Intelligent Solutions. Systems Product Overview

(1)

Systems

Product Overview

Intelligent Solutions

(2)

Creativity and know-how are

the basis for intelligent and

functional technical innovations,

simply “Living Innovation®”

(3)

• Integrated system and board design

• Mechanical 3D Design

• Prototyping

• Verification

• Approvals

• Custom specific systems

• Application specific enclosues

• Integration of mainboards, SBC and COM CPU boards

• Alternative system configuration

• Modification of standard products

• Special interfaces

• Color and silk screening

• Custom logo • Embedded Systems • Control Cabinet PC • 19“ Industrial PC • Industrial Displays • Panel PC

• Slot-CPUs | Embedded CPU-Boards

Standard

Semi-Customized

Full-Customized

Customer-specific

developments

Content

We develop and manufacture embedded systems and display solutions for various markets and applications. Our experienced team has extensive knowledge of the market-specific requirements and guarantees that your projects are delivered quickly and professionally.

Our embedded systems can be found everywhere; from the control system in a painting robot in the automotive industry to data acquisition in a wind energy plant to home automation operating and HMI systems.

(4)

Core

Competence

With more than 30 years of experience in the system business, we understand our customers requirements and implement them in innovative solutions.

The system design includes the integration of a mainboard, the HDDs/SDDs, the power supply and the wiring. A cooling solution optimized to the application has major importance. 3D CAD systems and a temperature simulation are used during the design phase.

In many applications the industrial computer is combined with a display, including touch, to form an HMI terminal. Microsoft®_Windows®_{, Windows}®_{Embedded and Linux Embedded are}

supported as operating systems.

The complete system is subjected to a functional test, a compatibility verification and tests that simulate various harsh environments. Certifications in accordance with CE, FCC, UL, EN 60601, etc. are routine.

(5)

System

Solutions

To further optimize the yield, intelligent con-trol computers with HMI Panel are increasingly being used in modern agricultural vehicles. Pri-or to each deployment, the compact terminal is programmed with the individual work steps. The current data can be displayed on an intu-itively operated display. The agricultural ma-chine can be navigated via GPS.

Important characteristics of the HMI Panel are the robustness of the deployed hardware and

practice-oriented software. The customized HMI Panel is equipped with a 10.4 cm TFT dis-play with resistive or PCT touch. The custom-ized system was specified in accordance with IP65 degree of protection and so provides pro-tection against dust penetration. The housing is also protected against spray water from all directions. The system can tolerate extreme vibrations of 3 G / 300 Hz 48 h / axis and is de-signed for operation at temperatures of -40° to +80° C.

Interconnected traffic and information systems are a prerequisite in order to keep regional, long-distance and cargo rail traffic competitive in future.

High-performance 19-inch industrial PCs in the control rooms handle the switch and sig-nal control as well as monitor the sigsig-nal box. The high-end system is based on the state-of-the-art Intel®_CoreTM_{processor family with high}

computing and graphic power.

The 2-unit high 19-inch computer has four free slots that can integrate as many as four RAID-conform HDDs (hard disk drives). Primary emphasis is placed on the robustness as well as the redundant ventilation and power supply of the IPC. The fans and the dust filter can be replaced during operation (hot-plug).

Fully customized HMI Panel for controlling tractors

(6)

Embedded Systems

„Embedded systems are the future of the industry. Small and easy to handle - simple to integrate.“

Christian Lang Product manager embedded systems

(7)

DIN Rail PC

Control

Cabinet PC

• Intel®_AtomTM_Z510/Z530 • For electrical cabinet

• Dimension (WxDxH): 124.5 (7U) x 90 x 41|55 mm

• Intel®_CoreTM_i7/i5 • Intel®_{QM57 chipset} • Assembly in control cabinet

• Dimension (WxDxH): 149 x 260 x 280 mm

• Hybrid cooling

• Intel®_CoreTM_{processor 3rd generation} • Dimension (WxDxH): 305 x 305 x 133 mm • Fanless • Intel®_AtomTM_N2600 • Dimension (WxDxH): 136 x 79.6 x 20 mm

