Datasheet
2
AggreGate
Supported
Platforms
• Windows XP and above (32-bit and 64-bit versions)
• Linux (32-bit and 64-bit versions)
• Mac OS X
IT + Automation + Security
Provide end-to-end monitoring and incident management for industrial equipment, network infrastructure and physical security systems of your datacenters by emplying a solid umbrella solution. Get rid of multiple systems and multiple points of integration between them.
For Commercial and Corporate Data Centers
Automate data centers built for corporate customers. Automate commercial data centers that will remain under your service. Our solution architecture can be tailored to a data center of any size, from ten to ten thousand racks.
Data Center Monitoring and Management
AggreGate Data Center Supervisor is an umbrella data center management solution. The system is designed for system integrators and MSPs completing turnkey data center design and implementation projects.
Being a based on enterprise-grade network management, industrial automation and physical security products, AggreGate Data Center Supervisor delivers a lot of opportunities for managing and monitoring data centers of any size and purpose.
3
AggreGate
Data Center
System
Requirements
Up to 100 devices: • CPU Cores: 1 • RAM: 1 Gb • Disk space: 10 Gb Up to 1000 devices: • CPU Cores: 4 • RAM: 4 Gb • Disk space: 100 Gb Up to 3000 devices: • CPU Cores: 8 • RAM: 8 Gb • Disk space: 200 Gb 3000+ devices:• CPU Cores: 16 or more • RAM: 16 Gb or more • Disk space: 500 Gb
Based on Mature Platform
Being based on AggreGate Network Manager, AggreGate SCADA/HMI, AggreGate Building Automation and AggreGate Access Control, the Data Center supervisor inherits all their advantages, as well as “generic” data acquisition, storage, processing and visualization features of the
underlying AggreGate Platform.
Rich Connectivity with Industrial Equipment
AggreGate Data Center Supervisor supports all widespread industrial control protocols out-of-the-box, including Modbus, OPC, OPC UA, BACnet, SNMP, and many more. Drivers for PLCs, sensors and
monitoring appliances that use other protocols can be easily designed using the open-source Driver Development Kit (DDK). Tibbo’s line of programmable controllers may be used for providing digital and analog I/O, as well as network-enabling any RS-232 and RS-485 devices.
Datacenter Environment Monitoring
Monitor temperature, humidity, hot/cold air pressure, airfl ows, overall carbon dioxide emission. Detect leakages, smoke and fl ooding. Provide per-rack environment displays, custom airfl ow mapping, overall environment KPIs, environment dashboards, and more. Benefi t from dynamic baselining and threshold violation alerting.
HVAC/CRAC Monitoring
Activate and control proportioning valves, boilers, hear-exchange units, pumps, blowers, and air handlers. Visualize equipment status on dynamic fl oor plans, provide comprehensive dynamic baseline violation alerting and reporting.
UPS/PDU Monitoring
Connect to advanced UPS/PDU units via standard industrial protocols or access UPS/PDU units with serial interface via CLI and parse their status. Visualize unit operational status, active alerts and bypass mode state. Track per-input voltages, currents and frequencies, per-battery statuses and charge/discharge currents. Monitor remaining battery time and load percentages, generator temperature readings and other custom metrics. Provide alerting and historical trending.
Genset Monitoring
4
AggreGate
Order
Information
License Item Code
10 devices agg-dc-10 20 devices agg-dc-20 50 devices agg-dc-50 100 devices agg-dc-100 200 devices agg-dc-200 500 devices agg-dc-500 1000 devices agg-dc-1000 2000 devices agg-dc-2000 Unlimited agg-nm-unlim
Data Center Visualization
Design maps, forms, widgets and HMIs in the integrated full-blown visual editor. Use 30+ component types, including complex components like tables, video player, network topology graphs etc. Graph data with 20+ chart types having thousands of confi gurable properties. Confi gure component templates (subwidgets), make use of 4 nestable container types with either classic absolute layouts or advanced HMTL-like grid layouts. Confi gure sizes, borders, fonts, colors, strokes, cursors, tooltips, etc. Add event-driver behavior to your interface via formula-based bindings between UI and server/device data.
Air Flow Visualization
Conduct thermal profi ling and visualize air fl ows in hot/cold aisles. Handle hundreds of sensors via sensor grid modeling technology while making equal use of server/router/switch internal sensors. Build heat maps based on standard fl oor plans for tracking minor deviations and hot/cold spots.
Energy Performance Analysis
Model overall data center power KPIs and analyze energy effi ciency. Automatically evaluate aggregated KPIs for multiple data centers in a distributed installation. As a result, benefi t from Power Usage
Effectiveness (PUE) trends and reports.
Deeper Data Center Facility Management
Manage other data center facilities, such as water reservoirs, lighting, car parking, and other secondary systems of a present day intelligent building. Develop custom HMIs and integrate them into main control room.
Access Control
Integrate with access control, fi re alarming, perimeter defense, and other physical security systems for retrieving security alerts and incidents via standard protocols (like SOAP, SQL, CAP, SNMP etc.) or proprietary APIs. Provide centralized security incident management and debriefi ng, manage security events using same workfl ows as applied for
automation and IT events. Use a single point of Service Desk integration. Optionally, build a custom access control solution based on Tibbo Project System.
Video Monitoring
5
AggreGate
Data Center
Supported
Databases
• MySQL • MS SQL Server • Oracle • PostgreSQL • Firebird • And moreComprehensive IT Monitoring and Management
The Data Center Supervisor enables comprehensive management of data center IT infrastructure. Thousands of network management features inherited from AggreGate Network Manager include automatic network discovery, L2/L3 mapping, server hardware and OS monitoring, consolidation of network events via SNMP traps and Syslog messages, event correlation and root cause analysis, capabilities of business service modeling and SLA violation tracking, as well as out-of-box monitoring of applications, services, databases, VoIP, wireless infrastructure, and more. The system also ensures network device confi guration and compliance tracking. It inherits hundreds of bundled dashboards, charts, reports and alerts.
