Field Office 2011 Software Suite Overview

(1)

Completion Production Intervention Drilling Evaluation Production optimization Artificial lift Control systems _{Flow measurement} Reservoir monitoring Software

• Analysis Workbench artificial-lift analysis • CygNet®_{EOP enterprise operation platform}

• CygNet Measurement electronic flow measurement and reconciliation • CygNet SCADA production midstream and pipeline operations • DataMart™_{analytical data}

• DTSPlus™_{temperature profiling}

• DynaLift™_{dynamic gas-lift optimization}

• i-DO®_{real-time optimization solution}

• LOWIS™_{life-of-well information software}

• MatBal®_{reservoir analysis and production forecasting}

• PanMesh™_{numerical well-test analysis}

• PanSystem®_{well-test analysis}

• PetroAtlas™_{petroleum engineering knowledgebase}

• PVTflex™_{fluid property analysis}

• ReO®_{network management optimization}

• ReO Forecast™_{production forecasting and field planning}

• RigPlan™_{resource scheduling}

• RMS reservoir monitoring system • Verge™_{production surveillance}

• WellFlo®_{well analysis}

• WellScribe™_{mobile data collection}

• WSM well-service manager

(2)

Weatherford’s Field Office™_{2011 software suite release is designed to}

help exploration and production companies optimize production from any field—whether conventional or unconventional—with naturally flowing and/or artificially lifted wells. The main objective is to help operators and engineers optimize the asset using real-time data and mathematical simulation models to minimize lifting costs and downtime. A significant increase in interest in shale and heavy-oil assets around the globe has led to many new features in the Field Office 2011 suite to monitor, analyze and optimize production from such assets.

What is new for the 2011 suite?

One key addition to the Field Office 2011 family is the CygNet® product

line. The CygNet enterprise operations platform (EOP) is currently used to monitor more than 250,000 wells in North America, and is now part of Weatherford’s real-time integrated production optimization solution. The

CygNet SCADA module is comprised of several building blocks, including

SCADA functions, protocol drivers, alarm management, security and a robust and efficient historian. CygNet’s pipeline module is widely used to monitor transportation of gas throughout North America safely.

The original applications of the Field Office family introduce many new functions. The LOWIS™ real-time production optimization solution now

supports optimization of progressing cavity pumping (PCP) and gas-lifted wells. The detailed analysis workbenches of these two lift types will help identify problematic wells through intelligent alarms and assist in running equipment at optimum settings so that production, as well as the life of the equipment, is maximized. Loading of gas wells with liquids is one of the main challenges faced when optimizing wells in shale fields. The newly added deliquification module in LOWIS software monitors gas production as well as liquid loading using real-time engineering calculations. This assists well analysts to take the right remedial actions, including the correct artificial-lift method selection proactively. WellFlo®

software, the artificial-lift design and analysis module of the Field Office suite, now supports plunger lift and jet pumps. Plunger-lift operators now have the ability to use WellFlo software to model gas-well deliquification.

(3)

For many assets, full-field real-time optimization—which is based on sub-surface, well and facilities models—is vital as bottlenecks could be present anywhere in the production system. In Field Office 2011, the i-DO®_{solution—designed for}

managing these systems in a real-time environment—is significantly enhanced to help the interdisciplinary team manage complex assets through a collaboration center. Extracting the correct information from various data bases and presenting it in the right form is required for quick and efficient analysis which ultimately augments efficiency of the entire asset-management team—from asset manager to the operator. The new key-performance-indicator (KPI) tracking functionality provides an overview of the asset’s performance with one click, while the issue-tracking feature keeps engineers and maintenance crews in synch.

Field Office suite modules include many new features, like the integration of LOWIS™ and ReO® software for facilities optimization of electric submersible

pumping (ESP) assets, parallel processing technology in the PanMesh™

application to achieve the maximum benefit of multi-core processors and an improved solver in the MatBal®_module.

To handle the diversity involved with collecting real-time data from different assets of various lift types, the Field Office suite uses open standards that ensure existing hardware and software tools are incorporated into the production optimization solution. This suite supports various mechanisms including web services and production markup language (ProdML) for data integration, and object-linking and embedding (OLE) for process controls (OPC®) to access

real-time systems.

Weatherford is committed to providing world-class solutions for maximizing production from any asset while minimizing CAPEX and OPEX. With the release of Field Office 2011, we have achieved another milestone in offering a unified real-time production optimization portal for all artificial-lift types.

(4)

ReO

®

Field Network

Optimization

ReO Forecast

™

Productivity

Forecasting

MatBal

®

Reservoir

Simulation

Verge

™

Field

Visualization

LOWIS

™

Real-Time

Well Monitoring

and Analysis

i-DO

®

Real-Time Well

and Network

Engineering

Analysis Workbench

Artificial-Lift Analysis

RigPlan

™

Asset Scheduling

WSM

Well Service Manager

™

WellScribe

™

Wellsite Activity Capture

PanSystem

®

Downhole

Well-Test Analysis

PanMesh

™

Downhole

Well-Test Simulation

RMS

Reservoir

Monitoring System

DTSPlus

™

Distributed Temperature

Data Acquisition

DynaLift

™

Gas-Lift

Dynamic

Simulation

WellFlo

®

_{Nodal Analysis}

LinkBox

™

Data

Communicator

CygNet® EOP

Enterprise Operation

Platform

PetroAtlas

™

Petroleum

Engineering

Knowledgebase

DataMart

™

Analyzed Data

PVTflex

™

Flow Assurance

CygNet® Measurement

Electronic Flow Measurement

and Reconciliation

CygNet® SCADA

Production Midstream

and Pipeline Operations

Field Office

™

2011 Integrated Applications

The rapid uptake of new technology in the production operations domain can expose companies to unnecessary financial risk. Use of the suite’s comprehensive offering eases this burden and allows producers to focus on the core activity of optimizing oil and gas production.

