2475.000 16.5.11 MSB - FF No 1 3300.000 Unit Qty
Item Description Unit Price
No. KD. Fils
16426 : Isolators and Switch Fuses& PANEL BOARDS
16.6
Supply, install and connect est and make necessary commissioning, complete with all necessary conduits feeding wirings and cables, earthing , HRC fuses, magnetic contactors ...etc. and all necessary accessories following electrical board and S/F , as per the drawing, specification, MOE (E&W) regulation, and approval of Engineer. All (S/F's, MCCB, ELCB, DB - AHU) protected by water tight enclosure.
The following items fed from MSB - A-G-1-1
16.6.01 DB-A-G-02L No 1 854.700 16.6.02 DB-A-G-02P No 1 737.000 16.6.03 DB-A-G-03L No 1 854.700 16.6.04 DB-A-G-03P No 1 907.500 16.6.05 DB-A-G-05LP No 1 693.000 16.6.06 DB-A-G-07L No 1 836.000 16.6.07 DB-A-G-07P No 1 902.000
16.6.08 30A TPN S/F in W.P.Enclosure for Water Cooler Type C No 1 192.500
16.6.09 15A TPN S/F in W.P.Enclosure for GU No 1 88.000
The following items fed from MSB - A-G-1-2
16.6.10 DB-A-G-01L No 1 825.000
16.6.11 DB-A-G-01P No 1 495.000
16.6.12 DB-A-G-04L No 1 495.000
Item Description Unit Price No. KD. Fils 16.6.16 DB-A-G-04P No 1 385.000 16.6.17 DB-A-G-06L No 1 660.000 16.6.18 DB-A-G-06P1 No 1 770.000 16.6.19 DB-A-G-06P2 No 1 412.500 16.6.20 DB-A-G-06P3 No 1 385.000 16.6.21 DB-A-G-08LP No 1 825.000
16.6.22 30A TPN S/F in W.P.Enclosure for Water Cooler Type C No 1 313.500
The following items fed from DB-A-G-06P1
16.6.23 15A SPN S/F in W.P.Enclosure No 1 89.100
The following items fed from MSB - A-G-2-2
16.6.24 30A TPN S/F in W.P.Enclosure for GU No 2 385.000
The following items fed from MSB - A-F-1-1
16.6.25 DB-A - F -02L No 1 660.000 16.6.26 DB-A - F -02P No 1 660.000 16.6.27 DB-A - F -03L No 1 632.500 16.6.28 DB-A - F -03P No 1 660.000 16.6.29 DB-A - F -05LP No 1 715.000 16.6.30 DB-A - F -07LP No 1 715.000
16.6.31 30A TPN S/F in W.P.Enclosure for Water Cooler Type C No 1 220.000
The following items fed from MSB - A-F-1-2
16.6.32 30A TPN S/F in W.P.Enclosure for Klin room No 1 385.000
Item Description Unit Price
No. KD. Fils
The following items fed from MSB - A-F-2-1
16.6.33 DB-A - F -01L No 1 385.000
16.6.34 DB-A - F -01P No 1 440.000
16.6.35 DB-A - F -04LP No 1 275.000
16.6.36 DB-A - F -06LP No 1 440.000
16.6.37 30A TPN S/F in W.P.Enclosure for Water Cooler Type C No 1 165.000
The following items fed from MSB - A-F-2-2
16.6.38 DB-A - S -02L No 1 825.000 16.6.39 DB-A - S -02P No 1 660.000 16.6.40 DB-A - S -03L No 1 385.000 16.6.41 DB-A - S -03P1 No 1 660.000 16.6.42 DB-A - S -03P2 No 1 742.500 16.6.43 DB-A - S -03P3 No 1 605.000 16.6.44 DB-A - S -05LP No 1 660.000
16.6.45 30A TPN S/F in W.P.Enclosure for Water Cooler Type C No 1 330.000
The following items fed from MSB - A-S-2
16.6.46 DB-A - S -01L No 1 660.000 16.6.47 DB-A - S -01P1 No 1 605.000 16.6.48 DB-A - S -01P2 No 1 605.000 16.6.49 DB-A - S -01P3 No 1 825.000 16.6.50 DB-A - S -04LP No 1 715.000 16.6.51 DB-A - S -06LP No 1 770.000 Unit Qty
Item Description Unit Price
No. KD. Fils
16.6.52 30A TPN S/F in W.P.Enclosure for Water Cooler Type C No 1 330.000
The following items fed from MSB - A-R
16.6.53 DB-A - Roof LP No 1 440.000
16.6.54 DB-A - EX FAN No 1 302.500
16.6.55 15A TPN S/F in W.P.Enclosure (for FAF-1&2, W.Pump 1&2) No 4 66.000
The following items fed from MSB - F-F
16.6.56 Main Fire Pump -01 No 1 192.500
16.6.57 Main Fire Pump -02 No 1 192.500