NanoServer

® • 1 slot (N1)

• Intel®_CoreTM_{processor 4th generation} • Dimension (WxDxH): 204 x 224 x 80 mm

• without slot (NN) | 1 slot (N1) | 2 slots (N2)

• Intel®_CoreTM_{processor 3rd/4th generation} • Dimension (WxDxH): 204 x 226 x 58|79|109 mm

• 1 slot

• Intel®_CoreTM_{4th generation}

NanoServer

®

IO

BookSize

EN

A1

BOXER Lite

• Fanless

• Intel®_AtomTM_{E3845 4 cores}

(8)

NanoServer

®

NanoServer

®

IO

BOXER Lite

BookSize

EN

A1

DIN Rail PC

Galaxy

® NN N1 N2 N1 B1 EN-A3 A1 H1 G4 CPU Intel® _CoreTM₂ Duo | Celeron® Dual CoreTM _| Intel®_CoreTM 3rd generation

CoreTM_{2 Duo | Celeron}®_{Dual Core}TM

Intel®_CoreTM_{3rd | 4th gen.} Intel

® _CoreTM_{4th gen. Intel}®_AtomTM_N2600 _CPU Intel ® _CoreTM 4th generation

Intel®_AtomTM_E3845 (formerly known as Bay Trail-I) Intel®_CoreTM 3rd generation Intel®_AtomTM Z510 | Z530 Intel ®_CoreTM_{i7 | i5}

Chipset Intel®_{GM45 | QM67} _Intel®_{GM45 | QM67 | QM87} _Intel® _Q87 _Intel®_NM10 _Chipset _Intel® _Q87 _- _Intel®_QM67 _US15W _Intel®_QM57

RAM (max.) 8 GB DDR2 16 GB DDR3 8 GB DDR2 16 GB DDR3 8 GB DDR2 16 GB DDR3 16 GB 2 GB DDR3 RAM (max.) 16 GB 8 GB DDR3L 16 GB DDR3 2 GB DDR2 8 GB DDR3

Slots - 1 x PCI | 1 x PCIe 2 x PCI | 1 x PCI, 1 x

PCIe | 2 x PCIe 1 x PCIe x16 - Slots 1 x PCIe x16

2 x Mini-PCIe

(1 x mSATA III) 1 x PCI Express x16

-4 x PCI | 3 x PCI and 1 x PCIe x1

Drives 1 x 2.5“ (int.) 2 x 2.5“ (int.) 2 x 2.5“ (int.) 1 x mSATA

2 x 2.5“ HDD mSATA Drives 1 x mSATA 2 x 2.5“ HDD 1 x 2.5“ (int.) 1 x 3.5“ 1 x 2.5“ (int.) SD-Card Slot onboard Flash 1 x 3.5“ 1 x 2.5“ (int.) Highlights flat maintenance- friendly bottom flap opt. dust-protection filter Embedded Desktop CPU fanless

opt. WiFi Highlights

Int. AC | Power supply Removeable Dust filter | Passive CPU

cooling

fanless

compact housing hybrid cooling for electrical cabinet

assembly in control cabinet Dimension (WxDxH) in mm 204 x 226 x 58 204 x 226 x 79 204 x 226 x 109 204 x 224 x 80 136 x 20 x 79.6 Dimension (WxDxH) in mm 330 x 206 x 88 200 x 200 x 51 305 x 305 x 133 124.5 (7TE) x 90 x 41 | 55 149 x 260 x 280 Order No. 96M1563-GM45 96M1563-QM67 96M1557-GM45 96M1557-QM67 96M1558-GM45 96M1558-QM67 96M1558-QM87 96M1661-Q87 AEC-6402-A3-1010

AEC-6402-A4-1010 Order No. 96M1470-Q87 96M1490-A3 96M1480-QM67

96M1670-Z510

96M1670-Z530 96M1644-QM57

Manufacturer Manufacturer

Embedded Systems

Overview

Our innovative embedded systems, specially designed for industrial applications, are characterized with their extremely compact measurements. The individual models that dif-fer in their unique characteristics have a modu-lar construction, scalable processor power, etc.

