ControlNet Traffic Analyzer

(1)

ControlNet Traffic

Analyzer

9220-WINTA

(2)

Important User Information

Because of the variety of uses for the products described in this publication, those responsible for the application and use of these products must satisfy themselves that all necessary steps have been taken to assure that each application and use meets all performance and safety requirements, including any applicable laws, regulations, codes and standards. In no event will Rockwell Automation be responsible or liable for indirect or consequential damage resulting from the use or application of these products.

Any illustrations, charts, sample programs, and layout examples shown in this publication are intended solely for purposes of

example. Since there are many variables and requirements associated with any particular installation, Rockwell Automation does not assume responsibility or liability (to include intellectual property liability) for actual use based upon the examples shown in this publication.

Allen-Bradley publication SGI-1.1, Safety Guidelines for the Application, Installation and Maintenance of Solid-State Control (available from your local Rockwell Automation office), describes some important differences between solid-state equipment and electromechanical devices that should be taken into consideration when applying products such as those described in this publication.

Reproduction of the contents of this copyrighted publication, in whole or part, without written permission of Rockwell Automation, is prohibited.

Throughout this publication, notes may be used to make you aware of safety considerations. The following annotations and their

accompanying statements help you to identify a potential hazard, avoid a potential hazard, and recognize the consequences of a potential hazard:

WARNING

!

Identifies information about practices or circumstances that can cause an explosion in a hazardous environment, which may lead to personal injury or death, property damage, or economic loss.

ATTENTION

!

Identifies information about practices or circumstances that can lead to personal injury or death, property damage, or economic loss.

(3)

Rockwell Automation

Support

Before you contact Rockwell Automation for technical assistance, we suggest you please review the troubleshooting information contained in this publication first.

If the problem persists, call your local distributor or contact Rockwell Automation in one of the following ways:

Your Questions or Comments on this Manual

If you find a problem with this manual, please notify us of it on the enclosed How Are We Doing form.

Rockwell Automation is a trademark of Rockwell Automation ControlNet is a trademark of ControlNet International.

Microsoft, Windows, Windows 95 and Windows NT are registered trademarks of Microsoft Corporation.

IMPORTANT Identifies information that is critical for successful application

and understanding of the product.

Phone United

States/Canada

1.440.646.5800 Outside United

States/Canada

You can access the phone number for your country via the Internet:

1. Go to http://www.ab.com 2. Click on Product Support

(http://support.automation.rockwell.com) 3. Under Support Centers, click on Contact

Information

Internet

⇒

1. Go to http://www.ab.com

2. Click on Product Support

(4)

(5)

Summary of Changes

This release of the ControlNet_{Traffic Analyzer Reference Manual}

contains new and updated information, specifically about Windows 2000 and Windows XP. You will see change bars, as shown to the left of this paragraph, throughout this manual to help you quickly identify revisions.

(6)

(7)

Chapter 1 Introduction

What This Chapter Contains . . . 1-1

Main Structure of ControlNet . . . 1-1

Information Exchange on a ControlNet Network Link . . 1-1

ControlNet Messages . . . 1-2

ControlNet MAC Frame Structure . . . 1-3

Audience . . . 1-3

Software Package . . . 1-4

Hardware Recommendations . . . 1-4

Install the Traffic Analyzer . . . 1-5

Uninstall the Previous Version of the Traffic Analyzer . . 1-5

Install the Traffic Analyzer . . . 1-6

Terminology . . . 1-8

Common Techniques Used in This Manual. . . 1-9

Rockwell Automation Support . . . 1-9

Local Product Support . . . 1-9

Technical Product Assistance . . . 1-9

Your Questions or Comments About This Manual . . . . 1-10

Chapter 2 The ControlNet Traffic

Analyzer Tool

What This Chapter Contains . . . 2-1

The User Interface. . . 2-1

The Control Panel View (the Upper Part) . . . 2-2

The Filter/Trigger View (the Middle Part) . . . 2-4

The MAC Frame Data View (the Lower Part). . . 2-5

Chapter 3 Accessories and Menus

What This Chapter Contains . . . 3-1

Accessories . . . 3-1

The Toolbar. . . 3-1

The Status Bar . . . 3-2

Menus and Shortcuts . . . 3-2

Main Menu . . . 3-2

File Menu . . . 3-2

Edit Menu . . . 3-3

Actions Menu . . . 3-4

View Menu . . . 3-5

Window Menu. . . 3-6

Help Menu . . . 3-6

Pop-up Menus . . . 3-6

Stop Trigger List Pop-up Menu . . . 3-7

Start Trigger List Pop-up Menu . . . 3-7

Pre-Filter List Pop-up Menu . . . 3-7

Post-Filter List Pop-up Menu. . . 3-8

MAC Frame Data View Pop-up Menu . . . 3-8

(8)

Table of Contents ii

Chapter 4 Triggers and Filters

What This Chapter Contains . . . 4-1

Triggers . . . 4-1

Start Trigger View . . . 4-1

Stop Trigger View . . . 4-2

How to Configure a Trigger . . . 4-3

Status of Frames. . . 4-4

Type of Frame . . . 4-4

How to Configure a Start Trigger on Data . . . 4-4

Example 1: Fixed LPacket. . . 4-6

Example 2: Generic LPacket . . . 4-7

Example 3: Fixed LPacket Using the UCMM Service List. 4-8

Filters . . . 4-8

Pre-Filter View. . . 4-9

Disable Time Stamp . . . 4-9

How to Configure a Pre-Filter. . . 4-9

Post-Filter View . . . 4-11

How to Configure a Post-Filter . . . 4-11

Interpreting Control Bits. . . 4-16

Chapter 5 Display Information

What This Chapter Contains . . . 5-1

Display View Options . . . 5-1

Time Display . . . 5-2

Data Format. . . 5-2

MAC Frames . . . 5-3

LPackets . . . 5-3

Interpreted . . . 5-4

LPacket Header for a Fixed Tag: . . . 5-4

Lpacket Header for a Generic Tag: . . . 5-5

Other Options . . . 5-6

Tools to Manage Frames . . . 5-6

Bookmarks . . . 5-6

Find Data . . . 5-7

Simple Find . . . 5-7

Advanced Find . . . 5-7

Select a Range of Frames . . . 5-8

Compute Time Difference . . . 5-9

Copy Data to the Clipboard . . . 5-10

(9)