The following items fed from DB-A - EX FAN
16.6.58 15A TPN S/F in W.P.Enclosure No 4 82.500
16.6.59 15A SPN S/F in W.P.Enclosure No 14 66.000
16140 : Electrical Points 16.7
Supply, install and connect to their respective DB's, the following points including conduit , wiring , draw boxes, outlet boxes , trenching, earthing, switches, accessories, cable, silicon wire, switches double pole switches and all requirements as specified and as shown in drawing and as per the approval of Engineer.
16.7.01 13 A switch / socket / outlet, 3 pin single socket No 438 16.500
16.7.02 13 A switch / socket / outlet, 3 pin Twin socket No 570 19.800
16.7.03 13 A W/T, 3 pin single socket, as specified and as per the drawing. No 51 39.600
16.7.04
3 Compartment Under Floor Service Outlet Box complete with all accessories including the flexible connection to the Power , Telephone , and Data.
No 5 55.000
16.7.05 Junction box with 20A DP switch for F.C. Unit No 7 27.500
16.7.06 Junction box with 20A DP switch for E. W. Heater No 16 27.500
16.7.07 Junction box with 20A DP switch for Fire A. C. Panel with AVA. No 1 27.500
Item Description Unit Price
No. KD. Fils
16.7.08 Junction box with 20A DP switch for W. Cooler No 6 27.500
16.7.09 Junction box with 20A DP switch for Fume No 2 27.500
16515 : Lighting Lighting System
16.8
The price for the following items shall included the lighting points C/W wiring conduit, earthing, switches, push-button, ceiling rose, silicon wire and all accessories with supplying installation, connecting, testing and making ready for work of all, lighting fittings. The contractor should submit the fixation way of light fittings for approval.
16.8.01 Light Points No 407 101.200
16.8.02 Exit sing + EM Light No 49 13.200
16.8.03
Lighting control panel with all Push Buttons, labeling in grave and indication lambs (the indication Lampe shall indicate the on-off).
No 1 550.000
LIGHTING FITTINGS:
16.9
Supply light fitting complete with lamps, tubes , reflectors, diffusers , louvers , transformers , control gears , etc…and with all required fixing accessories , brackets , concrete bases , etc… all as shown on the drawings , specified and as required for proper operation, and as per the approval of the Engineer.
16.9.01 Type A No 776 44.000 16.9.02 Type Ae No 113 77.000 16.9.03 Type B No 917 44.000 16.9.04 Type Be No 99 77.000 16.9.05 Type E No 205 60.500 16.9.06 Type E-EM No 47 93.500
Total Carried to Collection
Item Description Unit Price No. KD. Fils 16.9.07 Type F No 157 49.500 16.9.08 Type F-EM No 18 77.000 16.9.09 Type G-70 No 86 93.500 16.9.10 Type H No 109 55.000 16.9.11 Type H-EM No 37 82.500 16.9.12 Type-EX No 44 55.000 16.9.13 Type-EM No 5 33.000 16.9.14 Type I No 15 38.500 16.9.15 Type O No 91 55.000 16.9.16 Type FL No 12 82.500 16.9.17 Type M No 229 60.500 16.9.18 Type M-EM No 16 88.000 16.9.19 Type L No 45 44.000 16.9.20 Type L-EM No 45 71.500 16.9.21 Type Z No 18 38.500 16.9.22 Type Z-EM No 6 66.000 16.9.23 Type J No 60 82.500 16.9.24 Type J-EM No 5 110.000 16.9.25 Type N (1 x 3) No 16 275.000 16.9.26 Type ST No 6 27.500
Total Carried to Collection
Item Description Unit Price
No. KD. Fils
16452 : Earthing 16.10
Supply, install and connect complete earthing system as per drawings, specification and MOE (E&W) regulation. Any additional earth electrodes needed shall be included without extra cost.