The standardized building blocks used as basis also allow you to implement your customer-specific solution quickly and cost-optimized. All embedded systems are developed and manufactured with high quality. We guarantee long product availability.

(9)

NanoServer

®

NanoServer

®

IO

BOXER Lite

BookSize

EN

A1

DIN Rail PC

Galaxy

® NN N1 N2 N1 B1 EN-A3 A1 H1 G4 CPU Intel® _CoreTM₂ Duo | Celeron® Dual CoreTM _| Intel®_CoreTM 3rd generation

CoreTM_{2 Duo | Celeron}®_{Dual Core}TM

Intel®_CoreTM_{3rd | 4th gen.} Intel

® _CoreTM_{4th gen. Intel}®_AtomTM_N2600 _CPU Intel ® _CoreTM 4th generation

Intel®_AtomTM_E3845 (formerly known as Bay Trail-I) Intel®_CoreTM 3rd generation Intel®_AtomTM Z510 | Z530 Intel ®_CoreTM_{i7 | i5}

Chipset Intel®_{GM45 | QM67} _Intel®_{GM45 | QM67 | QM87} _Intel® _Q87 _Intel®_NM10 _Chipset _Intel® _Q87 _- _Intel®_QM67 _US15W _Intel®_QM57

RAM (max.) 8 GB DDR2 16 GB DDR3 8 GB DDR2 16 GB DDR3 8 GB DDR2 16 GB DDR3 16 GB 2 GB DDR3 RAM (max.) 16 GB 8 GB DDR3L 16 GB DDR3 2 GB DDR2 8 GB DDR3

Slots - 1 x PCI | 1 x PCIe 2 x PCI | 1 x PCI, 1 x

PCIe | 2 x PCIe 1 x PCIe x16 - Slots 1 x PCIe x16

2 x Mini-PCIe

(1 x mSATA III) 1 x PCI Express x16

-4 x PCI | 3 x PCI and 1 x PCIe x1

Drives 1 x 2.5“ (int.) 2 x 2.5“ (int.) 2 x 2.5“ (int.) 1 x mSATA

2 x 2.5“ HDD mSATA Drives 1 x mSATA 2 x 2.5“ HDD 1 x 2.5“ (int.) 1 x 3.5“ 1 x 2.5“ (int.) SD-Card Slot onboard Flash 1 x 3.5“ 1 x 2.5“ (int.) Highlights flat maintenance- friendly bottom flap opt. dust-protection filter Embedded Desktop CPU fanless

opt. WiFi Highlights

Int. AC | Power supply Removeable Dust filter | Passive CPU

cooling

fanless

compact housing hybrid cooling for electrical cabinet

assembly in control cabinet Dimension (WxDxH) in mm 204 x 226 x 58 204 x 226 x 79 204 x 226 x 109 204 x 224 x 80 136 x 20 x 79.6 Dimension (WxDxH) in mm 330 x 206 x 88 200 x 200 x 51 305 x 305 x 133 124.5 (7TE) x 90 x 41 | 55 149 x 260 x 280 Order No. 96M1563-GM45 96M1563-QM67 96M1557-GM45 96M1557-QM67 96M1558-GM45 96M1558-QM67 96M1558-QM87 96M1661-Q87 AEC-6402-A3-1010

AEC-6402-A4-1010 Order No. 96M1470-Q87 96M1490-A3 96M1480-QM67

96M1670-Z510

96M1670-Z530 96M1644-QM57

(10)

Infinity

®

19“ Industrial Rack Systems

„Our industrial systems offer a flexible, reliable and robust solution for every project.“

Klaus Wöllert Product manager 19“ systems

(11)

• 6 slots

• Depth: 408 mm

• Drive bays: 2 x 5.25“, 2.5“ (int.)

