Knowledge Based Environmental Data Validation

Knowledge Based Environmental Data Validation

, Davide Bognib

, and Sara Manzonia

a

Department of Computer Science, Systems and Communication, University of Milano–Bicocca, Via Bicocca degli Arcimboldi, 8, - 20126 Milan (ITALY), e.mail:[email protected]

b

Project Automation S.p.A., Viale Elvezia, 42 - 20052 Monza (MI)

Abstract: This work describes EcoExpert, a knowledge–based module supporting data validation and inte-grated into a system for environmental data management. The paper describes the integration of knowledge– based system technology and data monitoring networks for environment management purposes by means of influence graphs. EcoExpert has been designed to communicate directly with the air quality monitoring net-work managed by a Pilot Operating Unit. It is considered an example for achieving an integrated environ-ment manageenviron-ment system using knowledge–based technology and qualitative reasoning techniques to solve problems involving data validation, intelligent alarms filtering, network diagnosis, network configuration and maintenance scheduling.

Keywords:knowledge–based monitoring, environmental data management and validation

1 INTRODUCTION

The main aim of this work is to describe a knowledge–based system (EcoExpert) supporting data validation. EcoExpert is integrated into a gen-eral computational framework dedicated to environ-mental data management. In particular, EcoExpert has been designed to support professional staff ded-icated to validate data collected by a network of re-mote pollution data monitoring tools. Data valida-tion consists in two main steps. First, data collected by the remote sensors are processed to identify pos-sible anomalies, representing polluted air situations but also faults in the sensing tools. Then, each iden-tified set of suspect data is correlated to the set of its possible causes, and those not effectively correlated to any cause are invalidated.

Given a set of anomalous data the EcoExpert mod-ule supports the data validation process both in data processing and in finding out chemical, phys-ical or human conditions that could justify the de-tected anomaly. Two types of representations have been adopted for the EcoExpert knowledge base:

influence diagrams and the heuristic knowledge model. Influence diagrams support the numerical– statistical data analysis, describing the relationship among the concentrations of different types of pol-lutants and between the concentration of a pollutant and the state of remote sensing tools. The heuristic

classification model supports the correlation of each anomaly identified in data about pollutants to their possible causes, taking into account the monitor-ing log of the sensmonitor-ing tools, data about atmospheric conditions and other correlated pollutants, and the topology of the network of sensing tools. This rule– based representation models expert knowledge and it has allowed to support EcoExpert users (possi-bly not expert in analysis techniques) in the data validation process. Every day the EcoExpert sys-tem supports the professional staff of various Italian provinces and regions in validating data collected the previous day by a network of sensing tools and in justifying eventually identified anomalies. In the last few years, many different information technology applications have focused on environ-mental issues. Operators in the field have shown a growing interest in solutions designed to assess, prevent, and reduce the impact on the environment of human activities, or to monitor environmental conditions (Gerelli [1990], Lekkas et al. [1994]). Given the complexity of the processes to be ana-lyzed and the number of factors involved, decision– makers can gain considerable advantage from using automatic tools currently available to support some of the work deriving from the intricate panorama of environmental management (Guarisio and Werth-ner [1989]). Moreover, information technology pro-vides a testing ground for simulations that is free of all the time/cost restrictions and risks that real

ex-periments would involve.

The basic problems facing environmental manage-ment today include:

acquisition of data that are relevant to the problem (dynamic and/or static);

data organization and storing in order to make it easily readable;

reasoning over it with the aid of knowledge– based techniques or predefined models in or-der to recognize dangerous situations, iden-tify the causes of specific environmental degradation, predict the impact of human ac-tivities on the environment, and planning of urban and industrial development.

We can picture the technology for environmental control as a pyramid, where the base is made of telecommunication technologies, with monitoring networks collecting data about weather and pollu-tion condipollu-tions. Data acquired in this way are trans-mitted to supervision centers, and, if needed to op-erators and users.

Database management systems and geographical in-formation systems (GIS) technologies form the next level up. In this level, data required for environ-ment manageenviron-ment are organized and made easily readable by other system components and by sys-tem users; such data include:

meteorological data (rainfall, solar radiation, air temperature, relative humidity, wind speed and direction, hydrometric level, and so on); pollution data (e.g., concentration of S0

2, NO

2,

CO, Suspended Particles, hydrocar-bons);

static data (e.g., residential and industrial buildings, census data, regulations, land reg-isters);

information system management and mainte-nance data.

