IBM BPM V8.5.5.pdf

(1)

Creating implicit SOAP headers for inbound web service integrations 306 Retrieving SOAP headers from an inbound request message 307 Adding SOAP headers to an outgoing response message 309 Posting a message to IBM Business Process Manager Event Manager 311 Publishing IBM Business Process Manager web services 315

Web services compatibility 317

Verifying that the web service is working 318

Calling a web service using a SOAP connector 319

Integrating BPDs with IBM Case Manager cases 322

Adding an IBM Case Manager server 323

Building the IBM Case Manager Integration service 325

Building a query for a search case operation 327

Processing a search case operation result 328

Data mapping in case operations 330

Accessing an IBM Case Manager server using the Secure Sockets Layer (SSL) 332

Designing process interactions for business users 333

Configuring a role-based business user interface 334

Exposing business process definitions 335

Exposing the Ad Hoc Reports dashboard 337

Exposing heritage human services 338

Enabling resumable services 343

Globalizing dashboard names 346

Generating portlets for heritage human services exposed as dashboards 347

Exposing client-side human services 352

Making business data available in searches and views 356 Developing flexible and efficient process applications 358

Configuring activities for inline completion 360

Optimizing BPD execution for latency 363

Automatically starting the user's next task 365

Defining ad hoc actions (deprecated) 367

Setting up collaboration features for business users 369

Enabling Sametime Connect integration 370

Specifying experts for an activity 371

Enabling IBM Connections integration 372

Enabling process instance management 374

Setting the work schedule for a BPD 377

Examples 379

Managing time and holiday schedules 380

(5)

Enabling processes for tracking and reporting 384 Tracking IBM Business Process Manager performance data 385

Data tracking considerations 387

Autotracking performance data 389

KPIs and SLAs 391

Creating custom KPIs 393

Associating KPIs with activities 394

Creating SLAs 396

Setting up autotracking 398

Tracking groups of process variables 399

Creating a tracking group 400

Associating process variables to a tracking group 401

Creating a timing interval 402

Sending tracking definitions to Performance Data Warehouse 404

Exposing performance scoreboards 406

Defining reports (deprecated) 407

Defining a custom layout (deprecated) 409

Building cases 410

Case management overview 413

Case management concepts 415

Scenario: Financial services credit card dispute resolution 418

Scenario: Automobile insurance claims 420

Designing a case 422

Opening Case Designer from Process Center 423

Creating a case type 425

Configuring how a case is started 427

Adding a case type variable or property 429

Adding case type folders 431

Assigning teams to a case type 433

Adding a case activity 434

Setting preconditions 437

Implementing an activity 440

Creating a document type 442

Example document types 444

Creating case user interfaces 445

Testing and debugging a case type 448

Services to support case management applications 450

The IBM BPM content store 453

Case artifacts and the IBM BPM content store 454

Update restrictions for modifying case artifacts 456

Creating a team 461

Using services to define dynamic teams 463

Setting up a team retrieval service 465

Setting up a team filter service 467

Defining team managers 469

Defining Team rules (deprecated) 470

(6)

Variable types 475

Variable scope 477

Creating business objects 478

Shared business objects 480

Business objects, attributes, and variables that are renamed 482

Business object advanced properties 485

Declaring and passing variables 491

How variables are passed 493

Declaring variables 496

Mapping input and output data for an activity or step 498

Declaring variables for a subprocess 500

Testing declared variables and data mapping 502

XSD generation pattern for business objects 504

Using JavaScript in BPDs 506

Initializing complex variables 507

Creating exposed process values 508

Adding an EPV to a BPD or service 510

Adding an EPV to a report 511

Setting variables in pre and post assignments 512

Making business data available in searches and views 513

Creating user interfaces for business processes 513

Which artifacts should I use? 515

User interface concepts 517

Human services 519 Dashboards 520 Coaches 521 Coach views 523 Templates 525 Properties 526 General properties 527

Configuration properties and configuration options 529 Positioning options for coach view instances 533

Visibility properties 536

HTML attributes 538

Data binding for coach views 539

Binding data and configuration options 541

Boundary events 547

Event handlers overview 548

Framework managed versus view managed content for coaches 551

Controls 553

Advanced items for coach views 554

Content box 555

Custom HTML 557

Heritage artifacts 559

Difference between heritage human services and client-side human services 561

(7)

Modeling client-side human services 565 Tools available from the palette for client-side human services 568

Building a client-side human service 572

Implementing a BPD task using a client-side human service 574

Declaring variables 575

JavaScript API for client-side human service authoring 577 Calling another service from a client-side human service 582 Implementing exclusive gateways in client-side human services 584 Saving the state of a client-side human service during execution 586 Validating client-side coaches using client-side validation 588 Validating client-side coaches using server-side validation 591

Handling errors in client-side human services 594

Exposing client-side human services 596

Adding HTML meta tags to client-side human services 596 Enabling work to be postponed and resumed at run time 597

Navigation options for after service completion 599

Running and debugging client-side human services 600

Running client-side human services 601

Debugging client-side human services 602

Troubleshooting errors from running client-side human services 604 Keyboard accessibility for client-side human services 607 Adding nodes to client-side human services by using the keyboard 610 Heritage human service to client-side human service conversion 612

Building coaches 614

Validating coaches in heritage human services 617

Developing reusable coach views 619

Providing information about coach views 622

Defining coach view behavior 624

Improving coach view performance 627

Adding custom AMD modules 629

Accessing a child coach view 631

Configuring the design-time appearance of coach views 633

Adding variables to coach views 636

Defining the contents of coach views 637

Adding bidirectional language support 639

Setting the visibility of coach views 641

Calling Ajax services from coach views 646

Generating URLs of managed assets 649

Generating a unique ID for a coach view 651

Tips for debugging coach view lifecycle method inside client-side human services 652

