System Center 2012 R2 Configuration Manager Toolkit
System Center 2012 R2 Configuration Manager toolkit was most awaited software and this time toolkit contains fifteen downloadable tools to help you manage and troubleshoot Microsoft System Center 2012 R2 Configuration Manager. It’s not mandatory to install these tools however these tools are very good for troubleshooting issues related to SCCM 2012 R2. The tools are classified into two types- Server
Based Tools and Client Based Tools. In this post we will be taking a look at all these tools briefly and understand what each tool does, we
will see the details about all the tools in my coming posts. You can also refer to my SCCM 2012 R2 step by step guides here. Click on the below button to download System Center 2012 R2 Configuration Manager Toolkit.
Download System Center 2012 R2 Configuration Manager Toolkit
To install the System Center 2012 R2 Configuration Manager Toolkit (I am installing the System Center 2012 R2 Configuration Manager Toolkit on my SCCM box), click the Download button, and download ConfigMgrTools.msi. Run ConfigMgrTools.msi to install the System Center 2012 R2 Configuration Manager Toolkit. Click Next.
Accept the license agreement and click Next.
System Center 2012 R2 Configuration Manager Toolkit has been installed now. Click Finish.
Server Based Tools
DP Job Manager – A tool that helps troubleshoot and manage ongoing content distribution jobs to Configuration Manager distribution points.
(Requires Microsoft System Center 2012 R2 Configuration Manager for full functionality). The tool displays the list of jobs that the package transfer manager component has in its queue as well as the status of the jobs (ready to be executed, running or retrying). The tool also allows manipulation of the jobs in the queue, moving jobs higher on the list, cancelling or even kick start running a job manually.
Collection Evaluation Viewer – A tool that assists in troubleshooting collection evaluation related issues by viewing collection evaluation
details (Requires Microsoft System Center 2012 R2 Configuration Manager for full functionality). The collection evaluation process runs by evaluating the membership rules of a collection to update its members. The tool displays both historic and live information for full and incremental collection evaluations and the evaluation queue status. It will provide information on the time for collection evaluations to complete, which collections are currently being evaluated, and the estimated time that a collection evaluation will start and complete.
Content Library Explorer – A tool that assists in troubleshooting issues with and viewing the contents of the content library (Requires
Microsoft System Center 2012 R2 Configuration Manager for full functionality). This tool can be used to troubleshoot issues with the content library, as well as explore its contents. Using the tool, packages, contents, folders, and files can all be copied out of the content library. Packages can be redistributed to the distribution point, and on remote distribution points, packages can be validated. This tool must be run using an account that has administrative access to the target distribution point, as well as access to the WMI provider on the site server and the Configuration Manager provider.
Security Configuration Wizard Template for Microsoft System Center 2012 R2 Configuration Manager – The Security Configuration
Wizard (SCW) is an attack-surface reduction tool for the Microsoft Windows Server 2008 R2 operating system. Security Configuration Wizard determines the minimum functionality required for a server’s role or roles, and disables functionality that is not required.
Content Library Transfer – A tool that transfers content from one disk drive to another. The tool is useful for the scenario when the disk
drive hosting the content library becomes full. After a hard disk is installed with sufficient space to host the content library,
ContentLibraryTransfer.exe is used transfer content from the old filled hard disk to the new (empty) drive. Once the transfer is complete,
content is now accessible to client computers from the new location without admin intervention.
The syntax of the command is ContentLibraryTransfer.exe –SourceDrive <drive letter of source drive> –TargetDrive <drive letter of
Content Ownership Tool – A tool that changes ownership of orphaned packages (packages without an owner site server). Orphaned
packages are packages without an owner site server. Packages that are created at a site can become orphaned by removing the site server while they are still owned by this site server. You can select the package and change the site ownership of the package.
Role-based Administration Modeling and Auditing Tool – This tool helps administrators to model and audit RBA configurations.With this
tool you can select the Run As button in toolbar tray. You can input the specific user name to check the permissions for that user account. You will see the security roles assigned to the user or the security group the user belongs to.
Run Metering Summarization Tool – The purpose of this tool is to run the metering summarization task to analyze raw metering data. The RunMeterSumm tool is used to trigger Metering Summarization immediately on Primary Sites, by default it’s running as scheduled in Site
Maintenance tasks, which start after 12:00AM every day. These tasks summarize the data in table MeterData, and write the summary result into the tables FileUsageSummary and MonthlyUsageSummary, so the user can see the summarized result in metering reports. The administrator who can connect to the primary site database can use this tool to run summarization.
Client Based Tools
Client Spy – A tool that helps you troubleshoot issues related to software distribution, inventory, and software metering on System Center
2012 Configuration Manager clients. Click on Tools and click connect. You can connect it to a remote machine and troubleshoot issues related to software distribution, inventory, and software metering.
Configuration Manager Trace Log Viewer – A tool used to view log files created by Configuration Manager components and agents. Most
of you would have used this tool and I must say its an excellent log file viewer till date.
Deployment Monitoring Tool – The Deployment Monitoring Tool is a graphical user interface designed help troubleshoot Applications,
Updates, and Baseline deployments on System Center 2012 Configuration Manager clients. To connect to remote machine, click on Actions and click on Connect to Remote Machine, type the machine name, user name and password. The tool is read only it does not change any state on the client and can be safely used to diagnose common deployment scenarios.
Policy Spy – A policy viewer that helps you review and troubleshoot the policy system on System Center 2012 Configuration Manager
Power Viewer Tool – A tool to view the status of power management feature on System Center 2012 Configuration Manager clients. You
must run this tool as administrator, when you launch this tool it will display the power settings and capabilities data of local computer. You can connect to a remote computer and view the power management data.
Send Schedule Tool – A tool used to trigger a schedule on a client or trigger the evaluation of a specified DCM Baseline. You can trigger a
Wakeup Spy – A tool that provides a view of the power state of Configuration Manager client computers and which operate as managers or
manages. The tool is useful to get an understanding of wake up traffic being generated and the current power status of client computers. It cannot be used to control the power state of computers.
