MECHANICS OF

MATERIALS

Ferdinand P. Beer E. Russell Johnston, Jr. John T. DeWolf Lecture Notes: J. Walt Oler

Texas Tech University

CHAPTER

Analysis and Design

of Beams for Bending

(2)

Introduction

Shear and Bending Moment Diagrams Sample Problem 5.1

Sample Problem 5.2

Relations Among Load, Shear, and Bending Moment Sample Problem 5.3

Sample Problem 5.5

Design of Prismatic Beams for Bending Sample Problem 5.8

(3)

Introduction

• Beams - structural members supporting loads at various points along the member

• Objective - Analysis and design of beams

• Transverse loadings of beams are classified as

concentrated loads or distributed loads

• Applied loads result in internal forces consisting of a shear force (from the shear stress

distribution) and a bending couple (from the normal stress distribution)

• Normal stress is often the critical design criteria

S M I c M I My m x = − σ = = σ

Requires determination of the location and magnitude of largest bending moment

(4)
(5)

Shear and Bending Moment Diagrams

• Determination of maximum normal and shearing stresses requires identification of maximum internal shear force and bending couple.

• Shear force and bending couple at a point are determined by passing a section through the beam and applying an equilibrium analysis on the beam portions on either side of the

section.

• Sign conventions for shear forces V and V’ and bending couples M and M’

(6)

For the timber beam and loading shown, draw the shear and bend-moment diagrams and determine the maximum normal stress due to

bending.

• Treating the entire beam as a rigid body, determine the reaction forces

• Identify the maximum shear and bending-moment from plots of their distributions.

• Section the beam at points near

supports and load application points. Apply equilibrium analyses on

resulting free-bodies to determine internal shear forces and bending couples

• Apply the elastic flexure formulas to determine the corresponding

(7)

Sample Problem 5.1

SOLUTION:

• Treating the entire beam as a rigid body, determine the reaction forces

∑ = 0 = ∑ : = 40kN =14kN

from Fy MB RB RD

• Section the beam and apply equilibrium analyses on resulting free-bodies

(

20kN

)( )

0m 0 0 0 kN 20 0 kN 20 0 1 1 1 1 1 = = + ∑ = − = = − − ∑ = M M M V V Fy

(

20kN

)(

2.5m

)

0 50kN m 0 kN 20 0 kN 20 0 2 2 2 2 2 ⋅ − = = + ∑ = − = = − − ∑ = M M M V V Fy 0 kN 14 m kN 28 kN 14 m kN 28 kN 26 m kN 50 kN 26 6 6 5 5 4 4 3 3 = − = ⋅ + = − = ⋅ + = + = ⋅ − = + = M V M V M V M V

(8)

• Identify the maximum shear and bending-moment from plots of their distributions.

m kN 50 kN 26 = = ⋅ = m B m M M V

• Apply the elastic flexure formulas to determine the corresponding

maximum normal stress.

(

)(

)

3 6 3 3 6 2 6 1 2 6 1 m 10 33 . 833 m N 10 50 m 10 33 . 833 m 250 . 0 m 080 . 0 − − × ⋅ × = = × = = = S M h b S B m σ Pa 10 0 . 60 × 6 = m σ

(9)

Sample Problem 5.2

The structure shown is constructed of a W10x112 rolled-steel beam. (a) Draw the shear and bending-moment diagrams for the beam and the given loading. (b) determine normal stress in sections just to the right and left of point D.

SOLUTION:

• Replace the 10 kip load with an

equivalent force-couple system at D. Find the reactions at B by considering the beam as a rigid body.

• Section the beam at points near the support and load application points. Apply equilibrium analyses on

resulting free-bodies to determine internal shear forces and bending couples.

• Apply the elastic flexure formulas to determine the maximum normal

(10)

• Replace the 10 kip load with equivalent force-couple system at D. Find reactions at B.

• Section the beam and apply equilibrium analyses on resulting free-bodies.

( )

3

( )

0 1.5 kip ft 0 kips 3 0 3 0 : 2 2 1 1 + = = − ⋅ ∑ = − = = − − ∑ = x M M x x M x V V x F C to A From y

(

4

)

0

(

96 24

)

kip ft 24 0 kips 24 0 24 0 : 2 − + = = − ⋅ ∑ = − = = − − ∑ = x M M x M V V F D to C From y

(

226 34

)

kip ft kips 34 : ⋅ − = − = M x V B to D From

(11)

Sample Problem 5.2

• Apply the elastic flexure formulas to determine the maximum normal stress to the left and right of point D.

From Appendix C for a W10x112 rolled steel shape, S = 126 in3 about the X-X axis.

3 3 in 126 in kip 1776 : in 126 in kip 2016 : ⋅ = = ⋅ = = S M D of right the To S M D of left the To m m σ σ σm =16.0ksi ksi 1 . 14 = m σ

(12)

(

)

x w V x w V V V Fy ∆ − = ∆ = ∆ − ∆ + − = ∑ 0: 0 ∫ − = − − = D C x x C D V w dx V w dx dV

(

)

( )

2 2 1 0 2 : 0 x w x V M x x w x V M M M MC ∆ − ∆ = ∆ = ∆ ∆ + ∆ − − ∆ + = ∑ ∫ = − = D C x x C D M V dx M dx dM 0

• Relationship between shear and bending moment:

(13)

Sample Problem 5.3

SOLUTION:

• Taking the entire beam as a free body, determine the reactions at A and D.

