COR-A-VENT. Product Guide

(1)

COR-A-VENT

®

Product Guide

(2)

COR-A-VENT PRODUCT GUIDE

- Guide to Cor-A-Vent Products & Application - Product End Views

- Balanced Ventilation - How it Works

RIDGE VENT PRODUCT BROCHURES

- Revolution Rolled Ridge Vent - X-5 ridge vent

- V300 & Fold-A-Vent ridge vents - V400E ridge vent

COMPOSITION SHINGLE APPLICATIONS

- X5 11” with composition shingles (COR-COMP1) - V600 11” with comp. shingles (COR-COMP2) - V300 11” with comp. shingles (COR-COMP3) - Revolution 11” with comp. shingles (COR-COMP4)

CEDAR SHAKES & SHINGLES APPLICATIONS

- V600 8 ½” with cedar shakes (COR-CED1) - V300 8 ½” with cedar shakes (COR-CED2)

- V300 11” with cedar shakes – hip roof application (COR-CED3)

TILE & SLATE APPLICATIONS

- V600-TE with barrel or S-tile application (COR-TS1) - V300 8 ½” with flat tile application (COR-TS2)

- V300 11” with slate ridge & hip roof application (COR-TS3) - V600-TE with flat tile application (COR-TS4)

METAL ROOF APPLICATIONS

- Metal Roof Ventilation color brochure

- V600 11” with standing seam application (COR-MTL1) - V600-TE with standing seam application (COR-MTL2) - V600-TE with profile panel application (COR-MTL4) - V600-TE with profile panel application (COR-MTL5) - V600-TE with metal shingles (COR-MTL6)

- Purlin Vent – floating ridge application (COR-MTL7E) - Purlin Vent – shed roof detail (COR-MTL7F)

- Purlin Vent – gutter on wood frame construction detail (COR-MTL7G) - Purlin Vent – gutter on structural steel detail (COR-MTL7H)

- V600 & V600-TE – ridge with steel framing detail (COR-MTL8) - S-400 Strip Vent – soffit with steel framing detail (COR-MTL9) - SP1 – Spacer for metal roofing over asphalt shingles detail (COR-SP1)

(3)

SOFFIT APPLICATIONS

- RS-400 Raft-A-Vent brochure

- Soffit Vent (S-400, PS-400, RS-400) brochure

- S-400 with boxed-in eave & stucco soffit details (COR-SOF2) - S-400 zero overhang soffit detail (COR-SOF3)

- S-400 with engineered truss application (COR-SOF4)

- RS-400 (Raft-A-Vent) with bird blocks & open rafters (COR-SOF5) - S-400 with overhang soffit restoration/cornice detail (COR-SOF6) - S-400 shed roof application (COR-SOF7)

- RS-400 (Raft-A-Vent) with exposed eave & truss detail (COR-SOF8) - PS-400 soffit application (COR-SOF9)

- S-400 frieze board with brick exterior application (COR-SOF10) - S-400 frieze board with wood siding application (COR-SOF11)

SPECIALTY APPLICATIONS

- Siding Vent System (SV-3, SV-5, Sturdi-Strips) color brochure - Roof-2-Wall vent color brochure

- Roof-2-Wall vent with shingles & flat tile applications (COR-VAR1) - Roof-2-Wall vent with masonry veneer wall application (COR-VAR2) - IN-Vent rooftop intake vent with shingles application brochure - V600 11” wide ridge beam (3) details (COR-VAR4)

- V600T on slope-to-flat applications (COR-VAR5) - X5 11” ( ½ piece) unequal pitch details (COR-VAR3) - Purlin Vent foam & rigid insulation detail (COR-MTL7B)

- V600-TE roof-to-wall with standing seam metal application (COR-MTL3) - V600-T with zero overhang application (COR-SOF1)

- Cold roof application with S-400 on roof deck (COR-SPC1) - Cold roof application with S-400 at eaves (COR-SPC2) - V600 11” flat roof with expansion joint detail (COR-SPC3)

- V600-TE application on existing ridge of admin. Building (COR-SPC4) - V300 11” firewall detail for partition wall at ridge (COR-SPC5) - V600 11” firewall details for partition wall at ridge (COR-SPC6)

INSTALLATION INSTRUCTIONS & TESTING INFORMATION

- Soffit, Gable, and Ridge Vents details & information - Cor-A-Vent Installation & Information Guide (4 pages)

- RADCO Load Tests & Determination of Net Free Vent Area (5 pages)

(4)

FAV-20

V-400E–11'' & 8

1

_/

₂

_''

The “Original”shingle-over ridge vent – the one that started it all 30 years ago and the one everybody else has tried to copy.

•

V-400E – 17" NFVA provides superior ventilation

•

Each carton includes 21_/₂_{'' roofing nails}

•

Regular and Enhanced versions

•

V-400E includes 4 end caps

12 – 4' pieces per carton

V-600–

11'' & 8

1

_/

₂

_''

The highest airflow in the industry for nearly every pitch – from 3/12 to 16/12.

•

Available in 11'' and 81_/2'' widths

•

20'' NFVA provides superior ventilation

•

Radiused peak keeps the ridge well defined

V-600T & V-600TE

•

1'' x 31_/₄_{'' x 4' profile}

•

10'' NFVA, per lineal foot, per piece

•

Covers: 48 l.f. ridge, 96 l.f. roof to wall

V-300–

11'', 8

1

_/

₂

_{'' & 7''}

An ideal hip and ridge vent with a low 5_{/8'' profile} that virtually disappears beneath the cap shingle and even lower price – the best value in the industry.

•

Available in 11'', 81_/₂_{'' and 7'' widths}

•

Power-Nailable

•

13.5'' NFVA

•

Use on pitches from 3/12 to 16/12

•

(7" not enhanced)

12 – 4' pieces per carton or bundle

FAV-20–11'',

8

1

_/

₂

_{'' & 7''}

A flat, continuous 20' folded ridge vent that won’t roll back up and won’t hump up under the cap shingle. Low 5/8'' profile virtually disappears beneath the cap shingle.

•

Available in 11'', 81_/₂_{'' and 7'' widths}

•

13.5'' NFVA

•

Power-Nailable

•

For use on ridge and hips

•

(7" not enhanced)

Guide to COR-A-VENT

®

Products & Applications

These are general application guidelines. Ultimately, the building professional has to determine which product is the “Best Fit” for his/her application based on building codes, prevailing weather patterns and product venting capabilities.

For product end views & dimensions, please refer to Application Drawings CAV-EV. Most of our application drawings are available in .dwg & .pdf file formats on

our website at www.cor-a-vent.com/drawings.htm

Our enhanced products (REV-11" & REV-9", X-5 11" & 81_/₂_{'', V-600TE, V-400E 11" & 8}1_/₂_{'', V-300E 11'' & 8}1_/₂_{", & FAV-20E 11" & 8}1_/₂_{'') are particularly suited for areas where fine blowing snow occurs.} Note: The width of the ridge cap determines which product to use.

X-5 Ridge Vent–

11'' & 8

1

_/

₂

_''

Stop rain and snow cold

With the wind-activated A.W.F. (Active Weather Foil), X-5 provides complete protection in extreme weather conditions.

•

17'' NFVA per lineal foot provides superior ventilation

•

Power-Nailable

•

Each carton includes four end caps

Note: X-5 is specially designed for use on coastal areas, and wherever extreme wind driven rain and snow is typical.

