GENERAL CATALOGUE 2017/18

(1)

Service Machines for Ski & Snowboard

Accessories & Consumables

Rent- & Depot Systems

(2)

(3)

10-17

THE COMPANY

ICONS / SYMBOLS

INTRODUCTION OF MACHINERY

SERVICE CENTER

SF-1 SF-4

RACE MACHINERY

PROFI S200/350 RACE FEED

SOFTWARE

STRUCTURE DEVELOPMENT TOOL - PATRICH

BELT-STONE-GRINDING MACHINE

THE NEW PROFI 4

BELT-GRINDING MACHINERY

PROFI B VARIO PROFI B350 SN 350 PROFI

BASE-EDGE-TUNING MACHINERY

DTS-U PRO KFM-U KSM

BELT-WAXING MACHINERY

BWM 350 PRO BWM 350 C DIGITAL WAXFUTURE WALL SPEED

BASE REPAIR DEVICES

POLYMAT 1 & 2

WORKSHOP EQUIPMENT

MULTIFUNCTIONAL WORKBENCH SKI- & SNOWBOARD BOOT CLEANER

COMPRESSORS & DRYER

ACCESSORIES & CONSUMABLES

INTRODUCTION

WORKSHOP REQUIREMENTS SPARE & WEAR PARTS

WORKBENCH & BINDING BRIDGES DRESSING DIAMONDS

GRINDING STONES

GRINDING DISCS & DRESSING DIAMONDS POLISHING BELTS

BASE REPAIR WAXING ACCESSORIES EDGE TUNING - PREMIUM ACCESSORIES & BINDING FITTING

SULZBERG

RENT & DEPOT SYSTEMS

INTRODUCTION RENT EASY TOP UNIVERSAL SNOWBOARD SKATE & BOOT BOOT DRYER OTHERS DEPOT DEPOT LOCKERS

58-84

TABLE OF CONTENT

10-13 14-17 34-35 36-37 38-39 40-41 42-43 44-45 48-49 50-51

18-23

24-25

26-27

28-33

34-39

40-45

46-47

48-53

58-59 60-61 62-63 64-65 66-67 68-71 72-73 74-75 76-77 78-79 80-81 82-84

85

86-87 88-91 92-95 96-101 102-103 104-107 108-111 112-115 116-119

86-119

SERVICE CONTRACT

56-57

28-29 30-31 32-33

RACE EQUIPMENT

COOLING

54-55

6-7

8-9

120-121

NOTES / ORDER SHEET

18-21

(4)

The Reichmann & Sohn GmbH is a family-owned company based in the Bavarian Weißenhorn, Germany.

For almost hundred years the company has its roots in cutting and grinding. Every day around 70 employees work faithful to

the slogan:

„REICHMANN – Out of tradition and passion“

We‘re your partner for perfect grinding.

The trust-based partnership with our suppliers and with our customers is particularly important to us. Therefore we always

look for a solution which perfectly fits to the customer needs. In order to offer our customers an advantage, we are heavily

invested in our Research and Development Team, which is located directly within our company headquarters in Weißenhorn.

The feedback from our customers goes directly back to the R&D department for the development of new machines - to make

your everyday life continuously a little bit better. Our machines are directly manufactured in Weißenhorn and assembled by

specialists – that’s why we can say with pride: our machines are one hundred percent ‘Made in Germany’. The passion of

Reichmann employees is in each machine – from the idea to the construction to the production and delivery – and that’s

what makes us proud! You can feel the passion in every department of the company. Besides the SKI & BOARD TUNING

Division, we also have two other divisions with a long tradition as well:

Grinding, polishing and cut-off machines for the metal manufacturing sector

Specialized grinding and deburring machines for iron foundries

(5)

(6)

The High Quality Tuning from Reichmann

ensures perfect edge precision for your skis

and boards. Due to the HQT-finished

surface the lifetime of the edge stability

increases and the optimized sharpness

provides an optimum turning compliancy

combined with maximum security. The

ceramic discs ensures a precise geometry

on the side edges and the circumferential

polishing wheels are tuning the base edge

to a high-end finishing. They leave the

brand of HQT – the mirror finish.

This icon represents efficient waxing on

the highest level. Due to our continuous

research and development, our waxing

machines are always state-of-the-art.

According to our long-life brushes and the

minimal wax consumption, you will get a

prefect waxing finish with a minimal need

of expendable items. We call this efficient

waxing.

(7)

Belt grinding is a subject on which

Reichmann has worked since 1960. Since

then, belt technology has been constantly

developed and improved. Today you can

choose between numerous belt types which

can be used for different operations. We

offer a wide range of belt qualities - starting

from pre-grinding continuing with polishing.

Have a look on page 74.

We always try to create our machines as

compactly as possible – because space is

money and we know that. Therefore, if you

see this icon, you know that the machine

combines optimal performance within the

smallest amount of space. We call this

Space Wonder.

The structure in the base is the first thing

customers see after a service - no matter

the level of expertise. That‘s why you must

impress your customers and exceed their

expectations. Good referrals equal new

customers. But aside from the visual appeal

of the structured base, the ski or board

functions much better with this finish.

This is where your customer will feel the

difference. With a machine that has a wide

array of possible structures, you are able

to fulfill the customers needs based on any

snow conditions.

(8)

(9)

I N T R O D U C T I O N

to our Reichmann machines

A ski service machine is an investment in your future. To make your dream come true we invest a lot

of passion and experience into our machines. We will support you in any way that we can. You have

enough things to consider and think about and concerns about your machinery shouldn’t be one of

them.

We only use high-quality goods and manufacture almost all of our products in Weißenhorn, Germany.

This allows us to control our quality and standards personally and ensures that only products of the

highest quality find their way into your machine. For the products that we do not build in-house, we

work only with partners who meet our high standards.

Nobody needs a stable machine without technical progress. Therefore, we work together with

national and international partners such as ski and snowboard associations as well as world cup

professionals. With their ideas and our experience we work together for a solution to always make a

better product. Afterwards we will bring it from the world cup directly into your workshop.

(10)

(11)

The Reichmann SF-1 is a grinding robot of unparalleled ability, and was designed to keep up with

today’s higher volume ski rental shops. Especially the newly developed and patented circulation feed

system which enables the combination of rapid and gentle processing of the skis. Highest efficiency

and extraordinary operating comfort are guaranteed by the unique paternoster system with in and

output in pairs. Due to the individual adjusted base grinding, the HQT tuned edges as well as the

perfectly waxing of each ski, we can guarantee each winter sports athlete highest amount of safety

and fun!

CONSISTENT & FAST SERVICE RESULT

Highest efficiency and extraordinary operating comfort are guaranteed by the unique

paternoster system with in and output in pairs. Our customers confirm an output of 82 pairs of

skis per hour which are ready to ski. A maximum output with a minimum effort is guaranteed

due to the ability to put in the skis no matter which size or style.

SF-1

T h e s e r v i c e c e n t e r f o r

(12)

(13)

The newly developed, revolutionary feeding system by Reichmann combines gentle loading

with a constant high output rate. A 12” large, high-resolution touch panel enables simple

and effective operator guidance. The integrated remote diagnostic system guarantee

highest availability of service and continued production. For an optimized result you could

choose whether you need a belt or stone module.

Innovative technology

T e c h n i c a l d a t a

„One-Way“-Transport of the skis with fixation arms. In and output in pairs (up to 22 skis).

Dimensions (L x W x H) in mm / ft 9400 x 2750 x 2500 / 30’10’’ x 9’’ x 8’2’’

Weight in kg / lb 12000 / 26455

Connecting voltage 400 V, 3 PH/N/PE, 50 HZ

Connecting plug CEE 63A 5-pin

Connection power in kW 23

Coolant tank approx. in l / gal 520 / 137

Compressed air connection in bar 6 / 87

Grinding stone in mm / ft Ø 300 x 200 / Ø 11.8’’ x 7.9’’

Sending belt in mm / ft 200 x 1500 / 7.9’’ x 4’11’’

Tuning wheel in mm / ft Ø 250 x 80 / Ø 9.8’’ x 3.1’’

Disc wheel side edge in mm / ft Ø 154 x 25 / Ø 6’’ x 1’’

Control unit SPS with large 12’’ touch screen

Waxing role in mm / ft Ø 162 x 200 / Ø 6.4’’ x 7.9’’

Minimum requirement compressor 250 l / 66 gal tank; 1100 l/min / 291 gpm and dryer

(14)

(15)

SF-4

1-3 Modules

customizable combinations

The Reichmann SF-4 is the youngest member among the service robots.

