WAN Ethernet Services

(1)

WAN

Ethernet

Services

Summary

(2)

WAN Ethernet Services-Summary document

Table of

Understanding

Fundamentals

Defining the protection types: unprotected, deterministic, and mesh

protection

Unprotected circuit– This means that data traveling from location A to location Z has only a single defined path and incase of a cable failure there is no second route for the data to reach its destination.

Deterministic protection– This means that there are two clearly defined paths or cable routes for the data to reach from location A to location Z. In case of a cable failure on one path the data gets rerouted and reaches the destination through the second defined path.

Mesh protection– This means that there are multiple routes available from location A to location Z and the data can travel on any of these routes to reach its destination. In case of a failure on one of the routes the data will be re-routed automatically to one of the other available routes.

Defining CIR

CIR is Committed Information Rate. This means that the customer gets the exact committed bandwidth on our network. For example, if the customer buys 10 Meg of bandwidth, we will reserve 10 Meg of bandwidth for the customer on our network.

(4)

Ethernet Service Types as Defined by the Metro Ethernet Forum

(MEF)

E-Line- Any Ethernet service that is based on a point-to-point Ethernet Virtual Connection (EVC) is designated as an Ethernet Line (E-Line) Service type. An E-Line service type can be used to create a broad range of point-to-point services.

EPL- An Ethernet Private Line (EPL) service is specified using an E-Line service type. An EPL service uses a point-to-point EVC between two UNIs and provides a high degree of transparency for service frames between the UNIs it interconnects such that the service frame’s header and payload are identical at both the source and destination UNI when a service frame is delivered.

EVPL- An Ethernet Virtual Private Line (EVPL) is created using an E-Line service type. An EVPL can be used to create services similar to the Ethernet Private Line (EPL) with some notable exceptions. First, an EVPL allows for service multiplexing at the UNI. This capability allows more than one EVC to be supported at the UNI where the EPL does not allow this. Second, an EVPL need not provide as much transparency of service frames as with an EPL. Because service multiplexing is permitted, some service frames may be sent to one EVC while other service frames may be sent to other EVCs.

E-LAN- Any Ethernet Service that is based upon a multipoint-to-multipoint EVC is designated as an Ethernet LAN (E-LAN) service type.

EP-LAN- Subscribers with multiple sites often want to interconnect them at high speeds so all sites appear to be on the same Local Area Network (LAN) and have equivalent performance and access to resources such as servers and storage. Subscribers commonly desire a highly transparent service that connects multiple UNIs. To this end, the Ethernet Private LAN (EP-LAN) service is defined in this subsection, using the E-LAN service type.

EVP-LAN- Some subscribers commonly desire an E-LAN service type to connect their UNIs in a metro network, while at the same time accessing other services from one or more of those UNIs. An example of such a UNI is a subscriber site that wants to access a public or private IP service from a UNI that is also used for E-LAN service among the subscriber’s several metro locations. It is defined as the Ethernet Virtual Private LAN (EVP-LAN) service in this subsection to address this need.

E-Tree- Any Ethernet Service that is based on a rooted-multipoint-to-multipoint EVC is designated as an Ethernet Tree (E-LAN) service type.

EP-Tree- Subscribers with multiple sites may want to interconnect them to provide services other than those that resemble a LAN. These services may be distributed from a centralized site (or few such sites) where the distribution site is designated as a Root and all the remaining sites are designated as leaves.

EVP-Tree- Subscribers desire access to certain applications or content services from well-defined access points within their own (or an external) network. In this case it is necessary to interconnect the participating UNIs in a rooted-multipoint connection to the well-defined access (or root) point. One or more of the subscriber’s UNIs may also support other services, e.g., EVPL or EVP-LAN. For such cases, the EVP-Tree service is used.

(5)

What are MEF Certifications?

Metro Ethernet Forum (MEF) is a global industry alliance comprising more than 195 organizations including telecommunications service providers, cable MSOs, network equipment/software manufacturers, semiconductors vendors and testing organizations. The MEF develops Carrier Ethernet technical specifications and implementation agreements to promote interoperability and deployment of Carrier Ethernet worldwide.

MEF certifications are verified through independent testing and assure customers that our global Ethernet services meet rigorous international standards.

MEF 14 ensures that the latency, jitter and packet delivery performance of the services conforms to the rigorous MEF standards.