V-600

X-5 Ridge Vent

Revolution Rolled Ridge Vent

V-400E

V-300

Soffit Vents

SV-3, SV-5 &

Sturdi-Strip

Trapped moisture behind you siding can wreak havoc on your home’s exterior,

causing peeling paint, rotting wood, deteriorating underlayment and mold and mildew growth.

COR-A-VENT®_{SV-3 and SV-5 Siding Vents}

and Sturdi-Strips allow that moisture to drain out and let air pass through to keep your wall system dry.

•

A box of SVS contains 18 pcs. of SV-3 or SV-5 Siding Vent, a 4-feet long vent strip covered with our Enhanced Insect Screen, and 56 pcs. of 11_/₂_{" wide by}3_/₈_{" thick by 4-feet long}

Sturdi-Strips™ plastic furring strips

Siding Vent System

Purlin, IN-Vent

S-400 Strip Vent

Continuous strip soffit vent for hard-to-vent eave details – from zero overhang to open rafter.

•

Narrow 1'' profile easily concealed

•

10'' NFVA per lineal foot

PS-400

•

1'' x 3_/4'' x 4' profile ideal for 1x soffit panels

•

10'' Net Free Vent Area per lineal foot

RS-400

•

Power nail to the bird block for quick installation

•

18.75'' Net Free Vent Area per piece

48 – 221_/2'' pieces per carton

Black or White

Purlin Vent

Use Purlin Vent under metal roof and sidewall to vent the total building envelope.

•

Works as a thermal break between roofing/purlin and siding/girt to reduce heat/cold conduction

•

Doesn’t compress over time, so roofing & siding

screws holes don’t elongate and leak

•

Available in 3" wide x 1" thick x 4' long pcs

IN-Vent

•

Intake ventilation when soffits or overhangs are inaccessible – perfect for re-roof jobs

•

Won’t crush or compress after installation

•

10'' Net Free Vent Area per lineal foot

64 lineal ft. per ctn. plus 21_/₂_{" roofing nails} and IN-Vent end cap sections

REV-11 and REV-9.The first shingle-over ridge vents made from 100% pre-consumer recycled

plastic. Revolution is the only truly “Green” ridge vent available. The vent core is made entirely from the same polypropylene plastic used to manu-facture all of COR-A-VENT’s other products.

•

20-foot long by 11" or 9" wide rolls

•

100% pre-consumer recycled polypropylene*

•

Net Free Vent Area:12 square inches

per lineal foot

•

Power nailable

•

Color: Black

Packaged with two coils of 1¾" galvanized roofing nails and two peel-and-stick End Caps

(5)

CEDA

R A

PPS

SHINGLE A

PPS

METAL A

PPS

TILE/SLATE A

PPS

SPECIALTY A

PPS

SOFFIT A

PPS

RS-400 Raft-A-Vent™ PS-400 Soffit Vent

Shingle Applications

S-400 Strip Vent™ X-5 (1/2 PC) AIR FLOW OLD ROOF NEW ROOF AIR FLOW PURLIN ROOF HUGGER PURLIN VENT COR-A-VENT X-5 (1/2 pc) EXHAUST AIR WALL 1/2" MAXIMUM OVERHANG ON CAP CLOSED OPEN AIR FLOW

Cedar Applications

V-300 & V-300E – 81_/₂_" FAV-20 & FAV-20E – 81_/₂_" V-400E – 81_/₂_"

V-600 – 81_/₂_" X-5 – 81_/₂_"

Tile/Slate Applications

Barrel/Mission & “S” Tile

V-600T V-600TE Slate V-400 – 11" V-400E – 11" Flat Tile V-300 & V-300E – 11" V-300 & V-300E – 81_/₂_" FAV-20 & FAV-20E – 11" FAV-20 & FAV-20E – 81_/₂_" V-600 – 11" & 81_/₂_" X-5 – 11" & 81_/₂_"

Metal Applications

Standing Seam

V-300 & V-300E – 11" FAV-20 & FAV-20E – 11" V-400E – 11"

V-600 – 11" V-600T & V-600TE

Profile

V-300 & V-300E – 11" FAV-20 & FAV-20E – 11" V-600T & V-600TE

Metal Shake

V-300 – 7" & FAV-20 – 7" V-600T & V-600TE

Soffit Applications

S-400 – Zero overhang, wood soffit, frieze board PS-400 – Use on 1" x wood soffit panels RS-400 – Open rafter details

Specialty Applications

Hip Roof

FAV-20 & FAV-20E – 11" FAV-20 & FAV-20E – 81_/₂_" Roof to Wall

Metal Roofs – V-600TE Shingle, Cedar Shake & Flat Tile – use X-5 – 11" (cut in half) Siding Ventilation Sturdi-Strip SV-3 (3-ply) SV-3 (5-ply) Shed Roof S-400 Unequal Pitch

Use X-5 – 11" (cut in half)

Metal Roof & Side Walls

Purlin vent – to maintain air passageway between metal roofing/siding & insulation

HIP ROOF SHED ROOF

ROOF TO WALL

SIDING VENTILATION UNEQUAL PITCH METAL ROOF & SIDEWALLS

7" & 8" Enhanced Ridge Caps

V-300 – 7" & FAV-20 – 7"

9" Hip & Ridge Caps

V-300 & V-300E – 81_/2" FAV-20 & FAV-20E – 81_/2" V-400E – 81_/2" V-600 – 81_/2" X-5 – 81_/2" Revolution – REV-9" 12" Shingle Cap V-300 & V-300E – 11" FAV-20 & FAV-20E – 11" V-400 & V-400E – 11" V-600 – 11"

X-5 – 11"

(6)

(7)

(8)

THE

COR-A-VENT

®

SYSTEM

S-400

STRIP

VENT

COOLER OUTSIDE AIR COOLER OUTSIDE AIR VENTILATION CHUTE AIR FLO W INSULATION

S-400

STRIP

VENT

VENTILATION CHUTE AIR FLO W INSULA TION LO WE RE D A IR P RESS URE . . . DR_AW S A TT IC A IR O U T

HOT MOIST AIR HOT MOIST AIR

RELATIVE WIND

CA THEDRAL CEILING ATTIC

V-400E 11"

RIDGE

VENT

Balanced Ventilation

How It Works

A balanced vent system is one that best utilizes three natural forces: air pressure, the thermal effect and diffusion. Basically, for every square inch of ridge (exhaust) vent you must balance it with at least one square inch or more of soffit (intake) vent.

COR-A-VENT®_{ridge & soffit vent products offer:} • V-600 products – 20 sq. in.

Net Free Vent Area (NFVA)/lineal foot • V-400E & X-5 products – 17 sq. in.

NFVA/lineal foot

• V-300 & Fold-A-Vent®_{products – 13.5 sq. in.}

NFVA/lineal foot

• S-400 Strip Vent line offers 10 sq. in. NFVA/lineal foot

With a ridge and soffit system, cooler ventilation air will be drawn into the attic (or roof cavity if a cathedral ceiling) through the soffit/eave vents located within the positive pressure (intake) areas. It will exhaust through the vents in the negative pressure areas, at the ridge. Wind moving

over the ridge literally “siphons” the hot/moist air out of attic. If the ridge vent were to be installed alone, then part of the ridge would become an inlet vent to relieve this “draw”. This could cause weather infiltration.

The ridge vent must always be installed in combination with some form of soffit/eave intake vents. Do not use ridge vents with gable vents or other roof mounted vents.