During the development phase our primary focus was on efficiency, quality as well as

optimum use of space. The result is a service robot adjustable to your needs - with moduls

and options, which set new standards.

STONE MODULE

for ski & boards 350 mm / 1’2’’ grinding stone

STONE MODULE

RACE for ski

2 x 165mm / 6’’ grinding stones

+ 2 dresser

EDGE MODULE

for ski & boards

HQT for side and lower edge

1

2

3

AUTOMATIC

loading and unloading

4960 mm / 16’3’’ length with 1 module 5840 mm / 19’2’’ length with 2 modules 6720 mm / 22’1’’ length with 3 modules

(16)

(17)

The loading and unloading allows you to work efficient and comfortable.

RACE - PACKAGE for stone modules

Cycle time (maximum) 60 ski/h

Profitable with service load per season 1,500 - 25,000

Possible processing of ski with length of 0.9 - 2.15 m / 2’11’’ - 7’1’’

• NC drive of the dresser unit

• Automatic width detection of the ski and adjusting of the

pressure curve on ski width and type

• Racing structure package

OPTIONS

• Automatic drying system of the ski

• Transport system for snowboards

• Automatic filtering system

• Cooling unit

• Automatic balancing of the grinding stone

FACTS

The two 165 mm / 6.5’’ wide grinding stones with matching dressing units enables an efficient processing of ski at the highest level.

RACE - PACKAGE for edge module

• Arbitrary side or base edge angle easily adjustable on the

touch panel

• Variable speed for side and base edge tuning disc ensure

an accurate edge result

• Automatic grinding pressure controll provides a constant

and precise side edge finish

(18)

(19)

The PROFI S200 and PROFI S350 are the structural wonders among our stone grinding machines.

This is a result of close cooperation with different ski producers, snowboard associations, race

departments and world cup specialists. They are equipped with parameterized racing structures for the

Alpine and Nordic sector (S200) or the Alpine and Snowboard sector (S350). A triple jewel and

programmable grinding pressure curve allows precise structures with the PROFI S200/350. Therefore

allowing you to serve your most basic customers to the most elite racers.

REPRODUCIBLE STRUCTURES FOR SPECIALISTS

The conception of both machines has been thought out to the tiniest detail. By the use of our

structure development platform “PatRich” you can create structures effortlessly without any material

wear. The structure library includes all variations for customers of all types.

PROFI S200 / S350

(20)

(21)

Due to the 3-point centering you will get reproducible and precise symmetric structures every time – also by using it split.

The integrated structure consultant makes it easy to find the right structure.

The color 8“ touch-panel enables you (by an integrated structure consultant) to find the

structures that fits to your customer’s needs. There is still enough memory capacity to save your

own structures to adapt to sophisticated target groups.

Furthermore the split structure option of the 200 mm / 7.9’’ or 350 mm / 1’2’’ stone enables a

one-step pre-grinding and finish structure, without wasting time and material.

PROFI S200 / S350

O u r r a c e m a c h i n e s

Dimensions (L x W x H) in mm / ft 1475 x 900 x 1150 /

4’10’’ x 2’11’’ x 3’9’’ 1475 x 900 x 1150 / 4’10’’ x 2’11’’ x 3’9’’

Weight in kg / lb 450 / 992 500 / 1102

Connecting voltage (EU - data) 400 V, 3 PH/N/PE, 50 HZ 400 V, 3 PH/N/PE, 50 HZ

Connecting voltage (US - data) 230 V, 60 Hz, 3 Ph 230 V, 60 Hz, 3 Ph

Connecting plug (distribution only in the EU) CEE 16A 5-pin. CEE 16A 5-pin.

Engine speed stepless adjustable stepless adjustable

Connecting power in kW 5 5

Coolant tank approx. in l / gal 95 / 25 95 / 25

Grinding stone in mm / ft Ø 300 x 200 / Ø 11.8’’ x 7.9’’ Ø 300 x 350 / Ø 11.8’ x 1’2’’

Dressing speed stepless adjustable stepless adjustable

Feed speed stepless adjustable stepless adjustable

stepless adjustable kg / lb 0 - 50 / 0 - 110 0 - 50 / 0 - 110

T e c h n i c a l

d a t a

P R O F I

S 2 0 0

P R O F I

S 3 5 0

(22)

(23)

You will get the best out of your PROFI S200! Next, you need a race feed.

Due to an individual pressure regulation at the feeding wheel you can perfectly adjust to the situation.

Thereby the result of the structure will be more precise and you can offer your customers world cup

level service. You will also get smoother transfers at the varying shapes of the ski bases. Bindings will

be easily avoided with the use of the bride.

Allow yourself and get the most out of your PROFI S200.

RACE FEED

F o r a p e r f e c t r a c e r e s u l t

w i t h y o u r P R O F I S 2 0 0

1041939 Race feed, Aluminium-hub

(24)

(25)

The structure platform PatRich from Reichmann

supports you by developing new structures for your

machines. By changing the parameters you can see

the changes in the structure directly on your screen.

Afterwards you can put in the parameters from the

screen directly into your machines.

There are no limits to your creativity and you can stand

out from your competitors – without any material wear!

Register for free today at:

www.reichmann.com/patrich

PatRich

T h e f r e e o n l i n e s t r u c t u r e

-d e v e l o p m e n t - t o o l

Easy feed of the parameter for the desired structure.

(26)

The new PROFI 4 is a combined stone-belt-tuning machine that fulfills all

wishes regarding equipment repair and ease of operation due to the many

pneumatic

features. With its inline stone and belt the PROFI 4 is a real space saver and

can even be installed directly against a wall. If you choose the machine with

the optional side edge grinding device (87° to 90° angle) you get a central

working station for all required preparation steps for professional ski and

snowboard service.

This machine gives you the opportunity to make a rapid switch between belt

and stone without taking the ski or snowboard out of your hands. By only

pressing a button you can change the feed arm from belt to stone and back

effortlessly. The independent pneumatics accurately adjust the grinding

pressures for stone and belt. The aluminum feed roller is divided into three

parts to compensate convex and concave snowboards.

The new PROFI 4

B e l t - s t o n e - c o m b i n a t i o n f o r s k i s a n d b o a r d s

(27)

The new PROFI 4

B e l t - s t o n e - c o m b i n a t i o n f o r s k i s a n d b o a r d s

Reproducible structures & user comfort

The new 8” color-touch panel is ergonomically designed and located near the stone to enable the

perfect choice when deciding on various structures. The onboard computer has an entire library

of various stored structures and there are structure options for every skier and snowboarder. There

is still enough memory capacity to save your own structures to adapt to sophisticated customers.

Equipped with a 350 mm / 1’2’’ wide stone, the new PROFI 4 can handle skis and snowboards with

ease. Furthermore the split structure option enables a one-step pre-grinding and finish structure,

without wasting time and material.

Optional available with side edge.