(5)

ReO

®

Field Network

Optimization

ReO Forecast

™

Productivity

Forecasting

MatBal

®

Reservoir

Simulation

Verge

™

Field

Visualization

LOWIS

™

Real-Time

Well Monitoring

and Analysis

i-DO

®

Real-Time Well

and Network

Engineering

Analysis Workbench

Artificial-Lift Analysis

RigPlan

™

Asset Scheduling

WSM

Well Service Manager

™

WellScribe

™

Wellsite Activity Capture

PanSystem

®

Downhole

Well-Test Analysis

PanMesh

™

Downhole

Well-Test Simulation

RMS

Reservoir

Monitoring System

DTSPlus

™

Distributed Temperature

Data Acquisition

DynaLift

™

Gas-Lift

Dynamic

Simulation

WellFlo

®

_{Nodal Analysis}

LinkBox

™

Data

Communicator

CygNet® EOP

Enterprise Operation

Platform

PetroAtlas

™

Petroleum

Engineering

Knowledgebase

DataMart

™

Analyzed Data

PVTflex

™

Flow Assurance

CygNet® Measurement

Electronic Flow Measurement

and Reconciliation

CygNet® SCADA

Production Midstream

and Pipeline Operations

(6)

ReO

®

ReO Forecast

™

MatBal

®

Verge

™

LOWIS

™

i-DO

®

Analysis Workbench

RigPlan

™

WSM

WellScribe

™

PanSystem

®

PanMesh

™

RMS

DTSPlus

™

DynaLift

™

WellFlo

®

LinkBox

™

CygNet® EOP

PetroAtlas

™

DataMart

™

PVTflex

™

CygNet®

Measurement

CygNet®

SCADA

WellFlo

®

2011 well analysis

WellFlo systems analysis software is a powerful and simple-to-use application to design, model, optimize and troubleshoot individual oil and gas wells, whether naturally flowing or artificially lifted. The accurate and rigorous well models built using WellFlo software display the behavior of reservoir inflow, well tubing and surface pipeline flow for any reservoir fluid. Specific applications for which the software can be used include:

• Well configuration and completion design for maximum performance over the life of well

• Artificial-lift design and analysis for gas lift, ESP, PCP, jet pump and plunger lift

• Prediction of flowing temperatures and pressures in wells and flowlines and at surface equipment for optimum design calculations

• Reservoir, well and flowline monitoring

• Generate vertical-lift performance curves for use in reservoir simulators

What’s new for version 2011?

• Jet-pump design and analysis

• Plunger-lift design and analysis

• Equation of State (EoS) based compositional pressure-volume-temperature (PVT)

• Enhanced black-oil PVT correlation tuning functionality

• Enhancements in ESP module

• Enhancements in critical unloading velocity calculations

How does this application help improve job performance?

Engineers • Builds well models using a guided step-by-step well configuration interface

– Accurate and rigorous models display the behavior of reservoir inflow, well tubing and surface pipeline flow for any reservoir fluid

• Develops effective well completions including artificial-lift systems

– Ensures more effective capital expenditure by enhancing the design of wells and completions

– Reduces operating expenditure by finding and curing production problems

– Enhances revenues by improving well performance

Collaborators Operators and engineers analyze field problems and design solutions using rigorous algorithms and accurate models

(7)

ReO

®

ReO Forecast

™

MatBal

®

Verge

™

LOWIS

™

i-DO

®

Analysis Workbench

RigPlan

™

WSM

WellScribe

™

PanSystem

®

PanMesh

™

RMS

DTSPlus

™

DynaLift

™

WellFlo

®

LinkBox

™

CygNet® EOP

PetroAtlas

™

DataMart

™

PVTflex

™

CygNet®

Measurement

CygNet®

SCADA

WellFlo®_{jet-pump design}

WellFlo plunger-lift design

WellFlo gas-lift design

(8)

ReO

®

ReO Forecast

™

MatBal

®

Verge

™

LOWIS

™

i-DO

®

Analysis Workbench

RigPlan

™

WSM

WellScribe

™

PanSystem

®

PanMesh

™

RMS

DTSPlus

™

DynaLift

™

WellFlo

®

LinkBox

™

CygNet® EOP

PetroAtlas

™

DataMart

™

PVTflex

™

CygNet®

Measurement

CygNet®

SCADA

LOWIS software is a client-server, network-based, enterprise-wide well-management suite designed to help improve the bottom line for any oil and gas production operation. It includes real-time monitoring, analysis workbenches (AWB) for all forms of artificial lift–including reciprocating rod lift (RRL), ESP, PCP and gas lift. This workflow-management software contains applications for field managers, well analysts, operations managers, work-crew managers and upper management. The software application provides real-time monitoring and alarming capabilities coupled with integrated analytical and reporting tools to achieve optimum well performance. Using the program’s AWB modules and customizable workflow interface, operators can more quickly identify, prioritize, plan and service poor performing wells, thereby reducing downtime and the associated production losses. The combination of built-in score-carding tools and complete well histories available in the Well Service Manager™_{(WSM) module enables producers to}

develop and implement best practices in failure management. Valuable, historical well data once stored in spreadsheet files on individual desktops can now be stored and shared on central servers. Single-point viewing of data from multiple disparate sources enables the knowledge-sharing process and facilitates better decision making.

The software includes full SCADA functionality for well monitoring and control with a common interface to view and interact with data from multiple sources. It integrates surveillance, analysis and well service management tools and displays seamless trending, reporting and graphing. It supports all well types and processes and prioritizes field and well surveillance opportunities from several methods of wellhead telemetry.

LOWIS

™

(9)

What’s new for version 2011?

Introducing LOWIS™_PCP

The AWB module for PCP-lifted wells provides a set of analytical tools that help engineers and operators focus on the root cause of underperforming wells and equipment.

• Key functionalities of the AWB module

– Nodal-analysis-based operating point tracks well and equipment performance over time

– Pressure-traverse-analysis provides a tool for tuning the calculated data to the measured data

– Pump-flow-performance analysis enables tuning of flow performance using measured production data

– Pump-torque-performance analysis provides the ability to tune system torque based on measured operating data

• PCP analysis performance: Nightly analysis of calculated performance versus measured performance to identify potential well and equipment problems

• Intelligent alarms: Preprogrammed algorithms that recognize changes/slopes of different calculated and measured values using pattern recognitions

• Production reports: Provide engineers and operators tools that help manage field wide production for the next 24 hours

• Generic MODBUS®

and OPC controller supports

Introducing LOWIS gas lift

Surveillance and AWB modules for gas-lift wells help engineers to identify underperforming wells and calculate the optimum lift-gas injection rate for each well in the asset.