The third level of the pyramid is concerned with the problems that arise once the data provided by the lower levels have been processed. The work at this level is the most critical for environmental control organizations, since it requires the competencies of a highly qualified and experienced professional staff. The main activities of this staff can be summa-rized in: validating incoming data from the network, making network diagnoses, planning maintenance

work on monitoring and network instrumentation, summarizing, elaborating and presenting the data in a differentiated way to the users (local admin-istrators, engineers, operators, the public), making environmental impact assessments, studying corre-lations among different pollutant factors, propos-ing regulations, designpropos-ing and constantly updatpropos-ing a network configuration that best represents the reali-ties to be examined, selecting the most appropriate models (e.g., economic, physical, ecological, mete-orological).

People performing this work need great experience. This is the reason why these issues are suitable for the application of expert system technology, which enables knowledge and qualitative reasoning to be treated as data. In this way, a greater degree of ab-straction that is essential for dealing with this kind of problem can be obtained. As a matter of fact, the role of expert systems as integration tools in het-erogeneous automation environments is increasing (Terplan [1986]).

In this paper we present an experience in this field, concerning the automation of data validation, that is one of the most critical jobs immediately deriv-ing from data collection. Data validation concerns checking whether data coming from a network are correct and reliable. The work was done for Pilot Operating Units (UOP) which run air quality data monitoring networks in heavily polluted urban ar-eas, with the development of an expert system (Eco-Expert), designed to validate data concerning air quality.

2 THE DATA VALIDATION PROBLEM All the work concerning environmental manage-ment is first of all based on data concerning pol-lution levels and atmospheric conditions in a given area. These data are automatically collected by a monitoring system and sent to the UOP supervisory center where they undergo validation checks. Vali-dating means checking whether the data recorded by remote sensors in the field and sent to the supervi-sory system are not affected by errors. In particular, data collected by the network monitoring system are validated every day, and a report providing a sum-mary of the condition of air pollution of a given area is sent to many different public and private institu-tions.

The data validation of daily data, collected in twenty–four hours, can be divided in three distinct stages:

1. Numerical–statistical processing of the recorded data according to conformity

cri-teria, such as: maximum hour test, high difference test, spike test, high consecutive four hours test, and flat series test (the first four points are suggested by the Environmen-tal Protection Agency (Agency [1978])). The aim of this stage is to single out any odd– looking data needing further investigation. 2. Trying to find out the cause of the

numeri-cal difference in the suspicious data accord-ing to various possible causes (type, loca-tion and condiloca-tions of the instruments, atmo-spheric conditions, and so on) before defi-nitely declaring the data not valid. The fac-tors, that are considered in order to explain the odd values obtained for the suspicious data, vary significantly according to the type of pollutant in question (e.g., monitoring site, season, time of day, type of monitoring in-strument, maintenance history, meteorologi-cal and human factors).

3. If the above operation has not managed to find a cause for the odd–looking data, or if it has identified a malfunctioning of instrumen-tation as the cause, the data are effectively in-validated.

3 THE ROLE OF THE EXPERT SYSTEM It is obviously vital for the UOP and all the oper-ators involved in monitoring and assessing pollu-tion to base their decisions on reliable data. It is therefore essential for the methods and techniques used to collect and validate data to be as simple as possible. On the other hand, such methods must guarantee absolute reliability, so that the data pub-lished and subsequently used for study, modelling and forecasting purposes are undoubtedly correct. At the moment, there is no effective system allow-ing to diagnose any possible problem on the mon-itoring instrumentation or on the network quickly, remotely and automatically. Thus, the reliability of the instruments and, consequently, of the data col-lected can be assessed only with on–site controls. This means that the UOP people have to assess the effective validity of the data measured according to their own experience and knowledge of the measur-ing instrumentation.

The critical nature of the controls made by the UOP is self–explained if one considers the organizations, public authorities and public opinion that base their decisions on environmental data. An expert system dedicated to the support of this community of oper-ators has to preserve the intrinsic nature of the data

needed by operators, and at the same time must inte-grate different tools providing the data. We oriented our choice towards an integrated solution, in order to satisfy the requirements and the specific func-tional requirements. Because of the versatility of the techniques available nowadays in the framework of knowledge–based technologies, we focused our attention on rule–based technologies (for capturing heuristic knowledge) and on a qualitative reasoning approach. The latter choice has been made in order to describe at the conceptual level the knowledge involved, and in order to perform numerical com-putations to obtain data by inference whenever data are not directly available.