Table of Contents iii

Chapter 6 Network Information and

Statistics

What This Chapter Contains . . . 6-1

Network Information. . . 6-1

Statistics . . . 6-2

Statistical Data: Network Traffic . . . 6-3

Statistical Data: Network Utilization . . . 6-4

Chapter 7 Other Commands and Options

What This Chapter Contains . . . 7-1

Save a Document . . . 7-1

Create a Report . . . 7-2

Go Offline/Online Hardware Settings. . . 7-3

Reset the ControlNet Card and Time . . . 7-6

Application Options . . . 7-6

Save Options . . . 7-7

Buffer Size. . . 7-7

Report Option . . . 7-8

Default Display View Options . . . 7-11

Chapter 8 Troubleshooting

What This Chapter Contains . . . 8-1

Warning Messages. . . 8-1

Overflow/Underflow FIFO Error in the ControlNet ASIC . . . 8-1

The PC Is Not Able to Unload All the Received Data . . . 8-2

Good Scheduled Data Example . . . 8-3

All Unscheduled Data Starting on Good

Moderator Example . . . 8-3

Overflow Error in the ControlNet Traffic Analyzer

(10)

Table of Contents iv

Appendix A

Function and Shortcut Keys

What This Appendix Contains . . . A-1

Function Keys. . . A-1

Shortcut Keys . . . A-2

File Menu Shortcut Keys. . . A-2

Edit Menu Shortcut Keys . . . A-2

Actions Menu Shortcut Keys . . . A-3

View Menu Shortcut Keys . . . A-3

Window Menu Shortcut Keys . . . A-3

Help Menu Shortcut Keys. . . A-4

Start Trigger Menu Shortcut Keys . . . A-4

Stop Trigger Menu Shortcut Keys . . . A-4

Pre-Filter Menu Shortcut Keys. . . A-5

Post-Filter Menu Shortcut Keys . . . A-5

MAC Frame Data View Menu Shortcut Keys . . . A-6

(11)

Chapter

1 Introduction

What This Chapter Contains

This chapter introduces you to the ControlNet Traffic Analyzer tool. The following table describes what this chapter contains and where to find specific information.

Main Structure

of ControlNet

The ControlNet Traffic Analyzertoolis a 32-bit Windows_application

running on top of a 32-bit ControlNet Driver. This application is used to examine, store, and analyze network data on a ControlNet network. You can view the behavior of frames on the network, test ControlNet reliability, and make sure that every transmission on the network is correct.

Information Exchange on a ControlNet Network Link

A ControlNet network link’s most important function is to transport time-critical control information (i.e., I/O status and control

interlocking). Other information (i.e., non time-critical messages such as program uploads and downloads) is also transported, but does not interfere with time-critical messages because of ControlNet’s unique time-slice algorithm.

On a ControlNet network link, information is transferred between nodes by establishing connections. Each message sent by a producer contains a Connection ID (CID). Nodes that have been configured to recognize the CID consume the message, therefore becoming a consumer.

For information about See page

the main structure of ControlNet 1-1 the audience for this manual 1-3 the Traffic Analyzer tool’s software package 1-4

hardware recommendations 1-4

installation of the Traffic Analyzer tool 1-5 terminology used in this manual 1-8 common techniques used in this manual 1-9

(12)

1-2 Introduction

See the ControlNet International Specification for more information about information exchange on a ControlNet network link. The ControlNet International Specification can be purchased from ControlNet International.

The following illustration describes the ControlNet network’s link layer services.

ControlNet Messages

The repetitive time interval in which data can be sent on a link is called the Network Update Time (NUT). The NUT is divided into three parts containing three defined types of Media Access Control (MAC) frames:

•Scheduled

Every scheduled node in sequential order is guaranteed one opportunity to transmit. Information that is time-critical is sent during the scheduled part of the interval. The bandwidth is reserved in advance to support real time data transfers. Real time data transfers include:

•real time control data (I/O updates)

•analog data

•peer to peer interlocking

•Unscheduled

All nodes transmit on a rotating basis in sequential order. This rotation repeats until the time allocated for the unscheduled portion is used up.

7 8 9.. 8 9 10.. 9 10..

Network Update Time (NUT)

Scheduled Service Unscheduled Service Network Maintenance Service the “Guardband” 41561 0 ... SMAX 0 ... SMAX Time

Link Layer Services

(13)

Introduction 1-3

The amount of time available for the unscheduled portion is determined by the traffic load of the scheduled portion. ControlNet guarantees at least one node will have the opportunity to transmit unscheduled data every interval. The starting node for each NUT rotates to guarantee each node will have an unscheduled transmit time. The remaining bandwidth supports non time-critical data transfers. Non time-critical data transfers include:

•connection establishment

•peer to peer messaging

•programming (uploads and downloads)

•Moderator

The node with the lowest MAC ID (node address) assumes the moderator role. The moderator frame is transmitted to keep the other nodes synchronized. This moderator frame is sent in the guardband.

ControlNet MAC Frame Structure

All transfers use the MAC frame format shown in the following illustration.

Each node can send only one MAC Frame at each opportunity to transmit. Each MAC Frame contains one or more LPackets

(Link-Packets). Each LPacket contains one piece of “application information”.

Audience

This interface software is written for network specialists. It will assist network engineers in designing and debugging of ControlNet

products and will help maintenance personnel during installation or troubleshooting of a ControlNet network.

0 - 510 Bytes Max Source

MAC

LPacket LPacket ... LPacket

41562

(14)

Software Package

The software package is a Windows based product so as to maintain consistency across all ControlNet software products and to provide a user-friendly human interface. It is composed of a CD-ROM

installation disk plus the reference manual.

Hardware

Recommendations

The ControlNet Traffic Analyzer requires a dedicated computer with the following minimum configuration for:

•Microsoft_{Windows 95}_{or Windows}_{98 or Windows}_Me •166MHz Pentium-based PC

•32MB RAM

•10MB free hard drive space

•a color monitor with an 800 x 600 minimum resolution (1,024 x 768 recommended)

•Microsoft_{Windows NT}_4.0 •166MHz Pentium-based PC

•80MB RAM

•Microsoft_Windows₂₀₀₀_{or Windows}_XP •366MHz Pentium-based PC

•128MB RAM

To capture data on a ControlNet network, one of the following interface cards is required:

•1784-PCC Series B Allen-Bradley ControlNet Interface Card (PCMCIA) with:

•installation disk version 1.6 or later (shipped with the

1784-PCC card). If your installation disk is earlier than 1.6, we recommend that you download the latest version from the website www.ab.com./support/products/pccards.html.

•Microsoft Windows 95, Windows 98, Windows Me, Windows NT 4.0, Windows 2000, or Windows XP

(15)

•1784-PCC Series A Allen-Bradley ControlNet Interface Card (PCMCIA) with:

•installation disk version 1.6 or later (shipped with the

1784-PCC card). If your installation disk is earlier than 1.6, we recommend that you download the latest version from the website www.ab.com./support/products/pccards.html.