Router and Switch Monitoring
Monitor status, performance and bandwidth usage of individual router/ switch interfaces: all popular network hardware vendors, including Cisco, 3Com, Alcatel, Nortel and Juniper are supported. Use integrated charts, reports, alerts for both standard and custom metrics (e.g. fan status or voltages).
Traffi c Monitoring
Facilitate bandwidth problem troubleshooting, SLA verifi cation and capacity planning. View historical charts and reports for traffi c/ bandwidth. Employ network traffi c analysis and browse detailed information on traffi c composition (NetFlow, sFlow). Use visual network traffi c view builder, alerting when network talks matching specifi c criteria are detected, and more.
Virtualization Monitoring
Plan, consolidate, monitor, optimize, and automate your virtual
infrastructure. Monitor vSphere, VMware ESX/ESXi and Microsoft Hyper-V hypervisors, as well as guest virtual machines. Make use or out-of-the-box alerts for guest VM state change, high memory usage, high CPU load and extensive disk I/O.
Storage Monitoring
6
AggreGate
VLAN and Uplink Monitoring
Monitor and visualize individual VLAN networks within your data center. Track utilization and health of gateway routers’ uplink interfaces. Enable bandwidth utilization trending and early predicted violation alerting.
IT Asset Inventory
Add custom attributes to network devices and system resources, use tabular attributes with custom structure and any length.Use out-of-box inventory information defi nitions (serials, responsible persons, notes, photos, locations, asset events, etc.). Enrich system alerts and events with information fetched from any third-party inventory system via any protocol (SQL, SOAP, etc.) Automate hardware and software inventory via SNMP and WMI. Get printable inventory reports automatically e-mailed upon schedule.
Advanced SNMP Management
Collect, store and analyze custom metrics from all types of SNMP-enabled devices, such as fan status, environment temperature/humidity or wireless signal strength. Aggregate, browse and fi lter SNMP traps. Load MIB fi les from different vendors into an internal MIB database, use syntax-highlighted MIB editor. Mak SNMP device settings and traps available for integrated data processing tools, visual editors and third-party systems
DCIM and Service Desk Integration
Integrate with any DCIM or Inventory system for enriching alerts with context-sensitive physical asset details. Model relations between physical assets and business services. Forward enriched alerts to any Service Desk or Helpdesk system via standard (SOAP, CORBA, JMX, SQL, etc.) or custom integration connectors. Set up email-based alert-to-ticket conversion. Employ Tibbo team for implementing any custom integration scenario.
Patented Technology
7
AggreGate
Data Center
Charting and Trending
Charting support offers a wide list of chart types, including dynamically updated charts. Thousands of confi gurable chart properties. Support for auto-calculated trend lines such as percentiles, moving averages, etc.
Alerting and Event Processing
Flexible event management capabilities, including event fi ltering,
aggregation, deduplication, masking, correlation, acknowledgement, and root cause analysis. Customizable alerts supporting different types of notifi cations (sound, popup messages, e-mail, SMS etc.) Support for pending alerts. Flexible rules of alert escalation. Alert-to-action bindings ensure different kinds of remediation when alert is raised. Corrective actions may be controlled by operator or executed in non-interactive mode with pre-defi ned user input.
Comprehensive Reporting
Advanced reporting facility, automatic report generation from any viewed/edited data. Built-in report editor, report printing and exporting in different formats.
Free open-source SDK
Use our open-source Java and .NET APIs to extend the Data Center Supervisor and transparently integrate it into any enterprise system you may have.
Flexible Security Model
From the ground up, AggreGate was designed with a multi-tenant, multi-user approach. Granular permissions and role-based access control are inseparably woven into all aspects of the system.
Failover Clustering
Ensure high availability services by building a multi-node failover cluster for AggreGate Server and underlying database. Our home-grown
8
AggreGate
About Tibbo
Located in Taipei, Taiwan, Tibbo Technology Inc. brings simplicity to the embedded world defi ned by the enormous complexity of operating systems, programming languages, and design tools. Tibbo’s hardware, Tibbo-BASIC program-ming language with its Tibbo IDE software, and the AggreGate Platform offer a complete rapid development solution for data collection, automation, security, and monitoring devices and systems.
Distributed Architecture
Build distributed systems by supervising several geographically distributed data centers from a single location. The unique multi-tier architecture guarantees unlimited scalability by balancing system functionality between multiple servers divided into several layers.
Modular, Scalable and Reliable Architecture
Modular architecture of AggreGate Platform ensures that new data storage, processing and visualization modules may be installed into server core as plug-ins. For example, adding Access Control capabilities to an existing automation/IT management system is just a matter of extension pack installation.
Unifi ed Data Model
The Unifi ed Data Model inherited from AggreGate Platform delivers generic fl exible approach for confi guring, controlling and monitoring any device, data source or system object, regardless of its vendor, model, type and purpose.
Benefi ts of Integrated Data Center
Management System
Immediate technical benefi ts:
• Unifi ed operator access control
• Single point of integration with DCIM and SD • Homologous control room dashboards • Fast and less expensive deployment • Lower operator error rate
• Lower management solution TCO
Long-term business benefi ts:
• Lower energy costs and overall OPEX
• Increased QoS due to accelerated responses to failures and service degradation • Optimal capacity planning based on trend analysis
9
AggreGate
Data Center
Try it now!
Download 30-days trial or free version for 10 devices: http://aggregate.tibbo.com/network_management/