• Platform: Industrial ATX | 2 x Intel®_Xeon®_E5

Infinity

®

19“ S4 Server (4U)

• 1 slot

• Depth 303 mm

• Drive bays: 5.25“ slimline, 3.5“, 2.5“ (int.)

• Platform: Industrial mini-ITX

• 4 slots

• Depth: 380 - 448 mm

• Drive bays: 5.25“ slimline, 2 x 3.5“

• Platform: Industrial micro-ATX, slot CPU

• 12 slots

• Depth: 408 - 508 mm

• Drive bays: 2 x 5.25“, 2.5“ (int.) | 4 x 5.25“, 3.5“

• Platform: Industrial ATX, slot CPU

Infinity

®

19“ I1 series (1U)

Infinity

®

Infinity

®

Drive Cages

3.5“ Bay 3.5“ Bay 5.25“ Bay 5.25“ Bay 2 x 5.25“ Bay 2 x 5.25“ Bay

• 2 x 3.5“ SATA hard disk

• RAID 0,1 with display

• Slimline DVD

• 3.5“ SATA

• 2 x 2.5“ SATA

• 1 x Compact Flash

• 4 x 2.5" SATA hard disk

(12)

Infinity

®

I1

Infinity

®

I2

Infinity

®

I4

Infinity

®

S4

1U 2U 4U 4U

Platform mini-ITX micro-ATX Slot CPU - PICMG 1.0 Slot CPU - PICMG 1.3 Platform ATX Slot CPU - PICMG 1.0 Slot CPU - PICMG 1.3 ATX

CPU Intel®_Core™_{3rd gen.} _Intel®_CoreTM_{4th gen.} Intel

®_CoreTM_i7/i5/i3

Pentium®_{| Celeron}® Intel

®_CoreTM_{3rd gen.} _CPU _Intel®_CoreTM_{4th gen.} Intel

®_CoreTM_i7/i5/i3

®_CoreTM_{3rd gen.} _{2 x Intel}®_Xeon®_E5

Chipset Intel®_QM67 _Intel®_Q87 _Intel®_H61 _Intel®_Q67 _Chipset _Intel®_Q87 _Intel®_H61 _Intel®_Q67 _Intel®_C602

VGA

Intel®_{HD |} HD3000 | HD4000 (integrated in CPU)

Intel®_{HD | HD2000 | HD 2500 | HD4000 | HD4600 (integrated in CPU)} _VGA _Intel®_{HD | HD2000 | HD2500 | HD4000 | HD4600 (integrated in CPU)} Matrox G450 DualHead PCI, 32 MB

RAM (max.) 16 GB DDR3 32 GB DDR3 16 GB DDR3 16 GB DDR3 RAM (max.) 32 GB DDR3 16 GB DDR3 16 GB DDR3 2 x 96 GB DDR3

SATA 2 x SATA III

4 x SATA II

6 x SATA III

mSATA (via Mini PCIe) 4 x SATA II

2 x SATA III

4 x SATA II SATA

6 x SATA III

mSATA (via SATA III) 4 x SATA II

2 x SATA III 4 x SATA II

RAID - 0, 1, 1+0, 5 - 0, 1, 1+0, 5 RAID 0, 1, 1+0, 5 - 0, 1, 1+0, 5 PCIe x8 controller