• Surveillance

– Remotely capture real-time information on well performance and associated details

– Enable remote terminal unit (RTU) analog alarms based on any deviation

– Performance trending: Quick trending of the calculated production data

• Analysis

– Ability to determine the validity of the well test–validate well test, create engineered well test, update well model

– Automatically tune nodal-analysis-based well model using production well-test data

– Calculate daily production rates using real-time data and tuned-engineering well model

– Compare well-test/production data against gas-lift performance curve generated by the assigned well model

– Perform multi-point injection analysis and set associated intelligent alarms

– Optimum lift-gas distribution analysis based on the compressor station capacity

MODBUS is a registered trademark of Schneider Automation Inc.

LOWIS PCP operating point analysis chart

Gas-lift installation analysis: Analyze and tune well test, production data

(10)

What’s new for version 2011?

(continued) Introducing LOWIS™

gas-well deliquification

The gas-well deliquification AWB module for gas wells provides all the surveillance, alarming, trending, analysis and reporting functionalities that has become the industry standard for production optimization. This solution helps analysts perform liquid loading analysis and forecasting and the monitoring of gas wells not only based on real-time pressure, temperature and rate data, but also on calculated results based on nodal-analysis-based engineering calculations such as critical and actual gas velocities and the effect of the velocity string.

• Ability to remotely capture real-time information on well performance and associated details and generate necessary alarms for proactive asset management

• Enables quick visualization of trends that affect production and forecast of liquid loading

• Ability to determine a gas well’s liquid loading status, perform nodal-flow analysis (critical and in-situ analysis) and perform operating-point and sensitivity analysis (flowing tubing pressure, tubing size, etc.)

• Daily updated velocity curves and comparison to latest model with alarming functionality

• Provides a daily report of comparison results of well’s performance versus forecasted performance via the well model

LOWIS RRL

• Modified Everitt-Jennings1_{algorithm for}

downhole-card and rod-stress calculations

• Displays effective downhole loads, automatically determines the best damping factor for each card and calculates multiple stress points on each rod taper

• Downhole problems such as pump wear, gas compression, excessive friction, overstressed rods, tubing-anchor slippage and changes in fluid level can be easily identified

• Diagnostic reports and pattern-matching library enables user to build dynamometer card libraries specific to their field and assist both novice and advanced users in quickly identifying well problems and taking the proper corrective action

1_{Everitt, T.A. and Jennings, J.W. SPE 18189, Improved Finite-Difference Calculation of Downhole dynamometer Cards for}

Sucker-Rod Pumps, Feb 1992

LOWIS RRL AWB with Everitt-Jennings stress plot

Operating point analysis Effects of changing WGR

(11)

• Improved user-friendly interface and workflow enables users to make optimization decisions quicker

• Added new checks that enable users to make fully informed operational decisions to prevent premature failures and optimize production

• Added engineering calculations enable the user to check system performable against limitations including AOF; pump shaft, pump-housing burst pressure, motor HP, protector thrust bearing, surface-drive KVA and surface-transformer KVA limits

• Improved upthrust/downthrust detection by tracking

operating point movement and position in the recommended operating range in real-time mode. This new feature brings great benefits to operators for preventing fast ESP wear during well-commissioning periods

• New product catalogs

• Significantly improved analysis reports

• LOWIS ESP software is seamlessly linked to ReO®

surface-facilities-optimization software

LOWIS SCADA

• LOWIS admin tool

• New point-chart workbench

• Support for Microsoft®_{active directory}

How does this tool help improve job performance?

Operators • Enables well management by exception with easy-to-use surveillance

• Detects well performance degradation

• Assesses field operations

• Improves operational efficiency

Engineers • Modeling and analysis of various artificial-lift methods

• Identifies wells operating at less than optimal settings for different lift types

• Calculates optimum set points of various lift equipment and implements them remotely to maximize production and life of the equipment

• Smart approach for multiple scenarios

• Manages the asset in a proactive rather than reactive manner

Collaborators • Brings critical well and field data into a single application

• Provides a platform for sharing all well data, analysis and analysis tools for production optimization decision making

• Maximizes the efficiency of the team with unique alarm types for each job function

Managers • Enables performance analysis based on asset, region, engineer, etc.

• Provides routine management and reporting

• Plans, executes and evaluates processes of individual jobs in the field with comprehensive workflow management

• Helps achieve common objective for the whole asset with maximum production and minimal CAPEX and OPEX

Microsoft is a registered trademark of Microsoft Corporation

LOWIS ESP new interface enables users to see the impact of sensitivity analysis on both pressure traverse plot and operating point analysis simultaneously. Analysis is now run at the click of the mouse.

(12)

CygNet enterprise operations platform (EOP) collects, manages and

distributes massive amounts of real-time information while maintaining network performance. The CygNet EOP platform’s robustness, and performance contribute to the lowest total cost of ownership in the industry. The platform and its suite of vertical applications collects, manages and distributes vast amounts of data integral to all facets of production operations.

CygNet EOP has proven scalability to support thousands of users while

providing unparalleled speed and predictable response times.

The CygNet SCADA product consists of several building blocks or modules—

SCADA functions, protocol drivers, alarm management, security,

system-management utilities, historian, enterprise integration suite (EIS), gas applications and native CygNet clients—which provide human machine interface (HMI) functions. Modules combine to efficiently collect, manage and distribute data to various users from operators to the casual executive user. Some modules are packaged together in a clearly defined manner so quality-control testing, distribution of upgrades, bug fixes and patches are reliably tested and product installs/upgrades are not problematic.

What is new for version 2011?