With the new ergonomically optimized color touch panel you can operate easily and intuitive.

without side edge with side edge

Dimensions (L x W x H) in mm / ft 2080 x 880 x 1405 / 7’ x 2’11’’ x 4’7’’ 2080 x 1040 x 1405 / 7’ x 3’5’’ x 4’7’’

Weight in kg / lb 700 / 1543 800 / 1764

Connecting voltage (EU - data) 400 V, 3 PH/N/PE, 50 Hz 400 V, 3 PH/N/PE, 50 Hz

Connecting voltage (US - data) 230 V, 60 Hz, 3 Ph 230 V, 60 Hz, 3 Ph

Connecting plug (distribution only in the EU) CEE 16A 5-pin CEE 16A 5-pin

Engine speed (stone unit) rpm stepless stepless

Engine speed (belt unit) rpm (EU - data) 470 / 955 (2-stepped) 470 / 955 (2-stepped)

Engine speed (belt unit) rpm (US - data) 560 / 1145 (2-stepped) 560 / 1145 (2-stepped)

Engine speed (side edge unit) rpm

-- data for EU - 1370data for US - 1630

Connecting power in kW 4.5 4.95

Grinding stone in mm / ft Ø 300 x 350 / Ø 12’’ x 1’2’’ Ø 300 x 350 / Ø 12’’ x 1’2’’

Sanding belt in mm / ft Ø 350 x 1500 / Ø 1’2’’ x 4’11’’ Ø 350 x 1500 / Ø 1’2’’ x 4’11’’

Side edge tuning belt in mm / ft - Ø 20 x 1200 / Ø 0.8’’ x 3’11’’

Dressing speed stepless adjustable stepless adjustable

Feed speed stepless adjustable stepless adjustable

Grinding pressure feed in kg / lb 0 - 70 / 0 - 154 0 - 70 / 0 - 154

(28)

Edge grinding, pre-grinding and structuring with one machine – the new PROFI

B VARIO makes this possible. With the compact grinding machine you need

significantly less working steps and reach high-quality results similar to stone

grinding. Due to the simple construction, the machine is very easy to maintain

and guarantees highest availability at lowest maintenance costs. Especially for a

limited amount of service work the Profi B VARIO with its excellent

price-performance ratio is the optimal solution for a universal application.

REVOLUTIONARY GRINDING TECHNOLOGY

„NEW BASE TECHNOLOGY“

In the new Profi B VARIO specially developed pre-grinding and structuring belts

are used, which achieve an optimized gliding performance of the ski and boards

- comparable to stone grinding results. This is based on the new grinding

technology „New Base Technology“. Thereby, the pre-grinding belt creates a

smooth surface which is perfectly suitable for structuring. With the following

usage of the structuring belt you receive a structuring finish in premium quality.

PROFI B VARIO

A l l - i n - o n e g r i n d i n g m a c h i n e

(29)

PROFI B VARIO

A l l - i n - o n e g r i n d i n g m a c h i n e

Efficient and ergonomic working

Due to the pneumatic pressure regulation and the integrated lifting device for the feed roller, the

grinding pressures can be set even more precisely and the operator has to invest less power.

This enables a faster and fatigue-free working and at the same time ensures a better grinding

result. The pace of the grinding and feed motor is continuously adjustable; the structures can

be chosen according to the different requirements. So the machine is individually customizable

to the specific case of application.

With the intuitively operable touch-panel the user can switch instantly between pre-grinding and structuring. Predestined sequential programs secure consistently good grinding results independent of the user.

Grinding result with the PROFI B VARIO.

Te c h n i c a l

D a t a

4’2’’ x 2’12’’ x 4’7’’ 1280 x 960 x 1405 /4’2’’ x 3’2’’ x 4’7’’

Weight in kg / lb 420 / 926 475 / 165

Connecting voltage (EU - data) 400 V, 3PH/N/PE, 50 Hz 400 V, 3PH/N/PE, 50 Hz

Connecting voltage (US - data) 230 V, 1PH/N/PE, 60 Hz 230 V, 1PH/N/PE, 60 Hz

Connecting plug (EU) CEE 16A 5-pol. CEE 16A 5-pol.

Engine speed (belt unit) 1/min stepless stepless

Engine speed (side edge unit) 1/min 1380

Connecting power in kW 3.5 4

Sanding belt in mm / ft 350 x 1500 / 1’2’’ x 4’11’’ 350 x 1500 / 1’2’’ x 4’11’’

Side edge tuning belt in mm / ft 20 x 1200 / 0.8’’ x 3’11’’

Feed speed stepless stepless

Grinding pressure feed in kg / lb 0 - 60 / 0 - 2 0 - 60 / 0 - 2

PROFI B VARIO

with feed PROFI B VARIOwith side edge and feed

(30)

The PROFI B350 is a heavy-duty, efficient, adaptable machine, which can easily

serve alpine ski snowboard producers as well as service workshops. It was

designed with a particular focus on robust construction and as a supplement to

our stone grinding PROFI S line. Due to its feed it is a central processing station

for all required regular work steps for the tuning of skis and snowboards. It fits

and works within the smallest spaces, and can be equipped with an optional

edge tuning module. You can also get it as PROFI B350 Professional with

pneumatic adjustable grinding pressure and operate lifting device.

PROFI B350 PROFESSIONAL

As our robust machines are used for the production of ski and snowboards, the

PROFI B350 is also available in a Professional version. The PROFI B350

Professional also utilizes a step-less feed rate, a more powerful motor and a

manual belt setting to be able to use higher grinding pressures. The PROFI

B350 Professional isn’t standardly equipped with a side edge in contrast to the

PROFI B350. A great number of snowboard and ski producers also take the

PROFI B350 for the continuous operation.

PROFI B350

B a s e t u n i n g f o r s k i s a n d s n o w b o a r d s

(31)

Belt grinding – versatile application

The PROFI B350 is used for removal of contaminates and for pre-grinding of the base flat. The

machine is also used for the finish-grinding due to the application of scotch and corkbelt. The

two speeds of the grinding motor facilitates both pre and finish grinds, plus appropriate

concentration of abrasion. The machine fits well next to the PROFI S stone grinder making for

shorter work movements and an organized work space.

T e c h n i c a l

d a t a

The PROFI B350 is delivered with side edge in standard.

Optional with pneumatically withdrawal of the feed available.

4’10’’ x 2’11’’ x 3’9’’ 1475 x 900 x 1150 /4’10’’ x 2’11’’ x 3’9’’ 1475 x 900 x 1150 /4’10’’ x 2’11’’ x 3’9’’

Weight in kg / lb 510 / 1124 510 / 1124 500 / 1102

Connecting voltage (EU - data) 400 V, 3PH/N/PE, 50 Hz 400 V, 3PH/N/PE, 50 Hz 400 V, 3PH/N/PE, 50 Hz

Connecting voltage (US - data) 230 V, 60 Hz, 3Ph - 230 V, 60 Hz, 3Ph

Connecting plug (distribution only in the EU) CEE 16A 5-pin. CEE 16A 5-pin. without

Engine speed (belt unit) 1/min (EU - data) 470/955 (2-stepped) 470/955 (2-stepped) 470/955 (2-stepped)

Engine speed (belt unit) 1/min (US - data) 565/1160 (2-stepped) - 565/1160 (1-stepped)

Engine speed (side edge unit) 1/min EU - 1350

US - 1630 EU - 1350- -

-Connecting power in kW 3.7 3.7 4.7

Coolant tank approx. in l / gal 95 / 25 95 / 25 125 / 33

Sanding belt in mm / ft 350 x 2000 / 1’2’’ x 6’7’’ 350 x 2000 / 1’2’’ x 6’7’’ 350 x 2000 / 1’2’’ x 6’7’’ Side edge tuning belt in mm / ft 20 x 1200 / 0.8’’ x 3’11’’ 20 x 1200 / 0.8’’ x 3’11’’

-Feed speed 1-stepped 1-stepped stepless

Grinding pressure feed in kg / lb 20 - 40 / 44 - 88 20 - 40 / 44 - 88 0 - 70 / 0 - 154

PROFI B350

with feed and side edge

PROFI B350

with feed, side edge and pneumatically withdrawal

PROFI B350 PROFESSIONAL

with feed, pneumatically withdrawal, pneumatically grinding pressure; without side edge

(32)

The SN 350 PROFI is a heavy duty, efficient and adaptable belt grinding

machine, which can easily serve alpine ski or snowboard manufacturers as

well as service workshops. The mobility of this machine makes it ideal for any

workshop regardless of size.