• Apply the relationship between shear and load to develop the shear diagram.

Draw the shear and bending moment diagrams for the beam and loading shown.

• Apply the relationship between bending moment and shear to develop the bending moment diagram.

(14)

• Taking the entire beam as a free body, determine the reactions at A and D.

(

) (

)( ) (

)(

) (

)(

)

kips 18 kips 12 kips 26 kips 12 kips 20 0 0 F kips 26 ft 28 kips 12 ft 14 kips 12 ft 6 kips 20 ft 24 0 0 y = − + − − = = ∑ = − − − = = ∑ y y A A A D D M

• Apply the relationship between shear and load to develop the shear diagram.

dx w dV w dx dV = =

- zero slope between concentrated loads

(15)

Sample Problem 5.3

• Apply the relationship between bending moment and shear to develop the bending moment diagram. dx V dM V dx dM = =

- bending moment at A and E is zero

- total of all bending moment changes across the beam should be zero

- net change in bending moment is equal to areas under shear distribution segments - bending moment variation between D

and E is quadratic

- bending moment variation between A, B,

(16)

SOLUTION:

• Taking the entire beam as a free body, determine the reactions at C.

• Apply the relationship between shear and load to develop the shear diagram. Draw the shear and bending moment

diagrams for the beam and loading shown.

• Apply the relationship between

bending moment and shear to develop the bending moment diagram.

(17)

Sample Problem 5.5

SOLUTION:

• Taking the entire beam as a free body, determine the reactions at C.

⎟ ⎠ ⎞ ⎜ ⎝ ⎛ − − = + ⎟ ⎠ ⎞ ⎜ ⎝ ⎛ − = = ∑ = + − = = ∑ 3 3 0 0 0 2 1 0 2 1 0 2 1 0 2 1 a L a w M M a L a w M a w R R a w F C C C C C y

Results from integration of the load and shear distributions should be equivalent.

• Apply the relationship between shear and load to develop the shear diagram.

(

area under load curve

)

a w V a x x w dx a x w V V B a a A B − = − = ⎥ ⎥ ⎦ ⎤ ⎢ ⎢ ⎣ ⎡ ⎟ ⎟ ⎠ ⎞ ⎜ ⎜ ⎝ ⎛ − − = ∫ ⎟ ⎠ ⎞ ⎜ ⎝ ⎛ − − = − 0 2 1 0 2 0 0 0 2 1

- No change in shear between B and C. - Compatible with free body analysis

(18)

and shear to develop the bending moment diagram. 2 0 3 1 0 3 2 0 0 2 0 6 2 2 a w M a x x w dx a x x w M M B a a A B − = ⎥ ⎥ ⎦ ⎤ ⎢ ⎢ ⎣ ⎡ ⎟ ⎟ ⎠ ⎞ ⎜ ⎜ ⎝ ⎛ − − = ∫ ⎟ ⎠ ⎞ ⎜ ⎜ ⎝ ⎛ ⎟ ⎟ ⎠ ⎞ ⎜ ⎜ ⎝ ⎛ − − = −

(

)

(

)

(

)

⎟ ⎠ ⎞ ⎜ ⎝ ⎛ − = − − = − − = ∫ − = − 3 2 3 0 0 6 1 0 2 1 0 2 1 a L w a a L a w M a L a w dx a w M M C L a C B

Results at C are compatible with free-body analysis

(19)

Design of Prismatic Beams for Bending

• The largest normal stress is found at the surface where the maximum bending moment occurs.

S M I c M m = max = max σ

• A safe design requires that the maximum normal stress be less than the allowable stress for the material used. This criteria leads to the determination of the minimum

acceptable section modulus.

all all m M S σ σ σ max min = ≤

• Among beam section choices which have an acceptable section modulus, the one with the smallest weight per unit length or cross sectional area will be the least expensive and the best choice.

(20)

A simply supported steel beam is to carry the distributed and concentrated loads shown. Knowing that the

allowable normal stress for the grade of steel to be used is 160 MPa, select the wide-flange shape that should be used.

SOLUTION:

• Considering the entire beam as a free-body, determine the reactions at A and

D.

• Develop the shear diagram for the beam and load distribution. From the diagram, determine the maximum bending moment.

• Determine the minimum acceptable beam section modulus. Choose the best standard section which meets this criteria.

(21)

Sample Problem 5.8

• Considering the entire beam as a free-body, determine the reactions at A and D.

( ) (

)(

) (

)( )

kN 0 . 52 kN 50 kN 60 kN 0 . 58 0 kN 0 . 58 m 4 kN 50 m 5 . 1 kN 60 m 5 0 = − − + = = ∑ = − − = = ∑ y y y A A A F D D M

• Develop the shear diagram and determine the maximum bending moment.

(

)

kN 8 kN 60 kN 0 . 52 − = − = − = − = = B A B y A V curve load under area V V A V

• Maximum bending moment occurs at

V = 0 or x = 2.6 m.

(

)

kN 6 . 67 , max =

= area under shear curve AtoE M

(22)

• Determine the minimum acceptable beam section modulus. 3 3 3 6 max min mm 10 5 . 422 m 10 5 . 422 MPa 160 m kN 6 . 67 × = × = ⋅ = = − all M S σ

• Choose the best standard section which meets this criteria. 448 1 . 46 W200 535 8 . 44 W250 549 7 . 38 W310 474 9 . 32 W360 637 38.8 W410 mm , 3 × × × × × S Shape W360×32.9