•Microsoft Windows 95, Windows 98, Windows Me, Windows 2000, or Windows XP

•CN-1000 Pyramid Solutions ControlNet Interface Card (ISA) with:

•1.4.1F firmware or later

•1.2 driver or later

•Microsoft Windows 95, Windows 98, Windows Me, Windows NT 4.0, Windows 2000, or Windows XP

These interface cards contain a ControlNet ASIC that captures all data on the network. No ControlNet MAC ID is required for the Traffic Analyzer, since the ASIC is in “listen-only” mode. The data will be analyzed by the Traffic Analyzer tool after it has been processed by the ASIC.

Install the Traffic Analyzer

Before you install the 1784-PCC driver and the Traffic Analyzer, you should uninstall the previous version of the Traffic Analyzer.

Uninstall the Previous Version of the Traffic Analyzer

To uninstall the previous version of the Traffic Analyzer:

1. Click Start>Settings>Control Panel.

2. Double click the Add/Remove icon.

3. Double click ControlNet Traffic Analyzer.

4. Click Yes to uninstall the Traffic Analyzer.

TIP

If you are prompted to remove unused shared files, select No to All.

(16)

Install the Traffic Analyzer

1. Insert the CD-ROM into the computer’s CD-ROM drive. If Auto Insert Notification (Autorun) is enabled on your CD-ROM drive, the Setup Utility will start automatically. Go to step 5. Otherwise, continue with step 2.

2. Select Start>Run.

3. At the Run pop-up window, type x:\setup, where x is the CD-ROM drive.

4. Click OK.

5. You see this screen:

6. Click on Install Products.

IMPORTANT We recommend that you exit all Windows programs before

running this Setup program.

TIP

The CD-ROM supports Windows Autorun. If you have Autorun configured, once the CD is inserted into the CD-ROM drive, the installation will automatically start at the first setup screen.

(17)

You see this screen:

7. Click on Install ControlNet Traffic Analyzer.

8. Follow the on-screen instructions to install the driver and the Traffic Analyzer.

You need to have a ControlNet 1784-PCC PC card or a CN-1000 ISA card installed to work on line. If you do not have a card, ask your local Rockwell Automation representative for a 1784-PCC card package at:

•Telephone: 1.440.646.5800

or contact Pyramid Solutions for a CN-1000 card at:

•Web: www.pyrasol.com/Expertise_DataCom_Support.htm The ControlNet Traffic Analyzer has to be the single client of the ControlNet card. You can use the ControlNet 1784-PCC PC card or the CN-1000 ISA card for applications other than the Traffic Analyzer, but you cannot run these applications simultaneously with the same card. If you use another application with the card, you must go in offline mode or close the Traffic Analyzer tool. For more information about the online/offline modes, see page 7-3.

IMPORTANT Some screen savers take all the CPU resources. When the

Traffic Analyzer tool is in data recording mode, it may lose some data. You must choose the “blank screen” or “none” option in the display properties of the Screen Saver.

(18)

Terminology

Use the following table to become familiar with some terms specific to the Traffic Analyzer tool.

IMPORTANT You may need to disable Power Management if data captures

are missing data.

IMPORTANT The ControlNet Traffic Analyzer and RSLinx cannot run

simultaneously via the same network interface card.

Term Refers to

CNA10 the ControlNet ASIC containing the Media Access Control interface circuitry used to send and receive data on a ControlNet network. Connection ID (CID) an identifier assigned to a transmission that is associated with a

particular connection between producers and consumers that identifies a specific piece of application information.

Filter a selection used to let frames that meet a specified condition to pass from the network to the buffer, or from the buffer to the display. For example, you may set up an input filter that will only allow frames with a source MAC ID of 10 to pass from the network to the collection buffer. Fixed Tag a two byte tag that identifies a specific service to be performed by the

node identified in the second byte of the fixed tag. The second byte of the fixed tag contains the MAC ID of the destination node.

Generic Tag a three byte tag that identifies a specific piece of application information (same as Connection ID).

LPacket link packet - data packaged and labeled by a node in preparation for transmission. LPackets contain a header and data.

MAC Frame a collection of MAC symbols transmitted on the medium that contains a preamble, start delimiter, source MAC ID, LPackets, CRC, and end delimiter. After the ASIC processing, a MAC frame contains time, status, type, source MAC ID and LPackets.

MAC Symbol symbols that represent the data bits to be encoded and transmitted by the Physical Layer.

Trigger a collection that causes data collection to start or stop. You specify the condition the same way that a filter is specified.

Trigger Point a point within the collection buffer where a trigger occurs. If the trigger point is at the start of the buffer, data collection will begin when a trigger condition is detected. If the trigger point is at the end of the buffer, data collection will stop when a trigger condition is detected. Unconnected

Message Manager (UCMM)

the component within a node that transmits and receives unconnected explicit messages and sends them directly to the Message Router object.

(19)

Common Techniques Used

in This Manual

The following conventions are used throughout this manual:

•bulleted lists provide information, not procedural steps

•numbered lists provide sequential steps

•text written like this identify screen, menu, and toolbar names

•information in bold contained within text, identify areas of the screen, such as field names, radio buttons and check boxes

•text written like thisidentify icons

•a menu item in this format Control Panel>Define Start Trigger

identifies the submenu item after the caret (>) accessed from the menu

•pictures of symbols and/or screens represent the actual symbols you see or the screens you use

Rockwell Automation

Support

Rockwell Automation offers support services worldwide, with over 75 sales/support offices, 512 authorized distributors, and 260 authorized systems integrators located throughout the United States alone, plus Rockwell Automation representatives in every major country in the world.

Local Product Support

Contact your local Rockwell Automation representative for:

•sales and order support

•product technical training

•warranty support

•support service agreements

Technical Product Assistance

If you need to contact Rockwell Automation for technical assistance, call your local Rockwell Automation representative.

TIP

(20)

Your Questions or Comments About This Manual

If you find a problem with this manual, please notify us of it on the enclosed How Are We Doing form (at the back of this manual).

If you have any suggestions about how we can make this manual more useful to you, please contact us at the following address:

Rockwell Automation, Allen-Bradley Company, Inc. Control and Information Group

Technical Communication 1 Allen-Bradley Drive

(21)

Chapter

2 The ControlNet Traffic Analyzer Tool

What This Chapter Contains

Read this chapter for a description of the options provided in the Traffic Analyzer tool. The following table describes what this chapter contains and where to find specific information.

The User Interface

The User interface of the ControlNet Traffic Analyzertool was designed to be easy to use and to give you the maximum amount of information. When you open a document, you see a window divided into three parts:

• the Control Panel view (upper part)

• the Filter/Trigger view (middle part)

• the MAC Frame Data view (lower part)

These three parts are separated by horizontal splitters that are used to resize the views.

the user interface 2-1 the Control Panel view 2-2 the Filter/Trigger view 2-4 the MAC Frame Data view 2-5

Horizontal splitters Horizontal splitters

(22)

2-2 The ControlNet Traffic Analyzer Tool

The Control Panel View (the Upper Part)

When you launch the Traffic Analyzer tool and open a project, you see a screen similar to the one shown below.