Extended native integration capabilities of EIS with “business objects”, which provide a data-abstraction model to express data attributes with a user-defined naming convention. Multiple data object mappings are supported for enterprise SCADA installations with diverse implementations, enabling more data consumers to leverage operational performance information seamlessly within their transactional systems and business applications of choice.

Enhanced native equipment interface engines (EIEs) with improved use of IP-based communications infrastructure. Added support for a number of new EIEs for the latest industry field devices.

Improved gas measurement repository (GMR) data import/export capabilities with new on-demand data-export menu in GMR explorer; CFX file export with time boundaries identified by remote device, duplication of meter data between GMR

services and a new scheduled-data import task supporting multiple common file types.

Improved performance and reliability based on the support of clustering on Windows Server®

2008 R2 and Microsoft’s extensible storage engine (ESE), which is now incorporated into the native database services. These enhancements improve interface startup time and speed of service replication, provide recovery and simplify incremental backups.

Windows Server is a registered trademark of Microsoft Corporation.

CygNet

®

2011 enterprise operations platform for the oil and gas industry

CygNet software enterprise operations platform, applications and connectors to associated systems.

(13)

ReO

®

ReO Forecast

™

MatBal

®

Verge

™

LOWIS

™

i-DO

®

Analysis Workbench

RigPlan

™

WSM

WellScribe

™

PanSystem

®

PanMesh

™

RMS

DTSPlus

™

DynaLift

™

WellFlo

®

LinkBox

™

CygNet® EOP

PetroAtlas

™

DataMart

™

PVTflex

™

CygNet®

Measurement

CygNet®

SCADA

How does this tool help improve job performance?

Operators • Monitors and controls local and remote control events

• Navigates and proactively addresses alarms and controls

• Predictable performance

Engineers • Delivers real-time information for engineering applications

• Ensures compliance with operational safety, reliability and efficiency

• Optimizes production from existing assets through the delivery of real-time analytics

Collaborators • Empowers unified data use across the enterprise

• Open interface connectors to support a wide range of associated systems

• Unifies and distributes volumes of essential data without significant network use or latency throughout the enterprise

Over 11,000 CygNet®

clients operate on the desktops of oil and gas companies throughout the world. The performance oriented display of real time information is displayed in templates targeted to user personalities.

(14)

LOWIS Online service provides the benefits of real-time surveillance and analysis found in LOWIS life-of-well information software in a hosted environment. With

LOWIS Online service, Weatherford hosts a server running a full version of the

LOWIS application on its network, and provides secure Internet access to clients. This hosted environment enables small organizations with limited IT resources to have the full capabilities of the LOWIS application. As an added benefit, Weatherford offers engineering and consulting services to assist in the analysis and optimization of a client’s producing wells.

Benefits of

LOWIS

Online service

• Full use of the LOWIS application in a hosted environment

• Weatherford performs the server hosting and manages system reliability, security and accessibility

• Quick deployment

• Experienced well analysts available for consultation

How does this application help improve job performance?

Operators • Enables well management by exception with easy-to-use surveillance system

• Provides early detection of well-performance degradation

• Assesses field operations quickly

• Improves operational efficiency

Engineers • Provides comprehensive modeling and analysis of various artificial-lift methods

• Identifies wells operating at non-optimal settings for different lift types

• Manages the asset proactively rather than reactively

• Provides a platform for sharing all well data, analysis and analysis tools for production optimization decision making

LOWIS

™

Online–

LOWIS

as a service

Satellite Network Cellular Network LOWIS Server Weatherford Network Internet Engineer/Corporate Office Air Card/VPN

Weatherford Well Analysts

Production Foreman/Field Office

Analysis Services

• Experienced analysts • Detailed reports • Optimization services

(15)

Our LiftAdvisor service supplies operators with web-based well surveillance, operational-alert emails and detailed status reports for both RRL and PCP wells. This service can be scaled to include wellsite hardware and communication services. Additionally, the operator has access to Weatherford’s experienced analysts to provide evaluation and recommendations for well-operation improvements.

Benefits of

LiftAdvisor

service

• Web-based well status and reporting

• Quick deployment

• Experienced well analysts available for consultation

• Scalable solution can include wellsite automation and communication

How does this application help improve job performance?

Operators • Enables well management by exception with easy-to-use interface for surveillance of well status and dynagraph data

• LiftAdvisor service is used for early well startup monitoring, portable analysis service for trouble wells or as a fixed monitoring and analysis service

Collaborators Weatherford engineering and consulting services provide expert analysis and recommendations on well operational data

(16)

ReO

®

ReO Forecast

™

MatBal

®

Verge

™

LOWIS

™

i-DO

®

Analysis Workbench

RigPlan

™

WSM

WellScribe

™

PanSystem

®

PanMesh

™

RMS

DTSPlus

™

DynaLift

™

WellFlo

®

LinkBox

™

CygNet® EOP

PetroAtlas

™

DataMart

™

PVTflex

™

CygNet®

Measurement

CygNet®

SCADA

PVTflex software enables engineers to build black-oil and compositional fluid PVT models for accurate gas/oil/water phase behavior predictions of oil and gas systems at a wide range of temperatures and pressures. The program offers engineers a unified way of generating highly accurate PVT models, which can be employed in multiple Field Office™_{modules for various calculations and}

determining the optimum set points for wells and different segments in the production system. Using PVTflex

software as part of the Field Office suite ensures that a consistent methodology is applied across all modules and minimizes duplication efforts.

What is new for version 2011?

• Multiple black-oil fluid-models tuning based on laboratory experimental data (CCE, DV, CVD, etc.)

• Export original or tuned component properties for use in Field Office software or third-party application

• Plots of different experiments are now displayed on separate tabs

How does this application help improve job performance?

Engineers Calculates optimization accurately

Collaborators Unified compositional and black-oil PVT modeling for reservoir simulation

PVTflex

™

2011 fluid property analysis

(17)

solutions for surface networks incorporating practically every piece of equipment from wellhead to the processing plant. The application simulates the total production system behavior and concurrently optimizes the production. It does this while honoring the user-defined constraints, including economic models, which typically results in substantial production increases and/ or reductions in operating costs. The application’s unique integrated simulation and optimization approach enables users to handle large and complex networks with ease.