It is a central processing station for all required basic work steps for the tuning

of ski and snowboards and comes with an optional edge tuning module or

feed. That’s why a great number of snowboard manufacturers use the SN 350

PROFI for production of their snowboards.

SN 350 PROFI

B e l t t u n i n g m a c h i n e w i t h f r e e d o m o f c h o i c e

(33)

SN 350 PROFI

B e l t t u n i n g m a c h i n e w i t h f r e e d o m o f c h o i c e

Various options:

T e c h n i c a l

d a t a

With feed and side edge With feed

SN 350 PROFI SN 350 PROFI A

with side edge stop

SN 350 PROFI K

with side edge

SN 350 PROFI V

with feed

SN 350 PROFI VK

with feed and side edge

3’9’’ x 2’4’’ x 3’ 1150 x 700 x 1300 / 3’9’’ x 2’4’’ x 4’3’’ 1455 x 925 x 915 / 4’9’’ x 3’ x 3’ 1150 x 700 x 1300 /3’9’’ x 2’4’’ x 4’3’’ 1455 x 925 x 1300 / 4’9’’ x 3’ x 4’3’’

Weight in kg / lb 275 / 606 285 / 628 375 / 827 375 / 827 475 / 1047

Connecting voltage (EU - data) 400 V, 3PH/N/PE, 50 Hz 400 V, 3PH/N/PE,50 Hz 400 V, 3PH/N/PE,50 Hz 400 V, 3PH/N/PE,50 Hz 400 V, 3PH/N/PE, 50 Hz

Connecting voltage (US - data) 230 V, 60 Hz, 3 Ph 230 V, 60 Hz, 3 Ph 230 V, 60 Hz, 3 Ph 230 V, 60 Hz, 3 Ph 230 V, 60 Hz, 3 Ph

Connecting plug (distribution only

in the EU) CEE 16A 5-pin. CEE 16A 5-pin. CEE 16A 5-pin. CEE 16A 5-pin. CEE 16A 5-pin.

Engine speed (belt unit) rpm EU - 470 / 955 (2-stepped)

US - 560 / 1145 (2-step.) EU - 470 / 955 (2-stepped)US - 560 / 1145 (2-step.) EU - 470 / 955 (2-stepped)US - 560 / 1145 (2-step.) EU - 470 / 955 (2-stepped)US - 560 / 1145 (2-step.) EU - 470 / 955 (2-stepped)US - 560 / 1145 (2-step.)

Engine speed (side edge unit) rpm - - EU - 1380

US - 1630 - EU - 1380US - 1630

Connecting power in kW 3.0 3.0 3.45 3.25 3.7

Coolant tank approx. in l / gal 55 / 14 55 / 14 55 / 14 55 / 14 55 / 14

Sanding belt in mm / ft 350 x 2000 / 1’2’’ x 6’7’’ 350 x 2000 / 1’2’’ x 6’7’’ 350 x 2000 / 1’2’’ x 6’7’’ 350 x 2000 / 1’2’’ x 6’7’’ 350 x 2000 / 1’2’’ x 6’7’’

Side edge sanding belt in mm / ft - - 20 x 1200 / 0.8’’ x 3’11’’ - 20 x 1200 / 0.8’’ x 3’11’’

Grinding pressure feed in kg / lb - - - 20 - 30 / 44 - 66 20 - 30 / 44 - 66

(34)

The HQT edge grinding machine DTS-U Pro is the leader among edge

polishing service machines. The DTS-U Pro meets the highest requirements

in the ski and snowboard edge tuning industry made possible with HQT

technology. Through a perfect interaction between side edge and base edge

tuning devices, a burr-free ski or snowboard can be achieved in only one

step.

EFFICIENT HQT EDGE TUNING

You will get a refined edge surface and long edge endurance in less than 30

seconds. The side and base edges will be gently and optimally processed.

The results are skis and boards directly out of the machine and ready to ski.

DTS-U Pro

H i g h - Q u a l i t y - Tu n i n g m a c h i n e

(35)

HQT EDGE TUNING

The benefits of the HQT edge tuning technology provides better carving for you and your

customer in any snow conditions. The result will convince everyone - from beginners to experts.

Space saving storage in the summer by

disassembling some elements.

In a few seconds the DTS-U Pro will be ready to use.

Dimensions (L x W x H) in mm / ft - expanded

disassembled 3350 x 900 x 1625 / 10’12’’ x 2’11’’ x 5’4’’1450 x 900 x 1625 / 4’9’’ x 2’11’’ x 5’4’’

Weight in kg / lb 620 / 1367

Connecting voltage (EU - data) 400 V, 3 PH/N/PE, 50 HZ

Connecting voltage (US - data) 230 V, 60 Hz, 3Ph

Connecting plug (distribution only in the EU) CEE 16A 5-pin.

Engine sped rpm EU - 1350

US - 1630

Compressed air connection in bar 6

Tuning discs in mm / ft Ø 250 x 55 / Ø 9.8’’ x 2.2’’

Disc wheel side edge in mm / ft Ø 154 x 25 / Ø 6.1’’ x 1’’

Feed speed variable

(36)

The steel edge finish machine KFM-U ensures perfect base edges and

optimum rotation of Alpine skis for the highest customer satisfaction. This

machine is the basis for the edge tuning and is therefore a must for each ski

service workshop. This versatile and efficient machine produces outstanding

edge results within the smallest place. To be more flexible it is available with a

side edge polish or grinding unit and is always delivered as mobile version.

KFM-U

H i g h q u a l i t y e d g e t u n i n g

(37)

KFM-U

H i g h q u a l i t y e d g e t u n i n g

Perfect edge sharpness for base edges

The KFM-U base finishing machine gives base edges a mirrored finish for easy turning and better

edge grip. The circumferential wheel tunes the base edges without rounding off the edges or

generating burrs, thus both base edges can be polished and beveled in one step. Thanks to the

automatic feed wheel, as well as the mechanical lifting device the KFM-U achieves consistent

results.

That’s how an edge looks like without polish – you can see fine drag lines.

That’s how an edge looks like after polishing – you can see a surface without any weak points for external influences – the so called „mirror finish“.

Dimensions (L x W x H) in mm / ft 850 x 670 x 1320 / 2’9’’ x 2’2’’ x 4’4’’

Weight in kg /lb 280 / 617

Connecting voltage (EU - data) 400 V, 3 PH/N/PE, 50 HZ Connecting voltage (US - data) 230 V, 60 Hz, 3Ph

Connecting plug CEE 16A 5-pin

Engine speed rpm 910

Connecting power in kW 2.01

(38)

The steel edge sharpening machine KSM is the entry into the edge grinding

and delivers you a precise side edge processing within the smallest place. It

delivers angle adjustment from 86 to 90°C (187 to 194 °F) of side edge angle

and has an optional double support roller for snowboards available. You can

also get this machine with a base edge grinding device and a solid machine

stand as well.

KSM

P r e c i s e s i d e e d g e t u n i n g

(39)

The standard for your workshop

Optional double support roller for ski and boards.

Optional tuning device to grind the base edge.

Connecting plug (distribution only in the EU) CEE 16A 5-pin

Enging speed rpm EU - 1375

US - 1630

(40)

The BWM 350 Pro is the perfect solution for customers looking for premium

waxing result. The warm up period is very quick and the hot air supply offers

an automatic temperature regulation resulting in a constant waxing result.

EFFICIENT WAXING

The waxing belt is on the one hand cheap and on the other hand effective,

because the steel tension pulley allows for the ski or snowboard to maintain

perfect contact with the wax roller from tip to tail and avoid the rounding of

the edges. The belt allows for use of any wax. The direct drive, waxing belt

and a special developed texturing-roller guarantees a running smoothness,

low operating costs and an optimal waxing result. Efficient handling is

provided due to an easy to change belt change, and easy to clean.