The Control Panel allows you to follow data flow, start and stop analysis, access trigger and filter definitions, and display view options. You can also change data storage behavior (Full or Ring Buffer).

TIP _{If the}_Start_{icon in the Control Panel contains a red X (} _),

you can click the Start icon to access the Hardware Settings dialog box. See "Go Offline/Online Hardware Settings", page 7-3, for more information.

(23)

The ControlNet Traffic Analyzer Tool 2-3

The Control Panel view has two main functions:

•control the document during the configuration of the next record. You can:

•configure triggers and filters in the Filter/Trigger view (but only one type of filter or trigger at a time). You do this via the Control Panel by clicking on the Start Trigger, Stop Trigger,

Pre-Filter or Post-Filter icons. You select one topic for the current view. See the Trigger/Filter views in Chapter 4 for more information.

•click on the Full/Ring Buffer icon to define in which type of buffer the next record will be configured.

•click on the Display icon to access a dialog box in which you choose display options for the MAC Frame Data view. See “Display View Options,” page 5-1, for more information.

The following illustration shows the function of each element of the Traffic Analyzer Control Panel when the Traffic Analyzer is not in data recording mode.

•the second function of the Control Panel is to control the record itself. You can:

•start and stop the data record by clicking on the Start or Stop

icons. You can also perform these two actions from the

Actions menu or by pressing the F10 and F11 keys respectively.

•see how long the data record has been Started via a clock.

•know the number of frames filtered per second after the ASIC and after the pre-filter, respectively via two progress bars (Frames/s) with small edits above.

Click on this icon to change the data buffer behavior.

Click on this icon to view the

Display View Options dialog box. Click on the Start Trigger, Pre-Filter, Post-Filter, or Stop Trigger

(24)

The following illustration shows the function of each element of the Traffic Analyzer Control Panel when the Traffic Analyzer is in data recording mode.

The Filter/Trigger View (the Middle Part)

The Filter/Trigger view is used to configure the triggers or the filters you need for your analysis. Depending on the selection you made in the Control Panel (upper part of the document), you see one of the following four parameters:

•Start Trigger

•Stop Trigger

•Pre-filter

•Post-filter

The middle part of the user interface is shown in the following illustration. The Pre-Filter option has been selected.

See Chapter 4 for a more detailed explanation of the Filter/Trigger view.

Displays the data traffic after pre-filtering. Click on Start Trigger

to process the data. Click on the Start icon to

start analyzing the frames.

Click on the Stop icon to stop analyzing the frames. Displays the data traffic

after CNA10 ASIC filtering of ControlNet. The time the data

capture has been running or started.

(25)

The ControlNet Traffic Analyzer Tool 2-5

The MAC Frame Data View (the Lower Part)

The MAC Frame Data view is used to show the ControlNet MAC frames captured during the analysis. You can have it filtered through the post-filter before the data is displayed.

You have the possibility to view the data in different formats using the display options. Display options are explained in “Display

Information,” Chapter 5.

The following graphic shows an example of MAC Frame Data view, showing three frame records in Interpreted format. See “Data Format,” page 5-2, for an explanation of the three data formats.

MAC Frame Data view information is interpreted as follows:

IMPORTANT If you filter data through the post-filter, you will see only the

data after a post-filtering and not necessarily all data recorded in the buffer. By default, when you open a new document, post-filtering is disabled.

Column header name Identifies

Frame # the number of the recorded MAC frame in the collection buffer.

Time the time formats. The four time formats are days, hours, minutes, and seconds. See “Time Display,” page 5-2 for an explanation of each option.

Status the status of frames. The three statuses are Good, Bad, and Null. See “Status of Frames,” page 4-4 for an explanation of each status. In short display, only the first letter (G, B, or N) of each term displays.

Type the displayed types. The four types are Sched.. (scheduled), Unsch.. (unscheduled), Moder.. (moderator), or Aborted (a special case used only for bad frames). See “ControlNet Messages,” page 1-2 for an explanation of each type. In short display, only the first letter (S, U, M, or A) of each term displays.

(26)

Column header name Identifies

Data the data formats. The three data formats are MAC Frame, Lpacket, and Interpreted. See “Data Format,” page 5-2 for an explanation of the data formats.

(27)

Chapter

3 Accessories and Menus

What This Chapter Contains

Read this chapter for a description of the menu options and other accessories provided in the Traffic Analyzer tool. The following table describes what this chapter contains and where to find specific information.

Accessories

The Toolbar

The toolbar contains buttons for commonly used menu items. Use the toolbar to access these items quickly without opening the menu. Each button is a graphical representation of a command.

The toolbar is shown below. Only the buttons specific to the Traffic Analyzer tool are defined.

accessories 3-1

menus and shortcuts 3-2

Network Information Statistics Next Bookmark Add Bookmark Delete All Bookmarks Previous Bookmark Advanced Find Simple Find Find Previous Find Next Compute Time Difference Display Range Data view (Full Screen) Help About

(28)

3-2 Accessories and Menus

The Status Bar

The Status Bar contains three panes. Each pane’s function is described in the following illustration.

Menus and Shortcuts

Menus are used as entry points to do a specific action within your application. You will sometimes find shortcuts associated to menu entries. A shortcut is a simple way to do an action using a key or a combination of keys. See Appendix A for a list of function and shortcut keys.

You may use the Traffic Analyzer tool without the mouse interface - expect a mouse is required to use the Compute Time Difference dialog box which makes use of the drag and drop function.

Main Menu

The main menu is the entry point to the main actions you can perform in the Traffic Analyzertool. You will find the standard main menu functions (i.e., New, Open, Save) as well as functions specific to the Traffic Analyzer tool.

The following sections contain a summary of all menu options and the corresponding shortcuts.

File Menu

The File menu contains the following options, if a project is not open:

This pane is used to pass messages. These messages appear when you select an action from a menu or from the toolbar. It gives a brief description of the function.

This pane represents an LED and tells the ControlNet driver status.

This pane is used to show status messages from the ControlNet driver. These messages appear when the driver state has changed and could indicate a driver error.

The most recently opened project(s) show in this area. Up to four can be listed.

(29)

Accessories and Menus 3-3

If a project is open, you see the following menu:

Edit Menu

When you click on Edit, you see the following menu:

Or, you see the bookmark menu:

Creates a report in RTF format.

(30)

Or the Find menu:

Actions Menu

When you click on Actions, you see the following menu if a project is not open:

You see the following menu if a project is open:

Once you define a find criterion, you can find the next or previous string that matches the criterion.

Display the Network Monitoring window. You must be connected to a ControlNet network. Display the Statistical Information window. You must be connected to a ControlNet network. Switch to online mode or offline mode. Reset the ControlNet card and ASIC timer.

Start or stop recording the current project.