L.S. L.S. 8250.000
16.11 Prepare complete set of electrical and telephone as built drawings and get the approval from MOE (E&W) and MOC.
L.S. L.S.
16.12 Testing and inspection of the electrical and telephone installation on completion and before being energized and get the approved by MOE (E&W) and MOC inspectors in accordance to the MOE (E&W) and MOC regulations and to the approved drawing.
L.S. L.S.
16.13 Allow for submitting as built drawings, providing all operation, instruction and maintenance manuals etc…
L.S. L.S.
Total Carried to Collection
Description Unit Price
No. KD. Fils
DIVISION 16 - ELECTRICAL (LOW VOLTAGE) General Consideration for all items:
16.14
The price for all the following items shall include the supply of all materials and equipment unless other wise specified, delivery to site installations , connections , testing, commissioning and making ready for work complete with all necessary cables wiring, earthing, conduits, draw and outlet boxes , switches, push-buttons, cable trays, trenches, supply steel frames, angles, beams, rods fixation, etc…. and all necessary accessories and components for complete and perfect installation ready for work.
BUILDER WORK:
All necessary Builder works required by the Engineer for Electrical installation i.e. Manholes, handholes, earth pits, ducts, trenches cable tiles … etc.
16.15
All works shall be carried out according to drawings, particular and general specifications, contract conditions and to the latest rules and regulations of MOP (E&W), MPW, MOC, Kuwait Fire Brigade and any other concerned authorities, and as approved by these authorities and approved by the Engineer.
All works shall be carried out to comply with the BAS (Building Automation System) requirements.
16.16
The Contractor is referred to the specifications and Drawings for all details related to this section of the works and here is to include for complying with all the requirements contained therein, whether or not they are specifically mentioned within the items.
Item Description Unit Price
No. KD. Fils
Section:16721
Fire Detection & Alarm System
16.17 Supply, install, connect, test and commission the fire detection and alarm system complete as per the drawings, specification and to the rules and regulation of Kuwait fire brigade and as per approval of Engineer. Work shall include all conduits , wiring, accessories and components.
16.17.01 Fire Alarm Control Panel complete with all accessories. No 1 2585.000
16.17.02 Fire Alarm Active mimic display panel No 1 1750.000
16.17.03 Main operating , display graphics and programming terminal with processor.
No 1 4400.000
16.17.04 Logging and event system printer. No 1 275.000
16.17.05 Optical smoke detector ( addressable type). Nos 235 38.500
16.17.06 Heat Detector (addressable type). Nos 11 38.500
16.17.07 Duct Detector (addressable type). Nos 20 137.500
16.17.08 Fire alarm manual call point (addressable type). Nos 10 38.500
16.17.09 Local alarm horn. Nos 35 55.000
16.17.10 Connection up to Motorized Dampers, Doors Opener, HVAC control panels, elevator control panels, sprinkler flow switches, Air pressure fans, Smoke and Fresh air Fans…etc.
L.S. L.S. 825.000
Total Carried to Collection
Item Unit Price
No. KD. Fils
Section:16740 Telephone System - Cabling
16.18 Supply, install, connect, test and make ready for works the following Telephone System including conduits, wire, terminal boxes, draw boxes, socket outlet, all as per schematic, drawings
16.18.01 telephone socket outlets Nos 151 38.500
16.18.02 MDF Nos 1 715.000
16.18.03 TTB-A-F(80X90X15 CM) Nos 1 550.000
16.18.04 TTB-A-S(70X80X15 CM) Nos 1 440.000
16.18.05 TTB-A-F (80x90x15cm) Nos 1 550.000
16.18.06 TTB-A-S (70x80x15cm) Nos 1 440.000
16.18.7 Any other missing items required for full functioning of the job (if any)
L.S. L.S.