BWM 350 Pro

B e l t w a x i n g m a c h i n e f o r t u n i n g e x p e r t s

(41)

BWM 350 Pro

B e l t w a x i n g m a c h i n e f o r t u n i n g e x p e r t s

Outstanding waxing result &

minimal consumption

The BWM 350 Pro was designed for each waxing emergence up to continuous operation and

will save you a lot of time and money due to minimal wax consumption and long lasting brush.

Also qualified for every wax emergence - even for continous use - a constant companion in a

small place with low consumption.

Easy to clean due to the easy remove of the cover.

Now available with a horse hairbrush. For more information look at the accessories on page 78 / 79.

Connecting plug (distribution only in the EU) CEE 16A 5-pin

Engine speed rpm 560

Operating temperature in °C / °F 90 / 194

Waxing belt range in mm / ft 350 / 1’2’’

Structure brush range in mm / ft 350 / 1’2’’

(42)

A customizable waxing machine – how does it work?

Easy – with our individual adjustable heating aggregate! With the new BWM

350 C Digital from Reichmann you now have the possibilty to adjust the

temperature individually to your needs between 80 and 100° C (176 and

212 °F) according to your wax and thereby keeping the machine constantly at

the selected degree - no matter what temperature your shop has.

This regulation enables energy efficient waxing because the heating aggregate

only switch on if it’s really needed. You can see the increase of the

temperature directly on the digital display.

BWM 350 C Digital

T h e p r e c i s e l y a d j u s t a b l e w a x i n g m a c h i n e

(43)

The optional stand of the BWM 350 C Digital is light and offers a lot of space for your waxes – so you have everything required on hand.

Choose your temperature and see how the temperature rises directly on the display.

BWM 350 C Digital

T h e p r e c i s e l y a d j u s t a b l e w a x i n g m a c h i n e

Efficient waxing

Due to the 230 V capacity you are able to minimize energy consumption. The specially developed

waxing brush guarantees an optimized base finish and polishes a thin layer of wax into the base

exposing base structure and edges. By default the BWM 350 C Digital comes as a bench top unit

and there is an optional stand with casters if desired. Also the cleaning is made easy by opening

the lid in the front part to access the inside of the machine.

Gewicht in kg / lb 66 / 146

Connecting voltage (EU - data) 230 V AC 1 PH Connecting voltage (US - data) 230 V, 60 Hz, 1Ph

Connecting plug Schuko plug

Engine speed rpm EU - 560

US - 672

Operating temperature in °C / °F 90 / 194

(44)

(45)

Waxing on world cup level is done easily with the infrared waxing

machine from Wax Future. The infrared heating lamp ensures a gentle

but nevertheless intense treatment - the base is able to absorb more

wax, therefore the wax can penetrate further and lasts longer.

With the help of the Wax Future Wall Speed waxing of your ski and

snowboards can be done perfectly with minimum effort and space. It

can be direcly mounted on the wall and thus saves you valuable floor

area.

By using the Wax Future Wall Speed, you can choose between a variety

of different programs and speed levels - so it fits every demand.

Moreover, the two infrared lamps can be switched on and off according

to your specific needs by simply pushing a button. Therefore, the WAX

FUTURE WALL SPEED reaches an output of up to 40 pairs of skis per

hour.

WAXFUTURE

W A L L S P E E D - t h e o r i g i n a l !

The two infrared lamps can be switched on and off separately - according to your specific needs.

The wax penetrates further in the ski base and thus enables a finish at worldcup-level.

(46)

The POLYMAT automatically fills in damages in the base of skis or snowboards

- and is the optimum basis for excellent ski service. Only the damaged places

will be filled in with the base material. The POLYMAT 1 has been developed

for the repairing of one ski, whereas the POLYMAT 2 has been developed for

the repairing of one pair of skis or one snowboard. There‘s no time intensive

prep work required and base grinding is not needed. The POLYMAT

guarantees efficient and material saving work.

POLYMAT 1/ POLYMAT 2

S k i a n d S n o w b o a r d b a s e r e p a i r m a c h i n e

(47)

POLYMAT 1/ POLYMAT 2

S k i a n d S n o w b o a r d b a s e r e p a i r m a c h i n e

The POLYMAT 2 repairs two skis in one progress – so you can save time.

The POLYMAT could also be placed on the working bench.

T e c h n i c a l

d a t a

Dimensions (L x W x H) in mm / ft Stand design Table design 2530 x 500 x 1400 / 8’4’’ x 1’8’’ x 4’7’’2530 x 380 x 800 / 8’4’’ x 1’3’’ x 2’7’’ 2530 x 500 x 1400 / 8’4’’ x 1’8’’ x 4’7’’2530 x 380 x 800 / 8’4’’ x 1’3’’ x 2’7’’ Weight in kg / lb Stand design Table design 85 / 18770 / 154 100 / 220 85 / 187

Connecting voltage (EU-data) 230 V, 1 PH/N/PE, 50 HZ 230 V, PH/N/PE, 50 HZ

Connecting voltage (US-data) 230 V, 1 PH/N/PE, 60 HZ 230 V, 1 PH/N/PE, 60 HZ

Connecting plug Schuko plug 16A Schuko plug 16A

Engine speed rpm 1360 / 3.78 1360 / 3.78

Connecting power in kW 0.7 1.35

Operating temperature in °C / °F 280 / 536 280 / 536

Efficient working

POLYMAT 1 & 2 impress with their speed and minimal warm-up time. The automatic

temperature control and optimized repair speed arrange ensures an odorless and a permanent

connection of base and repair material. With the automatic base repair you will gain optimized

results and excellent quality. Moreover you will shorten your service processes and save time

and payroll. A door at the front enables you to clean the machine easily.

(48)

You will get a well-organized working station with the Reichmann

multifunctional workbench, which is a must-have for each service workshop.

The workbench is designed for one or two workplaces and will be delivered as

complete system including ski and board clamping devices, 24 classical load

devices, drawers, holding devices, lighting and power outlets and could

possibly be extended with a POLYMAT 1 or 2. The optional overhead feature is

also separately available.

Multifunctional workbench

P e r f e c t l y o r g a n i z e d w i t h i n y o u r d a i l y

s e r v i c e r o u t i n e

(49)

P e r f e c t l y o r g a n i z e d w i t h i n y o u r d a i l y

s e r v i c e r o u t i n e

Workshop equipment Organization

Components

•

Universal vise for binding adjustment for 2 skis or 2 snowboards

•

2 adjustable supports for skis and snowboards

•

Overhead and 110 V AC outlet(s)

•

2 load devices with each 12 boxes for screws, hole plus, etc.

•

Tool brackets to hold and organize tools

•

Clamping device for binding fitting (not possible with

connection to POLYMAT 1 + 2)

• Drawer

A lot of space inside of the drawer.

Even more space due to the 24 compartments.

Dimensions (L x W x H) in mm / ft 2200 x 900 x 1900 / 7’3’’ x 2’11’’ x 6’3’’ Working height approx. in mm / ft 800 / 2’7’’

Space requirement approx. in qm / ft² 2 / 21.5

(50)

The Reichmann ski and snowboard boot cleaner is perfectly suitable for ski rental

shops and the hotel industry in ski areas. You’ll be able to offer your customers

prepaired and clean equipment. Even the strongest contaminations like on the sole

or the side of the boots can easily be removed just with a soft pressure within

seconds and the used water can be released. So you can save a lot of time and

money due to the pair-wise cleaning. The value and functionality of your equipment

will be improved and rental and customer boots will last a long time.

Ski and Snowboard

boot cleaner

R a p i d c l e a n i n g f o r y o u r r e n t a l s h o p

(51)

Gentle cleaning of the bottom and the side.

Practical storage area and easy to move because of the rollers.

Connecting voltage 400 V, 3 PH/N/PE, 50 Hz

Connecting plug CEE 16A 5-pol.

Water tank in l / gal 50 / 13

With the purchase of this machine you will generate many customer benefits and increase the

trust of the customers in the hygiene of your equipment.

We recommend the usage of our Protect 50 for the usage of this machine. Protect 50 protects

the boots and the machine of corrosion. We recommend a concentration of min. 2%

(refractometer scale 1.5). One liter (0.3 gal) of the product fits to a new filling of the water tank.