The “Ventilation Chute”, or air passageway between the soffit and the ridge must not be blocked or restricted so as to impede airflow. Once again, the ridge vent in this situation can act as intake andexhaust, causing weather infiltration.

For a more attractive ridgeline, COR-A-VENT recommends installing the ridge vent to the very ends of any given ridge. A ridge that is the same height from end to end

makes our vent even less noticeable.

Please refer to the backside of this page for examples of typical continuous soffit vents and vent chute details.

(9)

Figuring Your Ventilation Needs:

V-400E: Square footage of building footprint X .48 = Lineal Feet V-400Eneeded 17

V-300: Square footage of building footprint X .48 = Lineal Feet V-300 needed 13.5

Example: 25' x 50' = 1250 Sq.F. 1250 x .48 = 600

600 ÷ 17 = 35 L.F. V-400E needed

The above formulas will give the amount of COR-A-VENT ridge vent needed for a 1/150 vent ratio, provided an equal or greater amount of soffit venting is used. For a 1/300 ratio, (building code minimum) use half the amount of ridge vent. Note: Code interpretation may vary. Consult your local building dept.

For the best appearance, install COR-A-VENT continuously the entire length of the ridge.

This material may be duplicated only for the purposes of specifying COR-A-VENT products. No permission is given to duplicate or otherwise copy this material for any other purpose without the express written permission of COR-A-VENT, Inc.

Note:Should you need any assistance in designing your ventilation system, fax or mail a sketch and information to our technical services department. COR-A-VENT will respond with recommendations for your particular building design.

COR-A-VENT®_{has promoted and taught}_{balanced ventilation}_{from the day we}

started. It’s a concept all vent manufactures readily endorse. Unfortunately, that information doesn’t always end up in the hands of the person designing the building or installing the vents. Balanced venting helps insure the performance you expect from ridge venting – uniform, increased airflow through the roof cavity without weather infiltration.

Balanced venting:An equal or greater amount of vent opening(sq. in net free vent area/NFVA) in the soffit (intake) than at the ridge. For example, our V-400E products have 17 sq. in NFVA per lineal foot. To balance this, you need 2 soffit/eave/intake vents of approximately 8.5 sq. in. per lineal foot (1_/₂_{of 17 in}

each overhang).

Balanced venting:

Continuous soffit vents are recommended, especially for venting cathedral ceilings. Wherever there is ridge

vent above, there should be soffit/eave/intake vents on the structure below. Also, COR-A-VENT strongly recommendsusing of one of our V-300 products (available in 11, 81_/₂_{or 7" widths) on cathedral ceiling and hip roof applications.}

V-300 delivers 13.5 sq. in net free vent area. The volume of space to be vented in cathedrals is smaller. Therefore a lower profile (5/8") vent is called for to further reduce the chance for infiltration. When installing a ridge vent system, allother vent openings (except soffits) must be closed off.

USE BALANCED AMOUNTS OF SOFFIT VENT TO RIDGE VENT

Continuous aluminum strip vent – 8-9 sq. in. NFVA per lineal foot.

8" x 16" under eave cornice vents with maximum spacing of 4' apart – gives 14 sq. in. NFVA per lineal foot.

Continuous perforated panels – 1' wide overhang (typical) – gives 12-13 sq. in NFVA per lineal foot.

COR-A-VENT’s S–400 Continuous Strip Vent – 10 sq. in NFVA per lineal foot.

Maintaining an unrestricted air passageway between the soffit and ridge is crucial to the performance of the vent system, and must not be blocked or restricted. COR-A-VENT recommends a minimum 2" air space between the roof sheathing and vent chute or insulation

① ➁ ➂ ➄ ➃ ➃ 1. SKYLIGHTS 2. DORMERS

3. INTERSECTING BUILDING COMPONENTS 4. VALLEYS 5. CHIMNEYS

4' MAX

Typical continuous soffit vents

The following NFVA values are approximate, except for COR-A-VENT S-400 strip vent. Consult the vent

manufacturer or distributor for actual values for specific products.

Typical Vent Chute Applications

Typical

Gable

Cathedral

Ceiling

Knee Wall

Balanced ventilation – The right proportion of venting.

INLET (BALANCING) VENTS RIDGE VENT

UNBALANCED VENTILATION AREAS

(10)

COR-A-VENT, INC.

P.O. Box 428 • Mishawaka, IN 46546-0428 Phone: (800) 837-8368 Fax: (800) 645-6162

[email protected] • www.cor-a-vent.com

www.revolutionvent.com

COR-A-VENT®_{, Inc.} _{is proud to introduce the first shingle-over}

ridge vent made from 100% pre-consumer recycled plastic, new

Revolution Rolled Ridge Vent.

Revolution (REV-11) is the only truly “Green” ridge vent available. The 11-inch wide by 20-foot long plastic vent core is made entirely from the same polypropylene plastic used to manufacture all of COR-A-VENT’s other products. We meticulously capture the excess scrap during production, reprocess it and feed it directly into the Revolution, keeping it out of landfills while also reducing the use of petroleum needed for

new plastic production.

Revolution’s precisely spaced ventilation channels provide 12 square inches of Net Free Vent Area per lineal foot to promote the removal of damaging moisture and heat from inside your attic. This helps reduce heating and cooling loads when used in conjunction with balanced intake ventilation. The simple, yet highly effective structural design of Revolution supports power-nailability for easy installation on asphalt shingle roofs, while also providing protection from rain, snow & insects.

• 100%

pre-consumer recycled

polypropylene*

•Net Free Vent Area:12 square inches per lineal foot

• 20-foot long by 11-inch wide rolls •Power nailable • Color:Black

•Enhanced Snow Screenprotects from rain, snow & insects

• Packaged withtwo coils of 1¾" galvanized roofing nails and two peel-and-stick End Caps

*Certification pending

(11)

4. Beginning at end of ridge, apply vent with minimum 1¾" nails (2 coils provided in box) following “NAIL HERE” guides along vent cap. Only apply nails within the area between leg cavities – DO NOT apply nails outside of “NAIL HERE” guide marks. Vent may be power nailed or hand nailed. Do not overdrive nails. Apply ﬁ rst four nails (two on each side), then remove colored band to unroll rest of vent. Continue to apply according to marked guides. Repeat Step 3 to seal opposite end of vent.

5. For runs longer than 20 feet, additional vent rolls can be applied. Line up end of additional vent roll with previous roll by overlapping at offset lip, then apply Peel-&-Stick end cap to seal junction. Follow Step 4

to apply rest of vent.

6. Center shingle cap on vent and nail along “NAIL HERE” guideline. Continue applying caps until all vent is covered with ridge caps. Do not overdrive nails. Nail head should be ﬂ ush with top of shingle, without indenting it. Pre-forming caps in cold weather helps avoid cracking.

Revolution Installation Instructions

1. Measure a 3" slot, 1½" each side of ridge centerline. This allows for a 2x ridge board or smaller. Snap chalk lines the entire length of the ridge. Cut slot with circular saw and clean out debris. Set saw depth so as not to cut roof rafters. Stop slot 12" short of any ridge end, intersecting ridge or obstruction (such as a chimney).

2. Cut clear band around roll, leaving colored band to hold all but the starter section together. Vent installs with legs down and ﬂ at cap on top.

3. Remove backing from 1 Peel-&-Stick end cap section. Apply half of the section to end of the vent, starting with the top cap. Wrap other half of end cap down and underneath vent legs and Snow Screen to close off end of vent.

