MICROSTRATEGY ON AWS

MICROSTRATEGY ON AWS

3:30 – 4:30 PM Track 8 | Session 3

WWW.IOLAP.COM 1

Presented by:

INTRODUCTIONS

iOLAP

 Data Warehousing and Business Intelligence consultancy

 MicroStrategy partner for 15 years

 Headquarters in Frisco, TX with national customer base

 50+ U.S. employees and 25+ developers in Europe

Nick Larsen

Managing Partner

 10 years at iOLAP

 MicroStrategy Architect

 AWS Architect

WHERE ARE YOU ON THE CLOUD JOURNEY?

What’s your current MicroStrategy infrastructure deployment?

 Evaluating

 Stealth

 IT closet

 Corporate data center

 Public data center

 Public Cloud (MicroStrategy/AWS/Azure/RackSpace/Other)

Is your organization running anything in a public cloud?

Who is currently an AWS customer?

61%

Moving to cloud in next 2 years

70%

10%

WWW.IOLAP.COM 3

PRESENTATION GOALS

 Provide an overview of Amazon Web Services products

 Describe AWS architectures that can benefit your data warehouse and BI platform

 Explore MicroStrategy deployment models in AWS and alternative use-cases

 Illustrate some experience differences of a cloud deployment

 Demonstrate an easy deployment of a disaster recovery scenario

CUSTOMER DEMANDS

Harder. Better. Faster. Cheaper.

“Developers are like artists; they produce their best work if they have the

freedom to do so, but they need good tools…agility is a function of

experimentation and fast failures.”

 Werner Vogels | CTO | Amazon.com

WWW.IOLAP.COM 5

KEY DW/BI AWS PRODUCTS

Workspaces

Cloud Formation EC2

Compute

S3 Glacier

Storage

RDS Redshift

Databases

VPC Direct Connect Route 53 Networking

EMR Kinesis Data Pipeline Data Processing

BIG PICTURE

corporate data center

3^rd Party Resources

S3

EMR Kinesis Data Pipeline Data Processing

EC2 Compute

RDS Redshift

Databases

EC2

Glacier Workspaces

WWW.IOLAP.COM 7

NETWORK & SECURITY ARCHITECTURE

us-east-1 us-east-1b

SUBNET1 SUBNET2

ISERV1

us-west-1 us-west-1a

SUBNET3 SUBNET4

ISERV2 WEB1

WEB2

SCALING MICROSTRATEGY

General Purpose

 T2: Development environments

 M3: Test and small production environments

Compute Optimized

 C3/C4: Large general production

Memory Optimized

 R3: High usage of Intelligence Cubes

IP Distribution

Data Warehouse

http://aws.amazon.com/ec2/instance-types/ WWW.IOLAP.COM 9

EXAMPLE DEPLOYMENT – INFRASTRUCTURE

Create basic services with Cloud Formation

 EC2

 RDS

 Redshift

Note Internal IP addresses

Attach an Elastic IP to the Web Server

MICROSTRATEGY AMI

MicroStrategy offers a free 30 day trial in an easy to deploy Amazon Machine

Image (AMI) from the AWS Marketplace. It includes 25 users and is deployed with

SQL Server 2012 to handle the metadata repository.

https://aws.amazon.com/marketplace/pp/B00JK1ZEK6/

Additional AMI’s are available for 50, 100, 250, and 1000 users. Pricing is by the

hour or annually plus EC2 usage, EBS storage, and data transfer fees.

WWW.IOLAP.COM 11

USE CASES – STARTING THE JOURNEY

Upgrades

 Easily upgrade your metadata and regression test against your primary environment using Integrity Manager

 Address issues in your AWS environment, upgrade your primary environment, and merge your changes back in

POC

 Mobile deployments

 New applications

 Portal integrations

Temporary Environments

8.x  9.x

USE CASES – GAINING TRACTION

Secondary Environments

Disaster Recovery

 Maintain an EBS snapshot of a MicroStrategy installation and have your CloudFormation scripts ready to go. When disaster strikes, create your environment and point it to your metadata or restore your latest metadata snapshot to RDS. Update DNS to point to AWS.

Development Branches

 Keep you existing development and test environments separate from external labor or special project needs

Dev/Test

 AWS is the perfect place for development and test environments

 Deploy Amazon Workspaces for client tools and forget about lost IServer connections

WWW.IOLAP.COM 13

USE CASES – ALMOST THERE

Unique Requirements

Seasonal Performance

 Additional hardware needs during certain time periods

 Cost effective…pay only for what you use

Geo Based Performance/Security

 Client connections must be routed to local data centers

 Reduce internet hops and latency

USE CASES – ALL IN

Temporary Environments Secondary Environments Unique Requirements

Assimilate

WWW.IOLAP.COM 15

CLOUD JOURNEY - EXAMPLE

Starting the Journey

 POC ingesting vendor PO and store inventory data

 Tech: Redshift, DMX on EC2

Gaining Traction

 Integrate daily store databases

 Tech: Redshift, custom .NET agent, S3, Python scripting on EC2, DMX on EC2

Almost There

 Integrate near real time store data

 Tech: Redshift, custom Java agent, S3, Python scripting

All In

 Migrated all websites to EC2

 Migrated all transactional databases to RDS

 Deployed multiple new applications that were previously outsourced

EXAMPLE DEPLOYMENT - CONFIGURATION

Connection from Web to iServer

Connection from iServer to Redshift

Determine private IP of Metadata (RDS)

Connection from iServer to Metadata (RDS)

Start the iServer

Connect Web to iServer

WWW.IOLAP.COM 17

CONSIDERATIONS FOR A CLOUD DEPLOYMENT

Location of Data

 Latency between data centers

 Security over network

 Data transfer costs

Security

 AWS provides multiple layers

 AWS warns you of unsafe configurations

Control

 You’ve lost some of it

Cost Management

 Monitor spending and adjust behaviors

 Purchase reserved instances

BYOL vs. Marketplace

 Capital vs. expense

 Do the math

Skillset

 A new kind of Architect may be needed

QUICK NOTE ON SECURITY

Physical

 24/7 trained security guards

 Electronic surveillance and multi-factor access control

Other Features

 SSL/TLS encrypted endpoints

 Security groups (firewalls)

 User management via IAM

 Private subnets via VPC

 Encrypted data storage

 Security logs

 Identification and configuration

Sharing the Responsibility

 With Infrastructure services, you own:

 Patching the OS

 Securing software

 Securing the security group

 With Platform services:

 AWS patches the OS

 You secure access to the service

WWW.IOLAP.COM 19

WHAT’S NEXT

As experts in Data Warehousing, Business Intelligence, and Cloud Architecture, iOLAP

is uniquely positioned to help you move through your cloud journey.

Services include:

 Cloud ready assessment

 Custom cloud architecture planning

 Cloud POC or Pilot

 Cloud migration

 Managed cloud service

www.iolap.com | 214.618.5206 | [email protected] Frisco, TX, USA | Rijeka, Croatia
