Unit 2: Building LiveView Applications
– Examine the Live Datamart Architecture
– Understand different techniques to insert data into Live Datamart
tables
– Define different types of LiveView Tables
– Introduce the Project Viewer
Publishing Data into Live Datamart
(the Data Layer)
LDM Data Layer
Item Category Price
RawItems Table
Data
Table
Query in LiveQL; processed on server side - example:
avg(Price) as priceAvg
“select Item, Category priceAvg From AggItems”
AggItems
Table
Transform
Data
Table
Join
Remember: Can pose queries to ANY LiveView Data
Table: base or generated
Manipulations
Generated Tbls
Base Tables
Pr
eproces
sor
sbapp
Embedded Data Source
Embedded Publisher
Java
Client
Uses
Publish
API
ItemsAvgPrice
Table
Item Category AvgPrice
Author-Time Agg
“select Item, Category, AvgPrice from ItemsAvgPrice”
OrdersTable
“select Item, Category, avg(Price) as priceAvg Group By Item, Category
from RawItems”
sbapp
• Data Sources
• Embedded Publishers
• LiveView Publish Adapter
• LiveView Client
• Implemented via sbapp hosted in-process
• Data Source
– Provides data to only a single Table
• Embedded Publisher
– May publish to multiple tables
– Supports recovery of persistent tables
• Preferred over Client APIs and LiveView Publish Adapters
because
– Life cycle management handled by server
– No connectivity issues (for example, no such host) because they are
in-process
– No reconnect worries
– Higher performance – uses local container connection
• LiveView Publish Adapter from a StreamBase app
– Convenient for use with external SBDs/existing StreamBase apps
– NO support for recovery of persistent tables (LiveView Publisher
HAS this support)
– NOT the fastest publishing method:
– Due to translations through different external protocols:
Adapter -> LiveView Protocol -> Services Layer -> StreamBase
Protocol -> Data Layer
• LiveView Client API
– Allows for use of multiple APIs (.NET, java, JS)
– Uses same underlying functionality as the LiveView Publish
Adapter
Includes relationships as directed graph of data flow. Created from lvconf configuration files. Continually monitored and updated to reflect project changes
Visual representation of relationship between various components
Provides project control features
Ability to run project; visual representation for status of tables (spinning disk animation while starting, green border when fully started). Supports dynamic add, drop, start and stop of tables
Live Datamart Data Layer and the Project Viewer
LDM Data Layer
Item Category Price
RawItems Table
Data
Table
Query in LiveQL; processed on server side - example:
avg(Price) as priceAvg
“select Item, Category priceAvg From AggItems”
AggItems
Table
Transform
Data
Table
Join
Remember: Can pose queries to ANY LiveView Data
Table: base or generated
Manipulations
Generated Tbls
Base Tables
Pr
eproces
sor
sbapp
Embedded Data Source
Embedded Publisher
Java
Client
Uses
Publish
API
ItemsAvgPrice
Table
Item Category AvgPrice
Author-Time Agg
“select Item, Category, AvgPrice from ItemsAvgPrice”
OrdersTable
“select Item, Category, avg(Price) as priceAvg Group By Item, Category
from RawItems”
sbapp
Use to specify table schema, either by reference to named schema or by editing a schema grid directly.
Data Table
Use to create simple data source EventFlow application that will send data to a specified table. Can automatically create a Feed Simulation based on the table’s schema to generate random data for the table.
Data Source
Use to create publishing application to publish data to one or more data tables. Includes options for Feedsim, EMS and FTL as sources. Bus options support recovery.
Publisher
Use to create aggregation between two existing tables (Base table feeds the Target table with some type of projection (and optional predicate)
Aggregation
Use to create a transformation application to take data from a source table, manipulate it in some way, then place into target table.
Transform
Preprocessor
Use to specify table schema, either by reference to named schema or by editing a schema grid directly.
Data Table
Use to create simple data source EventFlow application that will send data to a specified table. Can automatically create a Feed Simulation based on the table’s schema to generate random data for the table.
Data Source
Use to create publishing application to publish data to one or more data tables. Includes options for Feedsim, EMS and FTL as sources. Bus options support recovery.
Publisher
Use to create aggregation between two existing tables (Base table feeds the Target table with some type of projection (and optional predicate)
Aggregation
Use to create a transformation application to take data from a source table, manipulate it in some way, then place into target table.
Transform
Preprocessor
No naming conventions are enforced.
Table Name
Schema can be predefined and reused from
some saved project or entered here.
Schema
Every LiveView Table requires a Primary Key.
Primary Key (Indexes)
In addition to the required primary key, for
performance tuning secondary indexes may be
added
Secondary Indexes
Every LiveView Table requires a Primary Key.
Primary Key (Indexes)
In addition to the required primary key, for performance tuning secondary indexes may be added
Secondary Indexes