MEF 9 ensures the conditions required for delivery of services have specific Ethernet User Network Interface (UNI) and Ethernet Virtual Connection (EVC) service attributes, with corresponding parameter values.

MEF 14 and 9 certifications apply to our Global Dedicated Ethernet Service, National Dedicated Ethernet Services, EoSecure, Priority Ethernet Service, Multipoint Ethernet Service, Low Latency Global Dedicated Ethernet and Low Latency Multipoint Ethernet.

Visit www.metroethernetforum.org to learn more about MEF.

What is a MEF Carrier Ethernet Certified Professional (MEF-CECP)?

The MEF-CECP, is the MEF professional certification program designed for telecommunications professionals seeking to validate their expertise, skills and knowledge of Carrier Ethernet technologies, standards, services and applications.

Certification is awarded to individuals who successfully pass MEF administered tests developed by distinguished leaders and experts in the Carrier Ethernet industry. MEF authorized training partners, global leaders in telecommunication classroom based training, education and consulting, offer Carrier Ethernet training courses to prepare individuals for exams.

The MEF certification is a globally recognized and trusted reference for Carrier Ethernet professionals employed with global service providers, equipment vendors, enterprises and governments. It ensures that Carrier Ethernet professionals acquire key competency and skills to design, manage or implement Carrier Ethernet networks, services and applications. Tata Communications has CECP certified professionals on their Product Management teams, Sales Engineering teams and Operations teams. Tata has an active program to provide top performers CECP training.

(6)

Product

Nomenclature

Services MEF Defined_Service Protection type _FramesJumbo _CertifiedMEF

Global Dedicated

Ethernet EPL

Deterministic, ring or

unprotected Yes Yes National Dedicated

Ethernet EPL Deterministic, ring Yes Yes

EoSecure EPL Deterministic, ring or _unprotected Yes Yes Priority Ethernet

(point to point) EVPL Mesh Yes Yes

Priority Ethernet

(point to multipoint) EVPL Mesh Yes Yes

10 Gig Ethernet EPL Deterministic, ring or_unprotected Yes No Global Priority

Stretch Ethernet EPL Mesh No No

Multipoint Ethernet EP-LAN & EP-_Tree Deterministic, ring or _unprotected Yes Yes Virtual Private LAN

Service

EP-LAN &

EVP-LAN Mesh Yes Yes

Low Latency Global

Dedicated Ethernet EPL Unprotected Yes Yes

Low Latency Multipoint Ethernet

LAN &

(7)

Dedicated

Ethernet

Feature Details

Choice of bandwidth

2-100 Mb in 2 Mb increments

50 – 1,000 Meg in 50 Meg increments 1,000—10,000 Meg in 500 Meg increments

Choice of interface handoffs

Fast-E interfaces:

10BaseTx (copper, RJ45, full duplex) 100BaseTx (copper, RJ45, full duplex) Gig-E interface:

1000BaseLX (fiber, SM, 1310nm, full duplex) 1000BaseSX (fiber, MM, 850nm, full duplex) 1000BaseTx (copper, RJ45, full duplex) 10 Gig interface:

10GE LAN PHY:

10Gbase SR: 850nm, multimode, 26-300m 10Gbase LR: 1310nm, single mode, 2m-10km 10Gbase ER: 1550nm, single mode, 30-40km

Transparent pipes No deep packet inspection, no MAC learning and no VLAN _{forwarding required} Choice of frame sizes Standard frame sizes (64-1522 bytes) and jumbo frame sizes _{(9000 bytes) on request} Committed

bandwidth Committed Information Rate (CIR) Non service-affecting

upgrades

Bandwidth can be upgraded without service interruption and without changing ports

Service level agreements (SLAs)

GDE: Availability, Latency, Packet Delivery Ratio, MTTR NDE: Availability, MTTR

*Contact your sales representative for the latest information on the SLAs MEF certifications MEF 9 and 14 certified

Service details

• Dedicated, high performance Ethernet to locations spanning the globe

• Flexible bandwidth options, customized for the way you do business

• Bandwidth upgrades with no downtime or contract renewals • Aggressive service level guarantees

• MEF 9 & 14 certified

(8)

EoSecure

Service details

• Ethernet over SONET/SDH technology • Robust and reliable network

• Sub-50 ms switching over protected links

• Ring protection - diverse cables to all on-net locations • The Ethernet network is a series of connected Layer 2 switches • Guaranteed uncontended bandwidth