WRAP END FROM TOP TO UNDERSIDE OF VENT

7. For shorter runs of vent, trim areas provided every 12". Cut with utility knife, snips or saw, taking care to follow recognized manufacturers’ safety procedures for each.

Be careful not to touch knife blade. Always cut in a direction away from yourself. Wear proper hand and eye protection. 12 Square inches Net Free Vent Area per lineal foot. 20' long x 11" wide x 5/8" thick.

For use on roof pitches 3/12 - 16/12.

Call our technical department for any special application questions.

Important notes: COR-A-VENT ridge vents should always be installed with soffi t/eave/intake vents of equal or greater area. All other vent openings (except soffi ts) should be closed off. The air passage way or “Ventilation Chute” between the inlet (soffi t/eave/intake) and the outlet (ridge) vent must not be blocked or restricted. COR-A-VENT products meet or exceed all nationally recognized building codes for ventilation.

Patent pending #6,039,648

COR-A-VENT, Inc.

E-mail: [email protected] www.cor-a-vent.com www.revolutionvent.com

(12)

Note:MAXIMUM1/2" cap overhang required for valve (AWF) to close properly.

COR-A-VENT

®

has the answer for stopping all forms of weather infiltration with the

X-5ridge vent:The Complete Solution– superior ventilation performanceandthe ability to

stop rain and snow infiltration cold…even in weather extremes.

X-5employsdual protectionto stop infiltration. First is theAWF– theactive weather foil, a specially designed,wind-activated, weather impenetrable valve– permanently attached to the bottom layer of ourX-5vent material.

The AWF will stop wind driven rain from penetrating your roof cavity. Second is theenhanced

snow screen, an air-permeable filter that keeps out snow, even at low wind speeds, while still allowing hot, moist air to flow out of the attic.

(13)

How does the AWF work? We’ve engineered the valve to close at 10 MPH(± 2 MPH). The leading (windward) edge of the AWF, which is shaped like an airfoil, catches the wind blowing at it, whether directly or at an angle, and snaps shut. Meanwhile, on the downwind (leeward) side, the vent remains open and continues to exhaust hot, moist air from the attic. Below 10 MPH, the valve opens completely for positive ventilation fromboth sidesof the vent. TheAWFeffectively blocks weather from entering through the vent’s flutes.Dade County acceptance1and our own in house rain tests confirm this. The harder the wind blows, the tighter the AWF seals.

How long will the AWF last?Developed from a special formulation of Reemay®_{non-woven with a UV inhibited proprietary coating, it’s} guaranteed to last. Tested to the same standards as composition shingles, the AWF fabric was subjected to a 5000-hour exposure test from a Xenon Arc weatherometer.

That’s the

equivalent of25 years exposureto south Florida or Death Valley sun. The results –

no significant embrittlement or degradation.

X-5

is made from a special 4mm sheet of extruded PP. This means less restriction and more airflow. At the same time, it has

17 sq. inches of NFVA(Net Free Vent Area) per lineal foot, which exceeds all national building code requirements.

X-5

will work with shingle, metal, tile and cedarroofs and is also a

perfect Roof-To-Wall vent.

X-5

is available in 11''and 81_/ 2''

widths and is packaged 9 four foot pieces per box.

When performance counts – count on

X-5

. FromCOR-A-VENT– continuing our tradition as –

„The Leader In Innovative Rooftop Ventilation®_{‰ .}

Like our V-300 vent line, X-5 comes in convenient 4' sections, cuts easily with a utility knife and is power nailable2

. Packed 9 4' pcs. to a carton, with 4 EC-400 end caps, it’s easy to handle going up the ladder and on the roof.

X-5is covered under U.S. patents 6,213,868; 5,921,863; 5,704,834; 5,542,882 & Des. 465,839. Other patents pending.

1_{Testing completed, pending Dade County approval.}

2_{Use a minimum 1}₃_/₄_{" roofing nail. Nail tip must penetrate sheathing.}

Installer to determine proper nail length to use.

Specify COR-A-VENT

®

Enhanced X-5 for your next project!

Versatile, use on a wide variety of applications!

ROOF to WALL STANDING SEAM METAL FLAT TILE CEDAR SHAKE

COR-A-VENTridge vents must be installed with an equal or greater amount of soffit or intake ventilation to achieve optimal results. For more information on balanced ventilation, visit theCOR-A-VENTwebsite: www.cor-a-vent.com.

COR-A-VENT X-5 (1_/2pc) EXHAUST AIR WALL CLOSED OPEN AIR FLOW A METAL FLASHING AWF (ACTIVE WEATHER FOIL) 13/4" MIN. OP'G. LOW PROFILE CAP X-5 (11") CLOSED OPEN 4" FLASHING DETAIL A AIR FLOW A EXHAUST AIR _AWF (ACTIVE WEATHER FOIL) EXHAUST AIR AIR FLOW 2" MIN. OP'G. CLOSED OPEN X-5 (81_/₂_") AIR FLOW 13_/ 4" MIN. OP'G. AWF (ACTIVE WEATHER FOIL) CLOSED OPEN EXHAUST AIR X-5 (81_/₂_")

X-5 11” &

_NEW

8

1

_/

₂

_”

(14)

(15)

1. 13.5 Square Inches of Net Free Vent Area

2. Available in 3 Widths, 11", 81_/₂_{" & 7"}

3. Power Nailable

4. Easy to Apply 4 or 20 Foot Sections 5. Perfect on Hip Roofs & Cathedral Ceilings 6. Available with Enhanced Snow

Screen (V-300E & FAV-20E 11" & 81_/₂_")

7. Works on Steep Pitch Roofs1

8. Low 5_/₈_{" Profile}

Freedom…

in architectural design calls for flexibility and COR-A-VENT’s V-300 and Fold-A-Vent (FAV-20) families of ridge vents deliver the unique flexibility to adapt to just about any roof design – whether on new construction or when re-roofing. V-300 & FAV-20 are low profile (5_/₈_{" high) and recommended for hard to ventilate roofs,}

such as cathedral ceiling and hip roofs. Both are available in 11", 81_/₂_{" and 7" widths}

and work great with 3-tab or architectural shingles as well as cedar shake, slate, flat tile and metal roofs. Your ridge line will look sharp with V-300 or FAV-20.

Protection…

is what COR-A-VENT offers with our enhanced snow screen (V-300E & FAV-20E) to keep out wind-driven precipitation. The highly breathable filter will allow hot, moist air out, but won’t let weather in.

1_{3/12 to 16/12 pitch roofs – 5/12 minimum on hip applications.}

2 1/2" A B A 2 1/2" 5/8" 5 1/2" 11" 5 1/2" 5/8" 3 1/2" 7" 3 1/2" A B A 2" 2" * A=5/16" _* B=3/16" 5/8" 1 7/8" A B A 4 1/4" 8 1/2" 4 1/4" 1 7/8" V-300 11" & FAV-20 11" V-300 7" & FAV-20 7"

Enhanced products measure the same dimensions as standard products.

V-300 81_/₂_{" & FAV-20 8}1_/₂_"

9¬6WLFN3URGXFWV

(regular & enhanced)

V-300 11" V-300E 11" V-300 81_/₂_" _{V-300E 8}1_/₂_"

V-300 7"

)$9¬%XQGOH

(regular & enhanced)

FAV-20 11" FAV-20E 11" FAV-20 81_/₂_" _{FAV-20E 8}1_/₂_"

FAV-20 7"

(16)

Adaptability…

is what V-300 & FAV-20 offer in any hip design for a clean, uncluttered appearance. They are ideal for steep pitch and short ridge length hip roofs and can be extended all the way down the hip to the gutter for a smooth, unbroken roofline. V-300 7" or FAV-20 7" are sized for use with RIDGLASS™ and Z®_{Ridge* high profile hip and}

ridge caps. Call our technical department for help with hip installations or unique applications.

