Super-Simple-Play-Pals.pd

(1)

Full Size

Wood Toy

Scroll Saw

Patterns

Super Simple

Play Pals

VW Bug

Bat Car

Mini Van

Pickup

Trailer Truck

VW Bug 1-1/4” x 1-5/8” x 3-5/8” Tractor Trailer 1-1/4” x 2” x 6-5/16” Mini Van 1-1/4” x 1-3/4” x 3-11/16” Pickup 1-1/4” x 1-3/4” x 3-9/16” Bat Car 3/4” x 1-9/16” x 3-5/8” Pickup 1-1/4” x 1-3/4” x 3-9/16”

(2)

The Super Simple Play Pals are extremely easy

to assemble. Use the line full size Plan View line

drawings on page 9 for placement of trailer bed and

hitch. The axles are inserted into the vehicle bodies

and then the wheels are glued to the ends of the

axles. The axles are not glued to the bodies and are

designed to rotate freely within the axle holes.

The wheels are available at stores like

Hobby Lobby and online at great prices.

Visit craftparts.com to order item number

MW0750

Mini Wheel 3/4” dia. w/3/16” Hole

Actual Size

(3)

Warning: Read before copying.

The plans and patterns in this planset can

be photo-copied for your personal use when

building the toys. ToymakingPlans.com plans

and patterns are copyrighted and cannot

legally be copied, distributed or shared with

anyone for any other purpose.

The unauthorized reproduction or distribution of this copyrighted work is illegal. Criminal copyright infringement including infringement without

monetary gain, is investigated by the FBI and is punishable by up to 5 years in federal prison and a fine of $250,000.

ToymakingPlans.com is dedicated to providing you with the information

and ideas you need to develop your skills as a toymaker. We welcome your comments and any suggestions about this collection of toy plans.

Email: [email protected]

Note to the Readers: Due to different conditions, tools, and

individual skills, ToymakingPlans.com assumes no responsibility for any damages, injuries suffered, or losses incurred as a result of following the information published in this plan set. Before beginning any project review instructions carefully. If any doubts or questions remain consult local experts or authorities.

Copyright Information: Plans and patterns in this Plan Set

can be photo-copied for personal use when building the toys. ToymakingPlans.com plans and patterns are copyrighted and cannot be distributed or shared for free or for any other reason.

Make as many of each toy as you like! The

wood toys in this plan set are royalty-free.

You have the right to build any quantity of

these toys for any reason.

Color & Natural Wood Pictorial Views ... 4-5

Patterns Index and Full Size Plan Views ... 6-9

Full Size Patterns of All Play Pal Vehicles ... 10-15

Retail and Shipping Box Information ... 16

Printable Retail Box Labels ... 17-18

Gallery Photos ... 19-22

FULL-SIZE

SCROLL SAW PLAN SET

Super Simple

(4)

Painted toys are MDF (medium density fiberboard) or fine grained hardwoods to make a smooth base for a glossy surface. Finish is

spray can color glosses over white primer. First apply 3 coats of primer sanding each coat with 220 sandpaper when dry. Then apply

3 coats of gloss paint sanding each coat with 400 sandpaper when dry. Apply final coat of gloss clear. Do not sand final coat. Note: All

Rust-Oleum and Krylon paints and finishes are non-toxic when dry.

(5)

Baking the wood creates a safe but noticeable odor. As an alternative to baking the wood in your kitchen oven on a porch or deck. Used toaster ovens are available on Craigslist.org.

Step1: Pre-heat the oven to 400 degrees Fahrenheit or 200

degrees Celcius.

Step 2: Place the parts to be tinted on a cookie sheet and place it

in the oven. The dark tone requires one hour in the oven. The light tone requires 1/2 hour in the oven. For darker tones increase the oven time. For lighter tones decrease the oven time.

Step 3: Remove tinted parts from oven and let cool until warm to

the touch.

Step 4: Apply Cynthia’s Paste Wax Finish. The home-made formula

and How-To Video is on our website at www.toymakingplans.com.

Obtain tints from light to dark

on any wood without staining.

(6)

pg 11 pg 10 pg 12 pg 15 pg 13 pg 14 pg 17 1. 3/4” diameter x 3/16” buy 26 2. 3/16” diameter x 1-1/4” make 13 3. 3/16” diameter x 1/2” make 1 4. 3/4” x 1-3/4” x 3-11/16” make 1 5. 3/4” x 1-3/4” x 3-9/16” make 1 6. 3/4” x 1-9/16” x 3-5/8” make 1 7. 3/4” x 3/4” x 1-15/16” make 1 8. 3/16”–1/4” x 1-1/4” x 3-1/2” make 1 9. 3/4” x 1-7/8” x 3-5/8” make 1 10. 3/4” x 1-5/8” x 3-5/8” make 1

PARTS

LIST

3 1 2 5 4 6 7 10 8 9 1 2 1 2 1 2 1 2 1 2 7 7 8 8 8

NOTE: The quantities of parts in the parts list is for constructing one Play Pals set of 5 vehicles.