ReO Forecast software, a powerful companion

program to ReO software, is an ideal tool for production forecasting, facilities design and sizing and reservoir development planning. It couples ReO results of surface network modeling with sub-surface modeling applications such as material balance or reservoir simulators. This integrated solution helps the operator to make accurate production predictions over the life of the asset.

What is new for version 2011?

• ReO software

– Network trimming visualization

– Network copy-and-paste, including constraints

– ReO-LOWIS™

software integration for ESP wells

– Toolbar and equipment graphics update

• ReO Forecast software

– Compatibility with Windows®

7, 64 bit

How does this application help improve job performance?

Engineers • ReO software

– Its flexibility enables engineers to build and analyze complicated network models efficiently

– Assists the engineer with running the asset at optimum condition for maximizing the recovery and proactive field management to minimize production loss

– Identify and proactively mitigate flow interruptions caused by hydrate, wax or asphaltene deposits

• ReO Forecast software

– The software offers unprecedented flexibility and powerful calculation methodology to analyze and optimize production and perform business planning in the design, operations and forecast phases.

Collaborators Integrates reservoir, production and process teams to ensure that the software results can be realistically implemented in the field and the production forecasting is based on the model which covers the entire production system–reservoir to sales point

Windows is a registered trademark of Microsoft Corporation.

ReO Forecast

2011 production forecasting and field planning

ReO gas-lift system

ReO Forecast oil/gas/water production profile

(18)

i-DO software is a one-stop shop for asset teams designed to help oil and gas producers achieve their real-time optimization and analysis objectives. It provides full access to key information to enable an integrated team to maximize value from their asset by providing automated workflows, continual optimization, prediction and identification of crucial issues in a very clear, visual form. The i-DO platform aggregates data from multiple disparate data sources, including production-well testing, real-time data, corporate targets and modeling data. The program uses this data to run multiple automated petroleum-engineering workflows to produce an up-to-date view of the asset production performance and intelligent recommendations for optimization.

The integrated optimization engine continually analyzes and optimizes the asset in real time using all of the available information to decide, for example, whether a production-well test is valid, or if a well is starting to experience issues. It then provides ranked issues with recommended solutions. By automating the daily key processes in an asset and providing an intelligent optimization solution, i-DO

software enables engineering teams and management personnel to concentrate on critical issues with expert assistance to help decide the most appropriate actions.

The i-DO system provides a visualization layer to enable engineers and managers to go from a high-level overview of KPIs and the state of production at the precise moment to focus on the source of problems with just a few mouse clicks. All of the important information for a workflow is available in a single, clear visual screen that is contextually based and intuitively guides users through the various steps of workflows. The screens display the current state, in addition to predictions and recommendations for potential optimization gains. The platform has the ability to contextually launch multiple other applications enabling the user to do further, detailed analysis.

A built-in issue-tracking program enables engineers and managers to view the well’s full history and provides a portal to work together on outstanding issues. The i-DO tracking program includes automatic, rule-based email notifications to keep users conscious of critical issues and enables collaboration via instant messaging, email, Microsoft Office and contextual links to other systems. Discussions over issues are recorded for future reference and are searchable. A reporting component gives users the ability to effortlessly gather relevant information and create management reports.

i-DO

®

2011 real-time optimization solution

Key KPIs always available

Single-asset overview—current, prediction, ranked issues, optimization potential

(19)

ReO

®

ReO Forecast

™

MatBal

®

Verge

™

LOWIS

™

i-DO

®

Analysis Workbench

RigPlan

™

WSM

WellScribe

™

PanSystem

®

PanMesh

™

RMS

DTSPlus

™

DynaLift

™

WellFlo

®

LinkBox

™

CygNet® EOP

PetroAtlas

™

DataMart

™

PVTflex

™

CygNet®

Measurement

CygNet®

SCADA

The i-DO system’s intelligent-solution recommendations, optimization potential, predicted production and

clear contextual visualizations enable engineers and managers to work together as a single, integrated team to maximize production, minimize losses and concentrate on optimization opportunities rather than data gathering and analysis of out of date information. In addition to benefiting those directly related to an asset, the system enables other stakeholders and senior management to see how an asset is performing at any time, and make more timely, informed decisions.

What’s new for version 2011?

• KPI tracking

• Built-in workflows for engineers

• Issue tracking

• Custom report generation

• Enhanced-graphic user interface

How does this application help improve job performance?

Operators • Easy storage and analysis of real-time well and facilities data

• Quickly identifies and solves issues

Engineers Automated work flows enable engineers to focus on challenging optimization tasks

Collaborators • Helps reservoir, production and process engineers work together to:

– Prioritize issues

– Analyze data

– Design optimization strategies

Managers Quickly identifies problems with single-screen current overview of asset performance (actual against targets and optimization potential) with drill down capability

All key contextual well information in one screen—current, predicted, ranked issues, recommendations

(20)

ReO

®

ReO Forecast

™

MatBal

®

Verge

™

LOWIS

™

i-DO

®

Analysis Workbench

RigPlan

™

WSM

WellScribe

™

PanSystem

®

PanMesh

™

RMS

DTSPlus

™

DynaLift

™

WellFlo

®

LinkBox

™

CygNet® EOP

PetroAtlas

™

DataMart

™

PVTflex

™

CygNet®

Measurement

CygNet®

SCADA

Weatherford’s MatBal product provides analysis, evaluation and prediction of the response of hydrocarbon reservoir systems using fundamental material balance principles. The ease with which material balance principles can be applied results in an efficient and cost-effective alternative to more complex and expensive simulation techniques.

What is new for version 2011?

• Tabular relative permeability tables for fractional flow

• Condensate reservoir-modeling capabilities

• Improved solver for transmissibility between reservoirs

How does this application help improve job performance?