Reliability…

is what you get with V-300 & FAV-20. Our 4-ply design delivers 13.5 sq. inches of Net Free Ventilation Area (NFVA) and the dimensionally-stable, profile extruded polypropylene material is impact resistant and self-cleaning, but still cuts easily with a utility knife. Installation is a breeze. V-300 & FAV-20 are power nailable and go on fast and straight – they won’t compress or hump like other low profile products.

Fold-A-Vent…

is the perfect 20' solution. It is formed into 5 – 4' sections. The folds “relax” as the sections are extended, so the vent goes on flat and smooth. While nailing the first section, our exclusive

“Yellow Starter Band”keeps the remaining 4 sections together. Install with your power nailer and standard 11_/₂_{" coil nails. The unique routed}

center slot allows you to center the vent on the ridge by sighting down it. No need to snap chalk lines. The flexible center hinge allows easy alignment on roofs up to 16/12 pitch.

Unlike “rolled products”, the FAV-20 bundle stays put on the ridge while you install it – you won’t end up chasing it down the roof or picking

it up off the ground. Corrugated rolled vents look nice in the package, but wait until you try to unroll them! They have a

built-in curl. That’s because the vent is rolled into a package while the plastic is still warm. Roll it out and

it wants to come right back. Installation is tougher and you’re left with a series of humps to flatten out.

Fold-A-Vent

20'

Fold-A-Vent…fast and easy “one-man” installation. Performance for the life of your roof.

*Z®_{Ridge is a registered trademark of Elk Corporation of Dallas, an ElkCorp company.}

(17)

COR-A-VENT®_{has promoted and taught}_{balanced ventilation}_{from the day we started. It’s a concept all vent manufacturers}

readily endorse. Unfortunately, that information doesn’t always end up in the hands of the person designing the building or installing the vents. Balanced venting helps ensure the performance

you expect from ridge venting – uniform, increased airflow through the roof cavity without weather infiltration.

Balanced Venting:An equal or greater amount of vent opening

(sq. in. net free vent area/NFVA) in the soffit (intake) than at the ridge. For example, our V-300 & FAV-20 products have 13.5 sq. in. NFVA per lineal foot. To balance this, you need 2 soffit/eave/intake vents of at least 6.75 sq. in. per lineal foot.

Balanced Venting: Continuous soffit vents are recommended,

especially for venting cathedral ceilings. Wherever there is ridge vent above, there should be soffit/eave/intake vents on the structure below.

Also, COR-A-VENT strongly recommendsusing one of our V-300 or FAV-20 products (available in 11", 81_/₂_{" or 7"}

widths) on cathedral ceiling and hip roof applications. V-300 & FAV-20 deliver 13.5 sq. in. net free vent area. Because the volume of space to be vented in cathedrals is smaller, a lower profile (5_/₈_{") vent is needed to further reduce}

the chance for infiltration. When installing a ridge vent system, all other vent openings (except soffits) must be closed off.

USE BALANCED AMOUNTS OF SOFFIT VENT

TO RIDGE VENT

Balanced ventilation –The right proportion of venting.

COR-A-VENT®_{products meet or exceed all nationally recognized building codes for ventilation. COR-A-VENT products are}

covered under the following patents: 5,054,254; 5,339,582; 5,439,417 5,542,882; 5,603,657; 5,704,834; 5,921,863; 6,039,646; 6,213,868; 6,558,251B2; 6,589,113; D465,839 — additional patents pending.

For the best appearance, install V-300 & FAV-20 products

continuously the entire length of the ridge.

Figuring Your Ventilation Needs:

V-300 & FAV-20 have 13.5 sq. in. NFVA/lineal foot.

V-300: Square footage of building footprint X .48 = Lineal Feet V-300 or FAV-20 13.5 or FAV-20 needed

Example: 24' x 70' = 1,680 Sq.F. 1,680 x .48 = 806

806 ÷ 13.5 = 60 L.F. V-300 or FAV-20 needed

The above formulas will give the amount of COR-A-VENT ridge vent needed for a 1/150 vent ratio, provided an equal or greater amount of soffit venting is used. For a 1/300 ratio, (building code minimum) use half the amount of ridge vent.

Note: Code interpretation may vary. Consult your local building dept.

Note: Should you need any assistance in designing your ventilation system, fax or mail a sketch and information to our technical services department. COR-A-VENT will respond with recommendations for your particular building design.

1.Measure a 3" slot, 11_/₂_{" each side of ridge}

centerline. This allows for a 2x ridge board or smaller. Snap chalk lines the entire length of the ridge. Cut slot with a circular saw and clean out debris. Set saw depth so as not to cut roof rafters. Stop the slot 12" short of any ridge end, intersecting ridge or obstruction (such as a chimney).

2.Cut the 3 clear bands leaving the colored band to hold all but the starter section together. Turn the vent bundle upside down to expose the underneath side of the starter section end. Follow steps 3 – 4 to create its own Folded End Cap.

6.Continue to tack nail both sides of entire length of vent. Use nail pattern shown in step 4. Center shingle cap on vent and nail. Continue nailing until all vent is covered with ridge caps. Be careful not to overdrive nail. Nail head should be flush with top of shingle, without indenting it. Pre-forming caps in cold weather helps avoid cracking.

5.Continue applying FAV 20 by walking out remaining sections. Pull firmly to fully extend, center vent on ridge and nail other end down. Make sure vent matches roof pitch before nailing both sides in place. If necessary add FAV 20 until entire ridge is covered. Use a utility knife to cut last section to length. Fold end to finish (steps 3 – 4). Caulk between bottom edge of vent and roof.

B A

3.Use a utility knife to cut out a “V”shaped notch from the centerline approximately 13_/₄_{" in}

from edge and remove loose material (A). Cut through the bottom 3 layers of the vent as pictured (B) (located approx. 13_/₄_{" from &}

parallel to the end). Remove loose pieces. Be careful not to cut into top layer.

4.Fold flap under and secure with a 2" roofing nail. This allows the nail to penetrate an extra layer of vent material (inset). Align starter end

1_/₂_{" in from edge of roof, and centered on ridge.}

Be sure to caulk between bottom edge of vent and roof. Nail the starter section at points A, B & C, 2" up from edge.

C A

B

If Architectural Shingles, Shakes or roofing with an irregular surface is used, apply a bead of caulk to roof deck before installing vent. This will seal any gaps that could allow weather penetration under the vent.

P.O.Box 428 • Mishawaka, IN 46546-0428 Phone: (800) 837-8368 • Fax: (800) 645-6162

[email protected] • www.cor-a-vent.com

Our website contains a complete listing of application details in .PDF and .DWG formats for viewing or downloading, or

call our technical staff

at 800-837-8368.