Tips for debugging coach views in Process Portal 654

Enabling JavaScript debugging for coaches 656

Coach and coach view troubleshooting 657

Responsive settings for coach views 658

Coach and coach view examples 660

Example: creating a template 661

(8)

Example: creating a tabbed coach 667 Example: creating a Select control using custom HTML 673

Example: creating a Dojo button control 676

Example: creating a jQuery button control 678

Example: validating a coach in a client-side human service 680 Example: validating a coach in a heritage human service 683 Example: creating a coach that calls an Ajax service 687 Example: creating a coach for tablets and smartphones 690 Example: showing the label of a complex coach view 697

Building Heritage Coaches 701

Adding sections to a Heritage Coach and controlling the layout 702

Setting column widths in a Heritage Coach 704

Setting the number of columns in a Heritage Coach 705 Examples of building services with heritage coaches 706 Example: building an integration service with a Heritage Coach 707 Nesting the Integration service and mapping its variables 708 Building Heritage Coaches to collect input and display output 709 Building a heritage human service with heritage coaches 710 Example: Building a heritage human service with coaches 713 Building an Ajax service with Heritage Coaches 715

Configuring Heritage Coach controls 717

Populating a list with static data 718

Populating a list with dynamic data 719

Binding a complex data structure to a Table control 721 Populating a table control using an SQL query 723 Binding a variable to a custom HTML component 725

Making an input control a required field 726

Displaying a control based on the input value of another control 727

Displaying a control to a specific group 729

Changing the visibility of a Heritage coach control 730

Validating user input 732

Controlling field and other formatting in Heritage Coaches 733 Using pre-defined formats in Heritage Coach Controls 734 Using characters to apply custom numeric formatting 736

Adding custom format types 740

Using formatting with variables 741

Using formatting with language localization resources 742

Configuring a Hebrew or Islamic calendar 743

Aligning buttons in a Heritage Coach 744

Aligning check boxes and radio buttons in a Heritage Coach 745 Adding documents and reports to Heritage Coaches 746 Choosing the type of documents to attach to a Heritage Coach 747 Attaching IBM Business Process Manager documents to a Heritage Coach 750

Attaching ECM documents to a Heritage Coach 753

Embedding documents in a Heritage Coach 755

(9)

How Heritage Coaches work 761

Adding custom images to a Heritage Coach 763

Overriding CSS styles for selected controls and fields 764

Specifying a custom CSS for a Heritage Coach 766

Specifying an XSL transform override for a Heritage Coach 767

Setting the length of input text fields 768

Enhancing interface layout using custom attributes 769 System services to implement conditional activities 771

Troubleshooting Heritage Coaches 772

Localizing process applications 773

Creating localization resources 774

Localizing user interfaces 776

Localizing coach view configuration options 777

Versioning process applications 778

Naming conventions 780

Naming conventions for Process Center server deployments 782 Naming conventions for Process Server deployments 786

Enabling document support 788

Working with IBM BPM documents 789

The IBM BPM document store 791

Inbound events for the IBM BPM document store 792

Inbound events for the IBM BPM content store 794

The IBM_BPM_Document document type 796

Creating IBM BPM documents 798

Updating IBM BPM documents 799

Working with the IBM_BPM_Document_Properties property 800 Writing to the IBM_BPM_Document_Properties property 801 Reading from the IBM_BPM_Document_Properties property 802 Updating the IBM_BPM_Document_Properties property 804 Specifying search criteria for the IBM_BPM_Document_Properties property 806 Working with IBM BPM documents in the Document List coach view 807

Limitations in working with IBM BPM documents 808

Integrating with Enterprise Content Management (ECM) systems 809

Adding an Enterprise Content Management server 810

Outbound interactions with Enterprise Content Management systems 812

Authentication scenarios 813

How to use Coach views to store or view documents 815 Configuring coach views for storing and viewing Enterprise Content

Management documents 817

Building a service that integrates with an ECM system or the IBM BPM

document store 820

Building a query for an Enterprise Content Management search operation 824 Working with a search result programmatically 827

Working with document content 829

Data mapping in Enterprise Content Management operations 831 Inbound events from Enterprise Content Management systems 840

(10)

Performing modeling tasks for inbound events 842 Subscribing to document and folder events: the end-to-end approach 844 Creating and configuring event subscriptions 848

Content event types 851

Creating attached services 855

Creating and configuring an undercover agent for a content event 856

Adding a content event to a BPD 856

The ECMContentEvent business object 858

Performing administrative tasks for inbound events 859 Creating an event handler for an Enterprise Content Management system 860

Using the event handler for FileNet Content Manager 862 Troubleshooting interactions with Enterprise Content Management systems 867

Integration considerations for ECM products 868

IBM FileNet Content Manager 869

IBM Content Manager 871

Alfresco Community 873

Microsoft SharePoint 875

Accessing the SharePoint CMIS provider from IBM BPM 877

Testing and debugging process applications 880

Visualizing process data 881

Visualize variables 883

Visualize tag groups 884

Keyboard shortcuts for data visualization 885

Running and debugging processes with the Inspector 887

Managing process instances 889

Restricting access to debugging for services 890

Stepping through a process 893

Debugging a process 895

Resolving errors 897

Inspector reference 898

Authentication during playback to handle changes in user identity 903

Globalization 904

Bidirectional support in IBM Business Process Manager 905 Applying bidirectional text layout transformation 906

Contextual support 908

Troubleshooting Process Designer and Process Center connectivity 909

Enabling error logging 911

Troubleshooting Process Designer and Process Center connectivity 913

Enabling error logging 913

(11)

-Building process applications

In IBM® Business Process Manager (BPM), process applications are the containers for business processes and cases that are created in IBM Process Designer.