Engineers • Production engineers can:

– Estimate the volume of fluids initially present in the reservoir

– Estimate the type and size of the aquifer

– Examine the effects of changes resulting from produced and injected fluids

• Reservoir engineers can perform each stage of a material balance study quickly and efficiently including:

– Building an appropriate material balance model

– Matching to historical data

– Generating production forecasts

Collaborators Production and reservoir engineers work with practical reservoir descriptions to develop optimum exploitation strategies

MatBal

®

2011 reservoir analysis and production forecasting

Comparison of observed and calculated pressure values

(21)

ReO

®

ReO Forecast

™

MatBal

®

Verge

™

LOWIS

™

i-DO

®

Analysis Workbench

RigPlan

™

WSM

WellScribe

™

PanSystem

®

PanMesh

™

RMS

DTSPlus

™

DynaLift

™

WellFlo

®

LinkBox

™

CygNet® EOP

PetroAtlas

™

DataMart

™

PVTflex

™

CygNet®

Measurement

CygNet®

SCADA

PetroAtlas software is a web-based mentoring and

guidance system for petroleum production personnel. This robust linked knowledge management system is preloaded with thousands of pages of guidance properly linked to best practices, work flows and tasks leading production engineers through the labyrinths of variables to reach optimum results. PetroAtlas software covers the following processes:

• Selection, design appraisal, completion evaluation to execution

• Well integrity

• Field life cycle value optimization: Design through operation

• Production management

• Preparations for operation: Surveillance, monitoring, operating plans and guidelines

• Production performance and optimization

• Well and field production delivery assurance

How does this application help improve job performance?

Engineers and

Collaborators • PetroAtlascontext even highlighting unknowns such that teams gain a better software helps put decisions and their elements into understanding of their assets and can prioritize work required to maximize their potential

• Critical knowledge and expertise captured in the form of work flows, methods, guidance, tools and best practices provide production engineering mentoring to less experienced personnel; thereby enabling organizations to improve decision making and achieve higher efficiencies across the board

PetroAtlas software offers workflow-based and quick launch navigation to the knowledge base

(22)

ReO

®

ReO Forecast

™

MatBal

®

Verge

™

LOWIS

™

i-DO

®

Analysis Workbench

RigPlan

™

WSM

WellScribe

™

PanSystem

®

PanMesh

™

RMS

DTSPlus

™

DynaLift

™

WellFlo

®

LinkBox

™

CygNet® EOP

PetroAtlas

™

DataMart

™

PVTflex

™

CygNet®

Measurement

CygNet®

SCADA

PanSystem software is a robust yet easy-to-use software

that simplifies complex transient well testing through detailed analysis, simulation and reporting. PanSystem software is dedicated to transient well testing and has the unique capability to obtain information from within the reservoir surrounding the well and present the appropriate testing and analysis techniques that provide important reservoir parameters:

• Permeability of the reservoir-at-large and, in some cases, the near-wellbore region

• Completion efficiency, effective open interval size (over the life of the well)

• Reservoir structure (boundaries, heterogeneities)

• Reservoir pressure

• Nature of any pressure support

• Drainage area, connected pore volume and initial hydrocarbons in place

• Vertical permeability, vertical communication in layered systems

• Well performance (over the life of the well)

• Communication between wells

• Deliverability and production forecasts

What is new for version 2011?

• Completely revised graphical interface enabling more efficient and intuitive use

• Introduced a workflow based architecture to help guide the user through an analysis session and improved graphical interaction

• Improved appeal and efficiency of use to the industry, while retaining expert use tool ability

• Improved product stability and fuller use of the multiple graphics interface (MDI) capabilities

• Significantly improved processing speed in the preparation and analysis of large datasets

• Russian language support

• Added an analytical model for a horizontal well with multiple hydraulic fractures for analysis, simulation and forecasting in shale gas environments

How does this tool help improve job performance?

Operators • Improved and more intuitive product uptake by end users, with guidance through the workflow to less experienced users

• Pressure transient analysis is a key part of extending the reservoir into the well environment

Engineers • Improved user experience and efficiency of use

• Retained expert tool appeal while improving the graphical interaction and access to core functionality

Collaborators PanSystem software is released in an enterprise edition enabling network level collaboration within a client organization on all aspects of pressure transient analysis

PanSystem

®

2011 well test analysis

Comparison of buildup tests run in the same well in 2007 and 2009.

Pre-test data from a wireline formation tester with probe. PanSystem software has models to interpret the active and interference signals from a dual- or packer-probe combination.

(23)

Well-test analysts need a numerical simulator to reach beyond the limits of analytical simulation to handle complex situations like irregular or complex boundary geometries, multiple layers, multiple completions, rock and fluid heterogeneities. The PanMesh application, a true three-dimensional well-test simulator fully integrated into PanSystem®

software, meets all of these needs. It fulfills the same basic simulation objectives as the analytical quick match and advanced simulators available in the PanSystem application in terms of model validation and test design and occupies a similar place in the work flow, but has a far greater modeling capability.

What is new for version 2011?

• Improved graphical interface and entry point from

PanSystem software providing a closer link between

analytical and numerical work flows, enabling intuitive uptake of the PanMesh techniques.

• A significantly improved model-definition interface provides an easy to use drawing pad for model definition and offers the following key features:

– Drawing-pad-style toolbar

– Improved mouse functionality

– Improved scaling/view control of model

– Intuitive drag (move) option

– Undo/redo action

– One-step scale-model feature

– Extensive model-check feature

• Enhanced efficiency with added parallel processing technology. PanMesh

software now runs significantly faster on large models using the new parallel, multicore processing technology of modern PCs and laptops. For example, a simulation will run four times faster on a four-core processor. This particularly benefits modeling more complex model layouts.

How does this application help improve job performance?

Operators • Numerical analysis can provide insight to complicated or difficult to interpret analytical work flows

• It enables modification and investigation of a theoretical response to improve an analytical match to a reservoir response and hence structure

Engineers • Improved interface and use to help bridge the gap between the wealth of experience in the analytical domain and limited experience in the numerical domain

• PanMesh’s color visualization facility offers a deeper understanding of the nature of the transient response by tracking the pressure transient as it propagates through the reservoir

• Enables the analyst to see how changes in the model structure correlate with changes in the pressure derivative

Collaborators Better pressure-test designs result in improved reservoir understanding across domains

The new model building interface for

PanMesh software provides an easy to use drawing pad.

