OBEF(Odd Backward Even Forward) Page Replacement Technique

International Journal of Emerging Technology and Advanced Engineering

607

OBEF(Odd Backward Even Forward) Page Replacement

Technique

Kavit Maral Mehta

, Prerak Garg

, Ravikant Kumar

G-752, Socrates block, VIT university, vellore -632014

Abstract— This paper describes about a new technique of page replacement algorithm that I have thought about and gives more hit than other algorithms for a some kind of data entries. My page replacement algorithm basically works in two directions. For even cycles it will work on the right side and will find the frequency of data entries that are going to be used and for the odd cycles it works on the left side finding the time elapsed for that data to be used again in other words finds the least recently used element and replaces that entry

.

Keywords— page replacement algorithm, cache, main

memory, time complexity, asymptotic notation.

I. INTRODUCTION

With the advancement of our computer world, there has been a concurrent change in the components and different terminologies related to the computer. In a computer operating system that uses paging for virtual memory management, page replacement algorithms decide which memory pages to page out (swap out, write to disk) when a page of memory needs to be allocated. Paging happens when a page fault occurs and a free page cannot be used to satisfy the allocation, either because there are none, or because the number of free pages is lower than some threshold. When the page that was selected for replacement and paged out is referenced again it has to be paged in (read in from disk), and this involves waiting for I/O completion. This determines the quality of the page replacement algorithm: the less time waiting for page-ins, the better the algorithm. A page replacement algorithm looks at the limited information about accesses to the pages provided by hardware, and tries to guess which pages should be replaced to minimize the total number of page misses, while balancing this with the costs (primary storage and processor time) of the algorithm itself. This was all the basis why we require a page replacement algorithm. Now I would tell how my page replacement technique works. All the page replacement techniques till now implemented have proved to be efficient for different values of data. Our basic aim is to reduce the time of the CPU to search for the data inside main memory. So, the technique that I have developed also consists of some plus points and some minus points.

As a student I have implemented this technique in C++ and have made a comparison between different other page replacement techniques and I have got a positive result from it showing that this method may prove to be a vital for coming time. It’s time complexity is also equal to the other techniques.

II. EXISTING METHODS  First-in, first-out (FIFO):

The simplest page-replacement algorithm. FIFO is a low-overhead algorithm that requires little book-keeping. The pages is stored in queue with the most recent arrival at the back and the earliest arrival in front. When a page needs to be replaced, the page at the front of the queue is selected. While FIFO is cheap and intuitive, it performs poorly in practical application. Thus, it is rarely used in its unmodified form.

 Least recently used (LRU):

LRU works on the ides that pages that have been most heavily used in the past are more likely to be used in the next few instructions too. LRU is little bit expensive to implement.

 Least frequently used (LFU):

International Journal of Emerging Technology and Advanced Engineering

608  Aging:

It is similar to LFU, instead of just incrementing the counters of the pages referenced , putting equal emphasis on page references regardless of time, the reference counter on a page is first shifted right, before adding the referenced bit to the left of that binary number. For instance, if a page has referenced bits 1,0,0,1,1,0 in the past 6 clock ticks, its referenced counter will look like this: 10000000, 01000000, 00100000, 10010000, 11001000, 01100100. Page references closer to the present time have more impact than page references long ago. This ensures that pages referenced more recently, though less frequently referenced, will have higher priority over pages more frequently referenced in the past. Thus, when a page needs to be swapped out, the page with the lowest counter will be chosen.

 Clock: Clock is a more efficient version of FIFO than

Second-chance because pages don't have to be constantly pushed to the back of the list, but it performs the same general function as Second-Chance. The clock algorithm keeps a circular list of pages in memory, with the "hand" (iterator) pointing to the last examined page frame in the list. When a page fault occurs and no empty frames exist, then the R (referenced) bit is inspected at the hand's location. If R is 0, the new page is put in place of the page the "hand" points to, otherwise the R bit is cleared. Then, the clock hand is incremented and the process is repeated until a page is replaced.

 Random: Random replacement algorithm replaces a random page

in memory. This eliminates the overhead cost of tracking page references. Usually it fares better than FIFO, and for looping memory references it is better than LRU, although

generally LRU performs better in practice

III. PROPOSED METHOD

The basic purpose of the page replacement method is to get as many hits as possible. We call our technique ―THE HYBRID‖, Because this method works in two directions. We have taken a counter. It’s initially value is 1.