I t e m - N o .

D e s c r i p t i o n

1049517 Corrosion protection for Ski boot

(52)

Workshop equipment Machines

Compressors / dryer

COMPRESSOR LFX 2.0 / LFX 2.0 - 100

COMPRESSOR FINI - The alternative for LFX

•

For non-stop operation with single machinery

•

Nearly maintenance free operation

•

Standard tight construction and quiet operation

•

One-cylindrical, moveable piston compressor

•

For non-stop operation with single machinery

•

Nearly maintenance free operation; guaranted up to 100 % oil free

•

Standard tight construction and quiet operation (62 till 64 dBA)

•

One-cylindrical, moveable piston compressor

Item number 1014810 Dimensions (L x W x H) in mm / ft 520 x 440 x 818 / 1’8’’ x 1’5’’ x 2’8’’ Tank in l / gal 20 / 5 Performance in l/min / gpm 150 / 39.6

Item number 1048806 Dimensions (L x W x H) in mm / ft 1150 x 480 x 885 / 3’9’’ x 1’7’’ x 2’11’’ Tank in l / gal 50 / 5 Performance in l/min / gpm 310 / 81.9

(53)

COMPRESSOR RSKD-COMPACT

REFRIGERANT TYPE DRYER

This dryer is perfectly suited for fulfilling the requirements of industrial air conditions. Due to the drying system the moisture of the compressed air is segregated as

condensation is automatically bled off. This will increase the life span of the pneumatic cylinder and valves. It will improve work conditions, thus improving your work.

•

For non-stop operation of SF-2 Pro and SF-3

•

Nearly maintenance free operation; guaranted up to 100 % oil free

•

Standard tight construction and quiet operation (62 till 64 dBA)

Item number 1038585

Dimensions (L x W x H) in mm / ft 1002 x 458 x 926 / 3’3’’ x 1’6’’ x 3’

Tank 90 l / 23 gal

4.0 - 7.5 bar / 58 - 108.8 PSI with dryer

Performance 400 - 600 l/min / 106 - 159 gpm;

nominal power 4.0 kW; 400 V - 16 CEE plug

Item number 1055504

Type CQ 0020 AB

Volume rate m³/h / gpm 20 / 88

Volume rate m³/min 0.33 / 87

Pressure decrease in bar 0.15

Electrical connection V/Ph/Hz 230/1/50-60

Power consumption in kw 0.16

Volume of cooling air m³/h / gpm 200 / 881

Compressed air supply BSP 3/8“

(54)

(55)

This cooling coil is easy to integrate into the water tank. The water will be cooled down to a

temperature of 7 – 10° C (45 - 50° F)*.

EFFECTS:

• Constant and precise structures due to the minimal generation of heat

• Higher performance by higher application parameters

• Grinding emulsion is easier on the skin

• Longer service life of the grinding emulsion

*

Depending on the performance and room temperature

COOLING

F o r p e r f e c t r a c e r e s u l t s

I t e m - N o .

D e s c r i p t i o n

M a c h i n e

1048894 1055633

Coolant system with 3 m / 9’10’’ Flex hose; 4 KW

Coolant system with 3 m / 9’10’’ Flex hose; 2 KW

SF-1, SF-3

PROFI 4, PROFI S200, PROFI S350

(56)

(57)

To get through the season without worry, and to avoid unnecessary future maintenance and costly

downtime, summer machine maintenance is indispensable. That’s why we recommend that you

schedule a machine inspection right after the winter season. Our technician will check your

machines and make sure that they are in optimum condition for the next season.

Our service inspection includes among other things:

• Check and measure discs, stones, diamonds and belt control

• Oil and lube all mechanical and pneumatic elements

• Check, replace or refill oil levels (motors are maintenance-free)

• Check/ replace general control and function of all necessary components or wearing parts

SERVICE CONTRACT

M o r e s e c u r i t y f o r t h e n e x t s e a s o n

Inspection fee rates depend on the quantity and type of machines and the recommended service(s)

in accordance with our maintenance schedules. Parts demonstrating excessive wear will be replaced

and charged separately. Travel and accommodation expenses for our service technicians are

included in our service contract.

(58)

(59)

The machine and its construction is only one part of success – maintenance is the other. For optimal

care of your machine it is very important to use the right accessories. It is best to use original

accessories to ensure that the quality satisfies your requirements.

The accessories are perfectly matched to your machines. Accessories for the handy treatment of

skis, boards or bindings have been improved to meet the standards of your repair shop.

In this catalogue you will find only high quality select products that will provide you daily support.

Often it is the small changes that make a huge difference.

ACCESSORIES

(60)

Water-soluble and free of mineral oil coolant with long endurance and stable ph-value. Reliable protection against corrosion for your machine and good washing effect; high removal rate; mixture of components of water: 3:100; reading value on the refractrometer: 2

10 kg / 22 lb bottle.

SPARE ROLL FOR

PAPER-RACK & WALL BPAPER-RACKET

GRINDING EMULSION

HAND REFRACTOMETER

CORUNDUM - GRINDING

STONE

For measuring coolant ratio mixture. Helps you to save coolant, repair costs and your time.

Attention: Mind the conversion factor. Concentration in % = factor of refractometer x 2.7

For breaking of sanding belts.

MACHINE CLEANER

Sp e cial cl e an e r w i th p r o t e c ti o n agains t c o r r o si o n ; c o m e s in 5 l / 1. 3 gal sp r ay b o t tl e .

CERAMIC SCRAPER

600 m / 1969’ long; 24 cm / 9’’ width; double-ply.

7 5 0 3 3 0

I t e m - N o .

I t e m n o .

7 5 0 3 3 1

I t e m - N o .

1 0 2 8 1 4 5

I t e m - N o .

7 5 0 2 5 0

P lan e s th e s t o n e and av o ids g r ain t r ack s in b as e s .

1 0 0 3 4 9

I t e m - N o .

7 5 0 3 4 5

1 2 1 2 1 2 1 2

(61)

DISINFECT PLUS

SPRAY PAINT

SERVICE GLOVES

For refinishing defects in paint work. Perfect wet grip gloves; they are also resistant to cutting and emulsion; Packaging unit (PU): 1 Pair of gloves.

Perfectly cared ski boots are a must-have for every rental shop. But to keep the hygiene level high when often being used, only the right disinfection emulsion can help. Disinfect Plus in Combination with fresh air lemon is an invincible combination for your rental shop! Ratio of mixture: 1l / 0.3 gal for approx. 100l / 26.4 gal freshening cycles. (10ml / 0.003 gal mixture to 1l / 0.3 gal water).

1 0 2 2 3 1 0

P r i c e

/ I t e m

2 0 5 , - E U R

I t e m - N o .

1 0 1 2 2 6 8

I t e m - N o .

7 5 0 3 7 4

7 5 0 3 7 8

I t e m - N o .

FRESH AIR LEMON

1 0 2 2 3 0 9

I t e m - N o .

F o r r e n t al and d e p o t s y s t ems ; P lus sp r ay b o t tl e s ; Ra ti o o f mi x tur e : 1l / 0 . 3 gal f o r app r o x . 2 0 0 l / 52 . 8 gal f r e sh e ning c y cl e s ( 5ml / 0 .0 01 gal mi x tur e t o 1l / 0 . 3 gal w a t e r ) .

1 0 1 2 2 7 2

I t e m - N o .

7 5 0 3 7 6

I t e m - N o .

Reichmann blue : 400 ml / 0.1 gal

Anthracite: 400 ml / 0.1 gal Size: 9 Size: 10 Size: 8

F u l l e f f e c t i v e n e s s i n o n l y 3 0

s e c o n d s

E l i m i n a t e s s m e l l a n d r e f r e s h e s

t h e f o o t

S a f e o n t h e s k i n a n d p r o v e d b y

t h e f e d e r a l h e a l t h o f f i c e a s a

p h a r m a c e u t i c a l .