You can either create process applications in Process Center or export and import process applications into Process Center. After a process application is created or imported, it is stored and listed in the Process Center repository. You open process applications in Process Designer where you can create and edit the business

process definitions (BPDs) or cases within those process applications.

For information about designing high-performing IBM Business Process Manager solutions, see the following publications:

For designing processes, see Chapter 5: Design considerations and patterns in

Business Process Management Design Guide: Using IBM Business Process Manager.

For best practices, see Chapter 2: Architecture best practices and Chapter 3:

Development best practices in IBM Business Process Manager V8.5 Performance

Tuning and Best Practices.

For an overview of critical performance-related information, see IBM Business

Process Manager V8.5 Performance Tuning.

The following high-level diagram illustrates the basic tasks and activities that are typically associated with building a process application.

Business process management and case management

Business process management and case management are two approaches to build a process. The type of business situation you are addressing determines which approach you use.Case management functions are only available if you have IBM BPM Advanced with the Basic Case Management feature installed.

(12)

-Getting started with IBM Process Designer

Process Designer is an easy-to-use graphics-oriented tool that enables you to model and implement your business processes and easily demonstrate process design and functionality during development efforts. This overview describes how to begin using all of the tools that are available with Process Designer.

Creating new process applications

When you create a new process application, you provide a name, acronym, and optional description of the process application.

Creating a process application from a WebSphere Business Modeler process

You can import business processes from WebSphere Business Modeler to Process Designer.

Creating processes in IBM Process Designer

Create processes in Process Designer that represent the processes in your

company. When you run your processes inside Process Designer, you can analyze and simulate them in order to optimize your business activity.

Building cases

A case is a project that starts and finishes over time to resolve a problem. The problem can involve a claim or a request or a proposal and be supplemented by many documents and records relevant to the case. A case usually involves multiple people from inside and outside of an organization. These people often have a relationship to each other. For example, a customer with a problem and a corporate support representative who solves the problem for the customer.

Creating a team

A team is a group of users that perform similar tasks, and consists of a set of members and a team of managers. Teams are used to manage the tasks that users can perform in Process Portal. Because any team can be added as the manager of another team, you can flexibly define your organization's management structure.

Business objects and variables

In Process Designer, variables capture the business data that is used by activities in a business process definition or by steps in services such as integration services or human services.

Creating user interfaces for business processes

In IBM Business Process Manager, human services provide the logic and user interface through which users can view and interact with business processes, cases, data or process instances.

Versioning process applications

Versioning provides the ability for the runtime environment to identify snapshots in the lifecycle of a process application, and to be able to concurrently run multiple snapshots on a process server.

Enabling document support

Testing and debugging process applications Globalization

To ensure that applications can be used in multiple geographical locations and cultures, globalization support is built in through appropriate design and

(13)

-layout transformation, and calendar support for Hebrew and Hijri.

Troubleshooting Process Designer and Process Center connectivity

Resolve problems starting Process Designer, for example during login, by using various techniques such as correcting invalid connection information or logging errors that are captured with log4J or java.util.logging.

(14)

-1. 2. 3. 4. 5. 6.

-Business process management and

case management

Business process management and case management are two approaches to build a process. The type of business situation you are addressing determines which approach you use.Case management functions are only available if you have IBM BPM Advanced with the Basic Case Management feature installed.

IBM® Business Process Manager provides tools for the approaches to define and then improve a process: business process management and case management. Learn the differences so that you can select the best approach for your situation. Consider two types of situations that a corporation faces. In the first situation, the corporation wants more customers to use its credit card. In the second situation, the corporation wants a process to handle calls about credit card billing problems. The following sections describe the design and implementation you would likely use for each situation.

Designs for two types of business situations Building and running a business process Building and running a case

Key differences between business process management and case management

Designs for two types of business situations

If you needed to get more customers to use your credit card, you might come up with the following activities:

Define the type of customer you think might benefit from your credit card. Use an application to search a database for potential candidates.

Use an application to email the candidates.

Review the candidates who responded to assess the effectiveness of the email and determine patterns in the list of interested customers.

Use an application to check the credit rating of the respondents.

Use an application to mail the credit cards to candidates with good credit ratings. The activities are in order and their order follows a predictable and repeatable

process. The process determines the sequence of events. It is a stable process that likely remains unchanged over many years. A number of the actions can be

automated. In this scenario, a business process would most likely be your implementation choice.

If you wanted to handle customers with credit card billing problems, you might come up with the following unordered activities:

Capture the complaint when someone called or sent an email. Get information about the customer.

Get information about the vendor.

Collect receipts and invoices to verify the complaint.

Notify Customer Records if unusual information was found.

Notify system administrators if the billing system caused problems. Notify Vendor Records if unusual information was found.

(15)

The activities are unordered because the sequence of activities is unpredictable. The events determine the order in which the activities in the process are followed. People rather than programs interact to resolve the dispute. External documents are needed for verification. In this scenario, a case would most likely be your

implementation choice.

Example of building and running a business process

The following business process might get more customers to use the corporation's credit card. It is a wired process. You can see which activity follows the other. At run time, the activities drive the events. For example, a worker defines the type of

customer that the worker is looking for and then starts the application to get the candidates and email the candidates. Then, the worker waits until there is a list of candidates to review based on the people who responded to the email. Finally, the worker starts the credit check application. The credit check application is followed by the application that mails out the credit cards. A worker at run time does not select the next activity from a set of choices to choose what comes next; the next activity is predetermined at development time.

The activities are in swimlanes that define the type of activity. The team lane is for activities that people do and the system lane is for activities that programs do. Programs automate and complete many activities. To implement these activities with human services, subprocesses, services, and teams, you use the same set of tools as you do to implement a case.

