High Quality 15P Cable Coiled Air Lines
High Quality EBS Cable High Quality Adapter Cable 15P Power LECTRA COIL TM EBS DURACOIL TM
ABS DURACOIL TM 15P Power Socket EBS Socket ABS Socket 7S Socket 7N Socket
7S with WEATHER-TITE™ Cable
Adapter Cable Adapter C able ISO QCS® Corrosion-Proof EBS Quick-Change Socket ISO QCS® Corrosion-Proof ABS Quick-Change Socket ISO QCS® Corrosion-Proof 15P Quick-Change Socket Adapter box 15 P /24V
TABLE OF CONTENTS
TABLE OF CONTENTS
Phillips Industries has compiled the information contained herein from what it believes are authoritative sources and believes that it is accurate and factual as of the date printed. It is offered solely as a convenience to its customers and is intended only as a guide concerning the products mentioned. Since the user's product formulation, specific use application and conditions of use are beyond Phillips Industries control, Phillips Industries makes no warranty or representation regarding the results that may be obtained by the user, or its suitability or any products mentioned for the user's specific appli -cation. This information is not to be taken as a warranty or representation for which Phillips Industries assumes legal responsibility nor as permission to use any patented inventions without a license. Copyright © 2020 Phillips Industries. All rights reserved.
15-Pin Plug and EBS Plug
15-Pin Plug, EBS Plug, ABS Plug, ISO 7N & 7S Plugs, Clang Plug
15-Pin Sockets, EBS Sockets, ABS Sockets, ISO 7N & 7S Sockets, QCS® Socket Assemblies,
Parking Sockets, Clang Socket, Adapters and Accessories
15-Pin Plug, EBS Plug, ABS Plug, ISO 7N & 7S Plugs
Service and Emergency Air Coils and Air Coil Accessories Palm Couplers (Service and Emergency)
7-Pin, EBS, ABS
15-Pin Cables, 7-Pin EBS Cables, and Adapter Cable
15-Pin Cables, EBS Cables, ABS Cables, 7N & 7S Cables, Adapter Cables
High Quality Standard Trucks Electrical Assemblies
COLOR-BY-FUNCTION™ Plugs
COLOR-BY-FUNCTION™ Electrical Assemblies
COLOR-BY-FUNCTION™ Sockets
High Quality Standard Truck Electrical Plugs
High Quality Standard Truck Electrical Sockets
Hihgh Quality Standard 12V Assemblies
Air Coil Accesories
Air Assemblies
Low Pressure Tubes
5
19
9
21
12
23
25
28
30
26
O-ring seal prohibits water
from entering the plug
when connected to the
socket*
COLOR-BY-FUNCTION™
Electrical Assemblies
* Standard on Phillips ABS, EBS and 15P electrical cables
360º sealed cable guard
eliminates moisture and
corrosion*
Color-coded plug saves
time by easily identifying
cable application
Brass pins automatically
align to all brands of
sockets
Stainless steel plug-lock
provides a corrosion resistant,
long-life connection*
Jacketing designed to perform in
temperatures of -40ºC to 125ºC
Excellent recoil memory,
chemical and abrasion
resistance in extreme
conditions*
Unbreakable connectors
made from a proprietary
blend of high-strength
materials
POWER (15-Pin)
ABS (5-Pin)
EBS (7-Pin)
LECTRACOIL™ Power Cable
COLOR BY FUNCTION™
EURO 6
CO
MPLIANT
C O
M P L A I N
T
ELECTRICAL ASSEMBLIES - COLOR BY FUNCTION™
In an industry of black connectors and cables, Phillips makes it safe and easy to identify cable, plug and socket function from a distance. This helps eliminate confusion for the driver, increases safety and decreases repair and replacement time.