(18)

• NEW! V-400E – with enhanced snow screen • V-400E – certified 17 sq. inches NFVA* per foot • Exceeds all national building codes for ventilation • Easy to handle 4' pieces – 12 pieces (48 l.f.) per carton • 21_/₂_{'' roofing nails & 4 end caps included (with V-400E)}

• Can be applied on hip roofs (not S-400)

• More flexibility on steep pitch roofs – now works on 16/12 pitch

• Solid base provides a weather-tight seal under vent • Cuts with a utility knife – no waste

• “Live” flexible hinge – makes it easy to match roof pitch • Leaves a well defined ridge – “no hump or domed

shaped” peak

• Won’t crack or shatter in cold weather application • No baffles to clog with leaves or pine needles • Proven by 30+ years of on the roof performance • Lifetime warranty

• S-400 – certified 10 sq. inches NFVA per foot

V-400E

Protect Your Roofing Investment, Install...

COR-A-VENT

®

Ridge &Soffit Vent...

On NEW or REROOF Installations.

S-400

(19)

S-400 STRIP VENT AIR FLOW INSULATION AIR VENTILATION CHUTE TRUSS Engineered Truss INSULATION S-400 STRIP VENT AIR VENTILATION CHUTE AIR FLO W RAFTER S-400 STRIP VENT AIR VENTILATION CHUTE AIR FLO W RAFTER INSULATION

Wood Overhang (Typical) Zero Overhang (Salt Box/Cape Cod)

2 x 6 R OOF R AFTER RIDGE CAP V-400E RIDGE VENT ORIGINAL SHEATHING 2 x 2 INS ULATION RAILING

2 x 2 FIRING STRIPS @ O.C. - RAFTERS S-400 STRIP VENT AIR AIR FLOW AIR FLO W AIR FLO W RIGID FO AM IN SULA TION CONTINUOUS WATERPROOFING MEMBRANE 2" AIR-WAY

Cold Roof Application

Simple Solutions for all Your Eave Venting Details. The science of a good ridge and soffit vent system depends upon the equalization or “balance” of its two components – the soffit/eave (intake) air and the ridge (exhaust) air. This principle of good venting practice works well with most traditional roof designs.

However, many contemporary house and roof designs are limited in how well they can be naturally ventilated. This is a result of restriction in the amount of, or placement of critical intake ventilation. In the interest of modern architecture and good ventilation practices, COR-A-VENT has developed various unique soffit venting applications using our S-400 Strip Vent.

All ridge vents, work best with soffit/eave (intake) vents. For the top performance, place the intake vents low on the structure, typically at the overhangs.

With new construction or when re-roofing, all other attic exhaust vents such as gable-end, roof, or turbine vents should either be blocked off or removed.

The stack effect (rising warmer air) is enhanced and thus maximum updraft (ventilation) is obtained when no other opening(s) can distort the air pattern between the intake and the exhaust vents.

COR-A-VENT

®

S-400 Soffit/Eave Vents

•

There really are as many ways to install S-400 Strip Vent as

there are eave construction details

•

1" x 11_/2" x 4' cross section gives you maximum soffit/eave

ventilation in a minimum space

•

10 sq. in. NFVA* per

lineal foot

•

S-400 fits narrow spaces

where other vents can’t, like zero overhangs

•

The durable 4' Polypropylene (PP) sections are available in

black or white, 24 – 4' pieces ( 96 l.f.) per carton

•

Self-cleaning – vertical flute orientation doesn’t show the dirt

•

Crush resistant so you can install with a power nail gun

•

Pair up S-400 with any of COR-A-VENT’S ridge vent products

for an unbeatable system

•

Can be installed in multiple layers for additional ventilation

1" 1 1/2"

(END VIEW ) (EDGE VIEW )

4'-0"

V-400E: Square footage of building footprint X .48 = Lineal Feet V-400Eneeded

17

Example: 25' x 50' = 1250 Sq.F.

1250 x .48 = 600

600 ÷ 17 = 35 L.F. V-400E needed

The above formulas will give the amount of V-400E ridge vent needed for a 1/150 vent ratio, provided an equal or greater amount of soffit venting is used. For a 1/300 ratio, (building code minimum) use half the amount of ridge vent.

Note: Code interpretations may vary. Consult your local building dept.

For the best appearance and performance install COR-A-VENT ridge and soffit vents continuously at the ridge and in the soffits.

Note:Should you need any assistance in designing your ventilation system, fax or mail a sketch and information to our technical services department. COR-A-VENT will respond with recommendations for your particular building design.

Maintaining an unrestricted air passageway between the soffit and ridge is crucial to the performance of the vent system, and must not be blocked or restricted. COR-A-VENT recommends a minimum 2" air space between the roof sheathing and vent chute or insulation.

COR-A-VENT, Inc.

P.O. Box 428 • Mishawaka, IN 46546-0428 Phone: (800) 837-8368 • Fax: (800) 645-6162 [email protected] • www.cor-a-vent.com AIR FLOW RAFTER INSULATION BLOCKING S-400 STRIP VENT AIR FLO W Shed Roof *Net Free Vent Area

(20)

(21)

(22)

(23)

(24)

(25)

(26)

(27)

(28)

(29)

(30)

(31)

(32)

COR-A-VENT products are low profile,from 5/8'' to 1'' high, and virtually disappear beneath the ridge cap. Made of thermally stable, crush resistant polypropylene (PP) sheets*, our vents don’t compress over time, so roofing screw holes don’t elongate and leak. COR-A-VENTis easy to install, with a minimum of waste. A wide, solid base on all

our products insures a good seal under the vent. The vent’s cross section lets maximum air flow through, while our enhanced vents (V-600TE & V-400E) keep

fine powdered snow out. COR-A-VENT’sdesign also works with any closure and cap system.

We’re the leading manufacturer of attractive, tested vent applications for metal roofing. Offer your customer the low profile beauty and performance of continuous ridge venting, on whatever style and color roof they choose. With the growing acceptance of metal for light commercial, residential and institutional roofs, it just makes sense to top off the job with a ventilation system that looks as good as the rest of the roof.

Visit www.cor-a-vent.comand see all the ridge andeave venting details we offer for metal roofing. Our versatility and breadth of applications earns us the title of . . .

The Leader in Innovative Rooftop Ventilation!®

•

The great look of an uncluttered roofline as well as the benefit of continuous ventilation – removing heat and preventing condensation in your roof cavity.

•

The efficiency of a static ventilation system that is self-cleaning and maintenance-free.

•

Plenty of options for whatever style of metal roofing you choose – from standing seam to profile panel to metal shakes.

•

Light weight, easy to install vent that can be screwed down without crushing.

•

Long lasting, quality products that are guaranteed for the life of your roof.

•

When paired with our Purlin Vent,™ forms a total system for venting both sidewalls and roofs. See Purlin Vent details at: cor-a-vent.com

Protect the beauty of your metal roofing.

Profile –

Wayne Buildings – Cleves, OH

Metal Shake – KBS Metal Roofing – LaPorte, IN

Standing Seam –

All Spec Metal Systems – Holts Summit, MO

Since

1976

(SIDE VIEW )

(33)

Standing Seam.

This is becoming the preferred roofing system for builders of low-rise commercial, industrial

and institutional buildings. More than 50% of these types of structures erected in the past several years have standing seam roofs and more than 1 billion square feet of standing seam metal roofing has been installed. This roof-style is designed to be weather-tight, with a clip-fastened system beneath the steel panels to cut down on roof penetrations. Paired up with COR-A-VENTridge vents, it’s a beautiful roof that will last.

Profile.

Also known as “screw down” roofing, this system is durable, lightweight and relatively inexpensive compared to other

types of metal roofing and is installed over and

fastened directly to the decking underneath. Profile panel is widely used with industrial and agricultural structures like garages and utility buildings, or horse and animal barns.

