Schindler 5500 Efficiency. Flexibility. Performance.

Schindler Passenger Elevators

Schindler 5500

Key figures

Capacity 2100 lb (950 kg) to 5000 lb (2270) kg

Travel height Up to 350 ft (107 m)

Door width Up to 4’6”

Door height Up to 9’

Ceiling height Up to 10’

Drive PF1 regenerative drive standard

Speed 200 to 500 fpm (1.0 to 2.5 m/s)

Number of floors 33 stops, 40 landings

Efficiency means advanced technology,

implemented with care for the environment.

Machine room less (MRL) configurations save valuable building space, shorten installation time and reduce power consumption. Configurations with a machine room above and/or the

counterweight on the rear of the hoistway are possible.

Drive

High-performance gearless machine offers economical and environmentally-friendly operation. Variable-frequency control delivers a smooth ride, free of vibrations. Advanced compact motor is optimized to save energy, emit minimal heat and to run quietly. This results in true comfort for the passengers.

Suspension traction media

The innovative suspension traction media replaces conventional steel ropes. It’s lighter, needs less space and is quieter. Thanks to this innovation, less noise is transmitted to the car and building. The hoistway is efficiently utilized and ride comfort is significantly improved.

Car

The car is centrally guided and ideally balanced, which reduces friction and energy losses. The concept allows flexible car dimensions, offering much greater planning freedom. Car and landing operating panels have easily readable LED indicators with energy-saving performance.

Control

The highly integrated microprocessor control system optimally manages the diverse operations of up to six elevators. Numerous options are available, including energy-saving standby operation. When the car is empty, the car lighting and ventilation are automatically switched into energy saving mode.

You design. We deliver.

Laminate design

For a fresh look and feel, choose from colorful laminates. The value-for-money laminate design line creates a pleasant car atmosphere with a wide selection of finishes. This economical approach offers you a full range of design possibilities to suite your own personal vision.

Stainless steel design

Stainless steel gives a more clean and modern look. Start your concept for upscale residential or commercial buildings with an equally attractive elevator car dressed in brushed stainless steel. Choosing the bare car approach allows you to create your own custom design.

Laminate design Side walls: Atlanta Berry

Back Wall: Left and right rear wall mirror panels with center Atlanta Berry panel Handrails: Round brushed stainless steel rails on side walls with straight endings Ceiling: Brushed stainless steel with LED downlight

Stainless steel design Side walls: Brushed stainless steel Back wall: Brushed stainless steel

Handrail: Round brushed stainless steel rails on back wall with straight endings Ceiling: Brushed stainless steel with LED downlight

Not just for the eyes. Ambiance too.

Ceilings

For either laminate or stainless steel car designs, your suspended ceiling will have striking spot LED downlight.

Round stainless steel handrail Handrails

Round stainless steel handrails can complete the cars look and convey a feeling of security.

LED downlight

Fixtures and car operating panels

Make your elevator easy to operate for all passengers. Energy efficient operating panels all come in high quality materials and finishing. High-resolution and easy-to-read LED indicators make the ride even more enjoyable.

PORT Terminal

This new range of hall call destination terminals delivers brainpower to your building. Various PORT Terminal options are available to optimize traffic flows. For detailed information, visit www.theporttechnology.com.

PORT Terminal with card reader Car operating panels Car direction arrows Landing operating panel

Eye-catching transparency

From glass walls and doors to glass cars

Experience maximum visibility and unique views like never before. Select from a wide range of glass doors that suit your application. Glass can be selected for side and rear walls of the car for complete transparency or combined with other car interior materials.

Note: Specifications, options and colors are subject to change. All cabins and options illustrated in this flyer are representative only. The samples shown may vary from the original in color and material.

Glass rear and side walls with glass door Frames for glass walls are available in three stainless steel finishes. _{Glass door}

Glass rear wall

Glass side walls

Brushed Stainless Mirror Stainless

Glass side walls with brushed stainless steel rear wall and ceiling with LED lighting.

Rear glass wall with brushed stainless steel side walls and ceiling with LED lighting.

A perfect reflection

Mirrors add a new perspective

Half-height rear wall mirror Left and right rear wall mirror panels

Mirrors

The spacious design of the car can be enlarged with mirrors. Choose from the following options:

– Full-height mirror for the full width of the rear wall – Half-height mirror for the full width of the rear wall – Full-height mirror, in any combination, for the panels

of the rear wall.

Full-height mirror panels Full-height

mirror panels Full-height mirror

Half-height mirror

Note: Specifications, options and colors are subject to change. All cabins and options illustrated in this flyer are representative only. The samples shown may vary from the original in color and material.

Woodgrains

Raleigh Blonde

Washington Cherry Charleston Cherry

Calgary Maple

Columbia Walnut New York Night

Austin Oak

Shaker Heights Cherry

Denver High Line St. Louis Teak

Solids

Edmonton White

Vancouver White Sacramento Almond Atlanta Berry Napa Burgundy

Montreal Blue

Las Vegas Atlantis Havasu Beige Tucson Pepper Memphis Grey

Textures

Scottsdale Crisp Linen

San Francisco Elm Santa Fe Strandz

Seattle Park Elm

San Antonio Astro

Milwaukee Pewter Hampton Classic Linen

Detroit Satin Stainless Pittsburgh Steel

Note: Specifications, options and colors are subject to change. All cabins and options illustrated in this flyer are representative only. The samples shown may vary from the original in color and material.

From contemporary to classic

Stainless steel and laminate finishes

Stainless

BRN-1019g

L15PDF

© Schindler Elevator Corpor

ation

Ever greener

Keeping the environment in mind

Schindler is committed to helping you reduce the environmental footprint of your buildings and qualify for LEED® _{certification by incorporating}

sustainable green features into our elevator and escalator systems. Improving the environmental impact of our products and processes, particularly our consumption of energy and materials, is fundamental to our corporate responsibility as an industry leader. Schindler 5500 is a prime example of our continuing commitment to improve mobility while preserving resources.

LEED is a registered trademark of the U.S. Green Building Council