PanMesh software is now even more stable and uses a parallel solver to avail of multicore processors.

(24)

ReO

®

ReO Forecast

™

MatBal

®

Verge

™

LOWIS

™

i-DO

®

Analysis Workbench

RigPlan

™

WSM

WellScribe

™

PanSystem

®

PanMesh

™

RMS

DTSPlus

™

DynaLift

™

WellFlo

®

LinkBox

™

CygNet® EOP

PetroAtlas

™

DataMart

™

PVTflex

™

CygNet®

Measurement

CygNet®

SCADA

During production, wells that are down need immediate attention to reverse lost revenue back to production. Every hour, day or days that a well waits for a rig repair is a liability so operators need to find ways to bring wells on line as fast as possible. Adding more rigs to a field operation is not always the answer. Without an organized way of administering additional rigs, you can end up with more downtime for your resources. Getting production started faster after a well installation or repair requires having the precise assets ready for each job at the appropriate time. Rigs waiting on materials to arrive or a high-priority well waiting for a rig are both detrimental to starting wells in a timely manner. The WSM module in LOWIS™

software provides an efficient way to gather and store well information for effectively managing all well activities and the assets used for those events. The applications that make up this program present you with the ability to track, view and manage drilling and well intervention jobs in an organized way that enables you to make better decisions regarding resource usage, well prioritization and allocation of operational funds. With WSM software, you get more from your assets and can be confident when it is time to make additions because you have the information needed to effectively use your resources.

What is new for version 2011?

• Importation of drilling jobs, events and wellbore components from OpenWells®

• Spanish language support

• Better representation of fill components in the wellbore diagram

How does this application help improve job performance?

Operators • Quick access to well work histories and failures

• Job planning and execution tools

• Routine management and reporting

Engineers • Workover planning tools

• Failure analysis tools

• Best practices development

• Plans versus actual job cost evaluations

• Combines operation and engineering analysis tools

OpenWells is a registered trademark of Landmark Graphics Corporation.

WSM 2011 well-service manager

(25)

ReO

®

ReO Forecast

™

MatBal

®

Verge

™

LOWIS

™

i-DO

®

Analysis Workbench

RigPlan

™

WSM

WellScribe

™

PanSystem

®

PanMesh

™

RMS

DTSPlus

™

DynaLift

™

WellFlo

®

LinkBox

™

CygNet® EOP

PetroAtlas

™

DataMart

™

PVTflex

™

CygNet®

Measurement

CygNet®

SCADA

Collecting information in the field ensures accuracy because each event is entered as it occurs on site. However, traditional computers are not suitable for the rig floor. WellScribe screens are designed to accommodate field use through various devices that can handle the rigors of life in the field.

WellScribe tablet is a specially designed device that runs WellScribe software. The unit provides an easy-to-use interface sequence with large touch-screen button format that can be used with safety gloves.

WellScribe mobile is a barcode scanner that simplifies data input by eliminating keystrokes. The task list for a job is printed on a sheet of paper so field crews merely need to scan each task as they start and complete them.

What is new for version 2011?

Features

• Backlog filtering using global positioning system (GPS)

• Improved performance when using slow networks

• Spanish language support

• Entry of extended event information such as safety personnel

• Entry of job cost information

Benefits

• Field crew has flexibility to enter activities not foreseen by planners

• Costs associated with ad-hoc services are immediately captured

How does this application help improve job performance?

Operators No need to fill out forms for rig activity

Engineers • Receive up-to-date reports in near real time

• Eliminate transcription errors

Collaborators Immediate reconciliation of activities and costs enables planners and managers to address discrepancies sooner

(26)

ReO

®

ReO Forecast

™

MatBal

®

Verge

™

LOWIS

™

i-DO

®

Analysis Workbench

RigPlan

™

WSM

WellScribe

™

PanSystem

®

PanMesh

™

RMS

DTSPlus

™

DynaLift

™

WellFlo

®

LinkBox

™

CygNet® EOP

PetroAtlas

™

DataMart

™

PVTflex

™

CygNet®

Measurement

CygNet®

SCADA

ReO

®

ReO Forecast

™

MatBal

®

Verge

™

LOWIS

™

i-DO

®

Analysis Workbench

RigPlan

™

WSM

WellScribe

™

PanSystem

®

PanMesh

™

RMS

DTSPlus

™

DynaLift

™

WellFlo

®

LinkBox

™

CygNet® EOP

PetroAtlas

™

DataMart

™

PVTflex

™

CygNet®

Measurement

CygNet®

SCADA

RMS software is highly flexible, scalable data acquisition software that supports Weatherford’s production optimization–reservoir monitoring optical sensing and electronic gauge product lines. RMS software is a combination of embedded software implemented on custom electronic subsystems and application software that is executed on field-hardened Intel computers running a Microsoft Windows operating system. The design approach uses high-level components of Weatherford’s

RMS system for optical sensing systems. A similar architecture supports electronic gauge systems and combined optical sensing and electronic gauge systems. A two-tier architecture fully enables the separation of the data collection activities from the delivery of the results to the acquisition systems. Embedded software resides on the digital signal processor (DSP) of the optical interrogator. The data collection engine (DCE) running on the instrument computer manages the data acquisition process and schedules signal processing algorithms to compute pressure and temperature. The algorithm manager manages the execution of these calculations. Reliable operation of these devices is ensured by Weatherford Launcher, a design component capable of self-health diagnosis and autonomous failure recovery.

What is new for version 2011?

• Build environment move to VS2010

• High level bugs fixes

• Flow algorithm improvements

• Support of new high resolution DTS instrumentation

• Addition of Modbus scanner sensor

• XML output for multi-point array temperature sensing groups

How does this application help improve job performance?

