Online Potentiometer Handbook

Welcome to the on-line version of the “ The Potentiometer Handbook” originally published in hard cover by McGraw-Hill Book Company.

We have made only a few changes to the original in the area of Industry Standards and Military Specifications.

The technology represented in this handbook has had no significant change in years and remains as viable today as it was when this volume was published.

To use this version you can scroll down page by page or you can go to the Table of Contents to select a specific subject or chapter and click on the title or page number to go directly to the section you selected.

To return to the previous view simply right click your mouse and select “Previous View” from the pop up window.

In order for these functions to operate properly you must use Acrobat Reader 8 or higher. If you need to download Acrobat for free, use the Acrobat icon below.

For more information you can also go to the Bourns web site at www.bourns.com , select applications information under the “About Us” button then selecting the “Library button”.

You may also want to review applciaction information from the “Trimmer Primer” by using link below: http://www.bourns.com/pdfs/trmrpmr.pdf

Copyright 1975, 2008

Adobe and Adobe Reader are registered trade-marks of Adobe Systems Incorporated.

ACKNOWLEDGEMENTS

PHOTOGRAPHS CONTRIBUTED BY:

AMI MEDICAL ELECTRONICS BELL AERQSYSTEMS

BIDDLE CO., JAMES G. CALSPAN CORP.

CENTRAL SCIENTIFIC CO. CETEC, INC.

DUNCAN ELECTRONICS, INC. GENERAL RADIO CO.

HEWLEIT-PACKARD

INDUSTRY STANDARDS

INTERSTATE ELECTRONICS CORP. KRAFr SYSTEMS, INC.

LEEDS AND NORTHRUP POWER DESIGNS, INC.

SPACE-AGE CONTROL, INC. TEKTRONIX, INC.

WEYERHAUSER CO.

WILLI STUDER, SWITZERLAND

USERS' GUIDE TO

COST-EFFECTIVE APPLICATIONS

Written for

BOURNS, INC. By

CARL DAVID TODD, P.E.

CONSULTING ENGINEER

ASSOCIATE EDITORS

W. T. HARDISON

Product Marketing Specialist Trimpot Products Division

Bourns, Inc.

W. E. GALVAN Applications Engineer Trimpot Products Division

Bourns, Inc.

lHcGRAW-HILL

BOOK

COIHPANY

New York St. Louis Slln Francisco Auckland Diis~eldotf J()I,,"'nc~buty New Delhi Kual" Lumpur P~lnluna Sydney Paris Tokyo

London Mexico Munlteal Suo Paulo Singllpore

Library of Congress Cataloging in Publication Data Todd, Carl Dayid.

The potentiometer handbook.

I. Potentiometer-Handbooks, manuals, etc. 2. Electric resistors- Handbooks, manuals, etc. I. Bourns, inc. II. Title.

TK7872.P6T63 621.37'43 75-20010 ISBN 0-07-006690-6

Copyright

©

]975 by Bourns, Inc. All rights reserved. Printed in the United States of America. No part of this publication may be reproduced, stored in a retrieyal system, or transmitted, in any form or by any means, electronic, mechanical, photocopying. recording, or OIherwise, without the prior written permission of the publisher.

1234567890 MUB!' 784321098765

The inform31ion conveyed III Ihl. book has been carefully reviewed and believed 10 M aCCurale and r.ll~blc; however, "0 re,poIIsibiU'.y i. assumed for Ihe opcrabilny of any circuit di.sram or inaccuracie, In calculalions or

PREFACE

In the decades following the advent of the transistor, electronic technology experienced explosive growth. Thousands of new circuits were generated annually. The demand for variable resistive components to adjust, regulate or

control these circuits shared in

the expansion.

The number of applications [or variable resistive components has increased significantly. This is contrary to predictions of a few soothsayers of the '60's who interpreted the miniaturizing effects of integrated circuit technology as a threat to these components. Potentiometers will continue to enjoy strong growth into the foreseeable future. This optimistic forecast is particularly true in consumer and industrial applications where potentiometers provide the cost-effective solution in trimming applications and the ever-present necessity of control for man-machine interface.