Example of building and running a case

The following case might handle credit card billing complaints. The activities are not wired. No predetermined sequence is set at development time. A worker would likely start by describing the complaint and finish by resolving the dispute. However,

whether the worker receives the customer information before the vendor information would likely be determined by what the worker read in the complaint. The

information that is retrieved about the customer would determine whether the worker would check with the people who handle the customer records. The information that is retrieved about the vendor would determine whether the worker would check with the people who handle vendor records. The information that is retrieved about either the customer or the vendor might lead to investigating the computer billing system for problems.

(16)

controls the process at run time, the process is dynamic and influenced by current events. As in a business process, the required activities must be completed.

However, optional activities do not need to be completed.

People who interact with other people, rather than automated programs, determine the activities. To verify the complaint, receipts and invoices, which are external documents independent of the case, must be captured. To implement these activities with human services, subprocesses, services, and teams, you use the same set of tools as you do to implement a business process.

Key differences between business process management

and case management

Considering the previous scenarios, the following table summarizes the

characteristics of business process management and case management. Examining these characteristics, you can select which type of process might best suit your situation.

Table 1. Characteristics of business process management and case management

Business process management Case management

You can define an ordered sequence of activities that can be completed to solve a business challenge.

You can define an unordered set of activities that can be completed to solve a business challenge.

The sequence of activities is stable and seldom changes; that is, the process is predicable and repeatable.

The activities occur in an unpredictable order.

The process determines the events. The first activity determines the first set of events, which then leads to the next activity and the next set of events. The activities are wired to one another, which determines the sequence.

The events determine the process. As events occur, a worker selects the appropriate activity. The resulting process can vary depending on the current event and the subsequent

selection by the worker. Activities are not wired to one another.

(17)

Parent topic:Building process applications

The activities are often programmatic. A repeatable sequence, such as selecting a set of potential credit card owners from a database, can be automated.

People primarily determine the activities. Handling a customer with a billing error is done by a person who uses judgment to determine the best resolution of this particular case.

External documents are not part of the process.

External documents play a key role. For example, receipts provide a record for how the problem that must be resolved began.

(18)

-Getting started with

IBM Process Designer

Process Designer is an easy-to-use graphics-oriented tool that enables you to model and implement your business processes and easily demonstrate process design and functionality during development efforts. This overview describes how to begin using all of the tools that are available with Process Designer.

For a high-level overview of the components of the Process Designer interface,

watch Getting Started with Process Designer version 8.5.5, available on YouTube

or in the IBM Education Assistant information center. A transcript of the video is available.

Process Designer interface

Before you start to build processes with IBM Process Designer, you must understand the tools that are available in the Process Designer interface.

Where to edit Process Designer artifacts

Learn where you can edit artifacts in IBM Process Designer.

Process Designer tips and shortcuts

You can use several features in Process Designer to improve your efficiency.

Concurrent editing

Multiple users can simultaneously access and change process applications and library items in IBM Process Designer. When you edit concurrently, you collaborate with other team members to create the library items that you need for your project. For example, you can communicate about your ideas and edits with instant

messaging and see the results in the Designer view as they happen.

Setting preferences

IBM Process Designer provides several settings to control the appearance and functionality of the editors and interfaces that it includes.

(19)

Process Designer interface

Before you start to build processes with IBM® Process Designer, you must understand the tools that are available in the Process Designer interface.

The Process Designer interface provides the tools to model your processes in IBM BPM. The following image and corresponding table describe the parts of the

Designer view that you interact with when modeling processes and implementing the steps in those processes.

Table 1. Description of numbered areas on the Designer interface image

Number Area Description

1 Main toolbar Provides access to the

Designer view and

Inspector. Also provides access to Process Center and Optimizer if you open the Process Designer desktop editor. The main toolbar is also where you go to save all open editors, take a snapshot, and view web-based help.

2 Library Provides access to the

library items for the current process application. You can create and edit library items, as described in

Managing library items in the Designer view. Note: Users who have

administrative access to the application control access to process applications. For more

information, see Managing

access to the Process Center repository.

(20)

Parent topic:Getting started with IBM Process Designer

Related information:

Known issues for translated IBM BPM components

3 Main canvas Where you can graphically

model and configure your process and design the layout of coaches, human services, and heritage human services.

4 Palette Provides BPMN elements

and variables that you can use to model and configure your process.

5 Property manager Where you can set

properties and

configuration options for selected components in your process.

(21)

-Where to edit Process Designer artifacts

Learn where you can edit artifacts in IBM® Process Designer.

In previous releases, you worked with artifacts in Process Designer on your desktop. Now, you can work with artifacts that are in the Process Designer web editor and in the Process Designer desktop editor. For example, to create process applications that contain business process definitions (BPDs) and client-side human services, you must use both the desktop editor and the web editor because there are some Process Designer capabilities that you can access only on the web and some that you can access only on your desktop.

Multiple users can work simultaneously on the same process applications and artifacts in the two editors and changes happen automatically and seamlessly. If you have Process Designer open on your desktop and you are working in the web editor, you can edit certain artifacts in the desktop editor. When you click the

artifacts in the web editor, they open in the desktop editor so that you can edit them. You can access the Process Designer web editor in the following ways:

Open Process Designer desktop editor and then select an artifact that is editable only on the web, such as a client-side human service, case type, or document type. Case management functions are only available if you have IBM BPM Advanced with the Basic Case Management feature installed.

Open Process Designer desktop editor, select a coach view, and then right-click and select Open in > Web Editor.

The following table lists which artifacts you can edit where (indicated with asterisks). You can edit some artifacts in the desktop editor. You can edit other artifacts in the web editor. The web editor opens in a web browser from Process Designer.