NOTE: Part 1 Wheels

3/4” dia. x 3/16” w/ Hole 3/16” dia. www.craftparts.com Item #MW0750

(7)

Super Simple

PLAY PALS

NOTE: All flat parts are sawn from standard thicknesses of premium plywood and lumber found at Home Improvement Centers like Home Depot and Lowes. Dowel stock is sawn from standard diameter dowel stock found at Home Improvement and Hobby Centers.

ACTUAL SIZE

The wheels are available at stores like Hobby Lobby and online at great prices. Visit craftparts.com to order item number

MW0750

Mini Wheel 3/4” D w/3/16” Hole WHEELS 3/4” DIA. X 3/16” HOLE 3/16” DIA. www.craftparts.com Item #MW0750

(8)

Super Simple

PLAY PALS

IMPORTANT NOTE

To preserve printer ink print only the pages required for creating patterns for sawing. The pattern pages are all black line on white and print economically on any computer printer.

0printer scale 1 2 3

ACTUAL SIZE

Tractor Trailer

Plan View

ATTENTION:

THE FULL SIZE PRECISION PLAN VIEWS ARE FOR ASSEMBLY REFERENCE. INDIVIDUAL PATTERNS ON PAGES 10-15. 8 7 8 1 2 1 2 1 2 1 2 1 2 3 9 9 3

(9)

Super Simple

PLAY PALS

ACTUAL SIZE

Mini Van Plan View

Pickup Plan View

Bat Car Plan View

VW Bug Plan View

ATTENTION:

THE FULL SIZE

PRECISION PLAN VIEWS ARE FOR ASSEMBLY REFERENCE. INDIVIDUAL PATTERNS ON PAGES 10-15. 1 2 4 2 2 2 1 ₁ ₁ 1 2 2 1 1 2 2 1 5 6 10 4 6 10 5

(10)

Super Simple

PLAY PALS

IMPORTANT NOTE

ACTUAL SIZE

IMPORTANT NOTE

1/4” dia. hole thru 2 places 1/4” dia. hole thru 2 places 1/4” dia. hole thru” 2 places 1/4” dia. hole thru 2 places 3 8 1 2 8 8 8 7 7 7 7 trailer 1. 3/4” diameter x 3/16” buy 4 2. 3/16” diameter x 1-1/4” make 2 3. 3/16” diameter x 1/2” make 1 7. 3/4” x 3/4” x 1-15/16” make 1

The wheels are available at

stores like Hobby Lobby and

online at great prices.

Visit craftparts.com to order

item number MW0750 Mini

Wheel 3/4” dia. w/3/16” Hole

8. 3/16”–1/4” x 1-1/4” x 3-1/2” make 1 3/16” dia. hole thru 3/16” dia. hole thru 3/16” dia. hole thru 3/16” dia. hole thru Glue trailer hitch pin Part 3

to trailer bed Part 8 Glue trailer hitch pin Part 3

to trailer bed Part 8

Glue trailer hitch pin Part 3 to trailer bed Part 8 Glue trailer hitch pin Part 3

(14)

2. 3/16” diameter x 1-1/4” make 3

Super Simple

PLAY PALS

ACTUAL SIZE

1/4” dia. hole

thru 3 places x 3/4” 3 places1/4” dia. hole 1/4” dia. hole thru 3 places 1/4” dia. hole

x 7/16” deep 1/4” dia. holex 7/16” deep

1/4” dia. hole

x 7/16” deep 1/4” dia. holex 7/16” deep 9 1 2 9 9 9 tractor 1. 3/4” diameter x 3/16” buy 6

The wheels are available at stores like

Hobby Lobby and online at great prices.

Visit craftparts.com to order item

number MW0750 Mini Wheel 3/4” dia.

w/3/16” Hole.

9. 3/4” x 1-7/8” x 3-5/8” make 1

IMPORTANT NOTE

(15)

2. 3/16” diameter x 1-1/4” make 2 Super Simple

PLAY PALS

0printer scale 1 2 3 ACTUAL SIZE 1/4” dia. hole thru 2 places 1/4” dia. hole

thru 2 places x 3/4” 2 places1/4” dia. hole 1/4” dia. hole thru 2 places 10 1 2 10 10 10 vw bug 1. 3/4” diameter x 3/16” buy 4

The wheels are available at stores like

Hobby Lobby and online at great prices.

Visit craftparts.com to order item

number MW0750 Mini Wheel 3/4” dia.

w/3/16” Hole.

10. 3/4” x 1-5/8” x 3-5/8” make 1

IMPORTANT NOTE

(16)

Add a pro-touch to your work with these

labeled and signatured gift boxes. The cartons

are delivered to your door in 3 to 5 days from

www.uline.com. Print out the labels on

pages 17–18 and add your signature. Apply

the labels to the box with permanent spray

adhesive.

Display your

Play Pals in

professional

gift boxes.

Display & Shipping Box Item no. S-417

4” x 3” x 3” www.uline.com

Crinkle Paper is

perfect for a quality touch to add to your gift boxes. It’s available is natural and in bright colors. And it makes a perfect packing material for safe shipping! Item no. S-6118 www.uline.com

PRINTABLE BOX LABELS with

signature line are on pages 17 and 18. The labels print on standard letter size paper and use a minimum of black.

(17)

PLAY PAL

VW BUG

HAND CRAFTED WOOD TOY