Many articles, booklets, and standards have been published on potentiometers; yet, there is no single, comprehensive source of practical information on these widely used electronic components. It is this void that The Potentiometer

Handbook is intended to 611.

One objective of this handbook is to improve communications between po-tentiometer manufllcturcrs and users. To this end, explanlltions of performance specifications and test methods, arc included. Common understanding of ter-minology i~ the key to communication. For this reason, lesser known as well liS preferred terminology life included, with emphasis on the latter. Hopefully, this will create the base for easy. accurule dialogue. Over 230 photos. graphs and drawings illustru\e and clarify important concepts.

This book assumes the rellder has a knowledge of electronic and mathematical fundmentals. However, basic definitions and concepts can be understood by nontechnical personnel. The major portion of this text is written for systems and circuit designers, component engineers, and technicians as a pructical aid in design and selection. It is an important reference lind working hllndbook oriented towards practical application idells and problem solving. For the student, it introduces the basic component, its most common uses, and basic terminology.

Enough objective product design and manufacturing process information is in the lex! to allow the user to understand basic differences in materials, designs. and processes that arc availllble. This will sharpen his judgment on 'cost-versus-performance' decisions. Thus, he can avoid over-specifying prodUct require-ments and take advantage of the cost-effectiveness of variable resistive devices. Also included arc hints and design ideas compiled over the years. As with any discipline, these guidelines are often discovered or developed through unfortu-nate experience or misapplication. Most chllpters conclude with a summary of key points for quick review and reference.

Speaking o( misapplication, Chapter 9, To Kill a Potentiometer, is a tongue-in-check potpourri of devious methods to wipe out a potentiometer. This is a

lighthearted approach to occasional serious problems caused by human frailties. Not much more need be said except he/ore all else fails, read the book, or at least tbis chapter!

Suggestions from readers on improving this volume arc encouraged lind wcl-corned. Subsequent editions will include the results of these critiques together with advanced material relating to Ihe state-of-art in potentiometer design and

application.

CONTENTS

ii Acknowledgements v

Preface

xi List of illustrations

1

C

hapter ONE

-

I

NT

R

ODU

C

TION TO POTENTIOMETERS

Historical evolution and milestones of variable resistive devices from mid 19th century to present. Development of the basic concepts of resistive element and moveable cont<lct. Electri· cal and mechanical fundamentals including elementary readout devices.

I HISTORICAL BACKGROUND

6 PRACTICAL DEVELOPMENT OF THE POTENTIOMETER

17

C

hapter TWO

-

ELE

C

TR

I

C

AL PA

R

AMETERS

Interpretation of potentiometer electrical parameters in written and mathematical form with-out regard to application. Each definition is supplemcnlcd with terminology clarification and an example of electronic circuitry that will allow physical demonstration of each concept.

17 INTRODUCTION

18 TOTAL RESISTANCE, TR

18 ABSOLUTE MINIMUM RESISTANCE, MR

20 END RESISTANCE. ER

20 MINIMUM AND END VOLTAGE RATIOS

22 CONTACT RESISTANCE, CR

26 CONTACT RESISTANCE VARIATION. CRV

28 EQUIVALENT NOISE RESISTANCE, ENR

29 ENR and CRV

30 OUTPUT SMOOTHNESS, OS

31 ADJUSTABILITY. A

33 TEMPERATURE COEFFICIENT OF RESISTANCE, TC

34 RESOLUTION

37 CONFORMITY

40 ABSOLUTE CONFORMITY

40 LINEA RITY

45 POWER RATING

47 INSULATION RESISTANCE, JR

51

Chapter THREE -

APPLICATION FUNDAMENTALS

Presentation of the fundam(!ntal operational modes possible when applying the potentiometer in electrical circuits. Basic explanations assume ideal, theoretical conditions. Significance and effect of the parameters in Chapler Two. Subjects include error compensation, adjustment range control, data input and offset capability.