Only the frames you select will display. Displays the Compute Time Difference

(31)

Or, you see the Control Panel menu:

View Menu

When you click on View, you see the following menu if a project is not open:

Or, if a project is open, you see the following menu:

Displays the Options dialog box.

Make MAC Frame Data view the full screen. Click again to return to normal view.

(32)

Window Menu

You see the following menu when you click on Window:

Help Menu

You see the following menu when you click on Help:

Pop-up Menus

A pop-up menu is hidden until you perform an action that causes it to display. In the ControlNet Traffic Analyzer, pop-up menus are

implemented only from Filter/Trigger view or MAC Frame Data view by clicking the right mouse button.

(33)

Stop Trigger List Pop-up Menu

You see the following pop-up menu when you click the right mouse button in the stop trigger list area of Filter/Trigger view:

Start Trigger List Pop-up Menu

You see the following pop-up menu when you click the right mouse button in the start trigger list area of Filter/Trigger view:

Pre-Filter List Pop-up Menu

You see the following pop-up menu when you click the right mouse button in the pre-filter list area of Filter/Trigger view:

Displays the Edit Trigger dialog box so you can add or edit a trigger condition.

Displays the Trigger on data

dialog box so you can add or edit a trigger on a condition.

Displays the Edit Filter dialog box so you can add or edit a filter condition.

(34)

Post-Filter List Pop-up Menu

There are two list areas for a post-filter. They are referred to as the top list and the bottom list. You see the following pop-up menu when you click the right mouse button in the post-filter top list area:

You see the following pop-up menu when you click the right mouse button in the post-filter bottom list area:

MAC Frame Data View Pop-up Menu

You see the following pop-up menu when you click the right mouse button in MAC Frame Data view:

Displays the Edit Filter dialog box so you can add or edit a filter condition.

Displays the Edit LPacket dialog box so you can add or edit an LPacket condition.

Displays the Display View Options dialog box so you can change display options.

(35)

Chapter

4 Triggers and Filters

What This Chapter Contains

The following table describes what this chapter contains and where to find specific information.

Triggers

A trigger is used to initiate a process or to act as a reaction. There are two types of triggers: start and stop. A start trigger initiates the process; a stop trigger stops the process.

Start Trigger View

You see the Start Trigger view when you click the Start Trigger

icon in the Control Panel or from the Actions menu, click on

Control Panel>Define Start Trigger.

A trigger is a prerequisite condition, a passage toward the pre-filter phase. Once you start a trigger condition, there is nothing else to do. There are two types of trigger conditions: one related to the contents of the frames and the other related to the time elapsed. You can combine the two types of conditions. Triggering will start provided at least one condition is met.

The Start Trigger view is shown below.

triggers 4-1

filters 4-8

Start without conditions. Start with conditions. Define how much time is needed to start the analysis.

Enable/disable trigger condition.

(36)

4-2 Triggers and Filters

You can initiate only one specific Start Trigger: a Start Trigger on Data. See page 4-4 for more information.

The following illustration shows start trigger conditions with a Start Trigger on Data added.

Stop Trigger View

You see the Stop Trigger view when you click the Stop Trigger icon in the Control Panel or from the Actions menu, click on Control

Panel>Define Stop Trigger. There are two types of trigger conditions: one related to the contents of the frames and the other related to the time elapsed. You can combine the two types of conditions.

Triggering will stop provided at least one condition is met.

You can check the Center Trigger in Ring Buffer box to add data following the first Stop on Conditions and keep the preceding data as well. Otherwise, when the box is not checked, the data in the buffer is the data preceding the Stop Trigger.

The Stop Trigger view is shown below.

Start Trigger on Data.

Stop without conditions. _{Stop with conditions.}

Define how much time is needed to stop the analysis after a Start.

Stop the trigger in the center of the Ring buffer, keeping data preceding and adding data following the given condition.

Enable/disable trigger condition.

(37)

Triggers and Filters 4-3

How to Configure a Trigger

When you choose to start or stop a trigger on a condition, a trigger list area appears. You can add, edit, or delete conditions in this list area by clicking the right mouse button. A pop-up menu appears.

When you add or edit a trigger condition, you see the following box:

TIP

Another way you can add, edit, or delete a trigger condition is by pressing the Insert, Enter, or Delete key, respectively.

Define the Producer MAC ID(s) you want to trigger. You can define: • a single Producer MAC ID (in a range 0-255).

• a group of IDs. Separate the range by a hyphen (2-88). The range can extended from 0 to 255. • multiple IDs. Separate the IDs by a semi-colon (2;9;27) a group and multiple IDs (2-7;3;8). If you do not enter a value in this field, the full range (0-255) becomes the default value.

Define the Producer MAC ID(s) you want to trigger in each LPacket. • For a Generic LPacket, it is the Producer/Consumer ID. • For a Fixed LPacket, it is the Destination ID.

• For a Broadcast ID, it is 255. You can define:

• a single Producer/Consumer MAC ID (in a range 0-255). • a group of IDs. Separate the range by a hyphen (2-88).

The range can extended from 0 to 255.

• multiple IDs. Separate the IDs by a semi-colon (2;9;27). • a group and multiple IDs (2-7;3;8).

(38)

Status of Frames

A frame status can be defined in three ways:

•Good: a frame correctly received by the Traffic Analyzer tool.

•Bad: the Traffic Analyzer tool has detected a problem with this frame (e.g. a CRC problem).

•Null: a frame without any data.

Type of Frame

A frame type can also be defined in three ways:

•Scheduled

•Unscheduled

•Moderator

See page 1-2 for a definition of frame types.

How to Configure a Start Trigger on Data

When you want to add trigger onto data, you add a Start Trigger on Data condition. This implies that you are looking for a specific element and that you know its source, the type of frame, and its destination.

At the LPacket level, the standard trigger only checks for the Producer/Consumer MAC ID in a Generic LPacket or for the

Destination MAC ID in a Fixed LPacket. Within these limits, you can create an unlimited list of trigger conditions that will not affect the processing time during the record.

If you want to start after a specific LPacket - for example if there is a sign of future network troubles - you can create a unique and elaborate trigger condition on an LPacket.

TIP

For a definition of Status, see below. For a definition of Type, see page 1-2.

(39)

Each byte in the LPacket Header can be checked; a sequence of a maximum of 8 bytes will appear in the LPacket data field.

When you choose to start a trigger on a condition, a trigger list area appears. You can add, edit, or delete a Start Trigger on Data condition in this list area by clicking the right mouse button. A pop-up menu appears. Only one Start Trigger on Data can be created at one time. Once a Start Trigger on Data has been added, it can be edited or deleted. Also, you can create a Start Trigger on Data only on Good Scheduled or Good Unscheduled frames.

