Intelligent, customized, integrated solutions
CNS Solutions by Westell
Infrastructure equipment and services
designed to protect and support your critical
network needs
Building a communications network that can sustain harsh environmental conditions while providing the required reliability can be a challenge, especially while trying to contain costs. Whether it’s an industrial, utility, transportation or telecommunications network, the connections between devices must effectively, efficiently, and safely carry and process signals throughout the infrastructure (cables, racks, enclosures, power distribution, etc.) while providing remote management capabilities.
Enclosures are moving toward being more integrated and intelligent, whether in Broadband for consumers, Cell-site Backhaul, Business Class Ethernet,DAS, small cell, Wi-Fi, wireless or wireline networks. Westell provides a comprehensive range of Communications Network Solutions to connect nearly any outdoor building or facility.
Westell’s Communications Network Solutions
• Cabinets and Enclosures
• Power Distribution
• Network Connectivity
Westell offers a large line of secure, weather-tight outdoor cabinets, designed to house and protect a wide range of electronic equipment. Available in multiple sizes, Westell offers options for actively cooled and passively cooled cabinets.
Features and Benefits
• Broad line of outdoor cabinets and enclosures
• Passive and active cooled models to support wide range of applications
• Designed for harsh outdoor environments
• Wide selection of Telecordia GR-487 compliant cabinets
• Protection against corrosion
• Wind driven rain resistant
• Temperature hardened
• Impact resistant
• Modular in design with add-on battery and demarcation options
• Westell Boxer™ family outdoor cabinets are sized in increments of 5RU —> 30RU
Cabinets and Enclosures
Westell’s Cabinet and Enclosures product
offerings include:
•
Outdoor Cabinets
Outdoor Cabinets
Westell has been providing cabinets and enclosures for outdoor applications for more than 20 years. Built to strict compliance standards, including GR-487 and NEMA-4, these secure, weather-tight cabinets will withstand harsh climatic conditions such as rain, snow, sleet, high winds, ice and sand storms.
• Westell Boxer® Cabinets: The Westell Boxer family of Outdoor Cabinets are actively cooled, lightweight, GR-487 and NEMA-4 compliant cabinets available in sizes from 5RU to 30RU.
• CP Series Outdoor Cabinets: Westell’s CP Series of passively cooled outdoor cabinets are secure, weather-tight, fully tested empty enclosures that include a stainless steel mesh back plate to provide universal mounting locations for a wide variety of electronic equipment and networking solutions.
• Power Cabinet: Westell’s SmartCom™ ES Enhanced Power Cabinet is a fully integrated backhaul solution, specifically designed for the Utility Smart Grid market.
Intelligent Enclosures
Service providers, tower operators, governments, and other organizations need to ensure the right enclosures and supporting devices are used to protect networking equipment, especially when sites are in difficult to reach or remote locations. Westell provides a comprehensive range of outdoor enclosures that can be utilized in virtually any installation.
The enclosures are designed to NEMA Type 3R, NEMA Type 4, and Telcordia GR-487 guidelines to protect equipment from harsh environmental conditions. Because Westell enclosures have a similar yet flexible design layout, installation is fast and configuration changes can be easily made when a network demands change. This ensures equipment can be operational quickly, and no additional technician training is required. By adding an intelligent site device Remote suite of products that fits into nearly any Westell roadside, tower, or cell site enclosure, the “intelligent enclosure” can then provide critical data, including temperature, humidity, power quality, and more. Our intelligent enclosures also monitor alarms and report real-time data on:
• Enclosure door intrusion
• AC power failure
• Battery status (discharge/recharge, voltage, etc.)
• Enclosure inside temperature
• Fan fuse
• Rectifier fault
• Generator
• Video cameras
Westell offers an extensive line of fuse panels for secondary power distribution and breaker panels for primary protection applications. Built in the USA, Westell leads the industry in flexibility, price competitiveness, and product availability.