Table 1. Where you can edit Process Designer artifacts

Artifacts Editable in the Process

Designer desktop editor

Editable in the Process Designer web editor Advanced Integration service * Ajax service * business object * * BPD * case typeNote:Case

management functions are only available if you have IBM BPM Advanced with the Basic Case

Management feature installed.

(22)

coach viewNote: To use responsive features in coach views, for example to have the runtime

behavior respond to different screen size environments, you must edit coach views in the web editor.

* *

client-side human service *

decision service *

design file *

document typeNote:Case management functions are only available if you have IBM BPM Advanced with the Basic Case

Management feature installed.

*

event subscription *

external implementation *

exposed process value *

General System service *

heritage human service *

historical analysis scenario * IBM Case Manager

Integration service

*

Integration service *

key performance indicator (KPI)

*

localization resource * *

process application setting *

server file * * service-level agreement * simulation analysis scenario * teamNote: To define a

team using a filter or

retrieval service, you need to edit this artifact in the Process Designer desktop editor.

* *

timing interval *

tracking group *

undercover agent *

(23)

(24)

-Process Designer

tips and shortcuts

You can use several features in Process Designer to improve your efficiency. When you start using the Designer interface in Process Designer, there are some tips and shortcuts to keep in mind.

The following are tips and shortcuts for the Process Designer desktop editor:

To maximize the space available for the main canvas, you can hide the library by clicking the toggle at the bottom of the Revision History. You can also hide the palette by clicking the left margin of the palette. Click the toggle icon and the palette margin to restore the library and the palette.

To move from one open library item to another, click the arrow keys or the menu at the top of the window.

Unsaved changes have an asterisk next to the item name at the top of the window. To create a new library item while you are working in the Designer view, press Ctrl+Shift+N.

To open an existing library item while you are working in the Designer view, press Ctrl+Shift+O.

To choose multiple items in a category, press and hold the Ctrl key and then click each item.

You can capture your development progress in snapshots as described in

Creating snapshots in the Designer view.

You can revert to a previous snapshot (version) of a library item as described in

Reverting to a previous version of a library item.

You can copy the previous snapshot (version) of a library item to your current

project as described in Copying an asset from a snapshot.

You can add a dependency to a toolkit to use the library items from that toolkit as

described in Creating, changing, and deleting a toolkit dependency in the Designer

view.

You can see updates that are made by other users as described in Concurrent

editing.

For quick and easy access of particular library items, you can create favorites as described in Creating favorites.

To group library items for easy access, follow the instructions in Tagging library items.

To create smart folders of library items, follow the instructions in Organizing library items in smart folders.

To move or copy library items from one process application to another, follow the instructions in Copying or moving library items.

To add and manage external files as part of your IBM® BPM project, see

Managing external files.

The following are tips and shortcuts for the Process Designer web editor:

Click the "Hide the Library" icon at the top left corner of Process Designer to hide the library.

To maximize the space available for in the main canvas, you can resize the palette and the main canvas and you can also hide the property manager by clicking the

(25)

-To move from one open library item to another, click the arrow keys or the menu at the top of the window.

To choose multiple items in a category, press and hold the Ctrl key and then click each item.

You can capture your development progress in snapshots as described in

Creating snapshots in the Designer view.

Unsaved changes have an asterisk next to the item name at the top of the window. You can add a dependency to a toolkit to use the library items from that toolkit as

described in Creating, changing, and deleting a toolkit dependency in the Designer

view.

You can see updates that are made by other users as described in Concurrent

editing.

To tag library items for easy access, follow the instructions in Tagging library items. To move or copy library items from one process application to another, follow the instructions in Copying or moving library items.

To add and manage external files as part of your IBM BPM project, see Managing

external files.

(26)

-Concurrent editing

Multiple users can simultaneously access and change process applications and library items in IBM® Process Designer. When you edit concurrently, you

collaborate with other team members to create the library items that you need for your project. For example, you can communicate about your ideas and edits with instant messaging and see the results in the Designer view as they happen.

Note: Each user must be connected to the same Process Center and each user

must have write access to the process application or toolkit where the library items are located. When you edit concurrently with other users, ensure that your

connection status is good.

When you are working in the Designer view, you can see when other users are working in the same process application, as shown in the following screen capture:

You can also see when others are viewing or editing the same library item, as shown in the following screen capture:

When multiple users work on the same library item, such as a human service, each user can see the changes when edits are saved. To ensure that all users are aware which library items are open and what changes are being made, Process Designer provides the following notifications:

When another user opens a library item by showing a user icon. You can hover over the icon to see who that user is.

When another user is editing a library item by displaying the words Read Only next to the library item. When a user saves their work, the library item will be available to edit.

When another user has saved changes while you are editing a library item by displaying the words Read Only next to the library item. When you click Save, a Save conflict message displays to ask you either to save your changes and override the other user's changes or discard the changes and accept the other user's changes.

When multiple users start to edit a library item at the same time, before the Read

Only text appears, by displaying a warning icon and message to suggest to each

user that they either immediately save their changes or discard them.

(27)

1. 2. 3.

Setting preferences

IBM® Process Designer provides several settings to control the appearance and functionality of the editors and interfaces that it includes.

Process Designer preferences

The following steps describe how to access the preference settings and the following table describes the options that are available:

Select File > Preferences from the main menu.

Click the IBM BPM entry to display the available options.

Click the option that you want. For example, to set the user name for Blueworks Live™ process subscriptions, click the Blueworks Live option.

Table 1. Options for IBM Process Designer preferences

Option Description

Blueworks Live Set the Blueworks Live server

URL and email address for Blueworks Live process

subscriptions.Tip: Changing the email address or the URL logs you out of Blueworks Live.