3.1 The EcoSystem

EcoExpert belongs to the EcoSystem, an integrated system performing supervision, management and control of an air quality monitoring network. As shown in Figure 1, such a the EcoSystem consists of a set of applications. This applications can be clas-sified according to the task they perform. First, a set of devices are devoted to data acquisition, trans-ferring and storage into a centralized data base (re-spectively, EcoRemote and EcoManager modules). Moreover, other modules are dedicated to network configuration and management (i.e. EcoEdit), data post–computing and reporting (i.e. Analyzer and EcoNet) and data validation (i.e. EcoExpert). The EcoSystem architecture is quite complex and consists of three main levels: central, supervis-ing and peripheral levels. At the peripheral level

a set of monitoring devices are dedicated to data acquisition, analysis and sending to the central level in order to be validated, stored and used as source for pollution reports (supervising level). The EcoRemote module is dedicated to the numerical– statistical analysis of data acquired by the monitor-ing sensors. All the suspicious–lookmonitor-ing data are identified both with numerical analysis tools (e.g., by checking maximum and minimum, standard de-viation of the values) and by comparing the data against predefined threshold values. The EcoMan-ager module manages the environmental data base (i.e. EcoDB) that contains all the relevant static and dynamic data of the system. Static data include net-work configuration data and test configuration data, while the dynamic ones concerns the maintenance data and air pollution concentration data coming from the remote sensing systems. Dynamic data can be updated either at regular predefined inter-vals (e.g., every few hours) or by validation opera-tions, automatically performed by the inference

en-Figure 1: The EcoSystem Architecture.

gine of the EcoExpert module. The user interface of the EcoEdit module allows the management of all the operations involving final users and supports the graphical user interface. It is composed by three main subsystems: the manual analysis and valida-tion sub–system (graphical and numerical), the test configuration subsystem, and the subsystem that re-ports all the activities.

3.2 Heuristic Analysis of Data: the EcoExpert module

A priori, all data collected by the network have to be considered valid. Data transmission and archiv-ing systems are reliable, thus only the correct func-tioning of the sensors that collect and record data has to be analyzed. Unfortunately, network devices do not provide powerful auto–diagnosis capabili-ties, and the remote access to the functional status of the various monitor components is still limited. Thus, the main problem in the development of an automated support in this domain is to determine whether anomalies in the data are actually caused by air pollution or are the effect of the malfunction-ing of the remote sensors. This is the goal of the EcoExpert module.

The software architecture of EcoExpert is character-ized by a main component that manages the com-munication interface (i.e. socket) with the Eco-Manger module in order to receive a set of parame-ters needed for its elaboration (e.g. data to be vali-dated and validation start time). Only after a com-plete set of data has been acquired and stored by the EcoManger, the main component of EcoExpert can acquire data from the EcoDB. The first elabo-ration phase is the numerical–statistical analysis of this data in order to identify specific anomalies. Af-ter the storing of the result of this first elaboration, a second elaboration phase performs the heuristic analysis. The aim of the heuristic analysis is to try to justify every identified anomalies. This task is performed according to correlations among pollu-tant concentrations acquired by different peripheral devices, concerning different pollutants or different time periods. The conceptual model adopted for the representation of the knowledge involved in the heuristic analysis about pollutant correlations will be described in the following section.

4 THE CONCEPTUAL MODEL

If the appearance of anomalous data cannot be ex-plained with enough certainty by a failure of some network sensor, the idea is to, conversely, assume that the data are valid and the network instruments are working properly. Therefore, the system tries to determine whether the presence of suspicious data can be related to physical–chemical and/or human conditions.

4.1 Strategic Knowledge

The physical data validation process consists of an examination of all the data collected, in order to identify and single out all the elements that could be the results of errors or malfunctioning. Once one, or more, anomalies have been identified, the system first checks monitoring instruments. The reason for the anomaly, in fact, might be a failure in the instru-mentation, due to maintenance problems of moni-tors, low monitor reliability, status of the monitor when the measurement was made. For each of these conditions one or more possible causes are selected and checked (for example, an instrument not sub-ject to frequent maintenance, a monitor undergoing maintenance during the measurement), with a pro-cedure that generates and test different hypotheses. If none of the above causes clearly seems to be re-sponsible for the suspicious data, analysis process continues, by suggesting some external situations that might have given rise to the unusual variation of the value recorded. These solutions are based on the information of the experts of the field. In this case, the expert must distinguish between phe-nomena that could justify an increase in the pollu-tant and others that could make it decrease. These phenomena can be classified into accumulation and reduction processes respectively. In both cases the processes may have a physical–chemical or a hu-man origin. The identification of what caused the anomaly in the data may eventually lead to the di-rect invalidation of part the data collected by that particular monitor, depending on the type of cause identified (for example an unreliable monitor), even if the latter had not been indicated as suspect. The knowledge involved in this process has been represented by means of an influence graph (Ad-danki et al. [1991]), which represents data depen-dencies. The nodes of the graph define the possible states of both the concentration of pollutants and the functioning of the remote sensing tools. The nodes can be connected by two types of directed edges:

comparison edgesandverification edges. Compar-ison edges link correlated pollutant concentrations

(i.e., the homogeneous increase of NO2 in urban ar-eas implies the incrar-ease of CO). Verification edges can define both a link between a pollutant value and the state of the remote sensing tool, and between a pollutant set of values and temporized boundary conditions (e.g., time, season).