5-PIN
COLOR BY FUNCTION™
• Excellent recoil memory, abrasion, chemical and corrosion resistance • Durable jacketing flexible from -40°C to 125°C
• Jacket and plugs are color-coded dark blue for easy function identification from a distance
• ISO 7638 specifications for EBS systems compliance • ADR/GGVS approved for hazardous goods applications
• Excellent recoil memory, abrasion, chemical and corrosion resistance • Durable jacketing flexible from -40°C to 125°C
• Jacket and plugs are color-coded light blue for easy function identification from a distance
• ISO 7638 specifications for ABS systems compliance • ADR/GGVS approved for hazardous goods applications
7-PIN
EBS DURACOIL™
ABS DURACOIL™
LECTRACOIL™ Power Cable
• Excellent recoil memory, abrasion, chemical and corrosion resistance • Durable jacketing flexible from -40°C to 125°C
• Jacket and plugs are color-coded green for easy function identification from a distance
• ISO 12098 compliance
• ADR/GGVS approved for hazardous goods applications
15-PIN
EURO 6
CO MPLIANT C OM P L A I NTEURO 6
COMPLIANT C OM P L A I NT Part No. 683-7052 683-7072Maximum Extension Length 3.5 m 4.5 m
FLRY 12x1,5 mm2 +3x2,5 mm2
Color Green
Part No. 662-5052 662-5072
Maximum Extension Length 3.5 m 4.5 m
FLRY 5x1,5 mm2 +2x4,0 mm2
Color Dark Blue
LECTRACOIL
TM15-PIN Power Cable
EBS DURACOIL
TMCable
Part No. 661-3052 661-3072
Maximum Extension Length 3.5 m 4.5 m
FLRY 3x1,5 mm2 +2x4,0 mm2
Color Light Blue
ABS DURACOIL
TMCable
EURO 6
COMPLIANT
C OM P L A I NT
ELECTRICAL ASSEMBLIES - COLOR BY FUNCTION™
PERMACOIL™ 7N
• The WEATHER-TITE™ seal protects against corrosion and blocks contaminants from entering the electrical system
• Unbreakable and non-corrosive housing
• 360º compression ring secures plug to cable and significantly reduces moisture and corrosion
• Jacket is color-coded black for easy function identification from a distance • Good recoil memory, abrasion, chemical and corrosion resistance • Flexible from -40ºC to 125ºC • ISO 1185 compliance
EURO 6
COMPLIANT C OM P L A I NTEURO 6
COMPLIANT C OM P L A I NT • The WEATHER-TITE™ seal protects against corro-sion and blocks contaminants from entering the electrical system
• Great recoil memory, abrasion, chemical and corrosion resistance
• 360º compression ring secures plug to cable and significantly reduces moisture and corrosion • ISO 1185 & ISO 3731 compliance
7N & 7S PERMACOIL™
WEATHER-TITE™Electrical Cables
WEATHER-TITE™
PERMACOIL™ 7S
• The WEATHER-TITE™ seal protects against corrosion and blocks contaminants from entering the electrical system
• Unbreakable and non-corrosive housing
• 360º compression ring secures plug to cable and significantly reduces moisture and corrosion
• Good recoil memory, abrasion, chemical and corrosion resistance
• Jacket and plugs are color-coded yellow for easy function identification from a distance
• Flexible from -40ºC to 125ºC • ISO 3731 compliance
WEATHER-TITE™ Corrosion Resistant Seal WEATHER-TITE™
CORROSION RESISTANT SEAL
WEATHER-TITE™ Corrosion Resistant Seal
Part No. 636-5256 636-5276
Maximum Extension Length 3.5 m 4.5 m
FLRY 6x1,5 mm2 +1x2,5 mm2
Color Black
Part No. 647-5256 647-5276
Maximum Extension Length 3.5 m 4.5 m
FLRY 6x1,5 mm2 +1x2,5 mm2
Color Yellow
Part No. 636-5656 636-5676
Maximum Extension Length 3.5 mm 4.5 mm
FLRY 6x1,0 mm2 +1x1,5 mm2
Color Black
Part No. 647-5656 647-5676
Maximum Extension Length 3.5 m 4.5 m
FLRY 6x1,0 mm2 +1x1,5 mm2
Color Yellow
PERMACOIL
TM7N Cable with WEATHER-TITE
TMSeal - OEM
PERMACOIL
TM7S Cable with WEATHER-TITE
TMSeal - OEM
PERMACOIL
TM7N Cable with WEATHER-TITE
TMSeal
ELECTRICAL ASSEMBLIES - COLOR BY FUNCTION™
• The WEATHER-TITE™ seal protects against corrosion and blocks contaminants from entering the electrical system
• Flexible from -40ºC to 125ºC
• Great recoil memory, abrasion, chemical and corrosion resistance • Jacket and plugs are color-coded black and yellow for easy function
identification from a distance
• ISO 12098, ISO 1185 and ISO 3731 compliance • “Y” mold to prevent cables from
becoming tangled
15P to 7N&7S
PERMACOIL™ Adapter Cable
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 1/31 2/58L 3/L 4/54 5/R 6/58R 7/ZEN 1/31 2/58L 3/L 4/54 5/R 6/58R 7/ZEN 15P 7N 7S 15P to 7N&7S