0, 1, 5, 6, 10, 50, 60

Slots opt. 1 x PCIe x16

2 x PCIe x16 1 x PCIe x8 1 x PCI 4 x PCI 1 x PCIe x16 1 x PCIe x1 2 x PCI Slots 2 x PCIe x16 1 x PCIe x8 4 x PCI 4 x PCI 8 x ISA 1 x PCIe x16 2 x PCIe x4 8 x PCI, 2 x ISA 1 x PCIe x16 3 x PCIe x8, 1 x PCIe x4 1 x PCI Racks 1 x 5.25“ Slimline 1 x 3.5“, 1 x 2.5“ (int.) 1 x 5.25“ Slimline 2 x 3.5“ 1 x 5.25“ Slimline 2 x 3.5“ 1 x 5.25“ Slimline 2 x 3.5“ Racks 2 x 5.25“ 1 x 2.5“ (int.) 2 x 5.25“ 1 x 2.5“ (int.) 4 x 5.25“ 1 x 3.5“ 2 x 5.25“ 1 x 2.5“ (int.) Depth 303 mm 380 mm 448 mm 448 mm Depth 408 mm 408 mm 508 mm 408 mm

Order No. 96I1303-MBQM67 96I2380-MBQ87 96I2448-10H61 96I2448-13Q67 Order No. 96I4408-MBQ87 96I4408-10H61 96I4508-13Q67 96I4408B-MBC602

Manufacturer Manufacturer

The high-performance 19” computer systems of the Infinity®_{family are the right}

choice when industrial applications require different drives or more than two or three slots for

additional plug-in cards. We emphasized on an optimal combination of design and functionality of the systems.

Infinity

®

19“ Industrial Rack Systems

(13)

Infinity

®

I1

Infinity

®

I2

Infinity

®

I4

Infinity

®

S4

1U 2U 4U 4U

Platform mini-ITX micro-ATX Slot CPU - PICMG 1.0 Slot CPU - PICMG 1.3 Platform ATX Slot CPU - PICMG 1.0 Slot CPU - PICMG 1.3 ATX

CPU Intel®_Core™_{3rd gen.} _Intel®_CoreTM_{4th gen.} Intel

®_CoreTM_i7/i5/i3

®_CoreTM_{3rd gen.} _CPU _Intel®_CoreTM_{4th gen.} Intel

®_CoreTM_i7/i5/i3

®_CoreTM_{3rd gen.} _{2 x Intel}®_Xeon®_E5

Chipset Intel®_QM67 _Intel®_Q87 _Intel®_H61 _Intel®_Q67 _Chipset _Intel®_Q87 _Intel®_H61 _Intel®_Q67 _Intel®_C602

VGA

Intel®_{HD |} HD3000 | HD4000 (integrated in CPU)

Intel®_{HD | HD2000 | HD 2500 | HD4000 | HD4600 (integrated in CPU)} _VGA _Intel®_{HD | HD2000 | HD2500 | HD4000 | HD4600 (integrated in CPU)} Matrox G450 DualHead PCI, 32 MB

RAM (max.) 16 GB DDR3 32 GB DDR3 16 GB DDR3 16 GB DDR3 RAM (max.) 32 GB DDR3 16 GB DDR3 16 GB DDR3 2 x 96 GB DDR3

SATA 2 x SATA III

4 x SATA II

6 x SATA III

mSATA (via Mini PCIe) 4 x SATA II

2 x SATA III

4 x SATA II SATA

6 x SATA III

mSATA (via SATA III) 4 x SATA II

RAID - 0, 1, 1+0, 5 - 0, 1, 1+0, 5 RAID 0, 1, 1+0, 5 - 0, 1, 1+0, 5 PCIe x8 controller

0, 1, 5, 6, 10, 50, 60

Slots opt. 1 x PCIe x16

2 x PCIe x16 1 x PCIe x8 1 x PCI 4 x PCI 1 x PCIe x16 1 x PCIe x1 2 x PCI Slots 2 x PCIe x16 1 x PCIe x8 4 x PCI 4 x PCI 8 x ISA 1 x PCIe x16 2 x PCIe x4 8 x PCI, 2 x ISA 1 x PCIe x16 3 x PCIe x8, 1 x PCIe x4 1 x PCI Racks 1 x 5.25“ Slimline 1 x 3.5“, 1 x 2.5“ (int.) 1 x 5.25“ Slimline 2 x 3.5“ 1 x 5.25“ Slimline 2 x 3.5“ 1 x 5.25“ Slimline 2 x 3.5“ Racks 2 x 5.25“ 1 x 2.5“ (int.) 2 x 5.25“ 1 x 2.5“ (int.) 4 x 5.25“ 1 x 3.5“ 2 x 5.25“ 1 x 2.5“ (int.) Depth 303 mm 380 mm 448 mm 448 mm Depth 408 mm 408 mm 508 mm 408 mm