If you choose to add or edit a Start Trigger on Data, the Trigger on data dialog box appears. You must enter a value in the Producer MAC ID and/or Consumer MAC ID, and link data (if an offset is defined) field(s). Three examples follow showing the different options you can choose in this dialog box.

(40)

Example 1: Fixed LPacket

When you want to add a Start Trigger on Data with a fixed Tag, you see the following dialog box.

Enter the Producer MAC ID you want to trigger.

Define the frame type.

Choose the type of LPacket you want to trigger.

Enter the size of the LPacket you want to trigger (enter in hexadecimal).

Enter the control bits of the LPacket you want to trigger (enter in hexadecimal). The fields reflect the value entered in the Control Bits

field above. See “Interpreting Control Bits,” page 4-16. Enter the LPacket Link Data Offset in hexadecimal. The LPacket Link Data Offset 0 starts after the LPacket Header.

Enter the Link Data you want to check. Enter in

hexadecimal, limited to eight characters.

When Fixed Tag is chosen, enter the Service byte in hexadecimal.

Enter the destination MAC ID you want to trigger.

Select a predefined UCMM service. This value will automatically set the Offset and Link Data. Use this as a quick way to find a service without entering it. This option is disabled if Generic Tag is selected.

(41)

Example 2: Generic LPacket

When you choose Generic Tag, two new fields appear to define the Connection ID. They replace the Service and Consumer MAC ID

fields.

Set the Connection ID Number in hexadecimal. Define the Producer/Consumer

MAC ID you want to trigger.

The Predefined UCMM Service is disable when Generic Tag is chosen.

(42)

Example 3: Fixed LPacket Using the UCMM Service List

When you want to use a predefined UCMM Service, you see the following dialog box.

Filters

Filtering refers to a selection used to allow frames that meet a specified condition to pass from the network to the buffer, or from the buffer to the display. For example, you may set up an input filter that will only let frames with a source MAC ID of 10 to pass from the network to the collection buffer. There are two filtering levels:

•Pre-filter: determine which frames you will put into the buffer. This is a sorting procedure used mainly for adding filters on the destination of a frame.

•Post-filter: determine which frames are going to be in the buffer, i.e., which ones you want to see on the screen. This is the second level of sorting, more precise and elaborate than the pre-filter sort.

The UCMM Service number is 0x83.

The LPacket Data Offset and Link Data values are forced to match the selected UCMM Service.

(43)

Pre-Filter View

You see this view when you have selected the Pre-Filter icon in the Control Panel.

The Pre-filter view is shown below.

Disable Time Stamp

ASIC provides time indication for each frame. If the network traffic conditions are extremely heavy and/or the data capture is missing traffic, then you may need to lighten the task of the ASIC. You can do this by disabling the Time Stamp. See Chapter 8, “Troubleshooting.”

How to Configure a Pre-Filter

When you choose to filter on conditions, a filter condition list area appears. You can add, edit, or delete a pre-filter condition in this list area by clicking the right mouse button. A pop-up menu appears.

TIP You can also access the Pre-Filter view from the Actions

menu: Control Panel>Define Pre-Filter.

TIP Another way you can add, edit, or delete a filter condition is by

pressing the Insert, Enter, or Delete key, respectively.

Click on this radio button to get all frames from the network except the null.

Check this box to Disable the time stamping (the time will not be included in the data capture).

Enable/disable filter condition.

Pre-Filter condition.

Click on this radio button to filter on conditions.

(44)

When you add or edit a pre-filter, you see the following dialog box:

TIP For a definition of Status, see page 4-4.

For a definition of Type, see page 1-2.

Define the Producer MAC ID(s) you want to filter. You can define: • a single Producer MAC ID (in a range 0-255).

• a group of IDs. Separate the range by a hyphen (2-88). The range can extended from 0 to 255.

If you do not enter a value in this field, the full range (0-255) becomes the default value.

Define the Producer MAC ID(s) you want to filter in each LPacket. • For a Generic LPacket, it is the Producer/Consumer ID. • For a Fixed LPacket, it is the Destination ID.

• For a Broadcast ID, it is 255. You can define:

• a single Producer/Consumer MAC ID (in a range 0-255). • a group of IDs. Separate the range by a hypen (2-88).

(45)

Post-Filter View

You see this view when you have selected the Post-Filter icon in the Control Panel.

How to Configure a Post-Filter

Defining a post-filter is a little bit more complex than defining a pre-filter. Post-filtering provides a more precise way of filtering. When you choose to post-filter on conditions, two filter condition list areas appear. These two lists have been designed to show all the

information needed by the post-filter.

•the first list looks like the Pre-Filter list and performs almost the same function; it will be referred to as the top list.

•the second list is used to filter on some LPacket data and will be referred to as the bottom list.

TIP You can also access the Post-Filter view from the Actions

menu: Control Panel>Define Pre-Filter.

Click on this radio button to get all stored frames from the Data Buffer.

Click this button to enable any changes in post-filtering. This will update the MAC Frame Data view.

First Post-Filter condition. The “Yes” means LPacket filter is enabled. Enable/disable

filter condition.

Second Post-Filter condition. LPacket filter is enabled. Click on this radio

button to filter on conditions.

(46)

You can add, edit, or delete a post-filter condition in these two list areas by clicking the right mouse button. A pop-up menu appears.

When you add or edit a post-filter in the top list, you see the following dialog box:

TIP Another way you can add, edit, or delete a post-filter condition

is by pressing the Insert, Enter, or Delete key, respectively.

Define the Producer MAC ID(s) you want to filter. You can define: • a single Producer MAC ID (in a range 0-255).

• a group of IDs. Separate the range by a hyphen (2-88). The range can extended from 0 to 255.

If you do not enter a value in this field, the full range (0-255) becomes the default value.

Enable filter on an LPacket. This enables the bottom post-filter list. You will see a “Yes” in the Filter LPacket column in the Filter/Trigger view.

Disable filter on an LPacket. This disables the bottom post-filter list. You will see a “No” in the Filter LPacket column in the Filter/Trigger view.

TIP For a definition of Status, see page 4-4.

(47)

When you enable LPacket filtering and you want to add or edit frame conditions in the bottom list, you see the following dialog box:

•Size

•Ctrl Bits

•Prod/Cons MAC ID

•Link Data and an Offset

Enter the size of the LPacket header (in hexadecimal).

Define the Producer/Consumer MAC ID(s) you want to filter in each LPacket. • for a Generic LPacket, it is the Producer/Consumer ID.

• for a Fixed LPacket, it is the Destination ID. • for a Broadcast ID, it is 255.

You can define:

• a single Producer/Consumer MAC ID (in a range 0-255). • a group of IDs. Separate the range by a hypen (2-88).

• If you do not enter a value in this field, the full range (0-255) becomes the default value. When Any Tag is selected, you

cannot base your selection on Tag values.