Single Coil Adapter Cable
• Adapter cable combines the two separate 7N and 7S cables into one coil to avoid tangling
• 7N and 7S nylon WEATHER-TITE™ PERMAPLUGS™ seal protects against corrosion and blocks contaminants from entering the electrical system
• 7N and 7S cable leads measure 0,5M (from back of plugs to Y connection) • Temperature range: -40°C to 125°C
• Great recoil memory, abrasion, chemical and corrosion resistance
• Plugs are color coded black and yellow for easy function identification from a distance
• ISO 12098, ISO 1185 and ISO 3731 compliance • 13 pin population
• ADR certified 7N
WEATHER-TITE™ Corrosion Resistant Seal
WEATHER-TITE™ Corrosion Resistant Seal
EURO 6
COMPLIANT C OM P L A I NTEURO 6
COMPLIANT C OM P L A I NT Part No. 688-8456 688-8476Maximum Extension Length 3.5 m 4.5 m
FLRY 2x (6x1mm2 +1x1,5 mm2
)
Color Yellow / Black
Part No. 686-8056 686-8076
Maximum Extension Length 3.5 mm 4.5 mm
FLRY 15-Pin to 7N (6x1mm2 +1x1,5 mm2
)
15-Pin to 7S (4x1,5mm2 +3x2,5 mm2
)
Color Green
PERMACOIL
TMAdapter Cable 15-Pin to 7N&7S
with WEATHER-TITE
TMSeal
Single Coil Adapter Cable 15-Pin to 7N&7S
with WEATHER-TITE
TMSeal
ELECTRICAL CONNECTORS - COLOR BY FUNCTION™
COLOR-BY-FUNCTION™
Plugs
COLOR BY FUNCTION™
Color-coded plug saves
time by easily identifying
plug application
POWER (15-Pin)
ABS (5-Pin)
EBS (7-Pin)
Stainless steel plug lock provides
a corrosion-resistant, long-life
connection
Waterproof o-ring seal protects
against moisture and corrosion
Cable seal locks out
moisture and corrosion
Color identifiers for
easy wire installation
360º compression ring
secures plug to cable
Rubber cable
guard also provides
strain relief
Unbreakable, non-corrosive
housing can withstand the
toughest conditions
Machined brass pins with
crown spring and thread
sealer securely connects
wires to pins
STA-DRY
®
Power Plug
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 1/31 2/58L 3/L 4/54 5/R 6/58R 7/ZEN 1/31 2/58L 3/L 4/54 5/R 6/58R 7/ZEN 15P 7S Wiring diagram Wiring diagram
PLUGS - COLOR BY FUNCTION™
PLUGS - COLOR BY FUNCTION™
• Color-coded green for easy function identification from a distance • 360º compression ring secures plug to cable and eliminates mois- ture and corrosion
• Insert labeled with wire colors for quick and easy installation • Stainless steel plug lock and hardware provide a corrosion-resistant,
long-life connection • ISO 12098 compliance
• ADR/GGVS approved for hazardous goods applications
• WEATHER-TITE™ plugs seal out water to protect against corrosion • 360º compression ring secures plug to cable and significantly reduces
moisture and corrosion
• Floating brass pins to align with irregular socket pins • ISO 1185 compliance
• WEATHER-TITE™ plugs seal out water to protect against corrosion • 360º compression ring secures plug to cable and significantly reduces
moisture and corrosion
• Floating brass pins to align with irregular socket pins • ISO 3731 compliance
• Color-coded dark blue for easy function identification from a distance
• 360º compression ring secures plug to cable and eliminates mois- ture and corrosion
• Insert labeled with wire colors for quick and easy installation • Stainless steel plug lock and hardware provide a corrosion-resistant,
long-life connection • ISO 7638 compliance
• ADR/GGVS approved for hazardous goods applications
• Color-coded light blue for easy function identification from a distance
• 360º compression ring secures plug to cable and eliminates mois- ture and corrosion
• Insert labeled with wire colors for quick and easy installation • Stainless steel plug lock and hardware provide a corrosion-resis
tant, long-life connection • ISO 7638 compliance
• ADR/GGVS approved for hazardous goods applications
STA-DRY
®EBS PERMAPLUG™
STA-DRY
®ABS PERMAPLUG™
STA-DRY
®15P PERMAPLUG™
ISO 12098
ISO 7638
ISO 7638
STA-DRY
®
P
ower Plugs
Part No. 716-7491
Color Green
STA-DRY
®15-Pin Power Plug PERMAPLUG
TMPart No. 716-5471
Color Dark Blue
STA-DRY
®EBS PERMAPLUG
TMPlug
Part No. 716-5451
Color Light Blue
STA-DRY
®ABS PERMAPLUG
TMPlug
In an industry of blackconnec-tors and cables, Phillips makes it safe and easy to identify cable, plug and socket function from a distance.