• Secure links

• Customer traffic is segregated from ingress through egress • No Layer 2 bridging on port cards

• Every physical service port is dedicated to one customer • Link Loss Forwarding

• Available On-Net upon Request

Feature Details

Choice of bandwidth 48-1000 Mb in 48 Mb increment

Choice of interface handoffs Fast-E interfaces: 100BaseTX Gig-E interface: 1000BaseT 1000BaseSX 1000BaseLX 1000BaseZX

Transparent pipes No deep packet inspection, no MAC learning and no VLAN_{forwarding required} Choice of frame sizes Standard frame sizes (64-1518 bytes)_{Jumbo frame sizes (64-9000 bytes) on request}

Committed

bandwidth Committed Information Rate (CIR) Service level

agreements (SLAs) Availability, Latency, Packet Delivery Ratio, MTTR*Contact your sales representative for the latest information on the SLAs MEF certifications MEF 9 and 14 certified

(9)

Priority

Ethernet

Service details

• Multiple classes of service • Flexible bandwidth options

• Mesh-protection for a very high network reliability

• Bandwidth upgrades or adding/removing sites with no downtime or contract renewal

• Centralized processing for multiple locations with the hub and spoke configuration

• Automatic bursting into higher classes of service to utilize unused bandwidth

Feature Details

Choice of bandwidth

1-100 Meg in 1 Meg increments 105-145 Meg in 5 Meg increments 150 – 300 Meg in 10 Meg increments

Choice of interface handoffs Fast-E interface: 100BaseTx (copper RJ45) 100BaseFx (fiber, SM/MM 1310nm) Gig-E interface: 1000BaseLX (fiber, SM, 1310nm) 1000BaseSX (fiber, MM, 850nm)

1000BaseTx (copper RJ45) (case-by-case)

Choice of frame sizes Standard frame sizes (64-1522 bytes) and Jumbo frame size (up to _{9000 bytes) on request} Mesh protection Network protection designed with multiple pathways into_{Tata Communications PoPs}

Interclass bursting Allows for bursting from a lower CoS into unused higher CoS _bandwidth Non service-affecting

upgrades

Bandwidth can be upgraded without service interruption, without changing ports

Classes of service Choice of six CoS to prioritize frames and regulate network traffic

CoS 1: Service availability, Packet delivery ratio, Latency, Jitter CoS 2: Service availability, Packet delivery ratio, Latency, Jitter CoS 3: Service availability, Packet delivery ratio, Latency CoS 4: Service availability, Packet delivery ratio, Latency CoS 5: Service availability, Packet delivery ratio, Latency CoS 6: Service availability, Latency

(10)

Multipoint

Ethernet

Service details

• Dedicated Multipoint Ethernet

• Hub & spoke and any to any network service • Managed and unmanaged service options

• Bandwidth upgrades with no service interruption or contract renewals

• On-line web portal with near real time reporting for managed option

Feature Details

Choice of bandwidth

2-100 Meg in 2 Meg increments 50-1,000 in 50 Meg increments 1,000-10,000 in 500 Meg increments

Fast-E interfaces:

10BaseTx (copper, RJ45, full duplex) 100BaseTx (copper, RJ45, full duplex) Gig-E interface:

1000BaseLX (fiber, SM, 1310nm, full duplex) 1000BaseSX (fiber, MM, 850nm, full duplex) 1000BaseTx (copper, RJ45, full duplex) 10 Gig interface:

10GE LAN PHY:

10Gbase SR: 850nm, multimode, 26-300m 10Gbase LR: 1310nm, single mode, 2m-10km 10Gbase ER: 1550nm, single mode, 30-40km Choice of frame sizes Standard frame sizes (64-1522 bytes)_{Jumbo frames (up to 9000 bytes) on request} Protected and

unprotected circuits

Deterministic path

Circuits are ring protected

Offer unprotected multipoint plus protected multipoint networks Non service-affecting

upgrades

Transparent pipes No deep packet inspection and no VLAN forwarding required Service level

agreements (SLAs)

Managed option: Service uptime, Packet delivery ratio, Latency, Jitter

Unmanaged option: Service availability, Packet delivery ratio, Latency

MEF certifications MEF 9 and 14 certified

Multipoint Ethernet is available in two options with Tata Communications as follows

(11)

