Optimal sizing and operation planning of microgrids and operation analysis of charging stations for electric vehicles

Optimal sizing and operation planning of

microgrids and operation analysis of

charging stations for electric vehicles

by

Ioannis Zenginis

ADVERTIMENT La consulta d’aquesta tesi queda condicionada a l’acceptació de les següents condicions d'ús: La difusió d’aquesta tesi per mitjà del r e p o s i t o r i i n s t i t u c i o n a l UPCommons (http://upcommons.upc.edu/tesis) i el repositori cooperatiu TDX (h t t p : / / w w w . t d x . c a t /) ha estat autoritzada pels titulars dels drets de propietat intel·lectual únicament per a usos privats emmarcats en activitats d’investigació i docència. No s’autoritza la seva reproducció amb finalitats de lucre ni la seva difusió i posada a disposició des d’un lloc aliè al servei UPCommons o TDX. No s’autoritza la presentació del seu contingut en una finestra o marc aliè a UPCommons (framing). Aquesta reserva de drets afecta tant al resum de presentació de la tesi com als seus continguts. En la utilització o cita de parts de la tesi és obligat indicar el nom de la persona autora.

ADVERTENCIA La consulta de esta tesis queda condicionada a la aceptación de las siguientes condiciones de uso: La difusión de esta tesis por medio del repositorio institucional UPCommons (http://upcommons.upc.edu/tesis) y el repositorio cooperativo TDR (http://www.tdx.cat/?locale-attribute=es) ha sido autorizada por los titulares de los derechos de propiedad intelectual únicamente para usos privados enmarcados en actividades de investigación y docencia. No se autoriza su reproducción con finalidades de lucro ni su difusión y puesta a disposición desde un sitio ajeno al servicio UPCommons No se autoriza la presentación de su contenido en una ventana o marco ajeno a UPCommons (framing). Esta reserva de derechos afecta tanto al resumen de presentación de la tesis como a sus contenidos. En la utilización o cita de partes de la tesis es obligado indicar el nombre de la persona autora.

WARNING On having consulted this thesis you’re accepting the following use conditions: Spreading this thesis by the i n s t i t u t i o n a l r e p o s i t o r y UPCommons (http://upcommons.upc.edu/tesis) and the cooperative repository TDX (http://www.tdx.cat/?locale-attribute=en) has been authorized by the titular of the intellectual property rights only for private uses placed in investigation and teaching activities. Reproduction with lucrative aims is not authorized neither its spreading nor availability from a site foreign to the UPCommons service. Introducing its content in a window or frame foreign to the UPCommons service is not authorized (framing). These rights affect to the presentation summary of the thesis as well as to its contents. In the using or citation of parts of the thesis it’s obliged to indicate the name of the author.

Optimal sizing and operation planning of

microgrids and operation analysis of

charging stations for electric vehicles

Doctoral Thesis

By

Ioannis Zenginis

Submitted to the Universitat Polit`ecnica de Catalunya (UPC) in partial fulfillment of the requirements for the degree of

D

P

Supervisors:

Dr. Christos Verikoukis2, Dr. John Vardakas3 and Dr. Luis Alonso Z´arate1

1 _{Department of Signal Theory and Communications (TSC), Polytechnic University of} Catalonia (UPC), Barcelona, Spain

2 _{Catalan Telecommunications Technology Centre (CTTC), Barcelona, Spain} 3_{Iquadrat Informatica, Barcelona, Spain}

Abstract

Energy and transportation sectors are going through major changes as a result of technological advances, depletion of fossil fuels and climate change. With regard to the energy sector, the future smart grid is expected to be an interconnected network of small-scale and self-contained microgrids, in addition to a large-scale electric power backbone. By utilizing microsources, such as renewable energy sources, energy storage systems and vehicle-to-grid systems, microvehicle-to-grids target to satisfy the customers’ energy demands in a safe, reliable, economic and environmentally friendly way. With regard to the changes in the transportation sector, internal combustion engine vehicles are expected to be gradually replaced by electric vehicles, which are considered to be a promising solution for mitigating the impact of transportation sector on the environment. The presented thesis deals with two main topics; the first one refers to the optimal sizing and operation planning of microgrids comprising various urban building types, while the second one is related to the operation of fast charging stations for electric vehicles that are located in densely populated areas.

The first objective of the thesis is to examine the effect of energy exchanges among interconnected buildings with diverse load profiles on the sizes of power equipment to be installed at the buildings. To this end, a mixed integer linear programming optimization framework is presented that determines the optimal capacities of photovoltaic panels, energy storage systems, and inverters, as well as the optimum management of the generated power. As a first step, the benefits of cooperation among buildings that are already interconnected through an existing point of common coupling is examined. The cooperation benefits are derived by comparing the buildings’ costs when they participate in the microgrid with their costs when they operate as separate entities. As a second step, a different microgrid topology is proposed where energy exchanges take place through a common DC bus. In this way, neighboring buildings that are not already physically connected can be members of the same microgrid. Moreover, the optimization results for the new topology are obtained by using the Nash bargaining method, through which the benefits of cooperation are equally distributed among the participating members. Finally, the possible integration of new buildings in the existing microgrid at a later time point is also examined.

The second objective of the thesis is to provide an accurate operation analysis of fast charging stations for electric vehicles. To this end, a novel queuing theory-based model is presented that classifies the various electric vehicles by their battery size. As a first step, it is analyzed a charging station that contains DC outlets, and the electric vehicles recharge their batteries up to the maximum possible level. The proposed model takes into account the arrival rates and state of charge of the electric vehicles’ batteries when arriving at the station, in order to compute the maximum number of customers that can be served, subject to an upper bound for the waiting time in the queue. In addition, a charging strategy is proposed, which allows the charging station to serve more customers without any increase in

the queue waiting time. As a second step, it is considered that the charging station can serve both DC and AC electric vehicle classes, while a more flexible way is adopted for denoting the customers’ recharging patterns. Based on these additional novelties, the overall profit margin of the charging station operator, and the queue waiting times of the DC and AC classes are calculated under two different pricing policies.