Features and Benefits
• High quality, comprehensive selection of power distribution, protection, and alarm panel products
• Multiple fusing or breaker options for AC or DC applications
• Lead times measured in days...not months
• Installer friendly designs, larger termination and integrated Fuse Alarm connections and LEDs
• Universal 19” or 23” mount
• Front access and rear access panels
• Wide range of products with extended temperature range
• Competitive prices
• UL safety and NEBS Level 3 certifications for US and Canada
Fuse Panels
Westell offers a comprehensive selection of fuse panels for secondary power distribution. With multiple fusing options and installer friendly designs, the vast majority of Westell’s fuse panels meet both NEBS Level 3 and UL certification. Westell’s fuse panel line includes: GMT Fuse
Power Distribution
Westell’s Power Distribution product
offerings include:
•
Fuse Panels
•
Breaker Panels
•
Ancillary Power Distribution Products
Panels intended for primary protection applications. With single and dual bus configurations, field installed breaker counts up to 10 per bus, alarm contacts, and individual breaker capacities up to 100A, Westell has the panel for your particular requirements. Westell’s breaker panels line includes both AC and DC options.
Westell offers a complete line of network connectivity products for terminations and hand-offs. Westell fiber termination assemblies provide efficient all-in-one fiber terminations, connections and slack storage. Westell’s VirtualEdge® line of products includes secure access enclosures for Ethernet hand-off, as well as panels that provide a standard interface for a variety of Ethernet/Gigabit and DS3 services.
Features and Benefits
• VirtualEdge® products provide connectivity to hand off a variety of services
• Fiber-based GigE
• Copper-based Ethernet
• VirtualEdge® products provides separate network and customer access
• Fiber termination drawer is a slide-out fiber management drawer with removable splice trays and front or rear fiber cable entry ports on left and right sides
• SwingRack is the perfect solution to install rack mounted equipment in crowded equipment closets
Fiber Termination Drawers
Westell fiber termination assemblies provide efficient all-in-one fiber terminations, connections and slack storage.
Connectivity Enclosures
Westell’s VirtualEdge Enclosure is a secure access Ethernet hand-off solution that offers flexibility to handle copper, coax, and fiber connectivity.
Network Connectivity
Westell’s Network Connectivity
product offerings include:
•
Fiber Termination Drawers
•
Connectivity Enclosures
•
Connectivity Panels
Connectivity Panels
Westell’s VirtualEdge® line of Ethernet connectivity panels are used to provide a standard interface for a variety of Ethernet/Gigabit and DS3 services that can be delivered to end-users.
We offer custom integration solutions for cabinet-based installations ranging from small assemblies to large, systems-based outdoor cabinets. Our fully integrated, vendor neutral cabinet solutions are not only optimized for your broadband build-out and circuit turn-up but are designed to meet individual customer requirements. By handling all system integration details, including design, testing, equipment orders and procurement, Westell minimizes and controls your project cost while accelerating time-to-market.
Features and Benefits
• Minimize and control project costs
• Simple single SKU ordering, no need to issue multiple PO to many vendors
• Accelerate time-to-market
• Ensure consistent quality across all network installations
• Improve return on investment
• Simplify the integration process
• Built to individual requirements
• Comprehensive set of documentation for easy installation practices
• Ensure continuity and improve overall Quality
• Simplifies time to install
• Simplifies any trouble shooting, well documented and cookie cutter design and integration
Custom Systems Integration
Westell’s Systems Integration
product offerings include:
•
Custom Solutions
•
Order and Procurement Management
•
System Design and Testing
Applications
• Cellular Backhaul• Business Class “Metro Ethernet”
• Broadband for Consumers
• WiFi and DAS
• Small Cell
• Smart Grid
• Line Power
• Meter Reading
Equipment Options
• Multiplexers• iPDSLAMS
• Radios
• Business Class Ethernet
• Protection and Power Plants