Multipoint

Ethernet

Service details

• Any to any network service • Multiple classes of service (CoS)

• Managed and unmanaged service options

• Bandwidth upgrades with no service interruption or contact renewals

• Real time reporting

Feature Details

Choice of bandwidth

1-100 Meg in 1 Meg increments 105-145 Meg in 5 Meg increments 150 – 300 Meg in 10 Meg increments

Choice of interface handoffs Fast-E interface: 100BaseTx (copper RJ45) 100BaseFx (fiber, SM/MM 1310nm) Gig-E interface: 1000BaseLX (fiber, SM, 1310nm) 1000BaseSX (fiber, MM, 850nm)

1000BaseTx (copper RJ45) (case-by-case)

Choice of frame sizes Standard frame sizes (64-1518 bytes) and Jumbo frame size (up to _{9000 bytes) on request} Mesh protection Network protection designed with multiple pathways into _{Tata Communications PoPs}

Interclass bursting Allows for bursting from a lower CoS into unused higher CoS _bandwidth Non service-affecting

upgrades

Classes of service Choice of six CoS to prioritize frames and regulate network traffic

CoS 1: Service availability, Packet delivery ratio, Latency, Jitter CoS 2: Service availability, Packet delivery ratio, Latency, Jitter CoS 3: Service availability, Packet delivery ratio, Latency CoS 4: Service availability, Packet delivery ratio, Latency CoS 5: Service availability, Packet delivery ratio, Latency CoS 6: Service availability, Latency

(12)

Global Priority

Stretch

Ethernet

Service details

• Billed only for bandwidth used

• A best-effort service with no minimum or maximum commitments of bandwidth

• Bandwidth as used limited to 100 Meg on Fast-E and 1000 Meg on Gig-E port

• Web portal to check circuit utilization

Feature Details Choice of interface handoffs Fast-E interface: 100BaseTx (copper RJ45) Gig-E interface: 1000BaseLX (fiber, SM, 1310nm) 1000BaseSX (fiber, MM, 850nm)

1000BaseTx (copper RJ45) (case-by-case) Choice of frame sizes Standard frame sizes (64-1518 bytes)

Mesh protection Network protection designed with multiple pathways into _{Tata Communications PoPs} Classes of service Best - effort CoS

Web portal

Check network utilization daily, weekly, and monthly with the help of a web-based portal.

View and report trouble tickets Monitor circuit performance

Facilitates timely bandwidth management based on actual utilization

(13)

10 Gig

Ethernet

Feature Details

Bandwidth LAN Phy: maximum of 10 G effective throughput bandwidth Type of bandwidth

profile One bandwidth profile per UNI/EVC; Only one EVC per UNI Classes of service Port-based, single high-priority class-of-service, full preservation Choice of frame sizes

(MTU)

Standard frame sizes (64-1518 bytes) and jumbo frame sizes (up to 9000 bytes) on request

10GE LAN PHY:

10Gbase SR: 850nm, multimode, 26-300m 10Gbase LR: 1310nm, single mode, 2m-10km 10Gbase ER: 1550nm, single mode, 30-40km

Configuration Point-to-point EVC service with only two UNIs (MEF 6.1 defined _EPL) VLAN and QoS

transparent Pipe

802.1q VLAN transparent; Layer 2 and layer 3 QoS transparent (i.e. CoS, DSCP, PHB, etc)

Service level

agreement Service availability

Service details

• Maximum, future-proof bandwidth at a competitive price

• Secure, private network with transparent service to more locations • Guaranteed delivery, quality of service, and SLA options

• Global connections to 25 cities in 11 countries • Choice of protected or unprotected circuits

(14)

Low Latency

Global Dedicated Ethernet

Feature Details

Low Latency Ethernet

connecting sites London, Singapore, Tokyo, New York, Chicago and Hong Kong Choice of bandwidth Gig-E interfaces: 2-100 Megs in 2 Meg increments_{10Gig-E interfaces: 50-500 Megs in 50 Meg increments}

Choice of interface handoffs Gig-E Interface: 1000BaseLX (fiber, SM, 1310nm) 1000BaseSX (fiber, MM, 850nm) 1000BaseTx (copper Rj45) 10GE LAN PHY:

10GBaseSR :850nm, MM*,26-200m 10GBaseLR :1310nm, SM*, 2m-10km 10GBaseER :1550nm, SM*, 30-40km