COR-A-VENTis a perfect match for this

investment – the one on the roof and everything underneath it.

Metal Shake.

With the look of shingle and the durability of metal, this alternative to typical residential roofing has plenty of options.

Choose from metal shakes that resemble cedar wood or tile, or stone-coated products that resemble asphalt

shingles, like the inset photo of stone-coated shingles from COR-A-VENTcustomer Gerard Roofing Technologies.

COR-A-VENTcomes in a variety of widths

to match the cap sizes of today’s popular metal shake roofs.

*Crush test results of 7,653 PSF (#’S per square foot) per RADCO Test Report RAD-2376

Purlin Vent.

•

Use Purlin Vent under the roof and behind the sidewall to vent the total building envelope.

•

Fluted 1'' cross section provides maximum airflow in minimum space.

•

Works as a thermal break between roofing/purlin and siding/girt to reduce heat/cold conduction.

•

Purlin Vent provides a “drain path” for any rain or moisture that penetrates the sidewall.

•

Use with any of COR-A-VENT’s metal ridge and eave vent applications for a complete system (V600-TE shown).*

•

Use with Roof Hugger™ on metal re-roofs to add insulation and ventilation.

•

Made of heat stable, crush resistant polypropylene (PP) sheets.**

•

Doesn’t com-press over time, so roofing

& siding screws holes don’t elongate and leak.

AIR FLOW OLD ROOF NEW ROOF AIR FLOW PURLIN ROOF HUGGER PURLIN VENT FLOW AIR AIR AIR FLOW AIR CLOSURE RIDGE CAP V600-TE V600-TE FLASHING

STEEL FRAMING PURLIN

BLANKET INSULATION GIRTS PURLIN VENT PURLIN VENT PURLIN VENT

METAL ROOF DECK PURLIN VENT FLASHING PURLIN VENT STEEL SIDING AIR AIR AIR (SIDE VIEW) 4' 3" 1" 1" 4' PURLIN™ VENT (1") 10 Sq. In. Net Free Vent per L.F.

(34)

Our website contains a complete listing of application

details in .PDF and .DWG formats for viewing or

downloading, or call our technical staff at 800-837-8368.

COR-A-VENT®_{products meet or exceed all nationally recognized building codes for ventilation. COR-A-VENT products are covered under the following patents:}

5,054,254; 5,339,582; 5,439,417 5,542,882; 5,603,657; 5,704,834; 5,921,863; 6,039,646; 6,213,868; 6,558,251B2; 6,589,113; D465,839 — additional patents pending.

Metallic Products Corporation is a leading manufacturer of OEM and aftermarket roof vents for metal applications. They offer a made-to-order 10-ft. finished ridge vent assembly, and COR-A-VENT is the heart of this product. Steel parts match the roof type

and color finish, and all paint types and colors are available, including Kynar®_.

For more info. call them at 800-356-7746 or visit www.mpvent.com

Profile Metal

Applications with

V-600T & V-600TE

•

20 sq. in. NFVA* – 1” high

•

24 – 4’ pcs. per carton

•

Accommodates wide

ridge caps

•

Enhanced Snow Screen™ (V-600TE) for added weather protection

•

3/12 – 16/12 pitch applications

(See V-600TE illustration on cover)

TRUSS SHEATHING PROFILE PANEL METAL ROOFING METAL ROOF CAP 1 3/4" MIN. OP'G 7/8" MIN. OP'G

HEAVY FELT PAPER OR WATERPROOF MEMBRANE V-600T AIR FLOW METAL FLASHING FOAM CLOSURE FELT PAPER EXHAUST AIR METAL ROOF CAP V-600T AIR FLOW METAL C-CLOSURE CHANNEL EXHAUST AIR

Roof to Wall

Applications with

V-600TE

•

10 sq. in. NFVA* – 1'' high

•

24 – 4' pcs. per carton –

vents 96 l.f. of ridge in this application

•

Enhanced Snow Screen™ for added weather protection

•

3/12 – 16/12 pitch applications WALL FLASHING RAFTER OR TRUSS 1" SLOT

AIR FLOW STANDING SEAM METAL ROOFING CAULKING INSULATION ENHANCED SNOW SCREEN METAL SIDING 7/8" MIN. OP'G EXHAUST AIR V-600TE

Metal Shingle

Applications with

V-600TE

•

24 – 4' pcs. per carton

•

2 piece installation fits under

a range of ridge caps widths

•

Enhanced Snow Screen™

for added weather protection

•

3/12 – 16/12 pitch

applications CAULKING

11_/2''

HOT AIR FLOW

WATERPROOF MEMBRANE OR EQUIVALENT EXHAUST AIR 30# FELT OR EQUIVALENT SHEATHING METAL SHINGLE V-600TE

METAL RIDGE CAP

TRUSS

MINIMUM SLOPE

Standing Seam Metal

Applications with

V-600 or V-400E

V-600

•

Available in 11'' & 81_/₂_{'' widths}

•

Maximum airflow

•

3/12 – 16/12 pitch applications V-400E

•

Available in 11'' & 81_{/2'' widths}

•

Enhanced Snow Screen™ for

added weather protection

•

3/12 – 16/12 pitch applications (See V-400E illustration on cover)

The versatility of COR-A-VENT

®

_–

choose from these great ridge

vents for the product that matches your needs, in any application.

Wayne Buildings – Cleves, OH

*Net Free Vent Area

STANDING SEAM METAL ROOF FASTENERS TYP.

V-600 LOW PROFILE CAP

1 3/4" MIN. OP'G. A 7/8" MIN._OP'G HOT AIR EXHAUST AIR 31/2" FLASHING DETAIL A

(35)

(36)

(37)

(38)

(39)

(40)

(41)

(42)

(43)

(44)

(45)

(46)

SP

A

CER FOR MET

AL R

OOFING

O

VER ASPHAL

(47)

Raft-A-Vent

™

_{is available in}

either white or black.

You can power-nail or

screw down Raft-A-Vent and

pre-attach to the blocking for

fast installation!

A 22

1 _/

₂

_{” Eave Vent Designed to Fit Between the Rafters}

Introducing COR-A-VENT’s Latest Soffit Vent Innovation—

Providing soffit ventilation for open-rafter construction has long been a headache for many builders. The options have been few, consisting mainly of a couple of screened-over holes in the blocking or a few metal grates every two or three rafter bays that don’t provide nearly enough ventilation and, quite honestly, don’t look very good.

But COR-A-VENT®_{has the answer} with its newest product, Raft-A-Vent™, a 22.5" long vent strip designed to fit between the rafters, on top of the blocking.Raft-A-Ventis the ideal product for this situation.

At only one inch thick, Raft-A-Vent

will virtually disappear under the eave, but still provides 18.75" of Net Free Vent Area per piece and is designed to run continuously in every rafter bay* to provide the superior intake ventilation you need for a balanced vent system.

Good ventilation helps reduce moisture buildup and the possibility of mold growth.

For an unmatched system, pair Raft-A-Vent

up with any one of COR-A-VENT’sridge vents, like V-300 81_/₂_"_or_FAV-20₈1_/₂_"_,

both UL®_{Class A f}_i_{re rated products}_. *See the back of this flyer or go to cor-a-vent.comfor

more information about using COR-A-VENTridge and soffit ventilation products in areas that require more stringent design of roof diaphragms in accordance with IBC requirements for wind and/or earthquake loading.

