Workflow based performance testing

Suresh Srinivasan

(2)

•

Overview

•

Single user business process explanation

•

Workflow based business process scenario

•

Methods to simulate the conditions

•

Challenges to be met

•

Database preparation

(3)

3 _{© Virtusa Corporation ● Confidential}

Overview

• Business processes and its varieties

– Single user processes

– Multi user processes

• User role and its impact

– Single user role per process – Direct simulation for load testing

(4)

Application examples

• Shopping portals

– Typically a registered users completes a set activities related to procurement

• User scenarios in Banking, Financial applications etc

– An account holder transact using various facilities

• Online reservations

– Registered users search, book or cancel tickets

One common aspect to note here is only one user works through the

process start till end and might have multiple iterations before logout

(5)

User view

Typical single user

tasks

(6)

Process flow

Login

Task1 Task2 Task 5

Task 3

Task 4

Logout

Task1 Task2 Task3

Task1 Task2 Task3 Task4

Business Process 1

Business Process 3

Business Process 2

• User role within a process remains the same • Multiple process threads with defined user roles • Process could be iterative

(7)

Scripting approach simulating the loading scenario

Login

Task1 Task2 Task 5

Task 3

Task 4

Logout

Task1 Task2 Task3

Task1 Task2 Task3 Task4 Business Process 1

Business Process 3

Business Process 2 Script 1 20 Users 5 iterations

Script 2 30 Users 3 iterations

Script 3 50 Users 1 iteration

(8)

Application examples

• Insurance policy processing

– Where roles like sales person, agents, underwriters, insurance experts etc are involved in each process depending upon the need

• Bank loan processing

– Here the roles include sales person, appraiser, approver, cashier, dispatcher etc are involved to process a loan

• Order processing

– Order processing involves Quoting, evaluation, approval, delivery, etc and from one stage to the other lot of work is involved

• Hospital management

– This process involves Medical assistant, Primary analyst, Final analyst, approver, report processing etc to handle a patient from start to end of the treatment process

Here the common aspect to note is, multiple users work in a process

in different stages to complete the end-to-end business process

(9)

Process view

WORKFLOW TYPE BUSINESS PROCESS

Repeat Task 1

Repeat Task 2

Repeat Task 4 Repeat Task 5

Workflow based business process

Repeat Task 3 Role 1

Role 2

Role 3

(10)

(11)

User view

Repeat Task 1

Repeat Task 2

Repeat Task 4 Repeat Task 5 Workflow based business process

Repeat Task 3 Role 1 Role 2 Role 3 Role 4 Role 5 Login Logout Login Logout Login Logout

Login Logout Login Logout

•User role within a process could be more than one

•Different tasks are logically connected but need not be sequential real time •Each task is iterative

(12)

User view

(13)

Real Office Workflow Scenario

Verifier 3

Typical roles in a Sales workflow

Assess Verify Verifier 1 Verifier 2 Assessor 1 Assessor 2 Sales Person 1 Sales Person 2 Sales Person 3 Sales Person 4 Sales Person 5 Dispatcher 1 Dispatcher 3 Dispatcher 4 Dispatcher 2 Dispatcher 5 Approve Approver 1 Approver 3 Approver 5 Approver 4 Approver 2 Dispatch New Order Specification: 100 Orders 40 Assessments 60 Verifications 100 Approvals 100 Dispatches

•Throughput:100 orders to be processed in 8 hours

•Max load: 20 Concurrent users

(14)

Scripting approach

Repeat Task 1

Repeat Task 2

Repeat Task 4 Repeat Task 5 Workflow based business process

Repeat Task 3 Role 1 Role 2 Role 3 Role 4 Role 5 Login Logout Login Logout Login Logout

Script 1

Role -Sales Person Work Item -New order 5 V-users

20 Iterations

Script 2

Role -Assessor Work Item - Assessment 2 V-users

20 Iterations

Script 3

Role -Verifier Work Item -Verify order 3 V-users

20 Iterations

Script 4

Role -Approver Work Item -Approver 5 V-users

Script 5

Role - Dispatcher Work Item – Dispatch 5 V-users

20 Iterations

(15)

Simulation of the scenario

DB

Scripts App

Test data

DB to contain live data required for 20 users to process 100 orders in the cyclic manner through a day

Application to show the assigned tasks for all the 20 users when they login and claim from their work queue

Scripts for all the 5 work items (tasks) New order, Assess, Verify, Approve and Dispatch need to be available

Test data for all the above work items for 20 users for 20 iterations need to be available

(16)

Test execution challenges

• DB to be pre-loaded with real time data

– Approach

– Automation

• Upfront we may need to extract the process id’s

– To prepare test data

– for the individuals to claim their tasks

• There could be pagination issues for higher iterations

– When the number of tasks exceeds one page length, there could be multiple pages from where the task has to be picked up by the virtual user

(17)

Test execution challenges - Contd

• In order to repeat the tests after each load run, DB to be copied and retrieved

– This reduces time required for test preparation

– Same test conditions are repeated for consecutive runs

• Role allocation for the tasks

– Single role assigned for multiple tasks

– Multiple roles assigned to perform a single task

(18)

Backend data preparation

• Options

– DB scripts to fill various tables according to the planned task for all the virtual users

• DB integrity issues

• Data accuracy

• Time content

– Using performance test scripts to complete various tasks

• Requires very high protection for the DB maintenance

(19)

Backend data preparation

Repeat Task ١

Repeat Task ٢

Repeat Task ٤ Repeat Task ٥ Workflow based business process

Repeat Task ٣ Role ١ Role ٢ Role ٣ Role ٤ Role ٥ Login Logout Login Logout Login Logout

Initiate 400 orders at this point

Release 300 orders from this stage using Performance test scripts

Release 200 orders from this stage

Release 100 orders from this stage

• Objective: Assigning 100 task items for each stage ( 4 X 100)

(20)

Conclusion

• Workflows involves simulation of business processes with multiple roles

• There could be multiple user roles within a business process

• Though the tasks involved in a process are logically connected, they are

individually repetitive in nature asynchronously

• Simulation requires backend data preparation to show the assigned tasks

• Well defined process is required to manage reusability of test data for each run

Thank You….