*Please refer to the SLA schedule for the most current SLA parameters Choice of frame sizes Standard frame sizes (64-1518 bytes)_{Jumbo frame sizes (64-9000 bytes) on request}

Configuration Point-to-point

Resiliency London – Hong Kong route is protected (by default)_{All other route are unprotected} Committed bandwidth Committed Information Rate (CIR)

Non service-affecting Upgrades

Enterprise SLA option (Customer Premise to Customer Premise) : Availability, Packet delivery ratio, Latency, Jitter

Standard SLA (PoP to PoP): Service uptime, Packet delivery ratio, Latency

Service details

• Low latency solution connecting six major economic centres • Unprotected network except London to Hong Kong

• Standard guaranteed “latency” SLA with continuous latency monitoring, PoP to PoP • Enterprise SLA option - extending the SLA guarantees from your actual site to site and

web portal access

• Bandwidth options - pay for the exact bandwidth your business needs today • Scalability with Next Generation Ethernet Network

• Added security – Provider Backbone Bridging (PBB) isolates customers and prevents denial of service attacks on one customer from impacting other customers

(15)

Low Latency

Multipoint Ethernet

Service details

• Low latency solution connecting six major economic centres.

• Private multipoint network where your sites can share your bandwidth as high usage requirements “follow the sun”, saving you up to 50%* per month

• Single SLA covering key parameters with choice of Managed option, monitoring your circuit end to end

• Widest range of options to choose the best fit network for your business – hub & spoke and any to any topology

• Flexibility to upgrade, downgrade bandwidth and add sites without service interruptions and additional CAPEX

• One provider offering consolidated billing and single point of troubleshooting, which means reduced operational IT management

Feature Details

Low Latency Ethernet

connecting sites London, Singapore, Tokyo, New York, Chicago and Hong Kong Choice of bandwidth Gig-E interfaces: 2-100 Megs in 2 Meg increments_{10Gig-E interfaces: 50-500 Megs in 50 Meg increments}

Choice of interface handoffs Gig-E Interface: 1000BaseLX (fiber, SM, 1310nm) 1000BaseSX (fiber, MM, 850nm) 1000BaseTx (copper Rj45) 10GE LAN PHY:

10Gbase SR: 850nm, multimode, 26-300m 10Gbase LR: 1310nm, single mode, 2m-10km 10Gbase ER: 1550nm, single mode, 30-40km Choice of frame sizes Standard frame sizes (64-1518 bytes)_{Jumbo frame sizes (64-9000 bytes) on request} Configuration Hub & Spoke_{Any to Any}

Resiliency London – Hong Kong route is protected (by default)_{All other route are unprotected} Committed bandwidth Committed Information Rate (CIR)

Non service-affecting Upgrades

Managed option (Customer Premise to Customer Premise) : Service uptime, Packet Delivery Ratio, Latency, Jitter

Unmanaged option (PoP to PoP): Availability, Packet Delivery Ratio, Latency

(16)

Enterprise

SLA Option

ESO Service Level

Agreements Details

Service uptime Protected circuits – 99.9%_{Unprotected circuits – 99.5%}

Packet delivery ratio 99.97% of frames will pass through the network Latency (round-trip delay)

Measurement of the actual circuit path

Latency target is calculated based on the actual path

Jitter (one-way delay variation) Not to exceed 5 ms.

Web portal

• Check network utilization daily, weekly, and monthly with the help of a web-based portal • View and report trouble tickets

• Monitor circuit performance • Facilitates timely bandwidth

managementbased on actual utilization

Service details

• SLAs that extend from customer premise to customer premise • SLA includes service up time, packet delivery ratio, latency, and jitter • Web-based customer portal for SLA monitoring in near real time • End-to-end Monitoring

Tata Communications installs network interface devices (NIDs) at the customer premise. Data is collected from the NIDs every five minutes, allowing Tata Communications to deliver constant, end-to-end monitoring of the circuit. In addition to monitoring, this configuration also facilitates rapid diagnosis if network issues occur. This end-to-end capability delivers highly accurate service measurements in line with customer traffic for performance statistics that accurately reflect the customer’s traffic flow and experience.

(17)

FAQs

1. Which Ethernet service provides a point to point, dedicated connectivity globally?

- Global Dedicated Ethernet Service (GDE)

2. What is the name of the service that offers point to point, dedicated connectivity within India?

- National Dedicated Ethernet Service (NDE)

3. What is the difference between GDE and NDE?

- GDE is the name given to the point to point, dedicated Ethernet service that extends to any location outside India (either one point touching a location in India and the other outside India or both end locations are outside India).