Operators • Extensive communication networks are used to manage the data obtained from oilfield operations

• Implemented using COM/DCOM (distributed component object model) technology which enables software components to communicate

• Enables system administration, maintenance and reliable data access over a local area network or modem

• Client software utilities support basic configuration and diagnostic tasks from remote locations

Engineers Asset engineers can monitor real-time data produced by remote onshore or offshore installations from their shore-based office using extensible web data viewer clients

RMS

®

2011 reservoir monitoring system

(27)

ReO

®

ReO Forecast

™

MatBal

®

Verge

™

LOWIS

™

i-DO

®

Analysis Workbench

RigPlan

™

WSM

WellScribe

™

PanSystem

®

PanMesh

™

RMS

DTSPlus

™

DynaLift

™

WellFlo

®

LinkBox

™

CygNet® EOP

PetroAtlas

™

DataMart

™

PVTflex

™

CygNet®

Measurement

CygNet®

SCADA

Weatherford’s DTSPlus software is a standalone program designed to easily read, view and manipulate temperature profiling data, such as distributed temperature sensing (DTS) and array temperature sensing (ATS). The application is specifically suited for users of temperature profiling and monitoring data in the oil and gas industry. The software runs on Microsoft Windows-based PCs or servers and is capable of single or multiple, simultaneous users. The program can read and write from many different database formats, including open standards formats, WITSML™

and PRODML™

. DTS and point temperature data are easily viewed and manipulated for quick visualization and evaluation of multiple, time-lapse temperature profiles from multiple wells and vendors. DTSPlus software can also be used to identify and select traces that can be used for post-processing and detailed analysis.

What hardware does the application link to?

• RMS reservoir monitoring system

How does this application help improve job performance?

Operators • Detection of gas breakthrough

• Monitoring of water, steam and gas injection performance

• Optimization of gas lift

• Detection of fluid levels

• Identification of well problems such as flow behind casing and detection of leaks

Engineers • Rapid and flexible visualization of temperature profiles, including DTS and ATS

• Data quality control

• Qualitative data interpretation

• Selection of temperature profiling datasets to provide advanced processing software such as PLATO for production profiling analysis

Collaborators • Means to capture, display and print temperature profiling datasets

• Data conversion to/from industry standard formats

DTSPlus temperature profiling software

(28)

ReO

®

ReO Forecast

™

MatBal

®

Verge

™

LOWIS

™

i-DO

®

Analysis Workbench

RigPlan

™

WSM

WellScribe

™

PanSystem

®

PanMesh

™

RMS

DTSPlus

™

DynaLift

™

WellFlo

®

LinkBox

™

CygNet® EOP

PetroAtlas

™

DataMart

™

PVTflex

™

CygNet®

Measurement

CygNet®

SCADA

Weatherford’s RigPlan desktop scheduling tool provides the visualization and control needed to ensure that rigs and assets are effectively used. The user interface offers a multilevel calendar that displays where each rig is currently working, its expected completion time and the time frame for the next scheduled job.

Times are updated based on input from the WSM application in the Field Office™

suite. If a job is running long, the user can see the effect it will have on future jobs and enables rescheduling to better use rigs to avoid unnecessary downtime. The application provides more than just a calendar of scheduled events. Operators using

RigPlan software can take advantage of opportunistic scheduling, meaning that if there is an opening in the schedule a rig can be rescheduled to a nearby job even though it may not be the highest priority task in the queue. It enables the operator to take other factors into consideration such as location of nearby rig and expected time to complete the task verses travel time to a different task. This feature enables all the rigs to be used optimally rather than just executing jobs in the original priority order.

How does this application help improve job performance?

Operators • Schedule rigs based on varying priorities

• Easy-to-use task time line

RigPlan

™

2011 resource scheduling

(29)

ReO

®

ReO Forecast

™

MatBal

®

Verge

™

LOWIS

™

i-DO

®

Analysis Workbench

RigPlan

™

WSM

WellScribe

™

PanSystem

®

PanMesh

™

RMS

DTSPlus

™

DynaLift

™

WellFlo

®

LinkBox

™

CygNet® EOP

PetroAtlas

™

DataMart

™

PVTflex

™

CygNet®

Measurement

CygNet®

SCADA

easy-to-use interface that displays field data in meaningful ways. The data can be combined and displayed to provide simplistic views of complex analysis to real-life issues that occur in producing oil and gas fields.

The application interface, while standard, provides role-based views that encourage operational efficiency by sharing data from its source, and it presents powerful tools and features for each. One system provides multiple roles for mapping, engineering and operations. This flexible software is completely scalable so it can grow as your needs grow.

A clearer production picture

The powerful calculation engine has more than 120 functions. The functions can be linked to create complex

expressions and calculations to accurately describe well behaviors and provide statistical analysis for engineers and field personnel. The software includes recovery and depletion monitoring, validation of remedial work effectiveness and early detection of performance problems.

How does this application help improve job performance?

Operators • Highlight operational work flows

• Pinpoint areas of concern for the asset

Engineers Provides a rich interface for organizing and visualizing engineering and operational data

Collaborators The application creates a collaborative workspace enabling engineers, asset managers and project stakeholders to access critical information in a secure, flexible and shared environment

(30)

Field Office

™

Connectivity

SCADA

–OPC standards –MODBUS protocol

–ProdML production markup language

–PI™ software

–IP21™_{process browser}

Common applications and open standards

–SQL structured query language

–ODBC open database connectivity

–ProdML production markup language

–WITSML wellsite information transfer standard markup language

–Oracle®

relational database management system

–SAP®

integrated exploration and production

–Microsoft Office software

System of record

–WellView®

well information management system

–FieldView™

computational fluid dynamics (CFD) post-processing software

–Finder™_software

–OpenWells drilling morning report software

Well modeling

–ReO Connect™

connectivity software

–Prosper™_{well performance and modeling software}

–RodStar™

design and simulator software

Reservoir modeling

–VIP®_{reservoir simulation suite}

–Eclipse®

reservoir simulation software

The Field Office suite taps into corporate data through standard and

proprietary data links.

PI, IP21, Oracle, SAP, WellView, Finder, Prosper, Rodstar, VIP, and Eclipse are registered trademarks of their respective companies.

(31)