Capabilities Control the capabilities of the

current user. For example, to create external activities in IBM Process Designer, you must enable IBM BPM Developer Capability and IBM BPM Advanced Features.

Decisions Control the locale setting for BAL

Rules.

JavaScript Set preferences for the

JavaScript editor included in IBM Process Designer. For example, you can choose whether to display JavaScript warnings.

Optimizer Settings Set options for the Optimizer.

For example, the KPI thresholds that are used by the

Visualization Modes are the thresholds from the current working version of your process application or toolkit. If you want to use the KPI thresholds from the snapshot (version) of your process application or toolkit that was most recently run and

tracked, change the Optimizer to the following preference setting:

Use the KPI threshold values from the actual version of the Process App/Toolkit.

(28)

Process Center Console preferences

To set the locale for IBM Process Center Console and Process Designer, access the Process Center Console by opening your web browser to the following location:

http://[host_name]:[port]/ProcessCenter. Click Preferences in the upper

right corner and choose the language that you want from the list. When you change the locale, you must exit and then restart IBM Process Designer for the change to take effect. (When you are accessing Process Center Console from a browser, you can log out and then log back in for the change to take effect.)

The locale preference that you selected applies to the user who logs in. Each IBM Business Process Manager interface that is started by the same user in the same environment uses this preference setting.

Process Designer XML configuration settings

The IBM BPM settings related to Process Designer are transferred through the network from Process Center to Process Designer as properties of the

AuthoringEnvironmentConfig configuration object every time Process Designer is

launched. These properties affect the connections created between Process Designer and Process Center. Based on your business requirements, you might want to change the properties of Process Designer.

For IBM BPM XML configuration settings that are related to Process Designer, see the following table that contains properties and explains how to set the properties. The AuthoringEnvironmentConfig object contains the following properties:

Passwords Manage the passwords that are

stored when running tasks from the Inspector.

Web Browser Select the web browser to use

when web pages are opened from IBM Process Designer. If you do not see a particular external web browser as an option, click New to add it.

Name Description Additional Information

Images Prefix The Images Prefix

endpoint maps to the AE_IMAGES_PREFIX scenario key, which configures the URLs that are used in the Process Designer authoring

environment to get images.

Information about using the scenario keys to configure the IBM BPM endpoints is described in the topic

Configuring endpoints to match your topology.

(29)

Portal Prefix The Portal Prefix endpoint maps to the

AE_PORTAL_PREFIX scenario key, which configures the URLs that are used in the Process Designer authoring environment to reach Process Portal.

Repository Prefix The Repository Prefix

endpoint maps to the

AE_REPOSITORY_PREFI X scenario key, which configures the URLs that are used in the Process Designer authoring

environment to reach the repository.

Servlet Prefix The Servlet Prefix endpoint

maps to the

AE_SERVLET_PREFIX scenario key, which configures the URLs that are used in the Process Designer. This scenario must specify an absolute

URL by setting the url

property.

Social Bus WebApp Prefix The Social Bus WebApp Prefix endpoint maps to the

AE_SOCIALBUS_WEBAP P_PREFIX scenario key, which configures the URLs that are used in the

Process Designer

authoring environment to reach the social bus web application.

Web API Prefix The Web API Prefix

endpoint maps to the AE_WEBAPI_PREFIX scenario key, which configures the URLs that are used in the Process Designer authoring

environment to reach the web API.

(30)

REST Gateway Prefix The REST Gateway Prefix endpoint maps to the

AE_REST_GATEWAY_CR _PREFIX scenario key, which configures the URL that is used in the Process Designer authoring

environment to reach the Process Center REST Gateway.

Web PD Prefix The Web PD Prefix

endpoint maps to the AE_WEB_PD_PREFIX scenario key, which

configures the URL that is used in the Process

Designer authoring

environment to launch the web editor.

Webviewer WebApp Prefix The Webviewer WebApp Prefix specifies the

endpoint of the web

application contained in the webviewer.war file.The host and port number of the URL can be

customized by setting the IBM BPM virtual host. The context root of the URL can be customized by adding a prefix before the context root.

Information on setting the IBM BPM virtual host is found in the topic

Configuring endpoints to match your topology. For information about setting the context root prefix, see the topic

BPMConfig command-line utility.

BPM Asset Prefix The BPM Asset Prefix

specifies the endpoint of the web application contained in the

bpmasset.war file. The host and port number of the URL can be

customized by setting the IBM BPM virtual host. The context root of the URL can be customized by adding a prefix before the context root.

(31)

Process Portal Prefix The Process Portal Prefix specifies the endpoint of the web application

contained in the

process-portal.war file. The host and port number of the URL can be customized by setting the IBM BPM virtual host.

The context root of the URL can be customized by adding a prefix before the context root. For example,

/prefix/ProcessPortal.

HTTP Protocol Only If this attribute is set (which

is the default),

communication between Process Designer and Process Center is limited to using HTTP or HTTPS protocols instead of RMI with JMS.

Note that if the attribute is not set, HTTP or HTTPS communication still occurs between some Process Designer components and Process Center, but not exclusively.

Information on setting the

httpProtocolOnly

attribute is found in the topic Configuring the httpProtocolOnly property for Process Designer.

(32)

Suppress Redirect URL Password

Specifies whether to suppress the inclusion of the user password in the URLs that Process

Designer opens. For example, each time you run a playback in Process Designer, a new Process Portal browser session is opened. Process Designer then submits the user credentials, which consist of the user ID and

password, and the browser session uses these

credentials to log in. The

suppressRedirectUrlPas swd option stops the

password from being included in the URL to improve security. Note: When you use the

suppressRedirectUrlPas

swd option, you only need

to log into the browser the first time that you open a web editable artifact or run a playback in Process Designer. This option only applies to Process

Designer and can be turned on and off as needed.