Total Carried to Collection
Item Description Unit Price
No. KD. Fils
Section 16750 Audio Visual System
16.23 Supply, install, connect test and make ready for works, Sound system including all, conduit, boxes, draw boxes, terminal boxes wires, connection of Gl conduit, The price for the sound system shall include the supply of all materials and equipment delivery to site,installations, connections, testing, commissioning and making ready for work complete with all necessary cables wiring, earthing, conduits, draw and outlet boxes, switches , push-buttons , cable trays, and all work required to make the work done. All should be as per the contract drawing and the approval of Engineer.
16.23.4 Seminar Hall
16.23.4.01 Data And Video Projector 4000 ANSI Lumens No 1 2200.000
16.23.4.02 Rear Projection Lens No 1 385.000
16.23.4.03 Rear projection screen No 1 1375.000
16.23.4.04 Rear Projection screen frame No 1 220.000
16.23.4.05 DVD No 1 132.000
16.23.4.06 VCR No 1 82.500
16.23.4.07 Visualizer No 1 1430.000
16.23.4.08 PC interface No 1 330.000
16.23.4.09 Hide away unit No 1 1265.000
16.23.4.10 AV switcher No 1 132.000
16.23.4.11 Power amplifier Nos 3 495.000
16.23.4.12 Mixer and preamplifier No 1 715.000
16.23.4.13 Sub waffer speaker Nos 2
16.23.4.14 Monitoring panel No 1 385.000
16.23.4.15 Stage speaker Nos 6 275.000
PAGE DESCRIPTION NO DIVISION 16 - ELECTRICAL COLLECTION Page No. 16-1 Page No. 16-2 Page No. 16-3 Page No. 16-4 Page No. 16-5 Page No. 16-6 Page No. 16-7 Page No. 16-8 Page No. 16-9 Page No. 16-10 Page No. 16-11 Page No. 16-12 Page No. 16-13 Page No. 16-14
Total Price KD. Fils
Total Price KD. Fils 3300.000 2640.000 3168.000 2420.000 2420.000 3300.000 2750.000 2970.000 2475.000 3300.000
Total Price KD. Fils 854.700 737.000 854.700 907.500 693.000 836.000 902.000 192.500 88.000 825.000 495.000 495.000
Total Price KD. Fils 385.000 660.000 770.000 412.500 385.000 825.000 313.500 89.100 770.000 660.000 660.000 632.500 660.000 715.000 715.000 220.000 385.000
Total Price KD. Fils 385.000 440.000 275.000 440.000 165.000 825.000 660.000 385.000 660.000 742.500 605.000 660.000 330.000 660.000 605.000 605.000 825.000 715.000 770.000
Total Price KD. Fils 330.000 440.000 302.500 264.000 192.500 192.500 330.000 924.000 7227.000 11286.000 2019.600 275.000 192.500 440.000
27.500
Total Price KD. Fils 165.000 55.000 41188.400 646.800 550.000 34144.000 8701.000 40348.000 7623.000 12402.500 4394.500 42605.200
Total Price KD. Fils 7771.500 1386.000 8041.000 5995.000 3052.500 2420.000 165.000 577.500 5005.000 990.000 13854.500 1408.000 1980.000 3217.500 693.000 396.000 4950.000 550.000 4400.000 165.000 50666.000
Total Price KD. Fils
8250.000 Total Price
Total Price KD. Fils 2585.000 1750.000 4400.000 275.000 9047.500 423.500 2750.000 385.000 1925.000 825.000 24366.000
Total Price KD. Fils 5813.500 715.000 550.000 440.000 550.000 440.000
8508.500 Total Price KD. Fils 2200.000 385.000 1375.000 220.000 132.000 82.500 1430.000 330.000 1265.000 132.000 1485.000 715.000 385.000 1650.000