Enter the control bits of the LPacket header (in hexadecimal). The fields reflect the value entered in the Control Bits

field above. See “Interpreting Control Bits,” page 4-16.

Enter the LPacket Link Data Offset (in hexadecimal).

Enter the LPacket Link Data you want to check (in hexadecimal).

IMPORTANT In the preceding example, all the fields have been filled in for

illustration purposes but not all of them are required fields. When Any Tag is checked, only one of the following fields must be filled in:

(48)

When you choose the Fixed Tag option, the Service field appears and you see the following dialog box:

If you don’t enter a value in the Ctrl Bits field, “Fixed” appears in the Control Bits column in the bottom list area of Post-Filter view. If the Ctrl Bitsfield is filled in, the interface checks the consistency with the Fixed Tag option; in the Post-Filter view,

Control Bits field, a hexadecimal value will replace the “Fixed” string. See “Interpreting Control Bits,” page 4-16.

When Fixed Tag is chosen, the Service field appears.

The UCMM Service number is forced at 0x83 when a predefined UCMM Service is selected.

The values in the Offset and Link Data fields are forced when a predefined UCMM Service is selected.

Select a predefined UCMM Service.

IMPORTANT When Fixed Tag is chosen, it is not necessary to fill any fields

because the Fixed Tag option is automatically entered on several bits in the Control Bits field (see the Acc. Always, Tag Pad, and Fixed Screen fields above).

(49)

When you choose the Generic Tag option, the Connection field appears and you see the following dialog box:

If you don’t enter a value in the Ctrl Bits field, “Generic” appears in the Control Bits column in the bottom list area of Post-Filter view. If the Ctrl Bits field is filled in, the interface checks the consistency with the Generic Tag option; in the Post-Filter view,

Control Bits field, a hexadecimal value will replace the “Generic” string. See “Interpreting Control Bits,” on the next page.

IMPORTANT When Generic Tag is chosen, it is not necessary to fill any

fields because the Generic Tag option is automatically entered on several bits in the Control Bits field.

When Generic Tag is chosen, the Connection Number field appears.

Enter the Connection Number in hexadecimal.

(50)

Interpreting Control Bits

The bits of the control field are numbered 0 through 7 and are described below.

Bit 0 - Fixed Tag (type of LPacket)

Bit 0 is the least significant bit of the control field. Bit 0 indicates the type of LPacket. When set (bit 0 = 1), the LPacket is a fixed tag LPacket. Conversely, when clear (bit 0 = 0), the LPacket is a generic tag LPacket.

Bit 1 - Tag Pad (Odd Tag Size)

Bit 1 of the control field indicates whether the tag field contains an even or odd number of bytes. When clear (bit 1 = 0), it indicates that the tag contains an even number of bytes. When set (bit 1 = 1), it indicates that the tag contains an odd number of bytes. A fixed LPacket has an even tag so bit 1 = 0 and a generic LPacket has an odd tag so bit 1 = 1.

Bit 2 - Data Pad (Odd Link Data Size)

Bit 2 of the control field indicates whether the link data contains an even or odd number of bytes. When clear (bit 2 = 0), it indicates that the link data contains an even number of bytes. When set (bit 2 = 1), it indicates that the link data contains an odd number of bytes.

Bit 3 - Reserved

Bit 3 of the control field is reserved.

Bit 4 - Generic Tag (Type of LPacket)

Bit 4 of the control field is the inverse of bit 0 (see bit 0 above). If bit 0 is clear, then bit 4 will be set. If bit 0 is set, then bit 4 will be clear.

Bit 5, 6, 7 - Reserved 7:5

(51)

Chapter

5 Display Information

What This Chapter Contains

If you do not change the Traffic Analyzer controls in any way, the data will display the same way it displayed after the last post-filter you defined. You have the option of displaying data differently using the Display View Options dialog box. The following table describes what this chapter contains and where you can find specific information.

Display View Options

When you are ready to create a new document, you can choose display options. The Display View Options dialog box enables you to choose both time display and data format options.

The Display View Options dialog box is shown below.

display view options 5-1

tools to manage frames 5-6

IMPORTANT You can change the default display view options. They

will apply to every new project you create until you change the options again. See page 7-11 for more information.

(52)

5-2 Display Information

Time Display

The time can be expressed as absolute or relative. You can also change the time resolution.

The Display View Options dialog box appears when you click on the

Display icon on the Control Panel or, in the MAC Frame Data view area, click right with the mouse button and click Define Display. The time display options are defined below.

You can change the type of time information that will show in MAC Frame Data view.

Data Format

The following section describes the three data format options.

Data can be viewed in three ways:

• MAC Frame

• LPacket

• Interpreted

Click this button To

No Time remove the Time column from MAC Frame Data view. Select this option if the time is not significant.

Absolute Time express the time as absolute – from the time when ASIC was started.

Relative Time express the time as relative to the first pre-filter frame. Time between Frames express the time between two sequential frames in MAC

Frame Data view.

IMPORTANT If the last record was configured with the Pre-Filter Disable

Time Stamp option enabled, all Time Display options will be in shadow (no access to them). The No Time option will be forced.

Click on To show the time the data was collected in

Days days, hours, minutes, and seconds Hours hours, minutes, and seconds Minutes minutes and seconds Seconds seconds

(53)

Display Information 5-3

MAC Frames

MAC Frame data is displayed in hexadecimal, plain information with no separation between each other. The MAC Frame data format is shown below.

Between two LPackets, the CNA10 ASIC adds two bytes, which are shown only in the hexadecimal display. Use the following table of CNA10 ASIC tag index and description to interpret these two bytes.

Please note that bad MAC Frames are always displayed in the MAC Frame format. An example is shown below with the LPacket tag index underlined.

LPackets

Data is displayed in hexadecimal but the different LPackets are separated from one another. A small arrow on the left side of the text indicates a new LPacket is starting. The LPacket data format is shown below.

CNA10 Tag Index Description

sm, 0xF8 LPacket from the NAP port sm, 0xF9 Scheduled LPacket from the wire sm, 0xFA Unscheduled LPacket from the wire sm, 0xFB Moderator LPacket from the wire Note: sm = Source MAC ID

(54)

Interpreted

Each LPacket Header is interpreted. The first two lines of each LPacket details the contents of the LPacket Header. The Interpreted data format is shown below.

The next two sections describe LPacket Header information for fixed and generic tags.

LPacket Header for a Fixed Tag:

The LPacket Header for a fixed tag is composed of: Size + Control bits + Service + Destination MAC ID.

See the following table for fixed tag service numbers and their description.