Information on setting the

suppressRedirectUrlPas swd attribute is found in the

topic Installing IBM Process Designer.

Formatting Templates Specifies the predefined

character formats for text controls or specifies the creation of additional formats. The data type is FormattingTemplatesConfi g.<authoring-environment merge="mergeChildren"> <formatting-templates merge="replace"> <formatting-template comment="Currency" template="$ ###,###,###.##"/> <formatting-template comment="Currency" template="###,###,###.## €"/> <formatting-template comment="Currency" template="€ ###,###,###.##"/> <formatting-template comment="Integer" template="###,###,###"/> <formatting-template comment="Decimal" template="###,###,###.##"/> <formatting-template comment="US phone" template="(###) 000-0000"/> <formatting-template comment="US SSN" template="000-00-0000"/> </formatting-templates> </authoring-environment>

These properties are all configured using IBM BPM configuration XML files. For information about setting the properties, see

the topic Changing IBM

Process Server properties in 100Custom.xml.

(33)

Inspector This property specifies inspector configuration. The data type is

InspectorConfig. <authoring-environment merge="mergeChildren"> <inspector> <target-servers> <type></type> <name></name> <default-action-policy> <action> <type></type> <role>role1</role> <role>role2</role> </action> </default-action-policy> </target-servers> </inspector> </authoring-environment>

Library Event Stream Manager

The data type is

SequencedStateDeltaMan agerConfig.<authoring-environment merge="mergeChildren"> <sequenced-state-delta-manager> <fallback-timeout>15 </fallback-timeout> <slow-timeout>15 </slow-timeout> <scheduled-timeout-padding>15 </scheduled-timeout-padding> <time-in-fallback-before-link-reset>15 </time-in-fallback-before-link-reset> <time-in-fallback-after-link-reset-before-full-reset>15 </time-in-fallback-after-link-reset-before-full-reset> </sequenced-state-delta-manager> </authoring-environment>

Mime Types The data type is

MimeTypesConfig. <authoring-environment merge="mergeChildren"> <mime-types merge="replace"> <mime-type type="application/javascript"/> <mime-type type="application/octet-stream"/> <mime-type type="application/pdf"/> <mime-type type="application/xml"/> <mime-type type="application/xml-dtd"/> <mime-type type="application/zip"/> <mime-type type="image/gif"/> <mime-type type="image/jpeg"/> <mime-type type="image/png"/> <mime-type type="text/calendar"/> <mime-type type="text/css"/> <mime-type type="text/csv"/> <mime-type type="text/html"/> <mime-type type="text/rtf"/> </mime-types> </authoring-environment>

Repository Broken Ping Time

Specify an integer value.

The default value is 15000

if the value is set to 0 or a value is not specified.<authoring-environment merge="mergeChildren"> <repository-broken-ping-time merge="replace"> </repository-broken-ping-time> </authoring-environment>

Repository Max Wait During Shutdown

Specify an integer value. The default value is 3000 if the value is set to 0 or a value is not specified.<authoring-environment merge="mergeChildren"> <repository-max-wait-during-shutdown merge="replace"> </repository-max-wait-during-shutdown> </authoring-environment>

(34)

Repository Ping Delay Specify an integer value.

The default value is 15000

if the value is set to 0 or a value is not specified.<authoring-environment merge="mergeChildren"> <repository-ping-delay merge="replace"> </repository-ping-delay> </authoring-environment>

Repository Slow Ping Time Specify an integer value. The default value is 7500 if the value is set to 0 or a value is not specified.<authoring-environment merge="mergeChildren"> <repository-slow-ping-time merge="replace"> </repository-slow-ping-time> </authoring-environment>

Add Redirect URL Credentials

Specifies whether the

credentials are permitted to be passed in IBM Business Process Manager URLs. For example, a service can be started directly from IBM Process Designer without presenting a login screen. The default value is true.<authoring-environment merge="mergeChildren"> <add-redirect-url-credentials merge="replace">true </add-redirect-url-credentials> </authoring-environment>

Deploy Snapshot Using HTTPS

Specifies whether the Process Center Server uses HTTPS to deploy process applications and toolkits to process servers. If the property is set to the default value of true and all process servers are secure, then

communication from

Process Center to Process Server will work with HTTP Secure (HTTPS) or HTTP over SSL. However, if you have a mix of secure and non-secure servers, Process Center can only communicate with Process Servers that are configured to work with this mixed configuration. <authoring-environment merge="mergeChildren"> <deploy-snapshot-using-https merge="replace">true </deploy-snapshot-using-https> </authoring-environment>

(35)

Encode Redirect URL Credentials

Specifies whether the

credentials that are passed in an IBM Business

Process Manager URL that

implements

redirect-login.jsp are encoded. For example, you can encode credentials in a URL that is used to start a service directly from IBM Process Designer. By default, this property is set to true, which specifies that the credentials passed in an IBM BPM URL are encoded. If you change the setting to false, the URL is composed with credentials in plain text.<authoring-environment merge="mergeChildren"> <encode-redirect-url-credentials merge="replace">true </encode-redirect-url-credentials> </authoring-environment>

(36)

-1. 2. 3. 4. 5.

-Creating new process applications

When you create a new process application, you provide a name, acronym, and optional description of the process application.

About this task

You create new process applications in Process Center. You can access the Process Center console in the following ways:

From entering the remote Process Center URL (for example

https://servername:9080/ProcessCenter/login) into a web browser.

By starting the Process Designer desktop editor.

Tip: If you are creating processes in your process application, use the Process

Designer desktop editor. If you are building cases in your process application, use the remote Process Center URL.