Now whenever CPU checks for the data value in cache the value of the count increments by 1. And this value of count decides whether the page replacement algorithm will consider the values that the CPU will encounter in the future or the data values that the CPU has already come across.

Let us suppose that Cache memory size is 3(i.e it can hold 3 values) and main memory has size 10(i.e it can store 10 values).

Now CPU wants the data to perform mathematical operations. The cache consists of some previous values. First the CPU searches the cache for the data if it finds it then it’s a hit and no need of refering to the main memory. But if data is not found it will go to main memory for the data and will perform the page replacement algorithm.

Now if count value is initially 1 and for the first time only it gets a miss then OBEF will perform a search in the backward direction and will compare the data values in cache with the data values that CPU had taken from the main memory and the value which least recently used gets swapped out and the new data value comes in. Now this is performed only for the odd cycles like when count=1, 3, 5, 7, 9... and when the value of count is like 2, 4, 6, 8, 10.... then the comparison is made between the values in the cache and values in the main memory( stored in pages) which are going to be used in future and the value whose frequency is less among all gets swapped out and the new data comes in.

IV. ALGORITHM DEVELOPED

The above proposed method works according to the following algorithm:

 I am considering array to store data in cache and in main memory.

 Let m be the size of the cache and n be the size oo the main memory.(m<n)

 Now input the data values in the main memory that we would be requiring for calculations.

 The cache by default contains some values.

 Now we start our computation. CPU wants values , so it first looks in the cache.

 If it is a hit then CPU fetches the value from the cache and uses them. If it’s a miss then the CPU looks in the main memory and fetches the value from there.  Now if it is a miss, after fetching the value from the

International Journal of Emerging Technology and Advanced Engineering

609  This process repeats until CPU has completed it’s

computation.

 At the end of the process we calculate pagehit and pagemiss for the above algorithm.

 If pagehit > pagemiss then the above method is feasibly for the provided data values.

For our method (OBEF) we have used Dev C++ to compile and we have compared our developed program with other page replacement methods. And for many data value page-hit percentage > 60.

The comparison with other methods has been described below.

V. COMPARISON WITH OTHER TECHNIQUES

Let m be the size of cache and n be the size of the main memory.

Let m=5 and n=10 and a[] be the array keeping cache data and s[] be the array storing main memory data.

Let initial values in a[]={1,2,3,4,5} and data required for computation is stored in main memory i.e

s[]={9,1,8,2,7,3,6,4,5,5}.

Now at the student level I personally developed the code for LRU,LFU,FIFO and my own method(OBEF) in c++ and compared them for the above assumed values.

1. Comparison with FIFO

Output Given When OBEF is runned.

Output given when FIFO is runned

We can see that For our assumed data values we get 50% hits in case of OBEF and for the similar data value set we get 10% hits when FIFO is runned.

International Journal of Emerging Technology and Advanced Engineering

610

2. Comparison with LFU:

Output when LFU is runned

Now we see that Our method OBEF is of same importance that LFU has.

Both the techniques are giving 50% hits and therefore our method could be applied for the data values where LFU is used.

Both the techniques have O(n2) time complexity.

3. Comparison with LRU:

Output when LRU is runned

International Journal of Emerging Technology and Advanced Engineering

611 VI. CONCLUSION

The result of the following observations and tests tell us that this method may prove to play a important role in coming time as it proves to give more efficiency and taking equal time to execute with respect to the other techniques. The OBEF has performed better than FIFO,LFU,LRU and following virtues of this technique must be noted :

1.It is a simple technique and easy to implement not requiring mush of the hardware and technology. 2.It has an equal time complexity with respect to the

other techniques.

3.It has proved to be a good technique for scheduling process like round-robin.

VII. AKNOWLEDGEMENT

We would like to thank our parents for giving us such a support in our research. And we hope that through your publication we may be able to bring our work in front of the whole world. As a student and lack of resources we have implemented this technique only at the basic level.

REFERENCES

[1 ] Aho, Denning and Ullman, Principles of Optimal Page Replacement, Journal of the ACM, Vol. 18, Issue 1,January 1971, pp 80–93.

[2 ] Denning, P. J., "Virtual Memory," Computing Surveys, Vol. 2,No. 3, Sept. 1970, pp. 153-189.