This helps eliminate confusion for the driver, increases safety and decreases repair and replacement time.
COLOR BY FUNCTION™
STA-DRY
®ISO 7N Plug
STA-DRY
®ISO 7S Plug
WEATHER-TITE™ Corrosion Resistant Seal
WEATHER-TITE™ Corrosion Resistant Seal
STA-DRY
®7N Plug PERMAPLUG
TMwith WEATHER-TITE
TMSeal
Part No. 716-3971
Color Black
STA-DRY
®7S Plug PERMAPLUG
TMwith WEATHER-TITE
TMSeal
Part No. 716-4971
ABS (5-Pin)
EBS (7-Pin)
ELECTRICAL CONNECTORS - COLOR BY FUNCTION™
COLOR-BY-FUNCTION™
Sockets
Color-coded socket saves time by easily
identifying socket application
POWER (15-Pin)
COLOR BY FUNCTION™
STA-DRY
®
Power Socket
Color-coded lid to easily identify socket function
Proprietary material housing for durability
Stainless steel hinge pin and spring are designed
for durability and corrosion protection
Durable, non-corrosive, water-resistant housing
Rubber gasket seals against moisture
and corrosion when closed
Nickel coated machined brass pins with
thread sealer securely connects wires to pins
“Floating” pins to align with
irregular plugs
Color identifiers for easy wire installation
Reinforced mounting holes with stainless steel rings for
durability and corrosion protection
360° moisture barrier standard on all straight and 90°
cable exit sockets
Stainless steel collars for strength and durability
STA-DRY
®EBS Socket
STA-DRY
®ABS Socket
• Lid color-coded dark blue for easy function identification from a distance • Stainless steel lid hinge pin, spring and reinforced mounting holes for durability
and corrosion protection
• 360º compression ring protects against moisture and corrosion • Rubber gasket seals against moisture and corrosion when closed • ISO 7638 compliance
• ADR/GGVS approved for hazardous goods applications
• Color-coded light blue for easy function identification from a distance • Stainless steel lid hinge pin, spring and reinforced mounting holes for durability
and corrosion protection
• 360º compression ring protects against moisture and corrosion • Rubber gasket seals against moisture and corrosion when closed • ISO 7638 compliance
• ADR/GGVS approved for hazardous goods applications
ISO 7638
ISO 7638
STA-DRY
®Power Socket
• Lid color-coded green for easy function identification from a distance • Stainless steel lid hinge pin, spring and reinforced mounting holes for durability
and corrosion protection
• 360º compression ring protects against moisture and corrosion • Rubber gasket seals against moisture and corrosion when closed • ISO 12098 compliance
• ADR/GGVS approved for hazardous goods applications
ISO 12098
STA-DRY
®
Power Sockets
Part No. 716-7291
Color Green
Part No. 716-5271
Color Dark Blue
Part No. 716-5251
Color Light Blue
STA-DRY
®15-PIN Power Socket
STA-DRY
®EBS Power Socket
STA-DRY
®ABS Power Socket
STA-DRY
®7S Socket
STA-DRY
®7N Socket
• Fully sealed to prevent water from entering the wire harness system • Full-opening lid is unbreakable
• Slanted 5º for moisture drain
• Stainless steel spring and hinge pin for corrosion protection • ISO 3731compliance
• Fully sealed to prevent water from entering the wire harness system • Full-opening lid is unbreakable
• Stainless steel spring and hinge pin for corrosion protection • Slanted 5º for moisture drain
• ISO 1185 compliance Part No. 716-4171 Color Yellow Part No. 716-3171 Color Black
STA-DRY
®7S Socket
STA-DRY
®7N Socket
SOCKETS - COLOR BY FUNCTION™
SOCKETS - COLOR BY FUNCTION™
• Completely sealed for maximum protection against extreme weather and corrosion • Significantly reduces socket replacement time, lowering maintenance and warranty costs • Flexibility allows for very quick OEM installation, reducing production costs
• QCS® replacement sockets available
• Available for 7N, 7S, ABS, EBS and 15P connections
Eliminates over 95% of the labor time it takes to change a 7N, 7S, ABS, EBS or 15P socket. The patented
Phillips QCS
®(Quick-Change Socket) is a completely sealed, weather-proof design that meets all ISO standards.
Spend LESS time on warranty claims and repairs, and MORE time on the road!
The Phillips QCS
®Quick-Change Socket system is the next generation of molded, “PLUG-IN” truck and trailer
elec-trical sockets (7N, 7S, ABS, EBS, 15P) designed for progressive truck and trailer OEMs and leading-edge fleets.