The influence graph as been developed according to both general domain knowledge (i.e. correlation between pollutants, position of monitoring devices, weather conditions, and so on) and specific and cus-tomized knowledge characterizing each monitoring device. While the first type of knowledge has been acquired from domain expert during the system de-sign, the latter is the result of a second knowledge engineering process that has been performed after the EcoSystem installation. According to user re-quirements, in fact, specific features characterizing some of the devices have been included into the knowledge base of the EcoExpert system. Exam-ples of these features concern, for instance, specific information about device location and information about reliability of network functioning and mainte-nance scheduling that can be customized by system users.

4.2 Heuristic Knowledge

The characterization of the situation identified is correlated heuristically to one or more possible classes of causes (processes) capable of explaining the anomaly in question. By a process of refinement the various hypothetical interpretations are then ex-amined one by one, until the cause or causes at the root of the phenomenon are identified. Once the cause of the phenomenon observed has been iden-tified, the data in question can be classified, by def-inition, as valid or non valid. The classical model for representing this kind of knowledge has been the heuristic classification model (Clancey [1985]). It has been implemented by a rule–based development tool and consists in a separate module which exam-ines the suspect data (coming from the numerical– statistical analyzer) in order to justify the anomalies. In the following, two example rules are shown. The first one represent a typical data validity rule. The aim of this type of rules is to represent conditions (e.g. correlation between anomalous pollutant con-centration and location of the monitoring devices) that can explain an anomaly in acquired data. For instance, the rule below justifies an homogeneous increase of pollutant whose primary source is inten-sive traffic if the monitoring device is characterized by intensive traffic at the time of data acquisition.

Under this conditions the system judges as a nor-mal case of pollutant accumulation the high increase in the pollutant concentration. Conversely the sec-ond rule is a typical non–validity rule. In this case a problem in the monitoring tool and in its main-tenance is defined as the cause of an increase of pollutant concentration if it not contemporaneously present an increase of concentration of pollutants characterized by the same primary source.

RULE m: A Data Validity Rule IF

at time t a homogeneous increase of pollutants belonging to a station is present

AND

the pollutants whose increase is measured have as primary source the condition of intensive traffic AND

the expected time is maximum traffic time THEN

there is a accumulation process

RULE n: A Data Non–Validity Motivation Rule IF

at time t an homogeneous increase of pollutants is present

AND

the pollutants whose increase is measured have as primary source the condition of thermal plants AND

homogeneous increases of correlated pollutants are not monitored

AND

the station is in a rural area THEN

there is a problem in the monitoring tool maintenance

5 CONCLUSION AND FUTURE DEVEL-OPMENTS

The EcoSystem is an example of an integrated sys-tem for the environment, which, alongside the typ-ical environmental monitoring and control system functions (remote monitoring, data archiving and presentation), provides new facilities which make the system a real and valuable aid at all stages of environmental management. Moreover the EcoEx-pert module confirms that exEcoEx-pert system technology is able to provide concrete solutions to problems with high intrinsic complexity, that require great ex-perience from human experts and that lack com-plete theoretical structuring; such characteristics are typical of the problems surrounding environmental management, starting from the task of validating au-tomatically monitored data.

The technology involved into the EcoSystem are the ones commonly available, and specifically:

hardware consists of high quality Per-sonal Computers with multitasking oper-ating system (Windows 3.11 characteriz-ing the original system configuration has been recently upgraded to Windows 2000 Server/Professional);

software development, with C++ and RAD programming languages (e.g. Visual Basic), has followed the Object Oriented paradigm providing the whole system with modularity, scalability and high configurability;

communication protocols between applica-tions, even on various supports (serial link, local network, and so on), are all based on the TCP/IP standard;

the Data Base Management System is based on the relational model.

Following the successful outcome of this first step, and in view of achieving the system, EcoSystem will shortly be equipped with further expert func-tions such as routine and extraordinary network management, automatic, daily generation of work schedule for maintenance staff, intelligent alarm tools.

REFERENCES

Addanki, S., R. Cremonini, and J. Scott. Graphs of models.Artificial Intelligence, 51, 1991.

Agency, E. P. Screening procedures for ambient air quality data.Technical Report, 1978.

Clancey, W. J. Heuristic classification. Artificial Intelligence, 27:289–350, 1985.

Gerelli, E. Ascesa e declino del business ambien-tale. Ed. 11 Mulino, 1990.

Guarisio, H. and Werthner. Environmental decision support systems.Ellis Horwood Limited, 1989. Lekkas, G. P., N. M. Avouris, and L. G. Viras.

Case–based reasoning in environmental monitor-ing applications. Applied Artificial Intelligence, 8, 1994.

Terplan, K. Expert systems for network operational control.Proceedings of CMG–USA, 1986.