1 2 1 2 1 2 1 2

(62)

Easy to use. Keeps your machine running smoothly.

BRAKE RETAINER RUBBER

BAND

ONE-HAND GREASE GUN

Substitute for vacuum suction plate ; packaging unit: 2 pieces.

For SF-2 & SF-2 Pro

OIL CARTRIDGE

Wa t e r- r e sis t an t sp e cial o il f o r th e o n e - hand g r e as e gun.

red

Resistant to emulsion. Packaging unit: 200 pieces.

1 0 0 3 4 5

I t e m - N o .

7 5 0 2 8 9

I t e m - N o .

1 0 2 1 3 4 3

1 0 0 8 9 4 5

I t e m - N o .

For tip or tail (year of construction (YOC): 05/2010); existing of four different suction plates.

VACUUM-SUCTION PLATE for SF-2 Pro

VACUUM PAD

I t e m - N o .

B l a d e

1035550 1037612 1037613 1027516 Wide, oval - 43 x 83 mm / 1.7’’ x 3.3’’

For nordic ski - 30 x 110 mm / 1.2’’ x 4.3’’ Round Ø 60 mm / 2.4’’ Duo, narrow - 30 x 110 mm / 1.2’’ x 4.3’’

I t e m - N o .

S k i t a i l

1038604 1038606 1038605 1038603 1 2 1 2 1 2 1 2 2 1 1 1 1 1 Wide, oval - 43 x 83 mm / 1.7’’ x 3.3’’

For nordic ski - 30 x 110 mm / 1.2’’ x 4.3’’ Round Ø 60 mm / 2.4’’

Duo, narrow - 30 x 110 mm / 1.2’’ x 4.3’’

Workshop Equipment

Consumables

Spare & wear parts

ANTI-SLIP PAD

1 0 0 9 6 2 6

I t e m - N o .

Self-adhesive for feed wheel pedal; 1m long; black

BRAKE RETAINER RUBBER

BAND

blue - FREERIDE

Resistant to emulsion. Packaging unit: 200 pieces.

1 0 5 9 6 1 4

I t e m - N o .

(63)

For all service machines; to be cut according to the required length. The filter sock has to lay over the filter paper and the down under laying micro filter mat.

20m / 66’ roll packed in a foil.

FILTER PAPER ROLL

FILTER SOCK

FEEDING RUBBER RINGS

MICRO FILTER MAT / PU 5 pieces

I t e m - N o .

M a c h i n e

1031951 SF-2 Pro

DTS-U Pro with inserted, light grey tank DTS-U Pro with moveable, anthracite tank, PROFI B VARIO

KSM KSM-F

KFM-U, KFM-US, KFM-UK SN 350 Profi, ESM Junior PROFI S200; PROFI S350, B350 PROFI S150 PROFI 4

1 0 2 9 0 6 6

I t e m - N o .

4 0 0 6 0 4

I t e m - N o .

SF-3

1 0 3 8 4 3 8

I t e m - N o .

SF-1 & SF-4 Special filter material

1m / 3’3’’ wide - 50 running meters / 164’

Special filter material

1m / 3’3’’ wide - 50 running meters / 164’

1 0 0 5 2 8 3

I t e m - N o .

1 0 0 0 7 5 6

I t e m - N o .

White

Slotted spare rubber rings

Red

Slotted spare rubber rings

For all service machines with feed wheel – for better grip during the grinding.

For all service machines. The filter paper has to lay between the filter sock and the micro filter mat for optimal filtration resulting in a cleaning running machine.

1024839 1030107 1026008 1026004 1007026 1009039 1031950 1029322 1034020 1042911

(64)

For two skis or one board. Every shape of ski will be secured without any issue. Includes the adapter enlargements for boards.

DOUBLE CLAMP

PRO-UNIVERSAL

SKI SUPPORTS

One set with rail and rest. Adjustable in length or height.

Clamps for fast and easy binding installation of downhill and nordic skis.

For two skis or one board. Ski supports adjustable in length and height. Suitable for ski with high sidewalls. Together with the Universal ski clamp S3-Multi every shape of ski will be tightened and secured without any problem.

7 5 0 3 0 7

I t e m - N o .

7 5 0 3 4 4

I t e m - N o .

7 5 0 3 0 8

I t e m - N o .

7 5 0 0 6 0

UNIVERSAL-

SKI CLAMP S3-Multi

CLAMP

for binding adjustment

(65)

Lightweight eloxadized aluminum. Low abrasion of anti-slip surface due to special coating.

DOWNHILL SKI, ALUMINIUM

Lightweight eloxadized aluminium. With midpattern buffer. Low abrasion of anti-slip surface due to special coating. No pseudo boot for fixation on the binding necessary.

For Ski up to 1m / 3’3’’ Lightweight eloxadized aluminium.

With midpattern buffer. Low abrasion of anti-slip surface due to special coating. No pseudo boot for fixation on the binding necessary.

1 0 2 6 6 4 9

I t e m - N o .

1 0 2 6 2 4 4

I t e m - N o .

1 0 4 7 7 0 8

1 0 3 1 9 5 4

I t e m - N o .

NORDIC SKI, ALUMINIUM

CHILDREN SKI, ALUMINIUM

DOWNHILL SKI, CARBON

NORDIC SKI, CARBON

TEENAGE SKI, ALUMINIUM

Feathery. With midpattern buffer; For fixation on the binding. Feathery. With midpattern buffer.

No pseudo boot necessary

1 0 3 1 9 5 3

I t e m - N o .

Lightweight in eloxadized aluminium. With midpattern buffer. Low abrasion of anti-slip surface due to special coating. No pseudo boot for fixation on the binding necessary.

For Ski from 1m - 1.3m / 3’3’’ - 4’3’’

1 0 4 3 9 8 5

I t e m - N o .

1 2 1 2 3 4 6 6 5 5 3 4

B I N D I N G B R I D G E S

(66)

D R E S S I N G D I A M O N D

for all structures

R H O M B O I D A R R A N G E M E N T O F P I N E S

The rhomboid arrangement of the pins has the effect of

more exact and sharper structure results. With

rhom-boid dressing diamonds the cutting is more flat and

40% broader as the pin intensity itself. (For example:

pin intensity: 0.6 mm = 0.7 mm profile width /

0.02’’ = 0.03’’ profile width).

The dressing diamonds are used to bring the desired structure to the stone. Important: The finer the pin the finer the

structure. The whole picture of the structure comes from the arrangement of the diamond pins (rhomboid or parallel) and the

dressing parameters.

The advantage of our synthetic diamonds is the consistency of the defined structures, and higher service life because of their

hard diamond pins. For the right dressing parameter and for developing your own structures, we provide you the structure

development online platform, called PatRich at www.reichmann.com/patrich.

PA R A L L E L A R R A N G E M E N T O F P I N S

With an arrangement of parallel diamond pins a

u-shaped profile evolves with precise cutting width

and large-scaled structures. Therefore a diamond with

parallel arrangement is perfect for fine structuring.

(67)

I t e m - N o .

A r r a n g e m e n t o f p i n s D i m e n s i o n

1014936 1025477 1026957 1048807*

RHOMBOID RHOMBOID RHOMBOID RHOMBOID

0.6 mm / 0.024’’ 0.6 mm / 0.024’’ 0.4 mm / 0.016’’ 0.8 mm / 0.031’’ SF-1 SF-3 SF-2 Pro (from 2012) SF-2 / P ro (until 2011) PROFI 4 (from 2014) PROFI S350 PROFI 1 - 4 (until BJ 2013) PROFI S150 PROFI S200 TSM (TSM-S-V,

TSM-E-Multi), ESM Junior RS 2000

x

M a c h i n e 1031545 1048808 PARALLEL PARALLEL 0.4 mm / 0.016’’ 0.6 mm / 0.024’’

* only for pre-grinding

x

(68)

(69)

G R I N D I N G S T O N E S

top in quality

Reichmann grinding stones are perfectly matched to your needs. For a better orientation we have packaged the

stones into four categories. On the next double pages you will find the dresser which is paired with the right

stone. Here you will find the right combination.

