Safety Analysis based on IEC

61508: Lessons Learned and

the Way Forward

Jens Braband SAFECOMP 2006

Overview

ƒ Introduction (IEC 61508 and Railway Applications)

ƒ Definition of Operation Modes

ƒ SIL Allocation and SIL Table

ƒ SIL Capability and Safety Criticality

ƒ Properties and Rigor

ƒ Documentation Issues

Introduction

ƒ IEC 61508 is a basic safety publication for programmable electronic

systems (PES).

ƒ It serves either as a basis for the creation of sector-specific standards

or is applied as it stands.

ƒ It therefore needs to be generic.

ƒ In order to highlight certain problems, we have applied it as it stands to

some simple railway examples (although sector-specific standards do exist).

ƒ Where appropriate, we have also taken account of current proposals

PES: Railway Sector Application Examples Inte rloc king Auto_ma tic tr_ain pro tecti_on sys_tem

System according to IEC 61508 In general, a system consists of:

ƒ equipment under control (EUC): equipment used for manufacturing,

process, transportation, ...:

ƒ an EUC control system

Definition

The way in which a safety-related system is intended to be used, with respect to the frequency of demands made upon it.

Two modes exist:

– low-demand mode: in which the frequency of demands for operation made on a safety-related system does not exceed once per year

or twice the proof-test frequency.

– high-demand or continuous mode: in which the frequency of demands for operation made on a safety-related system exceeds once per year or twice the proof-test frequency.

Note: In the new CD for IEC 61508 the reference to the proof-test frequency has been deleted.

ATP Example

ƒ Automatic train protection (ATP)

system stops the train if the

driver passes a signal at danger (SPAD).

ƒ System safety depends on both

the reliability of the driver and

the ATP system.

ƒ Application example:

Eurobalise (ETCS Level 1)

ƒ Example: Hazard rate of 2x10-6

per train per hour

S afe ty -re la te_d P E S 2 Transparent-data balise 3 Fixed balise 4 Vehicle antenna

5 Interrogator On-board unit with peripheral equipment 1 Lineside electronic unit (LEU)

Problems with Modes of Operation Problems for railway applications:

ƒ Proof-test intervals as in the process industry are often not available,

although diagnostic self-checks may be performed every few minutes.

ƒ The demand rate often depends on the reliability of the human

operator (with him acting as a control system) and the operation profile, so it may be argued that the ATP system is both a low-demand system and a continuous mode system.

ƒ The distinguishing frequency (once a year) is not reasoned and

The Great Question: How Safe is Safe Enough?

Besides general requirements, IEC 61508 provides some 30 pages of informative risk analysis examples, including:

ƒ a typical MIL-STD risk matrix (mixed with ALARP)

ƒ a very simple probabilistic approach

ƒ a general risk graph and

ƒ a kind of three-dimensional risk matrix

This guidance is, however, of little use, as

ƒ the examples cannot be directly applied in any sector.

ƒ it fails to explain how to adapt and calibrate any of the methods.

ALARP as low as reasonably practicable MIL-STD US military standard

Safety Integrity Level Definition Unavailability of safety function? (IEC 61703) Instantaneous hazard rate? (IEC 61703) IEC 61508 – Definition:

SIL Allocation Issues

ƒ Step 1: definition of overall safety target and selection of

appropriate quantitative and qualitative figures

ƒ Step 2: apportionment to ATP, taking into account other

risk reduction factors

PdFH probability of dangerous failures per hour PES programmable electronic system

PFD probability of failure on demand T Proof-test interval

2

T

=

λ

×

λ

×

λ

ATP automatic train protection SPAD signal passed at danger

SIL Definition Problems (1)

ƒ Ambiguous definition of PdFH in IEC 61508 – same concept as

instantaneous failure rate or hazard rate?

Why is the concise terminology of IEC 61703 not used?

ƒ SIL is defined for complete safety functions only, but in practice used

mainly for hardware or software components.

ƒ Strong dependence of the PFD on proof-test intervals

ƒ This leads to contradictions, e.g.

ƒ requirement based on PdFH specifies design of ATP according to

SIL 1,

ƒ requirement based on PFD depends on proof-test interval and

SIL Definition Problems (2)

ƒ According to IEC 61508, the SIL 1 requirement applies to the entire

ATP system, i.e. sensors, communication, PES and actuators.

ƒ However, the PdFH or hazard rate for the PES may be much smaller,

say 2x10-7 _{per train per hour (depending on the apportionment, e.g. by}

FTA).