Order No. 96I1303-MBQM67 96I2380-MBQ87 96I2448-10H61 96I2448-13Q67 Order No. 96I4408-MBQ87 96I4408-10H61 96I4508-13Q67 96I4408B-MBC602

(14)

Panel PC / Industrial displays

„Singletouch, multitouch, widescreen, with or without PC. Panel systems and displays for today and tomorrow.“

Christian Lang Product manager panel PC

(15)

• 47 cm (18.5“)

• Multi Touch

• Intel®_AtomTM_D2550

• Drive bays: 1 x 2.5“, CF, extension I/0

• 47 cm (18.5“)

• Multi Touch

• Intel®_AtomTM_E3845

• Drive bays: 1 x 2.5“ (int.) | Compact Flash (int.)

ACP-1073

ACP-1103

AID-173SHRJ

PN18-A2

APC-18W9

PN15-A2

PN17-A2

Display D18

• 38 cm (15“) • Single Touch • Intel®_AtomTM _D2550

• 43 cm (17“)

• Single Touch

• Intel®_AtomTM _D2550

• 44 cm (17.3“)

• Single Touch

• Intel®_CoreTM_i7/i3 • Drive bay: 1 x 2.5“ (int.)

• Dimension (WxDxH): 505 x 54.5 x 336 mm

• 18 cm (7“)

• Multi Touch

• Intel®_AtomTM _N2600 • Drive bay: mSATA (int.)

• Dimension (WxDxH): 202.2 x 37.2 x 134.2 mm

• 26 cm (10.1“)

• Multi Touch

• Intel®_AtomTM _N2600 • Drive bay: mSATA (int.)

• Dimension (WxDxH): 266 x 30 x 183.5 mm

• 47 cm (18.5“)

• Multi Touch

• VGA | DVI input

• 12/24V DC

(16)

ACP-1073

ACP-1103

PN15-A2

PN17-A2

AID-173SHRJ

PN18-A2

APC-18W9

D18

Diagonale 18 cm (7“) 26 cm (10.1“) 38 cm (15“) 43 cm (17“) Diagonale 44 cm (17.3“) 47 cm (18.5“) 47 cm (18.5“) 47 cm (18.5“)

Resolution 1024 x 600 1280 x 800 1024 x 768 1280 x 1024 Resolution 1920 x 1080 1366 x 768 1366 x 768 1366 x 768

Contrast 500:1 600:1 700:1 1000:1 Contrast 650:1 1000:1 1000:1 1000:1

Touchscreen Multi Touch Multi Touch Single Touch Single Touch Touchscreen Single Touch Multi Touch Multi Touch Multi Touch

CPU Intel®_AtomTM_N2600 _Intel®_AtomTM_N2600 _Intel®_AtomTM _D2550 _Intel®_AtomTM _D2550 _CPU Intel

®_CoreTM_i7/i3

Intel® _Celeron® Intel

®_AtomTM _D2550 _Intel®_AtomTM_E3845

-RAM (max.) 2 GB DDR3 2 GB DDR3 2 GB DDR3 2 GB DDR3 RAM (max.) 8 GB DDR3 2 GB DDR3 8 GB DDR3L

-LAN 1 x Gigabit 1 x Gigabit 2 x Gigabit 2 x Gigabit LAN 1 x Gigabit 2 x Gigabit 2 x Gigabit

-Drive Bays mSATA (int.) mSATA (int.) 1 x 2.5“

Compact Flash

1 x 2.5“

Compact Flash Drive Bays 1 x 2.5“ (int.)