Backed by a 5 year warranty against corrosion, the QCS
®is designed to withstand the most punishing
environ-ments and weather conditions.
STA-DRY
®
QCS
®
Quick-Change Socket Assemblies
Available with:
STA-DRY
®QCS
®7N Socket
STA-DRY
®QCS
®Power Socket
STA-DRY
®QCS
®ABS Socket
STA-DRY
®QCS
®7S Socket
*Includes QCS® socket, waterproof socket boot and 1M cable*Includes QCS® socket, waterproof socket boot and 1M cable
*Includes QCS® socket, waterproof socket boot and 1M cable
*Includes QCS® socket, waterproof socket boot and 1M cable
*Includes QCS® socket, waterproof socket boot and 1M cable
STA-DRY
®QCS
®15-PIN
Power Socket - 1M Blunt Cut*
STA-DRY
®
QCS
®15-PIN
Replacement Power Socket
Part No. 716-71931 KIT
Color Green
Part No. 716-7193
Color Green
STA-DRY
®QCS
®EBS Socket
STA-DRY
®QCS
®EBS Socket -
1M Blunt Cut*
STA-DRY
®
QCS
®EBS Socket
Replacement Power Socket
Part No. 716-51731 KIT
Color Dark Blue
Part No. 716-5173
Color Dark Blue
STA-DRY
®QCS
®ABS Socket -
1M Blunt Cut*
STA-DRY
®
QCS
®ABS Socket
Replacement Power Socket
Part No. 716-51531 KIT
Color Light Blue
Part No. 716-5153
Color Light Blue
STA-DRY
®QCS
®7S Socket -
1M Blunt Cut*
STA-DRY
®
QCS
®7S Socket
Replacement Power Socket
Part No. 716-41731 KIT
Color Yellow
Part No. 716-4173
Color Yellow
STA-DRY
®QCS
®7N Socket -
1M Blunt Cut*
STA-DRY
®
QCS
®7N Socket
Replacement Power Socket
Part No. 716-31731 KIT
Color Black
Part No. 716-3173
Color Black
SOCKETS - COLOR BY FUNCTION™
EBS Tester
• Protects against water intrusion and contamination at the rear of the socket • Fits all 7N and 7S sockets
Adapter 15P(24V)
• Angled socket to prevent cables from being tangled • ISO 12098, 1185 and 3731 compliant
Power Socket Accesories
Socket Boot
Part No. 615-740
Part No. 716-5070
Part No. PGA-15-007
Socket Boot - fits 7N & 7S Sockets
EBS Tester
Black Adapter Box
Adapter 15P(24V)
Parking Socket 7P/24V
Parking Socket EBS/ABS*
• Angled socket to prevent cables from being tangled• ISO 12098, 1185 and 3731 compliance
• Firm housing made of high-quality and waterproof material ensuring durability • Rubber gasket seals against moisture and corrosion when closed
• Reinforced mounting holes with stainless steel rings for durability and corrosion protection
• Firm housing made of high-quality and waterproof material ensuring durability • Stainless steel hinge pin and spring are designed for durability and corrosion
protection
• Rubber gasket seals against moisture and corrosion when closed *Standard solution for EBS / ABS
Part No. PGAP-15-047-000
Black Adapter Box
Part No. S-07-P
Parking Socket 7P/24V
Part No. 200.02.P
Parking Socket
SOCKET ACCESORIES
Seal prevents water from
entering the plug when
connected to the socket*
Back seal prevents
dirt and moisture
from entering
Solid connection
of plug and cable
extending product life
Permanent plug lock
made of stainless steel*
Excellent recoil memory,
durable and flexible jacketing
Permanent connection of the
metal clip by using the most
modern connection method
- ultrasonic welding
15P Power Cable
ISO 12098 compliance
HIGH QUALITY Standard
TRUCK ELECTRICAL Assemblies
15-PIN Cable
EBS Cable
7N Cable
7S Cable
Part No. PA-EBS-16 PA-EBS-20
PU-EBS-29 PU-EBS-39
Maximum Extension Length 3.5 m 4.5 m
FLRY 3x1,5 mm2 +2x4,0 mm2 +2x1,5 mm2
Part No. PUA-15-47/36-1 PUA-15-47/49-1 Maximum
Extension Length 3.5 m 4.5 m
• Excellent recoil memory, durable and flexible jacketing • Solid connection of plug and cable extending product life
• Permanent connection of the metal clip by using the most modern connection method - ultrasonic welding
• Seal prevents water from entering the plug when connected to the socket • Permanent plug lock made of stainless steel
• Back seal prevents dirt and moisture from entering • ISO 12098 compliance