- NDE is the name given to Ethernet service that provides point to point, dedicated connectivity within India only.

4. Which point to point service provides multiple classes of service for traffic prioritization?

- Priority Ethernet Service.

5. Does Tata Communications have an any-to-any service that provides the multiple classes of service option as well?

- Yes. Our Multipoint Ethernet Service offers the customer the choice of classes of service.

6. Does Tata Communications offer usage based billing?

- Yes. Tata Communications Priority Stretch Ethernet service is a best effort service that offers usage based billing.

7. Does Tata Communications offer SLAs from customer premise to customer premise as a standard?

- No. As a standard, we offer SLAs from Tata Communications Point of Presence (POP) to Tata Communications POP.

8. What if a customer wants SLAs to be extended from customer premise to customer premise?

- Tata Communications offers an “Enterprise SLA option” that enables end to end monitoring of the network.

9. Does Tata Communications provide Low Latency Service?

- Yes, Tata Communications Ethernet Service do offer Low Latency Service. The product names are Low Latency Global Dedicated Ethernet (LL GDE) and Low Latency Multipoint Ethernet (LL Multipoint Ethernet).

(18)

WAN Ethernet

Coverage

APAC: Australia - Melbourne, Sydney; Bangladesh - Dhaka; China - Hong Kong; Guam – Piti; Indonesia - Jakarta; Japan – Tokyo; South Korea – Seoul; Malaysia - Kuala Lumpur; Mauritius – Port Louis; New Zealand – Auckland; Pakistan – Karachi; Philippines - Manila; Singapore; Sri Lanka - Colombo; Taiwan - Taipei; Thailand - Bangkok; Vietnam – Ho Chi Minh

India: PoPs in over 120 cities throughout India; Metro Ethernet in 31 cities in India Europe: Austria - Vienna; Belgium - Brussels; Denmark – Blaavand, Hersted-Vester;

France – Marseille, Paris; Germany - Frankfurt; Hungary - Budapest; Ireland - Dublin; Italy - Milan; Netherlands - Amsterdam; Norway - Oslo; Poland - Warsaw; Portugal - Lisbon; Russia - Moscow; Spain – Madrid, Barcelona; Sweden - Stockholm; Switzerland - Zurich, Geneva; Turkey - Istanbul; United Kingdom – London, Cressex, Somerset

Middle East and Africa:

Angola – Luanda; Bahrain – Manama; Ghana – Accra; Kenya - Nairobi; Morocco - Casablanca; Nigeria - Lagos; Qatar – Doha; Saudi Arabia – Riyadh; South Africa - Cape Town, Johannesburg; UAE – Fujairah, Dubai; Tanzania – Dar-es-Salaam; Uganda – Kampala; Zambia – Lusaka; Zimbabwe – Harare North

America:

California - Los Angeles, Palo Alto, Santa Clara, San Jose; Illinois - Chicago; Florida - Miami; Georgia- Atlanta; New York - New York City; New Jersey – Newark, Wall; Texas – Dallas, Houston; Virginia - Ashburn; Washington - Seattle; Massachusetts - Boston; Canada - Montreal, Toronto, Vancouver, Lake Cowichan, Nova Scotia, Weir

Latin America:

Argentina - Buenos Aires; Brazil - Sao Paulo; Chile - Santiago; Columbia - Bogota; Ecuador - Quito; Guatemala – Guatemala City; Mexico - Mexico City; Panama - Panama City; Peru - Lima; Uruguay - Montevideo; Caracas - Venezuela

(19)

Reference

Material

• Video on Tata Communications WAN Ethernet portfolio

• WAN Ethernet microsite

• Provider Backbone Bridging (PBB) Knowledge Center

http://www.tatacommunications.com/vpn/PBBknowledgeCentre.asp

• NGE technical tutorial

• Low Latency Ethernet microsite

http://www.tatacommunications.com/vpn/low-latency-ethernet.asp

• Have a query related to PBB ?