Procedure

To create a new process application, complete the following steps: Start the Process Designer desktop editor or enter the remote Process Center URL into a web browser.

In the Process Apps tab, click the Create New Process App option.

In the Create New Process App window, enter a name, acronym, and description of the process application. Ensure that the acronym for the process application is unique and limited to seven characters. IBM® Business Process Manager (BPM) uses the acronym as an identifier for this process application and the library items that it contains. For example, when you manipulate the items in the process

application with the IBM BPM JavaScript API, you can use the acronym to specify the namespace of the items. For example, when you manipulate the items in the process application with the IBM BPM JavaScript API, you can use the acronym to specify the namespace of the items. The acronym for the process application must be unique and limited to 7 characters. IBM BPM uses the acronym as an identifier for this process application and the library items that it contains. For example, when you manipulate the items within the process application with the IBM BPM JavaScript API, you can use the acronym to specify the namespace of the items.

Providing a description is optional. When you enter a description, you can view it in the Process Center console by clicking the question mark next to the process application name.

If you are building cases in the process application, you can select Allow users to open the process application in the web-based Case

Designer. For more information, see Opening Case Designer from Process

Center.Note:Case management functions are only available if you have IBM BPM Advanced with the Basic Case Management feature installed.

To create library items in the process application, click the appropriate option:

Open in Designer

(37)

-Management feature installed. You see the Open in Case Designer option only if you selected the option described in step 4.

What to do next

To use tracks in this process application, enable the tracks in the Process Center console.

You can create toolkits to enable Process Designer users to share library items across process applications.

(38)

1.

2. 3. 4.

Creating a process application from a WebSphere

Business Modeler process

You can import business processes from WebSphere Business Modeler to Process Designer.

About this task

You can do this by importing the BPMN models that you exported earlier from WebSphere Business Modeler BPMN 2.0 file archive (.zip) files. You can import your models into the IBM Process Center. You can then use the IBM Process

Designer to open the resulting Process App or Toolkit, if you want to see the details of what was imported or to make changes to the imported models.

Procedure

To import BPMN models into the IBM® Process Center complete the following steps:

Start the IBM Process Designer from your Windows desktop or using the URL for the Process Center in a browser. The first time you start the IBM Process

Designer it opens to the Process Center console.You can trigger the import of the models in two ways. You can either click Import Process App (on the Process App tab), or Import Toolkit (on the Toolkit tab). Either of these actions will result in an import window.

Click Import Process App. The Import Process App window displays.

Click Browse to select the BPMN 2.0 archive (.zip) file that you exported from IBM WebSphere® Business Modeler and click Next.

In the Import Process App window, a name and acronym have been specified based on information in the file you selected. You can edit the name and acronym and add a description. If you are using IBM BPM Advanced, you will see radio buttons that you can use to choose what will be generated for unimplemented services. Select either Advanced Integration Services or Integration Services and then click Next. Note: Advanced integration services are only available for unimplemented services. Integration services are always generated for

implemented services. Both radio buttons display only in IBM BPM Advanced. For

more information, see Building an Integration service and Building an Advanced

Integration service.

A Summary of the import results pane opens containing any generated error, warning and information messages. A new process application or a toolkit is created, containing the content from the BPMN 2.0 archive. It will include

integration services if the model contained web service bindings and advanced integration services if the model contained unimplemented advanced integration services. All Blueworks Live artifacts will also be integrated with a BPMN import if Blueworks Live phases and other BPMN 2 extensions were in the model.

A snapshot of the process application is automatically created in the Process Center, for your use as a baseline, in the future, if necessary.

(39)

5. 1. 2. 3. 4. A. B. A. B. C. D. 5.

You can filter the messages by clicking Errors or Warnings. Click Save and specify a location if you want to save the messages. All the messages will be saved as a text file even if a filter has been applied. Click Close.

What to do next

You have now imported your BPMN models successfully into the Process Center. The following procedure helps you identify the step-by-step actions you will take after a successful import. However these steps will vary depending on the contents of your model and how you intend to make use of these models in the future. If you had seen warning messages at the end of your import it is likely that you may need to take some remedial action. Warnings usually indicate an unsupported construct or invalid input model. For each warning, examine the contents of what was

generated and take additional action as required.

Parent topic:Building process applications

Next Steps after importing BPMN Models

Procedure

Open the Process App or Toolkit that you created

Open every single generated artifact and ensure that its contents appear as expected.

Replace any of the default generated logic with the intended logic wherever necessary.

Complete the following steps for each of the following artifact:Services: Enter the service flow details

Human services: Customize the default generated coach Rule services: Enter the rule details

Teams: Specify the team members Processes:

Private Variables: Provide default values for any variables that are not

initialized.

XOR and IOR Gateways: Enter the conditional logic Javascript Activities: Enter the javascript logic

Adjust the process layout to minimize connection crossing. Check for validation messages and fix them as necessary.

(40)

-Creating processes in IBM

Process Designer

Create processes in Process Designer that represent the processes in your

company. When you run your processes inside Process Designer, you can analyze and simulate them in order to optimize your business activity.

The following diagram illustrates the main tasks and activities that are associated with creating processes.

Modeling processes

A process is the major unit of logic in IBM Business Process Manager (BPM). It is the container for all components of a business process definition (BPD). Modeling a good process that matches your requirements is at the core of Process Designer.

Designing process interactions for business users

After you deploy a business process definition that you have built in Process Designer to the Process Portal, a business user might interact with it in a number of ways. The user might be the one to launch the process, or the user might be assigned individual activities in the process.

Enabling processes for tracking and reporting

IBM Business Process Manager provides ways to collect and consume process performance information. To take advantage of this information, you enable to design your processes to make them trackable.