• Excellent recoil memory, durable and flexible jacketing • Solid connection of plug and cable extending product life
• Permanent connection of the metal clip by using the most modern • connection method - ultrasonic welding
• Seal prevents water from entering the plug when connected to the socket • Permanent plug lock made of stainless steel
• Back seal prevents dirt and moisture from entering • ISO 7638 for EBS systems compliance
• Excellent recoil memory, durable and flexible jacketing • Solid connection of plug and cable extending product life • Permanent connection of the metal clip by using the most modern connection method - ultrasonic welding
• Seal prevents water from entering the plug when connected to the socket
• Permanent plug lock made of stainless steel • Back seal prevents dirt and moisture from entering • ISO 12098 / “N” 1185 / “S” 3731 compliance
HIGH QUALITY STANDARD ELECTRICAL ASSEMBLIES
Part No. PA-15-18 PA-15-22
PU-15-29 PU-15-36
Maximum Extension Length 3.5 m 4.5 m
FLRY 12x1,5 mm2 +3x2,5 mm2
Black Electrical Coil 15P / 24V
Black EBS Cable
Black Electrical Coil Adapter
Part No. PA-07-16/1-N PA-07-20/1-N PU-07-36/1-N PU-07-49/1-N Maximum
Extension Length 3.5 m 4.5 m
FLRY 6x1,0 mm2 + 1x1,5 mm2
Part No. PA-07-16/1-S PA-07-20/1-S PU-07-36/1-S PU-07-49/1-S Maximum
Extension Length 3.5 mm 4.5 mm
FLRY 6x1,0 mm2 + 1x1,5 mm2
• Excellent recoil memory, durable and flexible jacketing • Solid connection of plug and cable extending product life • Permanent connection of the metal clip by using the most modern connection method - ultrasonic welding • Seal prevents water from entering the plug when connected to the socket • Permanent plug lock made of stainless steel
• Back seal prevents dirt and moisture from entering
Black Electrical Coil 7N / 24V
15P to 7N&7S
Adapter Cable
• ISO 1185 compliance
Black Electrical Coil 7S / 24V
• ISO 3731 compliance
Back seal prevents dirt
and moisture from entering
Waterproof seal protects
against moisture and corrosion
Unbreakable housing can withstand
the toughest conditions
Brass pins securely connect wires
to pins
HIGH QUALITY Standard
TRUCK ELECTRICAL PLUGS
ISO 12098 compliance
Stainless steel plug lock
provides a corrosion-resistant,
long-life connection
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 1/31 2/58L 3/L 4/54 5/R 6/58R 7/ZEN 1/31 2/58L 3/L 4/54 5/R 6/58R 7/ZEN 15P 7S Wiring diagramHiGH QUALITY ELECTRICAL PLUGS
• Back seal prevents dirt and moisture from entering
• Stainless steel plug lock provides a corrosion-resistant, long-life connection
• Waterproof seal protects against moisture and corrosion • Brass pins securely connect wires to pins
• Unbreakable housing can withstand the toughest conditions • ISO 12098 compliance
BLACK EBS PLUG
BLACK POWER PLUG 15P/24V
BLACK POWER PLUG 7S/24V
Part No. PG-15-11 PG-15-21
Type Crimped contacts Pin with screw M3
Black Power Plug 15P / 24V
• Back seal prevents dirt and moisture from entering
• Stainless steel plug lock provides a corrosion-resistant, long-life connection
• Waterproof seal protects against moisture and corrosion • Brass pins securely connect wires to pins
• Unbreakable housing can withstand the toughest conditions • ISO 7638 compliance
Part No. PG-07-11 PG-07-21
Type Crimped contacts Pin with screw M3
Black EBS Plug
BLACK POWER PLUG 7N/24V
• Back seal prevents dirt and moisture from entering • Ergonomic handle for use with gloves
• Brass pins securely connect wires to pins
• Unbreakable housing can withstand the toughest conditions • ISO 1185 compliance
Part No. PGS-07-11N
Type Pin with screw M3
Black Power Plug 7N / 24V
• Back seal prevents dirt and moisture from entering • Ergonomic handle for use with gloves