(48)

(49)

S-400 Strip Vent: The original, continuous soffit venting solution is still the best choice for venting

overhangsand eaves– and oncearchitects find

outabout it, they spec it on every job!

With 10 sq. inchesNFVA per foot,

S-400 provides superior intake

ventilation for any detail –

from zero overhang to

(50)

The science of a good ridge and soffit vent system depends upon the equalization or “balance” of its two components – the soffit/eave (intake) air and the ridge (exhaust) air. This principle of good venting practice works well with most traditional roof designs.

However, many contemporary house and roof designs are limited in how well they can be naturally ventilated. This is a result of restriction in the amount of, or placement of critical intake ventilation. In the interest of modern architecture and good ventilation practices, COR-A-VENT has developed various unique soffit venting applications using our S-400 Strip Vent.

All ridge vents, work best with soffit/eave (intake) vents. For top performance, place the intake vents low on the structure, typically at the overhangs.

With new construction or when re-roofing, all other attic exhaust vents such as gable-end, roof, or turbine vents should either be blocked off or removed.

The stack effect (rising warmer air) is enhanced and thus maximum updraft (ventilation) is obtained when no other opening(s) can distort the air pattern between the intake and the exhaust vents.

AIR AIR FLOW INSULATION TRUSS VENTILATION CHUTE S-400 STRIP VENT S-400 STRIP VENT VENTILATION CHUTE AIRFL OW RAFT ER INSULATION

AIR Zero Overhang

(Salt Box/Cape Cod)

Engineered Truss

Simple Solutions for all Your Eave Venting Details

INSULATION RAFTER AIRFLOW VENTILA TION CHUTE ROOFING TILE S-400 STRIP VENT STUCCO

AIR Stucco Soffit

Wood Overhang

(51)

PS-400 Strip Vent 10 SQ. IN. NFVA PER LN. FT.

TOP VIEW

1" 3/4''

4' LENGTHS

SIDE VIEW PS-400SOFFIT VENT 1 x 6 SOFFIT BOARD BLOCKING DRIP EDGE AIR FLOW TRUSS FRIEZE BOARD AIR FLOW

Another new soffit product from COR-A-VENT is thePS-400 Strip Vent, a3/4" wide continuous strip that’s perfect for 1x soffit panels. Like the originalStrip Vent, PS-400is available in either black or white and provides 10 sq. in. Net Free Vent Area per lineal foot. Pre-attachPS-400to the 1x for quick installation.

BIRD BLOCK W/VENT RAFTER JOIST TOP PLATE ROOFING PAPER RS-400 RAFT-A-VENT PLYWOOD SHEATHING RS-400 Raft-A-Vent

NOTE: FASCIA BOARD w/ S-400 IS APPLIED AS AN ASSEMBLY AFTER BRICK WALL IS PUT UP TO MAKE FOR FASTER APPLICATION NAILER BOARD ASSEMBLY RAFTER SOFFIT BRICK WALL SHEATHING ROOFING FASCIA SOFFIT AIR FLO W RAFTER FASCIA

w/S-400 _{FILL ANY GAP BETWEEN}

BRICK AND S-400 WITH SILICONE CAULK BRICK WALL NAILER BOARD ASSEMBLY WALL AIR FLOW

Special application of S-400

made into an assembly –

COR-A-VENT S-400TAN Strip Vent w/Overhang Soffit Application

•There really are as many ways to install S-400 Strip Vent as there are eave construction details •1" x 11_/

2" x 4' cross section gives you maximum soffit/eave ventilation in a minimum space

•10 sq. in. NFVA per lineal foot

•S-400 fits narrow spaces where other vents can’t, like zero overhangs •The durable 4' PP sections are available in black, white or tan •Self-cleaning – vertical flute orientation doesn’t show the dirt •Crush resistant so you can install with a power nail gun

•Pair up S-400 with any of COR-A-VENT’S ridge vent products for an unbeatable system •Can be installed in multiple layers for additional ventilation

1" 11_/₂_"

(END VIEW ) (EDGE VIEW )

(52)

V-400E:Square footage of building footprint X.48 = Lineal FeetV-400Eneeded

17

V-300:Square footage of building footprint X.48 = Lineal FeetV-300needed

13.5

Example: 25' x 50' = 1250 Sq.F.

1250 x .48 = 600

600 ÷ 17 = 35 L.F. V-400E needed

The above formulas will give the amount of COR-A-VENT ridge vent needed for a 1/150 vent ratio, provided an equal or greater amount of soffit venting is used. For a 1/300 ratio, (building code minimum) use half the amount of ridge vent.

Note: Code interpretation may vary. Consult your local building dept.

For the best appearance and performance install COR-A-VENT ridge and soffit vents

continuously at the ridge and in the soffits.

COR-A-VENT products meet or exceed all nationally recognized building codes for ventilation. COR-A-VENT products are covered under the following patents: 5,054,254; 5,328,407; 5,339,582; 5,439,417; 5,542,882; 5,603,657; 5,704,834; 5,803,805; 5,839,059; 5,921,863; 6,039,646; 6,213,868; 6,558,251B2; 6,589,113; 6,598,356; D465,839 – additional patents pending.

Note:Should you need any assistance in designing your ventilation system, fax or mail a sketch and

information to our technical services department. COR-A-VENT will respond with recommendations for your particular building design.

COR-A-VENT®_{has promoted and taught}_{balanced ventilation}_{from the day we}

started. It’s a concept all vent manufactures readily endorse. Unfortunately, that information doesn’t always end up in the hands of the person designing the building or installing the vents. Balanced venting helps insure the performance you expect from ridge venting – uniform, increased airflow through the roof cavity without weather infiltration.

Balanced venting:An equal orgreater amount of vent opening(sq. in. net free vent area/NFVA) in the soffit (intake) than at the ridge. For example, our V-300 products have 13.5 sq. in NFVA per lineal foot. To balance this, you need 2 soffit/eave/intake vents of at least 6.75 sq. in. per lineal foot (1/2 of 13.5 in each overhang).

Balanced venting:

Continuous soffit vents are recommended, especially for venting cathedral ceilings. Wherever there is ridge

vent above, there should be soffit/eave/intake vents on the structure below. Also, COR-A-VENTstrongly recommendsusing of one of our V-300 products (available in 11, 81_/₂_{or 7" widths) on cathedral ceiling and hip roof applications.}

V-300 delivers 13.5 sq. in. net free vent area. The volume of space to be vented in cathedrals is smaller. Therefore a lower profile (5/8") vent is called for to further reduce the chance for infiltration.When installing a ridge vent system,allother vent openings (except soffits) must be closed off.

USE BALANCED AMOUNTS OF SOFFIT VENT TO RIDGE VENT

Maintaining an unrestricted air passageway between the soffit and ridge is crucial to the performance of the vent system, and must not be blocked or restricted. COR-A-VENT recommends a minimum 2" air space between the roof sheathing and vent chute or insulation

Typical Vent Chute Applications

Typical

Gable

Cathedral

Ceiling

Knee Wall

Balanced ventilation – The right proportion of venting.

① ➁ ➂ ➄ ➃ ➃

1. SKYLIGHTS 2. DORMERS

3. INTERSECTINGBUILDING COMPONENTS 4. VALLEYS 5. CHIMNEYS

INLET(BALANCING)VENTS RIDGE VENT

UNBALANCED VENTILATIONAREAS

(53)

(54)

(55)

(56)

(57)

(58)

(59)

(60)
