F1. Genetic Engineering

(1)

(2)

Genetic Engineering

• _{Genes from one organism can be transferred into}

another organism – this is called genetic engineering.

• _{Species that have genes incorporated from other}

(3)

(4)

Examples of GM organisms (GMOs)

• _{Crop plants that have had pest resistance genes added}

• _{Crop plants that have had drought resistance genes}

added

• _{Fish cells that have had a gene called luciferase}

transferred into them makes them glow in the dark.

• _{Christmas trees that have had luciferase transferred into}

(5)

(6)

The Process of Genetic Modification

• _The_{restriction enzymes}_{are used to cut out the}

desired gene out of the DNA.

• _{The desired gene is then inserted into a loop of DNA}

known as a plasmid.

• _{To ensure that desired gene is incorporated into the}

(7)

• _{The plasmid is then used to transfer the desired gene}

into a host cell.

• _{This host cell can now produce lots of the desired}

gene. For example, bacterial cells that have had the insulin gene transferred into them will produce lots of insulin.

• _{This same process can be used to produce drugs and}

other hormones.

(8)

(9)

Vectors

• _{A vector is something which is able to carry a gene}

from one place to another place

• _{Plasmids are vectors as they carry the desired gene}

(10)

Insulin is produced by GM bacteria

(11)

The GM bacteria are grown in a fermenter

(12)

(13)

Fermenters

• _{Industrial fermenters are equipped to make sure that}

large cultures of micro-organisms grow at their maximum rate.

Fermenters require:

• _{An oxygen and glucose source so bacteria can respire}

• _{A stirrer to keep the micro-organisms in suspension and}

nutrient concentration even.

• _{A cooling water-jacket to help keep the temperature at}

the optimum temperature. If the temperature is too high enzyme denature.

(14)

Sterile environment

• _{This is important to prevent contamination of the}

product

• _{Prevent competition from other bacteria for}

(15)

(16)

Advantages of using GM plants in food

production

• _{The world population has topped 7 billion people}

and is predicted to continue to rise. Ensuring an adequate food supply is a major challenge.

1. Pest resistance

• _{Growing GM crops that are resistant to pests this}

means we can use less pesticides. This limits damage to water supplies as less pesticides end up in our

(17)

2. Disease resistance.

• _{There are many viruses, fungi and bacteria that cause}

plant diseases. Plant biologists are working to create plants with genetically-engineered resistance to these diseases

3. Drought tolerance/salinity tolerance.

• _{As the world population grows and more land will}

need to be used for food production. If salty land or land that suffers from little rainfall can be used, this increases the possible areas for food production.

(18)

4. Nutrition

• _{Malnutrition is a common problem in poor countries.}

If rice could be genetically engineered to contain additional vitamins and minerals, nutrient

deficiencies could be alleviated.

(19)

Disadvantages of using GM plants in food

production

• _{Environmental activists, religious organizations,}

scientists and government officials have all raised concerns about GM foods.

• _{It seems that everyone has a strong opinion about}

GM foods! Most concerns about GM foods fall into three categories:

1. Environmental hazards 2. Human health risks

(20)

1. Environmental Hazards

• _{Unintended harm to other organisms}_{. For example,}

a pest resistant type of corn produces a toxin may not only kill pests of corn but other insects as well.

• _Super-Weeds._{If a herbicide resistance gene}

(21)

2. Human Health Risks

• _Allergies._{Many children have developed life-threatening}

allergies to peanuts and other foods. It is possible that introducing a gene into a plant may create an allergic reaction in susceptible people.

• _{e.g. A proposal to incorporate a gene from Brazil nuts into}

soybeans was abandoned because of the fear of causing unexpected allergic reactions

• _{Unknown effects on human health}_{There is a growing}

(22)

3. Ethical Reasons

• _{Some religious groups believe we should not be able}

(23)

Transgenic Organisms

• _{A transgenic organism is one which has a new gene}

inserted in it from another species

• _{E.g. pigs which have been given the human insulin}

gene

• _{Sheep that produce milk with proteins to treat cystic}

fibrosis

• _{Pigs used to grow human organs. These can be used}

(24)

Transgenic pig hearts

• _{Better tissue match}

• _{Less likelihood of rejection from patient} • _{Fewer donors needed}

(25)

Advantages of using transgenic

hearts

• _{They can be used for transplant which means we}

don’t need to have so many donors.

• _{Hearts made by transgenic pigs can be made to be}

the correct tissue type (blood type) so the organ is less likely to be rejected

(26)

Disadvantages of transgenic pigs

• _{Several religious groups would be against the use of}

pigs