• Brass pins securely connect wires to pins
• Unbreakable housing can withstand the toughest conditions • ISO 3731 compliance
Part No. PGS-07-11S
Type Pin with screw M3
Black Power Plug 7S / 24V
HIGH QUALITY STANDARD ELECTRICAL PLUGS
ELECTRICAL ASSEMBLIES - ADAPTER
HIGH QUALITY STANDARD
TRUCK ELECTRICAL SOCKETS
BLACK POWER PLUG 3P/24V
Black Power Plug 3P / 24V
Part No. PG-03-11-001
Type Pin with screw M3
Reinforced mounting holes with
stainless steel rings for durability
and corrosion protection
Firm housing made of
high-quality and waterproof
material ensuring durability
Rubber gasket seals against moisture
and corrosion when closed
Stainless steel hinge pin and spring
are designed for durability and
corrosion protection
Nickel coated machined brass
pins with thread sealer securely
connects wires to pins
BLACK POWER SOCKET 3P/24V
Part No. S-03-21-00
Type Pin with screw
Black Power Socket 3P / 24V
• Firm housing made of high-quality and waterproof material ensuring durability • Nickel coated machined brass pins with thread sealer securely connects wires to pins
• Reinforced mounting holes with stainless steel rings for durability and corrosion protection
• Rubber gasket seals against moisture and corrosion when closed
• Stainless steel hinge pin and spring are designed for durability and corrosion protection • ISO 12098 compliance • ISO 1724 compliance • ISO 7638-2 compliance • ISO 7638-2 compliance • ISO 1724 compliance • ISO 1724 compliance • ISO 7638-2 compliance • ISO 7638-2 compliance • Firm housing made of high-quality and waterproof material ensuring durability
• Nickel coated machined brass pins with thread sealer securely connects wires to pins
• Reinforced mounting holes with stainless steel rings for durability and corrosion protection
• Rubber gasket seals against moisture and corrosion when closed
• Stainless steel hinge pin and spring are designed for durability and corrosion protection
• ISO 7638 compliance
• Back seal prevents dirt and moisture from entering • Ergonomic handle for use with gloves
• Unbreakable housing can withstand the toughest conditions
• Machined brass pins with crown spring and thread sealer securely connects wires to pins
• ISO 1185 compliance
• Back seal prevents dirt and moisture from entering • Ergonomic handle for use with gloves
• Unbreakable housing can withstand the toughest conditions
• Machined brass pins with crown spring and thread sealer securely connects wires to pins
• ISO 3731 compliance
BLACK POWER SOCKET 15P/24V
BLACK EBS SOCKET
BLACK POWER SOCKET 7N/24V
BLACK POWER SOCKET 7N/24V
Part No. S-15-11 S-15-21
Type Crimped contacts Pin with screw M3
Part No. S-07-11 S-07-21
Type Crimped contacts Pin with screw M3
Part No. S-07-11N
Type Pin with screw M3
Part No. S-07-11S
Type Pin with screw M3
Black Power Socket 15P / 24V
Black EBS Socket
Black Power Socket 7N/24V
Black Power Socket 7S / 24V
HIGH QUALITY STANDARD ELECTRICAL SOCKETS
High Quality Standard 12V Assemblies
BLACK ELECTRICAL COIL 7P/12V
BLACK EBS CABLE
BLACK ABS CABLE
Part No. PU-07-18/1-7/12V
Maximum Extension Length Length on customer request
FLRY 6x1,0 mm2 +1x1,5 mm2
Black Electrical Coil 7P / 12V
Part No. PU-12EBS-29 PU-12EBS-39
Maximum Extension Length 3.5 m 4.5 m
FLRY 3x1,5 mm2 +2x4,0 mm2 +2x1,5 mm2
Part No. PU-12ABS-29 PU-12ABS-39
Maximum Extension Length 3.5 m 4.5 m
FLRY 3x1,5 mm2 +2x4,0 mm2
Black EBS Cable
Black ABS Cable
BLACK POWER PLUG 7P/12V
BLACK POWER SOCKET 7P/12V
Part No. ST 070
Type Pin with screw M3
Black Power Plug 7P /12 V
Part No. D 070
Type Pin with screw M3
Black Power Socket 7P /12 V
BLACK EBS PLUG
BLACK EBS SOCKET
Part No. PG-07-11/12V
Type Pin with screw M3
Black EBS Plug
Part No. S-07-11/12V
Type Crimped contacts
LOW PRESSURE TUBES
Part no.