51

INTRODUCTION

51 VARIABLE VOLTAGE DIVIDER MODE

62 VARIABLE CURRENT RHEOSTAT MODE

71

DATA INPUT

74 APPLICATION FUNDAMENTALS SUMMARY CHART

77

Chapter FOUR -

APPLICATION AS A CIRCUIT

ADJUSTMENT DEVICE

The potentiometer as a circuit component without regard to total system. Analog and digital ap-plications with transistors, diodes, fixed resistors, capacitors, integrated circuits and instruments.

77 INTRODUCTION

78 POTENTIOMETER OR FIXED RESISTORS?

78 POWER SUPPLY APPLICATIONS

81 OPERATIONAL AMPLIFIER APPLICATIONS

87 DIGITAL CIRCUITS

89 INSTRUMENTS

91 MISCELLANEOUS APPLICATIONS

.7

Chapter FIVE -

APPLICA TION AS A CONTROL DEVICE

The potentiometer as a system component. Application in interesting systems, e.g. oscilloscopes, power supplies, function generators, meters and recorders.

97 INTRODUCTION

98 BASICS OF CONTROL

101 INSTRUMENT CONTROLS

104 AUDIO CONTROLS

106 MISCELLANEOUS CONTROLS

112 SUMMARY

115

Chapter

SIX

-

APPLICATION AS A PRECISION DEVICE

The potentiometer in systems requiring high accuracy. Importance of electro-mechanical parameters in precision applications. Applications in systems and circuits where accuracy is the most important consideration.

115 INTRODUCTION

115 OPERATIONAL CHARACTERISTICS

115 POWER RATING

118 FREQUENCY CHARACTERISTICS 120 LI NEAR FUNCTIONS

121 NONLINEAR fUNCTIONS

126 VOLTAGE TRACKING ERROR 127 CLOSED LOOP FUNCTIONS

127 MECHANICAL PARAMETERS

129 PHASING

130 NQNWfREWOUND PRECISION POTENTIOMETERS 133 LINEAR DISPLACEMENT TRANSDUCER

[33 LQWTORQUE POTENTIOMETERS

134 COARSE/ PINE DUAL CONTROL

135 POSITION INDICATION TRANSMISSION

136 THE X-22A, V ISTQL AIRCRAFT

137 A DENDROMETER

138 SORTING BRJDGE

143 Chapter SEVEN

-

CONSTRUCTION DETAILS AND

143

143

159

163

166

171

171

174

SELECTION GUIDELINES

Description of the various potentiometer constituent parts. Advantages and disadvantages of the diverse technologies available 10 construct a variable resistance device. Selection charts are

included for quick reference to cost-effective applications. INTRODUCTION RESISTIVE ELEMENTS TERMINA nONS CONTACTS ACTUATORS HOUSINGS SUMMARY SELECTION CHARTS

177 Chapter EIGHT

-

PACKAGING GUIDELINES

How to install potentiometers using various methods and techniques. The importance of acces-sibility, orientation and mounting when packaging the potentiometer in electronic assemblies.

177 INTRODUCTION

177 PLAN PACKAGING EARLY

178 DETERMINE ACCESSIBLLITY

180 CONSIDER OTHER PACKAGING RESTRICTIONS

180 CHOOSE THE PROPER PHYSICAL FORM

180 MOUNTING METHODS

181 PACKAGE SELECTION CHARTS

189 STRESS AND STRAIN

189 SOLDERING PRECAUTIONS

191 SOLVENTS

191 ENCAPSULATION

193 Chapter NINE

-

TO KILL A POTENTIOMETER

The misadventures of mischievous and misdirected KUR KILLAPOTthal result in misuse and misapplication of potentiometers. 194 MAYHEM 199 SLAUGHTERING 201 ZAP 207 SUMMARY CHARTS

209 Appendices

211 l. STANDARDS OF THE VARIABLE RESISTIVE COMPONENTS INSTITUTE 259 II. MILITARY SPECIFICATIONS

283 HI. BIBLIOGRAPHY OF FURTHER READING 287 IV. METRIC CONVERSION TABLE

289 V. ABBREVIATIONS AND MATHEMATICAL SYMBOLS

293 Index