Email Tata Communications Ethernet experts at [email protected]

(20)

For more information about Tata Communications WAN Ethernet Services, visit www.tatacommunications.com/vpn/ethernet.asp

About Tata Communications

Tata Communications is a leading global provider of a new world of communications. With a leadership position in emerging markets, Tata Communications leverages its advanced solutions capabilities and domain expertise across its global and pan-India network to deliver managed solutions to multi-national enterprises, service providers and Indian consumers.

The Tata Global Network includes one of the most advanced and largest submarine cable networks, a Tier-1 IP network, with connectivity to more than 200 countries across 400 PoPs, and nearly 1 million square feet of data center and colocation space worldwide.

Tata Communications’ depth and breadth of reach in emerging markets includes leadership in Indian enterprise data services, leadership in global international voice, and strategic investments in operators in South Africa (Neotel), Sri Lanka (Tata Communications Lanka Limited) and Nepal (United Telecom Limited).

Tata Communications Limited is listed on the Bombay Stock Exchange and the National Stock Exchange of India and its ADRs are listed on the New York Stock Exchange. (NYSE: TCL)

WAN

Ethernet

Services

India Tata Communications Plot No C 21 & 36,

‘G’ Block, Bandra Kurla Complex Bandra (E), Mumbai 400 098 Tel +91 22 6657 8765

Fax +91 22 6691 0000

Asia

Tata Communications International Pte Ltd

Tata Communications Exchange 35 Tai Seng Street #06-01 Singapore 534103 Tel +65 6632 6700 Fax +65 6634 8570 Tata Communications 2402 Bank of America Tower 12 Harcourt Road

Central, Hong Kong Tel +852 3693 8888 Fax +852 3690 202

Australia

Tata Communications King Street Wharf Suite 503, 35 Lime Street Sydney NSW 2000 Australia Tel +61 2 9299 2014 Fax +61 2 9299 2019 North America Tata Communications 2355 Dulles Corner Blvd 7th floor Herndon, VA 20171, USA Tel +1 877 255 8282 Fax +1 703 547 6555 Tata Communications 90 Matawan Rd – 3rd Floor Matawan, NJ 07747, USA Tel +1 732 888 6700 Fax +1 732 888 6809145 Tata Communications 1555 Rue Carrie-Derick Montréal, Québec Canada, H3C 6W2 Tel +1 514 868 7272 Fax +1 514 868 7234

Middle East & North Africa

Tata Communications Hamdan Street, City Center Building, Block – A,

2nd Floor, Office # 204 P.O. Box 41660 Abu Dhabi, United Arab Emirates Tel +971 2 626 6223 Fax +971 2 627 2624

Europe

Tata Communications 1st Floor, 20 Old Bailey London EC4M 7AN United Kingdom Tel +44 20 7029 9500 Fax +44 20 7029 9640 Tata Communications 131 Avenue Charles de Gaulle 92200 Neuilly sur Seine France

Tel +33 1 41 43 4200 Fax +33 1 41 43 4209 Tata Communications Avenida de Europa 4, Bajo A Parque Empresarial “La Moraleja” 28108 Alcobendas Madrid, Spain Tel +34 916 57 48 90 Fax +34 916 62 06 79 Tata Communications Bettinastrasse 30 D-60325 Frankfurt am Main Germany Tel +49 69 97461 123 Fax +49 69 97461 149

WAN Ethernet Services

WAN

Ethernet

Services

Summary

Table of

Contents

Understanding

Fundamentals

Defining the protection types: unprotected, deterministic, and mesh

protection

Defining CIR

Ethernet Service Types as Defined by the Metro Ethernet Forum

(MEF)

What are MEF Certifications?

What is a MEF Carrier Ethernet Certified Professional (MEF-CECP)?

Product

Nomenclature

Dedicated

Ethernet

Service details

EoSecure

Service details

Priority

Ethernet

Service details

Multipoint

Ethernet

Service details

Multipoint

Ethernet

Service details

Global Priority

Stretch

Ethernet

Service details

10 Gig

Ethernet

Service details

Low Latency

Global Dedicated Ethernet

Service details

Low Latency

Multipoint Ethernet

Service details

Enterprise

SLA Option

Service details

FAQs

WAN Ethernet

Coverage

Reference

Material

• Video on Tata Communications WAN Ethernet portfolio

• WAN Ethernet microsite

• Provider Backbone Bridging (PBB) Knowledge Center

• NGE technical tutorial

• Low Latency Ethernet microsite

• Have a query related to PBB ?

About Tata Communications

WAN

Ethernet

Services