ƒ Question: Is SIL 1 still sufficient for the sensors, communication, PES

The Way Forward: Integrated SIL Allocation

ƒ Independently proposed and

justified by Sato

ƒ No definition of modes of

operation necessary

ƒ Unified SIL determination

using new metric:

mean time to hazard (MTTH)

λ

λ

μ

λ

2/T

00

10

01

11

λ

Model Evaluation

ƒ Index denotes the initial state

ƒ Model can be explicitly solved

ƒ Result is an explicit solution for MTTH

00 10 00 01 10 01 00

2

2

2

1

1

1

MTTH

T

T

T

MTTH

MTTH

MTTH

MTTH

MTTH

MTTH

+

+

+

=

+

+

+

=

+

+

+

+

+

=

λ

λ

λ

μ

μ

λ

μ

λ

λ

λ

λ

λ

λ

λ

λ

Proposal for a Harmonised SIL Table

ƒ Relates to real-life performance

ƒ Unambiguous SIL determination

ƒ Integrates all relevant parameters into SIL determination

> 10 years 1 > 100 years 2 > 1,000 years 3 > 10,000 years 4 MTTH SIL

Problems: SIL Capability and Safety Criticality (1)

ƒ SIL capability: measure of the confidence that an element safety

function will not fail due to relevant systematic failure mechanisms when the element is used in accordance with the instructions given in its element safety manual

ƒ Safety criticality: extent to which a deviation from the specified

functionality of an element has the potential to create a hazardous situation

ƒ Categories:

ƒ C3: single failure is hazardous

ƒ C2: second (independent) failure is hazardous

ƒ C1: interference free

ƒ Based on the safety criticality category, safety functions may be

Problems: SIL Capability and Safety Criticality (2)

ƒ IEC proposal:

A SIL X element safety function may be implemented by two

(independent) SIL X-1 elements, provided both elements have SIL criticality C2.

ƒ ATP example:

The PES may be implemented by two independent SIL 0 elements, i.e. two (different) PCs with either two separate SIL 0 voters or one common SIL 1 voter.

ƒ So far, no easy concept for SIL combinations has been validated,

and each individual case must be closely scrutinized (e.g. FMEA/FTA, with a very careful consideration of common-cause failures).

ƒ Also, the terminology is misleading (criticality has a different meaning

New Concepts: Properties and Rigor

ƒ IEC 61508-3 has extensive tables for the selection of fault avoidance

measures for particular SILs.

ƒ However, many alternatives are possible:

“Appropriate techniques/measures shall be selected according to the safety integrity level” is a standard note for each table and no rules are imposed on the possible combinations.

ƒ In maintenance, levels of rigor were introduced to assess the

achievement of a property:

ƒ R1: No, or limited, objective acceptance criteria

ƒ R2: Objective acceptance criteria

Properties and Rigor: Example

“However, many factors affect systematic and software safety integrity, and it is not possible to give an algorithm for selecting and combining the

techniques in a way that is guaranteed in any given application to achieve the desirable properties. ….”

Properties and Rigor: SIL Guidance

ƒ While the rigor of a great variety of techniques is evaluated in more

than 10 tables with respect to many properties, no combination or acceptance rules are given for determining what level of rigor (or combined levels) is (are) appropriate for which SIL.

Last, but not Least: Documentation (1)

ƒ The requirements for documentation are fairly general.

For example:

ƒ The documentation shall contain sufficient information …

ƒ In particular, a more detailed structure for safety documentation would

facilitate the cross-acceptance of products in different application sectors.

ƒ The safety case concept, which has improved cross-acceptance in the

Last, but not Least: Documentation (2)

ƒ A standard structure for safety

documentation should be introduced.

ƒ The approach can be supported

with structured notations for safety arguments.

ƒ The Goal Structure Notation

(GSN) should be recommended. 6: Safety Qualification Tests 5: Safety-related application conditions 4: Operation with external influences 3: Effects of Faults 2: Assurance of Correct Functional Operation 1: Introduction TECHNICAL SAFETY REPORT

The Way Forward: Conclusions

ƒ Use mathematically concise, standard terminology which is consistent

(at least) with other IEC standards.

ƒ Abandon the distinction between different operation modes.

ƒ Delete sections on risk analysis or give clear guidance for calibration

of methods.

ƒ Make sure that SIL determination is unambiguous, e.g. by a single

target metric such as MTTH.

ƒ Use only validated concepts and explain them fully.

References

ƒ Braband, J.: Risikoanalysen in der Eisenbahn-Automatisierung,

Eurailpress, 2005 (Risk analyses in railway automation)

ƒ Braband, J.: Ein Ansatz zur Vereinheitlichung der Betriebsarten und

Sicherheitsziele nach IEC 61508, Proc. EKA 2006 (An approach to

the standardisation of operating modes and safety targets in accordance with IEC 61508)

ƒ IEC 61508, Functional safety of electrical/electronic/programmable

electronic safety-related systems, 2000

ƒ IEC 61703: Mathematical expressions for reliability, availability,

maintainability and maintenance support terms, 1999

ƒ Yoshimura, I., Sato, Y., Suyanma, K.: Safety Integrity Level Model for

Safety-related Systems in Dynamic Demand State, Proceedings of the 2004 Asian International Workshop on Advanced Reliability Modeling (AIWARM 2004), Hiroshima, 577–584