1 x 2.5“ Compact Flash

1 x 2.5“ (int.)

Compact Flash (int.)

-Power Supply 12V DC 12V DC 12/24V DC 12/24V DC Power Supply 12~19V DC 12/24V DC 12~26V DC 12/24V DC

Dimension

(WxDxH) in mm 202.2 x 37.2 x 134.2 266 x 30 x 183.5 425 x 50 x 330 437 x 53 x 375

Dimension

(WxDxH) in mm 505 x 54.5 x 336 464 x 58 x 289 443 x 59 x 290 464 x 58 x 289

Order No. ACP-1073HTT-A1-1010

ACP-1073HTT-A2-1010

ACP-1103HTT-A1-1011

ACP-1103HTT-A2-1011 96M9150-A2-AR 96M9170-A2-AR Order No.

ADI-173SHRJ01-S01R ADI-173SHRJ02-S01R ADI-173SHRJ03-S01R ADI-173SHRJ04-S01R

96M9180-A2-AP APC-18W9 96M8280-AP

Manufacturer Manufacturer

Panel PC / Industrial Displays

Overview

Our panel systems support you in varying are-as of visualization and processing of different production processes within manufacturing

automation by means of the robust and com-pact construction.

(17)

ACP-1073

ACP-1103

PN15-A2

PN17-A2

AID-173SHRJ

PN18-A2

APC-18W9

D18

Diagonale 18 cm (7“) 26 cm (10.1“) 38 cm (15“) 43 cm (17“) Diagonale 44 cm (17.3“) 47 cm (18.5“) 47 cm (18.5“) 47 cm (18.5“)

Resolution 1024 x 600 1280 x 800 1024 x 768 1280 x 1024 Resolution 1920 x 1080 1366 x 768 1366 x 768 1366 x 768

Contrast 500:1 600:1 700:1 1000:1 Contrast 650:1 1000:1 1000:1 1000:1

Touchscreen Multi Touch Multi Touch Single Touch Single Touch Touchscreen Single Touch Multi Touch Multi Touch Multi Touch

CPU Intel®_AtomTM_N2600 _Intel®_AtomTM_N2600 _Intel®_AtomTM _D2550 _Intel®_AtomTM _D2550 _CPU Intel

®_CoreTM_i7/i3

Intel® _Celeron® Intel

®_AtomTM _D2550 _Intel®_AtomTM_E3845

-RAM (max.) 2 GB DDR3 2 GB DDR3 2 GB DDR3 2 GB DDR3 RAM (max.) 8 GB DDR3 2 GB DDR3 8 GB DDR3L

-LAN 1 x Gigabit 1 x Gigabit 2 x Gigabit 2 x Gigabit LAN 1 x Gigabit 2 x Gigabit 2 x Gigabit

-Drive Bays mSATA (int.) mSATA (int.) 1 x 2.5“

Compact Flash

1 x 2.5“

Compact Flash Drive Bays 1 x 2.5“ (int.)

1 x 2.5“ Compact Flash

1 x 2.5“ (int.)

Compact Flash (int.)

-Power Supply 12V DC 12V DC 12/24V DC 12/24V DC Power Supply 12~19V DC 12/24V DC 12~26V DC 12/24V DC

Dimension

(WxDxH) in mm 202.2 x 37.2 x 134.2 266 x 30 x 183.5 425 x 50 x 330 437 x 53 x 375

Dimension

(WxDxH) in mm 505 x 54.5 x 336 464 x 58 x 289 443 x 59 x 290 464 x 58 x 289

Order No. ACP-1073HTT-A1-1010

ACP-1073HTT-A2-1010

ACP-1103HTT-A1-1011

ACP-1103HTT-A2-1011 96M9150-A2-AR 96M9170-A2-AR Order No.