Fixed Tag Service Description

0x00 Moderator

0x01 – 0x08 Vendor specific 0x09 Ping request 0x0A – 0x14 Vendor specific

0x15 tMinus

0x16 – 0x28 Vendor specific 0x29 Ping reply 0x2A – 0x3F Vendor specific 0x40 – 0x6F Reserved 0x70 – 0x7F Vendor specific 0x80 I’m alive 0x81 Link parameters 0x82 Reserved 0x83 UCMM 0x84 TUI 0x85 Reserved for IP 0x86 WAMI

(55)

In case of a UCMM Service, a third line is added and interprets the first byte of the LPacket data, which contains the UCMM command code. See the Interpreted data format, page 5-4, Frame # 1, for an example.

See the following table for UCMM commands and their descriptions.

Lpacket Header for a Generic Tag:

The LPacket Header for a generic tag is composed of: Size + Control bits + Connection ID (CID). The CID is composed of a Consumer or Producer MAC ID plus a Connection Number.

See the ControlNet International Specification for more information on service numbers and commands. The ControlNet International

Specification can be purchased from ControlNet International.

Fixed Tag Service Description

0x87 Reserved 0x88 Keeper UCMM 0x89 – 0x8B Reserved 0x8C – 0x8F Time distribution 0x90 Debug 0x91 – 0xAF Reserved 0xD0 – 0xEF Group addresses 0xF0 – 0xFF Vendor specific

Command Description

0 Reserved

0x01 Acknowledge a request

0x02 Request with retry until acknowledged 0x03 Response with retry until acknowledged 0x04 Request with no acknowledge and no response 0x05 Acknowledge a response

0x06 Response which will not retry (no acknowledge) 0x07 Request with retry until response (no acknowledge)

0x08 Request which will not retry and will cause a code 6 response 0x09-0xFF Reserved

(56)

Other Options

Three other options appear in the Data Format section of the Display View Options dialog box:

•Show ASCII - if you check this box, the ASCII column displays

•Short Display - if you check this box, the Status and Type

columns take on an abbreviated form (only the initials of each status and type display)

•Show Frame # - if you check this box, the Frame # column displays

Tools to Manage Frames

The Traffic Analyzer tool contains several functions to help you manage the documents you create.

Bookmarks

If you want to mark some data lines, you can set bookmarks on them. Bookmarks are used to easily jump from one marked line to another.

The Traffic Analyzer tool provides the following Bookmark options:

• Add/Remove bookmarks

• Go to the Next bookmark

• Go to the Previous bookmark

• Delete all bookmarks

Access these bookmark options from the Edit menu, the MAC Frame Data view pop-up menu, or use the corresponding Hot keys. See “Edit Menu,” page 3-3, for more information.

When you add a bookmark on a line, a small flag ( ) displays in the left margin. Once you have added two or more bookmarks, you can use the Go to Next or Go to Previous bookmark options to jump from one bookmark to another.

The current bookmark looks like this: . When you want to jump to the next or the previous bookmark, you always do it from the current bookmark. Use the Delete All bookmark option to delete all the bookmarks.

(57)

Find Data

The Traffic Analyzer tool provides two find options: simple find and advanced find.

Simple Find

Use the simple find function to search for ASCII or Hexadecimal data within MAC Frame Data view. Access Simple Find from the Edit menu. You see this dialog box:

The Find function will rest on the first byte found in the data column of each MAC Frame, in however data format it is displayed.

Advanced Find

Use the advance find function to search directly for coded information in a MAC Frame. Access the Advanced Find function from the Edit

(58)

When you access Advanced Find, you see the following dialog box:

Enter the type of information you want to search for (Producer MAC ID, Frame Status/Type, Prod/Cons MAC ID, etc.) then click OK and the search will start. If the information is found, the corresponding line comes in view highlighted for easy recognition.

Select a Range of Frames

Use this function to select a range of frames for display. Access the

Select Range of Frames dialog box from the MAC Frame Data view pop-up menu.

The top part of this dialog box is similar to the Edit Filter dialog box in Post-Filter. See page 4-12 for more information.

The bottom part of this dialog box is similar to the Edit LPacket dialog box in post-filter. Note the three different LPacket Header tags. Each tag has a slightly different dialog box. See pages 4-13 through 4-15 for more information.

Click this box to show or hide the bottom part of this dialog box.

(59)

You see this dialog box:

Enter the first frame in the range in the Min frame number box and the last frame in the range in the Max frame number box and click OK. By default, the range of frames displayed correspond to the minimum & maximum frame numbers contained in the current document. You can only reduce the range.

Compute Time Difference

Use this function to compute the time difference between two ControlNet frames. Access the Compute Time Difference dialog box from the MAC Frame Data view pop-up menu.

You see this dialog box:

Enter Time T1 and Time T2 values by clicking on a frame in MAC Frame Data view and dragging and dropping it into the Time T1 or

Time T2 box.

Click on the pin to activate the dialog box. When pinned, the box is always visible.

The frame number of the frame is used to easily retrieve the corresponding frame.

The Compare Time result window always shows the positive time difference between T1 and T2.

(60)

After you drop a frame in either the T1 or T2 box, you see a marker next to the corresponding frame in MAC Frame Data view. The markers are shown below.

Next to the frame you dropped in the T1 box you see this marker

Next to the frame you dropped in the T2 box you see this marker

These markers serve as an easy way to retrieve a frame that is used as a time comparison value.

To hide this window, click on the pin button so it is in the “not pin” state. Then click in another window or just click on the X button.

Copy Data to the Clipboard

You can copy some frame data in text format and use it as

documentation. Select some lines from MAC Frame Data view and choose Copy Data to Clipboard from the MAC Frame Data view

pop-up menu or use the CTRL+C shortcut. To retrieve the data, open a word processing application and use the paste function.

You can select more than one line at a time. To select lines in a sequence:

1. Click on a line.

2. Hold the Shift key down.

3. Click on the last line in the range.

To select non-sequential lines hold the Ctrl key down while you click on the lines you want to select.

The data format will correspond to the one that is displayed in MAC Frame Data view.

(61)

Chapter

6 Network Information and Statistics

What This Chapter Contains

Network information and statistics cover 1 through 99 nodes. The following table describes what this chapter contains and where specific information can be found:

Network Information

The network information corresponds to dynamic data collection over the ControlNet network. The following

information is contained within the Network Information dialog box:

• Mini-Who - displays the active nodes on the network.

• some network attributes - the network attribute commands analyze the current moderator frames and display the following attributes:

• Network Update Time (ms)

• Scheduled Max. Node

• Unscheduled Max. Node

• Slot Time (

µ

s)

• Blanking Time

• Guard Band Start (

µ

s)

• Guard Band Center (

µ

s)

• Guard Band Prestart (

µ

s)

• Interval Modulus (NUTs)

• other network information that does not come from the moderator. This information corresponds to Scheduled and Unscheduled elements, for which the following

information is provided:

• scheduled information in the Interval Modulus average bandwidth used and maximum bandwidth used

• average available unscheduled information and average used unscheduled information in the Interval Modulus, both expressed in bytes per second

To read about the option See page

network information 6-1