Outer diameter Inner diameter
Minimal wall thickness Tube pressure range PA12 PHL min. Pr (bar) mm Tolerance mm Tolerance PP 555-4x1 4 ± 0,10 2 ± 0,2 0,90 44 PP 555-5x1 5 ± 0,10 3 0,90 33 PP 555-6x1 6 ± 0,10 4 0,90 27 PP 555-8x1 8 ± 0,10 6 0,90 19 PP 555-8x1,5 8 ± 0,10 5 1,35 31 PP 555-9x1,5 9 ± 0,15 6 1,35 27 PP 555-10x1 10 ± 0,10 8 0,90 15 PP 555-10x1,5 12 ± 0,15 7 ± 0,3 1,35 19 PP 555-11x1,5 13 ± 0,15 8 1,35 21 PP 555-12x1,5 14 ± 0,15 9 1,35 19 PP 555-14x2 15 ± 0,15 10 1,80 22 PP 555-15x1,5 16 ± 0,15 12 1,35 15 PP 555-16x2 17 ± 0,15 12 1,80 19 PP 555-18x2 18 ± 0,15 14 1,80 17
Low Pressure Tubes
DIN 74324/73378
Low Pressure Tubes
• Standard packaging are in spools 25, 100, 200 m
• Non-standard packaging can be discussed individually for each item
• Low pressure tubes are sold in five basic colors: black, red, yellow, green, blue
• Tubes assembly in self-clamping fittings is recommended by turning the until you feel the inner stop • The distance of insertion the tube into connection is always determined by producer of fittings • DIN 74324 / 73378 compliance
ELECTRICAL CONNECTORS - COLOR BY FUNCTION™
AIR ASSEMBLIES
Tubing available in red and
yellow to denote service and
emergency air lines
Nylon cable guards offer a
stowage ring to keep coils safe
when not in use
Assemblies available with color-coded
nylon cable guards to support tubing
and help reduce failure due to kinking
at the air fitting
AIR ASSEMBLIES
• DIN 73378 / ISO 7375 compliance
• DIN 73378 / ISO 7375 compliance
• DIN 73378 / ISO 7375 compliance • DIN 73378 / ISO 7375 compliance
• DIN 73378 / ISO 7375 compliance
Red (Emergency) Air Coils
Black (Emergency) Air Coils
Black (Service) Air Coils
Yellow (Service) Air Coils
Black (Service & Emergency)
Air Coils
Part No. SP PA/P-R/16/18x1,5R SP PA/P-R/18/18x1,5R
SP PU/P-R/22/18x1,5R SP PU/P-R/25/18x1,5R
Maximum Extension Length 4.0 m 4.5 m
Fitting M 18x1,5
Part No. SP PA/P-S/16/18x1,5R SP PA/P-R/18/18x1,5R
SP PU/P-S/22/18x1,5R SP PU/P-S/25/18x1,5R
Maximum Extension Length 4.0 m 4.5 m
Fitting M 18x1,5
Part No. SP PA/P-S/16/18x1,5R SP PA/P-R/18/18x1,5R
SP PU/P-S/22/18x1,5R SP PU/P-S/25/18x1,5R
Maximum Extension Length 4.0 m 4.5 m
Fitting M 18x1,5
Part No. SP PA/P-G/16/18x1,5G SP PA/P-G18/18x1,5G
SP PU/P-G/22/18x1,5G SP PU/P-G/25/18x1,5G
Maximum Extension Length 4.0 m 4.5 m
Fitting M 18x1,5
Part No. SP PA/2P1-SS/16/18x1,5RG-01 SP PA/2P1-SS/18/18x1,5RG-01 SP PA/2P1-SS/20/18x1,5RG-01 SP PA/2P1-SS/22/18x1,5RG-01 Maximum
Extension Length 4.0 m 4.5 m 5 m 5.5 m
Fitting M 18x1,5
Air Brake Coils
Air Brake Coils
Air Brake Coils
Air Brake Coils
ELECTRICAL CONNECTORS - COLOR BY FUNCTION™
AIR COil accesories
Color-coded covers to denote
service and emergency
Palm Coupler
Handle Grips
Palm Coupling Extension Grips
Covers protect air lines
when not in use
Adapter
Part No. M 18x1,5 / M16x1,5
Adapter
Part No. M 18x1,5 / M22x1,5
Yellow (Service) Palm Couplers with Filter Screen
Part No. GSZ-16x1,5-Y GSZ-22x1,5-Y
Fitting M 16x1,5 M 22x1,5
Red (Emergency) Palm Couplers with Filter Screen
Part No. GSZ-16x1,5-R GSZ-22x1,5-R
Fitting M 16x1,5 M 22x1,5
Adapter M 18x1,5 to M22x1,5
Red (Emergency) Palm Couplers
with Filter Screen
Adapter M 18x1,5 to M16x1,5
Yellow (Service) Palm Couplers
with Filter Screen
Palm Coupling Extension Grips
Part No. LPK-16x1,5 LPK-22x1,5
Fitting M 16x1,5 M 22x1,5