ADI-173SHRJ01-S01R ADI-173SHRJ02-S01R ADI-173SHRJ03-S01R ADI-173SHRJ04-S01R

96M9180-A2-AP APC-18W9 96M8280-AP

(18)

Industrial SBC / Add Ons

„Proven standard with state-of-the-art technology.“

Klaus Wöllert Product manager 19“ systems

(19)

• PICMG 1.0 | PICMG 1.3 (PCI express)

• Intel®_CoreTM_{2 Duo / Intel}®_CoreTM_{2 Quad} • Intel®_CoreTM_{processor 1st to 3rd generation}

• 3.5“ form factor

• Intel®_AtomTM • Intel®_CoreTM_i7/i5/i3

• PICMG 1.0 | PICMG 1.3 (PCI express)

• 3 -19 slots

• ISA | PCI | PCI Express

• Harddisk

• SSD (Solid State Drive)

• Compact flash

• CD / DVD-ROM drives

• ATX power supply

• DC / DC converter

• UPS

• TFT displays

• Touchscreens

• Microsoft®_Windows®

• Microsoft®_Windows®_Embedded • LinuxTM • Interface cables • Power cables • Keyboards, mice • Graphic cards • Network controller • I/O controller • Feldbus cards

Embedded Controller

Backplane

Bulk Memory

Expansion cards

Cabel and consumables

Operating systems

Power supply

Display, Touch

Slot CPU

We only use high-performance system components taking into account long-term availability and high quality for our industrial systems. We would be pleased to offer advice in the selection of the correct components.

(20)

Intelligent Solutions

Germany

Aachen Pascalstr. 16 • 52076 Aachen t +49 2408 709 0

Berlin Tempelhofer Ufer 37 • 10963 Berlin t +49 30 720089 0

Düsseldorf Max-Planck-Str.15a-c • 40699 Erkrath t +49 211 92593 0

Hannover Gaußstraße 10 • 31275 Lehrte t +49 5132 5099 680

Jena Göschwitzer Straße 25 • 07745 Jena t +49 3641 6825 0

Koblenz Auf dem Hahnenberg 19 • 55218 Mühlheim t +49 2630 96239 11

Maudach Torfstecherring 4 • 67067 Ludwigshafen t +49 621 58649 113

Neufahrn Zeppelinstr. 1a • 85375 Neufahrn t +49 8165 906 100

Nürnberg Vogelweiherstr. 20 • 90441 Nürnberg t +49 911 43970 0

Stuttgart Gutenbergstraße 15 • 70771 Leinfelden-Echterdingen t +49 711 78260 380

Wiesbaden Borsigstraße 36 • 65205 Wiesbaden t +49 6122 5871 422

Europe

Austria (also responsible for Slovenia )

Aredstrasse 13 • A - 2544 Leobersdorf t +43 (2256) 63975-13

Romania Pipera-Tunari 4c Voluntari • 077190 Ilfov (Bucharest) t +40 21 529 6911

Hungary Budafoki út 91-93 West Irodahaz • 1117 Budapest t +36 1 436 72 29

Switzerland Industriestr. 25 • CH - 8604 Volketswil t +41 43 355 33 66

Benelux countries Stadionstraat 2, 6th fl. • NL - 4815 NG BREDA t +31 76 5722400

Czech Republic/Poland Nádražní 2369/10 • CZ - 678 01 Blansko t +420 516 411 494-15

Turkey Inonu Cd. Seylan Is Merkezi 83/6 Kozyatagi • TR - 34736 Istanbul t +90 216 411-2333

Spain Calle Chile 10, 2nd Planta, Oficina 222 • ES - 28290 Las Matas, Madrid t +34 91 721 69 51 Fermín Calbetón Nº4 Planta 3 • 20600 Eibar (Guipúzcoa) t +34 943 257 105

Headquarters Stutensee MSC Technologies GmbH MSC Technologies Systems GmbH Industriestraße 16 76297 Stutensee t +49 7249 910 - 0 f +49 7249 910 7993 [email protected] www.msc-technologies.eu Munzinger Straße 3 79111 Freiburg im Breisgau t +49 761 88190