A L L R O U N D

High efficiency and structure quality for all

Alpine and Nordic needs.

A L P I N E S T R U C T U R E

Best performance with focus on structure variation

and slide property for Alpine.

A L P I N E P R E - G R I N D I N G

N O R D I C

Best performance with focus on structure variation

and slide property. Excellent structure quality

because of the stability of the edging inlet.

Best performance, optimized quality and abrasion

performance due to the stability of the edging inlet.

Removal Polish Flattening Structuring Removal Polish Flattening Structuring

60 %

100 %

75 %

50 %

100 %

50 %

100 %

75 %

100 %

(70)

GRINDING STONES: TOP IN QUALITY

M a c h i n e

D i m e n s i o n

I t e m - N o .

A p p l i c a t i o n R e c o m m e n d a t i o n

d r e s s i n g

d i a m o n d

p . 6 7

SF-1 Ø 300 mm; B = 200 mm / Ø 11.8’’; B = 7.9’’ 1036075 ALPINE STRUCTURE Structure diamond: 1048808

1040505 ALPINE PRE-GRINDING Pre-grinding diamond: 1048807

SF-3 2S Ø 300 mm; B = 200 mm / Ø 11.8’’; B = 7.9’’ 1048469 ALPINE STRUCTURE Structure diamond: 1048808

1050104 ALPINE PRE-GRINDING Pre-grinding diamond: 1048807

SF-3 SB Ø 300 mm; B = 350 mm / Ø 11.8’’; B = 1’2’’ 1046159 ALLROUND Structure diamond: 1048808

SF-2 Ø 300 mm; B = 350 mm / Ø 11.8’’; B = 1’2’’ 1047599 ALLROUND Allround diamond: 1025477

Tool holding: 1046184 ALPINE STRUCTURE Structure diamond: 1048808

cylindrical (from 2012) 1047094 ALPINE PRE-GRINDING Allround diamond: 1025477

SF-2 Ø 300 mm; B = 350 mm / Ø 11.8’’; B = 1’2’’ 1048063 ALLROUND Allround diamond: 1014936

Tool holding: 1044149 ALPINE STRUCTURE Allround diamond: 1014936

conical (up to 2012) 1051434 ALPINE PRE-GRINDING Allround diamond: 1014936

PROFI 4 Ø 300 mm; B = 350 mm / Ø 11.8’’; B = 1’2’’ 1043724 ALLROUND Allround diamond: 1014936

Tool holding: 1044149 ALPINE STRUCTURE Allround diamond: 1014936

conical (up to 2012) 1051434 ALPINE PRE-GRINDING Allround diamond: 1014936

PROFI 4 Ø 300 mm; B = 350 mm / Ø 11.8’’; B = 1’2’’ 1046159 ALLROUND Allround diamond: 1025477

cylindrical (from 2012) 1047094 ALPINE PRE-GRINDING Pre-grinding diamond: 1048807

PROFI S350 Ø 300 mm; B = 350 mm / Ø 11.8’’; B = 1’2’’ 1043724 ALLROUND Allround diamond: 1025477

Tool holding: 1051434 ALPINE PRE-GRINDING Pre-grinding diamond: 1048807

conical (up to 2012)

Workshop Equipment

Consumables

Grinding stones

SF-4 Ø 350 mm; B = 350 mm / Ø 1’2’’; B = 1’2’’ 1055242 ALLROUND Structure diamond: 1025477

without flange Ø 350 mm; B = 165 mm / Ø 1’2’’; B = 6.5’’ 1059869 ALPINE PRE-GRINDING Pre-grinding diamond: 1048807

(71)

plus deposit for flange

I t e m - N o .

1 0 3 8 6 0 7

M a c h i n e

D i m e n s i o n

I t e m - N o .

A p p l i c a t i o n

R e c o m m e n d a t i o n

d r e s s i n g

d i a m o n d

p . 6 7

PROFI S200 Ø 300 mm; B = 200 mm / Ø 11.8’’; B = 7.9’’ 1024528 ALLROUND Allround diamond: 1026957

conical (up to 2012) 1040505 ALPINE PRE-GRINDING Pre-grinding diamond: 1048807

1031973 NORDIC Nordic diamond: 1031545

cylindrical (from 2012) 1047605 ALPINE PRE-GRINDING Pre-grinding diamond: 1048807

PROFI 1 and Ø 300 mm; B = 150 mm / Ø 11.8’’; B = 5.9’’ 750106 for Alpine ski, Allround diamond: 1014936

TSM-E-Multi 150

perfect wear and a good grinding pattern

TSM-S-V and Ø 300 mm; B = 120 mm / Ø 11.8’’; B = 4.7’’ 750099 for Alpine ski, Allround diamond: 1014936

TSM-E-Multi 120

ESM Junior Ø 250 mm; B = 150 mm / Ø 9.8’’; B = 5.9’’ 1006982 for Alpine ski, Allround diamond: 1014936 perfect wear and

a good grinding pattern

ESM Ø 250 mm; B = 120 mm / Ø 9.8’’; B = 4.7’’ 750098 for Alpine ski, Allround diamond: 1014936

Workshop Equipment

Consumables

Grinding stones

PROFI S350 Ø 300 mm; B = 350 mm / Ø 11.8’’; B = 1’2’’ 1046159 ALLROUND Allround diamond: 1025477

(72)

ACCESSORIES for ICE SKATE GRINDING MACHINE SL-2

I t e m - N o .

A c c e s s o r i e s

400934 1011271 750312 Grinding disc Ø 200 x 6 x 51 mm / Ø 7.9’’ x 0.2’’ x 2.0’’, Grain 80; Universal grinding disc

Dressing diamond for SL-2

Grinding disc Ø 200 x 6 x 51 mm / Ø 7.9’’ x 0.2’’ x 2.0’’, Grain 100

1

2

1 2 5

ACCESSORIES for KSM-F, KFM-US

I t e m - N o .

1008185 750384 1006743

Base edge – tuning disc Ø 250 x 20 x 51 mm / Ø 9.8’’ x 0.8’’ x 2.0’’

Dressing diamond Ø 25 mm / 1’’, for side edge

Base edge – tuning disc Ø 250 x 20 x 150 mm / Ø 9.8’’ x 0.8’’ x 5.9’’

3

4

Workshop Equipment

Consumables

Grinding discs & dressing diamonds

1 0 4 6 5 0 2

I t e m - N o .

PULLER for grinding stones

universal for pulling all Reichmann grinding stones.

3

(73)

ACCESSORIES BASE EDGE for KFM-U, KFM-US

and/or KFM-UK

I t e m - N o .

750385 1011109 1043091 951210 1043092

Base edge tuning disc, Ø 300 x 55 mm / Ø 11.8’’ x 2.2’’; there are 2 discs for one machine required

(for KFM-U from 2002)

Dressing diamond Ø 150 mm / Ø 5.9’’;

for base edge (KFM-U, KFM-US, KFM-UK from 2012) Base edge tuning disc, Ø 300 x 140 mm / Ø 11.8’’ x 5.5’’; without flange (for KFM-U from 2003)

ACCESSORIES for DTS, DTS-U, DTS-U Pro, SF-2, SF-2 Pro,

SF-3, SF-4 and/or SF-1

I t e m - N o .

1016293 1023989 1049942 1013178 1032393 1041792

Side edge ceramic disc grey Ø 154 x 25 mm / Ø 6.1’’ x 1.0’’; cup wheel (DTS, DTS-U, SF-2)*

Side edge ceramic disc white Ø 154 x 25 mm / Ø 6.1’’ x 1.0’’; cup wheel (DTS-U Pro, SF-1, SF-2 Pro, SF-3, SF-4)*

Base edge tuning disc Ø 250 x 55 mm / Ø 9.8’’ x 2.2’’; without flange (DTS-U, DTS-U Pro, SF-2, SF-2 Pro, SF
